FieldServer Dart FS-8700-78 Driver Manual

A Sierra Monitor Company

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS -8700-78 Dart

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after January 18, 1999

Instruction Manual Part Number FS-8700-78

2/20/2003

Driver Manual

TABLE OF CONTENTS

1 Dart Driver Description................................................................................................................1

1.1 Performance Issues ................................................................................................................1

2 Driver Scope of Supply ................................................................................................................2

2.1 Supplied by Sierra Monitor for this driver...............................................................................2

2.2 Provided by user....................................................................................................................2

3 Hardware Connections .................................................................................................................3

3.1 Hardware Configuration – Dart Present ...................................................................................4

4 Basic Configuration.....................................................................................................................5

4.1 Data Arrays...........................................................................................................................5

4.2 Client Side Connections.........................................................................................................6

4.3 Client Side Nodes..................................................................................................................7

4.4 Client Side Map Descriptors ..................................................................................................8

4.4.1 FieldServer Specific Map Descriptor Parameters ..............................................................8

4.4.2 Timing Parameters..........................................................................................................8

4.4.3 Driver Specific Map Descriptor Parameters......................................................................8

4.4.4 Map Descriptor: Example 1 – Read all possible data....................................................... 11

4.4.5 Map of How Data Aire Device Data is stored in a Data Array..........................................12

4.4.6 Unit Types ................................................................................................................... 17

4.4.7 Map Descriptor: Example 2 – Writing a Set-Point ..........................................................19

4.4.8 Map Descriptor: Example 3 – Writing multiple points using one message. ....................... 20

5 Chapter 5...................................................................................................................................21

6 Advanced Topics....................................................................................................................... 23

6.1 Additional Driver Specific Map Descriptor Parameters ..........................................................23

6.1.1 DA_Func Parameter - Permitted values..........................................................................24

6.1.2 DA_Field Parameter - Permitted v alues.........................................................................25

6.1.3 DA_Method Parameter Values and Notes....................................................................... 27

6.1.4 Advanced Example 1 :.................................................................................................. 28

6.1.5 Advanced Example 2 ....................................................................................................29

6.1.6 Advanced Map Descriptor: Example 3 - Using the 'special' parameter............................. 30

6.1.7 Advanced Map Descriptor: Example 4 - Using the 'DA_Assoc' parameter....................... 31

6.1.8 Map Descriptor: Example 5 - Using a special / diagnostic command. ............................... 32

6.2 Related Documents..............................................................................................................34

6.3 Troubleshooting Tips........................................................................................................... 34

6.3.1 Bad Values................................................................................................................... 34

6.3.2 Dead Nodes ..................................................................................................................34

6.3.3 Ignored Messages......................................................................................................... 34

6.4 Writing data to Dap Devices................................................................................................ 35

7 Revision Change Notices............................................................................................................ 36

7.1 Rev1.06a-Rev0 Changes from previous releases.................................................................... 36

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page Index

1 Dart Driver Description

The Dart Driver is designed for connection to a Data Air Coporation Dart Device.
The Dart device is a active element on a network of Data Air devices such as DAP panels. It

manages the devices and provides co-ordination and supervision. In performing these duties the
Dart device polls all the devices on the network for all the data. The Dart is capable of ‘echoing’
the responses from these devices on one of its RS232 ports. This driver is designed to listen
passively to these echoes and store device data. In addition the driver can send messages
(containing set point data, for example,) directly to individual devices on the network.

The FieldServer is connected to the RS232 serial port of the Dart. The Fieldserver can read and
write but active polling must be minimized as in reduces the amount of time that the DART
spends controlling the networked devices. The driver operates primarily as a passive client
listening to echoes of the data being polled by the DART. The DART must be set to ‘Echo’ mode
on the front panel of the Dart for the driver to operate correctly. There is no alternative to this
essential but manual setup-step.

The driver may be configured very simply (See example 1 in section 4 of the manual). In addition
a number of advanced configurations are possible. The manual is divided to separate the basic
and advanced topics.

The driver supports the common message formats for common Data Aire devices. A list of the
supported messages is provided in the manual. The driver cannot be used to configure or read the
status of a DART device itself.

The inf ormation that follows describes how to expand upon the factory defaults provided in the
configuration files included with the FieldServer.

Driver Manual

1.1 Performance Issues

Several factors outside FieldServer’s control make for slow communications with Data Aire
devices. The Data Aire communications is based on a very low baud rate. In addition inter­message timing constraints and overhead requirements for active messages in a Dart
configuration add significant time to each transaction.

When a used with a DART device, writing to a set point (or other variable) may take up to 8
seconds to complete the transaction. The results of the write will not be seen until the DART has
timed-out back into control mode and echoes the new data to the Fieldserver. This could take
several minutes if there are many devices on the loop and will take at least 30 seconds.

When writing continuously, with DART configurations, the minimum time interval between
successive writes is 2 minutes and with non-DART configurations is 1.8 seconds.

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 1

Driver Manual

2 Driver Scope of Supply

2.1 Supplied by Sierra Monitor for this driver

RS485 connection adapter
Driver Manual.

2.2 Provided by user

Data Aire Dart and documentation
RS232 cable for the loop network

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 2

3 Hardware Connections

Hardware

Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 3

Driver Manual

3.1 Hardware Configuration – Dart Present

When a DART device is connected to the Data Aire field devices then the Fieldserver is connected to the
serial port of the DART. The DART must be set to ‘Echo’ mode. This is done on the front panel of the
DART.

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 4

Driver Manual

4 Basic Configuration

For a detailed discussion on FieldServer configuration, please refer to the instruction manual for the
FieldServer. The information that follows describes how to expand upon the factory defaults
provided in the configuration files included with the FieldServer (See “.csv” files on the driver
diskette).

The configuration file tells the FieldServer about its interfaces, and the routing of data required. In
order to enable the FieldServer for Dart Driver communications, the driver independent FieldServer
buffers need to be declared in the “Data Arrays” section, the destination device addresses need to be
declared in the “Client Side Nodes” section, and the data required from the servers needs to be
mapped in the “Client Side Map Descriptors” section. Details on how to do this can be found
below.

The Dart Serial Driver cannot be configured as a data server.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.

4.1 Data Arrays

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name Provide name for Data Array Up to 15 alphanumeric

characters

Data_Format Provide data format. Each data array can

only take on one format.

FLOAT, BIT, UInt16,
SInt16, Packed_Bit, Byte,
Packed_Byte,
Swapped_Byte

Data_Array_Length Number of Data Objects. Must be larger

1-10,000
than the data storage area required for the
data being placed in this array.

Example

// Data Arrays
//
Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 5

4.2 Client Side Connections

Section Title

Connections

Column Title Function Legal Values

Port Specify which port the device is

Secondary_Port* Using a Dart ? Do not specify

Baud* Specify baud rate 2400 (Others available but

Parity* Specify parity
Data_Bits* Specify data bits

Stop_Bits* Specify stop bits
Protocol Specify protocol used

Handshaking* Specify hardware handshaking
Poll Delay* Time between internal polls 0-32000 seconds

Example

// Client Side Connections

Connections
Port, Parity, Data_Bits, Stop_Bits, Protocol, Poll_Delay
P1, 2400 , None, 8, 1, Dart , 0.100s

Driver Manual

connected to the FieldServer

This is the port connected to the
DART’s RS232 port.

this parameter.

Either keyword may be used.

P1-P8, R1-R2
(P1-P8) requires 232/485
converter.

P1-P8, R1-R2
(R1-R2) requires 232/485
converter.

Daire only operates at 2400
baud.)

None
8

1

Dart

None
default 1 second

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 6

4.3 Client Side Nodes
Section Title

Nodes

Column Title Function Legal Values

Node_Name Provide name for node Up to 32 alphanumeric

Node_ID This is not the node address of

Protocol Specify protocol used Dart
Port Specify which port the Dart is

Example

// Client Side Nodes

Nodes
Node_Name, Node_ID, Protocol, Port
Unit1, 1, Dart , P1

Driver Manual

characters
1-259

the Dart device !
Specify the node address of the

DAP de vice whose data you
wish to monitor.

P1-P8, R1-R2

connected to the FieldServer

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 7

Driver Manual

4.4 Client Side Map Descriptors

4.4.1 FieldServer Specific Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric

Data_Array_Name Name of Data Array where data

is to be stored in the
FieldServer

Data_Array_Location Starting location in Data Array 0 to maximum specified in

Function Function of Client Map

Descriptor

The use of the WRBX keyword
is recommended for DART
configurations as
communications are minimized.

characters
One of the Data Array names

from “Data Array” section
above

“Data Array” section above
RDBC, WRBC, WRBX,
Passive

4.4.2 Timing Parameters

Column Title Function Legal Values

Scan_Interval Rate at which data is polled >0.1s

4.4.3 Driver Specific Map Descriptor Parameters

Column Title Function Legal Values

Node_Name Name of Node to fetch data

from

Length Length of Map Descriptor 1 The length must always be

Address Starting address of read block Not required for client

The following parameters apply only to the Dart Driver.
DA_Func* Tell the driver to poll the device

for all the data that is available.
The data is device specific.

Other uses of this parameter are
permitted. These uses are
discussed in the Advanced
Topics section of this manual.

One of the node names
specified in “Client Node
Descriptor” above

set to one.

configuration. This parameters
is used in simulation
configuration only.

Everything

See table 4.4.3.1 for a map of
how the data is stored in the
Fieldserver data arrays

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 8

Driver Manual

DA_Field Onl y required when the

function is a write (wrbc) or
when the map descriptor is
associated with a write by
means of the DA_Assoc
parameter value.

This is the name of the data
field whose value you wish to
set in the device.

Other uses of this parameter are
permitted. These uses are
discussed in the Advanced
Topics section of this manual.

DA_Assoc Use to associate passive map

descriptors with an active map
descriptor.

Using this parameter you
associate multiple fields with
one wrbc map descriptor, thus
reducing writing multiple
values to one device using just
one message.

See Table 4.4.3.3 for a list of
permitted values.

Any positive integer.

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 9

Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 10

Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 11

4.4.4 Map Descriptor: Example 1 – Read all possible data

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Func
Read_Node_01, DA_01 , 0 , passive , Unit1 , 0 , 1300 , Everything

The driver waits

passively fo

r the

Dart to echo
data from the
devices.

No Scan Interval. The

driver will process data as
fast as the Dart can serve
it.

Driver Manual

4.4.5 Map of How Data Aire Device Data is stored in a Data Array

In the example of 4.4.1 the Fieldserver listens passively for all possible data from the device called ‘unit1’
and stores the data in an array called ‘DA_01’.

The data that is obtained from ‘unit1’ is dependent on the type of de vice. Irrespective of the device type
the arrangement of data, stored in DA_01, is fixed. If a data field cannot be obtained from ‘unit1’ then
the array is left with a zero value for that data field.

Table 4.4.5.1: Array Locations of ‘Everything’

In the following table the array location indicates the offset in the data array at which a data field can be
found. (This offset is relative to the offset specified in the map descriptor.) The columns headed 2,3 …
indicate the unit types for which the data fields are available. For example: The field ‘d_temp’ can be read
from unit types 2,5,6,7,9 but not from any of the other unit types. It is beyond the scope of this manual to
describe each field and to indicate valid ranges. Such information should be obtained from the Data Aire
Corporation.

‘x’ Indicates Read only
‘X’ Indicates a point that can be read & written.
‘w’ Indicates a write only point.

Array
Location

1 1 1 Zone w w w w w w w w w Dap-Config
2 1 1 Inhibit w w w w w w w w w Dap-Config

3 4 1 unitType x x x x x x x x x x Dap-Unit

4 2 1 temp x x x x x Dap-Stat
5 2 1 hum x x x x x Dap-Stat
6 2 1 d_temp x x x x x Dap-Stat
7 3 8 mode x x x x x Dap-Stat
23 3 8 hold x x x x x Dap-Stat
39 1 1 cs_on x x x x x Dap-Stat
40 1 1 hs_on x x x x x Dap-Stat
41 1 1 valvePCT x x x x x Dap-Stat
42 1 1 hVlvPCT x x x x x Dap-Stat
43 4 14 errors x x x x x Dap-Stat
57 2 1 hiTemp x x x x x Dap-Stat
58 2 1 loTemp x x x x x Dap-Stat
59 2 1 hiHum x x x x x Dap-Stat
60 2 1 loHum x x x x x Dap-Stat
61 1 1 chilled_water x x x x x Dap-Stat
62 1 1 compressor_config x x x x x Dap-Stat

Method

Num

Elements

Data Field 2 3 4 5 6 7 8 9 14 15 Message Type

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 12

Driver Manual

63 1 1 heat_strip_config x x x x x Dap-Stat
64 1 1 hum_config x x x x x Dap-Stat
65 1 1 csUtilPct x x x x x Dap-Stat
66 1 1 hsUtilPct x x x x x Dap-Stat
67 1 1 valveUtilPct x x x x x Dap-Stat
68 1 1 humUtilPCT x x x x x Dap-Stat
69 1 1 alrm_select_1 x x x x x Dap-Stat
70 1 1 alrm_select_2 x x x x x Dap-Stat
71 1 1 alrm_select_3 x x x x x Dap-Stat
72 1 1 alrm_select_4 x x x x x Dap-Stat

73 3 56 bitErrors x x x x x Dap-Stat

185 1 1 runtime_c1 x x x x x Dap-Xtra
186 1 1 runtime_c2 x x x x x Dap-Xtra
187 1 1 runtime_c3 x x x x x Dap-Xtra
188 1 1 runtime_c4 x x x x x Dap-Xtra
189 1 1 runtime_ht1 x x x x x Dap-Xtra
190 1 1 runtime_ht2 x x x x x Dap-Xtra
191 1 1 runtime_ht3 x x x x x Dap-Xtra
192 1 1 runtime_hum x x x x x Dap-Xtra
193 1 1 runtime_evap x x x x x Dap-Xtra
194 1 1 runtime_cond x x x x x Dap-Xtra
195 1 1 runtime_dehum x x x x x Dap-Xtra
196 1 1 runtime_esc x x x x x Dap-Xtra
197 1 1 runtime_cwc x x x x x Dap-Xtra
198 4 20 errors x x x x x Dap-Xtra
218 6 10 errage x x x x x Dap-Xtra
258 1 1 version x x x x x Dap-Xtra
259 2 1 tmbmair x x x x x Dap-Xtra
260 2 1 tmbhum x x x x x Dap-Xtra
261 1 1 tmbairdb x x x x x Dap-Xtra
x x x x x
262 6 13 runtimes (as array) x x x x x Dap-Xtra
314 3 80 bitErrors x x x x x Dap-Xtra

474 4 1 adj_rate X X X Dap-Menu
478 1 1 alrm_delay_1 X X X Dap-Menu
479 1 1 alrm_delay_2 X X X Dap-Menu
480 1 1 alrm_delay_3 X X X Dap-Menu
481 4 1 alrm_enable_1 X X X Dap-Menu
482 4 1 alrm_enable_2 X X X Dap-Menu
483 4 1 alrm_enable_3 X X X Dap-Menu
484 4 1 alrm_select_1 X X X Dap-Menu
485 4 1 alrm_select_2 X X X Dap-Menu
486 4 1 alrm_select_3 X X X Dap-Menu

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 13

Driver Manual

487 1 1 chilled_water X X X Dap-Menu
488 1 1 compressor_config X X X Dap-Menu
489 1 1 c_mode X X X Dap-Menu
490 2 1 fire_lim X X X Dap-Menu
491 1 1 heat_strip_config X X X Dap-Menu
492 1 1 hi_cal X X X Dap-Menu
493 1 1 hi_h_cal X X X Dap-Menu
494 2 1 hi_t_lim X X X Dap-Menu
495 1 1 humid_config X X X Dap-Menu
496 1 1 h_calib X X X Dap-Menu
497 1 1 lead_lag X X X Dap-Menu
498 1 1 loc_h_deadband X X X Dap-Menu
499 1 1 loc_h_setpt X X X Dap-Menu
500 2 1 loc_t_dband X X X Dap-Menu
501 2 1 loc_t_setpt X X X Dap-Menu
502 1 1 lo_cal X X X Dap-Menu
503 1 1 lo_h_lim X X X Dap-Menu
504 2 1 lo_t_lim X X X Dap-Menu
505 1 1 main_int X X X Dap-Menu
506 1 1 passwd_a X X X Dap-Menu
507 1 1 passwd_b X X X Dap-Menu
508 1 1 rst_mode X X X Dap-Menu
509 1 1 s_delay X X X Dap-Menu
510 2 1 t_calib X X X Dap-Menu
511 1 1 voice X X X Dap-Menu
512 1 1 vvrg X X X Dap-Menu
513 1 1 cat1 X X X Dap-Menu
514 1 1 cat2 X X X Dap-Menu
515 1 1 cat3 X X X Dap-Menu
516 2 1 d_calib X X X Dap-Menu
517 2 1 lo_d_lim X X X Dap-Menu
518 1 1 ptc X X X Dap-Menu

519 2 1 supplyT x x x Chiller-Stat
520 2 1 returnT x x x Chiller-Stat
521 4 1 coolOn1 x x x Chiller-Stat
522 4 2 coolOn2 x x x Chiller-Stat
523 4 2 coolOn3 x x x Chiller-Stat
524 2 1 valvePct x x x Chiller-Stat
525 4 1 pumpsOn x x x Chiller-Stat
526 4 1 condOn x x x Chiller-Stat
527 4 1 modFail x x x Chiller-Stat
528 2 1 hiSupT x x x Chiller-Stat
529 2 1 loSupT x x x Chiller-Stat
530 2 1 hiRetT x x x Chiller-Stat
531 2 1 loRetT x x x Chiller-Stat
532 1 1 csUtilPct1 x x x Chiller-Stat

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 14

Driver Manual

533 1 1 csUtilPct2 x x x Chiller-Stat
534 1 1 csUtilPct3 x x x Chiller-Stat
535 1 1 valveUtilPct x x x Chiller-Stat
536 3 48 errors x x x Chiller-Stat
584 1 1 mode x x x Chiller-Stat

585 6 11 runtimes x x x Chiller-Xtra
596 3 80 errold x x x Chiller-Xtra
676 6 10 errage x x x Chiller-Xtra

854 4 1 adjust_rate x x x Chiller-Menu
855 4 1 auto_ack X X X Chiller-Menu
856 2 1 aux_setpt X X X Chiller-Menu
857 4 1 backup_mods X X X Chiller-Menu
858 2 1 backup_setpt X X X Chiller-Menu
859 4 1 cmota X X X Chiller-Menu
860 4 1 comp_type X X X Chiller-Menu
861 4 1 ptc X X X Chiller-Menu
862 2 1 hi_r_lim X X X Chiller-Menu
863 2 1 hi_s_lim X X X Chiller-Menu
864 4 1 LL_policy X X X Chiller-Menu
865 2 1 lo_r_lim X X X Chiller-Menu
866 2 1 lo_s_lim X X X Chiller-Menu
867 1 1 main_int X X X Chiller-Menu
868 4 1 mods_configd X X X Chiller-Menu
869 1 1 network_ID X X X Chiller-Menu
870 1 1 op_1_delay X X X Chiller-Menu
871 1 1 op_2_delay X X X Chiller-Menu
872 4 1 op_1_message X X X Chiller-Menu
873 4 1 op_2_message X X X Chiller-Menu
874 1 1 password X X X Chiller-Menu
875 4 4 relay_mask_0 X X X Chiller-Menu
879 4 4 relay_mask_1 X X X Chiller-Menu
883 4 4 relay_mask_2 X X X Chiller-Menu
887 4 1 restart_mode X X X Chiller-Menu
888 4 1 reverse_valve X X X Chiller-Menu
889 4 1 sc_alarm_on X X X Chiller-Menu
890 1 1 start_delay X X X Chiller-Menu
891 1 1 supply_dband X X X Chiller-Menu
892 2 1 supply_setpt X X X Chiller-Menu
893 4 1 temp_scale X X X Chiller-Menu
894 4 1 valve_voltage X X X Chiller-Menu
895 4 1 voice X X X Chiller-Menu
896 4 1 water_valve X X X Chiller-Menu
897 1 1 return_cal X X X Chiller-Menu
898 1 1 supply_cal X X X Chiller-Menu

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 15

Driver Manual

899 4 1 adj_rate X X X X Dap80-Menu
900 1 1 alrm_delay_1 X X X X Dap80-Menu
901 1 1 alrm_delay_2 X X X X Dap80-Menu
902 1 1 alrm_delay_3 X X X X Dap80-Menu
903 1 1 alrm_delay_4 X X X X Dap80-Menu
904 4 1 alrm_select_1 X X X X Dap80-Menu
905 4 1 alrm_select_2 X X X X Dap80-Menu
906 4 1 alrm_select_3 X X X X Dap80-Menu
907 4 1 alrm_select_4 X X X X Dap80-Menu
908 4 1 ant-enable X X X X Dap80-Menu
909 4 1 autoflush_time X X X X Dap80-Menu
910 4 1 auto_ack X X X X Dap80-Menu
911 4 1 comp_config X X X X Dap80-Menu
912 4 1 control_type X X X X Dap80-Menu
913 4 1 c_mode X X X X Dap80-Menu
914 4 1 da_volts X X X X Dap80-Menu
915 4 1 dehum_on X X X X Dap80-Menu
916 2 1 d_calib X X X X Dap80-Menu
917 4 1 esaver_supp_comp X X X X Dap80-Menu
918 2 1 fire_lim X X X X Dap80-Menu
919 4 1 heater_config X X X X Dap80-Menu
920 1 1 hi_h_lim X X X X Dap80-Menu
921 2 1 hi_t_lim X X X X Dap80-Menu
922 4 1 humid_config X X X X Dap80-Menu
923 2 1 h_calib X X X X Dap80-Menu
924 1 1 h_dband X X X X Dap80-Menu
925 4 1 lead_lag X X X X Dap80-Menu
926 2 1 lo_d_lim X X X X Dap80-Menu
927 1 1 lo_h_lim X X X X Dap80-Menu
928 2 1 lo_t_lim X X X X Dap80-Menu
929 2 1 main_int X X X X Dap80-Menu
930 1 1 network_id X X X X Dap80-Menu
931 2 1 nom_h_setpt X X X X Dap80-Menu
932 1 1 password X X X X Dap80-Menu
933 4 1 ptc X X X X Dap80-Menu
934 3 16 relay_1_mask_0 X X X X Dap80-Menu
950 3 16 relay_1_mask_1 X X X X Dap80-Menu
966 3 16 relay_1_mask_2 X X X X Dap80-Menu
982 3 16 relay_2_mask_0 X X X X Dap80-Menu
998 3 16 relay_2_mask_1 X X X X Dap80-Menu
1014 3 16 relay_2_mask_2 X X X X Dap80-Menu
1030 3 16 relay_3_mask_0 X X X X Dap80-Menu
1046 3 16 relay_3_mask_1 X X X X Dap80-Menu
1062 3 16 relay_3_mask_2 X X X X Dap80-Menu
1078 4 1 reverse_valve X X X X Dap80-Menu
1079 4 1 rst_mode X X X X Dap80-Menu
1080 4 1 sc_alarms X X X X Dap80-Menu

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 16

Driver Manual

1081 1 1 s_delay X X X X Dap80-Menu
1082 2 1 t_calib X X X X Dap80-Menu
1083 1 1 t_dband X X X X Dap80-Menu
1084 2 1 t_setpt X X X X Dap80-Menu
1085 4 1 valve_config X X X X Dap80-Menu
1086 4 1 voice X X X X Dap80-Menu

1100 1 1 sensor_1_name x x Dap80-Analog
1101 1 1 sensor_1_units x x Dap80-Analog
1102 1 1 sensor_1_type x x Dap80-Analog
1103 1 1 sensor_1_min_val x x Dap80-Analog
1104 1 1 sensor_1_max_val x x Dap80-Analog
1105 1 1 sensor_1_cal x x Dap80-Analog
1106 1 1 sensor_2_name x x Dap80-Analog
1107 1 1 sensor_2_units x x Dap80-Analog
1108 1 1 sensor_2_type x x Dap80-Analog
1109 1 1 sensor_2_min_val x x Dap80-Analog
1110 1 1 sensor_2_max_val x x Dap80-Analog
1111 1 1 sensor_2_cal x x Dap80-Analog

1112 1 1 sensor_1_input x x Dap80-Channels
1113 1 1 sensor_2_input x x Dap80-Channels
1114 1 1 sensor_3_input x x Dap80-Channels

4.4.6 Unit Types

When the driver reads everything from a device it must first obtain the device’s unit type so that it
can determine what other data is available. Once the unit type is obtained then the driver updates
the ‘Unit -Type’ field visible on the node screen of the RUIDebug program. The unit type is also
available in the data array defined in table 4.4.5.1.

The following table lists the unit type that can be processed by this driver.

Unit Type Numeric Unit Type Description
"-" 0
"1" 1
"2" 2
"3" 3
"4' 4
"5" 5
"6" 6

Unknown/unavailable/un-initialized
044 data logger
046 expanded DAP
046 2 mod chiller
046 3 mod chiller
048 DAP, 80-character display
049 DAP, 16-character display

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 17

Driver Manual

"7" 7
"8" 8
"9" 9
"10" 10
"11" 11
"12" 12
"13" 13
"E" 14
"F" 15

080 DAP II, no relay expansion
080 Chiller II
080 DAP II, with relay expansion
Not Defined
Not Defined
Not Defined
Not Defined
080 DAP II, with analog module
080 DAP II, with relay and analog

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262 -2299 fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 18

Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 19

4.4.7 Map Descriptor: Example 2 – Writing a Set-Point .

A Data Aire device cannot be written to until it has been read. This is a limitation of the Data Aire protocol. This means that you configuration cannot
consist only of wrbc map descriptors. It should consist of a at least a map descriptor like example 1for every unit that you wish to write to.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Field , Scan_Interval
Write_SP_01 , DA_SETPOINTS , 0 , wrbc , unit1 , 0 , 1 , nom_h_setpt, 120.0s

Reccomendation

Use wrbx instead of wrbc. This causes the driver to generate the command message only when the setpoint changes which in turn minimizes
communications. Using this method the DART’s control mode is interrupted the least.

The setpoint is

obtained from this data

array.

Always leave the

address

set to zero and

the length as one.

Specify the data field you wish to write.

Pick from table 4.5.1. Ensure that the
keyword can be written to the unit type
identified as unit1.

Example. If unit1 is a Chiller then the
above map descriptor will not function
correctly as it can only be used to write
to unit types 7,9,14,15.

This is how often the data will be

written to the device.

Slow the scan interval down. The
dart will only take control of the
devices when the network has been
idle for at least 50 seconds. If you
generate polls too often then the dart
will never exercise control.

Driver Manual

FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.fieldserver.com E-mail: [e-mail]

Page 20

4.4.8 Map Descriptor: Example 3 – Writing multiple points using one message.

Map_Descriptor_Name, Data_Array_Name , Data_Array_Offset, Function, node_name, Address, Length, DA_Field , DA_Assoc, Scan_Interval

Write_MapDesc_1, DA_ SETPOINTS, 0 , wrbc, unit1 , 0 1 , nom_h_setpt , 2 , 120.0s
Write_MapDesc_1, DA_SETPOINTS , 1 , passive, unit1 , 0 1 , t_setpt , 2

A 'Write' and a passive to the same node.

This write will update two fields, the
nom_h_setpt and the t_setpt.

The write MapDesc. Must precede the
passive.

This method is only appropriate if you plan

to continuosly write to the devices. If you
intend to write on change using the wrbx
function then use multiple map descriptors
that are not associated and give each one a

wrbx.

Associate the passive map descriptor to the

active (wrbc) map descriptor. In this way the
driver will use only one message to write to
the device. The message will be built using
both map descriptors. This method reduces
the communication load.

The association is made using the DA_Assoc

parameter. Use unique positive integers.
Omitting the DA_Assoc parameter when
using ‘passive’ map descriptors will produce
ambiguous results.

5 Chapter 5

This Chapter is blank.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 21

Driver Manual

its passive map descriptors

6 Advanced Topics

6.1 Additional Driver Specific Map Descriptor Parameters

What happens if you want to poll for one specific type of data more frequently than others ? What if you
want more control of the location of where data is stored ? What happens if you want to do diagnostic
polls … ?

To be able to achieve solutions to any of these types of questions the driver offers advanced configuration
by adding to and extending the map descriptors specific to the Dart Serial Driver.

Column Title Function Legal Values

DA_Func* Specifies the Data Aire

Command/Query function to be
used. Use a function
appropriate to the type of slave

Numeric/Text.

See section 6.1.1 for a list of

possible values.
(DAP/Chiller/DAP80) and the
type of data required.

DA_Field* Specifies the data field to be

retrieved from the slave device.
Salves are only capable of

responding with a data
composite consisting of many
data fields. You use this

This is a text field.

See section 6.1.2 for a list of

possible values as well as Table

4.4.5.1

parameter to specify which
parameter is you wish to have
extracted from the data
composite.

Note1.

DA_Assoc* Use to associate passive map

Any positive integer.
descriptors with an active map
descriptor. In some case you
may have a read (rdbc)
addressing the same node as a
write (wrbc). Both the read and
write may have associated map
descriptors. This field is used to
make the association. Give the
rdbc & passives map
descriptors associated with the
rdbc the same value (any
number) and give the wrbc and

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 23

Driver Manual

another value for DA_Assoc.

Da_Freq Used only for connection to

DART’s.

Specify in milliseconds the
interval at which you want a
wrbc/rdbc map descriptor to be
executed.

When using wrbc/rdbc’s to a
dart device set the scan interval
to 5.0s and set this parameter to
a number greater than 180000
(3 minutes). An interval of
300000 (5 minutes is
recommended).

DA_MethodΨ

Specifies the extraction method.
Such as Hex-ASCII to decimal

See section 6.3 for a list of

possible values.
number in 10's of a degree,

DA_BytcntΨ

Specifies the number of bytes

>= 1
that are to be processed by the
method specified above. For
method#6 which processes an
array of elements the
DA_Bytcnt specifies the
number of bytes that constitute
each element of the array.

DA_OffsetΨ

An offset into the data
composite that is returned when
the slave is polled. The offset is

0 to the length of the data

composite. No validation is

performed.
the number of bytes from the
first data byte.

DA_ElecntΨ

Number of elements that are

>= 1
produces by the extraction
method.

Ψ:
These parameters are only required for custom data extractions not provided for with DA_Field
parameter.

6.1.1 DA_Func Parameter - Permitted values.

The driver supports a limited subset of the Dart Poll & Response Functions. The selection
of the sub-set is based on the identification of useful & practical functions.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 24

Driver Manual

IN addition to the ‘Everything’ keyword indicated in chapter 4 the following specific
query functions are implemented.

Func. Description Driver Parameter Protocol Id.

‘1’ DART Config Query DA_Func = dart-config 49
‘2’ Dart Psswd Query DA_Func = dart-password 50
'3' DAP Config Command DA_Func = dap-config 51
'4' DAP Log Query DA_Func = dap-log 52
'5' DAP Unit-Type Query DA_Func = dap-unit 53
'6' DAP Stat Query DA_Func = dap-stat 54
'7' DAP Xtra Query DA_Func = dap-xtra 55
'8' DAP Menu Query DA_Func = dap-menu 56
'A' Chiller Stat Query DA_Func = chiller-stat 65
'B' Chiller Xtra Query DA_Func = chiller-xtra 66
'C' Chiller Menu Query DA_Func = chiller-menu 67
‘D” Dart Status DA_Func = dart-status 68
'E' DAP80 Menu Query DA_Func = dap80-menu 69
'G' DAP Analog Query DA_Func = dap80-analog 71
'H' DAP Channels Query DA_Func = dap80_channles 72

Each of the above queries returns a complex set of data consisting of many sub-fields.
Contact Data -Aire for a complete listing of the data composite returned.

The following special / diagnostic functions are also implemented.

Driver Parameter Protocol Id.

DA_Func = All-Listen 11
DA_Func = Ack 6
DA_Func = Dart-Transparant 2
DA_Func = Dart-Opaque 3
DA_Func = Test-Echo 16
DA_Func = Test-No-Echo 15
DA_Func = Unit -Talk 13

With the exception of the Unit -Talk command, these are nodeless commands.

When using any of these special commands no other DA_* fields need be specified.

The operation of these functions is as follows ;
All-Listen instructs the all units in the network to switch their relays to the listen position.

Those units already in the listen position will do nothing. Those in the talk position will
first echo the all-listen command and then switch their relays to the listen pos ition. A
pause of 0.15 seconds is required after the transmission of this command, to allow the
units time to switch their mechanical relays.

6.1.2 DA_Field Parameter - Permitted values.

Legal values depend on the value of DA_Func.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 25

Driver Manual

DA_Field Legal

Description Data Format DA_Func

Values

All The whole data record returned by the

Bytes
slave is stored in the data array byte for
byte. The number of bytes written is
dependent of the DA_Func.
DA_Func=dart-password Bytes =231
DA_Func=dart-config Bytes =41

DA_Func=dap-config Bytes =4
DA_Func=dap-log Bytes =240
DA_Func=dap-unit Bytes =1
DA_Func=dap-stat Bytes =68
DA_Func=dap-xtra Bytes =124
DA_Func=dap-menu Bytes =103
DA_Func=chiller-stat Bytes =54
DA_Func=chiller-xtra Bytes =104
DA_Func=chiller-menu Bytes =89
DA_Func=dap80-menu Bytes =138
DA_Func=dart-status Bytes = 9
DA_Func=dap80-analog Bytes =36
DA_Func=dap80-channels Bytes=12

Special Indicates that a user defined extraction is

specified in the map descriptor.
When this value is specified as the

DA_Field value then
DA_Method,DA_Bytcnt,DA_Offset,DA_
Elecnt must also be specfied.

See Table 4.4.5.1 for all
other keywords.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 26

Driver Manual

6.1.3 DA_Method Parameter Values and Notes

The DA_Method specifies a method for interpreting a range of bytes when the DA_Field=special.

Method 1:

Each byte is valid when its contains only one of the following ASCII characters.

{ 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, F }

Each byte being parsed is considered to be a hexadecimal digit. The most significant digit is the
left most byte.

Thus the four bytes
30 31 32 33 (hex) are interpreted by regarding the ASCII value of each byte as a hexadecimal
digit. Thus we interpret the 4 bytes as the hexadecimal number 0123 and the decimal value is
equal to 291.

Method 2

This method is the same as method one but is used for humidity's and temperatures which are
transmitted as the number of tenths of a unit.

Thus in the example of method 1. The 4 bytes yield the decimal number 29.1 °F/%.

Method 3

Each byte is regarded as containing a hexadecimal digit in ASCII format.

Example: incoming byte contains 41(hex). -> regard as the hexadecimal digit 'A' in ASCII
format.

The method then converts the hex digit to a series of 8 bits. In this example the bits are 00001010
with the msb being the left most.

Method 4

Each byte is regarded as containing a hexadecimal digit in ASCII format.

Example: incoming byte contains 41(hex). -> regard as the hexadecimal digit 'A' in ASCII
format. The decimal value of the this digit is written to the data array. In this example the number
10 would be written to the data array.

Method 5

There is no translation. The raw bytes are written to the data array.

Method 6

Processes an array of elements usin g method 1 translation. The raw data being parsed is
considered to consist of DA_elecnt elements each consisting of DA_bytecnt bytes. Method 1 is
applied to each cluster of bytes.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 27

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 28

6.1.4 Advanced Example 1 :

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Func, DA_Field, Scan_Interval
A1, DA_AI3, 0, rdbc, Node_A, 0, 1 , dap-stat, temp ,5
A2, DA_AI3, 1, passive, Node_A, 0, 1 , dap-stat, hum ,5
A3, DA_AI3, 2, passive, Node_A, 0, 1, dap-stat, d_temp ,5
A4, DA_AI3, 3, passive, Node_A, 0, 1 , dap-stat, hiTemp ,5
A5, DA_AI3, 4, passive, Node_A, 0, 1 , dap-stat, loTemp ,5
A6, DA_AI2, 0, passive, Node_A, 0, 1 , dap-stat, cs_on ,5
A7, DA_AI2, 1, passive, Node_A, 0, 1 , dap-stat, hs_on ,5

All these map

descriptors address
Node_a therefore
only one map
descriptor needs to
read (rdbc) the node.
The remaining map
descriptors can be
passive (thus
optimizing
communications.)

The scan time

is only
important for

the active map

descriptor.

It would be

sensible for
DA_AI3 to be an
array of FLOATs
because the temps
and humidity’s
return real
numbers with one
digit after the
decimal point.

DA_AI2 could be
any type of array
other than BIT

because the values

All these map

descriptors read
their data from
the same slave.

Slave is a DAP

and we are
reading status
information.

These

parameters need
to be typed in
exactly as
specified in this
manual. They
are case
sensitive.

The format of
the data
extracted
depends on the
parameter.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 29

6.1.5 Advanced Example 2

The DAP-II Status query returns 14 bytes of errors & status information. The arrangement and meaning of these bytes is defined by the Data Aire
Corporation and is also dependent on the type of DAPII module being polled.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Func, DA_Field, Scan_Interval
A1, DA_AI1, 0, rdbc, Node_A, 0, 1 , dap-stat, errors ,5
A2, DA_DI1, 1, passive, Node_A, 0, 1 , dap-stat, bitErrors ,5

The 'errors' key

word returns 14
bytes, thus we

DA_AI1 should be

a BYTE array.
Each byte will
have values 0-15
to represent the

value of the bits in

each byte.

The bitErrors
extracts the same

data from the DAP

but presents it as a

series of 14x8 bits.

Thus make

Slave is a DAP

and we are
reading status
information.

BitErrors is a synonym for errors. The

data is extracted using a different data
format.

Data arrangement and meaning of each

error is defined by Data Aire Corp.
Example: Bit 24 is a LOW TEMP

WARNING for DAPII-044/8/9 units.

Example: Bit 09 is a HUMIDITY
SENSOR PROBLEM for a DAPII-

080

unit.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 30

6.1.6 Advanced Map Descriptor: Example 3 - Using the 'special' parameter.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Func, DA_Field, DA_Method
,DA_Bytcnt, DA_Offset, DA_Elecnt Scan_Interval
A1, DA_AI3, 0, rdbc, Node_A, 0, 1 , dap-stat, special, 1 4, 10, 1, 5

You can use

specials as rdbc

and passive map

descriptors.

See table

6.3
for
descriptions
on how these
extraction

methods work.

It would be

sensible for
DA_AI3 to be an
array of FLOATs

because extraction

method(=1)
returns a floating
point number.

Performs a D

AP

status query

From the data bytes

returned by the slave,

extract 4 bytes
starting at

byte 10

and

apply method 1

to convert the bytes
before writing them to

the FieldServer data

Once you use

the parameter
'special' you

must specify the

additional
parameters.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 31

6.1.7 Advanced Map Descriptor: Example 4 - Using the 'DA_Assoc' parameter.

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Address, Length, DA_Func, DA_Field, DA_Assoc, Scan_Interval

A1, DA_AI3, 0, rdbc, Node_A, 0, 1 , dap80-menu, All , 1 ,5
A2, DA_AI3, 1, passive, Node_A, 0, 1 , dap80-menu, alrm_delay_1, 1 ,5
A3, DA_AI3, 2, passive, Node_A, 0, 1, dap80-menu, alrm_delay_2, 1 ,5
A4, DA_AI3, 3, passive, Node_A, 0, 1 , dap80-menu, alrm_delay_3, 1 ,5
A8, DA_AI4, 0, wrbc, Node_A, 0, 1 , dap80-menu, nom_h_setpt, 2 ,5
A9, DA_AI4, 1, passive, Node_A, 0, 1 , dap80-menu, t_setpt , 2, 5

A 'Read' and some

passive map
descriptors to
extract other data
fields from the
same read.
(optimizes
communications)

Read must precede

the passive's.

A 'Write' and a

passive to the
same node. This

write will update

two fields, the
nom_h_setpt
and the t_setpt.

The write map
desc. Must
precede the

passive.

DA_Assoc associates

the passives with the
correct active map
descriptor.

Thus Map Descriptors
A2,3,4 are associated
with A1 because the
value of DA_Assoc=1
for all these map
descriptors.

Thus Map
DescriptorsA89is
associated with A8
because the value of
DA_Assoc=2 for both

these map descriptors.

Potential

confusion for
the FieldServer
because the
node and the
DA_Func's are
the same for all
the map
descriptors.

Solve this
problem using
DA_Assoc.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 32

6.1.8 Map Descriptor: Example 5 - Using a special / diagnostic command.

Map_Descriptor_Name, Scan_Interval, Data_Array_Name , Data_Array_Offset, Function, node_name, Address, Length, DA_Func,

A1, 1.0s, UNUSED_ARRAY, 0 , wrb , No_node, 0, 1 , All-Listen,

This command

is sent only
once. If you
need to do this

periodically then

change this to a
wrbc.

A da

ta array must

be associated with

the map descriptor

even though it will

not be used. It
may be any data

type.

Must connect this map descriptor to a node whose node_id is

zero. For example.

Nodes
Node_Name, Node_ID, Protocol, Port
Unit1, 0, Daire, R1

This is a special

/ dianostic
command. It
causes a one
byte message to

be sent.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 33

6.2 Related Documents

The driver as specified in this manual is based on Data Aire Poll and Response Protocol
Revision 3.2 dated 4 Nov 1997.

The driver is compliant with a later release of the specification Revision 3.7 - 21 JUN

00.

6.3 Troubleshooting Tips

6.3.1 Bad Values

In the event that the driver cannot correctly decode the raw bytes it will generally write an value
which indicates bad data. In most cases the indicating value is -1 or 65535 (depending on data
type). Whe n setting bits for status fields the driver will not write new data to the array if the
incoming byte is invalid. Look in the error log for indication of this type of problem.

Example. Valid ASCII digits are 0..9,A..F. If a byte is being parsed and an hex digit is expected
but not found then the driver considers this an errors and writes the bad value indication OR
produces an error message when the bad value indication cannot be used.

Driver Manual

6.3.2 Dead Nodes

When a node is absent or dies it is possible that the Dart may go idle and stop communicating
with all other nodes. This problem is not related to the driver but to the Data Aire devices.

6.3.3 Ignored Messages

The driver reports ignored messages. These are messages sent by a DAP/DART for which the
driver cannot find a map descriptor to store the message. This does not mean the driver is not
working. It means that a message which contains data that the driver/you are not interested in is
being discarded.

The current version of the driver ignores a few messages r elating to the status of the DART
device. Later versions of the driver will be capable of storing these messages and the number of
ignored messages will decrease.

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 34

6.4 Writing data to Dap Devices

The variables in a DAP device are not individually addressable. When a DAP device is read a
data composite is returned. The driver extracts the data you require. When data is written to a
DAP device it is not possible to write a value to one individual data element such as a
temperature setpoint. Rather, the DAP devices requires the complete data composite (all its
variables, states, settings) be written at once. This makes the setting of a setpoint a complex
operation for the driver.

It involves the following steps

i. Read the device, obtain a complete set of data a nd store (internally in the driver.).

ii. Use this stored data to form the basis for a write. Modify the data with the data

the user wishes to set.

iii. Write the modified data composite back to the DAP device.

You can see that to complete a 'write' operation successfully, we must first read the device
successfully. If the read has not been completed then the write operation will be abandoned. The
driver prints messages to the error logs and records a NODE_OFFLINE stat each time that it
attempts to write but is una ble to.

The DAP -Config command is an exception to the above notes. A read is not required. The Dap
Config command is used to turn off/on DAP units. The Command uses two consecutive array
elements. The first is the zone, the second is the inhibit command. Valid zones are 0-63.

If any inhibit bit (bits 0-5) is set then the unit will not run. If bits 0 to 5 are off then the unit will
run. Bits 6& 7 are used for display only on the DAP panel.

0x01 - Inhibit Cooling
0x02 - Inhibit Heating
0x04 - Inhibit Humid
0x08 - Inhibit Dehumidification
0x10 - Inhibit fan
0x20 - Reserved
0x40 - Network Standby - Display on panel (only has no effect on unit)
0x80 - Network off inhibit is active - display only - no effect on operation

This function should be used as a wrbc/x. When the driver encounters this command it reads the
associated data array, loads the two elements found at the array offset into the message and
transmits the message. The driver does not set any data array elements to confirm that the
command concluded successfully.

Driver Manual

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 35

Driver Manual

Indicates Driver

se this release

Revisions to the manual. Each

7 Revision Change Notices

Revision Number Format Explained:

1.05a Rev0

relea
of the manual
corresponds to.

time that the driver release
number changes the manual
revision is set to zero.

7.1 Rev1.06a-Rev0 Changes from previous releases

This is the first release of this driver since its separation from a combined Dart/Dap driver.
Previously this manual was identified as the “Data Aire user Manual Rev1.05a Rev2”

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 [phone] fax: [phone]

Visit our website: www.sierramonitor.com E-mail: [e-mail]

Page 36
