TRAPPER BASS DISTORTION
13
LEDs
9V DC
INPUT
14
4 5 6
3
LEVEL 2 TONE 2FREQ 2
2
TRAPPER BASS DISTORTION
1
1. Distortion 2
Footswitch/LED
2. Output Jack
3. Sub Level (Distortion2)
4. Frequency (Distortion 2)
5. Level (Distortion2)
6. Tone (Distortion2)
7. Gain (Distortion2)
7
GAIN 2
GAIN 1SUB LVL 2 LEVEL 1 TONE 1
8
9
10
11
12
DIST 1DIST 2
8. Gain (Distortion1)
9. Tone (Distortion1)
10. Level (Distortion1)
11. Input Jack
12. Distortion 1
Footswitch/LED
13. LED Kill Switch
14. DC Power Connector
TRAPPER BASS DISTORTION
Add crunch to your low end with the Trapper Bass
Distortion. Featuring two separate and stackable
distortion circuits, this pedal specifically fits the
tonal needs of electric bass players. The main
distortion channel features a crossover-blend
circuit to preserve clean low-frequency information
for clarity and punch, while an additional “solo”
distortion channel provides added gain and
crunch. Use the Frequency and Sub Level controls
to dial in the fundamental tone.
Designed by our in-house team of experts, the
Trapper Bass Distortion is an all-original Fender
circuit. The chassis is crafted from lightweight,
durable anodized aluminum, and the LED-backlit
knobs easily show your control settings at a glance
on dark stages.
DESIGNED IN CALIFORNIA, U.S.A.
Distortion 1 and 2 Footswitches/LEDs
These footswitches bypass or engage each distortion effect. LED
illuminates when effect is on.
Output Jack
Low-impedance output jack connects to amp or to next effect pedal in
signal chain.
Sub Level 2
Adjusts clean-output volume level from low-pass filter.
Frequency 2
Adjusts low-pass frequency. Frequencies below knob setting will be
routed around distortion effect, providing a clear, basic tone to layer
the distortion on.
Level 2
Adjusts output level of Distortion 2.
Tone 2
Adjusts brightness of Distortion 2 circuit.
Gain 2
Adjusts sustain or drive of Distortion 2 circuit.
Gain 1
Adjusts sustain or drive of Distortion 1 circuit.
Tone 1
Adjusts brightness of Distortion 1 circuit.
Level 1
Adjusts output level of Distortion 1.
Input Jack
High-impedance input suitable for electric guitar, bass, acoustic guitars
with pickup systems, keyboards and other instruments.
LED Kill Switch
Deactivates control-knob illumination.
DC Power Connector
Standard center-negative 9VDC jack for use with appropriate power
supplies.
FENDER MUSICAL INSTRUMENTS CORPORATION
A PRODUCT OF
CORONA, CALIFORNIA, U.S.A.
®
is a registered trademark of FMIC.
Fender
Copyright © 2020 FMIC. All rights reserved.
PN 7720601000 REV. A
IMPORTANT SAFETY INSTRUCTIONS
•WARNING: To prevent damage, fire or shock hazard, do not expose the unit or its AC
power to rain or moisture.
•Do not alter the AC plug of the connected power adapter
•Do not drip or splash liquids on the unit.
•No user serviceable parts inside, refer servicing to qualified personnel only.
•WARNING: The unit must only be connected to a safety agency certified, regulated,
power source (adapter), approved for use and compliant with applicable local and
national regulatory safety requirements.
•Unplug AC power adapter before cleaning unit exterior. Use only a damp cloth
for cleaning; wait until unit is completely dry before reconnecting to power.
•Amplifiers and loudspeaker systems, and ear/headphones (if equipped) are capable
of producing very high sound pressure levels, which may cause temporary or permanent
hearing damage. Use care when setting and adjusting volume levels during use.
ADDITIONAL LANGUAGES
Manual available in additional languages at
www.fender.com/support
IMPEDANCES
POWER SUPPLY
POWER REQUIREMENTS
DIMENSIONS
WEIGHT
Product specifications subject to change without notice
SPECIFICATIONS
Input: 500KΩ Output: 470Ω
9VDC regulated adapter,
5.5 x 2.1 mm barrel connector, center negative
140mA @ 9VDC
4.84” x 3.74” x 1.77” (123mm x 95mm x 45mm)
1.32 lbs. (0.6kg)
NOTES
© FENDER MUSICAL INSTRUMENTS 2020
