FieldServer FS-8700-03 User Manual

Driver Version:

1.02

Document Revision:

1

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after December 2011

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-03 DF1

A Sierra Monitor Company

FS-8700-03 DF1 Driver Manual Table of Contents

TABLE OF CONTENTS

1 Allen Bradley DF1 Description ........................................................................................................................ 3

2 Driver Scope of Supply ................................................................................................................................... 3

2.1 Supplied by FieldServer Technologies for this driver ..................................................................................... 3

2.2 Provided by the Supplier of 3rd Party Equipment .......................................................................................... 3

3 Hardware Connections ................................................................................................................................... 4

4 Data Array Parameters ................................................................................................................................... 5

5 Configuring the FieldServer as a DF1 Client .................................................................................................... 6

5.1 Client Side Connection Parameters ............................................................................................................... 6

5.2 Client Side Node Parameters ......................................................................................................................... 7

5.3 Client Side Map Descriptor Parameters ......................................................................................................... 8

5.3.1 FieldServer Related Map Descriptor Parameters ................................................................................... 8

5.3.2 Driver Related Map Descriptor Parameters ........................................................................................... 8

5.3.3 Map Descriptor Example ........................................................................................................................ 9

6 Configuring the FieldServer as a DF1 Server ................................................................................................. 10

6.1 Server Side Connection Parameters ............................................................................................................ 10

6.2 Server Side Node Parameters ...................................................................................................................... 11

6.3 Server Side Map Descriptor Parameters ...................................................................................................... 11

6.3.1 FieldServer Specific Map Descriptor Parameters ................................................................................. 11

6.3.2 Driver Specific Map Descriptor Parameters ......................................................................................... 12

6.3.3 Map Descriptor Example ...................................................................................................................... 13

Appendix A. Troubleshooting .............................................................................................................................. 14

Appendix A.1. Continuous Map Descriptors ............................................................................................................ 14

Appendix A.2. Checksum ......................................................................................................................................... 14

Appendix A.3. Reading B File Types ......................................................................................................................... 14

Appendix B. Reference ........................................................................................................................................ 15

Appendix B.1. Command Support ........................................................................................................................... 15

Appendix B.2. Error Messages ................................................................................................................................. 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 3 of 16

FieldServer Technologies PART #

Description

FS-8915-10

UTP cable (7 foot) for RS-232 use

FS-8917-06

RJ45 to DB9M connection adapter

Part #

Description

AB DF1 compatible PLC, e.g. SLC5/03, PLC 5/40, etc. 1

DF1 Client, e.g. Wonderware, Intellution FIX, GE Cimplicity, etc.

2

1

2

1 ALLEN B RADLEY DF1 D E SCRIPTION

The DF1 driver allows the FieldServer to transfer data to and from devices over RS-232 using DF1 protocol. The
FieldServer can emulate either a Server or Client.

The information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer.

2 DRIVER S C OP E OF SUPP LY

2.1 Supplied by Fiel dServer Technologies fo r this driver

2.2 Provided by t h e Su pplier of 3

rd

Party Equipm e nt

If FieldServer used as Allen Bradley DF1 Client
If FieldServer used as Allen Bradley DF1 Server

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 4 of 16

FieldServer

P1

18

Allen Bradley PLC

COMM 2

FS8917-06

RJ45 CAT 5 Cable
FS8915-10

FS Function

RJ45 Pin#

DB9F Pin#

Color

RX 1 3

White

GND

4 5 Green

TX 8 2

Blue

3 HARDWA R E CONNECTIONS

It is possible to connect an Allen Bradley PLC to any of the RS-232 ports. These ports simply need to be configured
for an Allen Bradley PLC in the configuration file.

FS-8917-06 Pinouts

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 5 of 16

Section Title

Data_Arrays

Column Title

Function

Legal Values

Data_Array_Name

Provide name for Data Array

Up to 15
alphanumeric
characters

Data_Array_Format

Provide data format. Each Data Array can only take on one
format.

INT16, INT32, BIT,
FLOAT

Data_Array_Length

Number of Data Objects. Must be larger than the data storage
area required by the Map Descriptors for the data being placed in
this array.

1-10, 000
// Data Arrays

Data_Arrays

Data_Array_Name

, Data_Array_Format

, Data_Array_Length

DA_AI_01

, Float

, 200

DA_AO_01

, Float

, 200

DA_DI_01

, Bit

, 200

DA_DO_01

, Bit

, 200

4 DATA A RRAY PARAMETER S

Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is necessary

to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant data.

Example

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 6 of 16

Section Title

Connections

Column

Title

Function

Legal Values

Port

Specify which port the device is connected to the
FieldServer

P1-P83
Baud*

Specify baud rate

300 to 115200; 9600

Parity*

Specify parity

Even, Odd, None

Data_Bits*

Specify data bits

8

Stop_Bits*

Specify stop bits

1, 2

Protocol

Specify protocol used

DF1_FD, DF1_HD_MASTER,
DF1_HD_SLAVE

Checksum

Specify Checksum – refer to Appendix A.2

BCC, CRC-16

// Client Side Connections

Connections

Port

, Protocol

, Baud

, Parity

, Data_Bits

, Stop_Bits

P1

, DF1_FD

, 38400

, None

, 8

, 1

3

5 CONFI G U RING THE FIE L DSERVER AS A D F 1 CLIENT

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a DF1 Server

The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for DH+ communications, the driver independent FieldServer buffers need to be declared in the

“Data Arrays” section, the destination device addresses need to be declared in the “Client Side Nodes” section, and
the data required from the servers needs to be mapped in the “Client Side Map Descriptors” section. Details on

how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.

5.1 Client Side C o n n e ction Parameters

Example

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available

on specific hardware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 7 of 16

Section Title

Nodes

Column Title

Function

Legal Values

Node_Name

Provide name for node

Up to 32 alphanumeric characters

Node_ID

Node ID of physical Server node (PLC)

1-255

Protocol

Specify protocol used

DF1_FD, DF1_HD_MASTER,
DF1_HD_SLAVE

Port

Specify which port the device is connected to the
FieldServer

P1-P84

PLC_Type

Specify PLC
Communications type.

PLC3, PLC5, SLC5, Control_Logix
// Client Side Nodes

Nodes

Node_Name

, Node_ID

, Protocol

, PLC _Type

, Port

PLC_01

, 1

, DF1_FD

, SLC5

, P1

4

5.2 Client Side No d e Paramet e r s

Example

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available

on specific hardware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 8 of 16

Column Title

Function

Legal Values

Map_Descriptor_Name

Name of this Map Descriptor

Up to 32 alphanumeric characters

Data_Array_Name

Name of Data Array where data is to be
stored in the FieldServer

One of the Data Array names from
Section 4.

Data_Array_Offset

Starting location in Data Array

0 to (Data_Array_Length-1) as specified
in Section 4.

Function

Function of Client Map Descriptor

Rdbc, Wrbc, Wrbx

Column Title

Function

Legal Values

Node_Name

Name of Node to fetch data from

One of the Node names specified in Section 5.2

File_Type

File type in PLC

N, F, B, I, O5

File_Number

File Number in PLC

0-255

Address

Starting address of read block

0 – 255

Length

Length of read block

1-255

Scan_Interval

Rate at which data is polled

0-32000s, 1.0s

Data_Array_Low_Scale*

Scaling zero in Data Array

-32767 to 32767, 0

Data_Array_High_Scale*

Scaling max in Data Array

-32767 to 32767, 100

Node_Low_Scale*

Scaling zero in Connected Node

-32767 to 32767, 0

Node_High_Scale*

Scaling max in Connected Node

-32767 to 32767, 100

5

5.3 Client Side M ap Descriptor Parameters

5.3.1 FieldServer R elated Map D escriptor P a r a meters

5.3.2 Driver Related Map Descrip t or Paramete r s

Not all PLC’s can support all File_Types. Refer to DFS for further information.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 9 of 16s

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name

, Data_Array_Name

, Data_Array_Offset

, Function

, Node_Name

, File_Type

, File_Number

, Address

, Length

, Scan_Interval

CMD_AI_01

, DA_AI_01

, 0

, Rdbc

, PLC 1

, N

, 10

, 0

, 16

, 1.0s

CMD_AO_01

, DA_AO_01

, 0

, Rdbc

, PLC 1

, N

, 11

, 0

, 16

, 1.0s

CMD_DI_01

, DA_DI_01

, 0

, Rdbc

, PLC 1

, B

, 12

, 0

, 16

, 1.0s

CMD_DO_01

, DA_DO_01

, 0

, Rdbc

, PLC 1

, B

, 13

, 0

, 16

, 1.0s

5.3.3 Map Descriptor Example

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 10 of 16

Section Title

Connections

Column

Title

Function

Legal Values

Port

Specify which port the device is connected to the
FieldServer

P1-P86
Baud*

Specify baud rate

300 to 115200; 9600

Parity*

Specify parity

Even, Odd, None

Data_Bits*

Specify data bits

8

Stop_Bits*

Specify stop bits

1, 2

Protocol

Specify protocol used

DF1_FD, DF1_HD_MASTER,
DF1_HD_SLAVE

Checksum

Specify Checksum – refer to Appendix A.2

BCC, CRC-16
// Server Side Connections

Connections

Port

, Protocol

, Baud

, Parity

, Data_Bits

, Stop_Bits

P1

, DF1_FD

, 38400

, None

, 8

, 1

6

6 CONFI G U RING THE FIE L DSERVER AS A D F 1 SERVER

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” files provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a DF1 Client.

The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for DF1 communications, the driver independent FieldServer buffers need to be declared in the
“Data Arrays” section, the FieldServer virtual node(s) needs to be declared in the “Server Side Nodes” section, and
the data to be provided to the Clients needs to be mapped in the “Server Side Map Descriptors” section. Details
on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.

6.1 Server Side Co n nection Parameters

Example

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available

on specific hardware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 11 of 16

Section Title

Nodes

Column Title

Function

Legal Values

Node_Name

Provide name for node

Up to 32 alphanumeric characters

Node_ID

Node ID of physical Server node

1-255

Protocol

Specify protocol used

DF1_FD, DF1_HD_MASTER, DF1_HD_SLAVE

PLC_Type

Specify PLC Communications type.

PLC3, PLC5, SLC5

// Server Side Nodes

Nodes

Node_Name

, Node_ID

, Protocol

, PLC_Type

DF1_Srv_11

, 11

, DF1_FD

, SLC5

Section Title

Map_Descriptors

Column Title

Function

Legal Values

Map_Descriptor_Name

Name of this Map Descriptor

Up to 32 alphanumeric characters

Data_Array_Name

Name of Data Array where data is to be
stored in the FieldServer

One of the Data Array names from
Section 4.

Data_Array_Offset

Starting location in Data Array

0 to (Data_Array_Length-1) as specified
in Section 4.

Function

Function of Client Map Descriptor

Passive

6.2 Server Side No de Paramete r s

Example

6.3 Server Side M a p Descriptor Parameters

6.3.1 FieldServer S p e cific Ma p Descriptor P arameters

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 12 of 16

Section Title

Map_Descriptors

Column Title

Function

Legal Values

Node_Name

Name of Node to fetch data from

One of the node names specified in Section 6.2

File_Type

File type in PLC

N, F, B, I, O7

File_Number

File number in PLC

0-255

Address

Starting address of read block

0 - 255

Length

Length of read block

1 - 255

Data_Array_Low_Scale*

Scaling zero in Data Array

-32767 to 32767, 0

Data_Array_High_Scale*

Scaling max in Data Array

-32767 to 32767, 100

Node_Low_Scale*

Scaling zero in Connected Node

-32767 to 32767, 0

Node_High_Scale*

Scaling max in Connected Node

-32767 to 32767, 100

7

6.3.2 Driver Specific Map Descri p t o r Parame t e rs

Not all PLC’s can support all File_Types. Refer to DFS for further information.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 13 of 16

// Server Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name

, Data_Array_Name

, Data_Array_Offset

, Function

, Node_Name

, File_Type

, File_Number

, Address

, Length

SMD_AI_01

, DA_AI_01

, 0

, Passive

, DF1_Srv_11

, N

, 10

, 0

, 200

SMD_AO_01

, DA_AO_01

, 0

, Passive

, DF1_Srv_11

, N

, 11

, 0

, 200

SMD_DI_01

, DA_DI_01

, 0

, Passive

, DF1_Srv_11

, B

, 12

, 0

, 200

SMD_DO_01

, DA_DO_01

, 0

, Passive

, DF1_Srv_11

, B

, 13

, 0

, 200

6.3.3 Map Descriptor Example

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 14 of 16

// Client Side Connections

Connections

Port

, Protocol

, Baud

, Parity

, Data_Bits

, Stop_Bits

, Checksum

P1

, DF1_FD

, 38400

, None

, 8

, 1

, CRC-16

Appendix A. Troubleshooting

Appendix A.1. Continuous Map Descriptors

The Driver is not able to split data between 2 Data Arrays when writing, or to read a Server mapping that is
discontinuous.

For example, on the Server Side:
If:
Server map 1: N21: 0-31
Server map 2: N21: 32-100

This will panic the FieldServer and crash RS view as the DH+ will attempt to map N21: 0-100. If set up as Server
Map 1: N21: 0-100, no problems are experienced.

Similarly on the Client Side, it is not possible to read sections e.g. 32bits to one array and then 16bits from the
same file type to another array etc. Read Blocks must be contiguous.

Appendix A.2. Checksum

It is possible to specify a checksum parameter for the serial connection.

Example

Appendix A.3. Reading B File Types

It is advisable to read all data from one B type file into the same data array in one contiguous read if possible.
Doing otherwise may result in problems when reading these points.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 15 of 16

PLC_Type

File_Type

FNC

Read

FNC

Write

Typical

Command

PLC3

N 1 Range Read

0

Range Write

N7: 3, L5

F 1 Range Read

0

Range Write

F12: 3, L5

B 1 Range Read

2

Bit Write

B3/4: 5, l5

PLC5

N 1 Range Read

0

Range Write

N7: 3 , L5

F 1 Range Read

67

Typed Write

F12: 3, L5

B 1 Range Read

26

Read Modify Write

B3/4: 5, L5

SLC5

N

A2

Protected Typed Logical
Read

AA

Protected Typed Logical
Write

N7: 3, L5

F

A2

Protected Typed Logical
Read

AA

Protected Typed Logical
Write

B3/4: 5, L7

B

A2

Protected Typed Logical
Read

AB

Protected Typed Logical
Write

B3/4: 5, L8

I

A2

Protected Typed Logical
Read

- - I: 13, L5

O

A2

Protected Typed Logical
Read

- - O: 13, L5

Appendix B. Reference

Appendix B.1. Command Support

The following commands are supported by the FieldServer for the various PLC types:

Appendix B.2. Error Messages

DF1 Rem STS err F0-> Extended error code – Refer to following table.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]

FS-8700-03 DF1 Driver Manual Page 16 of 16

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: [phone] Fax: [phone] Toll Free: [phone] email: [e-mail]
