39FPD274B-T
User Manual
32 pgs5.58 Mb0

Finlux 39FPD274B-T User Manual

Contents
Safety Precautions ................................................. 2
Preparation ......................................................... 2
Intended Use ...................................................... 2
Power source ...................................................... 2
Positioning the TV ............................................... 2
Power cord and plug ........................................... 2
Moisture and Water ............................................ 3
Ventilation ........................................................... 3
Heat sources and Flames ................................... 3
Headphone Volume ............................................ 3
Wall Mounting (optional) ..................................... 3
Screen ................................................................ 3
Cleaning.............................................................. 3
Environmental Information ..................................... 3
Accessories included .............................................. 3
TV - Features ......................................................... 4
TV Control button & Operation ............................... 4
Viewing the TV ...................................................... 4
Remote Control ...................................................... 5
Using a Conditional Access Module ....................... 7
.............................................. 7
Inserting the Batteries to the Remote ..................... 8
Connect Power & Antenna ..................................... 8
Switching On/Off ..................................................... 8
To Switch the TV On ........................................... 8
To Switch the TV Off ........................................... 8
First Time Installation.............................................. 8
Media Playback via USB Input ............................... 9
Media Browser Menu .......................................... 9
Using the Channel List ......................................... 10
Menu Features and Functions .............................. 12
Menu Features and Functions .............................. 13
Menu Features and Functions .............................. 14
Electronic Programme Guide (EPG) .................... 15
Programme Options.......................................... 15
Recording a Programme ...................................... 15
Timeshift Recording ............................................. 16
Instant Recording ................................................. 16
Watching Recorded Programmes ....................... 16
Recordings Library............................................ 16
....................................... 16
Wired Connectivity................................................ 16
To Connect to a Wired Network ........................ 16
................... 17
......................................... 17
IP Address ........................................................ 17
............................... 18
Connectivity Troubleshooting ............................... 19
Connection is slow ............................................ 19
Distruption during playback or slow reactions .. 19
Using DLNA Network Service ........................... 19
1. Nero Media Home Installation ...................... 19
2. Connect to a Wired or Wireless Network ...... 19
3. Play Shared Files via Media Browser ........... 19
DLNA ................................................................... 19
iPlayer Application ................................................ 20
Digital Teletext ...................................................... 21
Software Upgrade................................................. 21
Troubleshooting & Tips ......................................... 21
No power .......................................................... 21
No picture ......................................................... 21
No sound .......................................................... 21
Remote control - does not operate .................. 21
Recording Unavailable ..................................... 21
USB Is too Slow ............................................... 21
Internet Connection Not Available / DLNA Mode
Not Operating ................................................... 21
Invalid Domain ................................................. 21
.............................................................22
............................................. 22
Internet Browser ................................................... 23
Appendix C: Supported File Formats for USB Media
Appendix F: AV and HDMI Signal Compatibility
(Input Signal Types) .............................................. 28
Mode ................................................................. 17
Wireless Connectivity .......................................... 17
Connecting to a Wireless Network.................... 17
English - 1 -
Safety Precautions
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufcient
magnitude to constitute a risk of electric shock of persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Preparation
Place the device on a solid even surface. For ventilation purposes, leave a free space of at least 10 cm all around the set. To prevent any fault and unsafe situations, do not place any objects on top of the set. Use this device in moderate climates. Operation temperature and operation humidity:
0ºC up to 40ºC, 85% rel. humidity max. (Note: Don’t
block ventilation holes.).
Intended Use
This device is used to receive and display TV
programmmes , as well as to play CDs and DVDs (see
“This device compatible disc types”).The different
connection options make an additional expansion of
the reception and display sources possible (various
external devices). This device is only suitable for
the operation in dry interiors. This appliance is intended solely for private domestic use and may not be used for industrial and commercial purposes.
We exclude liability in principle, if the
device is not used as intended, or unauthorized
modications have been made. To operate your TV in extreme ambient conditions may cause damage
of the device.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Please read these instructions fully
before installing or operating.
WARNING: Never let people (including
children) with reduced physical, sensory or mental abilities or lack of experience and / or knowledge use electrical devices unsupervised.
Children may not recognize dangers of incorrect use! The swallowing of batteries can be fatal. Keep batteries always out of reach of small children. If a battery is swallowed, immediately seek medical attention. Keep the packaging
lms out of reach of children to prevent the risk
of suffocation.
Power source
• The TV should be operated only from a 220-240 V AC, 50 Hz outlet.
• Warning: Do not leave your TV in standby or operating mode when you leave your house.
Positioning the TV
• For ventilation, please leave a clear space of at least 10cm all around the TV.
• Do not block the ventilation openings.
• Do not place the TV on sloping or unstable surfaces,
the TV may tip over.
• To prevent damage to the TV, do not place any objects on top of the TV.
• Only use the TV in moderate climates.
Power cord and plug
• The power cord plug should be easily accessible. If there is lightning or storms, or if the TV is not going to be used for a while (e.g. if going away on holiday), disconnect the TV set from the mains.
• The mains plug is used to disconnect TV set from the mains and therefore it must remain readily operable.
• Do not place the TV, furniture, etc. on the power cord or pinch the cord.
• Handle the power cord by the plug, do not unplug the TV by pulling the power cord.
• Never touch the power cord/plug with wet hands as this could cause a short circuit or electric shock.
• Never make a knot in the power cord or tie it with other cords.
• Power cords should be placed in such a way that they are not likely to be stepped on or provide a trip hazard.
• A damaged power cord/plug can cause re or give
you an electric shock. When damaged it must be
replaced, this should only be done by qualied
personnel.
English - 2 -
Moisture and Water
• Do not use this TV in a humid or damp place (avoid using in the bathroom or near the kitchen sink).
• Do not expose this TV to rain or water, as this may
be dangerous.
• Do not place objects lled with liquids, such as ower vases, on top of the TV. Avoid from dripping
or splashing.
• If any solid object or liquid falls into the cabinet, unplug the TV and have it checked by qualied
personnel before operating it any further.
Ventilation
• The slots and openings on the TV set are intended for ventilation and to ensure reliable operation.
• To prevent overheating, these openings must not be blocked or covered in anyway.
Heat sources and Flames
• Do not expose the TV to direct sunlight or other
heat sources.
• The TV should not be placed near to open ames or
sources of intense heat such as an electric heater.
• Ensure that no open ame sources, such as lit
candles, are placed on top of the TV.
Headphone Volume
• Excessive sound pressure from earphones and
headphones can cause hearing loss, please take care.
Wall Mounting (optional)
• To prevent injury, this TV must be securely attached to the wall in accordance with the installation instructions (if the option is available).
Screen
• Occasionally, a few non-active pixels may appear on the screen as a xed blue, green or red point.
Please note that this does not affect the performance of your product.
• Take care not to scratch the screen with ngernails
or other hard objects.
Cleaning
• Before cleaning, unplug the TV from the wall socket.
• Do not use liquid or aerosol cleaners. Only use a soft, dry cloth.
Environmental Information
This television is designed to consume less energy
to help save environment. You can not only help to
save the environment but you can also save money by reducing your electricity bills thanks to the energy efficiency feauture of this TV. To reduce energy consumption, you should take the following steps:
You can use the Power Save Mode setting, located
in the Picture Settings menu. If you set the Power Save Mode as Eco, the TV will switch to energy­saving mode and the luminance level of TV set will be decreased to the optimum level. Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.
If Picture Off is selected, “Screen will be off in 15 seconds.” message will be displayed on the screen.
Select PROCEED and press OK to continue. The
screen will be off in 15 seconds. If you disable Power Save Mode, Picture mode will be automatically set
to Dynamic.
When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce energy consumption.
Disconnect power when going away for longer time.
It is highly recommended that you activate the Power Save Mode setting to reduce your annual power consumption. And also it is recommended to disconnect the TV from the mains plug to save energy more when you do not use.
Please helps us to save environment by following these steps.
Repair Information
Please refer all servicing to qualied personnel. Only qualied personnel must repair the TV. Please contact
your local dealer, where you have purchased this TV for further information.
Accessories included
Remote Control
Batteries: 2 x AAA
Instruction Book Side AV Connection Cable
English - 3 -
TV - Features
• Remote controlled colour LED TV.
• Fully integrated digital tuner.
• HDMI Inputs are for connecting a device that has a HDMI socket.
• USB input.
• Programme recording.
• Programme timeshifting.
• 1000 programmes.
• OSD menu system.
• Scart socket for external devices (such as DVD Players,
PVR, video games, etc.).
• Teletext.
• Headphone connection.
• Manual tuning.
• Automatic power down after up to six hours.
• Sleep timer.
• Child lock.
• Automatic sound mute when no transmission.
• NTSC playback.
• AVL (Automatic Volume Limiting).
• PC input.
• Plug&Play for Windows 98, ME, 2000, XP, Vista,
Windows 7.
• Game Mode (optional).
• Ethernet (LAN) for Internet connectivity.
• 802.11n built in WiFi Support.
• DLNA.
TV Control button & Operation
The Control button allows you to control the Volume/ Programme/ Source and Standby-On functions of the TV.
To change volume: Increase the volume by pushing
the button up. Decrease the volume by pushing the
button down.
To change channel: Press the middle of the button, the channel information banner will appear on screen. Scroll through the stored channels by pushing the button up or down
To change source: Press the middle of the button twice, the source list will appear on screen. Scroll through the available sources by pushing the button up or down.
To turn the TV off: Press the middle of the button and hold it down for a few seconds, the TV will turn off into standby mode.
Viewing the TV
Menu Access
Press the MENU button on your remote control to
display the main menu screen. Use the “ ” or “ ” buttons to select a menu tab and press the OK button
to select option. Use the “ ” or “ ” or “ ” or “ ” buttons to select or set an item. Press BACK or EXIT or MENU button to quit a menu screen.
Input Selection
Once you have connected external systems to your
TV, you can switch to different input sources. Press
the (source) button on your remote control consecutively to select the different inputs.
English - 4 -
Remote Control
1. Standby: Switches On / Off the TV
2. TV: Displays channel list / Switches among
broadcast types / Switches to TV Source
3. Volume +/-
4. Menu: Displays TV menu
5. OK: Conrms user selections, holds the page (in
TXT mode), views channel list (DTV mode)
6. Back/Back: Returns to previous screen, opens
index page (in TXT mode)
7. Internet: Opens the portal page, where you can reach many web based applications
8. My button (*)
9. Netix: Launches the Netix application.
10. Coloured Buttons: Follow the on-screen
instructions for coloured button functions
11. Language: Switches between sound modes (analogue TV), displays and changes audio/subtitle language (digital TV, where available)
12. Rapid reverse: Moves frames backwards in media such as movies
13. Pause: Pauses the media being played/ Timeshift recording
14. Programme recording
15. Play: Starts to play selected media
16. Stop: Stops the media being played
17. Rapid advance: Moves frames forward in media
such as movies
18. Subtitles: Turns subtitles on and off (where available)
19. Screen: Changes the aspect ratio of the screen
20. Text: Displays teletext (where available), press
again to superimpose the teletext over a normal broadcast picture (mix)
21. Media browser: Opens the media browsing screen
22. EPG (Electronic programme guide): Displays the
electronic programme guide
23. Exit: Closes and exits from displayed menus or
returns to previous screen
24. Navigation buttons: Helps navigate menus, content etc. and displays the subpages in TXT mode when pressed Right or Left
25. Quick Menu: Displays a list of menus for quick
access
26. Info: Displays information about on-screen content,
shows hidden information (reveal - in TXT mode)
27. Programme +/-
28. Mute: Completely turns off the volume of the TV
29. Swap: Quickly cycles between previous and
current channels or sources
30. Numeric buttons: Switches the channel, enters a
number or a letter in the text box on the screen.
31. Source: Shows all available broadcast and content sources
English - 5 -
Using My button 1 (*)
This button’s main function is to run Youtube link.
However, if you want to change this function, you can
press MY BUTTON 1 for ve seconds when on a desired source, channel or link, until the “MY BUTTON IS SET” message is displayed on the screen. This conrms that the selected MY BUTTON is now associated with the selected function. Note that if you perform rst time installation, MY BUTTON 1 will return to its default
function.
Using My Button 2 (**)
Press MY BUTTON 2 for ve seconds when on a desired source, channel or link, until the “MY BUTTON
IS SET” message is displayed on the screen. This
confirms that the selected MY BUTTON is now
associated with the selected function.
Viewing the Connections
HEADPHONE
Connector Type Cables Device
Scart
Connection
(back)
Connection
(back)
SIDE AV
PC/YPbPr
Audio
Connection
(side)
HDMI
Connection
(back)
SPDIF
Connection
(back)
SIDE AV
Side AV
Connection
(side)
VGA
Side Audio/Video
Connection Cable
(Supplied)
AV Connection Cable
(supplied)
PC Audio Cable
(Not supplied)
HEADPHONE
Headphone
Connection
(side)
YPbPr Video
Connection
(side)
YPbPr Connection
Cable (Not supplied)
USB
Connection
(side)
CI
Connection
(side)
NOTE: When connecting a device via the Side AV input, you must use the supplied connection cables to enable connection. See the illustrations above. | YPbPr can be used only when you connect a device that has a YPbPr output through the PC input with YPbPr to PC cable (YPbPr to PC cable is not supplied). When the connection is made, switch to YPbPr source. To enable PC audio, you will need to use PC/YPBPR AUDIO CONNECTION WHITE & RED inputs. | If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.| When receiving DTV channels (Mpeg4 H.264) or while in Media Browser mode, output will not be available via the scart socket. | When using the wall mounting kit (optional), we recommend that you plug all your cables into the back of the TV before mounting on the wall. | Insert or remove the CI module only when the TV is SWITCHED OFF. You should refer to the module instruction manual for details of the settings. Obtain the Conditional Access Module (CAM) and the viewing card by subscribing to Digiturk or D-Smart. Insert the CAM and then the viewing card to the slot that is located in the terminal cover at the rear side of the TV. The module should be correctly inserted, it is impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted.
CAM
module
English - 6 -
Using a Conditional Access Module
IMPORTANT: Insert or remove the CI module only when
the TV is SWITCHED OFF.
In order to watch certain digital channels, a conditional access module (CAM) can be necessary. This module must be inserted in the CI slot of your TV.
1. Obtain the Conditional Access Module (CAM) and the viewing card by subscribing to a pay channel company, then insert those to the TV using the following procedure.
2. Insert the CAM and then the viewing card to the slot that is located in the terminal cover at the rear side of the TV.
3. The CAM should be correctly inserted, it is impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted.
4. Connect the TV to the mains supply, switch on and then wait for few moments until the card is activated.
5. When no module is inserted, “No Common Interface module detected” message appears
on the screen.
You can refer to the module instruction manual for details
of the settings.
CAM
module
Standby Notications
If the TV does not receive any input signal (e.g. from
an aerial or HDMI source) for 5 minutes, the TV will go into standby. When you next switch-on, the following
message will be displayed:
Press OK to continue.
When the Auto Tv Off timeout is reached, the following
message will be displayed on the screen. Select YES
to shut down the TV. Select NO to cancel. The TV will switch off as well, if you do not make a selection on this screen.
If the TV has been left on and not been operated for
4 hours, the TV will go into standby. When you next
switch-on, the following message will be displayed.
Press OK to continue.
English - 7 -
Inserting the Batteries to the Remote
1. Lift the cover on the back of the remote upward
gently.
2. Install two AAA batteries. Make sure to match the + and - ends of the batteries in the battery compartment (observe the correct polarity.)
3. Replace the cover.
First Time Installation
When turned on for the rst time, the “language
selection” menu appears. The message “Welcome please select your language!” is displayed and all
language options are listed alphabetically.
Connect Power & Antenna
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket. After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the mains. Plug the aerial cable into the ANT socket on your TV.
Switching On/Off
To Switch the TV On
Connect the power cord to the 220-240V AC, 50 Hz.
To switch on the TV from standby mode either:
Press the “ ” button, P+ / P- or a numeric button on the remote control.
Press the control switch located on the left side of the TV. The TV will then switch on.
To Switch the TV Off
Press the “ ” button on the remote control or press and hold the control switch on the TV until the TV shuts down, so the TV switches to the standby mode.
To power down the TV completely, unplug the power cord from the mains socket.
Note: When the TV is switched to standby mode, standby LED can blink to indicate that features such as Standby Search, Over Air Download or Timer is active. The LED can also blink when you switch on the TV from standby mode.
English - 8 -
Press the “ ” or “ ” button to highlight the required language, press OK button to select. “First Time
Installation” appears. Use “ ” or “ ” button to set the required country, and press “ ” button to select Search
Type. Use “ ” or “ ” to set the desired search type.
Available search types are Digital and analog, digital
only and analog only. When set, press “ ” to select
Teletext Language. Use “ ” or “ ” button to set the “Teletext Language” and select “Scan Encrypted” using
“ ” or “ ” button. You can set Scan Encrypted as Yes if you want to scan coded stations.
Press OK button on the remote control to continue and the following message will be displayed on the screen.
You can activate Store mode option by using “ ” or “ ” button. If Store Mode is selected, Store mode option will be available in other settings menu and your TV’s features will
be illustrated on the top of the screen. A conrmation
screen will be displayed after selecting the Store Mode. Select YES to proceed.
If Home Mode is selected, Store mode will not be available after the First Time Installation. Press OK button on the remote control to continue and the following message will be displayed on the screen.
Select Yes and the television will search for digital terrestrial TV broadcasts.
Media Playback via USB Input
You can connect a USB hard disk drive or USB
memory stick to your TV by using the USB inputs of
the TV. This feature allows you to play les stored in a USB drive. 2.5” and 3.5” inch (hdd with external power supply) external hard disk drives are supported.
IMPORTANT! You should back up your les before
making any connections to the TV set in order to avoid any possible data loss. The Manufacturer will not be
responsible for any le damage or data loss. It is
possible that certain types of USB devices (e.g. MP3 Players) or USB hard disk drives/memory sticks may not be compatible with this TV. The TV supports FAT32 and NTFS disk formatting but recording will not be available with NTFS formatted disks. Note: While formatting a USB hard disk that has 1TB (Tera Byte)
or more le capacity, you can experience problems
with the formatting process.
Quickly plugging and unplugging USB devices is a very hazardous operation. This may cause physical damage to the USB player and the USB device itself.
Do not pull out the USB module while playing a le.
Media Browser Menu
You can play photo, music, and movie les stored
on a USB disk by connecting it to your TV. Connect a USB disk to one of the USB inputs located on the side of the TV.
NOTE: You can press MENU button to cancel.
After all the available stations are stored, the Channel
List will be displayed on the screen. If you are satised
with the order of channels, press the OK button to quit the channel list and watch TV.
English - 9 -
The USB selection OSD will be displayed on the
screen. Press the MENU button and select the Media
Browser tab by using the Left/Right and OK buttons.
The Main media browser screen will be displayed.
You can display the approprite content by selecting
the Video, Music or Picture tab. Follow the button indications under each on screen menu for media playback features.
Pressing the MENU button while in the Media Browser mode will access the Picture, Sound and Settings menu options. Pressing the MENU button again will
exit from this screen.
You can set your Media Browser preferences by using
the Settings menu.
Loading...
+ 22 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
