FieldServer Envirotronics SystemsPlus FS-8700-88 Driver Manual

Download

Driver Version:

1.02

A Sierra Monitor Company

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-88 Envirotronics SystemsPlus

Effective for all systems manufactured after May 1, 2001

APPLICABILITY & EFFECTIVITY

Document Revision: 6

FS-8700

88 Envirotronics SystemsPlus

Table of Contents

TABLE OF CONTENTS

ENVIROTRONICS SYSTEMSPLUS DESCRIPTION........................................................5

DRIVER SCOPE OF SUPPLY..........................................................................................6

2.1.

Supplied by FieldServer Technologies for this driver ..................................................6

HARDWARE CONNECTIONS..........................................................................................7

CONFIGURING THE FIELDSERVER AS A ENVIROTRONICS SYSTEMSPLUS CLIENT

4.1.

Data Arrays/Descriptors..............................................................................................8

4.2.

Client Side Connection Descriptions...........................................................................9

4.3.

Client Side Node Descriptors......................................................................................9

4.4.

Client Side Map Descriptors......................................................................................10

4.4.1. FieldServer Related Map Descriptor Parameters...................................................10

4.4.2. Driver Related Map Descriptor Parameters ...........................................................10

4.4.3. Timing Parameters................................................................................................10

4.4.4. Map Descriptor Example 1 - read event event_num..............................................11

4.4.5. Map Descriptor Example 2 - set event event_num = Boolean................................11

4.4.6. Map Descriptor Example 3 - read aux. aux_num...................................................11

4.4.7. Map Descriptor Example 4 - set aux. aux_num = Boolean.....................................11

4.4.8. Map Descriptor Example 5 - read setpoint channel................................................12

4.4.9. Map Descriptor Example 6 - set setpoint channel = value......................................12

4.4.10. Map Descriptor Example 7 - read pv channel.....................................................12

4.4.11. Map Descriptor Example 8 - read deviation channel...........................................12

4.4.12. Map Descriptor Example 9 - read initial setpoint channel...................................13

4.4.13. Map Descriptor Example 10 - set initial setpoint channel = value.......................13

4.4.14. Map Descriptor Example 11 - read program status.............................................13

4.4.15. Map Descriptor Example 12 - read remaining step cycles..................................14

4.4.16. Map Descriptor Example 13 - read selected program.........................................14

4.4.17. Map Descriptor Example 14 - read step number.................................................14

4.4.18. Map Descriptor Example 15 - read step time......................................................14

4.4.19. Map Descriptor Example 16 - read remaining step time.....................................15

4.4.20. Map Descriptor Example 17 -read start step.......................................................15

4.4.21. Map Descriptor Example 18 - set start step = step_num ....................................15

4.4.22. Map Descriptor Example 19 - read start time enabled........................................15

4.4.23. Map Descriptor Example 20 - set start time enabled = Boolean.........................16

4.4.24. Map Descriptor Example 21 - read stop time enabled........................................16

4.4.25. Map Descriptor Example 22 - set stop time enabled = Boolean..........................16

4.4.26. Map Descriptor Example 23 - read start time......................................................17

4.4.27. Map Descriptor Example 24 - read stop time......................................................17

4.4.28. Map Descriptor Example 25 - read audible alarm...............................................17

4.4.29. Map Descriptor Example 26 - set audible alarm = Boolean................................18

4.4.30. Map descriptor Example 27 - read software version...........................................18

4.4.31. Map Descriptor Example 28 - read events..........................................................18

4.4.32. Map Descriptor Example 29 - read auxs.............................................................19

4.4.33. Map Descriptor Example 30 - read alarm status alarm.......................................19

4.4.34. Map Descriptor Example 31 - emergency stop...................................................19

4.4.35. Map Descriptor Example 32 - hold program .......................................................20

4.4.36. Map Descriptor Example 33 - resume program..................................................20

4.4.37. Map Descriptor Example 34 - start program.......................................................20

4.4.38. Map Descriptor Example 35 - start system.........................................................20

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Table of Contents

4.4.39.

4.4.40. Map Descriptor Example 37 - stop system.........................................................21

4.4.41. Map Descriptor Example 38 - alarm reset...........................................................21

4.4.42. Map Descriptor Example 39 - alarm acknowledge..............................................21

4.4.43. Map Descriptor Example 40 - edit alarms...........................................................22

4.4.44. Map Descriptor Example 41 - set circulators = Boolean.....................................22

4.4.45. Map Descriptor Example 42 - set lights = Boolean.............................................22

4.4.46. Map Descriptor Example 43 - select program program_num..............................22

4.4.47. Map Descriptor Example 44 - use keypad = Boolean.........................................23

4.4.48. Map Descriptor Example 45 - edit program program_num.................................23

4.4.49. Map Descriptor Example 46 - edit step step_num..............................................23

4.4.50. Map Descriptor Example 47 - edit analog channel..............................................23

4.4.51. Map Descriptor Example 48 - edit fuzzy channel................................................24

4.4.52. Map Descriptor Example 49 - edit remove step..................................................24

4.4.53. Map Descriptor Example 50 - edit insert step.....................................................24

4.4.54. Map Descriptor Example 51 - edit add step........................................................24

4.4.55. Map Descriptor Example 52 - edit clear program................................................25

4.4.56. Map Descriptor Example 53 - use emulator mode..............................................25

4.4.57. Map Descriptor Example 54 - end edit mode......................................................25

4.4.58. Map Descriptor Example 55 - edit set cycles = num_cycles...............................25

4.4.59. Map Descriptor Example 56 - edit set next = next_step_num.............................26

4.4.60. Map Descriptor Example 57 - edit set analog min. = value.................................26

4.4.61. Map Descriptor Example 58 - edit set analog max. = value................................26

4.4.62. Map Descriptor Example 59 - edit set analog type = number..............................26

4.4.63. Map Descriptor Example 60 - edit set engineering min. = value.........................27

4.4.64. Map Descriptor Example 61 - edit set engineering max. = value........................27

4.4.65. Map Descriptor Example 62 - edit set analog address = number........................27

4.4.66. Map Descriptor Example 63 - edit set units = number........................................27

4.4.67. Map Descriptor Example 64 - edit set fuzzy heat cycles time = value.................28

4.4.68. Map Descriptor Example 65 - edit set fuzzy cool cycles time = value.................28

4.4.69. Map Descriptor Example 66 - edit set fuzzy heat sensitivity = value...................28

4.4.70. Map Descriptor Example 67- edit set fuzzy cool sensitivity = value....................28

4.4.71. Map Descriptor Example 68 - edit set fuzzy heat max. power = value................29

4.4.72. Map Descriptor Example 69 - edit set fuzzy cool max. power = value.................29

4.4.73. Map Descriptor Example 70 - edit set fuzzy heat min. time = value....................29

4.4.74. Map Descriptor Example 71 - edit set fuzzy cool min. time = value ....................29

4.4.75. Map Descriptor Example 72 - edit set fuzzy heat stage delay = value................30

4.4.76. Map Descriptor Example 73 - edit set fuzzy cool stage delay = value.................30

4.4.77. Map Descriptor Example 74 - edit set fuzzy dead band = value.........................30

4.4.78. Map Descriptor Example 75 - edit set duration = hour:minute:second................31

4.4.79. Map Descriptor Example 76 - set start time = month/day hour:minute................31

4.4.80. Map Descriptor Example 77 - set stop time = month/day hour:minute................32

4.4.81. Map Descriptor Example 78 - set date = month / day / year...............................32

4.4.82. Map Descriptor Example 79 - set time = hour:minute:second.............................33

4.4.83. Map Descriptor Example 80 - edit set setpoint channel = value..........................33

4.4.84. Map Descriptor Example 80 - edit set gsoak channel = value.............................34

4.4.85. Map Descriptor Example 81 - edit set gsoak enabled channel = Boolean...........34

4.4.86. Map Descriptor Example 82 - edit set events = event_list...................................35

4.4.87. Map Descriptor Example 83 - edit set auxs = aux_list........................................35

4.4.88. Map Descriptor Example 84 - edit read program................................................36

4.4.89. Map Descriptor Example 85 - edit read step.......................................................36

Map Descriptor Example 36 - stop program .......................................................21

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Table of Contents

4.4.90.

4.4.91. Map Descriptor Example 87 - edit read duration.................................................37

4.4.92. Map Descriptor Example 88 - edit read events...................................................37

4.4.93. Map Descriptor Example 89 - edit read aux........................................................38

4.4.94. Map Descriptor Example 90 - edit read cycles....................................................38

4.4.95. Map Descriptor Example 91 - edit read next.......................................................39

4.4.96. Map Descriptor Example 92 - edit read analog min............................................39

4.4.97. Map Descriptor Example 93 - edit read analog max. ..........................................39

4.4.98. Map Descriptor Example 94 - edit read analog type...........................................40

4.4.99. Map Descriptor Example 95 - edit read engineering min....................................40

4.4.100. Map Descriptor Example 96 - edit read engineering max................................40

4.4.101. Map Descriptor Example 97 - edit read analog address..................................41

4.4.102. Map Descriptor Example 98 - edit read units...................................................41

4.4.103. Map Descriptor Example 99 - edit read fuzzy heat cycle time..........................41

4.4.104. Map Descriptor Example 100 - edit read fuzzy cool cycle time........................42

4.4.105. Map Descriptor Example 101 - edit read fuzzy heat sensitivity........................42

4.4.106. Map Descriptor Example 102 - edit read fuzzy cool sensitivity........................42

4.4.107. Map Descriptor Example 103 - edit read fuzzy heat max. power.....................43

4.4.108. Map Descriptor Example 104 - edit read fuzzy cool max. power .....................43

4.4.109. Map Descriptor Example 105 - edit read fuzzy heat min. time.........................43

4.4.110. Map Descriptor Example 106 - edit read fuzzy cool min. time.........................44

4.4.111. Map Descriptor Example 107 - edit read fuzzy heat stage delay.....................44

4.4.112. Map Descriptor Example 108 - edit read fuzzy cool stage delay......................44

4.4.113. Map Descriptor Example 109 - edit read fuzzy dead band..............................45

4.4.114. Map Descriptor Example 110 - read alarm log ................................................45

4.4.115. Map Descriptor Example 111 - edit read setpoint channel...............................45

4.4.116. Map Descriptor Example 112 - edit read gsoak enabled channel....................46

4.4.117. Map Descriptor Example 113 - edit read gsoak channel..................................46

4.4.118. Map Descriptor Example 114 - edit read scan alarm.......................................46

4.4.119. Map Descriptor Example 115 - edit set scan alarm = Boolean.........................47

Map Descriptor Example 86 - edit read number steps........................................36

APPENDIX A. PARAMETER TABLES .................................................................................48

Appendix A.1. System plus data types................................................................................48

Appendix A.2. Legal System PlusCommands.....................................................................48

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

1. Envirotronics SystemsPlus Description

The Envirotronics SystemsPlus driver allows the FieldServer to transfer data to and from devices over RS-232 using Envirotronics SystemsPlus protocol. The FieldServer can only emulate a Client.

Max Nodes Supported

FieldServer Mode Nodes Comments

Client 1 Only 1 Client node per port allowed

The Envirotronics SystemsPlus driver allows for direct interfacing to a SystemsPlus Programmer/Controller device. The driver acts as a Client to the device and can be used to read and set system parameters for status monitoring and control purposes. Combined with other protocol drivers on a FieldServer such as BACNet, complete SystemsPlus monitoring and control is made possible via control systems such as Scada.

The driver is not available as a Server since a FieldServer cannot fully emulate a SystemsPlus device’s interfaces. Any existing Server drivers are for FieldServer testing purposes only.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

2. Driver Scope of Supply

2.1. Supplied by FieldServer Technologies for this driver

FieldServer Technologies

PART #

Description

FS-8915-10 UTP cable (7 foot) for RS-232 use FS-8917-02 RJ45 to DB9F connector adapter FS-8917-01 RJ45 to DB25M connection adapter FS-8700-88 Driver Manual.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

3. Hardware Connections



The FieldServer is connected to the SystemsPlus Controller as shown below. Configure the SystemsPlus Controller according to manufacturer’s instructions.





#& !

   

$    !

       %! "  & "!! "  !  ( ')

 &  '"!

$ #  !

#& !

   

    !

"   " !!

 #  !

!,--./.0.123.

22











*#+(







    

 

Note:

• The SystemsPlus Controller MUST be set to COMMAND MODE using the manufacturer’s software before connecting the FieldServer.

• The SystemsPlus Controller’s “Command End of Line” setting MUST be set to “CR”. Using the manufacturer’s software to do this setting before connecting the FieldServer

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

4. Configuring the FieldServer as a Envirotronics SystemsPlus Client

For a detailed discussion on FieldServer configuration, please refer to the FieldServer instruction manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer to communicate with an Envirotronics SystemsPlus Server.

4.1. Data Arrays/Descriptors

The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable the FieldServer for Envirotronics SystemsPlus communications, the driver independent FieldServer buffers need to be declared in the “Data Arrays” section, the destination device addresses need to be declared in the “Client Side Nodes” section, and the data required from the Servers needs to be mapped in the “Client Side Map Descriptors” section. Details on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name Provide name for Data Array

Data_Array_Format

Provide data format. Each Data Array can only take on one format.

Number of Data Objects. Must be

Data_Array_Length

larger than the data storage area required by the Map Descriptors for the data being placed in this array.

Example

// Data Arrays Data_Arrays Data_Array_Name, Data_Format, Data_Array_Length Event_States, bit, 10

Up to 15 alphanumeric characters Float, Bit, UInt16, SInt16, Packed_Bit, Byte, Packed_Byte, Swapped_Byte

1-10,000

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

4.2. Client Side Connection Descriptions

Section Title

Connections

Column Title Function Legal Values

Port Protocol Specify protocol used SystemsPlus Baud* Specify baud rate Parity* Specify parity

Data_Bits* Specify data bits Stop_Bits* Specify stop bits Handshaking* Specify hardware handshaking Poll _Delay* Time between internal polls

Example

// Client Side Connections Connections

Port, Protocol, Baud, Parity, Handshaking, Poll_Delay P1, SystemsPlus, 19200, None, None, 0.100s

Specify which port the device is connected to the FieldServer

P1-P81

300 – 19200, standard baud rates only Even, Odd, None 7, 8 1, 2 RTS, RTS/CTS, None 0-32000 seconds, 1 second

4.3. Client Side Node Descriptors

Section Title

Nodes

Column Title Function Legal Values

Node_Name Provide name for node Protocol Specify protocol used SystemsPlus Port

Specify which port the device is connected to the FieldServer

Example

// Client Side Nodes Nodes

Node_Name, Protocol, Port SYSPLUS_01, SystemsPlus, P1

Up to 32 alphanumeric characters

P1-P81

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

4.4. Client Side Map Descriptors

4.4.1. FieldServer Related Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name

Name of this Map Descriptor Name of Data Array where

Data_Array_Name

data is to be stored in the FieldServer

Data_Array_Offset Function

Starting location in Data Array Function of Client Map Descriptor

4.4.2. Driver Related Map Descriptor Parameters

Column Title Function Legal Values

Node_Name

SysPlus_Data_Type

Name of Node to fetch data from

Specifies a SystemsPlus data type this mapdesc will use

SysPlus_Alarm_Name A SystemsPlus alarm name

Specifies a SystemsPlus

SysPlus_Cmd

command this mapdesc will use

Store_Data_Array_Name

Store_Data_Array_Offset

Name of the data array where data must be stored

Offset where data must be stored

Name of the data array that

Par_Data_Array_Name

will contain parameters needed by this mapdesc

Par_Data_Array_Offset

Offset where parameters will be located

Address Starting address Length Length of Map Descriptor

4.4.3. Timing Parameters

Up to 32 alphanumeric characters One of the Data Array names from “Data Array” section above 0 to maximum specified in “Data Array” section above RDBC, WRBC, WRBX, AWT, ART2

One of the node names specified in “Client Node Descriptor” above

Refer to Appendix A.1 Any four character alarm

name

Refer to Appendix A.2

Any data array name 0 to maximum offset into

store data array

Any data array name

0 to maximum offset into parameter data array

0 to value allowed for the specific mapdesc 1 to value allowed for the specific mapdesc

Column Title Function Legal Values

Scan_Interval Rate at which data is polled 40.001s

The new ART function stands for “Active Read on Trigger” and is used to effect a single data

read per trigger. Please refer to the Map Descriptor examples for using this function.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700-88 Envirotronics SystemsPlus Page 11 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.4. Map Descriptor Example 1 - read event event_num

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Event_States_00, 0s, Event_States, 0, rdbc, SYSPLUS_01, Event, 0, 1

The event_num is specified by the “Address” field. The state of the event will be stored as 1 for “ON” or 0 for “OFF”.

4.4.5. Map Descriptor Example 2 - set event event_num = Boolean

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Event_States_00, Event_States_0, 0, awt, SYSPLUS_01, Event, 0, 1

The event_num is specified by the “Address” field. The Boolean state of the event is retrieved from the value written into Data_Array_Name at Data_Array_Offset. Use a value of 1 for “ON” and a value of 0 for “OFF”.

4.4.6. Map Descriptor Example 3 - read aux. aux_num

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Aux_States_00, 0s, Aux_States, 0, rdbc, SYSPLUS_01, Aux, 0, 1

The aux_num is specified by the “Address” field. The state of the aux will be stored as 1 for “ON” or 0 for “OFF”.

4.4.7. Map Descriptor Example 4 - set aux. aux_num = Boolean

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Aux_States_00, Aux_States_0, 0, awt, SYSPLUS_01, Aux, 0, 1

The aux_num is specified by the “Address” field. The Boolean state of the aux is retrieved from the value written into Data_Array_Name at Data_Array_Offset. Use a value of 1 for “ON” and a value of 0 for “OFF”.

FS-8700-88 Envirotronics SystemsPlus Page 12 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.8. Map Descriptor Example 5 - read setpoint channel

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Setpoints_00, 0s, Setpoints, 0, rdbc, SYSPLUS_01, Setpoint, 0, 1

The channel is specified by the “Address” field.

4.4.9. Map Descriptor Example 6 - set setpoint channel = value

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Setpoints_00, Setpoints_0, 0, awt, SYSPLUS_01, Setpoint, 0, 1

The channel is specified by the “Address” field. value is retrieved from the value written into Data_Array_Name at Data_Array_Offset.

4.4.10. Map Descriptor Example 7 - read pv channel

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Pvs_00, 0s, Pvs, 0, rdbc, SYSPLUS_01, Pv, 0, 1

The channel is specified by the “Address” field.

4.4.11. Map Descriptor Example 8 - read deviation channel

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Deviation_00, 0s, Deviations, 0, rdbc, SYSPLUS_01, Deviation, 0, 1

The channel is specified by the “Address” field.

FS-8700-88 Envirotronics SystemsPlus Page 13 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.12. Map Descriptor Example 9 - read initial setpoint channel

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Init_Setpoint_00, 0s, Init_Setpoint, 0, rdbc, SYSPLUS_01, Init_Setpoint, 0, 1

The channel is specified by the “Address” field.

4.4.13. Map Descriptor Example 10 - set initial setpoint channel = value

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length Init_Setpoint_00, Init_Setpoint_0, 0, awt, SYSPLUS_01, Init_Setpoint, 0, 1

The channel is specified by the “Address” field; value is retrieved from the value written into Data_Array_Name at Data_Array_Offset.

4.4.14. Map Descriptor Example 11 - read program status

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Prg_Sts, 0s, Prog_Status, 0, rdbc, SYSPLUS_01, Prog_Status, 1

The program status will be stored to Data_Array_Name at Data_Array_Offset with one of the following possible values:

Program Status VALUE

Undefined

Timed Start 1 Alarm Hold 2 Hold 3 Run 4 Timed Stop 5 Stop 6

FS-8700-88 Envirotronics SystemsPlus Page 14 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.15. Map Descriptor Example 12 - read remaining step cycles

// Client Side Map Descriptors // Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Rm_Stp_Cy, 0s, Rem_Stepcycles, 0, rdbc, SYSPLUS_01, Rem_Step_Cyc, 1

4.4.16. Map Descriptor Example 13 - read selected program

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Sel_Prog, 0s, Selected_Prog, 0, rdbc, SYSPLUS_01, Selected_Prog, 1

4.4.17. Map Descriptor Example 14 - read step number

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Step_Number, 0s, Step_Number, 0, rdbc, SYSPLUS_01, Step_Number, 1

4.4.18. Map Descriptor Example 15 - read step time

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Step_Time, 0s, Step_Time, 0, rdbc, SYSPLUS_01, Step_Time, 3

The retrieved step time will be stored as follows in Data_Array_Name:

Offset from Data_Array_Offset Description

0 Hour 1 Minute 2 Second

FS-8700-88 Envirotronics SystemsPlus Page 15 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.19. Map Descriptor Example 16 - read remaining step time

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Rm_Stp_Tm, 0s, Rem_Steptime, 0, rdbc, SYSPLUS_01, Rem_Step_Tim, 3

The retrieved remaining step time will be stored as follows in Data_Array_Name:

Offset from Data_Array_Offset Description

0 Hour 1 Minute 2 Second

4.4.20. Map Descriptor Example 17 -read start step

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Start_Step, 0s, Start_Step, 0, rdbc, SYSPLUS_01, Start_Step, 1

4.4.21. Map Descriptor Example 18 - set start step = step_num

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Start_Step, Start_Step_0, 0, wrbx, SYSPLUS_01, Start_Step, 1

The step_num must be written into Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.22. Map Descriptor Example 19 - read start time enabled

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Start_Time_Ena, 0s, Start_Time_Ena, 0, rdbc, SYSPLUS_01, Start_Time_Ena, 1

The start time enabled status will be stored as 1 for “Enabled” or 0 for “Disabled” in Data_Array_Name at Data_Array_Offset.

FS-8700-88 Envirotronics SystemsPlus Page 16 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.23. Map Descriptor Example 20 - set start time enabled = Boolean

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Start_Time_Ena, Start_Time_Ena_0, 0, wrbx, SYSPLUS_01, Start_Time_Ena, 1

A Boolean value of 1 for “Enabled” or 0 for “Disabled” must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.24. Map Descriptor Example 21 - read stop time enabled

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Stop_Time_Ena, 0s, Stop_Time_Ena, 0, rdbc, SYSPLUS_01, Stop_Time_Ena, 1

The stop time enabled status will be stored as 1 for “Enabled” or 0 for “Disabled” in Data_Array_Name at Data_Array_Offset.

4.4.25. Map Descriptor Example 22 - set stop time enabled = Boolean

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Stop_Time_Ena, Stop_Time_Ena_0, 0, wrbx, SYSPLUS_01, Stop_Time_Ena, 1

A Boolean value of 1 for “Enabled” or 0 for “Disabled” must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 17 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.26. Map Descriptor Example 23 - read start time

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Start_Time, 0s, Start_Time, 0, rdbc, SYSPLUS_01, Start_Time, 4

The retrieved start time will be stored as follows in Data_Array_Name:

Offset from Data_Array_Offset Description

0 Month 1 Day 2 Hour 3 Minute

4.4.27. Map Descriptor Example 24 - read stop time

// Client Side Map Descriptor Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Stop_Time, 0s, Stop_Time, 0, rdbc, SYSPLUS_01, Stop_Time, 4

The retrieved stop time will be stored as follows in Data_Array_Name:

Offset from Data_Array_Offset Description

Month

1 Day 2 Hour 3 Minute

4.4.28. Map Descriptor Example 25 - read audible alarm

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Audible_Alarm, 0s, Audible_Alarm, 0, rdbc, SYSPLUS_01, Audible_Alarm, 1

The status of the audible alarm will be stored as 1 for “on” or 0 for “off” in Data_Array_Name at Data_Array_Offset.

FS-8700-88 Envirotronics SystemsPlus Page 18 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.29. Map Descriptor Example 26 - set audible alarm = Boolean

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Audible_Alarm, Audible_Alarm_0, 0, wrbx, SYSPLUS_01, Audible_Alarm, 1

A Boolean value of 1 for “on” or 0 for “off” must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.30. Map descriptor Example 27 - read software version

// Cleint Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length Sw_Version, 0s, Sw_Version, 0, rdbc, SYSPLUS_01, Sw_Version, 1

4.4.31. Map Descriptor Example 28 - read events

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length All_Event_States, 0s, All_Event_States, 0, rdbc, SYSPLUS_01, All_Events, 10

The retrieved event states will be stored as follows in Data_Array_Name: ( A value of 1 will be stored for “on” or 0 for “off” )

Offset from Data_Array_Offset Description

0 Event_0 state 1 Event_1 state 2 Event_2 state

.. ..

9 Event_9 state

FS-8700-88 Envirotronics SystemsPlus Page 19 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.32. Map Descriptor Example 29 - read auxs

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length All_Aux_States, 0s, All_Aux_States, 0, rdbc, SYSPLUS_01, All_Auxs, 10

The retrieved aux states will be stored as follows in Data_Array_Name: (A value of 1 will be stored for “on” or 0 for “off”)

Offset from Data_Array_Offset Description 0 Aux_0 state 1 Aux_1 state 2 Aux_2 state

.. ..

9 Aux_9 state

4.4.33. Map Descriptor Example 30 - read alarm status alarm

// Client Side Map Descriptors Map Descriptor

Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, SysPlus_Alarm_Name, Length Alarm_Sts_00, 0s, Alarm_Statuses, 0, rdbc, SYSPLUS_01, Alarm, volt, 1

alarm is specified by the name under SysPlus_Alarm_Name. The status of the alarm will be stored as 1 for “OK” or 0 for “FAIL” in Data_Array_Name at Data_Array_Offset.

4.4.34. Map Descriptor Example 31 - emergency stop

// Client Side Map Descriptors Map Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Emergency_Stop, ProgSysControl, 0, wrbx, SYSPLUS_01, Emergency_Stop, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

FS-8700-88 Envirotronics SystemsPlus Page 20 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.35. Map Descriptor Example 32 - hold program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Hold_Program, ProgSysControl, 1, wrbx, SYSPLUS_01, Hold_Program, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.36. Map Descriptor Example 33 - resume program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Resume_Program, ProgSysControl, 2, wrbx, SYSPLUS_01, Resume_Program, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.37. Map Descriptor Example 34 - start program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Start_Program, ProgSysControl, 3, wrbx, SYSPLUS_01, Start_Program, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.38. Map Descriptor Example 35 - start system

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Start_System, ProgSysControl, 4, wrbx, SYSPLUS_01, Start_System, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

FS-8700-88 Envirotronics SystemsPlus Page 21 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.39. Map Descriptor Example 36 - stop program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Stop_Program, ProgSysControl, 5, wrbx, SYSPLUS_01, Stop_Program, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.40. Map Descriptor Example 37 - stop system

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Stop_System, ProgSysControl, 6, wrbx, SYSPLUS_01, Stop_System, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.41. Map Descriptor Example 38 - alarm reset

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Alarm_Reset, AlarmControl, 0, wrbx, SYSPLUS_01, Alarm_Reset, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.42. Map Descriptor Example 39 - alarm acknowledge

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Alarm_Ack, AlarmControl, 1, wrbx, SYSPLUS_01, Alarm_Ack, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

FS-8700-88 Envirotronics SystemsPlus Page 22 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.43. Map Descriptor Example 40 - edit alarms

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Edit_Alarms, Edit_Alarms, 0, wrbx, SYSPLUS_01, Ed_Alarms, 1

Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.

4.4.44. Map Descriptor Example 41 - set circulators = Boolean

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Set_Circs, ManualControl, 0, wrbx, SYSPLUS_01, Set_Circs, 1

Write a value of 1 for “on” or 0 for “off” to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.45. Map Descriptor Example 42 - set lights = Boolean

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Set_Lights, ManualControl, 1, wrbx, SYSPLUS_01, Set_Lights, 1

Write a value of 1 for “on” or 0 for “off” to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.46. Map Descriptor Example 43 - select program program_num

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Select_Program, Program_Num, 0, wrbx, SYSPLUS_01, Select_Prog, 1

A program_num value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 23 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.47. Map Descriptor Example 44 - use keypad = Boolean

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Use_Keypad, Use_Keypad, 0, wrbx, SYSPLUS_01, Use_Keypad, 1

A Boolean value of 1 for “true” or 0 for “false” must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.48. Map Descriptor Example 45 - edit program program_num

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Program, Ed_Program, 0, wrbx, SYSPLUS_01, Ed_Program, 1

A program_num value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.49. Map Descriptor Example 46 - edit step step_num

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Step, Ed_Step, 0, wrbx, SYSPLUS_01, Ed_Step, 1

A step_num value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.50. Map Descriptor Example 47 - edit analog channel

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Analog, Ed_Analog, 0, wrbx, SYSPLUS_01, Ed_Analog, 1

A channel value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 24 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.51. Map Descriptor Example 48 - edit fuzzy channel

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Fuzzy, Ed_Fuzzy, 0, wrbx, SYSPLUS_01, Ed_Fuzzy, 1

A channel value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.52. Map Descriptor Example 49 - edit remove step

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Remove_Step, Ed_Remove_Step, 0, wrbx, SYSPLUS_01, Ed_Remove_Step, 1

Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.53. Map Descriptor Example 50 - edit insert step

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Insert_Step, Ed_Insert_Step, 0, wrbx, SYSPLUS_01, Ed_Insert_Step, 1

Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.54. Map Descriptor Example 51 - edit add step

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Add_Step, Ed_Add_Step, 0, wrbx, SYSPLUS_01, Ed_Add_Step, 1

Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 25 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.55. Map Descriptor Example 52 - edit clear program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Clr_Program, Ed_Clr_Program, 0, wrbx, SYSPLUS_01, Ed_Clr_Program, 1

Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.56. Map Descriptor Example 53 - use emulator mode

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Use_Emu_Mode, Misc_Cmds, 0, wrbx, SYSPLUS_01, Use_Emu_Mode, 1

A value of 1 to use emulator mode or a value of 0 to return to command mode must be written to Data_Array_Name at Data_Array_Offset to trigger this command. Note that all driver RDBC function Map Descriptors are stopped when entering emulator mode. Map Descriptors will resume polling when returning to command mode.

4.4.57. Map Descriptor Example 54 - end edit mode

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length End_Edit_Mode, Misc_Cmds, 1, wrbx, SYSPLUS_01, End_Edit_Mode, 1

Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.58. Map Descriptor Example 55 - edit set cycles = num_cycles

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Cycles, Ed_Cycles, 0, wrbx, SYSPLUS_01, Ed_Set_Cycles, 1

A value of num_cycles must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 26 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.59. Map Descriptor Example 56 - edit set next = next_step_num

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Next, Ed_Next, 0, wrbx, SYSPLUS_01, Ed_Set_Next, 1

A value of next_step_num must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.60. Map Descriptor Example 57 - edit set analog min. = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Ana_Min, Ed_Set_Ana_Min, 0, wrbx, SYSPLUS_01, Ed_Set_Ana_Min, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.61. Map Descriptor Example 58 - edit set analog max. = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Ana_Max, Ed_Set_Ana_Max, 0, wrbx, SYSPLUS_01, Ed_Set_Ana_Max, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.62. Map Descriptor Example 59 - edit set analog type = number

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Ana_Type, Ed_Set_Ana_Type, 0, wrbx, SYSPLUS_01, Ed_Set_Ana_Type, 1

A value of number must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 27 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.63. Map Descriptor Example 60 - edit set engineering min. = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Eng_Min, Ed_Set_Eng_Min, 0, wrbx, SYSPLUS_01, Ed_Set_Eng_Min, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.64. Map Descriptor Example 61 - edit set engineering max. = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Eng_Max, Ed_Set_Eng_Max, 0, wrbx, SYSPLUS_01, Ed_Set_Eng_Max, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.65. Map Descriptor Example 62 - edit set analog address = number

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Ana_Addr, Ed_Set_Ana_Addr, 0, wrbx, SYSPLUS_01, Ed_Set_Ana_Addr, 1

A value of number must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.66. Map Descriptor Example 63 - edit set units = number

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Units, Ed_Set_Units, 0, wrbx, SYSPLUS_01, Ed_Set_Units, 1

A value of number must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 28 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.67. Map Descriptor Example 64 - edit set fuzzy heat cycles time = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_Hct, Ed_Set_Fuz_Hct, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_Hct, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.68. Map Descriptor Example 65 - edit set fuzzy cool cycles time = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_Cct, Ed_Set_Fuz_Cct, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_Cct, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.69. Map Descriptor Example 66 - edit set fuzzy heat sensitivity = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_HSens, Ed_Set_Fuz_HSens, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_HSens, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.70. Map Descriptor Example 67- edit set fuzzy cool sensitivity = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_CSens, Ed_Set_Fuz_CSens, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_CSens, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 29 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.71. Map Descriptor Example 68 - edit set fuzzy heat max. power = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_HMPwr, Ed_Set_Fuz_HMPwr, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_HMPwr, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.72. Map Descriptor Example 69 - edit set fuzzy cool max. power = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_CMPwr, Ed_Set_Fuz_CMPwr, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_CMPwr, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.73. Map Descriptor Example 70 - edit set fuzzy heat min. time = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_HMTim, Ed_Set_Fuz_HMTim, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_HMTim, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.74. Map Descriptor Example 71 - edit set fuzzy cool min. time = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_CMTim, Ed_Set_Fuz_CMTim, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_CMTim, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 30 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.75. Map Descriptor Example 72 - edit set fuzzy heat stage delay = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_HSDly, Ed_Set_Fuz_HSDly, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_HSDly, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.76. Map Descriptor Example 73 - edit set fuzzy cool stage delay = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_CSDly, Ed_Set_Fuz_CSDly, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_CSDly, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

4.4.77. Map Descriptor Example 74 - edit set fuzzy dead band = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length Ed_Set_Fuz_Deadb, Ed_Set_Fuz_Deadb, 0, wrbx, SYSPLUS_01, Ed_Set_Fuz_Deadb, 1

A value of value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.

FS-8700-88 Envirotronics SystemsPlus Page 31 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.78. Map Descriptor Example 75 - edit set duration = hour:minute:second

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Duration, Par_Bit_Triggers, 0, awt, SYSPLUS_01, Ed_Set_Duration, Ed_Set_Duration, 0, 1

This command is used by first writing the parameter data (hour:minute:second) and then triggering the command by writing any value to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Hour

Minute

Second

4.4.79. Map Descriptor Example 76 - set start time = month/day hour:minute

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Set_Start_Time, Par_Bit_Triggers, 1, awt, SYSPLUS_01, Set_Start_Time, Set_Start_Time, 0, 1

This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Month

Day

Hour

Minute

FS-8700-88 Envirotronics SystemsPlus Page 32 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.80. Map Descriptor Example 77 - set stop time = month/day hour:minute

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Set_Stop_Time, Par_Bit_Triggers, 2, awt, SYSPLUS_01, Set_Stop_Time, Set_Stop_Time, 0, 1

This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Month

Day

Hour

Minute

4.4.81. Map Descriptor Example 78 - set date = month / day / year

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Set_Date, Par_Bit_Triggers, 3, awt, SYSPLUS_01, Set_Date, Set_Date, 0, 1

This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Month

Day

Year

FS-8700-88 Envirotronics SystemsPlus Page 33 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.82. Map Descriptor Example 79 - set time = hour:minute:second

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Set_Time, Par_Bit_Triggers, 4, awt, SYSPLUS_01, Set_Time, Set_Time, 0, 1

This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Hour

Minute

Second

4.4.83. Map Descriptor Example 80 - edit set setpoint channel = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Setpoint, Par_Val_Trigger, 0, awt, SYSPLUS_01, Ed_Set_Setpoint, Ed_Set_Setpoint, 0, 1

This command is used by first writing the parameter data value and then triggering the command by writing channel to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Value

FS-8700-88 Envirotronics SystemsPlus Page 34 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.84. Map Descriptor Example 80 - edit set gsoak channel = value

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Gsoak, Par_Val_Trigger, 1, awt, SYSPLUS_01, Ed_Set_Gsoak, Ed_Set_Gsoak, 0, 1

This command is used by first writing the parameter data value and then triggering the command by writing channel to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description

Value

4.4.85. Map Descriptor Example 81 - edit set gsoak enabled channel = Boolean

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Gs_Ena, Par_Val_Trigger, 2, awt, SYSPLUS_01, Ed_Set_Gsoak_Ena, Ed_Set_Gs_Ena, 0, 1

This command is used by first writing the parameter data Boolean and then triggering the command by writing channel to Data_Array_Name at Data_Array_Offset.

Parameter data setup:

Offset from par_data_array_offset Description 0 Boolean

FS-8700-88 Envirotronics SystemsPlus Page 35 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.86. Map Descriptor Example 82 - edit set events = event_list

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Events, Par_Val_Trigger, 3, awt, SYSPLUS_01, Ed_Set_Events, Ed_Set_Events, 0, 10

This command is used by first writing the parameter data event_list and then triggering the command by writing the number of events to Data_Array_Name at Data_Array_Offset.

Note:

Only consecutive events can be set ( eg. to set event9, all 10 events must be set and 10 written to Data_Array_Name ).

Parameter data setup: (Use a value of 1 for “on” or a value of 0 for “off” per event)

Offset from par_data_array_offset Description

Event0

Event9

4.4.87. Map Descriptor Example 83 - edit set auxs = aux_list

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length Ed_Set_Auxs, Par_Val_Trigger, 4, awt, SYSPLUS_01, Ed_Set_Auxs, Ed_Set_Auxs, 0, 10

This command is used by first writing the parameter data aux_list and then triggering the command by writing the number of auxs to Data_Array_Name at Data_Array_Offset. Note: Only consecutive auxs can be set ( eg. to set aux1, all auxs from 0 to 1 must be set and 2 written to Data_Array_Name ).

Parameter data setup: (Use a value of 1 for “on” or a value of 0 for “off” per aux)

Offset from par_data_array_offset Description

Aux0

Aux9

FS-8700-88 Envirotronics SystemsPlus Page 36 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.88. Map Descriptor Example 84 - edit read program

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Program, Rd_Triggers, 0, art, SYSPLUS_01, Ed_Rd_Program, Ed_Rd_Program, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Program number

4.4.89. Map Descriptor Example 85 - edit read step

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Step, Rd_Triggers, 1, art, SYSPLUS_01, Ed_Rd_Step, Ed_Rd_Step, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Step number

4.4.90. Map Descriptor Example 86 - edit read number steps

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Num_Steps, Rd_Triggers, 2, art, SYSPLUS_01, Ed_Rd_Num_Steps, Ed_Rd_Num_Steps, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Number of steps

FS-8700-88 Envirotronics SystemsPlus Page 37 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.91. Map Descriptor Example 87 - edit read duration

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Duration, Rd_Triggers, 3, art, SYSPLUS_01, Ed_Rd_Duration, Ed_Rd_Duration, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Duration

4.4.92. Map Descriptor Example 88 - edit read events

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Events, Rd_Triggers, 4, art, SYSPLUS_01, Ed_Rd_Events, Ed_Rd_Events, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Event0 status

Event9 status

FS-8700-88 Envirotronics SystemsPlus Page 38 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.93. Map Descriptor Example 89 - edit read aux.

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Aux, Rd_Triggers, 5, art, SYSPLUS_01, Ed_Rd_Aux, Ed_Rd_Aux, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Aux0 status

Aux9 status

4.4.94. Map Descriptor Example 90 - edit read cycles

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Cycles, Rd_Triggers, 6, art, SYSPLUS_01, Ed_Rd_Cycles, Ed_Rd_Cycles, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Number of cycles

FS-8700-88 Envirotronics SystemsPlus Page 39 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.95. Map Descriptor Example 91 - edit read next

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Next, Rd_Triggers, 7, art, SYSPLUS_01, Ed_Rd_Next, Ed_Rd_Next, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

4.4.96. Map Descriptor Example 92 - edit read analog min.

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Ana_Min, Rd_Triggers, 8, art, SYSPLUS_01, Ed_Rd_Ana_Min, Ed_Rd_Ana_Min, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Min analog value

4.4.97. Map Descriptor Example 93 - edit read analog max.

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Ana_Max, Rd_Triggers, 9, art, SYSPLUS_01, Ed_Rd_Ana_Max, Ed_Rd_Ana_Max, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

Max analog value

FS-8700-88 Envirotronics SystemsPlus Page 40 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.98. Map Descriptor Example 94 - edit read analog type

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Ana_Type, Rd_Triggers, 10, art, SYSPLUS_01, Ed_Rd_Ana_Type, Ed_Rd_Ana_Type, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Analog type

4.4.99. Map Descriptor Example 95 - edit read engineering min.

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Eng_Min, Rd_Triggers, 11, art, SYSPLUS_01, Ed_Rd_Eng_Min, Ed_Rd_Eng_Min, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Min engineering value

4.4.100. Map Descriptor Example 96 - edit read engineering max.

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Eng_Max, Rd_Triggers, 12, art, SYSPLUS_01, Ed_Rd_Eng_Max, Ed_Rd_Eng_Max, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Max engineering value

FS-8700-88 Envirotronics SystemsPlus Page 41 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.101. Map Descriptor Example 97 - edit read analog address

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Ana_Addr, Rd_Triggers, 13, art, SYSPLUS_01, Ed_Rd_Ana_Addr, Ed_Rd_Ana_Addr, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Analog address

4.4.102. Map Descriptor Example 98 - edit read units

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Units, Rd_Triggers, 14, art, SYSPLUS_01, Ed_Rd_Units, Ed_Rd_Units, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Units value

4.4.103. Map Descriptor Example 99 - edit read fuzzy heat cycle time

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_Hct, Rd_Triggers, 15, art, SYSPLUS_01, Ed_Rd_Fuz_Hct, Ed_Rd_Fuz_Hct, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Heat cycle time

FS-8700-88 Envirotronics SystemsPlus Page 42 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.104. Map Descriptor Example 100 - edit read fuzzy cool cycle time

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_Cct, Rd_Triggers, 16, art, SYSPLUS_01, Ed_Rd_Fuz_Cct, Ed_Rd_Fuz_Cct, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Cool cycle time

4.4.105. Map Descriptor Example 101 - edit read fuzzy heat sensitivity

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_HSens, Rd_Triggers, 17, art, SYSPLUS_01, Ed_Rd_Fuz_HSens, Ed_Rd_Fuz_HSens, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Heat sensitivity

4.4.106. Map Descriptor Example 102 - edit read fuzzy cool sensitivity

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_CSens, Rd_Triggers, 18, art, SYSPLUS_01, Ed_Rd_Fuz_CSens, Ed_Rd_Fuz_CSens, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Cool sensitivity

FS-8700-88 Envirotronics SystemsPlus Page 43 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.107. Map Descriptor Example 103 - edit read fuzzy heat max. power

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_HMPwr, Rd_Triggers, 19, art, SYSPLUS_01, Ed_Rd_Fuz_HMPwr, Ed_Rd_Fuz_HMPwr, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Max heat power

4.4.108. Map Descriptor Example 104 - edit read fuzzy cool max. power

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_CMPwr, Rd_Triggers, 20, art, SYSPLUS_01, Ed_Rd_Fuz_CMPwr, Ed_Rd_Fuz_CMPwr, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Max cool power

4.4.109. Map Descriptor Example 105 - edit read fuzzy heat min. time

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_HMTim, Rd_Triggers, 21, art, SYSPLUS_01, Ed_Rd_Fuz_HMTim, Ed_Rd_Fuz_HMTim, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Min heat time

FS-8700-88 Envirotronics SystemsPlus Page 44 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.110. Map Descriptor Example 106 - edit read fuzzy cool min. time

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_CMTim, Rd_Triggers, 22, art, SYSPLUS_01, Ed_Rd_Fuz_CMTim, Ed_Rd_Fuz_CMTim, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Min cool time

4.4.111. Map Descriptor Example 107 - edit read fuzzy heat stage delay

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_HSDly, Rd_Triggers, 23, art, SYSPLUS_01, Ed_Rd_Fuz_HSDly, Ed_Rd_Fuz_HSDly, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Heat stage delay

4.4.112. Map Descriptor Example 108 - edit read fuzzy cool stage delay

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_CSDly, Rd_Triggers, 24, art, SYSPLUS_01, Ed_Rd_Fuz_CSDly, Ed_Rd_Fuz_CSDly, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Cool stage delay

FS-8700-88 Envirotronics SystemsPlus Page 45 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.113. Map Descriptor Example 109 - edit read fuzzy dead band

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Fuz_Deadb, Rd_Triggers, 25, art, SYSPLUS_01, Ed_Rd_Fuz_Deadb, Ed_Rd_Fuz_Deadb, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Dead band

4.4.114. Map Descriptor Example 110 - read alarm log

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Rd_Alarm_Log, Rd_Triggers, 26, art, SYSPLUS_01, Rd_Alarm_Log, Rd_Alarm_Log, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 To be determined !

4.4.115. Map Descriptor Example 111 - edit read setpoint channel

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Setpoint, Rd_Par_Triggers, 0, art, SYSPLUS_01, Ed_Rd_Setpoint, Ed_Rd_Setpoint, 0, 1

This command is triggered by writing channel to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Setpoint

FS-8700-88 Envirotronics SystemsPlus Page 46 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.116. Map Descriptor Example 112 - edit read gsoak enabled channel

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Gsoak_Ena, Rd_Par_Triggers, 1, art, SYSPLUS_01, Ed_Rd_Gsoak_Ena, Ed_Rd_Gsoak_Ena, 0, 1

This command is triggered by writing channel to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows: ( A value of 1 is used for “true” or 0 for “false” )

Offset from Store_Data_Array_Offset Description

0 Gsoak enabled

4.4.117. Map Descriptor Example 113 - edit read gsoak channel

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Gsoak, Rd_Par_Triggers, 2, art, SYSPLUS_01, Ed_Rd_Gsoak, Ed_Rd_Gsoak, 0, 1

This command is triggered by writing channel to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows:

Offset from Store_Data_Array_Offset Description

0 Gsoak value

4.4.118. Map Descriptor Example 114 - edit read scan alarm

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, SysPlus_Alarm_Name, Store_Data_Array_Name, Store_Data_Array_Offset, Length Ed_Rd_Scan_00, Scan_Alm_Trigs, 0, art, SYSPLUS_01, Ed_Rd_Scan, fire, Ed_Rd_Scan, 0, 1

This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset. The retrieved data is stored as follows: ( A value of 1 is stored for “Fail” or 0 for “Normal” )

Offset from Store_Data_Array_Offset Description

0 Alarm status

FS-8700-88 Envirotronics SystemsPlus Page 47 of 49

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

4.4.119. Map Descriptor Example 115 - edit set scan alarm = Boolean

// Client Side Mao Descriptors Map Descriptor

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, SysPlus_Alarm_Name, Length Ed_Set_Scan_00, Set_Scan_Trig, 0, wrbx, SYSPLUS_01, Ed_Set_Scan, fire, 1

This command is triggered by writing a Boolean value to Data_Array_Name at Data_Array_Offset. A value of 1 is used for “true” or 0 for “false”.

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

Appendix A. Parameter Tables

Appendix A.1. System plus data types

Event Aux Setpoint Pv Deviation Init_Setpoint Prog_Status Rem_Step_Cyc Selected_Prog Step_Number Step_Time Rem_Step_Tim Start_Step Start_Time_Ena Stop_Time_Ena Start_Time Stop_Time Audible_Alarm Sw_Version All_Events All_Auxs Alarm

Appendix A.2. Legal System PlusCommands

Ed_Rd_Program Ed_Rd_Step Ed_Rd_Num_Steps Ed_Rd_Duration Ed_Rd_Events Ed_Rd_Aux Ed_Rd_Cycles Ed_Rd_Next Ed_Rd_Ana_Min Ed_Rd_Ana_Max Ed_Rd_Ana_Type Ed_Rd_Eng_Min Ed_Rd_Eng_Max Ed_Rd_Ana_Addr Ed_Rd_Units Ed_Rd_Fuz_Hct Ed_Rd_Fuz_Cct Ed_Rd_Fuz_HSens Ed_Rd_Fuz_CSens Ed_Rd_Fuz_HMPwr Ed_Rd_Fuz_CMPwr Ed_Rd_Fuz_HMTim Ed_Rd_Fuz_CMTim Ed_Rd_Fuz_HSDly Ed_Rd_Fuz_CSDly Ed_Rd_Fuz_Deadb Rd_Alarm_Log Ed_Rd_Setpoint Ed_Rd_Gsoak_Ena Ed_Rd_Gsoak Ed_Rd_Scan Emergency_Stop Hold_Program Resume_Program Start_Program Start_System Stop_Program Stop_System Alarm_Reset Alarm_Ack Ed_Alarms Set_Circs Set_Lights Select_Prog Use_Keypad Ed_Program Ed_Step Ed_Analog Ed_Fuzzy Ed_Remove_Step Ed_Insert_Step Ed_Add_Step Ed_Clr_Program Use_Emu_Mode Ed_Set_Cycles Ed_Set_Next Ed_Set_Ana_Min Ed_Set_Ana_Max Ed_Set_Ana_Type Ed_Set_Eng_Min Ed_Set_Eng_Max Ed_Set_Ana_Addr Ed_Set_Units Ed_Set_Fuz_Hct Ed_Set_Fuz_Cct Ed_Set_Fuz_HSens Ed_Set_Fuz_CSens Ed_Set_Fuz_HMPwr Ed_Set_Fuz_CMPwr Ed_Set_Fuz_HMTim Ed_Set_Fuz_CMTim Ed_Set_Fuz_HSDly Ed_Set_Fuz_CSDly Ed_Set_Fuz_Deadb Ed_Set_Scan Ed_Set_Duration Set_Start_Time Set_Stop_Time Set_Date Set_Time Ed_Set_Setpoint Ed_Set_Gsoak Ed_Set_Gsoak_Ena Ed_Set_Events Ed_Set_Auxs

End_Edit_Mode

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FS-8700

88 Envirotronics SystemsPlus

Page

of 49

THIS PAGE INTENTIONALLY LEFT BLANK

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com

FieldServer Envirotronics SystemsPlus FS-8700-88 Driver Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
