FieldServer FS-8700-41 User Manual

-

Driver Version:

1.07

A Sierra Monitor Company

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-41 Simplex Time Recorder

Company - 4100 Computer Port Protocol

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after May 1, 2001

Document Revision: 8

FS-8700-41 Simplex Driver Manual Table of Contents

TABLE OF CONTENTS

1. Simplex Time Recorder Company - 4100 Computer Port Protocol............................. 4

1.1. Supported Panel Types............................................................................................... 4

1.2. Simplex Panel Firmware Revision vs. Supported Functionality ................................... 4

2. Driver Scope of Supply .................................................................................................. 5

2.1. Supplied by FieldServer Technologies for this driver................................................... 5

2.2. Provided by Supplier of 3rd Party Equipment ............................................................... 5

3. Hardware Connections................................................................................................... 6

3.1. Connection to a Simplex 4020 Panel........................................................................... 7

3.2. Connection to a Simplex 4100 Panel........................................................................... 9

3.3. Connection to a Simplex 4100U Panel .......................................................................10

4. Configuring the FieldServer as a Simplex Time Recorder Company - 4100 Computer

Port Protocol Client .......................................................................................................12

4.1. Data Arrays ................................................................................................................12

4.2. Client Side Connection Descriptions ..........................................................................13

4.3. Client Side Node Descriptors .....................................................................................13

4.4. Client Side Driver Tables............................................................................................14

4.4.1. SHOW Response Attributes Driver Table .............................................................14

4.4.2. SHOW Response Attribute States Driver Table....................................................15

4.5. Client Side Map Descriptors.......................................................................................15

4.5.1. FieldServer Specific Map Descriptor Parameters..................................................15

4.5.2. Driver Specific Map Descriptor Parameters ..........................................................15

4.5.3. Timing Parameters ...............................................................................................15

4.5.4. Protocol (Simplex Device) Specific Parameters....................................................16

4.5.5. Map Descriptor Example 1. - Read Point Status ...................................................17

4.5.6. Map Descriptor Example 2. - Use unsolicited messages from the Panel to

determine point status ..........................................................................................18

5. Configuring the FieldServer as a Simplex Time Recorder Company - 4100 Computer

Port Protocol Server......................................................................................................19

Appendix A. Advanced Topics...........................................................................................20

Appendix A.1. Hardware Handshaking................................................................................20

Appendix A.2. Simplex Address Formatting – Specific Keywords .......................................20

Appendix A.2.1. Sim4100_Card Keyword ........................................................................24

Appendix A.2.2. <apoint>.................................................................................................24

Appendix A.2.3. Sim4100_Point Keyword........................................................................24

Appendix A.2.4. Sim4100_sub Keyword..........................................................................24

Appendix A.3. How to use Data Arrays to map to/from Card-Point-Sub addresses.............25

Appendix A.4. Simplex Point Status Data Format ...............................................................25

Appendix A.5. Simulation of the Xpoint command...............................................................26

Appendix A.6. Application Supervision Messages...............................................................26

Appendix A.7. Driver Stats ..................................................................................................26

Appendix A.7.1. How the Driver counts bytes and messages received and transmitted...26

Appendix A.7.2. Driver Exposed Stats .............................................................................27

Appendix A.8. SHOW Function Attributes and Attribute States ...........................................28

Appendix A.8.1. Extending the List of Show Attributes.....................................................31

Appendix A.9. Synchronizing the FieldServer with the Panel ..............................................31

Appendix A.10. Advanced Map Descriptor Example 1 - Errors............................................33

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex Driver Manual Table of Contents

Appendix A.11. Advanced Map Descriptor Example 2. - Read Panel Time.........................33

Appendix A.12. Advanced Map Descriptor Example 3 - Write Panel Time..........................34

Appendix A.13. Advanced Map Descriptor Example 4 - Panel Revision Information...........34

Appendix A.14. Advanced Map Descriptor Example 5 - AckAll ...........................................35

Appendix A.15. Advanced Map Descriptor Example 6 - Silence / Reset .............................35

Appendix A.16. Advanced Map Descriptor Example 7 - Acknowledge a specific point........36

Appendix A.17. Advanced Map Descriptor Example 8 - ClearAll.........................................37

Appendix A.18. Advanced Map Descriptor Example 9 - Earths...........................................38

Appendix A.19. Advanced Map Descriptor Example 10 - Show ..........................................39

Appendix A.20. Using Clist to Write-Through and Store point status from Unsolicited

Messages 41

Appendix B. Troubleshooting Tips....................................................................................42

Appendix B.1. Address Errors.............................................................................................42

Appendix B.2. Driver Limitations .........................................................................................42

Appendix B.3. Resolving Network Addresses above 255....................................................43

Appendix C. Error Messages .............................................................................................44

Appendix D. Pseudo Points ...............................................................................................49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 4 of 58

1. Simplex Time Recorder Company - 4100 Computer Port Protocol

The Simplex Time Recorder Company - 4100 Computer Port Protocol driver allows the
FieldServer to transfer data to and from devices over either RS-232 or RS-485 using Simplex
Time Recorder Company - 4100 Computer Port Protocol.

This driver is designed to connect to a Simplex 4100 panel equipped to support the “4100
Computer Port Protocol” as defined in Simplex’s document 950-004 Revision E dated 28 July

2000. The implementation provides a selected subset of protocol functions and subset of

functionality for each of these selected functions. It is important to note the exclusions and
limitations described in this document.

The driver is a capable of parsing and storing information sent by a panel in the form of
unsolicited messages which are typically generated when there is a state change in the panel or
one of the connected devices. The driver is also capable of polling for point and panel status
data and some additional data such as the panel’s time and revision information. In addition the
driver is capable of setting some control points in the panel – acknowledging and resetting
alarms and writing data (where permitted) to some analog and discrete points.

This is a client only driver and is not capable of emulating a Simplex Panel. Server emulation is
provided for test purposes only and is not supported or documented.

1.1. Supported Panel Types

The driver has been tested against 4020, 4100 and 4100U panels. There is no difference in
the protocol format between the various panels. What changes is the panel firmware version
and with the firmware changes the supported function set changes.

1.2. Simplex Panel Firmware Revision vs. Supported Functionality

This driver was primarily tested against a 4020 panel with firmware revision 9.2. Beta testing
against a 4100 panel with a firmware revision 10.x was also performed.

A grid of firmware revision number and supported functions is provided by Simplex. This
grid is available from Simplex. Request the ‘CPP Revision Compatibility’ Table.

All the functions described in this manual are supported for firmware revisions 10 or higher.
For revisions between 9.2 and 10, the ‘Earths’ and ‘Value’ functions described in this driver
are not supported by the Simplex Panels. For revisions lower than 9.2, then functions
supported need to be determined by trial and error. We are fairly confident that all the
functions supported by version 9x are also supported by versions 8x of the panel firmware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 5 of 58

2. Driver Scope of Supply

2.1. Supplied by FieldServer Technologies for this driver

FieldServer Technologies
PART #

FS-8917-16 Ethernet Cable with pigtail (4020 and 4100 Panels)

FS-8917-07

SPA59132 RS-485 connection adapter
FS-8700-41 Driver Manual.

Description

Ethernet cable with 25 pin male connector. (4100u
Panels)

2.2. Provided by Supplier of 3rd Party Equipment

To enable the 4100 Protocol, the 4100 system, supplied by the user, must have a free RS­232 port dedicated for use with the computer device. In most cases, this is not included in
the base configuration of the product provided by The Simplex Time Recorder Company,
and must be added as a sales option. All 4100 systems limit the number of computer ports
active at one time in a system. To determine the limit for the specific product configuration,
refer to the specific product specifications, or contact a Simplex sales representative.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 6 of 58

3. Hardware Connections

The FieldServer is connected to the Simplex Device’s RS-232 port of device type
"COMPUTER", the following port attributes may be configured specifically for that particular
port:

Ensure that these settings correspond to the settings described in section 4 of this document.

Sim4100 Panel

Setting Default Options

Baud Rate 9600 75, 110, 134.5, 300, 600, 1200, 1800, 2000, 2400, 4800, 9600, 19200
Parity EVEN1 ODD, EVEN, MARK, SPACE, NONE
Data Bits 8 7 or 8
Stop Bits 1 1 or 2

Sim4100U Panel
Setting Default Options

Baud Rate 9600 75, 110, 134.5, 300, 600, 1200, 1800, 2000, 2400, 4800, 9600, 19200
Parity NONE1 ODD, EVEN, MARK, SPACE, NONE
Data Bits 8 7 or 8
Stop Bits 1 1 or 2

The following are the Simplex, recommended connections to be used in cabling between the
4100 and the FieldServer device. For the computer device, the standard EIA signal description,
and the 25 pin (DB25) and 9 pin (DB9) connector assignments are shown.

4100 Host Computer

4100
Port
ATB1

Port
BTB2

DB25 Pin

Signal

8 1 2 TXD → RXD 2 2
6 3 3 RXD ← TXD 3 3
7 2 4 RTS
5 4 5 CTS CTS 5 8
4 5 7 GND ── GND 7 5

Cable

2

RTS 4 7

Signal DB25Pin DB9Pin

1

Odd or Even parity is recommended (by Simplex) to provide additional error detection at the character

level.

2

Note, that if HSHAKE is not used (Simplex Device Setting), the connections between RTS and CTS are

not required

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 7 of 58

assembly.

Chip 4100

RS2120

Terminal Block Markings

3.1. Connection to a Simplex 4020 Panel

Communication Board

Port A =1-5, Port B=6-10.

1=+com(xmt).
2=+com(rts),
3=-com(rcv),
4=-com(cts),
5=gnd,
6=xmt,
7=rts,
8=rcv,
9=cts,
10=gnd,

Card 4020/RS-232/2120 modem ready

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 8 of 58

Serial Connection

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 9 of 58

Net 1

Net 2

3.2. Connection to a Simplex 4100 Panel

WIRE LIST

SIMPLEX 4100
PANEL
XMIT
RCV
GND

SIMPLEX 100

PANEL

PORT B
CONNECTION

GND

CTS

RCV

RTS

XMIT

FS-8917-16

FS-X40
FUNCTION
RX
TX
GND

FROM

RJ45-01
RJ45-08
RJ45-04

P1-P8

P1 P7 R1 P2 R2P3 P4 P5 P6 P8 N1 N2

Tx Rx Tx

P4P1RxP2 P3

TxRx Rx

Tx Rx Tx TxRx Rx

RS232

P7P5 P6

P8 R1

Tx Rx Tx Rx Tx

R2

TxRx RxTx Con

RS485

Tx Rx Con

Sys

Com

10 Base T

ETHERNET

Act

Run

Pwr

(408)-262-2299

SIMPLEX 4100

CONNECTION DIAGRAM

BASE NAME:
FILE NAME: FS-T28700-41 .VSD

DATE: 09/26/07
BY: MN

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 10 of 58

Port B

Pin 2

-

White

Pin 3

-

Blue

Pin 7

-

Green

3.3. Connection to a Simplex 4100U Panel

Port A Front of 4100U Panel

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 11 of 58

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 12 of 58

4. Configuring the FieldServer as a Simplex Time Recorder Company - 4100

Computer Port Protocol Client

For a detailed discussion on FieldServer configuration, please refer to the relevant instruction
manual. The information that follows describes how to expand upon the factory defaults
provided in the configuration files included with the FieldServer (See “.csv” files provided with
the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer
to communicate with a Simplex Time Recorder Company - 4100 Computer Port Protocol
Server.

The configuration file tells the FieldServer about its interfaces, and the routing of data required.
In order to enable the FieldServer for Simplex Time Recorder Company - 4100 Computer Port
Protocol communications, the driver independent FieldServer buffers need to be declared in the
“Data Arrays” section, the destination device addresses need to be declared in the “Client Side
Nodes” section, and the data required from the servers needs to be mapped in the “Client Side
Map Descriptors” section. Details on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.

4.1. Data Arrays

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name Provide name for Data Array Up to 15 alphanumeric characters

Provide data format. Each Data

Data_Format

Data_Array_Length

Example

// Data Arrays

Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200

Array can only take on one
format.
Number of Data Objects. Must
be larger than the required data
storage area.

FLOAT, BIT, Uint16, Sint16,
Packed_Bit, Byte, Packed_Byte,
Swapped_Byte

1-65535

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 13 of 58

4.2. Client Side Connection Descriptions

Section Title

Connections

Column Title Function Legal Values

Port

Baud* Specify baud rate

Parity* Specify parity

Data_Bits*
Stop_Bits*

Protocol
Handshaking* Specify hardware handshaking RTS, RTS/CTS, None

Poll Delay*

Example

// Client Side Connections

Connections
Port, Protocol, Baud, Parity, Handshaking, Poll_Delay
P8, Sim4100, 9600, Even, None, 0.100s

Specify which port the device is connected
to the FieldServer

Specify data bits
Specify stop bits 1

Specify protocol used sim4100

Time between internal polls

P1-P8, R1-R23

110 – 115200, standard baud
rates only.
Even, Odd, None, Mark,
Space

7, 8

0-32000 seconds, 1 second

4.3. Client Side Node Descriptors

Section Title
Nodes
Column Title
Node_Name Provide name for node Up to 32 alphanumeric characters

Node_ID Ad

Protocol Specify protocol used Sim4100

Port

Specify which port the device is
connected to the FieldServer
Required for Simplex4100 Panels.
If not specified then a Simplex
4100/4020 panel is assumed.

PLC_Type*

4020/4100 - panels with firmware
version 9x or earlier.

4100U – panels with firmware
version 10x or later.

3

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

Function Legal Values

This parameter is IGNORED. Special
keywords to define the card-sub-point
are described in section 4.4

P1-P8, R1-R2

3

4100, 4020, 4100U

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 14 of 58

Example

// Client Side Nodes

Nodes
Node_Name, PLC_Type, Protocol, Connection
Device1, 4100U, Sim4100, P8

4.4. Client Side Driver Tables

A driver table is used to extend a table of values/attributes that have been hard coded into
the driver. It is possible to extend the tables using CSV file parameters.

Additional information on the use of these tables may be found in Appendix A.8

4.4.1. SHOW Response Attributes Driver Table

Column Title Function Legal Values

Protocol

sim4100_Attr_Name

sim4100_Attr_Offset

sim4100_Attr_Method

The protocol must be specified on each row
of a driver table.

The SHOW command response consists of
a number of attributes and their current
state/ values.

Use this parameter to add a new attribute to
the table.

If the response contains the attribute defined
above, its current state/value must be stored
at offset x in the associated Data Array.
Use this parameter to define x. Take care to
leave enough space for those attributes
which have multiple values.
This parameter tells the driver how to
convert the current state/value for storage in
the Data Array. For example, the driver
cannot store the state ‘Normal’ . By
specifying method 1, you tell the driver to
use the state descriptor ‘Normal’ in a lookup
table of attribute states to find the value
associated to Normal and to store that
value.

Sim4100

The exact
character
sequence that
must be
specified. May
include an equal
sign.

May not be zero.

1,2,3
May not be zero.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 15 of 58

4.4.2. SHOW Response Attribute States Driver Table

Column Title Function Legal Values

The protocol must be

Protocol

sim4100_Attr_State_Name

sim4100_Attr_State_Value

specified on each row of
a driver table.
Use this parameter to
extend this list of
predefined attribute
states.
This parameter is the
value to be associated
with the ‘name’

Sim4100

Define a state word such as
‘Normal’ and associate a
value using the ‘value’
parameter.

May not be zero.

4.5. Client Side Map Descriptors

4.5.1. FieldServer Specific Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name

Data_Array_Name

Data_Array_Location

Function

Name of this Map
Descriptor
Name of Data Array where
data is to be stored in the
FieldServer
Starting location in Data
Array
Function of Client Map
Descriptor

Up to 32 alphanumeric
characters
One of the Data Array
names from “Data Array”
section above
0 to maximum specified in
“Data Array” section above

RDBC, WRBC, WRBX

4.5.2. Driver Specific Map Descriptor Parameters

Column Title

Node_Name Name of Node to fetch data from

Length of Map Descriptor - must always be
specified.
If the length of the response (such as errors /

Length

Address

earths, show, revision) is not known in advance it
should be set to a value large enough to store to
allow some contingency. If data cannot be stored
because an array is too short the driver will
produce a message in the error log.
Not required. The address is specified by using the card-point-sub
specification described in section 4.4.2

Function Legal Values

4.5.3. Timing Parameters

Column Title Function Legal Values

Scan_Interval Rate at which data is polled >0.1s

One of the node
names specified in
“Client Node
Descriptor” above

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 16 of 58

4.5.4. Protocol (Simplex Device) Specific Parameters

Column Title Function Legal Values

Further notes on
these keywords
are provided in
Appendix A

A keyword which controls the function being

sim4100_func

performed or the type of data being polled /
written.

The Simplex Time Recorder Company - 4100 Computer Port Protocol only uses the
standard 4100 address format of <Card>-<Point>-<Sub-point>. Symbolic addressing is
not supported. The following keywords are used to address devices.

sim4100_Card Simplex Address <Card>

sim4100_Point Simplex Address <Point>

sim4100_Sub Simplex Address <Sub_Type>

Only appropriate when the
sim4100_func=clist.
Controls the write through behavior of the
clist function. See Appendix A.20 for

sim4100_WriteThru*

additional information.
When using the default value then the write
commands are done using the format SET
c-p-s ON/OFF. If the parameter is set to
value then writes are done using the format
SET c-p-s value.
Control the ability of ‘CLIST’ map descriptors

Store_Unsolicited*

to be used to store data from unsolicited
messages. Refer also to Appendix A.20

Ackall, Setd,
Disable, Restart,
Clistall, Clist,
Time, Ctime,
Ack,
Xpoint, Seta,
Super, Show,
Earths, Value,
ClearAll

Further notes
and examples
are provided in
Appendix A

Onoff, value

Yes/No

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

Simplex Device: Card

Perform the 'Computer

List Status' Function to

(in this case) read the

current point status of

the point specified by

card-point-sub. This

function returns fire,

supervisory, trouble....

data. The format of the

returned data is

described in Appendix A

Ignored for the

Simplex protocol

unless the

sim4100_func=ackal

l, clearall,

This identifier

must be the same

as the node name

used to identify

the port connected

to the Simplex

device being

described in this

map Descriptor.

The data is

written into the

array starting at

this position. A

value of zero is

equivalent to the

first position.

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

4.5.5. Map Descriptor Example 1. - Read Point Status

The Data

extracted from

the device is

placed in this

driver

independent

FS-8700-41 Simplex 4100 Driver Manual Page 17 of 58

of one Data Array element to a number indicating the point’s status. The values are described in Appendix A.4. You need one such

This Map Descriptor can be used to poll for the status of a particular point. When the response is obtained the driver sets the value

Map Descriptor for every point whose status you wish to poll. Notes in Appendix A.13 provide more information

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name Length Scan_Interval, sim4100_func sim4100_card, sim4100_point, sim4100_sub

A1, DA_AI3, 0, RDBC, Node_A, 1, 5, Clist, 1, 2, 3

data array.

When used with an Xpoint MapDesc this parameter

means ‘How many sub-points per point ?’

If the value is 10 then the driver uses 10 array locations

for each point. Thus

Point 0: Array locations 0-9

Point 1: Array location 10-19

Point 2: Array locations 20-29 … Thus for this MapDesc. If the Xpoint message is for 1-1-0

then the state will be stored at location 10.

. If the Xpoint message is for 1-2-5 then the state will be

stored at location 25.

Simplex Device: Card

for this card are stored

using this MapDesc.

All point-subpoint data

Set this to zero for xpoint

Driver stores

data from

unsolicited

xpoint

messages

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

status

4.5.6. Map Descriptor Example 2. - Use unsolicited messages from the Panel to determine point

The Data

extracted from the

device is placed in

this driver

independent data

FS-8700-41 Simplex 4100 Driver Manual Page 18 of 58

This Map Descriptor can be used to store point status data when the FieldServer receives an unsolicited message from the Panel

containing point status information (Xpoint messages). The panel sends an Xpoint message each time a point’s status changes to

information. The Map Descriptor’s are passive so they can be used in a joint strategy with the clist function (section 4.4.1) to keep

track of a point’s status. Notes in Appendix A provide more information

any non-normal state. Using these Map Descriptors will ensure that the FieldServer is constantly updated with the latest panel status

function based on the point-subpoint address to determine the array location to store the state for the c-p-s.

One Xpoint Map Descriptor is required for storage of Xpoint messages from each card. For a given card, the driver uses a mapping

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, sim4100_card, sim4100_point, sim4100_sub, Length

A1 DA_AI3, 0 passive, Node_A, xpoint, 1, 0, 10, 1000

array.

FS-8700-41 Simplex 4100 Driver Manual Page 19 of 58

5. Configuring the FieldServer as a Simplex Time Recorder Company - 4100

Computer Port Protocol Server

The driver contains some server side functionality which has been developed to meet
FieldServer’s continuous quality assurance efforts. However, the server side functions are not
documented or supported for customer use. If you have a strong requirement for this
functionality then please contact the Sales and Marketing group of FieldServer.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 20 of 58

Appendix A. Advanced Topics

Appendix A.1. Hardware Handshaking

The driver does not support the Simplex RTS/CTS handshaking model. Therefore deselect
the HSHAKE terminal flag or connect CTS to RTS with a jumper on the 4100 side.

Appendix A.2. Simplex Address Formatting – Specific Keywords

The Simplex Time Recorder Company - 4100 Computer Port Protocol only uses the
standard 4100 address format of <Card>-<Point>-<Sub-point>. Symbolic addressing is not
supported. The following table lists keywords which control the behavior of the FieldServer
with respect to connection to a Simplex device and the permissible values determining the
type of data being read/written.

Keyword Description Function

This command acknowledges all card-point-sub states
based on the values found in the associated arrays.
The FieldServer watches the Data Array to see if we need
to send an ack.

DA element Accepted

Ackall

Ack

Clist

Earths4

1st – ack all
2nd - ack A primary abnormal state
3rd – ack F Fire alarm
4th – ack P Priority 2
5th – ack S Supervisory
6th – ack T Trouble

7th – ack C Control
Set the array element to 1 to initiate the command. The
FieldServer clears the value on completion.
This command allows the user to acknowledge a single
point. The specified Data Array is inspected and the value
of the single element is used to determine which device
state's are ack'd. Refer to Appendix A.4

This command returns the current point status for one
point. Refer to Appendix A.4 and Appendix A.20

This function obtains earth/ground status information from
the panel. Two Data Array elements are used to store the
normal (=1) or abnormal (=2) for each card. The first
element is for the positive ground and the second element
is the negative ground. Where cards do not report both,
the first element of the pair is used.
The array position is obtained by multiplying the card
number by two and adding the offset specified in the Map
Descriptor. Set the length of this Map Descriptor to twice
the value of the maximum card number.

WRBC
Do not specify c-p-s in
the Map Descriptor.

WRBC
Specify c-p-s in the
Map Descriptor.

RDBC
Specify c-p-s in the
Map Descriptor.

RDBC
Do not specify c-p-s in
the Map Descriptor.

4

This driver function used the Simplex ‘CSHOW c-p-s CVAL’ command. It is only supported by panels

with firmware revision numbers greater than 10

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 21 of 58

Keyword Description Function

Stores analog value(s) read from a particular devicewithout
scaling or units. When more than one value is reported the

Value

Show

Setd

Seta

Xpoint

Disable Not Implemented
Restart Not Implemented

Time

driver stores the values in consecutive array elements.
Ensure that the Map Descriptor’s usage of the Data Arrays
is spaced appropriately.
Each type of Simplex device reports a different set of
attributes and attribute states/values. Refer to Appendix
A.8 for more information. The driver analyses the response
from the poll. When an attribute is recognized, the attribute
state is evaluated. If this is recognized then the driver
stores a value, corresponding to the attribute state, at an
array location corresponding to the attribute. 4.4 provides
additional information. The driver can only recognize
attributes and attribute states that it is programmed to
recognize.
Using the information provided in Appendix A.8, set the
length of the Map Descriptor equal to array position of
highest attribute.
Ensure that Map Descriptors using this function do not use
overlapping areas of the Data Arrays. See example in
Appendix A.19.
This command allows the user to manipulate the status
and/or priority of a control point
The port access level must be set appropriately in the
Simplex device otherwise the device returns an error.
This command allows the user to:

• Manipulate the status and/or priority of a control point

• Modify the value of an analog pseudo point.

• Set the sensitivity of a TrueAlarm sensor

• Set the rate-of-rise threshold of a TrueAlarm heat

sensor

• Select the audio channel of a speaker circuit
Point Status Change. This is an unsolicited message sent
automatically by a Simplex device to report a change in
point status. The card-point-sub is used to calculate an
offset into the associated Data Array. Read Appendix A.4 to
understand this better.
The state being reported determines the value being written
into the Data Array. Read Appendix A.5 to understand this
better.

This command sets and displays the time and date in
"user" format.
As a command it sets the hour minute second of the
Simplex device by getting the values from the Data Array
associated with the Map Descriptor. The first element
contains the hour, the second the minute and the third
contains the second. A 24 hour clock is assumed.
As a query, the data is unpacked into the Data Array in the
same format as described above.

RDBC
Specify c-p-s in the
Map Descriptor.

RDBC
Specify c-p-s in the
Map Descriptor.

WRBC
Specify c-p-s in the
Map Descriptor.

WRBC
Specify c-p-s in the
Map Descriptor.

Passive
Specify c-p-s in the
Map Descriptor.

RDBC (Query) or
WRBC (Set)
Do not specify c-p-s in
the Map Descriptor.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 22 of 58

Keyword Description Function

As a command it sets the hour minute second of the
Simplex device by getting the values from the Data Array
associated with the Map Descriptor. The first element

Ctime

Silence

Reset

Revision

Errors

contains the hour, the second the minute, the third element
contains the second, the 4th contains the day of the week,
the 5th contains the month, the 6th contains the day of the
month and the 7th element of the array contains the year
(value 01 indicates 2001). A 24 hour clock is assumed.
As a query, the data is unpacked into the Data Array in the
same format as described above.
Used to send a silence signal to the Simplex device. This
is a triggered command. When the element in the Data
Array associated with the Map Descriptor is set to 1 then
the command is sent to the Simplex device. The driver will
set the value to zero when the command has been
acknowledged.
Used to send a reset signal to the Simplex device.
This is a triggered command. When the element in the
Data Array associated with the Map Descriptor is set to 1
then the command is sent to the Simplex device. The
driver will set the value to zero when the command has
been acknowledged.
Used to request revision information from the Simplex
panel. Use of this Map Descriptor is recommended as it
allows the driver to generate a warning if an unknown
Simplex revision is encountered.
Make sure that the length of the Map Descriptor is sufficient
to store all the revision information. A Length of 200 is
recommended.

Use this keyword to define a Map Descriptor which tells the
driver where to store error messages received from the
Simplex device. The most recent message is stored in the
Data Array specified. Make sure that the Data Array length
is long enough to store enough meaningful information. A
length of 200 is recommended.

RDBC (Query) or
WRBC (Set)
Do not specify c-p-s in
the Map Descriptor.

WRBC
Do not specify c-p-s in
the Map Descriptor.

WRBC
Do not specify c-p-s in
the Map Descriptor.

RDBC
Do not specify c-p-s in
the Map Descriptor.

Passive
Do not specify c-p-s in
the Map Descriptor.
If using RUINET to
monitor the
FieldServer, display
the Data Array
associated with this
Map Descriptor in
‘String’ format so that
you can read the error
message easily. The
driver appends
information about the
Map Descriptor which
generated the error to
make the error more
easily understandable.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 23 of 58

Keyword Description Function

Map Descriptor’s which use this function do two things;
Firstly, they register a c-p-s with the driver.
Secondly they define a Data Array name and element
range that must be set to zero when the ClearAll function is
activated.
Up to 4 c-p-s’s may be registered per FieldServer. These

ClearAll

Warm_Start

Cold_Start Generates a cold restart message. Used to test the driver.

registered points are monitored each time a Clist response
is obtained as well as each time the panel sends an
unsolicited Xpoint message with a state change. If one of
these messages reports a ‘U1’ state for a registered point
then the driver processes all ‘ClearAll’ Map Descriptor’s
and sets all the associated array values to zero.
An example of the use of ClearAll is provided in section

6.12 example 9.
Generates a warm restart message.
Used to test the driver.

Passive
Specify c-p-s in the
Map Descriptor (but
read the notes on the
left)

Used for simulation
only.
Used for simulation
only.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 24 of 58

Appendix A.2.1. Sim4100_Card Keyword

The FieldServer will accept any positive integer number including zero; however, not all
values are valid for Simplex devices. Refer to Note (1).

Many commands and output message contain system point ID fields. These fields
reflect the way a 4100 point (local, external, real, pseudo), is referred to.

There are two basic formats allowed, address format <apoint>, and symbolic format
<spoint>.

In the Simplex device the terminal ADDRESS flag is set (DEFAULT) so that <apoint> is
always used in computer messages; otherwise, the symbolic form is used. The
FieldServer cannot work with symbolic (spoint) addresses.

Appendix A.2.2. <apoint>

Format <card>-<point>-<sub>
Legend:
<card> 4100 card, pseudos included, See note (1)
<point> 4100 point (sometimes slot), See note (2)
<sub> 4100 sub-point (sometime point), See note (2)
Examples:
0-6-6 Master trouble point (LCD trouble)
5-0-1 Typical card status point, card at address 5
3-1-0 Point 1 for card at address 3

Notes:
(1) The following ranges are valid for Simplex Devices:

Card address Card type
0-119 Physical (Hardware) cards
128-143 Digital Pseudo cards
144-159 Analog Pseudo cards
160-175 List Pseudo cards

(2) The range of point and sub-point fields for point addressing is very sparse and
depends on the type of card at that location. Contact Simplex Time Company for details
on point address ranges for specific cards.

Appendix A.2.3. Sim4100_Point Keyword

The FieldServer will accept any positive integer number including zero; however, not all
the values are valid for Simplex devices - see Sections 6.3 and 6.4 for further
information.

Appendix A.2.4. Sim4100_sub Keyword

The FieldServer will accept any positive integer number including zero; however, not all
the values are valid for Simplex devices - see Sections 6.3 and 6.4 for further
information.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 25 of 58

Appendix A.3. How to use Data Arrays to map to/from Card-Point-Sub

addresses

Some commands derive a card-point-sub address by inspecting a FieldServer Data Array.
Others receive data from a device with a card-point-sub address and modify the data in an
array based on the card-point-sub address. This section explains how to make the
connection between an index into a Data Array and a card-point-sub address.

In a simple world the Data Array index would be

Index = card * max point per card * max sub point per point + point * max sub point per point
+ sub
Where max point per card and max sub point per point could be large numbers.

As you can imagine this would require huge sparse Data Arrays. To reduce the Data Array
size the FieldServer uses a mapping algorithm which can be optimized based on the
addresses of the Simplex devices. The map is manipulated by using the
sim4100_card/point/sub parameter values.

Example:

Consider the following Map Descriptor fragment.
… , sim4100_func, sim4100_card, sim4100_point, sim4100_sub, data_array_offset
Xpoint,

If data is received for point <c>-<p>-<s> = 9-0-0
This data will NOT be processed because the card number does not match the value of the
sim4100-card

If data is received for point <c>-<p>-<s> = 10-20-0, however, the data will be processed.
The array location is derived using the following formula (sim4100_sub is to be read as the
“number of sub-points per point”; sim4100_card’s value will be ignored.)
Location = data_array_offset + <p> * sim4100_sub + <s>
= 0 + 20 * 10 + 0 = 200

10,

5, 10, 0

Appendix A.4. Simplex Point Status Data Format

When a point status is obtained the FieldServer will write one byte of data to a Data Array.
The byte will contain the following information. Because each point can report a number it
only makes sense to use Data Arrays that are not bit arrays.

Bit Identifier Description

0 (First Bit) F Fire Alarm
1 P Priority 2
2 S Supervisory
3 T Trouble
4 U Utility
5 C Control
6 D Disable
7 A Primary state (based on point type - F if smoke detector, C if signal

circuit, etc.)

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 26 of 58

Appendix A.5. Simulation of the Xpoint command

The following notes apply only to FieldServer Technologies engineers.
The sim4100_func=xpoint keyword is used to parse unsolicited point status change
messages sent by Simplex devices. For simulation purposes it a wrbc version of this
function has been implemented to test the response parsing ability of the slave portion of the
driver.

Appendix A.6. Application Supervision Messages

Section 7.2 of the Simplex 4100 protocol describes unsolicited messages from a Simplex
device. This sim4100_func=super wrbc command is used to test the driver's ability to parse
these messages.
The 4100 protocol supports a periodic application supervision message. This supervision
poll is performed if the TERMINAL flag POLL is set (COMPUTER DEFAULT). The objective
of the supervision poll is two-fold:

• It is the only periodic message that can be expected to be sent by the 4100, thus
establishing the basis for supervising the line.

• To ensure that all layers of the two systems are operating properly and able to respond
to messages. For example, in a PC implementation that uses a Terminate-and-Stay­Resident (TSR) device driver to implement the protocol, the answer to the supervision
poll should be done in a way such that if the program exits to DOS, the TSR will not
continue to indicate to the 4100 that everything is OK, when in fact, the PC will not be
able to annunciate an alarm.

Appendix A.7. Driver Stats

Appendix A.7.1. How the Driver counts bytes and messages
received and transmitted.

"Ack" messages sent/received by the driver in response to read/write messages are
NOT counted as messages. However, the single byte produced by these messages is
included in the byte count.

The driver does not count DLL layer messages as messages.

The driver counts bytes at the DLL layer. The byte count includes the bytes that wrap
application layer messages, acks and the port supervision and responses messages.
The driver counts messages at the application layer.. This means that if you use
RUINET to monitor the FieldServer and you view the Map Descriptor’s the byte count
stats will always be zero.

Some Map Descriptors require data in the Data Arrays to trigger a write command. An
example is the "Ack" command. The driver does not count one of these messages as
being sent until the array actually triggers a poll to be sent.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 27 of 58

SIM4100_STAT_XPOINT_QUALIFIER_AS_ENUM

Appendix A.7.2. Driver Exposed Stats

The driver is capable of exposing statistics about its behavior in a Data Array. It is
necessary to create a Data Array with name sim4100-stats as per the example below
and it will be updated by the driver. Note that the stat number corresponds to the offset.

Take care not to poke any values into the 1st 10 elements of this Data Array (offsets 0 to

9). Doing so will trigger internal diagnostics and may interfere with normal operation.

A different set of stats is maintained for each connection. Each connection uses 100
elements of the data array. Ensure the array length is large enough if the port number is
large.

Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
sim4100-stats , UINT16 , 1000

At revision 1.07a of the driver and before, no stats had been exposed.

Stat
number

10 SIM4100_STAT_XPOINT_CARD

11 SIM4100_STAT_XPOINT_POINT

12 SIM4100_STAT_XPOINT_SUB

13 SIM4100_STAT_XPOINT_QUALIFIER

14

15 SIM4100_STAT_XPOINT_STATE

16 SIM4100_STAT_XPOINT_ACK_STATE

17 SIM4100_STAT_XPOINT_HOUR

18 SIM4100_STAT_XPOINT_MIN

19 SIM4100_STAT_XPOINT_SEC

20 SIM4100_STAT_XPOINT_DOW

21 SIM4100_STAT_XPOINT_DAY

22 SIM4100_STAT_XPOINT_MONTH

Stats Description

The Card in c-p-s from most
recent xpoint store
The Point in c-p-s from most
recent xpoint store
The SubPoint in c-p-s from
most recent xpoint store
The Qualifier from most recent
xpoint store
The Qualifier from most recent
xpoint store, stored as an
enumeration – See Note1 for
bit states
The reported state from most
recent xpoint store. State
value: 0 FALSE/Normal 1
TRUE/Abnormal
The reported ack state from
most recent xpoint store. Ack
state: *=needs ack, -=acked
(always "-" for U or C states)
The Time from most recent
xpoint store
The Time from most recent
xpoint store
The Time from most recent
xpoint store
The Date from most recent
xpoint store
The Date from most recent
xpoint store
The Date from most recent
xpoint store

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 28 of 58

Stat
number

23 SIM4100_STAT_XPOINT_YEAR

24 SIM4100_STAT_XPOINT_COMBO_STATE_OLD

25 SIM4100_STAT_XPOINT_COMBO_STATE_NEW

Stats Description

Note 1 – Bit States.
Qualifier:
Enum=0 Qual=F Fire alarm state
Enum=1 Qual=P Priority 2 alarm state
Enum=2 Qual=T Trouble state
Enum=3 Qual=S Supervisory state
Enum=4 Qual=U Utility monitor, digital/analog pseudo state
Enum=5 Qual=C Control state (non pseudo)
Enum=6 Qual=D Disable Trouble state

The Date from most recent
xpoint store
A single point could potentially
be active in more than one
state simultaneously. The
driver tracks the combine state
by building a UINT whose bits
indicate the state. This is the
combo state before the update.
See Note 1 for bit states.
A single point could potentially
be active in more than one
state simultaneously. The
driver tracks the combine state
by building a UINT whose bits
indicate the state. This is the
combo state after the update.
See Note 1 for bit states.

Appendix A.8. SHOW Function Attributes and Attribute States

The Show command provides an ASCII response formatted for printing. The driver parses
these messages and converts the data to numbers which can be sent to upstream devices
using another protocol.

The driver performs the following tasks in analyzing the response.

• On a line by line basis from the left, it searches for an attribute against a table of attribute
strings. If an attribute string is found in the line then processing continues. Otherwise
the line is discarded.

• The attribute number is recorded. It will be used to determine the array location where
the attribute state/value will be stored.

• The attribute also determines the state/value extraction method and attempts to
determine the attribute state/value using the appropriate method.

o Method 1: The driver uses a table of attribute states, comparing them to the

remainder of the line. If there is a match the driver stores the value of the
attribute state in the array location determined by the attribute,

o Method 2: The driver looks for (up to three) analog values separated by forward

slashes.

o Method 3: The driver looks for analog values preceded by an equal sign.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 29 of 58

• The driver stores in the first array location the number of response lines which resulted
in attribute data being stored. This information can be used for trouble shooting.

The following table reports the attributes that the driver recognizes. This list may be
extended by changing the configuration. If, for example, the attribute ‘ENABLED STATE’ is
recognized then the state of this attribute will be stored at array location 6.

Attribute Array Position

Not Defined 0
PRIMARY STATUS 1
PHYSICAL STATE 2
RAW STATE 3
ACTIVE STATE 4
ARMED STATE 5
ENABLED STATE 6
UNVERIFIED 7
CURRENT DEVICE 8
DEVICE 9
TEST STATE 10
PRESENT SENSITIVITY SELECTED= 11
PRESENT SENSITIVITY SELECTED = 11
AVERAGE VALUE = 14
AVERAGE VALUE= 14
AVERAGE = 14
AVERAGE= 14
AVERAGE 14
VALUE = 17
VALUE= 17
PEAK= 20
PEAK = 20
TROUBLE THRESHOLD 23
OUTPUT STATE 24
OUTPUT STATUS 25
DETECTOR SOUNDER 26
ALARM TEMPERATURE SELECTED= 27
DETECTOR RELAY 30
TOTAL NUMBER OF TROUBLES 31
NODE MISSING 32
VERSION CONTROL 33
NODE INITIALIZATION IN PROGRESS 34
SIMPLEX SERVICE MODE 35
EARTH GROUND 36
AC POWER 37
BATTERY LOW/DISCHARGED 38
BATTERY CHARGE 39
SYSTEM PSEUDO STATUS 40
NETWORK CARD STATUS 41
CARD TROUBLE STATUS 42
MISCELLANEOUS STATUS 43
RELAY STATUS 44
PRIORITY 45

Method

1
1
1
1
1
1
1
2
1
1
1
2
2
3
3
2
2
2
2
2
2
2
1
1
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 30 of 58

Attribute Array Position

CONTROL STATUS 46
CURRENT (AMPS) 47
CARD MISSING/FAILED 48
CORRECT CARD 49
RS-232 Interface PORT A 40
RS-232 Interface PORT B 41
2120/RS-232 PORT Broadcast Fail 42
CARD MISSING/FAILED 43

Method

1
2
1
1
1
1
1
1

The table below reports the attribute states recognized for attribute method=1.

Attribute State Value Attribute State Value

AUTOMATIC CONTROL 1 ARMED 10
OUTPUT NORMAL 2 ENABLED 11
SELF TEST NORMAL 3 ON-LINE 12
CORRECT DEVICE 4 ENABLED 13
PRIORITY 15 5 NORMAL 14
RANGE NORMAL 6 TROUBLE 15
ALARM 7 OFF 16
SHORT 8 ON 17
SHORT 9 0

Examples:

PHYSICAL STATE SHORT
Driver recognizes ‘Physical State’ as attribute 2 and uses method 1 to evaluate the rest of
the line. Driver recognizes ‘Short’ as attribute state with value 8. Therefore, the driver stores
the number 8 at location 2 in the Data Array.

VALUE=77 / 0% OF ALARM / 1.0% SMOKE
Driver recognizes ‘VALUE=’ as attribute 17 and uses method 2 to evaluate the rest of the
line. Driver stores three values; 77, 0 and 1.0 in three consecutive locations starting at
location 17. Note that there is a gap between attribute 17 and the next attribute in the table
sufficient for storing up to 3 values. Note that a slash separates the three values.

AVERAGE VALUE=75 / ALARM LEVEL=145
Driver recognizes ‘AVERAGE VALUE’ as attribute 14 and uses method 3 to evaluate the
rest of the line. Driver stores two values; 75 and 145 in two consecutive locations starting at
location 14. Note that an equal sign ‘=’ precedes each numeric value.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 31 of 58

Attribute States.

pre-defined list of states.

Appendix A.8.1. Extending the List of Show Attributes

You can extend the list of attributes and attribute states that the driver recognizes by
modifying the configuration CSV file.
The following example adds three attributes and 4 attribute states. If a device reports an
attribute of ‘LIGHT STATE’ as ‘BRIGHT’ then the driver will load array element 32 with
the value 41.

Keyword
starts a new
section of the
CSV file.

Attribute Definitions.
The name will be
stripped of all
spaces between the
last character and

When allocating
offsets, be mindful
of the offsets
already used.

Driver_Table
sim4100_Attr_Name, sim4100_Attr_Offset, sim4100_Attr_Method, protocol
BROKEN , 30 , 1 , sim4100
FIXED , 31 , 1 , sim4100
LIGHT STATE , 32 , 1 , sim4100

Driver_Table
sim4100_Attr_State_Name, sim4100_Attr_State_value, protocol
DIM , 40 , sim4100
BRIGHT , 41 , sim4100

Use values that are not allocated to the

Use a digit.
The three
methods are
described
above.

Protocol must
be defined on
every line.

Appendix A.9. Synchronizing the FieldServer with the Panel

When using the Xpoint function to store point states, each time the panel does a warm-start
it sets all point states to normal and then starts evaluating every single one. Thus, after a
warm start, the FieldServer will receive Xpoint messages from the panel for every point not
in a normal state. This provides one synchronization method. The limitation of this method is
that the Simplex panels do not report when a point’s state changes back to normal. Thus to
maintain the synchronization the upstream device must clear the point to zero once it has
read its abnormal state, i.e. The upstream device should consider the data reported by the
Xpoint function as latched data.

A second method is to connect/reset the FieldServer when there are no points in an
abnormal state.

A third method is poll point states using the Clist function as described in Appendix A.20.
This way the FieldServer states will always be updated. Polling is slow and in a system with
many points it is possible that it may take several minutes to update status information for all
points. Thus combining this method with the use of Xpoint Map Descriptors gives the best
of both worlds. When a point changes to ‘not’ normal, then the FieldServer gets the state
change from the Xpoint function immediately and at the same time synchronization is
assured by the continuous polling.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 32 of 58

A fourth method is provided too. This method allows a range of a data array to be set to
zero when a user specified point reports a normal state. Refer to Appendix A.17 for more
information.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

Must be passive.

Index 1: Minute

Index 2: Second

Index 3: Day of week

Index 4: Day of month

Index 5: Month

Index 0: Hour (24 hour clock)

Most recent error returned by the panel is

stored here. Subsequent errors overwrite

the data in this array.

Index 6: Year (since 2000)

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Appendix A.10. Advanced Map Descriptor Example 1 - Errors

FS-8700-41 Simplex 4100 Driver Manual Page 33 of 58

If an error response is received from the panel then if a Map Descriptor similar to this one is defined, the driver will store the error

message (and some information about the Map Descriptor that caused the error) in the Data Array DA_ERRORS.

It is best to define the DA_ERRORS array as format BYTE and if you use RUINET to monitor this Data Array change the display

format to string so that you can read the error. Refer also to Appendix B.1.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Length

Error_Mapdesc, DA_ERRORS, 0, passive, Node_A, Errors, 200

Appendix A.11. Advanced Map Descriptor Example 2. - Read Panel Time

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Scan_Interval, Length

Time_Mapdesc, DA_TIME, 0, RDBC, Node_A, Time,, 30s, 70

Rdb may be sufficient as this

Index 0: Hour (24 hour clock)

Index 1: Minute

Index 2: Second

Index 3: Day of week

Index 4: Day of month

Index 5: Month

Index 6: Year (since 2000)

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Appendix A.12. Advanced Map Descriptor Example 3 - Write Panel Time

FS-8700-41 Simplex 4100 Driver Manual Page 34 of 58

Use Ctime to set the panel time and date and use Time just to set the hour minute and seconds. If the hour is zero then the driver

does not send a write message to the panel.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Scan_Interval, Length

Time_Mapdesc, DA_TIME, 0, wrbc, Node_A, CTime,, 30s, 7

Time_Mapdesc, DA_TIME, 0, wrbc, Node_A, Time,, 30s, 7

Appendix A.13. Advanced Map Descriptor Example 4 - Panel Revision Information

It is best to define tie DA_REV_INFO array as format BYTE and if you use RUINET to monitor this Data Array change the display

format to string so that you can read the information

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Scan_Interval, Length

Error_Mapdesc, DA_REV_INFO, 0, rdbc, Node_A, Revision, 30s, 200

If location 0 goes non-zero then a silence

message is sent. If location 1 goes non-zero

then a reset message is set.

Driver’s set the trigger back to zero once the

message has been set.

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

2nd – ack A Primary Abnormal State

3rd – ack F Fire alarm

4th – ack P Priority 2

5th – ack S Supervisory

6th – ack T Trouble

Appendix A.14. Advanced Map Descriptor Example 5 - AckAll

FS-8700-41 Simplex 4100 Driver Manual Page 35 of 58

This example illustrates the use of the ‘AckAll’ function. Each time the driver uses this Map Descriptor, it checks the data in the Data

sent when the value is updated.

The 1st element of the Data Array is used to trigger the ack all

Array. If one location is non-zero then the appropriate ack message is sent to the panel. As the function is wrbx, the message is only

Set the array element to 1 to initiate the command. The FieldServer clears the value on completion

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Scan_Interval, Length

AckAll_Mapdesc, DA_ACKALL, 0, wrbx, Node_A, AckAll, 1.0s, 6

Appendix A.15. Advanced Map Descriptor Example 6 - Silence / Reset

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, Scan_Interval, Length

Silence_Mapdesc, DA_TRIGGERS, 0, Wrbx, Node_A, Silence, 1.0s, 6

Reset_Mapdesc, DA_TRIGGERS, 1, Wrbx, Node_A Reset, 1.0s 6

As the function is wrbx, the message is only sent when the value is updated.

received.

Note: When configured as a Server, the driver increments the value in the associated DA element each time a silence/reset is

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Bit 0: F - Fire Alarm Panel

Bit 1: P - Priority 2 alarm state

Bit 2: T - Trouble State

Bit 3: S - Supervisory State

Bit 4: U - Utility Monitor

Bit 5: C - Control State

Bit 6: D - Disable Trouble State

Bit 7: A - Primary Point

Appendix A.16. Advanced Map Descriptor Example 7 - Acknowledge a specific point

FS-8700-41 Simplex 4100 Driver Manual Page 36 of 58

The ackall function can be used to ack all points or all points that are in a particular state. What about if you wish to send an ack

message for a single point. One Map Descriptor is required for each c-p-s combination you require specific acknowledgements for.

The driver checks the array location corresponding to the Map Descriptor. If the value is non-zero then an ack message is sent. The

value is used to determine what kind of ack is sent. As the function is wrbx, the message is only sent when the value is updated.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Length, Scan_Interval sim4100_Func Sim4100_Card, Sim4100_Point, Sim4100_Sub Length

Ack_mapdesc1, DA_ACK, 0, Wrbx, Node_A, 1, 1.0s, Ack, 1, 2, 3, 1

Ack_Mapdesc2, DA_ACK, 1, wrbx, Node_A, 1, 1.0s, Ack, 1, 2, 4, 1

The sim400_func must be

ClearAll.

If 1-2-3 or 1-2-4 go to state U1 then

the dara array regions associated

with both MapDesc’s’ are set to

zero.

created for any clear all c-p-s.

The clear all logic never gets

called until an xpoint store is

done for the c-p-s configured to

An xpoint mapdesc must be

do clearall.

Two different arrays, starting at two

different locations and with two

different lengths will get set to zero

when c-p-s=1-2-3 goes to state U1.

Two different arrays, starting at

two different locations and with

two different lengths will get set

to zero when c-p-s=1-2-3 goes

to state U1.

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Appendix A.17. Advanced Map Descriptor Example 8 - ClearAll

provided as an aid. Typically it is used in conjunction with a pseudo-point programmed into your panel.

sections of one or more Data Arrays.

When you create Map Descriptor’s with the ClearAll function the driver makes a note of the c-p-s. If an Xpoint message is received

from the Panel for the specified c-p-s or you use clist to poll for the state of the c-p-s and the state is U1 then this triggers this

ClearAll action. When the action is triggered the driver sets all array point covered by all Map Descriptor’s with the clearall function to

zero, without consideration of the c-p-s associated with the Map Descriptor.

FS-8700-41 Simplex 4100 Driver Manual Page 37 of 58

normal state you may require a way of synchronizing the FieldServer data to the Panel when everything is normal. This function is

As the Xpoint messages (unsolicited message from the panel reporting c-p-s status changes) only report when a c-p-s goes to a non-

The idea behind this function assumes that there is some point(s) which when they report a state of U1 trigger the driver to clear

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, sim4100_card, sim4100_point, sim4100_Sub, Length

Clear_Mapdesc1, DA_AI, 0, passive, Node_A, ClearAll, 1, 2, 3, 100

Clear_Mapdesc1, DA_2, 50, passive, Node_A, ClearAll, 1, 2, 3, 50

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, sim4100_func, sim4100_card, sim4100_point, sim4100_Sub, Length

Clear_Mapdesc1, DA_I, 0, passive, Node_A, Ack, 1, 2, 3, 100

Clear_Mapdesc1, DA_2, 0, passive, Node_A, Ack, 1, 2, 3, 100

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Appendix A.18. Advanced Map Descriptor Example 9 - Earths

FS-8700-41 Simplex 4100 Driver Manual Page 38 of 58

You can only use this function if the panel firmware version is greater than or equal to revision 10.0. This function uses reads earth /

ground status information from the panel.

If, for example, card 3 reports information then the driver uses array elements 6 & 7 to store information for this card. Obtain the

array location by multiplying the card number by two.

If the card reports positive and negative earth data then the driver stores the positive earth data at location 6 and the negative earth

data at location 7.

If the card reports earth / ground state information without the keywords ‘Positive’ or ‘Negative’ the driver stores the data at location

6.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Length, Scan_Interval sim4100_Func Sim4100_Card

Earth_mapdesc1, DA_EARTHS, 0, rdbc, Node_A, 20, 1.0s, Earths, 1

The driver stores a value of 1 to report normal and a value of 2 to report abnormal.

40 Character Custom Label

Mx-y-2 HEAT DETECTOR

DEVICE ADDRESS: 7-10-2 TYPE: COMBO

IDNET INTERFACE CARD

LOCAL UNIT – MAIN PANEL

UNIT NUMBER: 0 RUI NUMBER: LOCAL

----------------------------------------

PRIMARY STATUS NORMAL

CURRENT DEVICE CORRECT DEVICE

DEVICE ON_LINE

TEST STATE SELF TEST NORMAL

ALARM TEMPERATURE SELECTED= 135 DEG F

VALUE=0 / -41 DEG F

PEAK=0 / -41 DEG F

TROUBLE THRESHOLD RANGE NORMAL

ENABLED STATE ENABLED

UNVERIFIED 0

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Appendix A.19. Advanced Map Descriptor Example 10 - Show

FS-8700-41 Simplex 4100 Driver Manual Page 39 of 58

One Map Descriptor is required for each point whose attributes you wish to ‘show’. The show function reads data that describes the

attributes and the state of each attribute for a single device. Every type of device has a different set of attributes. When the response

is received by the driver, it fills a number of Data Array locations with numeric values that represent the attributes and their states.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Length, Scan_Interval sim4100_Func Sim4100_Card, Sim4100_Point, Sim4100_Sub

Show_mapdesc1, DA_SHOW, 0, rdbc, Node_A, 100, 1.0s, Show, 1, 2, 3

You should reserve at least 100 array locations for each Map Descriptor by setting the length to 100.

By way of example assume that point 1-2-3 is a Heat Detector and the response to the show query is as follows

The driver will load the array DA_SHOW starting at offset zero for up to 100 elements. Using the following tables we determine what

values you can expect for this response.

FS-8700-41 Simplex 4100 Driver Manual Page 40 of 58

Array Position Attribute Value Filled In

0 Not Defined 10 1 !

1 PRIMARY STATUS 14 (Normal) 1 #

2 PHYSICAL STATE ~

3 RAW STATE

4 ACTIVE STATE

5 ARMED STATE

6 ENABLED STATE 11 (Enabled) 1

7 UNVERIFIED 0 1

8 CURRENT DEVICE 4 (Correct Device) 1

9 DEVICE 12 (On_Line) 1

10 TEST STATE 3 (Self test normal) 1

11 PRESENT SENSITIVITY SELECTED

14 AVERAGE

17 VALUE 0 1

18 -41 1

19 *

20 PEAK 0 1

21 -41 1

22 *

23 TROUBLE THRESHOLD 6 (Range Normal) 1

24 OUTPUT STATE

25 OUTPUT STATUS

26 DETECTOR SOUNDER

27 ALARM TEMPERATURE SELECTED= 135 1

30 DETECTOR RELAY

5

Note

Notes:

! The value 10 represents the count of the number of attributes that were extracted from
the response. It is not equal to the number of array locations filled in because some
attributes (e.g. Value) result in more than one array location being updated.
~ The un-filled-in locations are not updated by the driver when this response is analysed
because the attributes corresponding to these locations were not reported in the
response to the query.
* Room for up two three numbers for attributes like value, peak but in this case only two
values are relevant for this device.

5

Locations marked with a 1 are updated when the driver analyses this response

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 41 of 58

Appendix A.20. Using Clist to Write-Through and Store point status from

Unsolicited Messages

From version 1.05 on the functionality of the ‘clist’ Map Descriptor’s has been enhanced.

The ‘Clist’ Map Descriptors can

• Read a point’s status

• Write to a point when a Write-Through is activated

• Store the point status when an ‘xpoint’ unsolicited message is received from the panel.

A Write-Through occurs when a Data Array value that is normally updated by a read (rdbc)
Map Descriptor is updated by some other driver or by using the Ruinet application.

In this case the updated value is written through the read Map Descriptor and the Simplex
4100 driver writes the updated value to the panel. The value is written once only each time
that the Data Array element is updated except when the value is updated by the response to
the read or if the point status is updated when an unsolicited message is received from the
panel.
Ensure that:

• The point is not a read only point

• The Panel’s access level has been set appropriately.

When an unsolicited message is received from the panel it would normally be stored using a
Map Descriptor with the ‘xpoint’ function. (See section 4.5.6) However, if you are polling for the
status of that point using a ‘Clist’ Map Descriptor and if that Map Descriptor has
‘Store_Unsolicited’ set to yes then you must omit the ‘xpoint’ Map Descriptor as the ‘Clist’ Map
Descriptor can be used to store the point status when it is updated with an unsolicited message.
If you have both Map Descriptor’s defined then the result will be unpredictable.

A write command can be sent to a Simplex panel in one of two formats:

1) SET c-p-s ON/OFF (default)

2) SET c-p-s value

Use the sim4100_WriteThru parameter in the CSV to change to the 2nd format.

Even if you are writing to an analog pseudo point using format 1 is suitable because by enabling
the point you force it to take its intrinsic value. By setting the point off you are setting its value to
zero.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 42 of 58

Appendix B. Troubleshooting Tips

Appendix B.1. Address Errors

If the driver produces BAD_ADDRESS stats then do the following

• Read the notes on processing errors. You can see the last error response and a report
of the MD's which received the error response in the error array.

• Alternatively, take a log, open the ASCII version of the log and look for error messages.
Error 2 is the response sent by the panel when it is polled for a point that doesn’t exist.
Find the Error #2's n the log. Now look at the line which precedes the error. It is the poll.
Look to see which point in being polled. Now you know the c-p-s of the invalid point, edit
the configuration and remove the MD which polls for data at that point. When you have
finished editing the configuration, download the modified file and reset the FS for the
changes to take effect.

Appendix B.2. Driver Limitations

• Other than being able to write through a Map Descriptor where the sim4100_func=’clist’ ,
write throughs are not supported by this driver.

• Port expansion is not supported.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 43 of 58

Appendix B.3. Resolving Network Addresses above 255

The Standard format for addressing a simplex point is c-p-s (Card-Point-Subpoint). Each of
these components in the address supports a maximum value of 255. However, when using
an NDU (Network Display Unit), addresses may be supplied in a Card-Address format
where the address value could be substantially larger than 255. In these applications it will
be necessary to convert the Card-Address format into c-p-s format before configuring the
points in the FieldServer.

The formula used to convert between the two formats is as follows:

Card is the same for both formats.
Network Address = ((Point-1)*256) + Sub-Point + 1

This conversion procedure is best illustrated by means of an example:

Example:

Card–Address point supplied = 5-2936

From this we deduce the card number to be 5. The next step is to break the address into
multiples of 256 in order to determine point and sub-point. Since this is also a hex
denominated calculation, an easy way to do this is to convert the value to Hex:

2936 = 0xB78

Now, break out the last two hex numbers for sub-point portion, and use the rest for point
address. So we get:

0xB = 11 = (Point-1)
0x78 = 120 = Sub-Point + 1

Solving this equation, we get:

Point = 12
Sub-Point = 119

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 44 of 58

Appendix C. Error Messages

Error Message Troubleshooting Tip

Sim4100:#1 <card><point><sub>
invalid for ack. Read manual.

Sim4100:#2 RTS has been asserted for
too long. Extend timer, check cable
uses RTS/CTS or reconfig 4100 device
to suppress hardware handshaking
Sim4100:#3 sim4100_chan_init() Init
with null chan.

Sim4100:#4 Unknown sim4100_func in
csv <nnn>

Sim4100:#5 Use Ackall function.

Sim4100:#6 ack/ackall/seta/setd must
be a write.

Sim4100:#7 disable/restart/list not
implemented

Sim4100:#8 Func=Clistall/Clist, wrbc
not allowed
Sim4100:#9 Write ack was not
expected.
Sim4100:#10 Invalid point status
<s><v><a>=(Hex)<%x><%x><%x>
<%c><%c><%c>
Sim4100:#11. Error. Array too short.
rqd= %d( max= %d) act= %d.
MapDesc= <%s> Data Abandoned!
Subsequent msgs suppressed!
Sim4100:#12 Error. Incoming data is being abandoned.

Subsequent message supressed!

Sim4100:#13 FYI. Login Function not
Implemented.

The card-point-sub is being used to derive an array
offset. The calculation requires division by the point
& the sub and one or both of these values are zero.
If RTS-CTS handshaking has been used then this
message is produced if the driver finds that the
RTS has been asserted by the slave device for too
long. The timeout is hard coded at 2.0s.

Requires support from FieldServer Technologies.

The driver has found a value for a sim4100_func
keyword that it does not recognize. Check the CSV
file and read Appendix A.2 of this manual for a list
of legal keywords.
The sim4100_func keyword has been assigned the
value 'ack' but a card-point-sub has not been
specified. It would be better to use the ackall
function instead.
You cannot use the rdbc function with these
keywords. Use a wrbc instead.
You cannot use these keywords at the present
time. If you require one of these functions
implemented call FieldServer Technologies.

These keywords must be used with a rdbc instead.

Please report this error to FieldServer
Technologies.

Please report his message to FieldServer
Technologies noting the values in braces.

Check the CSV file Data Array lengths.

Check the CSV file; there was no matching Map
Descriptor for a message.
Please contact FieldServer Technologies if you
would like this feature implemented.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 45 of 58

Error Message Troubleshooting Tip

A write thru is defined as follows. The FieldServer
reads data from a device and stores it in a Data
Array. If a remote device changes the value in that
Data Array, the FieldServer will write the new value
to the device that is being read. This driver does

Sim4100:#14 MD=%s Addr=%d

not permit write thru's except when the data is
being updated using CLIST. Refer also to Sections

4.5.4, 4.5.6 and Appendix A.20. In versions of the
driver up to and including 1.07a a panic is produced
when this message is printed. The message is
printed to a maximum of 10 times and then

suppressed.
SIM4100:#15 FYI. Incoming
abandoned. No Map Desc.

SIM4100:#16 FYI. No Map Desc.
Respond with Error.

SIM4100:#17 FYI. Incoming
Abandoned. No Data.

SIM4100:#18 FYI. Incoming
Abandoned. (%d)

Check the CSV file; there was no matching Map

Descriptor for a message.

If the server can’t find a matching MD (i.e. the point

being polled for doesn’t exist) then the driver

responds with Simplex Error #2.

Check the driver manual and Simplex User

Manuals. There is no driver response to the

message received.

Please report his message to FieldServer

Technologies noting the values in braces.

No corrective action is required on your part. The

message is printed for your information only.

Sim4100:#19a FYI. Sim4100 Firmware
found (%.2f)

Message ‘a’ is printed when version 9 firmware is

found in the panel.

Message ‘b’ is printed when version 10 firmware is

found in the panel.

Message ‘b’ is printed when version 11 firmware is

found in the panel.

The firmware version found is not one that the

driver explicitly supports. This does not mean the

driver will not work but if a feature of the driver isn’t

working correctly knowing that the firmware version

is not supported may help diagnose the problem
Sim4100:#19d FYI. Panel Firmware
Rev %.2f may be incompatible.

more easily.

No corrective action is required on your part. If

however, some you suspect that the driver is not

operating correctly it is important that you mention

seeing this message in the Error Buffer when

reporting the problem.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 46 of 58

Error Message Troubleshooting Tip

The format of the firmware version information

could not be interpreted correctly. This may mean

that your panel has a firmware version that is not

one that the driver explicitly supports. This does not

mean the driver will not work but if a feature of the

driver isn’t working correctly knowing that the
Sim4100:#19e FYI. Panel Firmware
may be incompatible.

firmware version is not supported may help

diagnose the problem more easily.

No corrective action is required on your part. If

however, some you suspect that the driver is not

operating correctly it is important that you mention

seeing this message in the Error Buffer when

reporting the problem.
Sim4100:#20 FYI. Data abandoned!
Array too short. MapDesc= <%s>
Sim4100:#21. Error. Data abandoned!
Array too short c-p-s= %d-%d-%d

Check the CSV file Data Array lengths.

Check the CSV file Data Array lengths.

Polling is disabled until the port supervision

message has been received. This message can be

Sim4100:#22. FYI. Polling Inhibited.

safely ignored. When the panel sends unsolicited

messages to the FieldServer this message is

printed. Polling remains inhibited until the

unsolicited message stream end.

When a stream of unsolicited messages is received
Sim4100:#23. FYI. Polling Enabled

from the Simplex panel then polling is inhibited until

the stream ends. When the stream ends this

message is printed. It may be safely ignored.
Sim4100:#25. Error. Data abandoned!
Array too short c-p-s= %d-%d-%d
Sim4100:#26 FYI. Data abandoned!
Array too short.(%d) MapDesc=<%s>
Sim4100:#27. FYI. Sequence Number
reset requested & done.
Sim4100:#28. Error. Bad
Sim4100_Func=%d in MD=<%s>

Sim4100:#29. FYI. Length changed to 1
in MapDesc= <%s>
Sim4100:#30. FYI. Length changed to 1
in MapDesc= <%s>
Sim4100:#31. FYI. Length changed to 1
in MapDesc= <%s>
Sim4100:#32. FYI. Sequence number
semi-reset.

Check the CSV file Data Array lengths.

Check the CSV file Data Array lengths.

Check the CSV file and driver manual for valid

Simplex functions.

Check the CSV file for the correct Map Descriptor

function type.

Check the CSV file for the correct Map Descriptor

function type.

Check the CSV file for the correct Map Descriptor

function type.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 47 of 58

Simplex User Manuals, and driver manuals.

No space is available in internal driver table.

No space is available in internal driver table.

Error Message Troubleshooting Tip

Message sequence numbers incorrect. Check
Sim4100:#33. Error. Invalid Seq
Number.

Contact FieldServer Technologies for additional

support.

Message sequence number incorrect. Check
Sim4100:#34. Bad Seq. Sequence
number reset.

Simplex User Manuals, and driver manuals.

Contact FieldServer Technologies for additional

support.
Sim4100:#36. FYI. Bad
sim4100_func=%d in MapDesc=<%s>
Sim4100:#38. FYI. Bad
sim4100_func=%d in MapDesc=<%s>

Sim4100:#39 FYI. Data abandoned!
State not recognized. Mapdesc=<%s>

Sim4100:#40 FYI. Data abandoned!
Array too short.(%d) Mapdesc=<%s>
Sim4100:#41 FYI. Data abandoned!
Array too short.(%d) Mapdesc=<%s>
Sim4100:#43. Err. Can only monitor %d
point(s) for ClearAll
Sim4100:#44 FYI. ClearAll mapDesc's
must be passive
Sim4100:#45 FYI. User added SHOW
attribute=<%s> offset=%d method=%d

Check the CSV file for the correct Simplex function

type.

Check the CSV file for the correct Simplex function

type.

Attribute was found, but State not found in driver

table. Contact FieldServer Technologies for

additional support.

Check the CSV file Data Array lengths

Check the CSV file Data Array lengths

Contact FieldServer Technologies for additional

support.

Map Descriptor function has been changed

automatically

Sim4100:#46 Err. No space. Driver
rejects SHOW attribute=<%s>
offset=%d method=%d
Sim4100:#47 Err. Duplicate. Driver
rejects SHOW attribute=<%s>
offset=%d method=%d
Sim4100:#48 FYI. User added SHOW
attr state=<%s> value=%d

Contact FieldServer Technologies for additional

support.

Duplicate found in internal driver table. Contact

FieldServer Technologies for additional support.

Sim4100:#49 Err. No space. Driver
rejects SHOW attr state=<%s>
value=%d
Sim4100:#50 Err. Duplicate. Driver
rejects SHOW attr state=<%s>
value=%d
sim4100:#51 Err. Length must be
specified and > 0.

Contact FieldServer Technologies for additional

support.

Duplicate found in internal driver table. Contact

FieldServer Technologies for additional support.

Check the CSV file for the length fields.

Check the CSV file for node definitions, Simplex
SIM4100:#52 FYI. Incoming
Abandoned. Node offline

hardware, and connections. A device node

appears to be offline. Contact FieldServer

Technologies for additional support.
Sim4100:#53. Md=<%s> Abandoned.
Polling was inhibited.

Obsolete. Contact FieldServer Technologies for

support.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 48 of 58

Error Message Troubleshooting Tip

Sim4100:#54. Err. SeqNumber check
disabled.

Sim4100:#55. Error. Bad
Sim4100_Func=%d in MD=<%s>

Sequence number checking was disabled. Check

your password. Contact FieldServer Technologies

for support.

Check the CSV file for the correct Simplex function

type.
Sim4100:#56 Not used.

Sim4100:#57* Err. Cant parse Login
message. Ignored.

Sim4100:#58 FYI. You could have used
an Array called <%s> to expose
diagnostic info.

Sim4100:#59 Err. Checkpoint. Report
this to Tech Support.

The driver ignored Login messages. No corrective

action is required. This message is printed for your

information only.

This message is printed for your information only. It

can safely be ignored. For additional information

read section “Appendix A.7.2 Driver Exposed Stats”

An internal driver diagnostic has been triggered.

You must report this error to FieldServer’s

Technical Support.

Every Sim4100 Map Descriptor must be connected

to a node. Ensure that the parameter ‘Node_Name’

Sim4100:#60 Err. MapDesc=%s. No
Node.

has been specified on the Map Descriptor.

To correct this problem, edit the CSV, make the

correction, download the corrected CSV file and

reset the FieldServer.

If you have a Map Descritor which has the

sim4100_func parameter set to ‘earths’ or to

‘values’ then you must set the PLC_Type

parameter on the node to 4100U. (See section 0

Client Side Node Descriptors ). It is only

appropriate to do so if the firmware version of your
Sim4100:#61 Err. PLC_Type=4100u
rqd for 'values'/'earths'

panel is 10.x or later. You can create a map

descriptor to read the version information if you are

not sure. You can also use the menu system on the

Panel to read the version number.

To correct this problem, edit the CSV, make the

correction, download the corrected CSV file and

reset the FieldServer.

This message is printed when the input buffer

overflows. This usually occurs when the panel

sends lots of messages and they are not being

processed by the driver fast enough. A panic is

printed immediate after this message.

Sim4100:#62 Err. Input Buffer Overflow.

The driver will clear the buffer and start capturing

new bytes as they arrive. Messages may have

been lost. We advise that you re-synch the panel.

This error has only been seen once. It occurred

when a panel was connected to the driver with the

wrong connection settings.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 49 of 58

Appendix D. Pseudo Points

It is beyond the scope of the driver manual to describe the full functionality of the Simplex
Panels. However, we have found it useful to provide the following data to customers. The
following information is not maintained and updated therefore you should use it for reference
only and should always consult with the vendor of your Simplex system before implementing
any project decisions or actions based on the information provided in this section.

Pseudo points are points that report states or attributes based on how the Simplex system has
been installed, configured and programmed. They are often programmed to groups, devices,
zones or other logic groupings. For example, a pseudo point may be programmed to report if
and only if more than one sensor in a particular area is reporting smoke.

Every Simplex system has a number of default pseudo points programmed into the firmware
supplied with the panel. These default points depend only on the firmware revision number and
are generally unaffected by the configuration programmed for a particular site.

Although the 4100 card number can range from 0-250 in theory, only the following ranges are
presently used in the system:

Card address Card type
0-119 Physical (Hardware) cards
128-143 Digital Pseudo cards
144-159 Analog Pseudo cards
160-175 List Pseudo cards

Digital Pseudo’s: There are 250 fixed pseudo's in the 4020 panel and 511 in the 4100 and
4100U. The numbering sequence is simple, 128 starts the first block of 256 (0 to 255), so the
first point is 128-0-0, the second is 128-1-0, and so on. The next block starts at 129 and follows
the same sequence, then 130 and so on up to 143. In the 4100 the first user definable pseudo
is P-256, in the 4100U it's P-512.

P0 SYSTEM RESET KEY UTILITY 128-0-0
P1 ALARM SILENCE KEY UTILITY 128-1-0
P2 FRONT PANEL LAMPTEST CONTROL (ANNUNC. 0) UTILITY 128-2-0
P3 FIRE ALARM DETECT UTILITY 128-3-0
P4 GLOBAL ACKNOWLEDGE ENABLE UTILITY 128-4-0
P5 SET SERVICE PSEUDO VALUES UTILITY 128-5-0
P6 ALARM SILENCE UTILITY 128-6-0
P7 EXTRA CARD IN THE SYSTEM TROUBLE 128-7-0
P8 KEYPAD ACTIVE UTILITY 128-8-0
P9 SYSTEM OUT OF CQB'S TROUBLE 128-9-0
P10 CODED INPUT ACTIVE UTILITY 128-10-0
P11 UNACKNOWLEDGED FIRE ALARM EXISTS UTILITY 128-11-0
P12 UNACKNOWLEDGED SUPERVISORY EXISTS UTILITY 128-12-0
P13 UNACKNOWLEDGED TROUBLE EXISTS UTILITY 128-13-0
P14 SYSTEM DISABLED - PROGRAMMER DOWNLOAD TROUBLE 128-14-0
P15 CFIG RAM WRITE PROTECT MISSING (SW1-1) TROUBLE 128-15-0
P16 SMPL PROGRAM 0 - SYSTEM DEFAULT UTILITY 128-16-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 50 of 58

P17 SMPL PROGRAM 1 - DEFAULT AUDIO UTILITY 128-17-0
P18 SMPL PROGRAM 2 - SYSTEM OPTIONS (CODING) UTILITY 128-18-0
P19 SMPL PROGRAM 3 - USER CUSTOM CONTROL UTILITY 128-19-0
P20 SMPL PROGRAM 4 - USER CUSTOM CONTROL UTILITY 128-20-0
P21 SMPL PROGRAM 5 - USER CUSTOM CONTROL UTILITY 128-21-0
P22 SMPL PROGRAM 6 - USER CUSTOM CONTROL UTILITY 128-22-0
P23 SMPL PROGRAM 7 - USER CUSTOM CONTROL UTILITY 128-23-0
P24 CODING GROUP 0 ACTIVE UTILITY 128-24-0
P25 CODING GROUP 1 ACTIVE UTILITY 128-25-0
P26 CODING GROUP 2 ACTIVE UTILITY 128-26-0
P27 CODING GROUP 3 ACTIVE UTILITY 128-27-0
P28 CODING GROUP 4 ACTIVE UTILITY 128-28-0
P29 CODING GROUP 5 ACTIVE UTILITY 128-29-0
P30 CODING GROUP 6 ACTIVE UTILITY 128-30-0
P31 CODING GROUP 7 ACTIVE UTILITY 128-31-0
P32 COLD START TROUBLE 128-32-0
P33 WARM START TROUBLE 128-33-0
P34 CITY DISCONNECT TROUBLE 128-34-0
P35 MANUAL EVACUATION SWITCH INPUT UTILITY 128-35-0
P36 ELEVATOR BYPASS TROUBLE 128-36-0
P37 DOORHOLDER BYPASS TROUBLE 128-37-0
P38 CONTROL POINT BYPASS TROUBLE 128-38-0
P39 SYSTEM EXECUTING FROM RAM TROUBLE 128-39-0
P40 AUTOMATIC DETECTOR RESET UTILITY 128-40-0
P41 MASTER FIRE ALARM ACK KEY UTILITY 128-41-0
P42 MASTER SUPERVISORY ACK KEY UTILITY 128-42-0
P43 MASTER TROUBLE ACK KEY UTILITY 128-43-0
P44 CODING BUS DISABLE SWITCH UTILITY 128-44-0
P45 DRILL SWITCH INPUT UTILITY 128-45-0
P46 DOOR HOLDER TRIGGER UTILITY 128-46-0
P47 SIGNALS/VISUALS ACTIVE UTILITY 128-47-0
P48 MANUAL EVACUATION FIRE 128-48-0
P49 SYSTEM AT ACCESS LEVEL 1 OR GREATER UTILITY 128-49-0
P50 SYSTEM AT ACCESS LEVEL 2 OR GREATER UTILITY 128-50-0
P51 SYSTEM AT ACCESS LEVEL 3 OR GREATER UTILITY 128-51-0
P52 SYSTEM AT ACCESS LEVEL 4 UTILITY 128-52-0
P53 SYSTEM LIST OVERFLOW - WARM START NEEDED TROUBLE 128-53-0
P54 NETWORK MIKE KEYED UTILITY 128-54-0
P55 CRT KEYPAD INACTIVITY TIMER DISABLE UTILITY 128-55-0
P56 CITY CIRCUIT STD TROUBLE RELAY OPERATION UTILITY 128-56-0
P57 KEYPAD INACTIVITY TIMER DISABLE UTILITY 128-57-0
P58 SYSTEM TIME/DATE INVALID OR NOT SET TROUBLE 128-58-0
P59 ALARM VERIFICATION TALLY LIMIT EXCEEDED TROUBLE 128-59-0
P60 ALARM VERIFICATION GROUP 0 ACTIVE UTILITY 128-60-0
P61 ALARM VERIFICATION GROUP 1 ACTIVE UTILITY 128-61-0
P62 ALARM VERIFICATION GROUP 2 ACTIVE UTILITY 128-62-0
P63 ALARM VERIFICATION GROUP 3 ACTIVE UTILITY 128-63-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 51 of 58

P64 ALARM VERIFICATION GROUP 4 ACTIVE UTILITY 128-64-0
P65 ALARM VERIFICATION GROUP 5 ACTIVE UTILITY 128-65-0
P66 ALARM VERIFICATION GROUP 6 ACTIVE UTILITY 128-66-0
P67 ALARM VERIFICATION GROUP 7 ACTIVE UTILITY 128-67-0
P68 FIRST STAGE TIMER EXPIRED UTILITY 128-68-0
P69 THE EVAC MESSAGE HAS PLAYED UTILITY 128-69-0
P70 WALK TEST GROUP 0 ENABLED TROUBLE 128-70-0
P71 WALK TEST GROUP 1 ENABLED TROUBLE 128-71-0
P72 WALK TEST GROUP 2 ENABLED TROUBLE 128-72-0
P73 WALK TEST GROUP 3 ENABLED TROUBLE 128-73-0
P74 WALK TEST GROUP 4 ENABLED TROUBLE 128-74-0
P75 WALK TEST GROUP 5 ENABLED TROUBLE 128-75-0
P76 WALK TEST GROUP 6 ENABLED TROUBLE 128-76-0
P77 WALK TEST GROUP 7 ENABLED TROUBLE 128-77-0
P78 ALARM SILENCE/ALARM CUTOUT PSEUDO UTILITY 128-78-0
P79 RESET SPKRS WHEN AUDIO CODING COMPLETE UTILITY 128-79-0
P80 MASTER MICROPHONE KEYED UTILITY 128-80-0
P81 REMOTE MICROPHONE 1 KEYED UTILITY 128-81-0
P82 REMOTE MICROPHONE 2 KEYED UTILITY 128-82-0
P83 REMOTE MICROPHONE 1 READY TO TALK UTILITY 128-83-0
P84 REMOTE MICROPHONE 2 READY TO TALK UTILITY 128-84-0
P85 VTG 1 - ACTIVE UTILITY 128-85-0
P86 VTG 2 - ACTIVE UTILITY 128-86-0
P87 EVACUATION MESSAGE ON UTILITY 128-87-0
P88 EVACUATION MESSAGE OFF UTILITY 128-88-0
P89 EVACUATION MESSAGE LED UTILITY 128-89-0
P90 ALERT MESSAGE ON UTILITY 128-90-0
P91 ALERT MESSAGE OFF UTILITY 128-91-0
P92 ALERT MESSAGE LED UTILITY 128-92-0
P93 DRILL MESSAGE ON UTILITY 128-93-0
P94 DRILL MESSAGE OFF UTILITY 128-94-0
P95 DRILL MESSAGE LED UTILITY 128-95-0
P96 ALL CLEAR MESSAGE ON UTILITY 128-96-0
P97 ALL CLEAR MESSAGE OFF UTILITY 128-97-0
P98 ALL CLEAR MESSAGE LED UTILITY 128-98-0
P99 AUX MSG 1 ON UTILITY 128-99-0
P100 AUX MSG 1 OFF UTILITY 128-100-0
P101 AUX MSG 1 LED UTILITY 128-101-0
P102 AUX MSG 2 ON UTILITY 128-102-0
P103 AUX MSG 2 OFF UTILITY 128-103-0
P104 AUX MSG 2 LED UTILITY 128-104-0
P105 PHONE PAGING ON UTILITY 128-105-0
P106 PHONE PAGING OFF UTILITY 128-106-0
P107 PHONE PAGING LED UTILITY 128-107-0
P108 AUDIO OVERRIDE ON UTILITY 128-108-0
P109 AUDIO OVERRIDE OFF UTILITY 128-109-0
P110 AUDIO OVERRIDE TROUBLE TROUBLE 128-110-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 52 of 58

P111 ALL SPEAKERS MINUS ON UTILITY 128-111-0
P112 ALL SPEAKERS MINUS OFF UTILITY 128-112-0
P113 ALL SPEAKERS MINUS LED UTILITY 128-113-0
P114 ALL SPEAKERS CHANNEL 1 ON UTILITY 128-114-0
P115 ALL SPEAKERS CHANNEL 1 OFF UTILITY 128-115-0
P116 ALL SPEAKERS CHANNEL 1 LED UTILITY 128-116-0
P117 ALL SPEAKERS CHANNEL 2 ON UTILITY 128-117-0
P118 ALL SPEAKERS CHANNEL 2 OFF UTILITY 128-118-0
P119 ALL SPEAKERS CHANNEL 2 LED UTILITY 128-119-0
P120 ALL SPEAKERS CHANNEL 3 ON UTILITY 128-120-0
P121 ALL SPEAKERS CHANNEL 3 OFF UTILITY 128-121-0
P122 ALL SPEAKERS CHANNEL 3 LED UTILITY 128-122-0
P123 LOCAL SPEAKER EVAC ON UTILITY 128-123-0
P124 LOCAL SPEAKER EVAC OFF UTILITY 128-124-0
P125 LOCAL SPEAKER EVAC LED UTILITY 128-125-0
P126 LOCAL SPEAKER ALERT ON UTILITY 128-126-0
P127 LOCAL SPEAKER ALERT OFF UTILITY 128-127-0
P128 LOCAL SPEAKER ALERT LED UTILITY 128-128-0
P129 ALL SPEAKERS TALK ON UTILITY 128-129-0
P130 ALL SPEAKERS TALK OFF UTILITY 128-130-0
P131 ALL SPEAKERS TALK LED UTILITY 128-131-0
P132 ANALOG SENSOR ALMOST DIRTY LOG ENABLE TROUBLE 128-132-0
P133 LOG ANALOG SENSOR PEAK VALUE ENABLE UTILITY 128-133-0
P134 CLEAR ANALOG SENSOR PEAK VALUE TROUBLE 128-134-0
P135 ALL ALERT UTILITY 128-135-0
P136 ALL EVAC UTILITY 128-136-0
P137 ALL ALERT LED UTILITY 128-137-0
P138 MASTER MIKE PRETONE PLAYING ON VTG2 UTILITY 128-138-0
P139 REMOTE MIKE 1 PRETONE PLAYING ON VTG2 UTILITY 128-139-0
P140 REMOTE MIKE 2 PRETONE PLAYING ON VTG2 UTILITY 128-140-0
P141 MANUAL AUDIO EVAC ON UTILITY 128-141-0
P142 MANUAL AUDIO EVAC OFF UTILITY 128-142-0
P143 MANUAL AUDIO EVAC LED UTILITY 128-143-0
P144 DISABLE SUPERVISION ON VTG 1 (2120 APPL) UTILITY 128-144-0
P145 DISABLE SUPERVISION ON VTG 2 (2120 APPL) UTILITY 128-145-0
P146 EMPTY AUDIO SERVICE QUEUE UTILITY 128-146-0
P147 EVAC MSG PLAYING WHEN MICROPHONE KEYED UTILITY 128-147-0
P148 SYSTEM OUT OF AQB'S TROUBLE 128-148-0
P149 SPEAKER SWITCH OFF AUTO TROUBLE 128-149-0
P150 AUDIO CODING GROUP 1 ACTIVE UTILITY 128-150-0
P151 AUDIO CODING GROUP 2 ACTIVE UTILITY 128-151-0
P152 VTG 1 - AUDIO SUPERVISION ACTIVE UTILITY 128-152-0
P153 VTG 2 - AUDIO SUPERVISION ACTIVE UTILITY 128-153-0
P154 PHONE TALK LINE RELAY FEEDBACK UTILITY 128-154-0
P155 PHONE NETWORK RELAY FEEDBACK UTILITY 128-155-0
P156 LOCAL MASTER PHONE HANDSET OFF HOOK UTILITY 128-156-0
P157 PHONE TALK LINE RELAY CONTROL INPUT UTILITY 128-157-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 53 of 58

P158 PHONE NETWORK RELAY CONTROL INPUT UTILITY 128-158-0
P159 PHONE TALK LINE RELAY CONTROL UTILITY 128-159-0
P160 PHONE NETWORK RELAY CONTROL UTILITY 128-160-0
P161 MASTER PHONE OFFHOOK SUPERVISION TROUBLE 128-161-0
P162 MASTER MIKE PRETONE PLAYING ON VTG1 UTILITY 128-162-0
P163 REMOTE MIKE 1 PRETONE PLAYING ON VTG1 UTILITY 128-163-0
P164 REMOTE MIKE 2 PRETONE PLAYING ON VTG1 UTILITY 128-164-0
P165 AMPS SWITCHED TO BATTERY UTILITY 128-165-0
P166 ENABLE RM PHONE TO RM PHONE CONVERSATION UTILITY 128-166-0
P167 ALERT MSG PLAYING WHEN MICROPHONE KEYED UTILITY 128-167-0
P168 MICROPHONE TO EVAC IN EFFECT UTILITY 128-168-0
P169 MICROPHONE TO ALERT IN EFFECT UTILITY 128-169-0
P170 MICROPHONE TO TALK (CHANNEL 3) IN EFFECT UTILITY 128-170-0
P171 BACKGROUND MUSIC RELAY CHANNEL 1 UTILITY 128-171-0
P172 BACKGROUND MUSIC RELAY CHANNEL 2 UTILITY 128-172-0
P173 BACKGROUND MUSIC RELAY CHANNEL 3 UTILITY 128-173-0
P174 VTG 1 CODE'S PRECODE PLAYING UTILITY 128-174-0
P175 VTG 1 CODE'S AFTER CODE PLAYING UTILITY 128-175-0
P176 AFTER CODE START - VTG 1 UTILITY 128-176-0
P177 VTG 1 'QUIET' MESSAGE PLAYING UTILITY 128-177-0
P178 VTG 2 CODE'S PRECODE PLAYING UTILITY 128-178-0
P179 VTG 2 CODE'S AFTER CODE PLAYING UTILITY 128-179-0
P180 AFTER CODE START - VTG 2 UTILITY 128-180-0
P181 VTG 2 'QUIET' MESSAGE PLAYING UTILITY 128-181-0
P182 (2120 APPL) VTG1 CODE START UTILITY 128-182-0
P183 (2120 APPL) STOP VTG1 QUEUE UTILITY 128-183-0
P184 (2120 APPL) VTG2 CODE START UTILITY 128-184-0
P185 (2120 APPL) STOP VTG2 QUEUE UTILITY 128-185-0
P186 MIKE DISABLE UTILITY 128-186-0
P187 VTG & AMPLIFIER TROUBLE DISABLE UTILITY 128-187-0
P188 VTG SUPERVISION TONE NOT ACTIVE TROUBLE 128-188-0
P189 SATELLITE PHONE TIMEOUT DISABLE UTILITY 128-189-0
P190 NETWORK MIKE PRETONE PLAYING UTILITY 128-190-0
P191 MASTER MIKE KEYED UTILITY 128-191-0
P192 REMOTE MIKE 1 KEYED UTILITY 128-192-0
P193 REMOTE MIKE 2 KEYED UTILITY 128-193-0
P194 MIKES ARE READY TO PAGE UTILITY 128-194-0
P195 S21 SWITCH ACTIVATED UTILITY 128-195-0
P196 RAM BATTERY MISSING/FAILED TROUBLE 128-196-0
P197 2120 1 COMM LOSS UTILITY 128-197-0
P198 INHIBIT SONALERT UTILITY 128-198-0
P199 INHIBIT ALARM DEFAULT UTILITY 128-199-0
P200 FORCE COLD START UTILITY 128-200-0
P201 AC VOLTAGE FAILURE/BROWNOUT UTILITY 128-201-0
P202 DETECTOR RESET UTILITY 128-202-0
P203 LCD ANNUNCIATORS OVERRIDE KEYSWITCH UTILITY 128-203-0
P204 SIGNALS SILENCED UTILITY 128-204-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 54 of 58

P205 TRUEALARM SENSITIVITY MODIFIED TROUBLE 128-205-0
P206 PRINT QUEUE OVERFLOW TROUBLE 128-206-0
P207 NETWORK DIAGNOSTIC MODE TROUBLE 128-207-0
P208 OUT OF NQB'S TROUBLE 128-208-0
P209 COMMUNICATIONS SHORT CIRCUIT TROUBLE TROUBLE 128-209-0
P210 NETWORK DETECTOR RESET UTILITY 128-210-0
P211 NETWORK SYSTEM RESET UTILITY 128-211-0
P212 DETECTOR/SYSTEM RESET UTILITY 128-212-0
P213 4120 NETWORK CARD CONFIGURED UTILITY 128-213-0
P214 CLEAR VERIFICATION TALLIES TROUBLE 128-214-0
P215 PRIORITY 2 ALARM DETECT UTILITY 128-215-0
P216 PRIORITY 2 ALARM RESET REQUEST UTILITY 128-216-0
P217 NETWORK SIGNAL SILENCE UTILITY 128-217-0
P218 UNACKNOWLEDGED PRIORITY 2 ALARM EXISTS UTILITY 128-218-0
P219 MASTER PRIORITY 2 ALARM ACK KEY UTILITY 128-219-0
P220 NETWORK PRIORITY 2 RESET UTILITY 128-220-0
P221 SIGNALS ACTIVE - OFF ON SILENCE UTILITY 128-221-0
P222 REMOTE DOWNLOAD ENABLED TROUBLE 128-222-0
P223 MASTER MICROPHONE READY TO TALK UTILITY 128-223-0
P224 NETWORK INITIALIZATION INCOMPLETE TROUBLE 128-224-0
P225 NETWORK OPERATING IN DEGRADED STYLE-7 TROUBLE 128-225-0
P226 NETWORK INITIALIZATION IN PROGRESS TROUBLE 128-226-0
P227 SDACT DATABASE VERSION MISMATCH TROUBLE 128-227-0
P228 PREVENT TIME/DATE LOGGING UTILITY 128-228-0
P229 TRUEALERT SILENT TEST ACTIVE TROUBLE 128-229-0
P230 TRUEALERT DEVICE TEST MODE ACTIVE TROUBLE 128-230-0
P231 EXTRA NODE ON NETWORK TROUBLE 128-231-0
P232 NETWORK POINT LABEL UPDATING INHIBITED TROUBLE 128-232-0
P250 ENABLE END PAIR AND MONITOR LOGGING UTILITY 128-250-0

Analog Pseudo's do not have alarm states, they have physical values such as the day, date,
time, number of fire events, number of troubles and so on.

A0 NUMBER OF SYSTEM FIRE ALARMS ANALOG 144-0-0
A1 NUMBER OF SYSTEM SUPERVISORIES ANALOG 144-1-0
A2 NUMBER OF SYSTEM TROUBLES ANALOG 144-2-0
A3 NUMBER OF OLD (UNCLEARED) FIRE ALARMS ANALOG 144-3-0
A4 NUMBER OF OLD (UNCLEARED) SUPERVISORIES ANALOG 144-4-0
A5 NUMBER OF OLD (UNCLEARED) TROUBLES ANALOG 144-5-0
A6 CURRENT HOUR ANALOG 144-6-0
A7 CURRENT MINUTE ANALOG 144-7-0
A8 CURRENT SECOND ANALOG 144-8-0
A9 CURRENT DAY ANALOG 144-9-0
A10 CURRENT MONTH ANALOG 144-10-0
A11 CURRENT YEAR ANALOG 144-11-0
A12 CURRENT ACCESS LEVEL ANALOG 144-12-0
A13 ACCESS LEVEL TIMEOUT TIMER 144-13-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 55 of 58

DOOR HOLDER BROWNOUT DROP TIMER SETPOINT

A14 SYSTEM RESET WINDOW TIMER TIMER 144-14-0
A15 SYSTEM RESET WINDOW TIMER SETPOINT ANALOG 144-15-0
A16 DETECTOR RESET PULSE TIMER TIMER 144-16-0
A17 4-WIRE RESET RELAY PULSE TIMER TIMER 144-17-0
A18 FIRE ALARM CLEAR DELAY TIMER TIMER 144-18-0
A19 FIRE ALARM CLEAR DELAY TIMER SETPOINT ANALOG 144-19-0
A20 FIRE ALARM CLEAR PULSE TIMER TIMER 144-20-0
A21 SYSTEM RESET PULSE TIMER TIMER 144-21-0
A22 ALARM SILENCE INHIBIT TIMER TIMER 144-22-0
A23 ALARM SILENCE INHIBIT TIMER SETPOINT ANALOG 144-23-0
A24 FIRE ALARM CUTOUT TIMER TIMER 144-24-0
A25 FIRE ALARM CUTOUT TIMER SETPOINT ANALOG 144-25-0
A26 FIRE ALARM CUTOUT SILENCE PULSE TIMER TIMER 144-26-0
A27 TROUBLE REMINDER CYCLE TIMER TIMER 144-27-0
A28 TROUBLE REMINDER OFF-TIME SETPOINT ANALOG 144-28-0
A29 TROUBLE REMINDER ON-TIME SETPOINT ANALOG 144-29-0
A30 DOOR HOLDER ALARM DROP TIMER TIMER 144-30-0
A31 DOOR HOLDER ALARM DROP TIMER SETPOINT ANALOG 144-31-0
A32 DOOR HOLDER BROWNOUT DROP TIMER TIMER 144-32-0
A33

ANALOG 144-33-0
A34 SYSTEM STARTUP PULSE TIMER TIMER 144-34-0
A35 FIRE ALARM AUDIBLE SIGNAL OPERATION ANALOG 144-35-0
A36 FIRE ALARM VISUAL SIGNAL OPERATION ANALOG 144-36-0
A37 ALARM VERIFICATION - RETARD TIME ANALOG 144-37-0
A38 ALARM VERIFICATION - RESET TIME ANALOG 144-38-0
A39 ALARM VERIFICATION - CONFIRMATION TIME ANALOG 144-39-0
A40 ALARM VERIFICATION - TALLY LIMIT ANALOG 144-40-0
A41 WALK TEST ABORT TIMEOUT SETPOINT ANALOG 144-41-0
A42 WALK TEST REACTIVATE DELAY SETPOINT ANALOG 144-42-0
A43 MONITOR ZONE ENABLE DELAY SETPOINT ANALOG 144-43-0
A44 CODED INPUT TIMEOUT SETPOINT ANALOG 144-44-0
A45 OFF TIME AFTER PNIS (NON-CONT.) CODES ANALOG 144-45-0
A46 CITY CIRCUIT CONFIGURATION ANALOG 144-46-0
A47 ALERT TONE/MSG AFTER MICROPHONE UNKEYED ANALOG 144-47-0
A48 TOTAL AUDIO CHANNELS ANALOG 144-48-0
A49 CHANNEL 1 ROUTING ANALOG 144-49-0
A50 CHANNEL 2 ROUTING ANALOG 144-50-0
A51 CHANNEL 3 ROUTING ANALOG 144-51-0
A52 LOCAL ROUTING ANALOG 144-52-0
A53 EVAC TONE/MSG AFTER MICROPHONE UNKEYED ANALOG 144-53-0
A54 SUPERVISION MSG# ANALOG 144-54-0
A55 EVACUATION MSG# ANALOG 144-55-0
A56 ALERT MSG# ANALOG 144-56-0
A57 DRILL MSG# ANALOG 144-57-0
A58 ALL CLEAR MSG# ANALOG 144-58-0
A59 AUX 1 MSG# ANALOG 144-59-0
A60 AUX 2 MSG# ANALOG 144-60-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 56 of 58

A61 MICROPHONE PRETONE MSG# ANALOG 144-61-0
A62 PHONE OFFHOOK TIMER TIMER 144-62-0
A63 PHONE CALLBACK TIMER TIMER 144-63-0
A64 PHONE TIMEOUT TIMER TIMER 144-64-0
A65 REMOTE MASTER PHONE TIMEOUT TIMER TIMER 144-65-0
A66 SPEAKER SWITCH OFF AUTO COUNT ANALOG 144-66-0
A67 AUDIO RESET PULSE TIMER TIMER 144-67-0
A68 VTG 1 PRIORITY ANALOG 144-68-0
A69 VTG 2 PRIORITY ANALOG 144-69-0
A70 CHANNEL 1 ROUTING PRIORITY ANALOG 144-70-0
A71 CHANNEL 2 ROUTING PRIORITY ANALOG 144-71-0
A72 CHANNEL 3 ROUTING PRIORITY ANALOG 144-72-0
A73 LOCAL SPEAKER ROUTING PRIORITY ANALOG 144-73-0
A74 AUDIO SUPERVISION PULSE TIMER VTG1 TIMER 144-74-0
A75 AUDIO SUPERVISION PULSE TIMER VTG2 TIMER 144-75-0
A76 ENABLE/DISABLE STATISTIC GROUP ANALOG 144-76-0
A77 ENABLE/DISABLE STATISTIC OUTPUT PORT ANALOG 144-77-0
A78 5 SEC TIMER FOR REMOTE MASTER PHONES TIMER 144-78-0
A79 CLEAR PEAK PULSE ANALOG 144-79-0
A80 PRECODE MESSAGE NUMBER - VTG 1 ANALOG 144-80-0
A81 AFTER CODE MESSAGE NUMBER - VTG 1 ANALOG 144-81-0
A82 PRECODE MESSAGE NUMBER - VTG 2 ANALOG 144-82-0
A83 AFTER CODE MESSAGE NUMBER - VTG 2 ANALOG 144-83-0
A84 ' QUIET' MESSAGE NUMBER ANALOG 144-84-0
A85 2 SECOND TIMER - VTG 1 TIMER 144-85-0
A86 2 SECOND TIMER - VTG 2 TIMER 144-86-0
A87 MIKE INHIBIT TIMER TIMER 144-87-0
A88 MIKE INHIBIT TIMER SETPOINT ANALOG 144-88-0
A89 PHONE CALLBACK TIMER SETPOINT ANALOG 144-89-0
A90 PHONE TIMEOUT TIMER SETPOINT ANALOG 144-90-0
A91 VTG & AMPLIFIER TROUBLE DISABLE TIMER TIMER 144-91-0
A92 SUPERVISION NOT ACTIVE - TBL DELAY TIMER TIMER 144-92-0
A93 4 WIRE DETECTOR RESET EXTEND TIMER TIMER 144-93-0
A94 ACTIVE MESSAGE NUMBER - VTG 1 ANALOG 144-94-0
A95 ACTIVE MESSAGE NUMBER - VTG 2 ANALOG 144-95-0
A96 ACTUAL CHIPSET PLUGGED INTO VTG 1 ANALOG 144-96-0
A97 ACTUAL CHIPSET PLUGGED INTO VTG 2 ANALOG 144-97-0
A98 BATTERY TROUBLE COUNTER COUNTER 144-98-0
A99 AC POWER FAIL COUNTER COUNTER 144-99-0
A100 SYSTEM TYPE ANALOG 144-100-0
A101 FIRST STAGE TIMER ANALOG 144-101-0
A102 FIRST STAGE TIMER SETPOINT ANALOG 144-102-0
A103 MASTER MIKE 5 SECOND UNKEY DELAY ANALOG 144-103-0
A104 REMOTE MIKE 1 5 SECOND UNKEY DELAY ANALOG 144-104-0
A105 REMOTE MIKE 2 5 SECOND UNKEY DELAY ANALOG 144-105-0
A106 MASTER MIKE'S PRETONE TIMER ANALOG 144-106-0
A107 MASTER MIKE'S PRETONE SETPOINT ANALOG 144-107-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 57 of 58

A108 REMOTE MIKE 1'S PRETONE TIMER ANALOG 144-108-0
A109 REMOTE MIKE 1'S PRETONE SETPOINT ANALOG 144-109-0
A110 REMOTE MIKE 2'S PRETONE TIMER ANALOG 144-110-0
A111 REMOTE MIKE 2'S PRETONE SETPOINT ANALOG 144-111-0
A112 GROUND TROUBLE COUNTER COUNTER 144-112-0
A113 PAGING CHANNEL ANALOG 144-113-0
A114 TRUEALARM MODIFICATION COUNTER COUNTER 144-114-0
A115 EXCESSIVELY DIRTY (OUT OF RANGE) ANALOG 144-115-0
A116 DIRTY SENSOR COUNTER COUNTER 144-116-0
A117 ALMOST DIRTY COUNTER COUNTER 144-117-0
A118 ALARMS SILENCED DELAY TIMER TIMER 144-118-0
A119 NUMBER OF LOCAL SYSTEM POINTS' TROUBLES COUNTER 144-119-0
A120 SYSTEM PAGING STATUS ANALOG 144-120-0
A121 KEYPAD INACTIVITY TIMEOUT SETPOINT ANALOG 144-121-0
A122 NUMBER OF SYSTEM PRIORITY 2 ALARMS ANALOG 144-122-0
A123 NUMBER OF OLD (UNCLEARED) PRI2 ALARMS ANALOG 144-123-0
A124 PRI2 RESET WINDOW TIMER TIMER 144-124-0
A125 PRI2 RESET WINDOW TIMER SETPOINT ANALOG 144-125-0
A126 PRI2 ALARM CLEAR DELAY TIMER TIMER 144-126-0
A127 PRI2 ALARM CLEAR DELAY TIMER SETPOINT ANALOG 144-127-0
A128 PRI2 ALARM CLEAR PULSE TIMER TIMER 144-128-0
A129 PRIORITY 2 RESET PULSE TIMER TIMER 144-129-0
A130 PRIORITY 2 RESET START TIMER TIMER 144-130-0
A131 SUPERVISION DELAY SETPOINT CHL1 ANALOG 144-131-0
A132 SUPERVISION DELAY SETPOINT CHL2 ANALOG 144-132-0
A133 SUPERVISION NOT ACTIVE DELAY SETPOINT ANALOG 144-133-0

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]

FS-8700-41 Simplex 4100 Driver Manual Page 58 of 58

THIS PAGE INTENTIONALLY LEFT BLANK

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: [e-mail]
