A Sierra Monitor Company
Driver Manual
(Supplement to the FieldServer Instruction Manual)
FS-8700-12 AB DH+
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after May 1, 2001
FS-8700-12_DH+ Manual Page 2 of 14
TABLE OF CONTENTS
1. Allen Bradley DH+ Description......................................................................................3
2. Driver Scope of Supply...................................................................................................4
2.1. Supplied by FieldServer Technologies for this Driver ...................................................4
2.2. Provided by the supplier of 3rd Party Equipment...........................................................4
2.2.1. Hardware...............................................................................................................4
3. Hardware Connections...................................................................................................5
4. Configuring theFieldServer as a DH+ Client.................................................................6
4.1. Data Arrays/Descriptors................................................................................................6
4.2. Client Side Connection Descriptors...............................................................................7
4.3. Client Side Node Descriptors........................................................................................7
4.4. Client Side Map Descriptors..........................................................................................8
4.4.1. Map Descriptor Example.......................................................................................9
5. FieldServer as a DH+ Server........................................................................................10
5.1. Server Side Connection Descriptors...........................................................................10
5.2. Server Side Node Descriptors.....................................................................................10
5.3. Server Side Map Descriptors ......................................................................................11
6. Driver Notes...................................................................................................................13
6.1. Continuous Map Descriptors.......................................................................................13
6.2. Checksum ...................................................................................................................13
6.3. DH+ as FieldServer Server.........................................................................................13
6.4. Command Support......................................................................................................13
7. Revision History............................................................................................................14
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 3 of 14
1. Allen Bradley DH+ Description
The DH+ driver allows the FieldServer to transfer data to and from devices using DH+ protocol.
The Communications Adapter card is included with the FieldServer. The FieldServer can
emulate either a Server or Client.
The information that follows describes how to expand upon the factory defaults provided in the
configuration files included with the FieldServer.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 4 of 14
2. Driver Scope of Supply
2.1. Supplied by FieldServer Technologies for this Driver
SMC PART # DESCRIPTION
FS-SPA23027 DH+ cable
2.2. Provided by the supplier of 3rd Party Equipment
2.2.1. Hardware
PART # DESCRIPTION
AB DH+ compatible PLC, e.g. SLC5/03, PLC 5/40, etc
1
DH+ Client, e.g. RSView, Wonderware, Intellution FIX, GE Cimplicity, etc.
2
1
If FieldServer used as Allen Bradley DH+ Client
2
If FieldServer used as Allen Bradley DH+ Server
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 5 of 14
3. Hardware Connections
Configure the PLC according to manufacturer’s instructions and configure checksum to use
BCC checksum, not CRC.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 6 of 14
4. Configuring theFieldServer as a DH+ Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer
Configuration Manual. The information that follows describes how to expand upon the factory
defaults provided in the configuration files included with the FieldServer (See “.csv” sample files
provided with the FS).
This section documents and describes the parameters necessary for configuring the FieldServer
to communicate with a DH+ Server.
4.1. Data Arrays/Descriptors
The configuration file tells the FieldServer about its interfaces, and the routing of data
required. In order to enable the FieldServer for DH+ communications, the driver
independent FieldServer buffers need to be declared in the “Data Arrays” section, the
destination device addresses need to be declared in the “Client Side Nodes” section, and
the data required from the servers needs to be mapped in the “Client Side Map
Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being
the default.
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array
Data_Format Provides data format
Data_Array_Length Number of Data Objects 1-10,000
Example
// Data Arrays
Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
DA_AI_01, Float, 200
DA_AO_01, Float, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200
Up to 15 alphanumeric
characters
Float, Bit,
UInt16, SInt16,
Uint32, Sint32,
Packet_Bit, Byte,
Packet_Byte,
Swapped_Byte
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 7 of 14
4.2. Client Side Connection Descriptors
Section Title
Connections
Column Title Function Legal Values
Port Port name DH+
Protocol Specify protocol used AB_DH+
Example
// Client Side Connections
Connections
Port, Protocol
DH+, AB_DH+
4.3. Client Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node
Node_ID
Protocol Specify protocol used AB_DH+
PLC_Type Specify PLC Type Being Polled PLC3, PLC5, SLC5
Example
// Client Side Nodes
Nodes
Node_Name, Node_ID, Protocol, PLC_Type, Port
PLC 1, 1, AB_DH+, SLC5, DH+
Node ID of physical server node
(PLC)
Up to 32 alphanumeric
characters
1-255
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 8 of 14
4.4. Client Side Map Descriptors
Section Title
Map_Descriptors
Column Title Function Legal Values
Map_Descriptor_Name
Name of this Map
Descriptor
Name of Data Array where
Data_Array_Name
data is to be stored in the
FieldServer
Data_Array_Offset
Function
Node_Name
File_Type
File_Number
Address
Starting location in Data
Array
Function of Client Map
Descriptor
Name of Node to fetch
data from
File type in PLC N, B
File Number in PLC 0-255
Starting address of read
block
Length Length of read block 1-255
Data_Array_Low_Scale* Scaling zero in Data Array
Data_Array_High_Scale* Scaling max in Data Array
Node_Low_Scale*
Node_High_Scale*
Scaling zero in Connected
Node
Scaling max in Connected
Node
Up to 32 alphanumeric
characters
One of the Data Array
names from “Data Array”
section above
0 to maximum specified
in “Data Array” section
above
RDBC, WRBC, WRBX
One of the node names
specified in “Client Node
Descriptor” above
0 – 255
-32767 to 32767, default
0
-32767 to 32767, default
100
-32767 to 32767, default
0
-32767 to 32767, default
100
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 9 of 14
4.4.1. Map Descriptor Example
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function Node_Name File_Type, File_Number, Address, Length Scan_Interval
CMD_AI_01, DA_AI_01, 0, Rdbc PLC 1 N 10 0 16 1.0s
CMD_AO_01, DA_AO_01, 0, Rdbc PLC 1 N 11 0 16 1.0s
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function Node_Name File_Type, File_Number, Address, Length Scan_Interval
CMD_DI_01, DA_DI_01, 0, Rdbc PLC 1 B 12 0 16 1.0s
CMD_DO_01, DA_DO_01, 0, Rdbc PLC 1 B 13 0 16 1.0s
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 10 of 14
5. FieldServer as a DH+ Server
5.1. Server Side Connection Descriptors
Section Title
Connections
Column Title Function Legal Values
Port Port name DH+
Protocol Specify protocol used AB_DH+
Example
// Server Side Connections
Connections
Port, Protocol
DH+, AB_DH+
5.2. Server Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node
Node_ID
Protocol Specify protocol used AB_DH+
PLC_Type Specify PLC Type Being Polled PLC3, PLC5, SLC5
Example
// Server Side Nodes
Nodes
Node_Name, Node_ID, Protocol, PLC_Type
DHP_Srv_11, 11, AB_DH+, SLC5
Node ID of virtual server node
(FieldServer)
Up to 32 alphanumeric
characters
1-255
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 11 of 14
5.3. Server Side Map Descriptors
Section Title
Map_Descriptors
Column Title Function Legal Values
Map_Descriptor_Name
Name of this Map
Descriptor
Name of Data Array where
Data_Array_Name
data is to be stored in the
FieldServer
Data_Array_Offset
Function
Node_Name
File_Type
Starting location in Data
Array
Function of Client Map
Descriptor
Name of Node to fetch
data from
File type in PLC N, B
File_Number File number in PLC 0-255
Address
Starting address of read
block
Length Length of read block 1 - 255
Data_Array_Low_Scale* Scaling zero in Data Array -32767 to 32767, 0
Data_Array_High_Scale* Scaling max in Data Array -32767 to 32767, 100
Node_Low_Scale*
Node_High_Scale*
Scaling zero in Connected
Node
Scaling max in Connected
Node
Up to 32 alphanumeric
characters
One of the Data Array
names from “Data Array”
section above
0 to maximum specified
in “Data Array” section
above
Server
One of the node names
specified in “Client Node
Descriptor” above
0 - 255
-32767 to 32767, 0
-32767 to 32767, 100
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 12 of 14
Map Descriptor Example
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, File_Type, File_Number, Address, Length, Data_Array_Low_Scale, Data_Array_High_Scale, Node_Low_Scale, Node_High_Scale
SMD_AI_01, DA_AI_01, 0, Server, DHP_Srv_11, N, 10, 0, 200, 0, 100, 0, 100
SMD_AO_01, DA_AO_01, 0, Server, DHP_Srv_11, N, 11, 0, 200, 0, 100, 0, 100
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, File_Type, File_Number, Address, Length
SMD_DI_01, DA_DI_01, 0, Server, DHP_Srv_11, B, 12, 0, 200
SMD_DO_01, DA_DO_01, 0, Server, DHP_Srv_11, B, 13, 0, 200
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-12_DH+ Manual Page 13 of 14
6. Driver Notes
6.1. Continuous Map Descriptors
RS View has been known to crash if it tries to read a server mapping that is discontinuous.
e.g. Server map 1: N21: 0-31
Server map 2: N21: 32-100
This will panic the FieldServer and crash RS view as the DH+ will attempt to map N21:
0-100
If set up as: Server Map 1: N21: 0-100
No problems are experienced
6.2. Checksum
When selecting checksum options for DH+ devices communicating to the FieldServer, take
note that BCC (Block Check Sum) is supported, whereas CRC (Cyclic Redundancy Check)
is not.
6.3. DH+ as FieldServer Server
If the FieldServer is to be polled by the DH+ network, then it is important to declare the
station address in the “FieldServer” portion of the configuration file.
e.g. FieldServer
Title, System_Station_Address
DCC099 Primserv.csv v3.00u, 11
This sets the FieldServer address to 11. The Node_ID on the server side must then be the
same as the station address declared.
6.4. Command Support
The following commands are supported by the FieldServer for the various PLC types:
PLC_Type File_type FNC Read FNC Write
N 1 Range Read 0 Range Write N7: 3, L5
PLC3
PLC5
SLC5
F 1 Range Read 0 Range Write F12: 3, L5
B 1 Range Read 2 Bit Write B3/4: 5, l5
N 1 Range Read 0 Range Write N7: 3 , L5
F 1 Range Read 67 Typed Write F12: 3, L5
B 1 Range Read 26 Read Modify Write B3/4: 5, L5
N A2
F A2
B A2
I A2
O A2
Protected Typed
Logical Read
Protected Typed
Logical Read
Protected Typed
Logical Read
Protected Typed
Logical Read
Protected Typed
Logical Read
Protected Typed
AA
Logical Write
Protected Typed
AA
Logical Write
Protected Typed
AB
Logical Write
- - I: 13, L5
- - O: 13, L5
Typical
Command
N7: 3, L5
B3/4: 5, L7
B3/4: 5, L8
FS-8700-12_DH+ Manual Page 14 of 14
7. Revision History
Date
11/28/03 1 MF Updated formatting
2/18/04 2 JD Releasing
Driver
Version
Document
Revision
Resp Comment
