APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after May 1, 2001
Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8700-124 TIC UPS
Driver Version:
1.01
Document Revision:
0
A Sierra Monitor Company
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Table of Contents
TABLE OF CONTENTS
1. TIC UPS DESCRIPTION ................................................................................................. 3
2. DRIVER SCOPE OF SUPPLY ........................................................................................ 4
2.1. Supplied by FieldServer Technologies for this driver ................................................... 4
2.2. Provided by the Supplier of 3rd Party Equipment .......................................................... 4
2.2.1. Required 3rd Party Hardware ..................................................................................... 4
2.2.2. Required 3rd Party Software ....................................................................................... 4
2.2.3. Required 3rd Party Configuration ............................................................................... 4
3. HARDWARE CONNECTIONS....................................................................................... 5
3.1. Hardware Connection Tips / Hints ................................................................................. 5
4. CONFIGURING THE FIELDSERVER AS A TIC UPS CLIENT .............................. 6
4.1. Data Arrays/Descriptors ................................................................................................. 6
4.2. Client Side Connection Descriptions ............................................................................. 7
4.3. Client Side Node Descriptors ......................................................................................... 7
4.4. Client Side Map Descriptors .......................................................................................... 8
4.4.1. FieldServer Related Map Descriptor Parameters ...................................................... 8
4.4.2. Driver Related Map Descriptor Parameters .............................................................. 8
4.5. Map Descriptor Example. .............................................................................................. 9
4.5.1. Example 1.................................................................................................................... 9
4.5.2. Example 2.................................................................................................................... 9
APPENDIX A. COMMANDS SPECIFIC TO DEVICES ..................................................... 10
Appendix A.1. Client Read commands ................................................................................... 10
Appendix A.1.1. FAULT command: .................................................................................... 12
Appendix A.1.2. ALARM command: ................................................................................... 13
Appendix A.1.3. STATUS command: .................................................................................. 13
Appendix A.1.4. Commands supported by Different Models .............................................. 14
Appendix A.2. Client Write Commands ................................................................................. 14
Appendix A.2.1. Commands supported by different models. .............................................. 15
APPENDIX B. TROUBLESHOOTING TIPS ........................................................................ 16
Appendix B.1. Connection Tips & Hints ................................................................................ 16
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
ProtoNode Mode
Nodes
Comments
Client
1
As the Toshiba protocol only allows for 1:1 communication
at this stage, only 1 client is allowed per RS-232 port.
Server
1
The server only serves for emulation purposes. It will have
a static address as per Toshiba spec.
Page 3 of 17
1. TIC UPS Description
The serial TIC UPS driver allows the ProtoNode to transfer data to and from devices over RS232 using TIC UPS protocol. The ProtoNode can emulate a Client.
This driver is intended for use with Toshiba models UPS.
It is intended to do the following:
Read information from the UPS such as battery life, voltages etc. This will be done in
user mode on the UPS.
Write information and commands such as shutdown commands to the UPS.
Advanced options such as reading/writing EEPROM is not supported. No date/time
reads or writes will be supported. No string type commands will be supported.
Max Nodes Supported
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
FieldServer Technologies
PART #
Description
FS-8917-02
RJ45 to DB9F connector adapter.
FS-8917-03
RJ45 to DB9M connector adapter.
FS-8700-124
Driver Manual.
Part #
Description
-
TIC UPS model
1600/1800/4200/G8000/G8000MM/G9000
Page 4 of 17
2. Driver Scope of Supply
2.1. Supplied by FieldServer Technologies for this driver
2.2. Provided by the Supplier of 3rd Party Equipment
2.2.1. Required 3rd Party Hardware
2.2.2. Required 3rd Party Software
None
2.2.3. Required 3rd Party Configuration
The baud rate of the UPS must match the configuration file of the ProtoNode.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
FUNCTION FROM TO COLOUR
Rx RJ45-01 DB9F-03 WHITE
GND RJ45-04 DB9F-05 GREEN
Tx RJ45-08 DB9F-02 BLUE
BASE NAME:
FILE NAME: FS-8700-124
PROTONODE
TOSHIBA UPS
CONNECTION DIAGRAM
DATE: 10/10/07
BY: MC
(408)-262-2299
8917-02 WIRE LIST
Toshiba UPS
DB9M
DB9F
FUNCTION FROM TO COLOUR
Rx RJ45-01 DB9M-02 GREY
GND RJ45-04 DB9M-05 GREEN
Tx RJ45-08 DB9M-03 BLUE
8917-03 WIRE LIST
PROTONODE
Page 5 of 17
3. Hardware Connections
The ProtoNode is connected to the UPS as shown in connection drawing.
Configure the TIC UPS according to manufacturer’s instructions.
3.1. Hardware Connection Tips / Hints
The RTS/DTS signals are not used by the driver. Make sure they are not connected and
do not enable them in the configuration file.
The cable must be a NULL modem cable, i.e. the TX must be connected to the other
connector’s RX.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Section Title
Data_Arrays
Column Title
Function
Legal Values
Data_Array_Name
Provide name for Data Array
Up to 15 alphanumeric
characters
Data_Array_Format
Provide data format. Each Data
Array can only take on one format.
Float, Bit
Data_Array_Length
Number of Data Objects. Must be
larger than the data storage area
required by the Map Descriptors for
the data being placed in this array.
1-10,000
// Data Arrays
Data_Arrays
Data_Array_Name,
Data_Array_Format,
Data_Array_Length
DA_AI_01,
Float,
200
DA_DI_01,
Bit,
200
Page 6 of 17
4. Configuring the FieldServer as a TIC UPS Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer
Configuration Manual. The information that follows describes how to expand upon the factory
defaults provided in the configuration files included with the FieldServer (See “.csv” sample files
provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer
to communicate with a TIC UPS Server.
4.1. Data Arrays/Descriptors
The configuration file tells the FieldServer about its interfaces, and the routing of data
required. In order to enable the FieldServer for TIC UPS communications, the driver
independent FieldServer buffers need to be declared in the “Data Arrays” section, the
destination device addresses need to be declared in the “Client Side Nodes” section, and the
data required from the servers needs to be mapped in the “Client Side Map Descriptors”
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.
Example
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device
is connected to the ProtoNode
P1-P8
Protocol
Specify protocol used
TOSHIBA_UPS, TOSH_UPS
Baud*
Specify baud rate
1200–9600, standard baud rates
only (Vendor limitation)
Parity*
Specify parity
Even
Data_Bits*
Specify data bits
7
Stop_Bits*
Specify stop bits
1
Handshaking*
Specify hardware handshaking
None
Poll _Delay*
Time between internal polls
0-32000 seconds, 0.05 seconds
// Client Side Connections
Connections
Port,
Protocol,
Baud,
Parity,
Handshaking,
Data_Bits
Poll_Delay
P1,
TOSH_UPS,
1200,
Even,
None,
7
0.100s
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for node
Up to 32 alphanumeric characters
Node_ID
Modbus station address of
physical server node
1
Protocol
Specify protocol used
TOSH_UPS, TOSHIBA_UPS
Node_Type
The model of the TIC UPS
1600, 1800, 4200, G8000,
G8000MM, G9000
Connection
Specify which port the device is
connected to the ProtoNode
P1-P81
Page 7 of 17
4.2. Client Side Connection Descriptions
Example
4.3. Client Side Node Descriptors
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for
details of the ports available on specific hardware.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
// Client Side Nodes
Nodes
Node_Name,
Node_ID,
Protocol,
Node_Type,
Connection
PLC 1,
1,
TOSH_UPS,
1600,
P1
Column Title
Function
Legal Values
Map_Descriptor_Name
Name of this Map Descriptor
Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array where
data is to be stored in the
FieldServer
One of the Data Array names
from “Data Array” section
above
Data_Array_Offset
Starting location in Data
Array
0 to maximum specified in
“Data Array” section above
Function
Function of Client Map
Descriptor
RDBC, WRBC, WRBX
Column Title
Function
Legal Values
Node_Name
Name of Node to fetch
data from
One of the node names specified in
“Client Node Descriptor” above
Toshiba_Command
Type of information
on UPS
OV1, OV2, OV3 etc (Appendix A)
Length
Length of Map
Descriptor
1 – All value commands
24 – All bit commands
Page 8 of 17
Example
4.4. Client Side Map Descriptors
4.4.1. FieldServer Related Map Descriptor Parameters
4.4.2. Driver Related Map Descriptor Parameters
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual Page 9 of 17
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name,
Data_Array_Name,
Data_Array_Offset,
Function,
Node_Name,
Toshiba_Command,
Length,
Scan_Interval
A1,
DA_AI_01,
0,
RDBC,
Node_A,
OV1,
1,
5
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name,
Data_Array_Name,
Data_Array_Offset,
Function,
Node_Name,
Toshiba_Command,
Length,
Scan_Interval
B1,
DA_DI_01,
23,
RDBC,
Node_A,
ALARM,
1,
5
B2,
DA_DI_01,
15,
RDBC,
Node_A,
ALARM,
4, 5 B3,
DA_DI_01,
0,
RDBC,
Node_A,
ALARM,
23,
5
For all commands except
FAULT and ALARM,
ensure that the
Data_Array_Name points
to an array of type float.
Make sure the Toshiba
command supports the
selected function.
For a list of
commands, see
Appendix A
All commands except
ALARM and FAULT
have length 1.
For ALARM and
FAULT, use bit
arrays
Use the offset to read a specific bit or
start reading at a specific bit. Use in
conjunction with length. Max value is
23.
Specify number of bits to
read. Maximum for Offset
+ Length is 23.
4.5. Map Descriptor Example.
4.5.1. Example 1
4.5.2. Example 2
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Page 10 of 17
Appendix A. Commands Specific to Devices
Appendix A.1. Client Read commands
The following commands are supported with the RDBC function.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Command
Description
ALARM
Alarm data
BC
Battery current
BECR
Battery estimated charge remaining
BEMR
Battery estimated minutes remaining
BLR
Battery life remaining
BPV1
Bypass voltage phase 1
BPV2
Bypass voltage phase 2
BPV3
Bypass voltage phase 3
BPC
Bypass current
BPFREQ
Bypass frequency
BRHT
Battery rated holding time
BT
Battery temperature
BVP
Battery voltage percentage
DCBV
DC bus voltage
FAULT
Fault data
IC1
Input current phase 1
IC2
Input current phase 2
IC3
Input current phase 3
IFRQ
Input frequency
IV1
Input voltage phase 1
IV2
Input voltage phase 2
IV3
Input voltage phase 3
OC1
Output current phase 1
OC2
Output current phase 2
OC3
Output current phase 3
OFRQ
Output frequency
OLP1
Output load percent phase 1
OLP2
Output load percent phase 2
OLP3
Output load percent phase 3
OV1
Output voltage phase 1
OV2
Output voltage phase 2
OV3
Output voltage phase 3
SOB
Seconds on battery
SAD
Shutdown after delay
OV12
Output voltage between phase 1 & 2
OV23
Output voltage between phase 2 & 3
OV31
Output voltage between phase 3 & 1
Page 11 of 17
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Bit #
Function
Bit 23:
Not used
Bit 22:
1
Bit 21:
Input over current
Bit 20:
DC over current
Bit 19:
DC bus over voltage
Bit 18:
DC bus under voltage
Bit 17:
Phase rotation error
Bit 16:
DC Bus imbalance
Bit 15:
Not used
Bit 14:
1
Bit 13:
EEPROM error
Bit 12:
Battery or charger circuit fault
Bit 11:
Battery overheat
Bit 10:
UPS overheat
Bit 9:
0
Bit 8:
Fuse has opened
Bit 7:
Not used
Bit 6:
1
Bit 5:
Inverter over current
Bit 4:
UPS overload
Bit 3:
Inverter overload
Bit 2:
Inverter under voltage
Bit 1:
Overload 110% load
Bit 0:
Inverter over voltage
Page 12 of 17
Appendix A.1.1. FAULT command:
Stored in bits, make sure array’s length is 24 and its type is bits.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Bit #
Description
Bit 23:
Not used
Bit 22:
1
Bit 21:
Low battery voltage
Bit 20:
Battery replacement alarm
Bit 19:
Parallel running mode
Bit 18:
0
Bit 17:
0
Bit 16:
UPS lifetime alarm
Bit 15:
Not used
Bit 14:
1
Bit 13:
Asynchronous operation
Bit 12:
Ambient overheat
Bit 11:
Overload accumulation started
Bit 10:
0
Bit 9:
0
Bit 8:
0
Bit 7:
Not used
Bit 6:
1
Bit 5:
Countdown started for shutdown
Bit 4:
0
Bit 3:
0
Bit 2:
0
Bit 1:
0
Bit 0:
0
Bit #
Description
Bit 7:
Not used
Bit 6:
1
Bit 5:
UPS fault detected
Bit 4:
Input voltage out of spec
Bit 3:
Low battery voltage detected
Bit 2:
UPS output from bypass
Bit 1:
UPS output from inverter
Bit 0:
UPS input and output voltage sync
Page 13 of 17
Appendix A.1.2. ALARM command:
Stored in bits, make sure array’s length is 24 and its type is bits.
Appendix A.1.3. STATUS command:
Stored in bits, make sure array’s length is 8 and its type is bits.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
1600:
1800
4200
G8000 & G8000MM
G9000
ALARM
ALARM
BC
BC
BC
BC
BC
BPV1
BECR
BECR
BEMR
BECR
BPV2
BPV1
BLR
BEMR
BPV3
BPV2
BPV1
BLR
BPC
BPV3
BPC
BPV1
BPFREQ
BPC
BPC
BPFREQ
BPC
BRHT
BPFREQ
BPFREQ
BRHT
BPFREQ
BVP
BRHT
BRHT
BT
BRHT
DCBV
BVP
BVP
BVP
BT
FAULT
DCBV
DCBV
FAULT
BVP
IC1
FAULT
FAULT
IC1
DCBV
IC2
IC1
IC1
IFRQ
FAULT
IC3
IC2
IC2
IV1
IC1
IFRQ
IC3
IC3
OC1
IFRQ
IV1
IFRQ
IFRQ
OFRQ
IV1
IV2
IV1
IV1
OLP1
OC1
IV3
IV2
IV2
OV1
OFRQ
OC1
IV3
IV3
SAD
OLP1
OC2
OC1
OC1
STATUS
OV1
OC3
OC2
OC2
SOB
OFRQ
OC3
OC3
SAD
OLP1
OFRQ
OFRQ
STATUS
OLP2
OLP1
OLP1
OLP3
OLP2
OLP2
OV1
OLP3
OLP3
OV2
OV1
OV1
OV3
OV2
OV2
SAD
OV3
OV3
STATUS
STATUS
OV12
OV23
OV31
STATUS
Page 14 of 17
Appendix A.1.4. Commands supported by Different Models
Appendix A.2. Client Write Commands
The following commands are supported with the WRBC functions.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Command
Description
SAD
Shutdown after delay.
BTEST
Battery Test2
1600:
1800
4200
G8000 & G8000MM, G9000
SAD
SAD
SAD
No Write commands supported
BTEST
BTEST
BTEST
Page 15 of 17
Appendix A.2.1. Commands supported by different models.
2
Please note that due to battery health, this point can only be tested as specified by TIC
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Page 16 of 17
Appendix B. Troubleshooting Tips
Appendix B.1. Connection Tips & Hints
1. What should the baud rate in my configuration file be set to?
Consult the UPS manual for the default baud rate of your UPS.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
ProtoNode Driver Manual (FS-8700-124) rev 6.doc Manual
Page 17 of 17
THIS PAGE INTENTIONALLY LEFT BLANK
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web:www.protocessor.com
Tel: 408.964.4433 Fax: 408.964.4425 Toll_Free: 800.317.8319 email: sales@protocessor.com
Loading...
