Firetide 1500S 1 User Manual
wireless instant networks™
User Manual
HotPoint 1500S Indoor Wireless Mesh Router
HotPoint 1500S Indoor Wireless Mesh Router
User Manual
HotPoint 1500S Indoor Wireless Mesh Router
Part No. xxxxxx
Copyright Notice
© 2003-2004 Firetide, Inc. All rights reserved.
Trademarks
Firetide, the Firetide logo, Instant Networks, HotPoint are trademarks of Firetide, Inc. All other
trademarks are the property of their respective owners.
ii
User Manual
HotPoint Limited End User Product Warranty
Pursuant to all provisions described herein, Firetide products are warranted for one (1) year from
the date of purchase against defects in the build materials and workmanship. Firetide also
warrants that the Software will materially conform to the documentation supplied by Firetide with
the Software. In the event that the Software fails to materially conform to the documentation and
an authorized Firetide reseller is notified in writing of such failure within the warranty period,
Firetide or its reseller shall use commercially reasonable efforts to promptly correct the
nonconformity. Firetide does not warrant that the use of the Software will be uninterrupted or error
free. Firetide does not warrant that the Products will meet any requirements or specifications of
any End User Customer. This warranty applies to the entire Firetide product, including antennas
and the AC power adapter.
The above warranties are void if the alleged defect cannot be verified by Firetide or if, as
determined by Firetide, the product failure was due to tampering, abuse, misuse, accident,
shipping, handling, or storage; or if the product has been installed, used, or maintained in a
manner not described in the product user manual, if the product has been altered In any way, or If
product serialization has been altered. Any attempt to disassemble or repair the product by
anyone other than Firetide immediately voids this warranty.
This warranty applies only to the original End User purchaser of the product and may not be
transferred to any other individual or entity.
THE FOREGOING ARE THE EXCLUSIVE WARRANTIES APPLICABLE TO THE PRODUCT
INCLUDING THE SOFTWARE, AND THE EXCLUSIVE REMEDY FOR DEFECTS IN THE
PRODUCT. FIRETIDE DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS,
IMPLIED, STATUTORY OR OTHERWISE, INCLUDING BUT NOT LIMITED TO IMPLIED
WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT OR FITNESS FOR A
PARTICULAR PURPOSE. SOME LAWS DO NOT ALLOW THE EXCLUSION OF IMPLIED
WARRANTIES SO TO THAT EXTENT THIS LIMITATION MAY NOT APPLY TO YOU.
In no event will Firetide be liable for any special, incidental, consequential, punitive or indirect
damages whatsoever (including, without limitation, damages for loss of profits, business
interruption, loss of information, or other pecuniary loss) arising out of the use or inability to use
the product or the performance, interruption or failure of the product, irrespective of the cause of
action, even if Firetide has been advised of the possibility of such damages. Firetide's cumulative
liability for all claims arising out of or in connection with this warranty will not exceed the amount
paid by the original End User purchaser to purchase the product. The amounts payable for the
product are based in part on these limitations and these limitations shall apply not-withstanding
the failure of essential purpose of any remedy. Some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, so to that extent the above limitations or
exclusions may not apply to you.
By using the product the original End User purchaser agrees to and is bound by these terms and
conditions.
In the event that a product fails to meet this warranty and Firetide’s authorized reseller is notified
in writing of such failure within the warranty period, Firetide shall, at its own discretion, either
repair the product or replace it with the same or a functionally-equivalent product free of charge.
Replacement products may contain refurbished materials in whole or in part. Firetide will honor
this warranty provided the product is returned through an authorized Firetide reseller or dealer
with shipping charges prepaid, along with a proof of purchase describing the original purchase
date and product serial numbers if applicable. The authorized reseller must acquire a Return
Materials Authorization (RMA) number from Firetide prior to returning any product. Firetide does
not accept shipments of defective products without shipping charges prepaid.
iii
HotPoint 1500S Indoor Wireless Mesh Router
Explanation of Graphical Symbols:
This symbol is intended to alert the user to the presence of important operating,
maintaining and servicing instructions in the literature accompanying the 1500S. Failing to
comply with this instruction may result in electrical shock.
This symbol is intended to alert the user to the presence of important operating,
maintaining and servicing instructions in the literature accompanying the 1500S. Failing to
comply with this instruction may result in a hazard.
DO NOT OPEN THE COVER
•
Dangerous voltages inside.
•
No serviceable parts inside.
•
Refer to qualified service personnel.
•
Unit must be disconnected from power prior to servicing
iv
User Manual
Table of Contents
OTPOINT LIMITED END USER PRODUCT WARRANTY ............................................................................ III
H
Explanation of Graphical Symbols:.................................................................................................. iv
TABLE OF CONTENTS .................................................................................................................................... V
FIRETIDE™ HOTPOINT™ 1500S INDOOR WIRELESS MESH ROUTER........................................................ 1
FIRETIDE INSTANT MESH NETWORK.......................................................................................................... 1
WHAT IS A FIRETIDE MESH NETWORK? .................................................................................................... 1
BUILDING A FIRETIDE MESH NETWORK ........................................................................................................ 2
HOTPOINT MANAGER™ SOFTWARE ......................................................................................................... 5
CONNECTING TO THE MESH....................................................................................................................... 6
CONFIGURING TO THE MESH ..................................................................................................................... 7
CONFIGURING THE TX MODE AND CHANNEL SELECTION ......................................................................... 7
ENABLING SINGLE PORT OPERATIONS...................................................................................................... 7
REMOTE MANAGEMENT OF HOTPOINT MANAGER.................................................................................... 8
POWER ADJUSTMENTS .............................................................................................................................. 8
RESTORING DEFAULT SETTINGS ............................................................................................................... 9
APPENDIX A- CONTACTING FIRETIDE........................................................................................................11
APPENDIX B- TROUBLESHOOTING.............................................................................................................. 12
APPENDIX C- REGULATORY NOTICES ........................................................................................................ 14
APPENDIX C- SPECIFICATIONS.................................................................................................................... 15
v
Firetide™ HotPoint™ 1500S Indoor Wireless Mesh Router
Firetide™ HotPoint™ 1500S wireless mesh routers enable instant deployment of wireless
networks and provide a simple and reliable alternative to standard LAN cabling. Deploy Ethernet
ports anywhere—instantly! HotPoint routers eliminate costly backhaul wiring for wireless access
points and hotspots. In addition, they also enable wireless connectivity for standard networkin g
devices such as computers, printers, access points, surveillance cameras, and Ethernet switches.
HotPoint 1500S wireless mesh routers provide a robust, flexible, and scalable LAN backbone
solution. Because they form automatically without wires, Firetide mesh networks do not require
elaborate site surveys or physical modifications to buildings and workspaces. Network installation
costs will drop dramatically because time consuming wiring between offices, walls, floors and
different buildings is no longer needed. Provisioning is also easy and fast because special
drivers, setup, and interfaces are not required for the equipment you connect to a Firetide instant
mesh network. A simple to use management client is available to configure the mesh for each
network deployment.
Note: The HotPoint 1500S is an indoor only product. Any modification or enhancement of
this product for use outdoors is strictly prohibited.
The HotPoint 1500S routers provide fast and easy indoor network deployment and their extended
throughput ensures higher link performance over longer distances. A Firetide mesh also provides
a portable network backbone, so moving your network is as easy as taking your HotPoint routers
with you to your new site. HotPoint 1500S indoor mesh routers are fully compatible with HotPoint
1500R outdoor mesh routers enabling the mesh to extend to outdoor applications.
HotPoint wireless mesh routers employ a high performance radio (100mW) for optimized network
coverage. Greater throughput between HotPoint nodes enables you to extend your network
applications with services that previously required greater bandwidth over expensive cabling.
Built into a HotPoint are three standard 10/100 Ethernet ports for connecting standard networked
client devices. You can also use one of these ports to link the Firetide mesh network with an
existing wired LAN or to the Internet through a DSL modem or gateway device. The mesh node
can operate freestanding or mounted to a wall. An external transformer supplies power from a
standard 120 volt AC outlet.
Firetide Instant Mesh Network
Firetide developed the Wireless Instant Network, based on the HotPoint Mesh Router, to enable
faster, easier and more affordable network deployment. Firetide’s patented mesh networki ng
technology (FMRP) Firetide Mesh Routing Protocol makes it possible to survey, plan and deploy
an entire network within one day rather than weeks. The Firetide network is also portable. Your
entire network can be relocated simply by taking your HotPoint routers with you to your new
location.
What is a Firetide Mesh Network?
Firetide mesh networks feature a self-configuring, self-healing, multi-hop topology. Because of
these inherent self-organizing properties, a mesh network requires n o manual configuration.
Thus, creating a new network or adding or relocating network equipment is as easy as poweri ng
