FieldServer FS-8700-23 User Manual

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after April 2011

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-23 Cleaver Brooks Hawk

Driver Version:

1.01

Document Revision:

1

A Sierra Monitor Company

FS-8700-23 Cleaver Brooks Hawk Driver Manual Table of Contents

TABLE OF CONTENTS

1 CB-Link Description ........................................................................................................................................ 3

2 Driver Scope of Supply ................................................................................................................................... 3

2.1 Provided by the Supplier of 3rd Party Equipment .......................................................................................... 3

3 Hardware Connections ................................................................................................................................... 4

4 Data Array Parameters ................................................................................................................................... 5

5 Configuring the FieldServer as a ChB-Link Client ............................................................................................ 6

5.1 FieldServer ..................................................................................................................................................... 6

5.2 Client Side Connection Descriptions .............................................................................................................. 6

5.3 Client Side Node Descriptors ......................................................................................................................... 7

5.3.1 CB Link_ID .............................................................................................................................................. 7

5.3.2 Node_Type ............................................................................................................................................. 8

5.4 Client Side Map Descriptors........................................................................................................................... 8

5.4.1 FieldServer Related Map Descriptor Parameters ................................................................................... 8

5.4.2 Driver Related Map Descriptor Parameters ........................................................................................... 8

5.4.3 Timing Parameters ................................................................................................................................. 8

5.4.4 Map Descriptor Example ........................................................................................................................ 9

Appendix A. Reference ........................................................................................................................................ 10

Appendix A.1. Device Information Table ................................................................................................................. 10

Appendix A.1.1. Property Files .......................................................................................................................... 10

Appendix A.1.2. Configuration Files ................................................................................................................. 11

Appendix A.2. Driver Compatibility Matrix .............................................................................................................. 11

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 3 of 11

PART #

Description

CB-Link Controller

1 CB-LINK DESC R IPTION

The CB-Link driver allows the FieldServer to transfer data to and from devices over RS-485 using CB-Link protocol.
The information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer.

Refer to “Model 833-2771 CB-Link” Manual #65-0216 and “Model 833-2757 General Purpose Interface ControlBus
Module” Manual #65-0220 from Cleaver Brooks.

2 DRIVE R SCO PE OF SUPPLY

2.1 Pro vided by the Sup plier o f 3

rd

Pa rty Eq uipme n t

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 4 of 11

A B C

FURTHER CB-LINKS

C1

833-2425

833-2757

RS485

9600 N81

CLEAVER BROOKS MODEL 833-2771 CB LINK or
HONEYWELL Q7700 NETWORK INTERFACE UNIT

CB

HAWK

AKA: ASCII INTERFACE
EMS INTERFACE
BDI CARD
QS7850
GPI (GENERALPURPOSE INTERFACE)

POSSIBLE DEVICES

BCS7700 BURNER CONTROL
CB-HAWK BURNER CONTROL
RM7800 BURNER CONTROL
RM7800 EXPANDED ANNUNCIATOR
QS7X00X CARDS (QM40XX,
PULSATROL,

TRAPSCAN)

Q7700 NETWORK INTERFACE.

etc

C2

SLOT 1 2 3 4 5

6

CONFIG PC

(RUISYS)

FieldServer

Gnd

_

+

Gnd

FG

_

+

RS-485

Opto

Isolated

3 HARDW ARE C ONNECT IONS

The FieldServer can be connected to the CB – Link device as shown below.

Configure the PLC according to manufacturer’s instructions

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 5 of 11

Section Title

Data_Arrays

Column Title

Function

Legal Values

Data_Array_Name

Provide name for Data Array

Up to 15
alphanumeric
characters

Data_Array_Format

Provide data format. Each Data Array can only take on one
format.

FLOAT, BIT, Int16,
Int32,

Data_Array_Length

Number of Data Objects. Must be larger than the data storage
area required by the Map Descriptors for the data being placed in
this array.

1-10, 000
// Data Arrays

Data_Arrays

Data_Array_Name

, Data_Array_Format

, Data_Array_Length

DA_AI_01

, Float

, 200

4 DATA A RRAY PARAM ETERS

Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is necessary

to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant data.

Example

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 6 of 11

Section Title

Bridge

Column Title

Function

Legal Values

Title

Title for CSV file

Any text, Maximum 32 characters

System_Node_ID

Node ID of the FieldServer

8 – 254

// Common Information

Bridge

Title

, System_Node_ID

CB_Link client

, 11

Section Title

Connections

Column Title

Function

Legal Values

Port

Specify which port the device is connected to the FieldServer

R1-R2

Baud

Specify baud rate

9600

Parity

Specify parity

None

IC_Timeout

Inter-Character Timeout

≥10 s

Squelch_Timer

Squelch suppression time

≥0.02 s

Poll_Delay

Minimum time between polls

0.6

// Client Side Connections

Connections

Port

, Baud

, Parity

, IC_Timeout

, Squelch_Timer

, Poll_Delay

R1

, 9600

, None

, 10

, 0.02

, 0.6

5 CONFI GURING THE F I ELDS ERVER AS A C HB- LINK CLIENT

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration f iles
included with the FieldServer (See “.csv” sample files provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a ChB-Link Server

Note that * indicates an optional parameter, with the bold legal value being the default.

5.1 FieldSer ver

Example

5.2 Client S ide C onnec t ion Des criptions

Example

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 7 of 11

Section Title

Nodes

Column Title

Function

Legal Values

Node_Name

Provide name for node

Up to 32 alphanumeric characters

CB Link_ID

Device address

Refer to Section 5.3.1

Protocol

Specify protocol used

CB_Link

Port

Port connection

R1-R2

Node_Type

Specify controller connected to CB-Link

See Section 5.3.2

// Client Side Nodes

Nodes

Node_Name

, CBlink_ID

, Protocol

, Port

, Node_Type

CBH1

, 0 1 20

, CB_Link

, R1

, Hawk

Device Description

Device Type Code

Auxenh

26

Ec78xx

32

Efenh

26

Hawk

20

Llenh

26

Orenh

26

Pulsa

19

Q7700

1

Qm40xx

17

Rm78xx

32

S7800

36

S7830

34

Tdenh

26

Testcard

99

Trapscan

18

5.3 Client S ide N ode De scriptors

Example

5.3 .1 CB Link_ ID

The CB Link ID is declared in the format A B C where:

A describes the number of CB-Link units attached. Legal values 0 (1 Link Attached - default), 8-24 (Multiple Links
Attached)

B describes the slot the device is attached to in the PC Link 1-5, default 1

C: describes the Device type (Declare Device Type Code from the following table):

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 8 of 11

Column Title

Function

Legal Values

Map_Descriptor_Name

Name of this Map Descriptor. This Name refers to
the variable in the related .bp2 property file.

Any of the variable names in the
related .bp2 property file.

Data_Array_Name

Name of Data Array where data is to be stored in
the FieldServer

One of the Data Array names
from “Data Array” section above

Data_Array_Offset

Starting location in Data Array

0 to maximum specified in “Data
Array” section above

Function

Function of Client Map Descriptor

RDBC

Column Title

Function

Legal Values

Node_Name

Name of Node to fetch data
from

One of the node names specified in “Client Node Descriptor”
above

Scan_Interval

Specify poll rate

>1.0s

Column Title

Function

Legal Values

Timeout

Specify maximum response time

>30.0s

5.3 .2 No de_Typ e

Hawk, EC78XX. Others by request. (Refer to Appendix A.1

5.4 Client S ide M ap Des cript o rs

5.4 .1 FieldSer ver Re lated Map Des cript or Paramete rs

5.4 .2 Dri ver R elated Map Descr iptor Param eters

5.4 .3 Tim ing P arame ters

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 9 of 11

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name

, Data_Array_Name

, Data_Array_Offset

, Function

, Node_Name

, Scan_Interval

, Timeout

Control_Source

, DA_AI_01

, 1

, RDBC

, CBH1

, 10

, 30

Oper_Pressure

, DA_AI_01

, 2

, RDBC

, CBH1

, 10

, 30

5.4 .4 Map Descripto r Exam ple

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 10 of 11

NETWORK INTERFACE UNIT

MAKE

MODEL

NAME

Honeywell

Q7700

Network Interface Unit

Cleaver Brooks

833-2771

CB-Link

CONTROL MODULES

MAKE

MODEL No.

OF MODULE

MODULE NAME

PROPERTY FILE

NAME (.BP1;.BP2)

CONFIGURATION FILE

NAME (.CSV)

NOTES

Honeywell

QS7700A

BCS7700

N/A

N/A Honeywell

QS7800A

7800 SERIES Control

N/A

N/A

Honeywell

QS7800C

QM40XX Data
Acquisition Module

ON REQUEST

QM40XX

Data Acquisition
Modules

Armstrong

QS7800D

Trapscan System

ON REQUEST

ON REQUEST

Honeywell

QS7800E

PulsaFeeder PULSAtrol

PULSA

PULSA

Honeywell

QS7800A

S7830 Expanded
Annunciator

S7830

S7830

Expanded
Annunciator

Honeywell

QS7800A

S7800
Keyboard/Display
Module

S7800

S7800
Honeywell

QS7800A

ST7800 Relay Module

ST7800

Requires S7800
module

Honeywell

RM7800E,G,L,M Relay
Modules

RM78XX

RM78XX

Honeywell

RM7840E,G,L,M Relay
Modules

RM78XX

RM78XX
Honeywell

N/A

Q7700A,B

CB-Link

833-2727

Display Module

N/A

N/A

CB-Link

833-2729

Data Control Bus
Module

N/A

N/A
CB-Link

833-2734

CB 783

ON REQUEST

ON REQUEST

Requires 833-2727 or
833-2729 on module

CB-Link

833-2734

CB 780

ON REQUEST

ON REQUEST

CB-Link

833-2734

CB 784

ON REQUEST

ON REQUEST

Appendix A. Reference

Appendix A.1. Device Information Table

Appendix A.1.1. Pro p erty F i les

Each Controller interfacing to the FieldServer requires associated property files (denoted by file extensions .bp1
and .bp2) to be loaded into the FieldServer. The property files listed in the device information table (Appendix A.1)
are preloaded onto the FieldServer when delivered. Other property files may be available upon request.



This is the chassis that the above modules plug into

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-23 Cleaver Brooks Hawk Driver Manual Page 11 of 11

FieldServer Model

Compatible with this driver

FS-x2010

Yes

FS-x2011

Yes

FSx25

No

FS-x30

Yes

FS-x40

Yes

SlotServer

No

ProtoNode

No

ProtoCessor FPC-FO2

No

ProtoCessor FPC-FD2

No

QuickServer FS-QS-1010

No

QuickServer FS-QS-1011

No

Appendix A.1.2. Con f igura t i on Fil e s

Each Controller has an associated configuration file as shown in the device information table (Appendix A.1). This
configuration file contains the mapping for the related module and can be used as a basis for building a
configuration for the FieldServer.

Note: SYSNet is the generic name for networks of the listed modules. Controlbus is the generic name for the
networks in a NIM/CBLink configuration

Appendix A.2. Driver Compatibility Matrix

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
