Page 1
2021 FIAT® 500X OWNER’S MANUAL
Page 2
The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in an accident and personal
injury. FCA US LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road. Use of any
electrical devices, such as cellular telephones, computers, portable radios, vehicle navigation or other devices, by the driver while the vehicle is moving is dangerous
and could lead to a serious accident. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you nd yourself unable to devote
your full attention to vehicle operation, pull off the road to a safe location and stop your vehicle. Some states or provinces prohibit the use of cellular telephones or
texting while driving. It is always the driver’s responsibility to comply with all local laws.
This Owner’s Manual has been prepared to help you get acquainted with your new FIAT® brand vehicle and to provide a convenient reference source for common
questions.
Not all features shown in this manual may apply to your vehicle. For additional information, visit www.mopar.com (U.S.), www.mopar.ca (Canada) or your local FIAT®
brand dealer.
This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include
a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this
manual that are not on this vehicle. FCA US LLC reserves the right to make changes in design and specications, and/or make additions to or improvements to its
products without imposing any obligation upon itself to install them on products previously manufactured.
With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution therefore.
If you are the rst registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet by calling 1-888-242-6342 (U.S.) or
1-800-387-1143 (Canada) or by contacting your dealer.
This Owner’s Manual is intended to familiarize you with the important features of your vehicle. Your most up-to-date Owner’s Manual, Navigation/Uconnect manuals
and Warranty Booklet can be found by visiting the website on the back cover. U.S. residents can purchase replacement kits by visiting www.techauthority.com and
Canadian residents can purchase replacement kits by calling 1-800-387-1143.
WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle
can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are
known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a wellventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more
information go to www.P65Warnings.ca.gov/passenger-vehicle.
Page 3
TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
11
INTRODUCTION.............................................................................................................................. 7
GET
TING TO KNOW YOUR VEHICLE ..................................................................................13
GETTING TO KNOW YOUR INSTRUMENT PANEL ....................................................... 66
STARTING AND OPERATING .................................................................................................85
MULTIMEDIA ............................................................................................................................... 133
SAFETY .........................................................................................................................................188
IN CASE OF EMERGENCY ....................................................................................................238
SERVICING AND MAINTENANCE ......................................................................................254
TECHNICAL SPECIFICATIONS .............................................................................................310
CUSTOMER ASSISTANCE ......................................................................................................316
INDEX ............................................................................................................................................. 322
1
2
3
4
5
6
7
8
9
10
11
Page 4
2
INTRODUCTION
Symbols Key............................................................ 8
ROLLOVER WARNING ........................................... 8
VEHICLE MODIFICATIONS/ALTERATIONS........... 9
Symbol Glossary..................................................... 9
GETTING TO KNOW YOUR VEHICLE
KEYS ......................................................................13
Key Fob......................................................... 13
SENTRY KEY ..........................................................15
IGNITION SWITCH .................................................16
Keyless Enter-N-Go — Ignition.....................16
REMOTE START — IF EQUIPPED .........................17
How To Use Remote Start ........................... 18
To Exit Remote Start Mode ......................... 18
Remote Start Front Defrost Activation — If
Equipped ...................................................... 19
Remote Start Comfort Systems — If
Equipped .....................................................19
Remote Start Windshield Wiper De–Icer
And Rear Defrost Activation — If
Equipped ...................................................... 20
Remote Start Cancel Message — If
Equipped ...................................................... 20
VEHICLE SECURITY SYSTEM — IF EQUIPPED....20
To Arm The System .....................................20
To Disarm The System ................................20
Disabling....................................................... 21
DOORS................................................................... 21
Manual Door Locks...................................... 21
Power Door Locks........................................ 22
Keyless Enter-N-Go ..................................... 22
Automatic Door Locks — If Equipped ........25
Child-Protection Door Lock System — Rear
Doors ............................................................25
STEERING WHEEL ................................................ 26
Manual Tilt/Telescoping Steering
Column ......................................................... 26
Heated Steering Wheel — If Equipped ....... 26
SEATS ....................................................................27
Manual Adjustment (Front Seats) ..............27
Manual Adjustment (Rear Seats) ............... 28
Power Adjustment Front Seats — If
Equipped ......................................................30
Heated Seats — If Equipped ...................... 31
Head Restraints .......................................... 31
UCONNECT VOICE RECOGNITION....................... 33
Introducing Voice Recognition.................... 33
Get Started................................................... 34
Basic Voice Commands............................... 34
Additional Information................................. 34
MIRRORS .............................................................35
Inside Rearview Mirror ................................ 35
Illuminated Vanity Mirrors — If Equipped .. 35
Outside Mirrors ........................................... 35
Power Mirrors............................................... 36
Folding Mirror............................................... 36
Power Folding Mirrors — If Equipped.......... 36
Heated Mirrors — If Equipped..................... 37
EXTERIOR LIGHTS.................................................37
Headlight Switch ......................................... 37
Daytime Running Lights (DRLs) — If
Equipped ..................................................... 38
High Beams.................................................. 38
Flash-To-Pass............................................... 38
Automatic Headlights — If Equipped ......... 39
Parking Lights .............................................. 39
Headlight Time Delay ................................. 39
Front Fog Lights — If Equipped .................. 39
Turn Signals ................................................. 40
Lane Change Assist .................................... 40
Courtesy Lights/Approaching Lights .......... 40
INTERIOR LIGHTS ................................................40
Front Courtesy Light .................................... 40
Cargo Area Lights ........................................ 42
WINDSHIELD WIPERS AND WASHERS.............42
Windshield Wiper Operation ...................... 42
Rain Sensing Wipers — If Equipped ........... 43
Rear Window Wiper/Washer ...................... 44
Windshield Wiper De-Icer — If Equipped.... 45
CLIMATE CONTROLS ...........................................45
Automatic Climate Control Descriptions
And Functions .............................................. 45
Manual Climate Control Descriptions And
Functions ..................................................... 48
Automatic Temperature Control (ATC) ...... 51
Climate Voice Recognition .......................... 51
Operating Tips ............................................. 51
Page 5
3
INTERIOR STORAGE AND EQUIPMENT..............53
Storage ......................................................... 53
Sun Visors “Slide-On-Rod” ..........................54
USB/Media Player Control .......................... 55
Power Outlets ..............................................55
Cigar Lighter — If Equipped ........................ 56
Ashtray — If Equipped..................................56
Grab Handles ...............................................56
WINDOWS..............................................................57
Power Window Controls............................... 57
SUNROOF — IF EQUIPPED ...................................58
Opening And Closing The Sunroof .............. 59
Pinch Protect Feature.................................. 59
Venting Sunroof ........................................... 59
Sun Shade.................................................... 59
Sunroof Maintenance.................................. 59
Emergency Operation .................................. 60
Power Sunroof Relearn Procedure ............. 60
HOOD .....................................................................60
To Open The Hood ....................................... 60
To Close The Hood....................................... 61
LIFTGATE................................................................62
To Unlock/Open The Liftgate ...................... 62
Lock/Close The Liftgate ..............................62
Cargo Area Features....................................63
ROOF LUGGAGE RACK — IF EQUIPPED ............65
GETTING TO KNOW YOUR
INSTRUMENT PANEL
INSTRUMENT CLUSTER ....................................... 66
Instrument Cluster Descriptions................. 67
INSTRUMENT CLUSTER DISPLAY .....................67
Instrument Cluster Display Control
Buttons......................................................... 68
Engine Oil Change Reset — If Equipped..... 68
Instrument Cluster Display Main Menu .....69
WARNING LIGHTS AND MESSAGES.................. 73
Red Warning Lights .....................................74
Yellow Warning Lights ................................. 76
Yellow Indicator Lights ................................80
Green Indicator Lights................................. 81
White Indicator Lights ................................. 81
Blue Indicator Lights.................................... 82
Gray Indicator Lights ...................................82
ONBOARD DIAGNOSTIC SYSTEM — OBD II....... 82
Onboard Diagnostic System (OBD II)
Cybersecurity ............................................... 83
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS........................................................... 83
STARTING AND OPERATING
STARTING THE ENGINE........................................85
Tip Start Feature ......................................... 85
If Engine Fails To Start ............................... 85
Cold Weather Operation.............................. 86
Extended Park Starting ............................... 86
After Starting — Warming Up The Engine... 86
Stopping The Engine ................................... 86
Turbocharger “Cool Down” — If Equipped.. 87
ENGINE BREAK-IN RECOMMENDATIONS .........87
ELECTRIC PARK BRAKE (EPB)............................87
Auto Park Brake........................................... 89
SafeHold....................................................... 90
Brake Service Mode .................................... 90
AUTOMATIC TRANSMISSION .............................91
Gear Selector............................................... 92
Gear Ranges ................................................ 92
Transmission Limp Home Mode................. 96
Ignition Park Interlock ................................. 96
Brake Transmission Shift Interlock (BTSI)
System.......................................................... 96
ALL WHEEL DRIVE (AWD) — IF EQUIPPED .......96
DYNAMIC SELECTOR — IF EQUIPPED ................97
Warning Messages...................................... 97
ELECTRIC POWER STEERING .............................97
Page 6
4
STOP/START SYSTEM..........................................98
Automatic Mode........................................... 98
Possible Reasons The Engine Does Not
Autostop ....................................................... 98
To Start The Engine While In Autostop
Mode............................................................. 98
To Manually Turn Off The Stop/Start
System..........................................................99
To Manually Turn On The Stop/Start
System..........................................................99
System Malfunction..................................... 99
CRUISE CONTROL SYSTEMS — IF
EQUIPPED ........................................................... 100
Cruise Control — If Equipped.....................100
Adaptive Cruise Control (ACC) — If
Equipped ....................................................102
FRONT/REAR PARK ASSIST — IF
EQUIPPED ........................................................... 111
Park Assist Sensors ...................................111
Park Assist Warning Display......................112
Park Assist Display ....................................112
Enabling And Disabling Park Assist..........115
Service The Park Assist System................115
Cleaning The Park Assist System .............116
Park Assist System Usage Precautions....116
LANESENSE — IF EQUIPPED ........................... 117
LaneSense Operation................................117
Turning LaneSense On Or Off ...................117
LaneSense Warning Message ..................118
Changing LaneSense Status.....................119
PARKVIEW REAR BACK UP CAMERA .............119
ADDING FUEL......................................................121
VEHICLE LOADING ............................................121
Certification Label .....................................121
TRAILER TOWING...............................................123
Common Towing Definitions .....................123
Trailer Hitch Classification ........................125
Trailer Towing Weights (Maximum Trailer
Weight Ratings)..........................................125
Trailer And Tongue Weight........................126
Towing Requirements ...............................126
Towing Tips.................................................129
RECREATIONAL TOWING (BEHIND
MOTORHOME) ....................................................130
Towing This Vehicle Behind Another
Vehicle........................................................130
DRIVING TIPS......................................................130
Driving On Slippery Surfaces ....................130
Driving Through Water ..............................131
MULTIMEDIA
UCONNECT SYSTEMS .......................................133
CYBERSECURITY ...............................................133
UCONNECT SETTINGS .......................................134
Customer Programmable Features ..........134
UCONNECT INTRODUCTION ..............................148
System Overview .......................................148
Drag & Drop Menu Bar..............................150
Safety And General Information ............... 150
UCONNECT MODES ........................................... 151
Steering Wheel Audio Controls ................151
Radio Mode ...............................................152
Media Mode ..............................................160
Phone Mode .............................................163
ANDROID AUTO™ & APPLE CARPLAY® — IF
EQUIPPED........................................................... 174
Android Auto™ ..........................................174
Apple CarPlay®.......................................... 177
Android Auto™ And Apple CarPlay® Tips
And Tricks...................................................179
NAVIGATION MODE — IF EQUIPPED................ 179
Navigation Main Menu..............................179
Navigating A Route....................................181
Search ........................................................ 181
Current Route ............................................ 182
My Places...................................................184
Parking .......................................................185
Gas Stations...............................................185
Settings ......................................................185
RADIO OPERATION AND MOBILE DEVICES ..187
Regulatory And Safety Information ..........187
SAFETY
SAFETY FEATURES ............................................ 188
Anti-Lock Brake System (ABS) ................. 188
Electronic Brake Control (EBC) System....189
Page 7
5
AUXILIARY DRIVING SYSTEMS ........................ 193
Blind Spot Monitoring (BSM) — If
Equipped ...................................................193
Full Brake Control System With
Mitigation ...................................................197
Tire Pressure Monitoring System
(TPMS) ........................................................201
OCCUPANT RESTRAINT SYSTEMS .................. 204
Occupant Restraint Systems.....................204
Important Safety Precautions ...................204
Seat Belt Systems......................................205
Supplemental Restraint Systems (SRS)...211
Child Restraints .........................................223
SAFETY TIPS....................................................... 234
Transporting Passengers ..........................234
Transporting Pets.......................................234
Safety Checks You Should Make Inside
The Vehicle ................................................234
Periodic Safety Checks You Should Make
Outside The Vehicle...................................236
Exhaust Gas ..............................................236
Carbon Monoxide Warnings......................237
IN CASE OF EMERGENCY
HAZARD WARNING FLASHERS ....................... 238
JACKING AND TIRE CHANGING ...................... 238
Preparations For Jacking ..........................239
Jack Location/Spare Tire Stowage — If
Equipped ....................................................239
Jacking Instructions...................................240
TIRE SERVICE KIT — IF EQUIPPED ...................243
Tire Service Kit Storage.............................243
Tire Service Kit Components And
Operation....................................................244
Tire Service Kit Usage Precautions ..........245
Replacing The Sealant ..............................246
JUMP STARTING.................................................246
Preparations For Jump Start..................... 246
Jump Starting Procedure ..........................247
IF YOUR ENGINE OVERHEATS ..........................248
GEAR SELECTOR OVERRIDE ............................249
FREEING A STUCK VEHICLE .............................250
TOWING A DISABLED VEHICLE .......................251
All Wheel Drive (AWD) Models .................. 251
Tow Eye Usage — If Equipped .................. 252
ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .................................................................253
EVENT DATA RECORDER (EDR) .......................253
SERVICING AND MAINTENANCE
SCHEDULED MAINTENANCE.............................254
Maintenance Plan .....................................254
ENGINE COMPARTMENT...................................259
1.3L Turbo Engine .....................................259
Checking Oil Level .....................................260
Adding Washer Fluid..................................260
Maintenance-Free Battery .......................261
Pressure Washing......................................261
VEHICLE MAINTENANCE................................... 261
Engine Oil .................................................. 262
Engine Oil Filter..........................................262
Engine Air Cleaner Filter............................262
Accessory Drive Belt Inspection ...............263
Air Conditioner Maintenance....................263
Body Lubrication........................................ 264
Windshield Wiper Blades .......................... 264
Exhaust System ........................................ 266
Cooling System .......................................... 267
Brake System ............................................270
Automatic Transmission............................271
FUSES......................................................... 272
BULB REPLACEMENT ................................279
TIRES................................................................... 289
Tire Safety Information..............................289
Tires — General Information ....................296
Tire Types ...................................................300
Spare Tires — If Equipped ......................... 301
Wheel And Wheel Trim Care ..................... 303
Snow Traction Devices .............................304
Tire Rotation Recommendations .............305
DEPARTMENT OF TRANSPORTATION
UNIFORM TIRE QUALITY GRADES .................. 305
Treadwear .................................................. 305
Traction Grades .........................................306
Temperature Grades ................................. 306
STORING THE VEHICLE ..................................... 306
Page 8
6
BODYWORK........................................................ 306
Protection From Atmospheric Agents.......306
Body And Underbody Maintenance ..........307
Preserving The Bodywork..........................307
INTERIORS ......................................................... 308
Seats And Fabric Parts..............................308
Plastic And Coated Parts...........................308
Leather Surfaces .......................................309
Glass Surfaces ..........................................309
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN)....... 310
BRAKE SYSTEM .................................................310
WHEEL AND TIRE TORQUE
SPECIFICATIONS................................................ 310
Torque Specifications................................310
FUEL REQUIREMENTS ...................................... 311
1.3L Turbo Engine .....................................311
Reformulated Gasoline .............................311
Materials Added To Fuel ...........................311
Gasoline/Oxygenate Blends .....................312
Do Not Use E-85 In Non-Flex Fuel
Vehicles ......................................................312
CNG And LP Fuel System Modifications...312
Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline..................312
Fuel System Cautions................................313
FLUID CAPACITIES .............................................314
ENGINE FLUIDS AND LUBRICANTS..................314
CHASSIS FLUIDS AND LUBRICANTS ..............315
CUSTOMER ASSISTANCE
SUGGESTIONS FOR OBTAINING SERVICE
FOR YOUR VEHICLE ..........................................316
Prepare For The Appointment...................316
Prepare A List.............................................316
Be Reasonable With Requests .................316
IF YOU NEED ASSISTANCE .............................. 316
FCA US LLC Customer Center...................317
FCA Canada Inc. Customer Center...........317
Mexico ........................................................ 317
Puerto Rico And U.S. Virgin Islands.......... 317
Customer Assistance For The Hearing Or
Speech Impaired (TDD/TTY) ..................... 317
Service Contract .......................................317
WARRANTY INFORMATION.............................. 318
MOPAR PARTS................................................... 318
REPORTING SAFETY DEFECTS ........................ 318
In The 50 United States And
Washington, D.C. ....................................... 318
In Canada...................................................318
PUBLICATION ORDER FORMS ........................ 319
General Information.......................................... 319
Page 9
INTRODUCTION
7
Dear Customer,
Congratulations on the purchase of your new Fiat® vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality.
This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance
of your vehicle. It is supplemented by customer-oriented documents. Within this information, you will find a description of the services that FCA US LLC
offers to its customers as well as the details of the terms and conditions for maintaining its validity. Please take the time to read all of these publications
carefully before driving your vehicle for the first time. Following the instructions, recommendations, tips, and important warnings in this manual will help
ensure safe and enjoyable operation of your vehicle.
This Owner's Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated
in the text. Therefore, you should only consider the information that is related to the trim level, engine, and version that you have purchased. Any content
introduced throughout the Owner's Information, which may or may not be applicable to your vehicle, will be identified with the wording “If Equipped”.
All data contained in this publication are intended to help you use your vehicle in the best possible way. FCA US LLC aims at a constant improvement
of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For
further information, contact an authorized dealer.
When it comes to service, remember that authorized dealers know your vehicle best, have factory-trained technicians and genuine MOPAR® parts, and
care about your satisfaction.
1
Page 10
8
SYMBOLS KEY
WARNING!
CAUTION!
NOTE:
TIP:
PAGE REFERENCE
ARROW
FOOTNOTE
These statements are against operating
procedures that could result in a collision,
bodily injury and/or death.
These statements are against procedures that
could result in damage to your vehicle.
A suggestion which will improve installation,
operation, and reliability. If not followed, may
result in damage.
General ideas/solutions/suggestions on easier
use of the product or functionality.
Follow this reference for additional information
on a particular feature.
Supplementary and relevant information
pertaining to the topic.
If you do not read this entire Owner’s Manual, you may miss important
information. Observe all Cautions and Warnings.
ROLLOVER WARNING
Utility vehicles have a significantly higher rollover rate than other types of
vehicles. This vehicle has a higher ground clearance and a higher center
of gravity than many passenger vehicles. It is capable of performing better
in a wide variety of off-road applications. Driven in an unsafe manner, all
vehicles can go out of control. Because of the higher center of gravity, if
this vehicle is out of control it may roll over while some other vehicles may
not.
Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving
actions that can cause loss of vehicle control. Failure to operate this
vehicle safely may result in a collision, rollover of the vehicle, and severe
or fatal injury. Drive carefully.
Rollover Warning Label
Page 11
9
Failure to use the driver and passenger seat belts provided is a major
cause of severe or fatal injury. In fact, the U.S. government notes that the
universal use of existing seat belts could cut the highway death toll by
10,000 or more each year and could reduce disabling injuries by two
million annually. In a rollover crash, an unbelted person is significantly
more likely to die than a person wearing a seat belt. Always buckle up.
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could seriously affect its
roadworthiness and safety and may lead to a collision resulting in
serious injury or death.
SYMBOL GLOSSARY
Some car components have colored labels with symbols indicating
precautions to be observed when using this component. It is important to
follow all warnings when operating your vehicle. See below for the
definition of each symbol Ú page 67.
Red Warning Lights
Air Bag Warning Light
Ú page 74
Red Warning Lights
Brake Warning Light
Ú page 74
Battery Charge Warning Light
Ú page 75
Coolant Temperature Warning Light
Ú page 75
Door Open Warning Light
Ú page 75
Electric Power Steering (EPS) Fault Warning
Light
Ú page 75
Electronic Throttle Control (ETC) Warning Light
Ú page 75
Hood Open Warning Light — If Equipped
Ú page 76
Oil Pressure Warning Light
Ú page 76
1
Page 12
10
Red Warning Lights
Seat Belt Reminder Warning Light
Ú page 76
Transmission Fault Warning Light
Ú page 76
Trunk Open Warning Light
Ú page 76
Yellow Warning Lights
Adaptive Cruise Control Fault Warning Light — If
Equipped
Ú page 76
Anti-Lock Brake System (ABS) Warning Light
Ú page 76
Audio System Failure Light — If Equipped
Ú page 77
Electronic Park Brake Warning Light
Ú page 77
Yellow Warning Lights
Electronic Stability Control (ESC) Active Warning
Light — If Equipped
Ú page 77
Electronic Stability Control (ESC) OFF Warning
Light — If Equipped
Ú page 77
Drive Mode System Overheating
Ú page 77
Loose Fuel Filler Cap Warning Light — If
Equipped
Ú page 78
Low Fuel Warning Light
Ú page 78
LaneSense Warning Light — If Equipped
Ú page 78
Service LaneSense Warning Light — If Equipped
Ú page 78
Page 13
11
Yellow Warning Lights
Engine Check/Malfunction Indicator Warning
Light (MIL)
Ú page 78
Service Warning Light — If Equipped
Ú page 78
Service Stop/Start System Warning Light — If
Equipped
Ú page 79
Tire Pressure Monitoring System (TPMS)
Warning Light
Ú page 79
Transmission Temperature Warning Light
Ú page 80
Yellow Indicator Lights
Full Brake Control System Indicator Light — If
Equipped
Ú page 80
Full Brake Control System Off Indicator Light —
If Equipped
Ú page 80
Yellow Indicator Lights
Fuel Cutoff Failure Light — If Equipped
Ú page 80
Fuel Cutoff Indicator Light — If Equipped
Ú page 81
Fuel Level Sensor Failure
Ú page 81
Icy Road Condition Indicator Light — If Equipped
Ú page 81
Immobilizer Fail/VPS Electrical Alarm Indicator
Light
Ú page 81
Green Indicator Lights
Cruise Control Set Indicator Light
Ú page 81
Front Fog Indicator Light — If Equipped
Ú page 81
1
Page 14
12
Green Indicator Lights
Park/Headlight On Indicator Light
Ú page 81
Stop/Start Active Indicator Light — If Equipped
Ú page 81
Turn Signal Indicator Lights
Ú page 81
White Indicator Lights
Light Sensor Failure
Ú page 82
Speed Warning Indicator Light — If Equipped
Ú page 82
Blue Indicator Lights
High Beam Indicator Light
Ú page 82
Gray Indicator Lights
Cruise Control Ready/Canceled Indicator Light
Ú page 82
Page 15
GETTING TO KNOW YOUR VEHICLE
13
KEYS
KEY FOB
Your vehicle is equipped with a key fob which
supports Passive Entry, Remote Keyless Entry
(RKE), Keyless Enter-N-Go (if equipped), and
Remote Start (if equipped). The key fob allows
you to lock or unlock the doors and liftgate or
activate the Panic Alarm from distances up to
approximately 66 ft (20 m). The key fob does
not need to be pointed at the vehicle to activate
the system. The key fob also contains an
emergency key, which is stored in the rear of the
key fob.
NOTE:
The key fob’s wireless signal may be blocked if
the key fob is located next to a mobile phone,
laptop, or other electronic device. This may
result in poor performance.
Keyless Ignition Key Fob
1 — Unlock
2 — Emergency Key
3 — Lock
4 — Remote Start
5 — PANIC
In case the ignition switch does not change with
the push of a button, the key fob may have a low
or fully depleted battery. A low key fob battery
can be verified by referring to the instrument
cluster, which will display directions to follow
Ú page 319.
To Unlock/Lock The Doors And Liftgate
Push and release the unlock button on the key
fob once to unlock the driver’s door, or twice
within five seconds to unlock all the doors and
the liftgate. To lock all the doors and the liftgate,
push the lock button once.
When the doors are unlocked, the turn signals
will flash and the illuminated entry system will
be activated. When the doors are locked, the
turn signals will flash and the horn will chirp.
2
Page 16
14 GETTING TO KNOW YOUR VEHICLE
NOTE:
If the vehicle is unlocked by a key fob, and no
door is opened within 60 seconds, the vehicle
will re-lock and if equipped, the security system
will arm.
All doors can be programmed to unlock on the
first push of the unlock button within Uconnect
Settings Ú page 134.
Replacing The Battery In The Key Fob
The recommended replacement battery is one
CR2032 battery.
NOTE:
Customers are recommended to use a
battery obtained from Mopar. Aftermarket
coin battery dimensions may not meet the
original OEM coin battery dimensions.
Perchlorate Material — special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate for further information.
Do not touch the battery terminals that are
on the back housing or the printed circuit
board.
1. Remove the emergency key (2) by sliding
the emergency key release (1) on the back
of the key fob and pull the emergency key
out with your other hand.
Emergency Key Removal
1 — Emergency Key Release Button
2 — Emergency Key
2. Separate the key fob halves using a #2 flat
blade screwdriver or a coin, and gently pry
the two halves of the key fob apart. Make
sure not to damage the seal during removal.
Emergency Key Removal
Separating Case With A Coin
Page 17
GETTING TO KNOW YOUR VEHICLE 15
Key Fob Battery Replacement
3. Remove the back cover to access and
replace the battery. When replacing the
battery, match the (+) sign on the battery to
the (+) sign on the inside of the battery clip,
located on the back cover. Avoid touching
the new battery with your fingers. Skin oils
may cause battery deterioration. If you
touch a battery, clean it with rubbing
alcohol.
4. To assemble the key fob case, snap the two
halves together.
Programming And Requesting Additional Key Fobs
Programming the key fob may be performed by
an authorized dealer.
NOTE:
Once a key fob is programmed to a vehicle, it
cannot be repurposed and reprogrammed to
another vehicle.
Only key fobs that are programmed to the
vehicle electronics can be used to start and
operate the vehicle.
WARNING!
Always remove the key fobs from the
vehicle and lock all doors when leaving the
vehicle unattended.
Always remember to place the ignition in
the OFF mode.
Duplication of key fobs may be performed at an
authorized dealer. This procedure consists of
programming a blank key fob to the vehicle
electronics. A blank key fob is one that has
never been programmed.
NOTE:
When having the Sentry Key Immobilizer
system serviced, bring all vehicle keys with
you to an authorized dealer.
Keys must be ordered to the correct key cut
to match the vehicle locks.
SENTRY KEY
The Sentry Key Immobilizer system prevents
unauthorized vehicle operation by disabling the
engine. The system does not need to be armed
or activated. Operation is automatic, regardless
of whether the vehicle is locked or unlocked.
The system uses a key fob, keyless push button
ignition and a Radio Frequency (RF) receiver to
prevent unauthorized vehicle operation.
Therefore, only key fobs that are programmed
to the vehicle can be used to start and operate
the vehicle. The system will shut the engine off
in two seconds if an incorrect key fob is used to
start the engine.
2
Page 18
16 GETTING TO KNOW YOUR VEHICLE
After placing the ignition switch in the ON/RUN
position, the vehicle security light will turn on for
three seconds for a bulb check. If the light
remains on after the bulb check, it indicates
that there is a problem with the electronics. In
addition, if the light begins to flash after the
bulb check, it indicates that someone used an
invalid key fob to start the engine. Either of
these conditions will result in the engine being
shut off after two seconds.
If the vehicle security light turns on during
normal vehicle operation (vehicle running for
longer than 10 seconds), it indicates that there
is a fault in the electronics. Should this occur,
have the vehicle serviced as soon as possible by
an authorized dealer.
CAUTION!
The Sentry Key Immobilizer system is not
compatible with some aftermarket remote
starting systems. Use of these systems may
result in vehicle starting problems and loss of
security protection.
All of the key fobs provided with your new
vehicle have been programmed to the vehicle
electronics Ú page 319.
IGNITION SWITCH
KEYLESS ENTER-N-GO — IGNITION
This feature allows the driver to operate the
ignition switch with the push of a button as long
as the key fob is in the passenger compartment.
The START/STOP ignition button has three
operating modes. These modes are OFF, ON,
and RUN.
START/STOP Ignition Button
The push button ignition can be placed in the
following positions:
OFF
The engine is stopped.
No electrical devices are available.
ON
The vehicle is not running.
Some electrical devices (central locking,
alarm, etc.) are still available.
RUN
Driving mode.
All the electrical devices are available (e.g.
climate controls, heated seats, etc).
NOTE:
The vehicle will not start if the key fob is located
inside the cargo area and the liftgate is opened.
Backup Starting Method
Page 19
GETTING TO KNOW YOUR VEHICLE 17
NOTE:
If the ignition switch does not change with the
push of a button, the key fob may have a low or
depleted battery. In this situation, a back up
method can be used to operate the ignition
switch. Put the nose side (side opposite of the
emergency key) of the key fob against the
START/STOP ignition button and push to
operate the ignition switch.
WARNING!
When leaving the vehicle, always remove
the key fob from the vehicle and lock your
vehicle.
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
Allowing children to be in a vehicle unat-
tended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the gear selector.
(Continued)
WARNING! (Continued)
Do not leave the key fob in or near the
vehicle, or in a location accessible to children, and do not leave the ignition in the ON
or RUN mode. A child could operate power
windows, other controls, or move the
vehicle.
Do not leave children or animals inside
parked vehicles in hot weather. Interior
heat build-up may cause serious injury or
death.
CAUTION!
An unlocked vehicle is an invitation for
thieves. Always remove key fob from the
vehicle and lock all doors when leaving the
vehicle unattended.
NOTE:
For more information on proper engine starting
procedures, see Ú page 85.
REMOTE START — IF EQUIPPED
This system uses the key fob to start
the engine conveniently from outside
the vehicle while still maintaining
security. The system has a range of
approximately 328 ft (100 m).
Remote start is used to defrost windows in cold
weather, and to reach a comfortable climate in
all ambient conditions before the driver enters
the vehicle.
NOTE:
Obstructions between the vehicle and key fob
may reduce this range.
WARNING!
Do not start or run an engine in a closed
garage or confined area. Exhaust gas
contains Carbon Monoxide (CO) which is
odorless and colorless. Carbon Monoxide is
poisonous and can cause serious injury or
death when inhaled.
Keep key fobs away from children. Opera-
tion of the Remote Start system, windows,
door locks or other controls could cause
serious injury or death.
2
Page 20
18 GETTING TO KNOW YOUR VEHICLE
HOW TO USE REMOTE S TART
Push and release the Remote Start button on
the key fob twice within five seconds. The
vehicle doors will lock, the parking lights will
flash, and the horn will chirp twice (if
programmed). Then, the engine will start, and
the vehicle will remain in the Remote Start
mode for a 15 minute cycle. Pushing the remote
start button a third time shuts the engine off.
With Remote Start, the engine will only run
for 15 minutes.
If an engine fault is present or fuel level is
low, the vehicle will start and then shut down
in 10 seconds.
The park lamps will turn on and remain on
during Remote Start mode.
For security, power window and power
sunroof operation (if equipped) are disabled
when the vehicle is in the Remote Start
mode.
The ignition must be placed in the ON/RUN
position before the Remote Start sequence
can be repeated for a third cycle.
All of the following conditions must be met
before the engine will remote start:
Gear Selector in PARK
Doors closed
Hood closed
Liftgate closed
Hazard switch off
Brake switch inactive (brake pedal not
pushed)
Battery at an acceptable charge level
PANIC button not pushed
System not disabled from previous remote
start event
Vehicle Security system indicator flashing
Ignition in OFF position
Fuel level meets minimum requirement
Vehicle Security system is not signaling an
intrusion
Malfunction Indicator Light is not illuminated
WARNING!
Do not start or run an engine in a closed
garage or confined area. Exhaust gas
contains Carbon Monoxide (CO) which is
odorless and colorless. Carbon Monoxide is
poisonous and can cause serious injury or
death when inhaled.
Keep key fobs away from children. Opera-
tion of the Remote Start System, windows,
door locks or other controls could cause
serious injury or death.
TO EXIT REMOTE START MODE
To drive the vehicle after starting the Remote
Start system, push and release the START/
STOP ignition button while pressing the brake
pedal prior to the end of the 15 minute cycle.
The Remote Start system will turn the engine off
with another push and release of the remote
start button on the key fob, or if the engine is
allowed to run for the entire 15 minute cycle.
Once the ignition is placed in the ON/RUN
position, the climate controls will resume the
previously set operations (temperature, blower
control, etc.).
Page 21
GETTING TO KNOW YOUR VEHICLE 19
NOTE:
For vehicles equipped with the Keyless
Enter-N-Go — Passive Entry feature, the
message “Remote Start Active — Push Start
Button” will display in the instrument cluster
display until you push the START/STOP ignition button.
To avoid unintentional shutdowns, the
system will disable for two seconds after
receiving a valid remote start request.
REMOTE START FRONT DEFROST
CTIVATION — IF EQUIPPED
A
When remote start is active, and the outside
ambient temperature is 40°F (4.5°C) or below,
the system will automatically activate front
defrost for 15 minutes or less. The time is
dependent on the ambient temperature. Once
the timer expires, the system will automatically
adjust the settings depending on ambient
conditions. See “Remote Start Comfort Systems
— If Equipped” in the next section for detailed
operation.
REMOTE START COMFORT SYSTEMS —
F EQUIPPED
I
When remote start is activated, the front and
rear defrost will automatically turn on in cold
weather. The heated steering wheel and driver
heated seat feature will turn on if selected in
the comfort menu screen within Uconnect
Settings Ú page 134. In warm weather, the
driver vented seat feature will automatically
turn on when the remote start is activated and
is selected in the comfort menu screen. The
vehicle will adjust the climate control settings
depending on the outside ambient
temperature.
Automatic Temperature Control (ATC) — If
Equipped
The climate controls will be automatically
adjusted to the optimal temperature and mode
settings depending on the outside ambient
temperature. This will occur until the ignition is
placed in the ON/RUN position where the
climate controls will resume their previous
settings.
Manual Temperature Control (MTC) — If
Equipped
In ambient temperatures at 40°F (4.5°C) or
below, the climate settings will default to
maximum heat, with fresh air entering the
cabin. If the front defrost timer expires, the
vehicle will enter Mix Mode.
In ambient temperatures from 40°F (4.5°C)
to 78°F (26°C), the climate settings will be
based on the last settings selected by the
driver.
In ambient temperatures at 78°F (26°C) or
above, the climate settings will default to
MAX A/C, Bi-Level Mode, with Recirculation
on.
For more information on ATC, MTC, and climate
control settings, see Ú page 45.
NOTE:
These features will stay on through the duration
of remote start until the ignition is placed in the
ON/RUN position. The climate control settings
will change if manually adjusted by the driver
while the vehicle is in remote start mode, and
exit automatic override. This includes the OFF
button on the climate controls, which will turn
the system off.
2
Page 22
20 GETTING TO KNOW YOUR VEHICLE
REMOTE START W INDSHIELD WIPER
E–ICER AND R EAR DEFROST
D
CTIVATION — IF EQUIPPED
A
When remote start is active and the outside
ambient temperature is less than 40°F (4.4°C),
the Windshield Wiper De-Icer and the Rear
Defrost will be enabled. Exiting remote start will
resume its previous operation. If the Windshield
Wiper De-Icer was active, the timer and
operation will continue.
REMOTE START CANCEL MESSAGE — IF
QUIPPED
E
The following messages will display in the
instrument cluster if the vehicle fails to remote
start or exits remote start prematurely:
Remote Start Cancelled — Door Open
Remote Start Cancelled — Hood Open
Remote Start Cancelled — Fuel Low
Remote Start Cancelled — Liftgate Open
Remote Start Cancelled — Too Cold
Remote Start Cancelled — Time Expired
Remote Start Disabled — Start Vehicle To
Reset
The message will stay active until the ignition is
placed in the ON/RUN position.
VEHICLE SECURITY SYSTEM — IF EQUIPPED
The Vehicle Security system monitors the
vehicle doors, hood, liftgate, and the Keyless
Enter-N-Go — Ignition for unauthorized
operation. While the Vehicle Security system is
armed, interior switches for door locks and
liftgate release are disabled. If something
triggers the alarm, the Vehicle Security system
will provide the following audible and visible
signals:
The horn will pulse
The turn signals will flash
The Vehicle Security Light in the instrument
cluster will flash
TO ARM THE SYSTEM
Follow these steps to arm the Vehicle Security
system:
1. Make sure the vehicle’s ignition is placed
in the OFF position.
2. Perform one of the following methods to
lock the vehicle:
Push the lock button on the interior
power door lock switch with the driver
and/or passenger door open.
Push the lock button on the exterior
Passive Entry Door Handle with a valid
key fob available in the same exterior
zone Ú page 22.
Push the lock button on the key fob.
3. If any doors are open, close them.
TO DISARM THE SYSTEM
The Vehicle Security system can be disarmed
using any of the following methods:
Push the unlock button on the key fob.
Grab the Passive Entry door handle to unlock
the door Ú page 22.
Cycle the ignition out of the OFF position to
disarm the system.
Page 23
GETTING TO KNOW YOUR VEHICLE 21
NOTE:
The driver's door key cylinder cannot arm or
disarm the Vehicle Security system.
The Vehicle Security system remains armed
during liftgate entry. If someone enters the
vehicle through the liftgate and opens any
door, the alarm will sound.
When the Vehicle Security system is armed,
the interior power door lock switches will not
unlock the doors.
The Vehicle Security system is designed to
protect your vehicle. However, you can create
conditions where the system will give you a false
alarm. If one of the previously described arming
sequences has occurred, the Vehicle Security
system will arm, regardless of whether you are
in the vehicle or not. If you remain in the vehicle
and open a door, the alarm will sound. If this
occurs, disarm the Vehicle Security system.
If the Vehicle Security system is armed and the
battery becomes disconnected, the Vehicle
Security system will remain armed when the
battery is reconnected; the exterior lights will
flash, and the horn will sound. If this occurs,
disarm the Vehicle Security system.
DISABLING
To completely disable the alarm (e.g. in the case
of long inactivity of the car), lock the doors by
turning the emergency key in the exterior door
lock cylinder.
NOTE:
If the batteries in the key fob discharge in the
event of a failure to the system or to switch off
the alarm, place the ignition in the ON/RUN
position.
DOORS
MANUAL DOOR LOCKS
To lock each door from the inside, rotate the
door lock button on each door trim panel
forward. To unlock the doors from the inside,
pull the inside door handle to the first detent or
rotate the door lock button until the lock symbol
is no longer visible.
If the lock symbol is visible when the door is
shut, the door will lock. Therefore, make sure
the key fob is not inside the vehicle before
closing the door.
2
Manual Lock/Unlock Switch
1 — Door Unlocked
2 — Door Locked
NOTE:
The manual lock knob unlocks each individual
door separately.
WARNING!
When exiting the vehicle, always remove
the key fob from the vehicle and lock your
vehicle.
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
(Continued)
Page 24
22 GETTING TO KNOW YOUR VEHICLE
WARNING! (Continued)
Allowing children to be in a vehicle unat-
tended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the gear selector.
Do not leave the key fob in or near the
vehicle, or in a location accessible to children, and do not leave the ignition of a
vehicle equipped with Keyless Enter-N-Go
in the ON/RUN mode. A child could operate
power windows, other controls, or move the
vehicle.
Do not leave children or animals inside
parked vehicles in hot weather. Interior heat
build-up may cause serious injury or death.
CAUTION!
An unlocked car is an invitation. Always
remove the key from the ignition and lock all
doors when leaving the vehicle unattended.
POWER DOOR L OCKS
The power door lock switches are located on
each front door panel. Push the switch to lock or
unlock the doors and liftgate.
Push the lock button on the driver or passenger
door trim panel to lock the doors.
With the doors locked, push the unlock button
to unlock the doors.
Power Lock/Unlock Switch
The doors can also be locked and unlocked with
the Keyless Enter-N-Go (Passive Entry) system if
equipped Ú page 22.
KEYLESS ENTER-N-GO
The Passive Entry system is an enhancement to
the vehicle’s Remote Keyless Entry system and
a feature of Keyless Enter-N-Go. This feature
allows you to lock and unlock the vehicle’s
door(s) without having to push the key fob lock
or unlock buttons.
NOTE:
Passive Entry may be programmed on/off
through Uconnect Settings Ú page 134.
The key fob may not be detected by the
vehicle Passive Entry system if it is located
next to a mobile phone, laptop, or other electronic device; these devices may interfere
with the key fob’s wireless signal and prevent
the Passive Entry system from locking and
unlocking the vehicle.
If wearing gloves, or if it has been raining/
snowing on the Passive Entry door handle,
the unlock sensitivity can be affected,
resulting in a slower response time.
If the vehicle is unlocked by the Passive Entry
door handle, and no door goes ajar within
60 seconds, the vehicle will re-lock and if
equipped, the Vehicle Security system will
arm.
Page 25
GETTING TO KNOW YOUR VEHICLE 23
To Unlock From The Driver Or Passenger Side
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the door handle, grab the handle to
unlock the vehicle. Grabbing the driver’s door
handle will unlock the driver door automatically.
Grabbing the passenger door handle will unlock
all doors and the liftgate automatically.
Grab The Door Handle To Unlock
NOTE:
Either the driver door only or all doors will
unlock when you grab hold of the front
driver’s door handle, depending on the
selected setting in the Uconnect system
Ú page 134.
All doors will unlock when the front
passenger door handle is grabbed regardless
of the driver’s door unlock preference
setting.
Frequency Operated Button Integrated Key
(FOBIK-Safe)
To minimize the possibility of unintentionally
locking a Passive Entry key fob inside your
vehicle, the Passive Entry system is equipped
with an automatic door unlock feature.
FOBIK-Safe only executes in vehicles with
Passive Entry. There are three situations that
trigger a FOBIK-Safe search in any Passive Entry
vehicle:
A lock request is made by a valid Passive
Entry key fob while a door is ajar.
A lock request is made by the Passive Entry
door handle while a door is ajar.
A lock request is made by the door panel
switch while the door is ajar.
When any of these situations occur, after all ajar
doors are shut, the FOBIK-Safe search will be
executed. If it finds a Passive Entry key fob
inside the car, and it does not find any Passive
Entry key fobs outside the car, then the car will
unlock and alert the customer.
NOTE:
The vehicle will only unlock the doors when a
valid Passive Entry key fob is detected inside
the vehicle, and no valid Passive Entry key fob is
detected outside the vehicle. The vehicle will
not unlock the doors when any of the following
conditions are met:
The doors are manually locked using the door
lock knobs.
There is a valid Passive Entry key fob outside
the vehicle and within 5 ft (1.5 m) of either
Passive Entry door handle.
To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s Passive Entry key fobs
within 5 ft (1.5 m) of either front door handles,
pushing the Passive Entry lock button will lock
the vehicle.
2
Page 26
24 GETTING TO KNOW YOUR VEHICLE
Push The Door Handle Button To Lock
NOTE:
DO NOT grab the door handle, when pushing the
door handle lock button. This could unlock the
door(s).
DO NOT Grab The Door Handle When Locking
NOTE:
After pushing the door handle button, you
must wait two seconds before you can lock or
unlock the doors, using any Passive Entry
door handle. This is to allow you to check if
the vehicle is locked by pulling the door
handle without the vehicle unlocking.
The Passive Entry system will not operate if
the key fob battery is depleted.
The vehicle doors can also be locked by using
the lock button located on the vehicle’s interior
door panel.
To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built
into the electronic liftgate release. With a valid
Passive Entry key fob within 3 ft (1.0 m) of the
liftgate, push the electronic liftgate release to
open.
Electronic Liftgate Release
NOTE:
The liftgate will either unlock along with the
vehicle doors, or it will need to be unlocked by
pushing the electronic liftgate release,
depending on the selected setting in the
Uconnect system Ú page 134.
Page 27
GETTING TO KNOW YOUR VEHICLE 25
To Lock The Liftgate
With a valid Passive Entry key fob within 3 ft
(1.0 m) of the liftgate, push the Passive Entry
lock button located to the right of electronic
liftgate release.
Liftgate Passive Entry Lock Button
NOTE:
The liftgate Passive Entry lock button will lock all
doors and the liftgate.
Activation/Deactivation Of Keyless Enter-N-Go
Keyless Enter-N-Go can be activated or
deactivated through the instrument cluster
display or through the Uconnect system
Ú page 319.
AUTOMATIC DOOR LOCKS — IF
QUIPPED
E
When the auto door lock feature is enabled, if
all of the doors are closed properly, the door
locks will lock automatically when the vehicle's
speed exceeds 12 mph (20 km/h). The auto
door lock feature is enabled/disabled within
Uconnect Settings Ú page 134.
CHILD -PROTECTION DOOR LOCK
YSTEM — R EAR DOORS
S
To provide a safer environment for small
children riding in the rear seats, the rear doors
are equipped with a Child-Protection Door Lock
system.
To use the system, open each rear door, use a
flat blade screwdriver (or emergency key) and
rotate the dial to the lock or unlock position.
When the system on a door is engaged, that
door can only be opened by using the outside
door handle even if the inside door lock is in the
unlocked position.
2
Child-Protection Door Lock Location
NOTE:
When the Child-Protection Door Lock system
is engaged, the door can only be opened by
using the outside door handle even though
the inside door lock is in the unlocked position.
After disengaging the Child-Protection Door
Lock system, always test the door from the
inside to make certain it is in the unlocked
position.
After engaging the Child-Protection Door Lock
system, always test the door from the inside
to make certain it is in the locked position.
Page 28
26 GETTING TO KNOW YOUR VEHICLE
For emergency exit with the system engaged,
rotate the lock button to the unlocked position, roll down the window, and open the door
with the outside door handle.
WARNING!
Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only
be opened from the outside when the
Child-Protection locks are engaged.
NOTE:
Always use this device when carrying children.
After engaging the child lock on both rear doors,
check for effective engagement by trying to
open a door with the internal handle. Once the
Child-Protection Door Lock system is engaged,
it is impossible to open the doors from inside
the vehicle. Before getting out of the vehicle, be
sure to check that there is no one left inside.
STEERING WHEEL
MANUAL TILT/TELESCOPING STEERING
OLUMN
C
This feature allows you to tilt the steering
column upward or downward. It also allows you
to lengthen or shorten the steering column. The
tilt/telescoping lever is located below the
steering wheel at the end of the steering
column.
Tilt/Telescoping Lever
To unlock the steering column, push the tilt/
telescoping lever downward (toward the floor).
To tilt the steering column, move the steering
wheel upward or downward as desired. To
lengthen or shorten the steering column, pull
the steering wheel outward or push it inward as
desired.
To lock the steering column in position, pull the
tilt/telescoping lever upward until fully
engaged.
WARNING!
Do not adjust the steering column while
driving. Adjusting the steering column while
driving or driving with the steering column
unlocked, could cause the driver to lose
control of the vehicle. Failure to follow this
warning may result in serious injury or death.
HEATED STEERING WHEEL — IF EQUIPPED
The steering wheel contains a heating element
that helps warm your hands in cold weather.
The heated steering wheel has only one
temperature setting. Once the heated steering
wheel switch has been turned on, it will
operate for an average of 80 minutes or more
before automatically shutting off. This time may
vary depending on the environmental
temperature. The heated steering wheel can
shut off early or may not turn on when the
steering wheel is already warm. The heated
steering wheel control button is located on the
center of the instrument panel below the
climate controls.
For information on use with the Remote Start
system, see Ú page 19.
Page 29
GETTING TO KNOW YOUR VEHICLE 27
WARNING!
Persons who are unable to feel pain to the
skin because of advanced age, chronic
illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when
using the steering wheel heater. It may
cause burns even at low temperatures,
especially if used for long periods.
Do not place anything on the steering wheel
that insulates against heat, such as a
blanket or steering wheel covers of any type
and material. This may cause the steering
wheel heater to overheat.
SEATS
Seats are a part of the Occupant Restraint
System of the vehicle.
WARNING!
It is dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely
to be seriously injured or killed.
(Continued)
WARNING! (Continued)
Do not allow people to ride in any area of
your vehicle that is not equipped with seats
and seat belts. In a collision, people riding
in these areas are more likely to be seriously injured or killed.
Be sure everyone in your vehicle is in a seat
and using a seat belt properly.
MANUAL ADJUSTMENT (FRONT SEATS)
WARNING!
Adjusting a seat while the vehicle is moving
is dangerous. The sudden movement of the
seat could cause you to lose control. The
seat belt might not be adjusted properly
and you could be injured. Adjust the seat
only while the vehicle is parked.
Do not ride with the seatback reclined so
that the shoulder belt is no longer resting
against your chest. In a collision you could
slide under the seat belt and be seriously or
even fatally injured. Use the recliner only
when the vehicle is parked.
Manual Front Seat Forward/Rearward Adjustment
Some models may be equipped with manual
seats. The seat can be adjusted forward or
rearward by using a bar located by the front of
the seat cushion, near the floor.
Manual Seat Adjustment Levers
1 — Forward/Rearward Adjustment Bar
2 — Seat Height Adjustment Lever (If Equipped)
3 — Recline Lever
While sitting in the seat, lift up on the bar
located under the seat cushion and move the
seat forward or rearward. Release the bar once
you have reached the desired position. Then,
2
Page 30
28 GETTING TO KNOW YOUR VEHICLE
using body pressure, move forward and
rearward on the seat to be sure that the seat
adjusters have latched.
WARNING!
Adjusting a seat while driving may be
dangerous. Moving a seat while driving could
result in loss of control which could cause a
collision and serious injury or death.
Seats should be adjusted before fastening
the seat belts and while the vehicle is
parked. Serious injury or death could result
from a poorly adjusted seat belt.
Height Adjustment — If Equipped
The front driver and passenger seats height can
be raised or lowered by using a lever, located on
the outboard side of the seat. Pull upward on
the lever to raise the seat height or push
downward on the lever to lower the seat height.
Recline Adjustment
To adjust the seatback, lift the lever located on
the outboard side of the seat, lean back to the
desired position and release the lever. To return
the seatback, lift the lever, lean forward and
release the lever.
MANUAL ADJUSTMENT (REAR SEATS )
WARNING!
Do not pile luggage or cargo higher than the
top of the seatback. This could impair
visibility or become a dangerous projectile in
a sudden stop or collision.
Manual Folding Second Row Seat
The manual folding split rear seat increases the
storage of the rear cargo area.
NOTE:
Prior to folding the rear seat down, it may be
necessary to position the front seat to its
mid-track position. Be sure that the front
seats are fully upright and positioned
forward, this will allow the rear seat to fold
down easily.
You may experience deformation in the seat
cushion from the seat belt buckles if the
seats are left folded for an extended period
of time. This is normal and by simply opening
the seats to the open position, over time the
seat cushion will return to its normal shape.
WARNING!
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are
more likely to be seriously injured or killed.
Do not allow people to ride in any area of
your vehicle that is not equipped with seats
and seat belts.
Be sure everyone in your vehicle is in a seat
and using a seat belt properly.
Cargo Area Enlargement
Folding both sides of the rear seat provides
additional storage in the rear cargo area.
Proceed as follows:
1. Remove the rear shelf (if equipped).
2. Fully lower the rear seat head restraints.
3. Move the safety belts to the outboard side
of the seat.
4. Pull the seatback release lever to fold both
sides of the rear seatbacks completely
forward.
Page 31
Partial Enlargement Of The Cargo Area
Enlargement of the left side of the cargo area
allows you to carry a single passenger on the
right side of the rear seat, while the
enlargement of the right side allows you to carry
two passengers.
Proceed as follows:
1. Remove the rear shelf (if equipped).
2. Fully lower the rear seat head restraints.
3. Move the safety belts to the outboard side
of the seat and rest them on the seat belt
guide.
4. Pull the seatback release lever to fold the
left or right rear seatback completely
forward.
Seatback Release Lever
Seatback Repositioning
NOTE:
If interference from the cargo area prevents the
seatback from fully locking, you will have difficulty returning the seat to its proper position.
1. Move the safety belts to the seat belt
guides on the top edge of the seat to
ensure the seatbacks properly latch.
2. Lift the seatbacks, pushing them back until
they lock on both the latches. Verify the red
notches are no longer visible on the release
lever. If the red notches are visible, the
seatback is not secure.
GETTING TO KNOW YOUR VEHICLE 29
2
Rear Seat Latch
WARNING!
Be certain that the seatback is securely
locked into position. If the seatback is not
securely locked into position the seat will not
provide the proper stability for child seats
and/or passengers. An improperly latched
seat could cause serious injury.
Page 32
30 GETTING TO KNOW YOUR VEHICLE
POWER ADJUSTMENT FRONT SEATS —
F EQUIPPED
I
The power seat switches are located on the
outboard side of the seat.
Use the switch to move the seat up/down,
forward/rearward, tilt if equipped and to set the
angle of the seatback.
Power Seat Switches
1 — Power Seat Switch
2 — Power Recline Switch
3 — Power Lumbar Switch
Adjusting The Seat Forward Or Rearward
The seat can be adjusted both forward and
rearward by using the power seat switch. The
seat will move in the direction of the switch.
Release the switch when the desired position
has been reached.
Adjusting The Seat Up Or Down
The height of the seats can be adjusted up or
down by using the power seat switch. The seat
will move in the direction of the switch. Release
the switch when the desired position is reached.
Tilting The Seat Up Or Down
The angle of the seat cushion can be adjusted
up or down using the power seat switch. The
front of the seat cushion will move in the
direction of the switch. Release the switch when
the desired position has been reached.
Reclining The Seatback
Push the seat recliner switch forward or
rearward. The seatback will move in the
direction of the switch. Release the switch when
the desired position has been reached.
WARNING!
Adjusting a seat while driving may be
dangerous. Moving a seat while driving
could result in loss of control which could
cause a collision and serious injury or
death.
Seats should be adjusted before fastening
the seat belts and while the vehicle is
parked. Serious injury or death could result
from a poorly adjusted seat belt.
Do not ride with the seatback reclined so
that the shoulder belt is no longer resting
against your chest. In a collision you could
slide under the seat belt, which could result
in serious injury or death.
CAUTION!
Do not place any article under a power seat
or impede its ability to move as it may cause
damage to the seat controls. Seat travel may
become limited if movement is stopped by an
obstruction in the seat’s path.
Page 33
GETTING TO KNOW YOUR VEHICLE 31
Power Lumbar — If Equipped
Vehicles equipped with power driver or
passenger seats may also be equipped with
power lumbar. The power lumbar switch is
located on the outboard side of the power seat.
Push the switch forward to increase the lumbar
support. Push the switch rearward to decrease
the lumbar support. Pushing upward or
downward on the switch will raise and lower the
position of the support.
NOTE:
The power lumbar adjustment knob can only be
used when the ignition is in the ON/RUN position and for 20 minutes after the ignition is
placed in the OFF position. The device will automatically be deactivated when the ignition is in
the OFF position if the vehicle is locked from the
outside.
HEATED SEATS — IF EQUIPPED
The heated seat switches are located on the
instrument panel.
You can choose between two heating levels:
Push the heated seat button once to turn
the HI setting on.
Push the heated seat button a second
time to turn the LO setting on.
Push the heated seat button a third time
to turn the heating elements off.
If the HI-level setting is selected, the system will
automatically switch to LO-level after
approximately 145 minutes of continuous
operation. At that time, the display will change
from HI to LO, indicating the change. The
LO-level setting will turn off automatically after
approximately 60 minutes.
NOTE:
The engine must be running for the heated
seats to operate.
For information on use with the Remote Start
system, see Ú page 19.
WARNING!
Persons who are unable to feel pain to the
skin because of advanced age, chronic
illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when
using the seat heater. It may cause burns
even at low temperatures, especially if
used for long periods of time.
Do not place anything on the seat or seat-
back that insulates against heat, such as a
blanket or cushion. This may cause the seat
heater to overheat. Sitting in a seat that has
been overheated could cause serious
burns due to the increased surface
temperature of the seat.
HEAD RESTRAINTS
Head restraints are designed to reduce the risk
of injury by restricting head movement in the
event of a rear impact. Head restraints should
be adjusted so that the top of the head restraint
is located above the top of your ear.
2
Page 34
32 GETTING TO KNOW YOUR VEHICLE
WARNING!
All occupants, including the driver, should
not operate a vehicle or sit in a vehicle’s
seat until the head restraints are placed in
their proper positions in order to minimize
the risk of neck injury in the event of a
crash.
Head restraints should never be adjusted
while the vehicle is in motion. Driving a
vehicle with the head restraints improperly
adjusted or removed could cause serious
injury or death in the event of a collision.
Front Adjustment
Your vehicle is equipped with driver and
passenger head restraints.
To raise the head restraint, pull upward on the
head restraint. To lower the head restraint,
push the adjustment button, located on the
base of the head restraint, and push downward
on the head restraint.
Front Head Restraint
1 — Adjustment Button
2 — Release Button
Rear Adjustment
Your vehicle is equipped with two outboard
head restraints and one center head restraint
for its rear passengers. The rear head restraints
can be raised or lowered. When the center seat
is being occupied, the head restraint should be
in the raised position. When there are no
occupants in the center seat, the head restraint
can be lowered for maximum visibility for the
driver.
To raise the head restraint, pull upward on the
head restraint. To lower the head restraint,
push the adjustment button, located at the
base of the head restraint, and push downward
on the head restraint.
Rear Head Restraint
1 — Adjustment Button
2 — Release Button
Page 35
GETTING TO KNOW YOUR VEHICLE 33
Front Removal
To remove the head restraint recline the
backrest of the seat to avoid interference with
the roof. Raise the head restraint as far as it can
go then push the release button and
adjustment button at the base of each post
while pulling the head restraint up. To reinstall
the head restraint, put the head restraint posts
into the holes and push downward. Then adjust
it to the appropriate height.
NOTE:
Do not reposition the head restraint 180 degrees
to the incorrect position in an attempt to gain
additional clearance to the back of the head.
WARNING!
A loose head restraint thrown forward in a
collision or hard stop could cause serious
injury or death to occupants of the vehicle.
Always securely stow removed head
restraints in a location outside the occupant compartment.
(Continued)
WARNING! (Continued)
ALL the head restraints MUST be rein-
stalled in the vehicle to properly protect the
occupants. Follow the re-installation
instructions above prior to operating the
vehicle or occupying a seat.
Rear Removal
To remove the head restraint, raise it as far as it
can go then push the release button and
adjustment button at the base of each post
while pulling the head restraint up. To reinstall
the head restraint, put the head restraint posts
into the holes and push downward. Then adjust
it to the appropriate height.
NOTE:
Do not reposition the head restraint 180 degrees
to the incorrect position in an attempt to gain
additional clearance to the back of the head.
WARNING!
A loose head restraint thrown forward in a
collision or hard stop could cause serious
injury or death to occupants of the vehicle.
Always securely stow removed head
restraints in a location outside the occupant compartment.
ALL the head restraints MUST be rein-
stalled in the vehicle to properly protect the
occupants. Follow the re-installation
instructions above prior to operating the
vehicle or occupying a seat.
UCONNECT VOICE RECOGNITION
INTRODUCING VOICE RECOGNITION
Start using Uconnect Voice Recognition with
these helpful quick tips. It provides the key
Voice Commands and tips you need to know to
control your vehicle’s Voice Recognition (VR)
system.
2
Page 36
34 GETTING TO KNOW YOUR VEHICLE
Uconnect 4/4 NAV With 7-inch Display
GET STARTED
The VR button is used to activate /deactivate
your Voice Recognition system.
Helpful hints for using Voice Recognition:
Reduce background noise. Wind noise and
passenger conversations are examples of
noise that may impact recognition.
Speak clearly at a normal pace and volume
while facing straight ahead.
Each time you give a Voice Command, first
push the VR button, wait until after the beep,
then say your Voice Command.
You can interrupt the help message or
system prompts by pushing the VR button
and saying a Voice Command from the
current category.
Uconnect Voice Command Buttons
1 — Push To Start Or Answer A Phone Call And
Send Or Receive A Text
2 — Push The Voice Recognition Button To Begin
Radio, Media, And Climate Functions
BASIC VOICE COMMANDS
The basic Voice Commands below can be given
at any point while using your Uconnect system.
Push the VR button . After the beep, say:
“Cancel” to stop a current voice session.
“Help” to hear a list of suggested Voice
Commands.
“Repeat” to listen to the system prompts
again.
Notice the visual cues that inform you of your
Voice Recognition system’s status.
ADDITIONAL INFORMATION
© 2020 FCA US LLC. All rights reserved. Mopar
and Uconnect are registered trademarks and
Mopar Owner Connect is a trademark of FCA US
LLC. Android™ is a trademark of Google Inc.
SiriusXM® and all related marks and logos are
trademarks of SiriusXM® Radio Inc.
Ú page 319.
For Uconnect system support, call
1-877-855-8400 (24 hours a day 7 days a
week) or visit DriveUconnect.com (US) or
DriveUconnect.ca (Canada).
Page 37
GETTING TO KNOW YOUR VEHICLE 35
MIRRORS
INSIDE REARVIEW MIRROR
Manual Mirror — If Equipped
The mirror can be adjusted up, down, left, and
right. The mirror should be adjusted to center
on the view through the rear window. Headlight
glare from vehicles behind you can be reduced
by moving the lever under the mirror to the night
position (toward the rear of the vehicle). The
mirror should be adjusted while the lever under
the mirror is set in the day position (toward the
windshield).
Mirror Lever
Automatic Dimming Mirror — If Equipped
This mirror automatically adjusts for headlight
glare from vehicles behind you. You can turn the
feature on or off by pushing the button at the
base of the mirror. A light to the left of the
button will illuminate to indicate when the
dimming feature is activated. The sensor to the
right of the button does not illuminate.
Automatic Dimming Button
NOTE:
This feature is disabled when the vehicle is
moving in reverse.
ILLUMINATED VANITY MIRRORS — IF
QUIPPED
E
An illuminated vanity mirror is located on each
sun visor. To use the mirror, rotate the sun visor
down and swing the mirror cover upward. The
lights will turn on automatically. Closing the
mirror cover will turn the light off.
Vanity Mirror Light
OUTSIDE MIRRORS
The outside mirror(s) can be adjusted to the
center of the adjacent lane of traffic to achieve
the optimal view.
2
Page 38
36 GETTING TO KNOW YOUR VEHICLE
WARNING!
Vehicles and other objects seen in an outside
convex mirror will look smaller and farther
away than they really are. Relying too much
on side convex mirrors could cause you to
collide with another vehicle or other object.
Use your inside mirror when judging the size
or distance of a vehicle seen in a side convex
mirror.
POWER MIRRORS
The power mirror switch is located on the
driver’s door trim panel.
To adjust the mirror, rotate the mirror selection
switch to the left or to the right and then push
the mirror adjustment switch in the four
directions indicated by arrows.
NOTE:
To adjust the power mirrors, the ignition must
be in the ON/RUN position.
Once the mirror is adjusted, rotate the
control to the neutral position to avoid accidental movements.
The power mirror switches will remain active
for up to three minutes after the ignition is
placed in the OFF position. Opening either
front door will cancel this feature.
Power Mirror Switch
1 — Mirror Selector Switch
2 — Mirror Adjustment Switch
FOLDING MIRROR
The exterior mirrors are hinged to allow the
mirror to pivot forward or rearward to help avoid
damage. The mirror has three detent positions:
full forward, normal and full rearward.
Folding Exterior Mirror
POWER FOLDING MIRRORS — I F
QUIPPED
E
If equipped, the outside mirrors can be folded
using the power folding mirror switch, located
on the driver’s door trim panel. The power
mirror switch will operate with the ignition in the
ON/RUN position, and for three minutes after
the ignition is placed in the OFF position. This
feature will disable if either front door is
opened.
Page 39
GETTING TO KNOW YOUR VEHICLE 37
NOTE:
The Automatic Fold/Unfold Mirrors feature can
be turned on and off using the Uconnect system
Ú page 134.
Power Folding Mirror Switch
1 — Mirror Selector Switch
2 — Mirror Adjustment Switch
3 — Power Folding Mirror Switch
To fold the outside mirrors, push the power
folding mirror switch. Push the switch a second
time to unfold the mirrors to the driving position.
Any push of the power folding mirror switch will
reverse the operation.
Power Folding Mirrors
NOTE:
The outside mirrors must always be in the
unfolded position when the vehicle is in motion,
except when driving through narrow locations.
Automatic Power Folding Mirrors
When the Automatic Fold Mirrors feature is
enabled, the exterior mirrors will fold in when
exiting the vehicle (the ignition is OFF, all doors
are closed, and the doors are locked).
If the exterior mirrors were auto-folded, they
will unfold when the ignition is placed in the
ON position or when the doors are unlocked.
If the exterior mirrors were manually folded,
they will not automatically unfold.
HEATED MIRRORS — I F EQUIPPED
These mirrors are heated to melt frost
or ice. This feature will be activated
whenever you turn on the rear window
defroster (if equipped) Ú page 45.
EXTERIOR LIGHTS
HEADLIGHT SWITCH
The headlight switch is located on the left side
of the instrument panel. The headlight switch
controls the operation of the headlights,
parking lights, daytime running lights, fog lights
and the dimming of the instrument cluster and
interior lighting.
2
Page 40
38 GETTING TO KNOW YOUR VEHICLE
Headlight Switch
1 — Rotate Headlight Control
2 — Ambient Lighting Control
3 — Instrument Panel Dimmer Control
4 — Front Fog Light Switch
Turning on the headlights will illuminate the
instrument cluster and the controls located on
the instrument panel.
NOTE:
On vehicles sold in Canada, both the rear position lights and Daytime Running Lights (DRLs)
will turn on when the headlight switch is rotated
to the “Off” (“O”) position.
DAYTIME RUNNING LIGHTS (DRL S) — IF
QUIPPED
E
The Daytime Running Lights (DRLs), if enabled
through Uconnect settings, will turn on when
the ignition is placed in the ON/RUN position
and the park brake is not applied.
NOTE:
For vehicles sold in Canada, the Daytime
Running Lights will automatically deactivate
when the front fog lights are turned on.
On some vehicles, the Daytime Running
Lights may deactivate, or reduce intensity, on
one side of the vehicle (when a turn signal is
activated on that side), or on both sides of
the vehicle (when the hazard warning lights
are activated).
HIGH BEAMS
To activate the high beam headlights, push the
multifunction lever forward (toward the front of
the vehicle), and an indicator will illuminate in
the instrument cluster display.
To deactivate the high beam headlights, pull the
multifunction lever rearward (toward the rear of
the vehicle).
High Beam And Turn Signal Controls
NOTE:
The headlights must be on for the high beams
to activate.
FLASH -TO -PASS
You can signal another vehicle with your
headlights by lightly pulling the multifunction
lever toward you. This will cause the high beam
headlights to turn on, and remain on, until the
lever is released.
Page 41
GETTING TO KNOW YOUR VEHICLE 39
AUTOMATIC HEADLIGHTS — IF EQUIPPED
This system automatically turns the headlights
on or off according to ambient light levels. To
turn the system on, rotate the headlight switch
clockwise to the last detent (AUTO position) for
automatic headlight operation. To turn the
automatic system off, move the headlight
switch out of the AUTO position.
NOTE:
The ignition must be in the ON/RUN or START
position before the headlights will come on in
the automatic mode.
Light Sensor
The light sensor is equipped with an infrared
LED, located on the windshield. It detects
changes in light intensity outside the vehicle,
based on the sensitivity of light set by using the
Menu on the display or on the Uconnect system.
The higher the sensitivity, the lesser the amount
of external light required for controlling the
lighting.
PARKING LIGHTS
Rotate the headlight switch to the first position
to turn on the parking lights. The parking light
indicator in the cluster will illuminate.
HEADLIGHT TIME DELAY
This feature provides the safety of headlight
illumination for up to 90 seconds when leaving
your vehicle in an unlit area.
The time delay of the headlights is programmable
between 0, 30, 60 and 90 seconds within
Uconnect Settings Úpage 134.
Headlight Delay Activation
To activate the delay feature, place the ignition
in the OFF position while the headlights are still
on. Then, turn off the headlights within two
minutes. The delay interval begins when the
headlight switch is turned off.
Headlight Delay Deactivation
The feature is disabled by turning on the
headlights, the parking lights or by placing the
ignition in the ON/RUN position.
If you shut off the lights before the ignition is
turned on, they will turn off in the normal
manner.
NOTE:
The lights must be turned off within two minutes
of placing the ignition in the OFF position to activate this feature.
FRONT FOG LIGHTS — IF EQUIPPED
The front fog light switch is built into the
headlight switch.
2
Front Fog Light Switch
To activate the front fog lights, turn on the
parking lights or the low beam headlights and
push the fog light button on the headlight
switch. To turn off the front fog lights, push the
headlight switch a second time or turn off the
headlight switch.
An indicator light in the instrument cluster
illuminates when the fog lights are turned on.
Page 42
40 GETTING TO KNOW YOUR VEHICLE
NOTE:
The fog lights will operate with the low beam
headlights or parking lights on. Selecting the
high beam headlights will turn off the fog
lights.
The fog lights also function as cornering
lights. Therefore there will be times when
only one light is on.
If the ignition is placed in the OFF position
with the fog lights on, they will remain on
when the ignition is placed back in the ON/
RUN position.
For vehicles sold in Canada, if the selector is
moved to the parking lights position and the
front fog lights are activated, the DRL will be
deactivated and the front parking lights will
be activated. Once the front fog lights are
deactivated, the DRL will be activated again.
TURN SIGNALS
Move the multifunction lever up or down to
activate the turn signals. The arrows on each
side of the instrument cluster display flash to
show proper operation.
LANE CHANGE ASSIST
Lightly push the multifunction lever up or down,
without moving beyond the detent, and the turn
signal will flash five times then automatically
turn off.
COURTESY LIGHTS /APPROACHING
IGHTS
L
The courtesy lights feature allows you to
activate the low beam, parking lights, and side
marker lights for 25 seconds when the vehicle
is unlocked. The courtesy lights feature can be
activated or deactivated through the Uconnect
Settings. When a door is open with the feature
active, the activation of the lights is extended
for 10 seconds. The feature is disabled when
the vehicle is locked or when the ignition is
placed in the ON/RUN position.
INTERIOR LIGHTS
FRONT COURTESY LIGHT
The courtesy lights will automatically turn on
when the door is open or closed. The light
switches in the overhead console are for
reading lamps.
Front Courtesy/Reading Lights
1 — Courtesy/Reading Lights
2 — Light Switches
Push the driver or passenger light switch to
operate the reading lamps individually.
NOTE:
Before exiting the vehicle, make sure that the
interior lights are turned off. This will prevent
the battery from discharging once the doors
are closed.
If a light is left on it will automatically be
turned off after approximately 15 minutes
after the ignition is in the OFF position.
Page 43
GETTING TO KNOW YOUR VEHICLE 41
Dome Light Timing
The dome light will automatically illuminate
when the doors are unlocked, the doors are
opened or after the doors are closed.
Timing Entering The Vehicle
The dome lights illuminate in the following ways:
When the doors are unlocked, the dome light
will illuminate for approximately 27 seconds.
When one of the doors is opened, the dome
light will illuminate for approximately three
minutes.
When the doors are closed, the dome light
will automatically shut off after approximately 27 seconds.
NOTE:
The timing stops once the ignition is placed in
the ON/RUN position.
The dome light will turn off under any of the
following conditions:
The dome light is disabled when the ignition
is placed in the ON/RUN position.
The dome lights will turn off automatically
when the doors are locked.
The dome lights will automatically turn off
after approximately 15 minutes of inactivity
to preserve the battery.
Timing Exiting The Vehicle
The dome light will illuminate under the
following conditions when the ignition is placed
in the OFF position:
The dome light will illuminate for 27 seconds
after the key is removed from the vehicle.
The opening of one of the doors (approxi-
mately three minutes).
After closing a door (approximately 27
seconds).
The dome light timing is disabled when the
doors are locked.
Dimmer Controls
Rotate the ambient dimmer control upward or
downward to increase or decrease the
brightness of the ambient light located in the
overhead console, lower instrument panel
lights, and cubby bin lights.
With the parking lights or headlights on, rotate
the instrument panel dimmer control upward or
downward to increase or decrease the
brightness of the instrument panel. At the top
detent of the instrument panel dimmer, all the
interior lights will also illuminate. At the bottom
most setting of the thumb wheel, all the interior
lights will be turned to their lowest dimmable
setting.
Headlight Switch
1 — Ambient Light Control (If Equipped)
2 — Instrument Panel Dimmer
Rear Dome Light — If Equipped
Push the switch on the rear dome light once to
turn the light on, the light will remain on at all
times. Push the switch a second time to turn the
light off, the light will remain off until a door is
opened.
2
Page 44
42 GETTING TO KNOW YOUR VEHICLE
Rear Dome Light On/Off Switch
Retractable Roof Lights
For vehicles equipped with a retractable roof,
there are two interior lights located below the
grab handles of the rear doors.
The lights come on by opening any of the doors.
CARGO AREA LIGHTS
An interior light is located on the left side panel
in the cargo area.
This light automatically turns on/off when the
liftgate is opened and closed, regardless of the
position of the ignition.
NOTE:
In order to preserve the life of the battery, the
light will turn off after 15 minutes.
WINDSHIELD WIPERS AND WASHERS
The windshield wiper/washer controls are
located on the lever on the right side of the
steering column. The front wipers are operated
by rotating a switch, located on the end of the
lever.
Windshield Wiper Lever
CAUTION!
Always remove any buildup of snow that
prevents the windshield wiper blades from
returning to the “park” position. If the
windshield wiper switch is turned off, and the
blades cannot return to the “park” position,
damage to the wiper motor may occur.
WINDSHIELD WIPER O PERATION
Rotate the windshield wiper knob to one of the
first two detent positions for intermittent
settings, the third detent for low wiper operation
and the fourth for high wiper operation.
Windshield Washers
To use the washer, pull the lever toward you and
hold. If the lever is pulled while in the
intermittent setting, the wipers will turn on and
operate for several wipe cycles after the lever is
released, and then resume the intermittent
interval previously selected.
If the lever is pulled while the wipers are in the
off position, the wipers will operate for several
wipe cycles, then turn off.
WARNING!
Sudden loss of visibility through the
windshield could lead to a collision. You might
not see other vehicles or other obstacles. To
avoid sudden icing of the windshield during
freezing weather, warm the windshield with
the defroster before and during windshield
washer use.
Page 45
GETTING TO KNOW YOUR VEHICLE 43
Mist
Push the lever upward to the Mist position and
release for a single wiping cycle.
NOTE:
The Mist feature does not activate the washer
pump; therefore, no washer fluid will be sprayed
on the windshield. The wash function must be
used in order to spray the windshield with
washer fluid.
For information on wiper care and replacement,
see Ú page 264.
RAIN SENSING WIPERS — IF EQUIPPED
This feature senses moisture on the windshield
and automatically activates the wipers. Rotate
the end of the multifunction lever to one of two
detent positions for intermittent settings to
activate this feature.
NOTE:
If the end of the multifunction lever rotates from
the off (O) position to the first intermittent
setting or from the first intermittent setting to
the second intermittent setting, the wipers will
perform a round up to clean the windshield.
Rain Sensor Location
The sensitivity of the system can be adjusted
with the multifunction lever. Wiper delay
position one is the least sensitive, and wiper
delay position two is the most sensitive. Place
the wiper switch in the off (O) position when not
using the system.
NOTE:
The Rain Sensing feature will not operate
when the wiper switch is in the low or
high-speed position.
The Rain Sensing feature may not function
properly when ice or dried salt water is
present on the windshield.
Use of Rain-X or products containing wax or
silicone may reduce Rain Sensing performance.
The Rain Sensing feature can be turned on
and off through Uconnect Settings
Ú page 134.
The Rain Sensing system has protection
features for the wiper blades and arms, and will
not operate under the following conditions:
Low Ambient Temperature — When the igni-
tion is first placed in the ON/RUN position,
the Rain Sensing system will not operate until
the wiper switch is moved, vehicle speed is
greater than 0 mph (0 km/h), or the outside
temperature is greater than 32°F (0°C).
Transmission In NEUTRAL Position — When
the ignition is in the ON/RUN position, and
the automatic transmission is in the
NEUTRAL position, the Rain Sensing system
will not operate until the wiper switch is
moved, vehicle speed is greater than 3 mph
(5 km/h), or the gear selector is moved out of
the NEUTRAL position.
Remote Start Mode Inhibit — On vehicles
equipped with the Remote Starting system,
Rain Sensing wipers are not operational
2
Page 46
44 GETTING TO KNOW YOUR VEHICLE
when the vehicle is in the remote start mode.
Once the operator is in the vehicle and has
placed the ignition switch in the ON/RUN
position, rain sensing wiper operation can
resume, if it has been selected, and no other
inhibit conditions exist.
Rain Sensing Wipers — Inhibition — When the
user changes the ignition position from OFF
to ON/RUN with the windshield wiper lever
already in the intermittent position, no wipe
cycle is performed for safety reasons. This
temporary inhibition avoids accidental activations of the wiping (e.g. during the hand
washing of the windshield, blocking the
blades in ice/snow conditions).
The user can activate the Rain Sensing Wipers
in three ways:
Moving the lever from the off (O) position to
the intermittent positions.
One Mist command actuation.
The vehicle speed exceeds 3 mph (5 km/h)
and the rain sensor detects the presence of
rain.
REAR WINDOW WIPER /WASHER
The rear wiper/washer controls are located on
the windshield wiper lever on the right side of
the steering column. The rear wiper/washer is
operated by rotating a switch, located at the
middle of the lever.
NOTE:
If the front wiper is moving and the vehicle is
shifted in REVERSE, the rear wiper will perform
one round up to clean the rear window.
Rotate the center portion of the lever
upward to the first detent for
intermittent operation and to the
second detent for continuous rear
wiper operation.
To use the washer, push the lever
forward and hold while spray is
desired. If the lever is pushed while in
the intermittent setting, the wiper will
turn on and operate for several wipe cycles after
the end of the lever is released, and then
resume the intermittent interval previously
selected.
NOTE:
As a protective measure, the pump will stop if
the switch is held for more than 30 seconds.
Once the lever is released, the pump will
resume normal operation.
If the lever is pushed while the wiper is in the off
position, the wiper will operate for several wipe
cycles, then turn off.
If the rear wiper is operating when the ignition is
placed in the OFF position, the wiper will
automatically return to the “park” position.
CAUTION!
Failure to follow these cautions can cause
damage to the heating elements:
Use care when washing the inside of the
rear window. Do not use abrasive window
cleaners on the interior surface of the
window. Use a soft cloth and a mild
washing solution, wiping parallel to the
heating elements. Labels can be peeled off
after soaking with warm water.
(Continued)
Page 47
GETTING TO KNOW YOUR VEHICLE 45
CAUTION! (Continued)
Do not use scrapers, sharp instruments, or
abrasive window cleaners on the interior
surface of the window.
Keep all objects a safe distance from the
window.
WINDSHIELD WIPER D E-ICER — IF
QUIPPED
E
Your vehicle may be equipped with a Windshield
Wiper De-Icer feature that may be activated
under the following conditions:
Activation By Rear Defrost — The Windshield
Wiper De-Icer will be activated automatically
when the rear defrost is turned on and the
ambient temperature is below 40°F (4.4°C).
Activation By Remote Start Operation —
When Remote Start is active and the outside
ambient temperature is less than 40°F
(4.4°C), the Windshield Wiper De-Icer will be
enabled. Upon exiting remote start mode the
Windshield Wiper De-Icer will remain on
Ú page 134.
CLIMATE CONTROLS
The Climate Control system allows you to
regulate the temperature, air flow, and direction
of air circulating throughout the vehicle. The
controls are located on the touchscreen (if
equipped) and on the instrument panel below
the radio.
AUTOMATIC CLIMATE CONTROL
ESCRIPTIONS AND FUNCTIONS
D
Automatic Climate Controls
MAX A/C Setting
MAX A/C sets the system for
maximum cooling performance.
Rotate the driver temperature control
adjust knob counterclockwise for
MAX A/C. Both driver and passenger
temperature displays will show MAX A/C LO. In
MAX A/C, the blower speed and mode position
can be adjusted to desired user settings.
Pressing other settings will cause the MAX A/C
operation to switch to the selected setting and
MAX A/C to exit.
A/C Button
Push the A/C Control Button to
change the current setting. The A/C
indicator illuminates when A/C is on.
Pushing the AUTO control button will
cause the A/C operation to change to AUTO
mode and the A/C indicator will turn off.
The Air Conditioning (A/C) button allows the
operator to manually activate or deactivate the
air conditioning system. When the air
conditioning system is turned on, cool
dehumidified air will flow through the outlets
into the cabin. For improved fuel economy,
press the A/C button to turn off the air
conditioning and manually adjust the blower
and airflow mode settings. Also, make sure to
select only Panel, Bi-Level, or Floor modes.
2
Page 48
46 GETTING TO KNOW YOUR VEHICLE
NOTE:
If your air conditioning performance seems
lower than expected, check the front of the A/C
condenser (located in front of the radiator), for
an accumulation of dirt or insects. Clean with a
gentle water spray from the front of the radiator
and through the condenser.
SYNC Button
Push the Sync button to toggle the
Sync feature on/off. The Sync
indicator illuminates when Sync is on.
Sync synchronizes the passenger
temperature setting with the driver temperature
setting. Changing the passenger temperature
setting while in Sync mode will automatically
exit this feature and return to the separate
management of air temperatures in the two
zones.
Recirculation Button
Press and release this button to
change the system between
Recirculation mode and outside air
mode. The Recirculation indicator
illuminates when Recirculation is on.
Recirculation can be used when outside
conditions such as smoke, odors, dust, or high
humidity are present. Recirculation can be used
in all modes. Recirculation may be unavailable
if conditions exist that could create fogging on
the inside of the windshield. Continuous use of
the Recirculation mode may make the inside air
stuffy and window fogging may occur. Extended
use of this mode is not recommended.
In cold weather, use of Recirculation mode may
lead to excessive window fogging. The
Recirculation feature may be unavailable if
conditions exist that could create fogging on the
inside of the windshield.
AUTO Button
Set your desired temperature and
press AUTO. AUTO will achieve and
maintain your desired temperature by
automatically adjusting the blower
speed and air distribution. AUTO mode is highly
recommended for efficiency. Push the button
on the faceplate to turn AUTO on. The AUTO
indicator illuminates when AUTO is on. Toggling
this function will cause the system to switch
between manual mode and automatic mode
Ú page 51.
MAX Defrost Button
Push the MAX Defrost button to
change the current airflow setting to
Defrost mode. The MAX Defrost
indicator illuminates when MAX
Defrost is on. Performing this function will
cause the automatic climate controls to change
to manual mode. The blower speed increases to
full (all LEDs on) when MAX Defrost mode is
selected, the air conditioning compressor is
turned on (LED on), both driver and passenger
temperature controls are set to (HI), defrost
mode is selected (LED on), rear defroster is
turned on (LED on) and the air recirculation is
turned off (LED off). If the MAX Defrost mode is
turned off, the climate system will return to the
previous setting.
Rear Defrost Button
Push the Rear Defrost button to turn
on the rear window defroster and the
heated outside mirrors (if equipped).
The Rear Defrost indicator illuminates
when the rear window defroster is on. The rear
window defroster automatically turns off after
20 minutes.
Page 49
GETTING TO KNOW YOUR VEHICLE 47
CAUTION!
Failure to follow these cautions can cause
damage to the heating elements:
Use care when washing the inside of the
rear window. Do not use abrasive window
cleaners on the interior surface of the
window. Use a soft cloth and a mild
washing solution, wiping parallel to the
heating elements. Labels can be peeled off
after soaking with warm water.
Do not use scrapers, sharp instruments, or
abrasive window cleaners on the interior
surface of the window.
Keep all objects a safe distance from the
window.
Driver And Passenger Temperature Knobs
The passenger temperature knob provides the
passenger with independent temperature
control. The driver temperature knob provides
the driver with independent temperature
control. Rotate the adjustment knob to set the
desired temperature.
Rotating the temperature knob
clockwise increases the temperature.
Rotating the temperature knob
counterclockwise decreases the
temperature.
The set temperature is shown on the display.
Turning the temperature knob completely in
one direction or the other activates the HI
(maximum heating) or LO (maximum cooling)
functions shown in the display, respectively.
Rotate the driver temperature knob fully
counterclockwise for maximum A/C (LO).
To deactivate these functions, turn the
temperature knob to the desired temperature.
NOTE:
Rotating the passenger temperature control
knob while in Sync mode will automatically exit
Sync.
Blower Control Knob
Blower Control is used to regulate the
amount of air forced through the
Climate Control system. Adjusting the
blower will cause automatic mode to switch to
manual operation. The speeds can be selected
by rotating the Blower Control adjustment knob.
Mode Control
Select Mode by pressing one of the
Mode buttons to change the airflow
distribution mode. The airflow
distribution mode can be adjusted so
air comes from the instrument panel outlets,
floor outlets, defrost outlets and demist outlets.
Front Defrost Button
Push and release the button on the
faceplate to change the current
airflow setting to Defrost mode. The
Front Defrost indicator illuminates
when Front Defrost is on. Air comes from the
windshield and side window demist outlets.
When the defrost button is selected, the blower
level may increase. Use Defrost mode with
maximum temperature settings for best
windshield and side window defrosting and
defogging. When toggling the front defrost
mode button, the Climate Control system will
return to the previous setting.
2
Page 50
48 GETTING TO KNOW YOUR VEHICLE
Panel Mode
Air comes from the outlets in the
instrument panel. Each of these
outlets can be individually adjusted to
direct the flow of air. The air vanes of
the center outlets and outboard outlets can be
moved up and down or side to side to regulate
airflow direction. There is a shut off wheel
located below the air vanes to shut off or adjust
the amount of airflow from these outlets.
Floor Mode
Air comes from the floor outlets. A
slight amount of air is directed
through the defrost and side window
demister outlets.
Bi-Level Mode
Bi-Level Mode is obtained by pressing
both the Panel Mode button and the
Floor Mode button, activating them
both. Air comes from the instrument
panel outlets and floor outlets. A slight amount
of air is directed through the defrost and side
window demister outlets.
NOTE:
Bi-Level Mode is designed under comfort conditions to provide cooler air out of the panel
outlets and warmer air from the floor outlets.
Mix Mode
Mix Mode is obtained by pressing
both the Windshield Mode button and
the Floor Mode button, activating
them both. Air is directed through the
floor, defrost, and side window demister
outlets. This setting works best in cold or snowy
conditions that require extra heat to the
windshield. This setting is good for maintaining
comfort while reducing moisture on the
windshield.
Hi-Level Mode
Hi-Level Mode is obtained by pushing
the Defrost Mode button and the
Panel Mode button. Air comes from
the instrument panel outlets and the
defrost outlets. A slight amount of air is directed
through the side window demister outlets.
Tri-Level Mode
Tri-Level Mode is obtained by pressing
the Defrost Mode button, the Panel
Mode button, and the Floor Mode
button. Air comes from the instrument panel
outlets, the defrost outlets, and floor outlets. A
slight amount of air is directed through the side
window demister outlets.
Climate Control Power Button
Press and release the Climate Control
Power button to turn the Climate
Control on/off.
MANUAL CLIMATE C ONTROL
ESCRIPTIONS AND FUNCTIONS
D
Manual Climate Controls
MAX A/C Setting
Set the temperature control knob to
the MAX A/C setting to change the
current setting to the coldest output
Page 51
GETTING TO KNOW YOUR VEHICLE 49
of air. Moving the temperature control knob
away from the MAX A/C setting causes the MAX
A/C operation to exit.
A/C Button
Push the A/C button to engage the Air
Conditioning (A/C). The A/C indicator
illuminates when A/C is on.
NOTE:
For Manual Climate Controls, if the system is
in Mix, Floor or Defrost Mode, the A/C can be
turned off, but the A/C system shall remain
active to prevent fogging of the windows.
If fog or mist appears on the windshield or
side glass, select Defrost mode, and increase
blower speed if needed.
If your air conditioning performance seems
lower than expected, check the front of the
A/C condenser (located in front of the radiator), for an accumulation of dirt or insects.
Clean with a gentle water spray from the front
of the radiator and through the condenser.
Recirculation Button
Push the Recirculation button to
change the system between
recirculation mode and outside air mode. The
Recirculation indicator and the A/C indicator
illuminate when the Recirculation button is
pressed. Recirculation can be used when
outside conditions, such as smoke, odors, dust,
or humidity are present. Recirculation can be
used in all modes except for Defrost.
Recirculation may be unavailable if conditions
exist that could create fogging on the inside of
the windshield. The A/C can be deselected
manually without disturbing the mode control
selection. Continuous use of the Recirculation
mode may make the inside air stuffy and
window fogging may occur. Extended use of this
mode is not recommended.
On systems with Manual Climate Controls, if
equipped, the Recirculation mode is not
allowed in Defrost mode to improve window
clearing operation. Recirculation is disabled
automatically if this mode is selected.
Attempting to use Recirculation while in this
mode causes the LED in the control button to
blink and then turns off.
Front Defrost Setting
Turn the mode control knob to the
Front Defrost mode setting. Air comes
from the windshield and side window
demist outlets. When the defrost button is
selected, the blower level may increase. Use
Defrost mode with maximum temperature
settings for best windshield and side window
defrosting and defogging.
Rear Defrost Button
Push and release the Rear Defrost
Control button to turn on the rear
window defroster and the heated
outside mirrors (if equipped). The
Rear Defrost indicator illuminates when the rear
window defroster is on. The rear window
defroster automatically turns off after
20 minutes.
CAUTION!
Failure to follow these cautions can cause
damage to the heating elements:
Use care when washing the inside of the
rear window. Do not use abrasive window
cleaners on the interior surface of the
window. Use a soft cloth and a mild
washing solution, wiping parallel to the
heating elements. Labels can be peeled off
after soaking with warm water.
(Continued)
2
Page 52
50 GETTING TO KNOW YOUR VEHICLE
CAUTION! (Continued)
Do not use scrapers, sharp instruments, or
abrasive window cleaners on the interior
surface of the window.
Keep all objects a safe distance from the
window.
Temperature Control
Temperature Control regulates the temperature
of the air forced through the climate system.
The temperature increases as you
turn the temperature control knob
clockwise.
The temperature decreases as you
turn the temperature control knob
counterclockwise.
Blower Control
Blower Control regulates the amount
of air forced through the climate
control system. There are seven
blower speeds available. The blower
speed increases as you turn the blower control
knob clockwise from the lowest blower setting.
The blower speed decreases as you turn the
blower control knob counterclockwise.
Mode Control
Turn the mode control knob to adjust
airflow distribution. The airflow
distribution mode can be adjusted so
air comes from the instrument panel
outlets, floor outlets, defrost outlets and demist
outlets.
Panel Mode
Air comes from the outlets in the
instrument panel. Each of these
outlets can be individually adjusted to
direct the flow of air. The air vanes of
the center outlets and outboard outlets can be
moved up and down or side to side to regulate
airflow direction. There is a shut off wheel
located below the air vanes to shut off or adjust
the amount of airflow from these outlets.
Bi-Level Mode
Air comes from the instrument panel
outlets and floor outlets. A slight
amount of air is directed through the
defrost and side window demister
outlets.
NOTE:
Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel
outlets and warmer air from the floor outlets.
Floor Mode
Air comes from the floor outlets. A
slight amount of air is directed
through the defrost and side window
demister outlets.
Mix Mode
Air comes from the floor, defrost, and
side window demister outlets. This
setting works best in cold or snowy
conditions that require extra heat to
the windshield. This setting is good for
maintaining comfort while reducing moisture on
the windshield.
Climate Control OFF
To turn the Climate Controls off, turn
the blower control knob to the OFF (O)
position.
Page 53
GETTING TO KNOW YOUR VEHICLE 51
AUTOMATIC TEMPERATURE CONTROL (ATC)
Automatic Operation
1. Push the AUTO button on the front ATC
panel and the word “AUTO” will illuminate
in the front ATC display, along with two
temperatures for the driver and front
passenger. The system will then automatically regulate the amount of airflow.
2. Adjust the temperature you would like the
system to maintain, by adjusting the driver,
and passenger temperatures. Once the
desired temperature is displayed, the
system will achieve and automatically
maintain that comfort level.
3. When the system is set up for your comfort
level, it is not necessary to change the
settings. You will experience the greatest
efficiency by simply allowing the system to
function automatically.
NOTE:
It is not necessary to move the temperature
settings. The system automatically adjusts the
temperature, mode, and fan speed to provide
comfort as quickly as possible.
To provide you with maximum comfort in the
automatic mode, during cold start-ups, the
blower fan will remain on low until the engine
warms up. The fan will engage immediately if
the Defrost mode is selected, or by changing the
front blower knob setting.
Manual Operation Override
This system offers a full complement of manual
override features. The AUTO symbol in the front
ATC display will be turned off when the system
is being used in the manual mode.
CLIMATE VOICE RECOGNITION
Adjust vehicle temperatures hands-free and
keep everyone comfortable while you keep
moving ahead. (If vehicle is equipped with
climate control.)
Push the VR button . After the beep, say one
of the following commands:
“Set the driver temperature to 70 degrees”
“Set the passenger temperature to
70 degrees”
Did You Know: Voice Command for Climate may
only be used to adjust the interior temperature
of your vehicle. Voice Command will not work to
adjust the heated seats or steering wheel if
equipped.
OPERATING TIPS
NOTE:
Refer to the chart at the end of this section for
suggested control settings for various weather
conditions.
Summer Operation
The engine cooling system must be protected
with a high-quality antifreeze coolant to provide
proper corrosion protection and to protect
against engine overheating. OAT coolant
(conforming to MS.90032) is recommended.
Winter Operation
To ensure the best possible heater and
defroster performance, make sure the engine
cooling system is functioning properly and the
proper amount, type, and concentration of
coolant is used. Use of the Air Recirculation
mode during Winter months is not
recommended, because it may cause window
fogging.
2
Page 54
52 GETTING TO KNOW YOUR VEHICLE
Vacation/Storage
For information on maintaining the Climate
Control system when the vehicle is being stored
for an extended period of time, see
Ú page 306.
Window Fogging
Vehicle windows tend to fog on the inside in
mild, rainy, and/or humid weather. To clear the
windows, select Defrost or Mix mode and
increase the front blower speed. Do not use the
Recirculation mode without A/C for long
periods, as fogging may occur.
Outside Air Intake
Make sure the air intake, located directly in
front of the windshield, is free of obstructions,
such as leaves. Leaves collected in the air
intake may reduce airflow, and if they enter the
air distribution box, they could plug the water
drains. In Winter months, make sure the air
intake is clear of ice, slush, and snow.
Cabin Air Filter
The Climate Control system filters out dust and
pollen from the air. Contact an authorized
dealer to service your cabin air filter, and to
have it replaced when needed.
System Maintenance
In Winter, the Climate Control system must be
turned on at least once a month for
approximately 10 minutes.
Have the system inspected at an authorized
dealer before the summer.
NOTE:
The system uses R-1234yf (refrigerant) which
does not pollute the environment in the event of
accidental leakage. Under no circumstances is
the use of R-134a (refrigerant) allowed.
Rapid Window Demisting (MAX-Defrost Function)
Push the MAX-defrost button to activate (LED
on) the windshield and side window demisting
function.
The Climate Control system carries out the
following operations:
Turns on the air conditioning compressor
when environmental conditions are suitable
Turns air recirculation off
Sets blower fan to the maximum speed and
displays the fan speed (Blower Control Indicator LED illuminated)
Directs air flow to windshield and front side
window diffusers
Activates the heated rear window defrost
Activates the heated windshield (if equipped)
When the function is activated, the AUTO button
LED turns off. With the function activated, the
only possible manual adjustments are pushing
the A/C control button, adjusting the fan speed
and turning the heated rear window off.
When the Recirculation Control or AUTO buttons
are pushed, the Climate Control system will
deactivate the Front Defrost (MAX-DEF)
function.
Selecting the footwell/windshield or only
windshield distribution activates the Climate
Control system compressor and the air
recirculation is set to outside air intake.
This logic guarantees optimum visibility at the
windows. Max-defrost is also available in
manual mode.
Climate Control System Compressor
Push the A/C Control button to activate/
deactivate the compressor (activation is
indicated by the LED on the button turning on).
Page 55
GETTING TO KNOW YOUR VEHICLE 53
The system remembers that the compressor
has been turned off, even after the engine has
stopped.
Pushing the A/C button will stop AUTO mode
(AUTO LED will turn off). To restore automatic
control of compressor, push the AUTO button
again.
NOTE:
With the compressor off, air cannot be introduced to the passenger compartment with a
temperature lower than the outside temperature. Under certain environmental conditions,
windows could fog rapidly since the air is not
dehumidified.
Operating Tips Chart
WEATHER CONTROL SETTINGS
Set the mode control
to (Panel Mode),
Hot Weather And
Vehicle Interior Is Very
Hot
(MAX A/C) on, and
blower on high. Roll
down the windows for
a minute to flush out
the hot air. Adjust the
controls as needed to
achieve comfort.
WEATHER CONTROL SETTINGS
Turn (A/C) on and
Warm Weather
Cool Sunny
Cool & Humid
Conditions
Cold Weather
set the mode control
to the (Panel
Mode) position.
Operate in
(Bi-Level Mode)
position.
Set the mode control
to (Mix Mode) and
turn (A/C) on to
keep windows clear.
Set the mode control
to the (Floor
Mode) position. If
windshield fogging
starts to occur, move
the control to the
(Mix Mode) position.
INTERIOR STORAGE AND EQUIPMENT
STORAGE
Glove Compartments
The glove compartments are located on the
passenger side of the instrument panel.
Glove Compartments
1 — Upper Glove Compartment Release Button
2 — Lower Glove Compartment Release Handle
To open the upper compartment, push in the
button located on the bottom side of the upper
door. The door will automatically open.
To close the upper compartment, push
downward on the door's surface to latch the
door closed.
2
Page 56
54 GETTING TO KNOW YOUR VEHICLE
To open the lower glove compartment, pull
outward on the latch and lower the glove
compartment door.
NOTE:
Do not insert objects in the glove compart-
ments that will not allow the compartment to
fully close.
The glove compartments should be completely
closed while the vehicle is in motion.
Front Armrest
The front armrest is located between the front
seats.
The armrest can be adjusted by moving it in the
direction indicated by the arrows.
Front Armrest Handle
Storage Compartment
Push the storage handle and lift up the armrest
to access the storage compartment.
WARNING!
Do not operate this vehicle with a console
compartment lid in the open position. Driving
with the console compartment lid open may
result in injury in a collision.
SUN VISORS “SLIDE-ON-ROD”
Sun visors are located on both sides of the
rearview mirror. The visors can be lowered or
moved to the side to help block sunlight from
entering the windshield or door glass.
To move the sun visor against the driver or
passenger door glass, remove the sun visor
from the hook and turn it toward the side
window.
Sun Visor Mirror Cover
The visors also have illuminated vanity mirrors
to allow use in low light conditions.
Lift upward on the mirror cover to access the
mirror.
Extendible Sun Visor
To extend the sun visor, proceed as follows:
1. Place the sun visor against the door glass
by detaching it from the hook and turning it
toward the side window.
2. Slide the visor.
Page 57
GETTING TO KNOW YOUR VEHICLE 55
3. Slide out the sun visor extender.
Fully Extended Sun Visor
USB/M EDIA PLAYER CONTROL
Located below the heating ventilation and air
conditioning controls is the front USB ports.
Front USB Ports
This feature allows an external device to be
plugged into the USB port.
Rear Center Console USB Port
Located on the back of the center console is a
third, charge only USB port.
Rear Center Console USB Port — If Equipped
NOTE:
Depending on vehicle configuration, the USB
port may be charge only, or media file capable.
POWER OUTLETS
There is one 12 Volt (13 Amp) power outlet in
this vehicle, located under the climate controls.
This power outlet can power mobile phones,
electronics and other low power devices.
This power outlet is located in front of the gear
selector.
2
12 Volt Power Outlet
NOTE:
The power outlet can be changed to “battery”
powered at all times by switching the power
outlet Engine Compartment Fuses/Distribution
Unit fuse from location F84 to F23.
NOTE:
Do not exceed the maximum power of
160 Watts (13 Amps) at 12 Volts. If the
160 Watt (13 Amp) power rating is exceeded,
the fuse protecting the system will need to be
replaced.
Page 58
56 GETTING TO KNOW YOUR VEHICLE
Power outlets are designed for accessory
plugs only. Do not insert any other object in
the power outlet as this will damage the
outlet and blow the fuse. Improper use of the
power outlet can cause damage not covered
by your new vehicle warranty.
Power Outlet Fuse Location:
F84 Fuse 20A Yellow Instrument Panel Power
Outlet.
CIGAR LIGHTER — IF EQUIPPED
The cigar lighter is located on the instrument
panel, below the climate controls. To activate
the cigar lighter, push and release the knob.
After a few seconds the knob automatically
returns to its initial position, and the cigar
lighter is ready for use.
WARNING!
When the cigar lighter is in use it becomes
very hot. To avoid serious injury, handle the
cigar lighter with care. Always check that the
cigar lighter has turned off.
NOTE:
Always check that the cigar lighter is
switched off.
Do not connect devices with power higher
than 180 W to the socket. Do not damage the
socket by using unsuitable adapters.
ASHTRAY — IF EQUIPPED
NOTE:
Ashtrays can be purchased at an authorized
dealer through Mopar parts.
The ashtray is a plastic container that can be
placed into one of the cup holders.
Ashtray Location
GRAB HANDLES
The grab handles are located immediately
above the doors. The rear handles are equipped
with hooks for dress hangers.
Rear Grab Handle Assembly
1 — Grab Handle
2 — Hook
Page 59
GETTING TO KNOW YOUR VEHICLE 57
WINDOWS
POWER WINDOW CONTROLS
The window controls on the driver's door control
all the door windows.
Power Window Switches
The passenger door windows can also be
operated by using the single window controls on
the passenger door trim panel. The window
controls will operate only when the ignition is in
the ACC or ON/RUN position.
NOTE:
The power window switches will remain active
for up to three minutes after the ignition is
placed in the OFF position. Opening either front
door will cancel this feature.
WARNING!
Never leave children unattended in a vehicle,
and do not let children play with power windows. Do not leave the key fob in or near the
vehicle, or in a location accessible to children,
and do not leave the ignition of a vehicle
equipped with Keyless Enter-N-Go in the ACC
or ON/RUN mode. Occupants, particularly
unattended children, can become entrapped
by the windows while operating the power
window switches. Such entrapment may
result in serious injury or death.
Automatic Window Features
Auto-Down Feature
The driver and front passenger door power
window switches have an Auto-Down feature.
Push the window switch down for a short period
of time, then release, and the window will go
down automatically.
To stop the window from going all the way down
during the Auto-Down operation, pull up or push
down on the switch briefly when the window has
reached the desired position.
Auto-Up Feature With Anti-Pinch Protection
Lift the window switch up for a short period of
time and release; the window will go up
automatically.
To stop the window from going all the way up
during the Auto-Up operation, pull up or push
down on the switch briefly.
To close the window part way, lift the window
switch briefly and release it when you want the
window to stop.
If the window runs into any obstacle during
auto-closure, it will reverse direction and then
go back down. Remove the obstacle and use
the window switch again to close the window.
NOTE:
Any impact due to rough road conditions may
trigger the auto-reverse function unexpectedly
during auto-closure. If this happens, pull the
switch lightly and hold to close the window
manually.
2
Page 60
58 GETTING TO KNOW YOUR VEHICLE
WARNING!
There is no auto-reverse protection when the
window is almost closed. To avoid personal
injury be sure to clear your arms, hands,
fingers and all objects from the window path
before closing.
Reset Auto-Up
Should the Auto-Up feature be interrupted and
stop working, the feature will need to be reset.
To reset Auto-Up:
1. Pull the window switch up to close the
window completely and continue to hold
the switch up for an additional two seconds
after the window is closed.
2. Push the window switch down firmly to open
the window completely and continue to hold
the switch down for an additional two
seconds after the window is fully open.
NOTE:
All doors must be closed before beginning the
Auto-Up reset procedure.
Window Lockout Switch
The window lockout switch on the driver's door
trim panel allows you to disable the window
controls on the rear passenger doors. To
disable the window controls, push and release
the window lockout button (the indicator light
on the switch will turn on). To enable the window
controls, push and release the window lockout
switch again (the indicator light on the switch
will turn off).
Window Lockout Switch
Wind Buffeting
Wind buffeting can be described as the
perception of pressure on the ears or a
helicopter-type sound in the ears. Your vehicle
may exhibit wind buffeting with the windows
down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal
occurrence and can be minimized. If the
buffeting occurs with the rear windows open,
open the front and rear windows together to
minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof
opening to minimize the buffeting or open any
window.
SUNROOF — IF EQUIPPED
The sunroof has two glass panels (the front one
is operational and the rear one fixed) and is
equipped with two manual operated
sunshades, front and rear.
The power sunroof can be operated only when
the ignition is placed in ON/RUN.
The power sunroof switches are located in the
overhead console.
Page 61
GETTING TO KNOW YOUR VEHICLE 59
Operation Switch
1 — Front Panel Open/Close Switch
2 — Front Panel Vent Switch
WARNING!
Never leave children alone in a vehicle, or
with access to an unlocked vehicle. Never
leave the key fob in or near the vehicle or in
a location accessible to children. Occupants, particularly unattended children,
can become entrapped by the power
sunroof while operating the power sunroof
switch. Such entrapment may result in
serious injury or death.
(Continued)
WARNING! (Continued)
In a collision, there is greater risk of being
thrown from a vehicle with an open sunroof.
You could also be seriously injured or killed.
Always fasten your seat belt properly and
make sure all passengers are properly
secured too.
Do not allow small children to operate the
sunroof. Never allow your fingers, other
body parts, or any object to project through
the sunroof opening. Injury may result.
OPENING AND CLOSING THE SUNROOF
To retract the front panel to the open position,
push the open/close switch and the sunroof will
fully open. The sunroof can be stopped in any
position by pushing the switch a second time
while is opening.
To close the front panel completely, pull the
open/close switch from the open position. The
sunroof can be stopped in any position by
pulling the sunroof switch a second time while it
is closing.
PINCH PROTECT FEATURE
This feature will detect an obstruction in the
opening of the sunroof during Express Close
operation. If an obstruction in the path of the
sunroof is detected, the sunroof will
automatically retract. Remove the obstruction if
this occurs.
VENTING SUNROOF
To vent the sunroof, push the vent switch.
NOTE:
The vent switch has the automatic function only
at the opening of the sunroof. During the closing
of the sunroof, the switch must be held until
closed.
SUN SHADE
The two sun shades are manually operated and
can be adjusted in any position.
SUNROOF MAINTENANCE
Use only a non-abrasive cleaner and a soft cloth
to clean the glass panel. Periodically check for
and clear out any debris that may have
collected in the tracks.
2
Page 62
60 GETTING TO KNOW YOUR VEHICLE
EMERGENCY OPERATION
If the power sunroof switch fails, the sunroof
can be operated manually as follows:
1. Remove the protective cap located on the
inner lining.
2. Remove the Allen Key that is supplied in the
tool bag in the cargo area.
3. Insert the Allen Key into the key hole and
turn it clockwise to open the roof or
counter-clockwise to close.
Emergency Key And Key Hole
1 — Allen Key
2 — Key Hole
CAUTION!
When refitting sunroof, be careful to avoid
fingers, scarves, ties and items of clothing
from getting caught under the panel.
Do not open the roof in the presence of
snow or ice. There is risk of damage.
POWER SUNROOF RELEARN
ROCEDURE
P
As a result of any abnormal behavior of the roof
or as a result of an emergency operation, and
you must relearn the automatic operation of the
sunroof.
Proceed as follows:
1. Push the open/close button to move the
roof in the fully closed position.
2. Place the ignition in the OFF position and
wait for at least 10 seconds.
3. Place the ignition in the ON/RUN position.
4. Pull the open/close button and hold it for at
least 10 seconds, after which you should
feel the mechanical stop of the electric
motor of the roof.
5. Within five seconds, pull to close and hold
the open/close button, the roof makes a
complete cycle of opening and closing
automatically (to indicate that the relearn
procedure has been successful). If this does
not happen and you need to repeat the
procedure from the beginning.
HOOD
TO OPEN THE HOOD
To open the hood, two latches must be
released.
1. Pull the release lever located underneath
the driver’s side of the instrument panel.
Hood Release Lever
Page 63
GETTING TO KNOW YOUR VEHICLE 61
2. Move to the outside of the vehicle and push
the safety latch release lever toward the
passenger side of the vehicle. The hood
release lever is located behind the center
front edge of the hood.
Safety Latch Release Lever Location
3. Remove the support rod from the locking
tab and insert it into the seat located on the
underside of the hood. Be sure the rod is
locked into position.
Hood Prop System
1 — Locking Tab
2 — Support Rod
3 — Support Rod Seat
TO CLOSE THE H OOD
1. Hold up the hood with one hand and with
the other hand remove the support rod
from its seat and reinsert it into the locking
tab.
2. Lower the hood to approximately 12 inches
(30 cm) from the engine compartment and
drop it. Make sure that the hood is
completely closed.
WARNING!
Be sure the hood is fully latched before
driving your vehicle. If the hood is not fully
latched, it could open when the vehicle is in
motion and block your vision. Failure to follow
this warning could result in serious injury or
death.
CAUTION!
To prevent possible damage, do not slam the
hood to close it. Lower hood to approximately
12 inches (30 cm) and drop the hood to
close. Make sure hood is fully closed for both
latches. Never drive vehicle unless hood is
fully closed, with both latches engaged.
2
Page 64
62 GETTING TO KNOW YOUR VEHICLE
LIFTGATE
TO UNLOCK /OPEN THE LIFTGATE
To unlock the liftgate from the outside, push the
electronic liftgate release and pull the liftgate
open with one fluid motion.
Electronic Liftgate Release
When opening the door, the interior dome light
will illuminate. The interior dome light will turn
off automatically by closing the liftgate
Ú page 40.
If the liftgate is left open, the interior dome light
will shut off after a few minutes to conserve
battery life.
Emergency Opening
Proceed as follows:
1. Lower the headrests and fold the
seatbacks.
2 — Release Tab Slot
LOCK/CLOSE THE LIFTGATE
Grab the liftgate closing handle and lower the
liftgate.
1 — Yellow Tab
2. Using the supplied screwdriver (located
under cargo floor in tool kit), remove the
yellow tab from the liftgate latching
mechanism.
3. With the yellow tab removed, insert the
screwdriver into the now open release tab
slot to trigger the release of the liftgate.
Liftgate Closing Handle
Page 65
GETTING TO KNOW YOUR VEHICLE 63
NOTE:
Before closing the liftgate, make sure to be in
possession of the key because the liftgate will
be locked automatically.
CARGO AREA FEATURES
Removable Rear Shelf — If Equipped
To remove rear shelf, proceed as follows:
1. Disconnect the two links that support the
shelf at the eyelets.
Rear Shelf Support Links
1 — Eyelets
2 — Links
2. Lift the rear part of the overhead luggage
shelf.
3. Clear the pins placed outside of the shelf,
and then remove the rear shelf pulling it
upwards.
4. The rear shelf can be stored in the cargo
area, or behind the front seatbacks.
Cargo Load Floor — If Equipped
The vehicle is equipped with a load floor that
can be adjusted as needed.
Position 1 (Lowered Position):
This position allows you to make the load floor
flat for ease of loading/unloading objects from
the cargo area. This position also makes it
possible to use the space below as another
compartment for storing fragile or smaller
objects.
Position 2 (Elevated Position):
When the rear seatbacks and front passenger
seat are folded flat, it creates space for objects
of long dimensions. This position is
recommended only when transporting objects,
then move the load floor back to position 1.
NOTE:
With a full size spare, the floor will be at the
elevated position.
Access To The Loading Floor
To access the double load compartment,
proceed as follows:
1. Lift up on the load floor handle.
Load Floor Handle
2. Place the desired objects inside the
compartment.
2
Page 66
64 GETTING TO KNOW YOUR VEHICLE
3. Reposition the load floor.
Cargo Area Storage
CAUTION!
The load floor must be arranged in a central
position with respect to cargo area.
Displacement Load Floor
To position the load from the lower to the upper
position, proceed as follows:
1. Grab the load floor handle and lift up the
load floor.
2. Correctly place the load floor on the side
panel guides and on the rear cross member.
Access To Tire Service Kit Or Spare Tire
To access the Tire Service Kit or spare tire and
container carrier, proceed as follows:
1. Grab the load floor handle and remove the
floor.
2. Pull the tab and lift up on the carpet.
Anchoring Of The Load
The cargo tie-downs, located on the trim panels
around the cargo area floor, should be used to
safely secure loads when the vehicle is moving.
Tie-Downs
Cargo Box — If Equipped
The cargo area contains a preformed cargo box
that can be used for the storage of objects that
allows you to obtain a uniform level when
loading.
Cargo Box
NOTE:
The cargo box is sized for a maximum capacity
of distributed weight equal to 242 lbs (110 kg).
Page 67
GETTING TO KNOW YOUR VEHICLE 65
ROOF LUGGAGE RACK — IF EQUIPPED
Your vehicle may be equipped with a Roof
Luggage Rack for transporting accessories.
Crossbars should always be used whenever
cargo is placed on the Roof Luggage Rack.
Check the straps frequently to be sure that the
load remains securely attached.
NOTE:
Crossbars can be purchased at an authorized
dealer through Mopar parts. External racks do
not increase the total load carrying capacity of
the vehicle. Be sure that the total occupant and
luggage load inside the vehicle, plus the load on
the Roof Luggage Rack, do not exceed the
maximum vehicle load capacity.
The load carried on the roof, when equipped
with a Roof Luggage Rack, must not exceed
110 lbs (50 kg), and it should be uniformly
distributed over the cargo area.
Do not use the sunroof when using the
crossbars.
WARNING!
Cargo must be securely tied down before
driving your vehicle. Improperly secured loads
can fly off the vehicle, particularly at high
speeds, resulting in personal injury or
property damage. Follow the roof rack
cautions when carrying cargo on your roof
rack.
CAUTION!
To avoid damage to the Roof Luggage Rack
and vehicle, do not exceed the maximum
roof rack load capacity. Always distribute
heavy loads as evenly as possible and
secure the load appropriately.
Long loads, which extend over the wind-
shield, such as wood panels or surfboards,
should be secured to both the front and
rear of the vehicle.
Place a blanket or other protection
between the surface of the roof and the
load.
Travel at reduced speeds and turn corners
carefully when carrying large or heavy loads
on the roof rack. Wind forces, due to
natural causes or nearby truck traffic, can
add sudden upward lift. This is especially
true on large flat loads and may result in
damage to the cargo or your vehicle.
2
Page 68
66
GETTING TO KNOW YOUR INSTRUMENT PANEL
INSTRUMENT CLUSTER
Instrument Cluster
NOTE:
The illumination of the graphics on the instrument cluster may vary according to the version (Monocolor or Color display).
Page 69
GETTING TO KNOW YOUR INSTRUMENT PANEL 67
INSTRUMENT CLUSTER D ESCRIPTIONS
1. Speedometer
Indicates the speed of the car.
2. Fuel Level Gauge
The fuel gauge in the instrument panel
indicates the amount of fuel left in the
tank.
The light comes on, together with a chime
and the display of a message in the
instrument cluster display, when the gas
tank has 1.5 to 2 gallons (5 to 7 liters) of
fuel remaining.
3. Instrument Cluster Display
The vehicle can be equipped with multi
functional instrument cluster display
which offers useful information to the
driver.
With the ignition in the OFF position (and
the key removed, for vehicles with a
mechanical key), opening/closing of a
door will activate the instrument cluster
display for viewing, and display the total
miles or kilometers in the odometer.
Instrument Cluster Display Control Buttons
4. Engine Coolant Temperature
The temperature gauge on the instru-
ment panel displays the temperature of
the engine coolant and starts providing
indications when the coolant temperature exceeds approximately 122°F
(50°C). In the normal use of the car, the
temperature gauge can move in different
directions based on the use of the car.
The light comes on, together with a chime
and the display of a message in the
instrument cluster display, to indicate an
excessive increase in the temperature of
the engine coolant. Stop the engine and
contact an authorized dealer.
5. Tachometer
Indicates the engine speed in Revolu-
tions Per Minute (RPM x 1000).
INSTRUMENT CLUSTER DISPLAY
The vehicle is equipped with multi functional
instrument cluster display which offers useful
information to the driver. With the ignition in the
OFF position (and the key removed, for vehicles
with a mechanical key), opening/closing of a
door will activate the instrument cluster display
for viewing, and display the total miles or
kilometers in the odometer. The instrument
cluster display is designed to display important
information about the vehicle’s systems and
features. Using a driver interactive display
located on the instrument panel, your
instrument cluster display can show you how
systems are working and give you warnings
when they aren’t. The steering wheel mounted
controls allow you to scroll through and enter
the main menus and submenus. You can
access the specific information you want and
make selections and adjustments.
3
Page 70
68 GETTING TO KNOW YOUR INSTRUMENT PANEL
INSTRUMENT CLUSTER D ISPLAY
ONTROL BUTTONS
C
The system allows the driver to select
information by pushing the following buttons
mounted on the steering wheel:
Instrument Cluster Display Control Buttons
The instrument cluster display features a driver
interactive display that is located in the
instrument cluster. Pushing the controls on the
left side of the steering wheel allows the driver
to select vehicle information and Personal
Settings.
Push the up arrow button to scroll upward
through the main menus and submenus
(Speedometer, Trip, Drive Mode Selector,
Vehicle Info, Driver Assist, Audio, Phone,
Navigation, Messages, Settings).
Push the down arrow button to scroll
downward through the main menu and
submenus (Speedometer, Trip, Drive Mode
Selector, Vehicle Info, Driver Assist, Audio,
Phone, Navigation, Messages, Settings).
Push the right arrow button to access the
information screens or submenu screens of a
main menu item.
Push the back/left arrow button to access
the information screens or submenu screens
of a main menu item.
Push the OK button to access/select the
information screens or submenu screens of a
main menu item. Push and hold the OK
button for two seconds to reset displayed/
selected features that can be reset.
ENGINE OIL CHANGE RESET — I F
QUIPPED
E
Your vehicle may be equipped with an engine oil
change indicator system. The “Change Engine
Oil” message will display in the instrument
cluster display. The engine oil change indicator
system is duty cycle based, which means the
engine oil change interval may fluctuate,
dependent upon your personal driving style.
Unless reset, this message will continue to
display each time you turn the ignition switch to
the ON/RUN position. To reset the oil change
indicator system (after performing the
scheduled maintenance), refer to the following
procedure.
1. Turn the ignition switch to the ON position
(do not start the engine).
2. Fully push the accelerator pedal slowly,
three times, within 10 seconds.
3. Turn the ignition switch to the OFF/LOCK
position.
NOTE:
If the indicator message illuminates when you
start the vehicle, the oil change indicator
system did not reset. If necessary, repeat this
procedure.
Page 71
GETTING TO KNOW YOUR INSTRUMENT PANEL 69
INSTRUMENT CLUSTER D ISPLAY MAIN
ENU
M
The Main Menu is composed of several options
that can be selected using the control buttons
above.
NOTE:
The display mode of the menu items varies
depending on the type of display.
For some items, a submenu is provided.
In the Uconnect system, some items on the
menu are not shown on the instrument
cluster display Ú page 67.
Instrument Cluster Display Menu/ Submenu Items
The Menu is composed of the following items:
Speedometer
Trip
Instantaneous Info
Trip A
Trip B
Drive Mode Selector — If Equipped
Auto Mode
Sport Mode
All Weather Mode
Vehicle Info
Tire Pressure
Oil Temperature
Battery Voltage
Driver Assist
Lane Departure Warning
Audio
Phone
Navigation
Messages
Settings
Display
Units
Clock and Date
Security
Safety & Assistance
Lights
Doors & Locks
Engine OFF Procedure — If Equipped
Stop/Start — If Equipped
Speedometer
View and change the speedometer scale from
mph to km/h (km/h to mph).
Trip
This instrument cluster display menu item
allows you to view and select information about
the "Trip Computer”:
Instantaneous info
View the distance to empty (miles or km).
View the instantaneous consumption
(mpg, or l/ 100km or km/l).
Trip A
View Trip A distance (miles or km).
View travel time A (hours/minutes/
seconds).
3
Page 72
70 GETTING TO KNOW YOUR INSTRUMENT PANEL
View average consumption A (mpg, or
l/ 100km or km/l).
View average speed A (mph or km/h).
Trip B
View Trip B distance (miles or km).
View travel time B (hours/minutes/
seconds).
View average consumption B (mpg, or
l/ 100km or km/l).
View average speed B (mph or km/h).
Drive Mode Selector
This instrument cluster display menu/submenu
items allows you to view and select information
about the "Drive Mode".
Vehicle Info
Push and release the up or down arrow
button until "Vehicle Info" is highlighted in the
instrument cluster display. Push and release
the right arrow button and Coolant Temp will
be displayed. Push the right or left arrow
button to scroll through the following
information displays:
Tire pressure
View the information relating to the Tire
Pressure Monitoring System (TPMS) (if
equipped).
Oil Temperature
View the engine oil temperature.
Battery Voltage
View the voltage value (state of charge)
of the battery.
Driver Assist
This menu item allows you to change the
settings (Notice LaneSense and Intensity
LaneSense) relating to the LaneSense system
(if equipped):
Notice LaneSense
By selecting this function, you can select the
“readiness” of LaneSense, choosing
between the options "Near," "Medium," or
"Far."
Intensity LaneSense
Using this function, you can select the force
applied to the steering wheel to keep the car
in the roadway through the electrical drive
system due to LaneSense.
Audio
This menu item allows you to view the
instrument cluster display and the information
present on the display of the Uconnect system.
The information displayed is:
“Radio (AM or FM)”: view Radio Station Name
(if equipped), frequency, and graphical icon.
MP3: title display or song number playing.
USB: title display or song number playing.
Ipod: display the song title and graphic
element.
Bluetooth®: displays the song title and a
graphic element.
SAT: displays the station name and a graphic
element.
APP: displays strings and a graphic element.
Phone
This menu displays the current status of a
phone connected to the vehicle via Bluetooth®.
Page 73
GETTING TO KNOW YOUR INSTRUMENT PANEL 71
If no phone is connected, the menu will not
function when the OK button is pushed.
Otherwise, if a phone is connected, push the OK
button to enter the menu. The following items
will display:
Recent calls: displays a list of the last
10 calls.
SMS reader: displays the last 10 text
messages and if they are read or unread.
Favorite numbers: displays a maximum of
six favorite numbers.
Navigation
If activated, this menu item will display
navigation status and directions.
Messages (Stored)
This menu item allows you to display the
information messages/malfunction stored.
The background color of the display varies
according to the priorities of the failure:
Failed Messages with low priority display in
yellow.
Failed Messages with high priority display in
red.
Settings
This menu item allows you to change the
settings for the following:
Display
Units
Clock and Date
Security
Safety and Assistance
Lights
Doors and Locks
Engine OFF Procedure — If Equipped
Display
By selecting "Display," you can access the
following settings:
Screen Setup: Allows you to configure the
display screen.
Language: Allows you to select the language
in which to display the information/warnings.
Automatic Reset Trip B: Allows you to set the
options to reset the Trip B (never, always,
every two hours or every eight hours).
Phone Repetition: Allows you to select “On”
or “Off”. The instrument cluster display can
also display the information concerning
phone mode. The information that can be
displayed is the connection status of the
mobile phone (phone connected or disconnected), the active telephone calls/
incoming/on hold, and the management of
double calls (first incoming second waiting,
etc.).
Navigation Repetition: Allows you to select
“On” or “Off” on the instrument cluster
display, information relating to the navigation
mode.
Units
By selecting the item "Units Of Measure,” you
can select the unit of measure used in the
display.
Possible options are:
US
Metric
Custom
3
Page 74
72 GETTING TO KNOW YOUR INSTRUMENT PANEL
Clock And Date
By selecting the item "clock and date," you can
adjust the clock.
Possible options are:
Set Time: Adjust hours/minutes.
Set Format: Adjust the time format "12h"
(12 hours) or "24h" (24 hours).
Set Date: Adjust day/month/year.
Security
By selecting the item “Security,” you can make
the following adjustments:
Speed Warning: Set the vehicle speed limit
(mph or km/h), which the driver is notified
through a visual and acoustic signaling
(display of a message and a symbol on the
display).
Seat Belt Buzzer: This function is only view-
able when the Seat Belt Reminder (SBR)
system is active.
Hill Start Assist: Activation/Deactivation of
the Hill Start Assist system.
Safety And Assistance
By selecting the item "Safety & Assistance," you
can make the following adjustments:
Full Brake Control: A selection of operating
modes of the Full Brake Control system.
Full Brake Control Sensitivity: A selection of
the "readiness" of intervention of the Full
Brake Control system, based on the distance
to the obstacle.
Park Assist: A selection of the type of informa-
tion provided by Park Assist.
Park Assist Vol.: A selection of the volume of
acoustic signals provided by Park Assist.
Rain Sensing Wipers: Enabling/disabling the
automatic operation of wipers in the event of
rain.
LaneSense Warning — If Equipped: A selec-
tion of the "readiness" of intervention of
LaneSense.
Warning Buzzer Volume: Increase or
decrease the volume of the buzzer by
selecting “Low”, “Medium”, or “High”.
Maintenance Brakes — If Equipped: Activa-
tion of the procedure to carry out braking
system maintenance.
Auto Park Brake — If Equipped: Enable/
disable auto-insertion of the Electric Parking
Brake.
Lights
By selecting the item "Lights," you can make the
following adjustments:
Headlight Off Delay: Set the delay for head-
light shutoff after engine shutoff.
Headlight Sensitivity: Adjust the sensitivity of
headlight brightness.
Interior Ambient Lights: Increase or decrease
the brightness of the Interior Ambient Lights.
Greeting Lights: Enable/disable the vehicle’s
Greeting Lights.
Auto High Beam: Activate/deactivate the
automatic main beam headlights — If
Equipped.
Page 75
GETTING TO KNOW YOUR INSTRUMENT PANEL 73
Daytime Lights: Activate/deactivate the
daytime running lights.
Cornering Lights: Activate/deactivate the
cornering lights — If Equipped.
Doors And Locks
By selecting the item "Doors & Locks," you can
make the following adjustments:
Auto Door Lock: Activate/deactivate the
automatic locking of the doors with the
vehicle moving.
Auto Unlock On Exit: Automatic unlocking of
the doors when exiting the vehicle.
Flash Light With Lock: Activate the direction
indicators when closing the doors.
Sound Horn With Lock: Activate/deactivate
the horn when pushing the lock button on the
Remote Keyless Entry. The options are "Off,"
"First Press,” and "Second Press."
Horn With Remote Start: Activate/deactivate
the horn at the Remote Starting of the engine
with the Remote Keyless Entry.
Remote Door Unlock Without Passive Entry:
Allows you to choose whether to unlock all
the doors or only the driver’s side door on the
first push of the unlock button on the Remote
Keyless Entry.
Door Unlock With Passive Entry: Allows you to
open the driver door only on the first push of
the unlock button on the Remote Keyless
Entry or using the passive entry handles on
the doors or liftgates.
Passive Entry — If Equipped: Activate the
automatic locking of the doors.
Engine OFF Procedure — If Equipped: Allows
you to turn off the engine from the instrument
cluster in the event of an ignition switch
failure. Instructions for turning off the engine
via the instrument cluster display controls
will display in the instrument cluster.
Stop/Start — If Equipped
Automatically stops the engine during a vehicle
stop under the right conditions to reduce fuel
consumption.
Push and release the up or down arrow
button until the Stop/Start menu title is
displayed in the instrument cluster. This menu
shows messages related to Stop/Start. Only
one message can be viewed at a time until the
condition is cleared.
When the Stop/Start is engaged (and the
engine is off), the associated hardware
indicator light is turned on. When the Stop/Start
button on the central stack is pushed, a Stop/
Start status message will appear in the
instrument cluster display.
WARNING LIGHTS AND MESSAGES
The warning/indicator lights will illuminate in
the instrument panel together with a dedicated
message and/or acoustic signal when
applicable. These indications are indicative and
precautionary and as such must not be
considered as exhaustive and/or alternative to
the information contained in the Owner’s
Manual, which you are advised to read carefully
in all cases. Always refer to the information in
this chapter in the event of a failure indication.
All active telltales will display first if applicable.
The system check menu may appear different
based upon equipment options and current
vehicle status. Some telltales are optional and
may not appear.
3
Page 76
74 GETTING TO KNOW YOUR INSTRUMENT PANEL
RED WARNING LIGHTS
Air Bag Warning Light
This warning light will illuminate to
indicate a fault with the air bag, and
will turn on for four to eight seconds
as a bulb check when the ignition is
placed in the ON/RUN or ACC/ON/RUN
position. This light will illuminate with a single
chime when a fault with the air bag has been
detected, it will stay on until the fault is cleared.
If the light is either not on during startup, stays
on, or turns on while driving, have the system
inspected at an authorized dealer as soon as
possible.
Brake Warning Light
This warning light monitors various
brake functions, including brake fluid
level and parking brake application. If
the brake light turns on it may
indicate that the parking brake is applied, that
the brake fluid level is low, or that there is a
problem with the Anti-Lock Brake System
reservoir.
If the light remains on when the parking brake
has been disengaged, and the fluid level is at
the full mark on the master cylinder reservoir, it
indicates a possible brake hydraulic system
malfunction or that a problem with the Brake
Booster has been detected by the Anti-Lock
Brake System (ABS) / Electronic Stability
Control (ESC) system. In this case, the light will
remain on until the condition has been
corrected. If the problem is related to the brake
booster, the ABS pump will run when applying
the brake, and a brake pedal pulsation may be
felt during each stop.
The dual brake system provides a reserve
braking capacity in the event of a failure to a
portion of the hydraulic system. A leak in either
half of the dual brake system is indicated by the
Brake Warning Light, which will turn on when
the brake fluid level in the master cylinder has
dropped below a specified level.
The light will remain on until the cause is
corrected.
NOTE:
The light may flash momentarily during sharp
cornering maneuvers, which change fluid level
conditions. The vehicle should have service
performed, and the brake fluid level checked.
If brake failure is indicated, immediate repair is
necessary.
WARNING!
Driving a vehicle with the red brake light on is
dangerous. Part of the brake system may
have failed. It will take longer to stop the
vehicle. You could have a collision. Have the
vehicle checked immediately.
Vehicles equipped with the Anti-Lock Brake
System (ABS) are also equipped with Electronic
Brake Force Distribution (EBD). In the event of
an EBD failure, the Brake Warning Light will turn
on along with the ABS Light. Immediate repair to
the ABS system is required.
Operation of the Brake Warning Light can be
checked by turning the ignition switch from the
OFF position to the ON/RUN position. The light
should illuminate for approximately two
seconds. The light should then turn off unless
the parking brake is applied or a brake fault is
detected. If the light does not illuminate, have
the light inspected by an authorized dealer.
The light also will turn on when the parking
brake is applied with the ignition switch in the
ON/RUN position.
Page 77
GETTING TO KNOW YOUR INSTRUMENT PANEL 75
NOTE:
This light shows only that the parking brake is
applied. It does not show the degree of brake
application.
Battery Charge Warning Light
This warning light will illuminate when
the battery is not charging properly. If
it stays on while the engine is running,
there may be a malfunction with the
charging system. Contact an authorized dealer
as soon as possible.
This indicates a possible problem with the
electrical system or a related component.
Coolant Temperature Warning Light
This light warns of an overheated
engine condition. If the light turns on
while driving, safely pull over and stop
the vehicle. If the Air Conditioning
(A/C) system is on, turn it off. Also, shift the
transmission into NEUTRAL and idle the vehicle.
If the temperature reading does not return to
normal, turn the engine off immediately and call
for service.
NOTE:
As the coolant temperature gauge approaches
"H," this indicator will illuminate and a single
chime will sound.
Door Open Warning Light
This indicator will illuminate when one
or more door(s) are not fully closed.
NOTE:
If the vehicle is moving and a door is opened,
there will also be a single chime.
Electric Power Steering (EPS) Fault Warning Light
This warning light will turn on when
there's a fault with the EPS system
Ú page 97.
WARNING!
Continued operation with reduced assist
could pose a safety risk to yourself and
others. Service should be obtained as soon
as possible.
Electronic Throttle Control (ETC) Warning Light
This warning light will illuminate to
indicate a problem with the ETC
system. If a problem is detected while
the vehicle is running, the light will
either stay on or flash depending on the nature
of the problem. Cycle the ignition when the
vehicle is safely and completely stopped and
the transmission is placed in the PARK position.
The light should turn off. If the light remains on
with the vehicle running, your vehicle will
usually be drivable; however, see an authorized
dealer for service as soon as possible.
NOTE:
This light may turn on if the accelerator and
brake pedals are pressed at the same time.
If the light continues to flash when the vehicle is
running, immediate service is required and you
may experience reduced performance, an
elevated/rough idle, or engine stall and your
vehicle may require towing. The light will come
on when the ignition is placed in the ON/RUN or
ACC/ON/RUN position and remain on briefly as
a bulb check. If the light does not come on
during starting, have the system checked by an
authorized dealer.
3
Page 78
76 GETTING TO KNOW YOUR INSTRUMENT PANEL
Hood Open Warning Light — If Equipped
This warning light will illuminate when
the hood is left open and not fully
closed.
Oil Pressure Warning Light
This warning light will illuminate to
indicate low engine oil pressure. If the
light turns on while driving, stop the
vehicle, shut off the engine as soon as
possible, and contact an authorized dealer. A
chime will sound when this light turns on.
Do not operate the vehicle until the cause is
corrected. This light does not indicate how
much oil is in the engine. The engine oil level
must be checked under the hood.
Seat Belt Reminder Warning Light
This warning light indicates when the
driver or passenger seat belt is
unbuckled. When the ignition is first
placed in the ON/RUN or ACC/ON/
RUN position and if the driver’s seat belt is
unbuckled, a chime will sound and the light will
turn on. When driving, if the driver or front
passenger seat belt remains unbuckled, the
Seat Belt Reminder Light will flash or remain on
continuously and a chime will sound
Ú page 204.
Transmission Fault Warning Light
This light will illuminate (together with
a message in the instrument cluster
display and a buzzer) to indicate a
transmission fault. Contact an
authorized dealer if the message remains after
restarting the engine.
Vehicle Security Warning Light — If Equipped
This light will flash at a fast rate for
approximately 15 seconds when the
vehicle security alarm is arming, and
then will flash slowly until the vehicle
is disarmed.
Trunk Open Warning Light
This indicator will illuminate when the
trunk is open and not fully closed.
YELLOW WARNING LIGHTS
Adaptive Cruise Control (ACC) Fault Warning Light — If Equipped
This warning light will illuminate to
indicate a fault in the ACC system.
Contact a local authorized dealer for
service Ú page 102.
Anti-Lock Brake System (ABS) Warning Light
This warning light monitors the ABS.
The light will turn on when the ignition
is placed in the ON/RUN or ACC/ON/
RUN position and may stay on for as
long as four seconds.
If the ABS light remains on or turns on while
driving, then the Anti-Lock portion of the brake
system is not functioning and service is
required as soon as possible. However, the
conventional brake system will continue to
operate normally, assuming the Brake Warning
Light is not also on.
If the ABS light does not turn on when the
ignition is placed in the ON/RUN or ACC/ON/
RUN position, have the brake system inspected
by an authorized dealer.
Page 79
GETTING TO KNOW YOUR INSTRUMENT PANEL 77
Audio System Failure Light — If Equipped
This light will illuminate to report a
failure of the Audio System. Contact
an authorized dealership as soon as
possible.
Electronic Park Brake Warning Light
This warning light will illuminate to
indicate the Electronic Park Brake is
not functioning properly and service is
required. Contact an authorized
dealer.
Electronic Stability Control (ESC) Active Warning Light — If Equipped
This warning light will indicate when
the ESC system is Active. The ESC
Indicator Light in the instrument
cluster will come on when the ignition
is placed in the ON/RUN or ACC/ON/RUN
position, and when ESC is activated. It should
go out with the engine running. If the ESC
Indicator Light comes on continuously with the
engine running, a malfunction has been
detected in the ESC system. If this warning light
remains on after several ignition cycles, and the
vehicle has been driven several miles
(kilometers) at speeds greater than 30 mph
(48 km/h), see an authorized dealer as soon as
possible to have the problem diagnosed and
corrected.
The ESC OFF Indicator Light and the ESC Indi-
cator Light come on momentarily each time
the ignition is placed in the ON/RUN or ACC/
ON/RUN position.
The ESC system will make buzzing or clicking
sounds when it is active. This is normal; the
sounds will stop when ESC becomes inactive.
This light will come on when the vehicle is in
an ESC event.
Electronic Stability Control (ESC) OFF Warning Light — If Equipped
This warning light indicates the ESC is
off.
Each time the ignition is turned to ON/RUN or
ACC/ON/RUN, the ESC system will be on, even
if it was turned off previously.
Drive Mode System Overheating
This symbol appears, together with a
dedicated message on the display, in
case of overheating of the Drive Mode
Selector system. In these conditions,
the Drive Mode Selector system can still be
used to select the required driving mode, but
the mode will be engaged only when the system
cools down.
The symbol will stay on for as long as the
overheating condition persists.
External Light Failure Indicator Light — If Equipped
The External Light Failure Indicator
will come on when a failure to one of
the following lights is detected:
Direction Indicators
Backup Lights
Parking Lights
Daytime Running Lights
License Plate Lights
The failure relating to these lights could be:
One or more blown bulbs
A blown protection fuse
A break in the electrical connection
3
Page 80
78 GETTING TO KNOW YOUR INSTRUMENT PANEL
Loose Fuel Filler Cap Warning Light — If Equipped
This warning light will illuminate when
the fuel filler cap is loose. Properly
close the filler cap to disengage the
light. If the light does not turn off,
please see an authorized dealer.
Low Fuel Warning Light
When the fuel level reaches
approximately 1.3–1.8 gal (5–7 L)
this light will turn on, and remain on
until fuel is added.
LaneSense Warning Light — If Equipped
The LaneSense Warning Light will be
solid yellow when the vehicle is
approaching a lane marker. The
warning light will flash when the
vehicle is crossing the lane marker
Ú page 117.
Service LaneSense Warning Light — If Equipped
This warning light will illuminate when
the LaneSense system is not
operating and requires service.
Please see an authorized dealer.
Engine Check/Malfunction Indicator Warning Light (MIL)
The Engine Check/Malfunction
Indicator Light (MIL) is a part of an
Onboard Diagnostic System called
OBD II that monitors engine and
automatic transmission control systems. This
warning light will illuminate when the ignition is
in the ON/RUN position before engine start. If
the bulb does not come on when turning the
ignition switch from OFF to ON/RUN, have the
condition checked promptly.
Certain conditions, such as a loose or missing
gas cap, poor quality fuel, etc., may illuminate
the light after engine start. The vehicle should
be serviced if the light stays on through several
typical driving styles. In most situations, the
vehicle will drive normally and will not require
towing.
When the engine is running, the MIL may flash
to alert serious conditions that could lead to
immediate loss of power or severe catalytic
converter damage. The vehicle should be
serviced by an authorized dealer as soon as
possible if this occurs.
WARNING!
A malfunctioning catalytic converter, as
referenced above, can reach higher
temperatures than in normal operating
conditions. This can cause a fire if you drive
slowly or park over flammable substances
such as dry plants, wood, cardboard, etc. This
could result in death or serious injury to the
driver, occupants or others.
CAUTION!
Prolonged driving with the Malfunction
Indicator Light (MIL) on could cause damage
to the vehicle control system. It also could
affect fuel economy and driveability. If the
MIL is flashing, severe catalytic converter
damage and power loss will soon occur.
Immediate service is required.
Service Warning Light — If Equipped
The “Maintenance Plan” includes
vehicle maintenance at fixed
intervals. For further information
Ú
page 254. This message is
displayed automatically along with the warning
Page 81
GETTING TO KNOW YOUR INSTRUMENT PANEL 79
light when the key is turned to RUN - 1,242 miles
(2,000 km) or 30 days before these deadlines,
and reappears every time the key is turned to
RUN. The indication will appear in miles or
kilometers according to the "Unit Of
Measurement" settings. When the next
scheduled service is approaching and the key is
turned to RUN, the word “Service” will appear on
the display, followed by the number of miles or
kilometers left. Contact an authorized
dealership. The operations in the “Maintenance
Plan” will be performed and the message will be
reset.
Service Stop / Start System Warning Light — If Equipped
This warning light will illuminate when
the Stop/Start system is not
functioning properly and service is
required. Contact an authorized
dealer for service.
Tire Pressure Monitoring System (TPMS) Warning Light
The warning light switches on and a
message is displayed to indicate that
the tire pressure is lower than the
recommended value and/or that slow
pressure loss is occurring. In these cases,
optimal tire duration and fuel consumption may
not be guaranteed.
Should one or more tires be in the condition
mentioned above, the display will show the
indications corresponding to each tire.
CAUTION!
Do not continue driving with one or more flat
tires as handling may be compromised. Stop
the vehicle, avoiding sharp braking and
steering. If a tire puncture occurs, repair
immediately using the dedicated tire repair
kit and contact an authorized dealer as soon
as possible.
Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. If your
vehicle has tires of a different size than the size
indicated on the vehicle placard or tire inflation
pressure label, you should determine the
proper tire inflation pressure for those tires.
As an added safety feature, your vehicle has
been equipped with a TPMS that illuminates a
low tire pressure telltale when one or more of
your tires is significantly underinflated.
Accordingly, when the low tire pressure telltale
illuminates, you should stop and check your
tires as soon as possible, and inflate them to
the proper pressure. Driving on a significantly
underinflated tire causes the tire to overheat
and can lead to tire failure. Underinflation also
reduces fuel efficiency and tire tread life, and
may affect the vehicle’s handling and stopping
ability.
Please note that the TPMS is not a substitute for
proper tire maintenance, and it is the driver’s
responsibility to maintain correct tire pressure,
even if underinflation has not reached the level
to trigger illumination of the TPMS low tire
pressure telltale.
Your vehicle has also been equipped with a TPMS
malfunction indicator to indicate when the
system is not operating properly. The TPMS
malfunction indicator is combined with the low
tire pressure telltale. When the system detects a
malfunction, the telltale will flash for
approximately one minute and then remain
continuously illuminated. This sequence will
continue upon subsequent vehicle start-ups as
long as the malfunction exists. When the
3
Page 82
80 GETTING TO KNOW YOUR INSTRUMENT PANEL
malfunction indicator is illuminated, the system
may not be able to detect or signal low tire
pressure as intended. TPMS malfunctions may
occur for a variety of reasons, including the
installation of replacement or alternate tires or
wheels on the vehicle that prevent the TPMS from
functioning properly. Always check the TPMS
malfunction telltale after replacing one or more
tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow
the TPMS to continue to function properly.
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures
and warning have been established for the tire
size equipped on your vehicle. Undesirable system operation or sensor damage may result
when using replacement equipment that is not
of the same size, type, and/or style. Aftermarket wheels can cause sensor damage. Using
aftermarket tire sealants may cause the Tire
Pressure Monitoring System (TPMS) sensor to
become inoperable. After using an aftermarket
tire sealant it is recommended that you take
your vehicle to an authorized dealer to have
your sensor function checked.
Transmission Temperature Warning Light
This light indicates that the
transmission fluid temperature is
running hot. This may occur with
severe usage, such as trailer towing. If
this light turns on, safely pull over and stop the
vehicle. Then, shift the transmission into PARK
and run the engine at idle or slightly higher until
the light turns off.
WARNING!
If you continue operating the vehicle when
the Transmission Temperature Warning Light
is illuminated you could cause the fluid to boil
over, come in contact with hot engine or
exhaust components and cause a fire.
CAUTION!
Continuous driving with the Transmission
Temperature Warning Light illuminated will
eventually cause severe transmission
damage or transmission failure.
YELLOW INDICATOR LIGHTS
Exterior Bulb Failure Indicator Light — If Equipped
This light will illuminate when there is
a malfunction in one of the exterior
bulbs.
Full Brake Control System Indicator Light — If Equipped
This telltale will turn on to warn you of
a possible collision with the vehicle in
front of you.
Full Brake Control System Off Indicator Light — If Equipped
This indicator light illuminates to
indicate that the Full Brake Control
System is off.
Fuel Cutoff Failure Light — If Equipped
This light will illuminate if there is a
fuel cutoff failure. If this light
illuminates, take it to an authorized
dealer and have them inspect it.
Page 83
GETTING TO KNOW YOUR INSTRUMENT PANEL 81
Fuel Cutoff Indicator Light — If Equipped
This telltale will illuminate after an
accident has occurred, and the
system has shut the fuel off.
Fuel Level Sensor Failure
This light illuminates when there is a
fuel level sensor failure. If this light
illuminates, take it to an authorized
dealer and have them inspect it.
Icy Road Condition Indicator Light — If Equipped
This light will illuminate during an icy
road condition.
Immobilizer Fail / VPS Electrical Alarm Indicator Light
This telltale will illuminate when the
vehicle security alarm system has
detected an attempt to break into the
vehicle.
NOTE:
After cycling the ignition to the ON/RUN position, the Vehicle Security Warning Light could
illuminate if a problem with the system is
detected. This condition will result in the engine
being shut off after two seconds.
GREEN INDICATOR LIGHTS
Cruise Control Set Indicator Light
This light will turn on when the cruise
control is set to the desired speed
Ú page 100.
Front Fog Indicator Light — If Equipped
This indicator light will illuminate
when the front fog lights are on.
LaneSense Indicator Light — If Equipped
The LaneSense indicator light
illuminates solid green when both
lane markings have been detected
and the system is “armed” and ready
to provide visual and torque warnings if an
unintentional lane departure occurs
Ú page 117.
Park / Headlight On Indicator Light
This indicator light will illuminate
when the park lights or headlights are
turned on.
Stop/Start Active Indicator Light — If Equipped
This indicator light will illuminate
when the Stop/Start function is in
“Autostop” mode.
Turn Signal Indicator Lights
When the left or right turn signal is
activated, the turn signal indicator will
flash independently and the
corresponding exterior turn signal
lamps will flash. Turn signals can be activated
when the multifunction lever is moved down
(left) or up (right).
NOTE:
A continuous chime will sound if the vehicle is
driven more than 1 mile (1.6 km) with either
turn signal on.
Check for an inoperative outside light bulb if
either indicator flashes at a rapid rate.
WHITE INDICATOR LIGHTS
LaneSense Indicator Light — If Equipped
When the LaneSense system is ON,
but not armed, the LaneSense
indicator light illuminates solid white.
3
Page 84
82 GETTING TO KNOW YOUR INSTRUMENT PANEL
This occurs when only left, right, or neither lane
line has been detected. If a single lane line is
detected, the system is ready to provide only
visual warnings if an unintentional lane
departure occurs on the detected lane line
Ú page 117.
Light Sensor Failure
This light illuminates when there is
light sensor failure. If this light
illuminates, have an authorized
dealer inspect it.
Speed Warning Indicator Light — If Equipped
The indicator light will illuminate white
along with a notification text message
(Speed Warning Set to XX followed by
unit). When the set speed is
exceeded, a single chime will sound along with
pop up message of “Speed Warning Exceeded.”
Speed Warning can be turned on and off in the
instrument cluster display.
The number “55” is only an example of a speed
that can be set.
BLUE INDICATOR LIGHTS
High Beam Indicator Light
This indicator light will illuminate to
indicate that the high beam
headlights are on. With the low beams
activated, push the multifunction
lever forward (toward the front of the vehicle) to
turn on the high beams. Pull the multifunction
lever rearward (toward the rear of the vehicle) to
turn off the high beams. If the high beams are
off, pull the lever toward you for a temporary
high beam on, "flash to pass" scenario.
GRAY INDICATOR LIGHTS
Cruise Control Ready/Canceled Indicator Light
This light will turn on when the cruise
control has been turned on, but not
set, or canceled by the driver
Ú page 100.
ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated
Onboard Diagnostic system called OBD II. This
system monitors the performance of the
emissions, engine, and transmission control
systems. When these systems are operating
properly, your vehicle will provide excellent
performance and fuel economy, as well as
engine emissions well within current
government regulations.
If any of these systems require service, the
OBD II system will turn on the Malfunction
Indicator Light (MIL). It will also store diagnostic
codes and other information to assist your
service technician in making repairs. Although
your vehicle will usually be drivable and not
need towing, see an authorized dealer for
service as soon as possible.
CAUTION!
Prolonged driving with the MIL on could
cause further damage to the emission
control system. It could also affect fuel
economy and driveability. The vehicle must
be serviced before any emissions tests can
be performed.
If the MIL is flashing while the vehicle is
running, severe catalytic converter damage
and power loss will soon occur. Immediate
service is required.
Page 85
GETTING TO KNOW YOUR INSTRUMENT PANEL 83
ONBOARD DIAGNOSTIC SYSTEM (OBD II)
YBERSECURITY
C
Your vehicle is required to have an OBD II and a
connection port to allow access to information
related to the performance of your emissions
controls. Authorized service technicians may
need to access this information to assist with
the diagnosis and service of your vehicle and
emissions system Ú page 133.
WARNING!
ONLY an authorized service technician
should connect equipment to the OBD II
connection port in order to read the VIN,
diagnose, or service your vehicle.
If unauthorized equipment is connected to
the OBD II connection port, such as a
driver-behavior tracking device, it may:
Be possible that vehicle systems,
including safety related systems, could
be impaired or a loss of vehicle control
could occur that may result in an accident involving serious injury or death.
Access, or allow others to access, infor-
mation stored in your vehicle systems,
including personal information.
EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS
In some localities, it may be a legal requirement
to pass an inspection of your vehicle's
emissions control system. Failure to pass could
prevent vehicle registration.
For states that require an Inspection
and Maintenance (I/M), this check
verifies the Malfunction Indicator
Light (MIL) is functioning and is not on
when the engine is running, and that the OBD II
system is ready for testing.
Normally, the OBD II system will be ready. The
OBD II system may not be ready if your vehicle
was recently serviced, recently had a depleted
battery or a battery replacement. If the OBD II
system should be determined not ready for the
I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition actuated test,
which you can use prior to going to the test
station. To check if your vehicle's OBD II system
is ready, you must do the following:
1. Cycle the ignition switch to the ON position,
but do not crank or start the engine.
NOTE:
If you crank or start the engine, you will have to
start this test over.
2. As soon as you cycle the ignition switch to
the ON position, you will see the
Malfunction Indicator Light (MIL) symbol
come on as part of a normal bulb check.
3. Approximately 15 seconds later, one of two
things will happen:
The MIL will flash for about 10 seconds
and then return to being fully illuminated
until you turn OFF the ignition or start the
engine. This means that your vehicle's
OBD II system is not ready and you
should not proceed to the I/M station.
The MIL will not flash at all and will
remain fully illuminated until you place
the ignition in the off position or start the
engine. This means that your vehicle's
OBD II system is ready and you can
proceed to the I/M station.
3
Page 86
84 GETTING TO KNOW YOUR INSTRUMENT PANEL
If your OBD II system is not ready, you should
see an authorized dealer or repair facility. If your
vehicle was recently serviced or had a battery
failure or replacement, you may need to do
nothing more than drive your vehicle as you
normally would in order for your OBD II system
to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle's OBD II
system is ready or not, if the MIL is illuminated
during normal vehicle operation you should
have your vehicle serviced before going to the
I/M station. The I/M station can fail your vehicle
because the MIL is on with the engine running.
Page 87
STARTING AND OPERATING
85
STARTING THE ENGINE
Before starting your vehicle, adjust your seat,
adjust the inside and outside mirrors, fasten
your seat belt, and if present, instruct all other
occupants to buckle their seat belts.
WARNING!
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
Allowing children to be in a vehicle unat-
tended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the gear selector.
Do not leave the key fob in or near the
vehicle (or in a location accessible to children), and do not leave the ignition in the
ON or RUN mode. A child could operate
power windows, other controls, or move the
vehicle.
Start the engine with the gear selector in the
NEUTRAL or PARK position. Apply the brake
before shifting to any driving range.
Proceed as follows:
1. Set the Electric Park Brake (EPB) and put
the gear selector in the PARK or NEUTRAL
position.
2. Press on the brake pedal, without pressing
the accelerator.
3. Place the ignition in the START mode and
release it as soon as the engine is started.
4. If the engine does not start, place the
ignition in the OFF mode and wait 10-15
seconds before attempting to restart the
engine.
TIP START FEATURE
Do not press the accelerator. Place the ignition
switch briefly in the START mode and release it.
The starter motor will continue to run but will
automatically disengage when the engine is
running.
IF ENGINE FAILS TO START
If the engine fails to start after you have
followed the "Normal Starting" or "Cold Weather
Operation" procedure, and has not experienced
an extended park condition as identified in
"Extended Park Starting" procedure it may be
flooded. Push the accelerator pedal all the way
to the floor and hold it there. Crank the engine
for no more than 15 seconds. This should clear
any excess fuel in case the engine is flooded.
Leave the ignition in RUN mode, release the
accelerator pedal and repeat the “Normal
Starting” procedure.
WARNING!
Never pour fuel or other flammable liquid
into the throttle body air inlet opening in an
attempt to start the vehicle. This could
result in flash fire causing serious personal
injury.
(Continued)
4
Page 88
86 STARTING AND OPERATING
WARNING! (Continued)
Do not attempt to push or tow your vehicle
to get it started. Vehicles equipped with an
automatic transmission cannot be started
this way. Unburned fuel could enter the
catalytic converter and once the engine has
started, ignite and damage the converter
and vehicle.
If the vehicle has a discharged battery,
booster cables may be used to obtain a
start from a booster battery or the battery in
another vehicle. This type of start can be
dangerous if done improperly Ú page 246.
CAUTION!
To prevent damage to the starter, do not
continuously crank the engine for more than
25 seconds at a time. Wait 60 seconds
before trying again.
COLD WEATHER OPERATION
To ensure reliable starting under extreme cold
conditions an externally powered electric block
heater (if equipped) is required below -20°F
(-29°C).
To prevent possible engine damage while
starting at low temperatures, this vehicle will
inhibit engine cranking when the ambient
temperature is less than -20°F (-29°C), and the
oil temperature sensor reading indicates an
engine block heater has not been used. The
message “Plug in Engine Heater” will be
displayed in the instrument cluster when the
ambient temperature is below -4°F (-20°C) at
the time the engine is shut off as a reminder to
avoid possible crank delays at the next cold
start.
EXTENDED PARK STARTING
NOTE:
Extended Park condition occurs when the
vehicle has not been started or driven for at
least 30 days.
1. Install a battery charger or jumper cables
to the battery to ensure a full battery
charge during the crank cycle.
2. Place the ignition in the START mode and
release it when the engine starts.
3. If the engine fails to start within 10 to 15
seconds, place the ignition in the OFF mode,
wait 5 seconds to allow the starter to cool,
then repeat the Extended Park Starting
procedure.
4. If the engine fails to start after 8 attempts,
allow the starter to cool for at least
10 minutes, then repeat the procedure.
CAUTION!
To prevent damage to the starter, do not
crank continuously for more than 10 seconds
at a time. Wait 10 to 15 seconds before trying
again.
AFTER STARTING — WARMING UP THE
NGINE
E
Proceed as follows:
Travel slowly, letting the engine run at a
reduced RPM, without accelerating suddenly.
It is recommended to wait until the engine
coolant temperature gauge starts to rise for
maximum performance.
STOPPING THE ENGINE
To shut off the engine with vehicle speed
greater than 5 mph (8 km/h), you must push
and hold the ignition or push the ENGINE
Page 89
STARTING AND OPERATING 87
START/STOP button three times consecutively
within a few seconds. The engine will shut
down, and the ignition will be placed in the RUN
position.
Turning off the car (place the ignition from the
RUN mode to the OFF mode), the power supply
to the accessories are maintained for a period
of three minutes.
NOTE:
If the vehicle fails to shut off using the ignition
Ú page 67.
Opening the driver side door with the ignition in
RUN will sound a short chime that reminds the
driver to place the ignition to OFF.
When the ignition is in the OFF mode, the
window switches remains active for three
minutes. Opening a front door will cancel this
function.
After severe driving, idle the engine to allow the
temperature inside the engine compartment to
cool before shutting off the engine.
TURBOCHARGER “COOL DOWN ” — IF
QUIPPED
E
This vehicle is equipped with an after-run pump
to cool the turbocharger after the engine is shut
off. Depending on the type of driving and the
amount of cargo, the pump will run for up to
10 minutes after the engine has been shut off
to circulate coolant through the turbocharger.
Although the pump is rubber-mounted for quiet
operation, it is normal to hear it running during
this time.
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the
engine and drivetrain (transmission and axle) in
your vehicle.
Drive moderately during the first 300 miles
(500 km). After the initial 60 miles (100 km),
speeds up to 50 or 55 mph (80 or 90 km/h) are
desirable.
While cruising, brief full-throttle acceleration
within the limits of local traffic laws contributes
to a good break-in. Wide-open throttle
acceleration in low gear can be detrimental and
should be avoided.
The engine oil installed in the engine at the
factory is a high-quality energy conserving type
lubricant. Oil changes should be consistent with
anticipated climate conditions under which
vehicle operations will occur. For the
recommended viscosity and quality grades
Ú page 314.
CAUTION!
Never use Non-Detergent Oil or Straight
Mineral Oil in the engine or damage may
result.
NOTE:
A new engine may consume some oil during its
first few thousand miles (kilometers) of operation. This should be considered a normal part of
the break-in and not interpreted as a problem.
ELECTRIC PARK BRAKE (EPB)
Your vehicle is equipped with an EPB that offers
simple operation, and some additional features
that make the parking brake more convenient
and useful.
The parking brake is primarily intended to
prevent the vehicle from rolling while parked.
Before leaving the vehicle, make sure that the
parking brake is applied. Also, be certain to
leave the transmission in PARK.
4
Page 90
88 STARTING AND OPERATING
The EPB switch is located in the center console.
You can engage the EPB in two ways;
Manually, by pulling up on the EPB switch
momentarily to apply.
Automatically, by enabling the Auto Park
Brake feature in the Customer Programmable Features section of the Uconnect
Settings.
Electric Park Brake Switch
To apply the EPB manually, pull up on the switch
momentarily. You may hear a sound from the
back of the vehicle while the EPB engages.
Once the parking brake is fully engaged, the
Brake Warning Light in the instrument cluster
and an indicator on the switch will illuminate. If
your foot is on the brake pedal while you apply
the EPB, you may notice a small amount of
brake pedal movement. The EPB can be applied
even when the ignition is in the OFF mode
however, it can only be released when the
ignition is in the RUN mode.
NOTE:
The EPB fault lamp will illuminate if the EPB
switch is held for longer than 60 seconds in
either the released or applied position. The light
will extinguish upon releasing the switch.
If the Auto Park Brake feature is enabled, the
EPB will automatically engage whenever the
transmission is moved into PARK when the
ignition switch is in the STOP/OFF position. If
your foot is on the brake pedal, you may notice
a small amount of brake pedal movement while
the EPB is engaging.
The EPB will be automatically released if the
driver’s seat belt is buckled (in case of
automatic transmission) and driver's intention
to start (in forward or reverse direction) is
recognized by the system
To release the EPB manually, the ignition must
be in the RUN mode. Put your foot on the brake
pedal, then push the EPB switch down
momentarily. You may hear a sound from the
back of the car while the parking brake
disengages. You may also notice a small
amount of movement in the brake pedal. Once
the EPB is fully disengaged, the Brake Warning
Light in the instrument cluster and the LED
indicator on the switch will extinguish.
NOTE:
When parking on a hill, it is important to turn the
front wheels toward the curb on a downhill
grade and away from the curb on an uphill
grade. Apply the EPB before placing the gear
selector in PARK, otherwise the load on the
transmission locking mechanism may make it
difficult to move the gear selector out of PARK.
The EPB should always be applied whenever the
driver is not in the vehicle.
WARNING!
When exiting the vehicle, always remove
the key fob from the vehicle and lock your
vehicle.
(Continued)
Page 91
STARTING AND OPERATING 89
WARNING! (Continued)
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
Allowing children to be in a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the transmission gear
selector.
Do not leave the key fob in or near the
vehicle (or in a location accessible to children), and do not leave the ignition in the
ON or RUN mode. A child could operate
power windows, other controls, or move the
vehicle.
Be sure the parking brake is fully disen-
gaged before driving; failure to do so can
lead to brake failure and a collision.
Always fully apply the parking brake when
leaving your vehicle, or it may roll and
cause damage or injury. Also be certain to
leave the transmission in PARK. Failure to
do so may allow the vehicle to roll and
cause damage or injury.
CAUTION!
If the Brake System Warning Light remains on
with the parking brake released, a brake
system malfunction is indicated. Have the
brake system serviced by an authorized
dealer immediately.
If exceptional circumstances should make it
necessary to engage the EPB while the vehicle
is in motion, maintain upward pressure on the
EPB switch for as long as engagement is
desired. The brake warning lamp could
illuminate in case of the hydraulic system is not
available. The rear stop lamps will also be
illuminated automatically while the vehicle
remains in motion.
To disengage the EPB while the vehicle is in
motion, release the switch. If the vehicle is
brought to a complete stop using the EPB, when
the vehicle reaches approximately 1.9 mph
(3 km/h) the EPB will remain engaged.
WARNING!
Driving the vehicle with the parking brake
engaged, or repeated use of the parking
brake to slow the vehicle may cause serious
damage to the brake system. Be sure the
parking brake is fully disengaged before
driving; failure to do so can lead to brake
failure and a collision.
4
In the unlikely event of a malfunction of the EPB
system, a yellow EPB fault lamp will illuminate.
This may be accompanied by the Brake Warning
Light flashing. In this status, some EPB
functionalities may be deactivated. In this
event, urgent service of the EPB system is
required. Do not rely on the EPB to hold the
vehicle stationary.
AUTO PARK BRAKE
The EPB can be programmed to be applied
automatically whenever the vehicle speed is
below 1.9 mph (3 km/h) and the automatic
transmission is placed in PARK whenever the
ignition is in the OFF mode. Auto Park Brake is
enabled and disabled by customer selection
through the Customer Programmable Features
section of the Uconnect Settings.
Page 92
90 STARTING AND OPERATING
Any single Auto Park Brake application can be
bypassed by pushing the EPB switch to the
release position while the transmission is
placed in PARK and the ignition is in the RUN
mode. In some cases, if the ignition is cycled
from ON/RUN to OFF and the gear selector is
not firmly locked in the PARK position, EPB
applies automatically even if Auto Park Brake
has been previously disabled.
SAFEHOLD
SafeHold is a safety feature of the EPB system
that will engage the parking brake automatically
if the vehicle is left unsecured while the ignition
switch is in the RUN mode.
The EPB will automatically engage if all of the
following conditions are met:
Vehicle speed is below 1.9 mph (3 km/h).
There is no attempt to press the brake pedal
or accelerator pedal.
The seat belt is unbuckled.
The driver door is open.
The vehicle is not in the PARK position.
SafeHold can be temporarily bypassed by
pushing the EPB switch while the driver door is
open and the brake pedal is pressed. Once
manually bypassed, SafeHold will be enabled
again once the vehicle reaches 12 mph
(20 km/h) or the ignition is cycled to the OFF
mode and back to RUN mode.
BRAKE SERVICE MODE
We recommend having your brakes serviced by
an authorized dealer. You should only make
repairs for which you have the knowledge and
the right equipment. You should only enter
Brake Service Mode during brake service.
When servicing your rear brakes, it may be
necessary for you or your technician to push the
rear piston into the rear caliper bore. With the
EPB system, this can only be done after
retracting the EPB actuator. The actuator
retraction can be done easily by entering the
Brake Service Mode. This menu based system
will guide you through the steps necessary to
retract the EPB actuator in order to perform rear
brake service.
Service Mode has requirements that must be
met in order to be activated:
The vehicle must be at a standstill.
The parking brake must be disabled.
The transmission must be in PARK or
NEUTRAL.
The EPB switch not activated.
The ignition is in the ON/RUN mode.
The brake pedal not pressed.
While in service mode, the EPB fault lamp will
flash continuously while the ignition is placed in
the ON position.
NOTE:
A dedicated message will appear in the instrument cluster if Brake Service Mode cannot be
activated.
When brake service work is complete, the
following steps must be followed to reset the
parking brake system to normal operation:
Ensure the vehicle is at a standstill.
Press the brake pedal with moderate force.
Apply the EPB switch.
Page 93
STARTING AND OPERATING 91
NOTE:
A dedicated message will appear in the instrument cluster if Brake Service Mode cannot be
deactivated.
WARNING!
You can be badly injured working on or
around a motor vehicle. Do only that service
work for which you have the knowledge and
the right equipment. If you have any doubt
about your ability to perform a service job,
take your vehicle to a competent mechanic.
AUTOMATIC TRANSMISSION
NOTE:
You must press and hold the brake pedal while
shifting out of PARK.
The transmission gear range (PRND) is
displayed both beside the gear selector and in
the instrument cluster. To select a gear range,
press the lock button on the gear selector and
move the lever rearward or forward. You must
also press the brake pedal to shift the
transmission out of PARK (or NEUTRAL, when
the vehicle is stopped or moving at low speeds).
Select the DRIVE range for normal driving.
WARNING!
It is dangerous to shift out of PARK or
NEUTRAL if the engine speed is higher than
idle speed. If your foot is not firmly pressing
the brake pedal, the vehicle could accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and your
foot is firmly pressing the brake pedal.
Unintended movement of a vehicle could
injure those in or near the vehicle. As with
all vehicles, you should never exit a vehicle
while the engine is running. Before exiting a
vehicle, always come to a complete stop,
then apply the parking brake, shift the
transmission into PARK, and turn the ignition OFF. When the ignition is in the OFF
mode, the transmission is locked in PARK,
securing the vehicle against unwanted
movement.
When exiting the vehicle, always make sure
the ignition is in the OFF mode, remove the
key fob from the vehicle, and lock the
vehicle.
(Continued)
WARNING! (Continued)
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
Allowing children to be in a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the transmission gear
selector.
Do not leave the key fob in or near the
vehicle (or in a location accessible to children), and do not leave the ignition in the
ON or RUN mode. A child could operate
power windows, other controls, or move the
vehicle.
CAUTION!
Shift into or out of PARK or REVERSE only
after the vehicle has come to a complete
stop.
Do not shift between PARK, REVERSE,
NEUTRAL, or DRIVE when the engine is
above idle speed.
(Continued)
4
Page 94
92 STARTING AND OPERATING
CAUTION! (Continued)
Before shifting into any gear, make sure
your foot is firmly pressing the brake pedal.
GEAR SELECTOR
The transmission gear selector has PARK,
REVERSE, NEUTRAL, DRIVE, and AutoStick (+/-)
shift positions. Manual shifts can be made
using the AutoStick shift control. Toggling the
gear selector forward (-) or rearward (+) while in
the AutoStick position (beside the DRIVE
position) will manually select the transmission
gear, and will display the current gear in the
instrument cluster as 1, 2, 3, etc.
NOTE:
If the gear selector cannot be moved to the
PARK, REVERSE, or NEUTRAL position (when
pushed forward) it is probably in the AutoStick
(+/-) position (beside the DRIVE position). In
AutoStick mode, the transmission gear (1, 2, 3,
etc.) is displayed in the instrument cluster.
Move the gear selector to the right (into the
DRIVE [D] position) for access to PARK,
REVERSE, and NEUTRAL.
The electronically-controlled transmission
adapts its shift schedule based on driver inputs,
along with environmental and road conditions.
The transmission electronics are
self-calibrating; therefore, the first few shifts on
a new vehicle may be somewhat abrupt. This is
a normal condition, and precision shifts will
develop within a few hundred miles
(kilometers).
The nine-speed transmission has been
developed to meet the needs of current and
future FWD/AWD vehicles. Software and
calibration is refined to optimize the customer’s
driving experience and fuel economy. By design,
some vehicle and driveline combinations utilize
9th gear only in very specific driving situations
and conditions.
Gear Selector Lock Button
Only shift from DRIVE to PARK or REVERSE
when the accelerator pedal is released and the
vehicle is stopped. Be sure to keep your foot on
the brake pedal when shifting between these
gears.
Do not press the accelerator pedal when
shifting from PARK or NEUTRAL into another
gear range.
CAUTION!
After selecting any gear range, wait a moment
to allow the selected gear to engage before
accelerating. This is especially important
when the engine is cold.
GEAR RANGES
PARK (P)
The engine can be started in this range. Never
attempt to use PARK while the vehicle is in
motion.
When parking on a hill, apply the EPB before
shifting the transmission to PARK, otherwise
the load on the transmission locking
mechanism may make it difficult to move the
gear selector out of PARK. As an added
Page 95
STARTING AND OPERATING 93
precaution, turn the front wheels toward the
curb on a downhill grade and away from the
curb on an uphill grade.
When exiting the vehicle, always:
Apply the parking brake.
Shift the transmission into PARK.
Turn the engine off.
Remove the key fob.
WARNING!
Never use the PARK position as a substi-
tute for the parking brake. Always apply the
parking brake fully when exiting the vehicle
to guard against vehicle movement and
possible injury or damage.
Your vehicle could move and injure you and
others if it is not in PARK. Check by trying to
move the transmission gear selector out of
PARK with the brake pedal released. Make
sure the transmission is in PARK before
exiting the vehicle.
(Continued)
WARNING! (Continued)
It is dangerous to shift out of PARK or
NEUTRAL if the engine speed is higher than
idle speed. If your foot is not firmly pressing
the brake pedal, the vehicle could accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and your
foot is firmly pressing the brake pedal.
Unintended movement of a vehicle could
injure those in or near the vehicle. As with
all vehicles, you should never exit a vehicle
while the engine is running. Before exiting a
vehicle, always come to a complete stop,
then apply the parking brake, shift the
transmission into PARK, and turn the ignition OFF. When the ignition is in the OFF
mode, the transmission is locked in PARK,
securing the vehicle against unwanted
movement.
When exiting the vehicle, always make sure
the ignition is in the OFF mode, remove the
key fob from the vehicle, and lock the
vehicle.
(Continued)
WARNING! (Continued)
Never leave children alone in a vehicle, or
with access to an unlocked vehicle.
Allowing children to be in a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously
or fatally injured. Children should be
warned not to touch the parking brake,
brake pedal or the transmission gear
selector.
Do not leave the key fob in or near the
vehicle (or in a location accessible to children), and do not leave the ignition in the
ON or RUN mode. A child could operate
power windows, other controls, or move the
vehicle.
CAUTION!
Before moving the transmission gear
selector out of PARK, you must turn the ignition to the ON/RUN mode, and also press
the brake pedal. Otherwise, damage to the
gear selector could result.
(Continued)
4
Page 96
94 STARTING AND OPERATING
CAUTION! (Continued)
DO NOT race the engine when shifting from
PARK or NEUTRAL into another gear range,
as this can damage the drivetrain.
The following indicators should be used to
ensure that you have properly engaged the
transmission into the PARK position:
When shifting into PARK, press the lock
button on the gear selector, and firmly move
the gear selector all the way forward until it
stops and is fully seated.
Look at the transmission gear position
display and verify that it indicates the PARK
position (P), and is not blinking.
With the brake pedal released, verify that the
gear selector will not move out of PARK.
REVERSE (R)
This range is for moving the vehicle backward.
Shift into REVERSE only after the vehicle has
come to a complete stop.
NEUTRAL (N)
Use this range when the vehicle is standing for
prolonged periods with the engine running. The
engine may be started in this range. Apply the
Electric Park Brake and shift the transmission
into PARK if you must exit the vehicle.
WARNING!
Do not coast in NEUTRAL and never turn off
the ignition to coast down a hill. These are
unsafe practices that limit your response to
changing traffic or road conditions. You might
lose control of the vehicle and have a
collision.
CAUTION!
Towing the vehicle, coasting, or driving for any
other reason with the transmission in
NEUTRAL can cause severe transmission
damage.
For Recreational Towing Ú page 130.
For Towing A Disabled Vehicle Ú page 251.
DRIVE (D)
This range should be used for most city and
highway driving. It provides the smoothest
upshifts and downshifts, and the best fuel
economy. The transmission automatically
upshifts through all forward gears.
When frequent transmission shifting occurs
(such as when operating the vehicle under
heavy loading conditions, in hilly terrain,
traveling into strong head winds or while towing
a heavy trailer), use the AutoStick shift control
to select a lower gear. Under these conditions,
using a lower gear will improve performance
and extend transmission life by reducing
excessive shifting and heat buildup.
If the transmission temperature exceeds
normal operating limits, the transmission
controller may modify the transmission shift
schedule, reduce engine torque, and/or expand
the range of torque converter clutch
engagement. This is done to prevent
transmission damage due to overheating.
If the transmission becomes extremely hot, the
“Transmission Temperature Warning Light”
may illuminate and the transmission may
operate differently until the transmission cools
down.
During cold temperatures, transmission
operation may be modified depending on
engine and transmission temperature as well
as vehicle speed. This feature improves warm
Page 97
STARTING AND OPERATING 95
up time of the engine and transmission to
achieve maximum efficiency. Engagement of
the torque converter clutch, and shifts into
EIGHTH or NINTH gear, are inhibited until the
transmission fluid is warm. Normal operation
will resume once the transmission temperature
has risen to a suitable level.
AutoStick
AutoStick is a driver-interactive transmission
feature providing manual shift control, giving
you more control of the vehicle. AutoStick
allows you to maximize engine braking,
eliminate undesirable upshifts and downshifts,
and improve overall vehicle performance. This
system can also provide you with more control
during passing, city driving, cold slippery
conditions, mountain driving, trailer towing and
many other situations.
Operation
When the gear selector is in the AutoStick
position (beside the DRIVE position), it can be
moved forward and rearward. This allows the
driver to manually select the transmission gear
being used. Moving the gear selector forward (-)
triggers a downshift, and rearward (+) an
upshift. The current gear is displayed in the
instrument cluster.
NOTE:
In AutoStick mode, the transmission will only
shift up or down when the driver moves the gear
selector rearward (+) or forward (-), except as
described below.
The transmission will automatically upshift
from FIRST to SECOND when necessary to
prevent engine overspeed.
The transmission will automatically down-
shift as the vehicle slows (to prevent engine
lugging) and will display the current gear.
The transmission will automatically down-
shift to FIRST or SECOND gear (depending on
model) when coming to a stop. After a stop,
the driver should manually upshift (+) the
transmission as the vehicle is accelerated.
You can start out (from a stop) in FIRST or
SECOND gear. Starting out in SECOND gear
can be helpful in snow or icy conditions. Tap
the gear selector forward or rearward to
select the desired gear after the vehicle is
brought to a stop.
If a requested downshift would cause the
engine to overspeed, that shift will not occur.
The system will ignore attempts to upshift at
too low of a vehicle speed.
Avoid using Cruise Control when AutoStick is
engaged because the transmission will not
shift automatically.
Transmission shifting will be more noticeable
when AutoStick is enabled.
The system may revert to automatic shift
mode if a fault or overheat condition is
detected.
To disengage AutoStick mode, return the gear
selector to the DRIVE position. You can shift in
or out of the AutoStick position at any time
without taking your foot off the accelerator
pedal.
WARNING!
Do not downshift for additional engine
braking on a slippery surface. The drive
wheels could lose their grip and the vehicle
could skid, causing a collision or personal
injury.
4
Page 98
96 STARTING AND OPERATING
TRANSMISSION LIMP HOME MODE
Transmission function is electronically
monitored for abnormal conditions. If a
condition is detected that could result in
transmission damage, Transmission Limp
Home Mode is activated. In this mode, the
transmission may operate only in a fixed gear,
or may remain in NEUTRAL. The Malfunction
Indicator Light (MIL) may be illuminated. Limp
Home Mode may allow the vehicle to be driven
to an authorized dealer for service without
damaging the transmission.
In the event of a momentary problem, the
transmission can be reset to regain all forward
gears by performing the following steps:
1. Stop the vehicle.
2. Shift the transmission into PARK.
3. Turn the ignition OFF.
4. Wait approximately 10 seconds.
5. Restart the engine.
6. Shift into the desired gear range. If the
problem is no longer detected, the
transmission will return to normal
operation.
NOTE:
Even if the transmission can be reset, we
recommend that you visit an authorized dealer
at your earliest possible convenience. An authorized dealer has diagnostic equipment to
assess the condition of your transmission. If the
transmission cannot be reset, authorized dealer
service is required.
IGNITION PARK INTERLOCK
This vehicle is equipped with an Ignition Park
Interlock, which requires the transmission to be
in PARK before the ignition can be turned to the
OFF mode. Also, the transmission is locked in
PARK whenever the ignition is in the OFF mode.
BRAKE TRANSMISSION SHIFT
NTERLOCK (BTSI) S YSTEM
I
This vehicle is equipped with a BTSI that holds
the transmission gear selector in PARK unless
the brakes are applied. To shift the
transmission out of PARK, the ignition must be
in the RUN mode (engine running or not) and
the brake pedal must be pressed.
The brake pedal must also be pressed before
pushing the button on the gear selector to shift
from NEUTRAL into DRIVE or REVERSE when the
vehicle is stopped or moving at low speeds.
ALL WHEEL DRIVE (AWD) — IF EQUIPPED
This feature provides on-demand All-Wheel
Drive (AWD). The system is automatic with no
driver inputs or additional driving skills
required. Under normal driving conditions, the
front wheels provide most of the traction. If the
front wheels begin to lose traction, power is
shifted automatically to the rear wheels. The
greater the front wheel traction loss, the greater
the power transfer to the rear wheels.
Additionally, on dry pavement under heavy
throttle input (where one may have no wheel
spin), torque will be sent to the rear in a
preemptive effort to improve vehicle launch and
performance characteristics.
CAUTION!
All wheels must have the same size and type
tires. Unequal tire sizes must not be used.
Unequal tire size may cause failure of the
power transfer unit.
Page 99
STARTING AND OPERATING 97
DYNAMIC SELECTOR — IF EQUIPPED
The Dynamic Selector combines the capabilities
of the vehicle control systems, along with driver
input, to provide the best performance in all
driving conditions.
Dynamic Selector Switch
The Dynamic Selector consists of the following
positions:
Auto Mode – This mode is designed for comfort
and safety in normal driving conditions. In
versions equipped with All-Wheel Drive, this
mode also reduces fuel consumption by
automatically altering the distribution of torque
between the front and rear axle.
All Weather Mode – This mode offers increased
traction control and stability control for low
traction conditions such as driving on a dirt road
or off-road as well as wet and slippery roads.
Sport Mode – This mode is designed to increase
steering feedback to the driver with a slight
increase in effort and changes the transmission
shift schedules for more aggressive shifting.
This driving mode is useful while driving on
twisty roads where more steering precision is
desired in spirited cornering.
WARNING MESSAGES
In the event of a system fault, the system
automatically defaults to “Auto” mode and a
message will appear in the instrument cluster
display.
For further information Ú page 67.
ELECTRIC POWER STEERING
The electric power steering system will provide
increased vehicle response and ease of
maneuverability. The power steering system
adapts to different driving conditions.
WARNING!
Continued operation with reduced assist
could pose a safety risk to yourself and
others. Service should be obtained as soon
as possible.
If the “SERVICE POWER STEERING” OR “POWER
STEERING ASSIST OFF - SERVICE SYSTEM”
message and a steering wheel icon are
displayed on the instrument cluster screen, it
indicates that the vehicle needs to be taken to
the dealer for service. It is likely the vehicle has
lost power steering assistance Ú page 67.
NOTE:
Even if the power steering assistance is no
longer operational, it is still possible to steer
the vehicle. Under these conditions there will
be a substantial increase in steering effort,
especially at low speeds and during parking
maneuvers.
If the condition persists, see an authorized
dealer for service.
4
Page 100
98 STARTING AND OPERATING
STOP/START SYSTEM
The Stop/Start function was developed to
reduce fuel consumption. The system will stop
the engine automatically during a vehicle stop if
the required conditions are met. Releasing the
brake pedal or pressing the accelerator pedal
will automatically restart the engine.
AUTOMATIC MODE
The Stop/Start feature is enabled after every
normal customer engine start. At that time, the
system will go into STOP/START READY and if all
other conditions are met, can go into a STOP/
START AUTOSTOP ACTIVE “Autostop” mode.
To Activate The Autostop Mode, The Following
Must Occur:
The system must be in STOP/START READY
state. A STOP/START READY message will be
displayed in the instrument cluster display
within the Stop/Start section Ú page 67.
The vehicle must be completely stopped.
The gear selector must be in a forward gear
and the brake pedal pressed.
The engine will shut down, the tachometer will
move to the zero position and the Stop/Start
telltale will illuminate indicating you are in
Autostop. Customer settings will be maintained
upon return to an engine running condition.
POSSIBLE REASONS THE ENGINE DOES
OT AUTOSTOP
N
Prior to engine shut down, the system will check
many safety and comfort conditions to see if
they are fulfilled. Detailed information about the
operation of the Stop/Start system may be
viewed in the instrument cluster display Stop/
Start Screen. In the following situations the
engine will not stop:
Driver’s seat belt is not buckled.
Driver’s door is not closed.
Battery temperature is too warm or cold.
Battery charge is low.
The vehicle is on a steep grade.
Cabin heating or cooling is in process and an
acceptable cabin temperature has not been
achieved.
HVAC is set to full defrost mode at a high
blower speed.
HVAC set to MAX A/C.
Engine has not reached normal operating
temperature.
The transmission is not in a forward gear.
Hood is open.
Vehicle is in 4WD Low transfer case mode (if
equipped with 4WD).
Brake pedal is not pressed with sufficient
pressure with vehicle in DRIVE position.
Accelerator pedal input.
Engine temp too high.
5 mph (8 km/h) threshold not achieved from
previous AUTOSTOP.
Steering angle beyond threshold.
It may be possible for the vehicle to be driven
several times without the Stop/Start system
going into a STOP/START READY state under
more extreme conditions of the items listed
above.
TO START THE E NGINE WHILE IN
UTOSTOP MODE
A
While in a forward gear, the engine will start
when the brake pedal is released or the throttle
