FieldServer FS-8700-105 User Manual

A Sierra Monitor Company
Driver Manual
(Supplement to the FieldServer Instruction Manual)
National Time & Signal FACP
(Fire Alarm Control Panel) Driver
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after May 1, 2001
FS-8700-105_National_Time_and_Signal_FACP Manual Table of Contents
TABLE OF CONTENTS
1. National Time & Signal FACP Driver Description......................................................... 1
2. Driver Scope of Supply....................................................................................................... 2
1.01 Supplied by FieldServer Technologies for this driver ................................................... 2
3. Hardware Connections....................................................................................................... 3
1.02 Connection Notes...........................................................................................................3
4. Configuring the FieldServer as a National Time & Signal FACP Client......................4
1.03 Data Arrays/Descriptors................................................................................................. 4
1.04 Client Side Connection Descriptions ............................................................................. 5
1.05 Client Side Node Descriptors......................................................................................... 6
1.06 Client Side Map Descriptors.......................................................................................... 7
4.1.1. FieldServer Related Map Descriptor Parameters...................................................... 7
4.1.2. Driver Related Map Descriptor Parameters .............................................................. 7
4.1.3. Timing Parameters...................................................................................................... 8
4.1.4. Map Descriptor Example 1 – Port has no Sub-Ports................................................. 9
4.1.5. Map Descriptor Example 2 – Port has Sub-Ports.................................................... 10
5. Configuring the FieldServer as a National Time & Signal FACP Server................... 11
Appendix A. Advanced Topics.............................................................................................. 12
Appendix A.1. Modifying the Trouble String Table............................................................. 12
Appendix A.2. Controlling which arrays get cleared when a Reset is received. .................. 12
Appendix A.3. Controlling case sensitivity in Trouble String Matching.............................. 13
Appendix A.4. Trouble Strings ............................................................................................. 13
Appendix A.5. Panel / Driver Synchronization..................................................................... 15
Appendix A.6. Connection Status.........................................................................................15
Appendix A.7. Node Status................................................................................................... 15
Appendix B. Troubleshooting tips........................................................................................ 17
Appendix B.1. Connection Tips & Hints.............................................................................. 17
Appendix B.2. Exposing Driver operating Statistics............................................................ 17
Appendix B.3. Driver Error Messages.................................................................................. 18
Appendix C. Revision History............................................................................................... 25
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 1 of 25
1. National Time & Signal FACP Driver Description
Fire Alarm Control Panels (FACPs) are manufactured by the National Time and Signal Corp. The series 900 and 902 FACP’s can be purchased with a ‘BACnet’ interface option. When suitably equipped and when this interface is enabled, the FACPs can transmit data to a FieldServer which can, in turn, make this data available to other devices including devices which are capable of communicating using the BACnet and other protocols.
This driver is a passive client driver. This means that the driver does not actively poll for data but listens passively for data to be sent by the FACP’s that it is connected to. Messages sent by the panel are either ignored stored by the FieldServer based on panel status. How these messages are processed is dependent on the configuration.
No automatic panel data synchronization technique exists. The data in the FieldServer and the panel status have to be synchronized manually.
This is a serial driver. Data is transferred using RS-232 or RS-485 (with converter). The driver provides both client and server emulation. The server side of the driver is intended to
support FieldServer’s Quality Assurance program and is not intended to provide complete emulation of a FACP. Thus the server side is not fully documented. However, at a customer’s request the server side functionality can be documented and enhanced. If you are interested in this functionality, then please contact FieldServer’s sales group.
Max Nodes Supported FieldServer Mode Nodes Comments
Client 1 One such connection can be made per FieldServer port. Server
Server emulation provided for QA purposes only. Not supported or documented except at customer request.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 2 of 25
2. Driver Scope of Supply
1.01 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART #
Description
FS-8917-16 RJ45 pigtail cable. FS-8700-105 Driver Manual.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 3 of 25
3. Hardware Connections
The FieldServer is connected to the ‘BACnet’ port of the FACP as shown in connection drawing.
TD
GND
CH1 -
GND
CH2 +
CH2 -
CH1 +
RD
Pin 1 = RX - Brown
Pin 8 = TX - Orange/White
Pin 5 = GND - Blue/White
1.02 Connection Notes
A FACP network consists of up to 32 panels. One of those panels acts as the network interface by means of its ‘BACnet’ interface port. This interface serves data to the FieldServer by means of a serial connection. Each one of these connections requires exclusive use of a FieldServer port. Thus, only one network of FACP’s can be connected to one FieldServer serial port.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 4 of 25
4. Configuring the FieldServer as a National Time & Signal FACP Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” sample files provided with the FS). This section documents and describes the parameters necessary for configuring the FieldServer to communicate with a National Time & Signal FACP Server.
1.03 Data Arrays/Descriptors
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable the FieldServer for National Time & Signal FACP driver communications, the driver independent FieldServer buffers need to be declared in the “Data Arrays” section, the destination device addresses need to be declared in the “Client Side Nodes” section, and the data required from the servers needs to be mapped in the “Client Side Map Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array
Up to 15 alphanumeric characters Float, Bit, UInt16, SInt16,
Data_Array_Format
Provide data format. Each Data Array can only take on one format.
Packed_Bit, Byte, Packed_Byte, Swapped_Byte
Number of Data Objects. Must be
Data_Array_Length
larger than the data storage area required by the Map Descriptors for
1-10,000
the data being placed in this array.
Example
// Data Arrays Data_Arrays Data_Array_Name, Data_Format, Data_Array_Length, DA_AI_01, UInt16, 200 DA_AO_01, UInt16, 200 DA_DI_01, Bit, 200 DA_DO_01, Bit, 200
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 5 of 25
1.04 Client Side Connection Descriptions
Section Title
Connections
Column Title Function Legal Values
Port
Specify which port the device is connected to the FieldServer
P1-P81 National_Time_FACP,
Protocol Specify protocol used
National_Time_Fire, natsco_facp
Baud* Specify baud rate
9600 Baud (Vendor
limitation) Parity* Specify parity None (Vendor limitation) Data_Bits* Specify data bits 8 (Vendor limitation) Stop_Bits* Specify stop bits 1 (Vendor limitation) Handshaking* Specify hardware handshaking
None
Specify a time in seconds. The driver reports the connection as being offline when a new valid
NATSfacp_Timeout*
message has not been received on the connection during this interval. Each time one is received the
0-600 seconds.
Default = 180Secs.
interval is restarted. If this parameter is omitted then the driver assumes a period of 180 seconds. Use this parameter to specify a Data Array. The Data Array need only contain one element as only the 1st element is used for the connection status. If the connection is ‘online’
st
element is set to 1. If the
Up to 15 alphanumeric
characters
NATSfacp_Status_DA*
then the 1 connection is offline then the 1st element is set to zero.
We recommend that the Length of the DA be set to 33. One element for the connection status and the other 32 elements for Node / Panel Status. Further information is provided in Appendix A.7
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for
details of the ports available on specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 6 of 25
Example
// Client Side Connections
Connections Port, Protocol, Baud, Parity, NATSfacp_Timeout, NATSfacp_Status_DA P8, National_Time_Fire, 9600, None, 120s, DA_NATS_STATUS1
1.05 Client Side Node Descriptors
Create one node for each panel connected to the National Time & Signal Network. You can have multiple nodes on the same port.
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters Node_ID
Protocol Specify protocol used
Connection
This parameter is used to specify the PANEL number.
Specify which port the device is connected to the FieldServer
1-32 National_Time_FACP,
National_Time_Fire, natsco_facp P1-P82
Example
// Client Side Nodes
Nodes Node_Name, Node_ID, Protocol, Connection Panel1, 1, National_Time_FACP, P1 Panel2, 2, National_Time_FACP, P1
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for
details of the ports available on specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 7 of 25
1.06 Client Side Map Descriptors
4.1.1. FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name
Data_Array_Name
Data_Array_Offset
Function
Name of this Map Descriptor Name of Data Array where data is to be stored in the FieldServer Starting location in Data Array Function of Client Map Descriptor
Up to 32 alphanumeric characters One of the Data Array names from “Data Array” section above 0 to maximum specified in “Data Array” section above
RDBC, WRBC, WRBX
4.1.2. Driver Related Map Descriptor Parameters
Column
Title
Function Legal Values
Node_Name Name of Node to fetch data from
You must specify one of the 4 choices.
If the ‘Any’ type is used then all messages will be stored using the MD irrespective of the Data
Data_Type
Type.
Do not create two MD’s with all parameters the same except that one has a specific Data Type and the other has ‘Any’. The driver can only store data in one MD.
Board
Loop
The Board Number. One set of Map Descriptors required for each board. The Loop number on the Board. One set of Map Descriptors required for each loop. Use one of the 4 permitted values shown on the
Port-Type
right. You can abbreviate the port-types to use the
st
1
character.
The address and length are used to specify a range
Address
of Port Numbers. Think of the Address as a synonym for port. Starting address of read block
One of the node names specified in “Client Node Descriptor” above
Alarm Trouble Supervisory Other Any
1, 2, 3 etc...
1,2,3 etc
Input; Output; Fault; P(Other)
1,2, 3 … etc
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 8 of 25
1, 2, 3 etc. Ensure that the length added to the offset is no greater than the Data Array length.
Length
Length of Map Descriptor. Specifies the number of ports processed by the MD.
Thus if address is 1 and length is 10 the Map Descriptor processes ports 1... 9 inclusive.
Set this parameter to ‘None’ to store data for a range of ports which do not have sub-ports. To store data for a specific port, set the sub-port type
Sub-Port­Type
appropriately. If the sub-port-type is ‘Other’, it must be specified in the configuration file as ‘S(Other)’ or 'S'. Only the first character is used,
Input; Output; Fault; S(other);
None therefore the configuration may omit the rest of the term (e.g. it is sufficient to specify ‘I’ for ‘Input’)
Sub-Port May be omitted if sub-port-type=None. 1,2,3 etc
4.1.3. Timing Parameters
Scan_Interval
This commonly used parameter has no meaning for this driver as the driver is a passive client driver and does not poll for data.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 9 of 25
4.1.4. Map Descriptor Example 1 – Port has no Sub-Ports.
This Map Descriptor is used to store messages from ‘Panel2’ if they meet the following criteria
Panel
= Node ‘Panel2’‘s Node_ID Number Board = 1 Loop = 2 Port-Type = Inputs Port = 1 to 100 (Address and length
parameters) Data_Type = Alarms
Typically you will create one MD for each of the 4 data types for each Panel/Board/Loop/Port-Type/Port combination. Only messages which report trouble allocated to the ‘Alarm’ category will update the DA below. Appendix A.4 provides more information on which messages are allocated to each data type.
If any of the Port’s has a sub-port then additional MD’s must be created because the Sub-Port_Type = None.
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name Board Loop Data_Type Port_Type Address Length Sub-Port_Type P2B3L4_ia, P2B3L4_iA , 0, Passive_Client , Panel2 , 1 2 Alarms Input 0, 100 None
Driver cannot poll. Always use this keyword.
Address is a synonym for ‘Port’. Use the length to tell the driver the Port range
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 10 of 25
4.1.5. Map Descriptor Example 2 – Port has Sub-Ports.
This Map Descriptor is used to store messages from ‘Panel2’ if they meet the following criteria
Panel Number = Node ‘Panel2’s Node_ID Board = 1 Loop = 2 Port-Type = Inputs Port = 20 Data_Type = Alarms Sub-Port-Type = Output Sub-Port-
= 1
Number
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Board, Loop, Data_Type, Port-Type, Address, Length, Sub-Port-Type Sub-Port P2B3L4_ia, P2B3L4_iA , 0, Passive_Client , Panel2 , 1, 2, Alarms, Input, 0, 1, Output 1
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 11 of 25
5. Configuring the FieldServer as a National Time & Signal FACP Server
Server side emulation has been developed and is functional. (FST use this functionality to complete the QA requirements and to ensure that the driver is compatible with firmware changes not directly related to this driver.)This has, however, not been documented and is not supported. If you require the server side of this driver for one of your projects then contact the sales group at FST.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 12 of 25
Appendix A. Advanced Topics
Appendix A.1. Modifying the Trouble String Table
The trouble string table can be modified/extended using the configuration file.
In the example below, the keyword ‘Broken’ is added and allocated an index value of 1 and a trouble type of 1. When this message is received it will not be used to clear the Data Arrays
The following are permitted Trouble_Types 1 – Alarms 2 – Troubles 3 – Supervisories 4 – Others
Use the same system to modify existing entries in the table. If the Trouble string exists then the driver updates the other values. If the string doesn’t exist then a new entry is added. The table has space for 100 strings.
Driver_Table Trouble_String, Index_Value, Trouble_Type, Is_Reset, Protocol Broken, 1, 1, No, National_Time_Fire Fixed, 0, 1, No, National_Time_Fire DigiFail, 99, 2, No, National_Time_Fire
Appendix A.2. Controlling which arrays get cleared when a Reset is received.
When a reset message is received on a port then all Data Arrays being used by the Map Descriptors on that port will have their values set to zero. Specifically: each Map Descriptor is associated with a section of a Data Array based on the ‘Data Array Offset’ parameter and the ‘Length’ parameter specified on the Map Descriptor. It is these sections that get reset when a reset message is received. It is possible to modify this behavior by poking the value 1 into offset 5 in the stats Data Array. You can do this on a temporary basis using the Ruinet utility or on a permanent basis by including the following in your configuration. Only the Data Arrays associated with Map Descriptors with panel numbers matching the panel number of the incoming message are reset.3
Data_Arrays Data_Array_Name, Data_Format, Data_Array_length natsfacp-stats, natsfacp-stats, 1000
3
If you cut and past the above text into your configuration file ensure that you do not duplicate the line which says
“natsfacp-stats, natsfacp-stats, 1000,” Duplication will cause an error.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 13 of 25
Preloads Data_Array_Name, Preload_Data_Value, Preload_Data_Index natsfacp-stats, 1,
5
Appendix A.3. Controlling case sensitivity in Trouble String Matching
When a message is processed the driver extracts the 8 character trouble string from the message and compares it against the contents of the table provided in Appendix A.4. The comparison is case sensitive by default. It is possible to modify this behavior by poking the value 1 into offset 1 in the stats Data Array.
You can do this on a temporary basis by using the Ruinet utility or on a permanent basis by including the following in your configuration.
Data_Arrays, Data_Array_Name, Data_Format, Data_Array_length natsfacp-stats, UINT32, 1000
Preloads, Data_Array_Name, Preload_Data_Value, Preload_Data_Index natsfacp-stats, 1, 1
Appendix A.4. Trouble Strings
The table below outlines the various messages which are reported by a National Time & Signal FACP. Each message is allocated to a data type. The data type can be changed – refer to Appendix A.1.for more information.
If a message is processed with a trouble string corresponding to a row in the table indicating that the string is used for a reset then the Data Arrays used for that connection will be cleared.
Trouble String
Index value
Data_Type Used to Reset Data Arrays
Alarm 1 Alarms 0 Suprv 2 Supervisories 0 OutpShrt 3 Troubles 0 OutpOpen 4 Troubles 0 OutpOcur 5 Troubles 0 InpOpen 6 Troubles 0 I/PwrFail 7 Troubles 0 Wdt Fail 8 Troubles 0 Low Batt 9 Troubles 0 AC Fail 10 Troubles 0
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 14 of 25
Trouble String
Index value
Data_Type Used to Reset Data Arrays
GndFault 11 Troubles 0 CommFail 12 Troubles 0 WalkTest 13 Troubles 0 InpDsbl 14 Troubles 0 OutpDsbl 15 Troubles 0 CommDsbl 16 Troubles 0 Sys Fail 17 Troubles 0 24V Fail 18 Troubles 0 LoopTbl 19 Troubles 0 InputTbl 20 Troubles 0 AudioLink 21 Troubles 0 DVR Fail 22 Troubles 0 DirtySnsr 23 Troubles 0 MicTimer 24 Troubles 0 DeviceErr 25 Troubles 0 Addr Err 26 Troubles 0 ExtraDev 27 Troubles 0 ShortTbl 28 Troubles 0 Open Tbl 29 Troubles 0 OverHeat 30 Troubles 0 DigiFail 31 Troubles 0 Switch 32 Others 0 RemoteAct 33 Others 0 Monitor 34 Others 0 AlrmSilG 35 Troubles 0 PnlSil L 36 Troubles 0 Reset G 37 Troubles IS_RESET Brd Dsbl 38 Troubles 0 PortDsbl 39 Troubles 0 ActnDsbl 40 Troubles 0 Drill G 41 Alarms 0 Drill L 42 Alarms 0 AlrmSil L 43 Troubles 0 PnlSil S 44 Troubles 0 Reset L 45 Troubles 0 Burglar 46 Others 0 DuplAddr 47 Troubles 0 TechMode 48 Troubles 0 ConfigErr 49 Troubles 0 DigiClasA 50 Troubles 0 City Dis 51 Troubles 0 Dev Stat 52 Others 0
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 15 of 25
Trouble String
Index value
Data_Type Used to Reset Data Arrays
Call In 53 Troubles 0 MicSwitch 54 Troubles 0 PnlSil G 55 Troubles 0 Unknown 56 Troubles 0
Appendix A.5. Panel / Driver Synchronization
There is no automatic system of synchronizing the Fire Alarm Panels and the data in the FieldServer. This is because the FieldServer cannot poll for status information from the panel but has to rely on the panel sending messages with changes in status.
To synchronize the panel to the FieldServer you should push the reset button on the Fire Alarm Panel. When this is done the driver clears all the Data Arrays associated with the connections. In this case ‘associated’ means those DA’s used by the Map Descriptors logically connected to the serial port on which the message was received. This is the default behavior of the driver – however it is possible to limit the Data Arrays which get cleared so that only those DA’s associated with the panel which sent the message get cleared. Further information is provided in Appendix A.2
Appendix A.6. Connection Status
This is a passive client driver connected to a Fire Alarm Panel. Normally there are no alarms and thus there would be no way for the FieldServer to know if it was still connected to the FACP network. The National Time & Signal panel, however, sends a message at a regular interval of approximately one minute. This driver uses this message to monitor and report the status of the connection.
A connection timeout may be specified. Read about the NATSfacp_Timeout and NATSfacp_Status_DA connection parameters in section 1.04. If the driver doesn’t receive a ‘valid’ message within this timeout period then the driver considers the connection as lost. It reports this providing a connection status bit which can be monitored by the upstream node. The bit is set to 1 when the connection is good and set to zero when the connection is lost.
A ‘valid’ message is one that does not fail parsing.
Appendix A.7. Node Status
If the FACP sends a message that one of its networked panels has a communications failure by sending a message with the Trouble String = “CommFail” then the driver reports that panel/Node as offline. If the event is restored to normal then the driver reports the node as being online. Furthermore, if a valid message is received from a panel in an offline state then the driver sets the node status to online.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 16 of 25
Thus: A Comms Fail message puts the node offline and the node is put online when either a valid message is received from the panel or the Comms Fail event is restored.
The driver reports the node status by updating the Data Array specified by the NATSfacp_Status_DA parameter specified on the connection. If this parameter is not specified then the node status cannot be reported. Ensure the Data Array is at least 33 items long. The 1st element is used for the connection status. The remaining 32 elements are used for node status. One element for each node and the offset corresponds to the Node_ID/Panel number.
This is the only way that an upstream node can monitor if the node is online/offline. The data obtained by this driver will always be made available to other drivers even if the node associated with the driver is offline.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 17 of 25
Appendix B. Troubleshooting tips
Appendix B.1. Connection Tips & Hints
The Panel must be configured to send ‘Extended’ Messages. This is not the default state. The following procedure is used to achieve this setting.
1) Hit Menu/Exit
2) Use arrow keys to go to Tech Menu
3) Press up arrow twice to enter password of 2000
4) Hit Enter (at this point the panel makes a beeping noise)
5) Hit Panel Silence
6) Use arrow keys to move to Factory
7) Hit Enter
8) Use arrow keys to move to RS232CNFG
9) Hit Enter
10) Use arrow keys to move to Settings
11) Hit Enter
12) Use arrow keys to move to Expanded
13) Hit Enter
14) Hit Exit
15) Hit Exit
16) Use arrow keys to move to Tech Exit
17) Hit Enter
Appendix B.2. Exposing Driver operating Statistics
The driver makes some of its operating statistics available in a Data Array where they can be read by an upstream device. The lines from the example below can be cut and pasted into a configuration file.
Data_Arrays Data_Array_Name, Data_Format, Data_Array_length natsfacp-stats, UINT32, 1000
The driver maintains one set of stats for each communication port. To determine the base offset use the following formula:
Base Offset = Port Number * 100 where Port Number is the port number printed in the error log by message #22.
Relative
Offset4
Description
4
Add this number to the Base Offset
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 18 of 25
Relative
Offset4
Description
6 Increments each time a port 'Alive' message is received 7 Increments each time a message is received and is sent to the parsing routine
8
Increments by message length each time a message is received and is sent to the
parsing routine 9 Increments each time a message is received and is sent to the parsing routine 10 Increments each time a message is received and is sent to the store routine
11
Increments each time a message is received and is sent to the store routine and
results in a store 12 Increments each time a message is received and is sent to the reset routine
13
Increments each time a message is received and is sent to the reset routine and
at least one DA was reset 14 Panel Number: Most recent message (after parse, prior to store) 15 Board Number: Most recent message (after parse, prior to store) 16 Loop Number: Most recent message (after parse, prior to store)
17
Port Type: Most recent message (after parse, prior to store). ASCII value
shown. ASCII value shown. 28 Port Number: Most recent message (after parse, prior to store)
19
Sub Port Type: Most recent message (after parse, prior to store). ASCII value
shown. 20 Sub Port: Most recent message (after parse, prior to store) 21 Trouble String Index: Most recent message (after parse, prior to store)
22
Trouble Level: Most recent message (after parse, prior to store). Ascii value
shown.
Data_Arrays, Data_Array_Name, Data_Format, Data_Array_length, natsfacp-stats, UINT32, 1000,
Appendix B.3. Driver Error Messages
Message Interpretation and Corrective Action
This message is normally only printed when the driver is NATS:#01a FYI Validation ignored for simulation. MD=%s
being tested for QA purposes. If it is printed during
normal operation, take a log and call Technical support.
There are a number of variants of this message. Be sure to
quote the correct one when reporting the error. NATS:#02a Err. Bad Port­Type=0x%x. Expected I/O/F/P.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
A Map Descriptor is being validated and has been rejected
because the ‘Port-Type’ has not been correctly specified
FS-8700-105_National_Time_and_Signal_FACP Manual Page 19 of 25
Message Interpretation and Corrective Action
NATS:#02b Err. Bad Port­Type=%c. Expected I/O/F/P.
NATS:#05 Err. Bad Sub­Port=%d.
The sub-port type has not been specified for the Map
Descriptor.
NATS:#06a Err. Bad Sub­Port-Type=0x%x. Expected I/O/F/S/N. NATS:#06b Err. Bad Sub­Port-Type=%c. Expetced
A Map Descriptor is being validated and has been rejected
because the ‘Sub-Port-Type’ has not been correctly
specified. I/O/F/S/N.
NATS:#07 Err. Loop Not specified NATS:#08 Err. Board Not specified
The Loop has not been specified for the Map Descriptor.
The Board has not been specified for the Map Descriptor.∗
A message is being processed to determine the event that
is being reported. During the processing an error was
found. If this error occurs occasionally then you could
assume that it is an occasional corrupt message. You
could determine this yourself. The driver prints a copy of
the incoming messages on the ‘F’ screen (when using NATS:#09 Err. Parse: Found a '%c' instead of a 'L' for Loop.
Ruinet). Note the messages and look for corruption. If
there is any take steps to improve the connection.
If it occurs frequently then assume that there is a
systematic error. Take a log, note the error and call Tech
Support.
Valid Port Types are I/O/F/P. NATS:#10 Err. Undefined
Loop
The parameter heading ‘Loop’ has been provided on the
Map Descriptor in the configuration CSV file, but the
parameter value has not been specified.∗
This message is normally only printed when the driver is NATS:#11a FYI Validation ignored for simulation. MD=%s
being tested for QA purposes. If it is printed during
normal operation, take a log and call Technical support.
There are a number of variants of this message. Be sure to
quote the correct one when reporting the error. NATS:#12 Err. Undefined
Board
NATS:#13 Err. Undefined Sub-Port
The parameter heading ‘Board’ has been provided on the
Map Descriptor in the configuration CSV file, but the
parameter value has not been specified.
The parameter heading ‘Sub-Port’ has been provided on
the Map Descriptor in the configuration CSV file, but the
parameter value has not been specified.∗ NATS:#14 Err. Undefined The parameter heading ‘Port-Type has been provided on
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 20 of 25
Message Interpretation and Corrective Action
Port_Type the Map Descriptor in the configuration CSV file, but the
parameter value has not been specified.∗ NATS:#15 Err. <%s> file not found. NATS:#16a Err. Diagnostic 1 NATS:#16b Err. Diagnostic 2
This message is normally only printed when the driver is
being tested for QA purposes. If it is printed during
normal operation, take a log and call Technical support.
FieldServer’s provide ‘write-through-read’ technology but
it has been defeated for this driver because this driver
cannot write to the FACP panel as it is a passive client
driver. When you see this message you know that some
other node (or possibly a ruinet user) has poked a value NATS:#17 Err. Driver cannot
poll. Cache MD Ignored.
into one of the Data Arrays used by the driver. When this
occurs the FieldServer attempts to write the new value to
the FACP. This is not permitted and the message is
printed. You can review the configuration checking to see
if any Data Array areas used by the different drivers
overlap. Or you can check to see that the other
nodes/connections in the configuration are not writing to
the Data Array being used to store panel data.
The trouble string in the message is contained in character
positions 28-36. The driver extracted a trouble string
from an incoming message and then compared the string
to a look-up table of trouble strings. There was no match.
Apply one of the following:
Determine if this is a legitimate trouble string. Is the rest
of the message corrupt or valid? Do other messages have
the same trouble string? Does the equipment vendor
confirm that this is a new trouble string? If it is a NATS:#18 Err. Parse: Trouble
String Unknown.
legitimate trouble string and the driver does not recognize
it then you need to add the string to the driver’s look-up
table. More information is provided in Appendix A.1 .
Once you have added the new string to the configuration,
reset the FieldServer for the changes to take effect. Now
generate the same event again. This time there should be
no message.
The case sensitivity of the look-up can be controlled.
More information is provided in Appendix A.3
If neither of the previous strategies work and you are sure
this isn’t a rare corrupt message then take a log and call
tech Support.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 21 of 25
Message Interpretation and Corrective Action
When the driver was parsing a message it found that it NATS:#19 Err. Parse: Found a
'%c' instead of a 'P' for Panel.
could not correctly extract some data. It is possible that
new versions of FACP firmware support new values that
this driver does not know.
If this error is printed on rare occasions then it could be NATS:#20 Err. Parse: Found a
'%c' instead of a 'B' for Board.
attributed to a corrupted message. You can choose to
ignore the problem, or you could resynchronize the panel
to the FieldServer. Appendix A.5 in this manual provides
information on how to do this. NATS:#21 Err. Parse: Found a
'%c' instead of a '%s' for PortType.
If it is printed often then assume that there is new
permitted value. Confirm with the equipment vendor and
then take a log and call tech support. NATS:#22a FYI. Port(=%d) Supervision Timeout set to %d Secs NATS:#22b FYI. Port(=%d) Supervision Timeout reset to %d Secs
When the driver starts up it prints this message to alert
you to the default ‘timeout’ value. You can safely ignore
this message if you are satisfied with the setting. If you
want to change the setting then read about the
‘NATSfacp_Timeout’ parameter in section 1.04 NATS:#23 Err. Parse: Found a
'%c' instead of a '%s' for
Please read and apply the same notes as with message 19. SubPort.
The driver needs a Data Array to store the status of the
connection. A different DA is required for each NATS:#24 FYI. Can’t store connection status. DA required.
connection. Only the 1st element of the DA is used.
Create the DA (See section 1.03) and then use that name
when specifying the ‘NATSfacp_Status_DA’ parameter
on the connection. More information is provided in
section 1.04
If no valid message has been received in the connection
timeout period then this message is printed. The
connection status is updated too, if a NATS:#25 Err. Going offline. No msgs in last %ld Secs. (%d)
NATSfacp_Status_DA’ parameter is specified on the
connection. More information is provided in section 1.04.
If the loss of the connection corresponds to your
expectations then ignore the message. If not, then
investigate why the panel lost its connection to the
FieldServer.
When a valid message is received on a connection then
this message is printed. No corrective action is required. NATS:#26 FYI. Going online. New msg rcvd. (%d)
However, if the message was unexpected then it may
indicate that the connection between the Panel and
FieldServer was lost for a period of time and recovered.
You may wish to investigate the loss of the connection.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 22 of 25
Message Interpretation and Corrective Action
The message is also printed the very 1st time that a valid
message is received.
Typically the message preceding this one provides the
reason and that issue must be resolved to prevent this NATS:#27 Err. Parse Failed
message being printed. The message is printed a small
number of times and is suppressed for subsequent similar
errors.
This message will typically be printed when the
terminating characters of a message are not received and a
new message is received from the panel.
NATS:#28 Err. Parse: Msg too long. Ignored. Len=%d
If the message is printed rarely, you could treat the source
as an occasional corrupt message. Reset the configuration
error light by clearing the error log using the <R>eset key.
If the message is printed frequently or can be produced
systematically take a log and call Tech Support.
The address/port contained in a message is used to
determine the offset into a Data Array when data is stored.
This message is printed when the required storage offset NATS:#29 Err. MD=%s too short. Act=%d Rqd=%d
is larger than the range of addresses specified on the Map
Descriptor being used to store the data. Edit the
configuration, adjusting the Length parameter. Download
the modified configuration file to the FieldServer and
reset the FieldServer for your changes to have effect.
A message has been received and when its Panel number,
Board number, Loop Number, Port-Type, Port Number
(and possibly Sub-Port-Type and Sub-Port-Number) are
analyzed, the driver cannot find a Map Descriptor suitable
for the storage of the event contained in the message.
You need one node configured for each Panel that will be
sending messages to the FieldServer using a single NATS:#30 Err. Message ignored. No suitable storage location.
connection. The Node_Id must match the panel number.
Then, for each node, you need one Map Descriptor (MD)
for each Board in each of those panels, whose events, will
be sent to the FieldServer. In fact you need one for each
Board / Loop / Port-Type combination in the system. Use
the parameters called Address and Length, on each MD,
to specify a range of port numbers.
If a port has sub ports then for each port that has a sub-
port you will need a set of MD’s, one for each Sub-Port-
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 23 of 25
Message Interpretation and Corrective Action
Type / Sub-Port-Number combination.
The message which follows Message #30, in the error log
will provide a suggestion as to what a suitable Map
Descriptor might look like.
To resolve this problem you must edit the configuration
file, creating a Map Descriptor suitable for the message
whose attributes are printed in the error log. Download the
updated configuration file to the FieldServer and then
reset the FieldServer for the changes to take effect.
This message is the extreme form of message #30. NATS:#31 Err. There are No MD's for this driver.
Resolve it the same way. First though, we suggest that
you review some of the Map Descriptor examples found
in section 4.1.4. Then read the notes for message #30. NATS:#32 Err. There are No MD's for Panel/Node_id=%d NATS:#33 FYI. Suggestion.
Read the notes for Message #30. Modify MD=%s
This message is printed if a reset message was received NATS:#34 Err. Reset Rcvd but
ignored.
but no suitable map descriptors were found and thus no
data was reset.
Read Appendix A.2 for more information. NATS:#35 FYI. Use an array called <%s> to expose diagnostic info.
This message may be safely ignored. It is printed to
prompt you to read Appendix B.2
The driver’s default list of recognized Trouble Strings can
be amended by means of configuration. An attempt to NATS:#36 Err. String <%s>
rejected. Max Len=8
modify the list has failed because no Trouble String can
be more than eight characters. Read Appendix A.1 then
correct the configuration file. Download the modified file
to the FieldServer and reset the FieldServer for your
changes to have effect. NATS:#37 FYI. String<%s> update. ndx/typ/rst=%d/%d/%d
NATS:#38 Err. No space. String <%s> rejected.
NATS:#39 FYI. String<%s> added. ndx/typ/rst=%d/%d/%d
Based on the notes in Appendix A.1 the Trouble String
Table has been successfully amended. No corrective
action is required.
The maximum number of Trouble Strings’ is 100. There
is no corrective action you can take other than to review
the exiting list and see if they are all necessary.
Based on the notes in Appendix A.1 the Trouble String
Table has been successfully added. No corrective action
is required. NATS:#40 Err. Cant set node Valid Panel / Node_ID’s are whole numbers in the range
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 24 of 25
Message Interpretation and Corrective Action
status if Node_ID < 1 (%d) 1 to 32. It is possible that this message could get pointed
as a consequence of a single corrupted message. If this
error occurs frequently then call Tech Support after taking
a log. NATS:#414 FYI. Cant store Node status. DA required.
See Message #24
This message is printed when a message is received that NATS:#42 Err. Node /
Panel=%d offline. Comms Failed. Port=%d
reports that communication to the indicated panel has
failed.
You must review and inspect your FACP equipment to
resolve this problem. NATS:#43 FYI. Node /
Panel=%d online. Port=%d
No corrective action is required. The message is printed
when a node that had been reported as having failed
communications has this state restored to normal.
This message is printed when the driver tries to update the
node status using the Data Array specified by the
‘NATSfacp_Status_DA’ parameter on the connection.
The offset used is equal to the node number and the driver
has found that the DA is too short to store the status as the NATS:#44 Err. DA=%s too short. Required=%d
required offset. Edit the configuration file, setting the DA
length to the required length printed in the message.
Typically you will set this length to 32 as there are 32
possible panels on a connection.
Download the modified config file to the FieldServer and
reset the FieldServer for your changes to take effect.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
FS-8700-105_National_Time_and_Signal_FACP Manual Page 25 of 25
Appendix C. Revision History
Date Resp Format
Driver Ver.
Doc. Rev.
Comment
6/29/04 PMC 1.00 0 Document Created 6/29/04 PMC 1.00 1
Added notes on Node Status and added some error messages.
Updated formatting. Redrew connection
7/6/04 Meg Meg 1.00 2
diagram. Some text modifications. Generally improved readability.
9/13/04 Meg Meg 1.00 3
Example table added for Appendix B2 – DUR0436. Updated connection diagram. Updated Max
10/15/04 Meg Meg 1.00 4
nodes supported table. Removed reference to R1&R2. Added connection notes. Changed Company to Corp. Refer DUR0471
12/29/04 JD 1.00 5 Releasing
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
Loading...
