Feig Electronic MLL02 Users Manual

INSTALLATION

OBI

D

®

Cabinet Lock

megalock-l

up from Firmware 4.00 (with real time clock)

(2)

(1)

Fig. 1: megalock-l layout right (layout left = mirror image)

(1) Recommended door hole diameter 23 mm
(2) max. door thickness 21.5 mm

final
public
2004-10-06
megalock-l-manual.DOC

OBID

®

megalock-l

Installation

Note

 Copyright 1998 - 2004 by

FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg-Waldhausen
Tel.: [phone]

http://www.feig.de

With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.

Copying of this document, and giving it to others and the use or communication of the contents
thereof are forbidden without express authority. Offenders are liable to the payment of damages. All
rights are reserved in the event of the grant of a patent or the registration of a utility model or design.

Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this manual
and may not be held liable for damages ensuing from incorrect or incomplete information. Since, despite all our
efforts, errors may not be completely avoided, we are always grateful for your useful tips.

The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments.

FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this document
and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does not convey
any license under its patent rights nor the rights of others.

OBID® is a registered trademark of FEIG ELECTRONIC GmbH.

FEIG ELECTRONIC GmbH Page 2 of 14 megalock-l-manual.DOC

OBID

®

megalock-l

Installation

Contents

1. Safety and warning notices – read before commissioning............................................4

2. Basic functions of the megalock-l..........................................................................................5

2.1. Locking the megalock-l.........................................................................................................5

2.2. Unlocking the megalock-l......................................................................................................5

3. Installation....................................................................................................................................6

4. Start-up procedure....................................................................................................................6

4.1. Function testing with the "TestKey"......................................................................................6

4.2. Configuring the megalock-l with the "SetupKey" ...............................................................7

4.3. Configuring for standard/daylight saving time "DSTKey"..................................................8

4.4. . Setting time of day and date "ClockSetKey".....................................................................8

5. Resetting a megalock-l with the "ResetKey"....................................................................10

6. Replacing a megalock-l...........................................................................................................10

7. Battery.........................................................................................................................................11

7.1. Battery replacement.............................................................................................................11

8. Service / Maintenance.............................................................................................................11

ANNEX A Technical Data............................................................................................................12

ANNEX B:........................................................................................................................................13

Europe (CE)..................................................................................................................................13

USA (FCC) ....................................................................................................................................13

ANHANG C: LED Blink-Codes...................................................................................................14

FEIG ELECTRONIC GmbH Page 3 of 14 megalock-l-manual.DOC

OBID

®

megalock-l

Installation

1. Safety and warning notices – read before commissioning

• The device may only be used for the purpose intended by the manufacturer.

• The operating instructions have to be handed out to every user and kept in an easily accessible

place.

• Unacceptable changes as well as the use of spare parts and special features which are not
sold or recommended by the manufacturer, may cause fire, electric shocks and injuries.
Therefore, such measures lead to nonliability of the manufacturer and a lapse of all warranty
claims.

• The appliance is subject to the manufacturer’s guarantee regulations in the version valid at the
time of purchase. We cannot be held liable for improper or faulty manual or automatic adjus t­ment of parameters resp. improper use of the appliance.

• Repair work may only be carried out by the manufacturer.

• The user has to make sure that the appliance is installed and operated according to the techni-

cal rules of the country of installation as well as other regional regulations.

FEIG ELECTRONIC GmbH Page 4 of 14 megalock-l-manual.DOC

OBID

®

megalock-l

Installation

2. Basic functions of the megalock-l

(1) Rotary knob:

With integrated LED display (red / green) and antenna for exchange
between megalock-l and megaKey.

(2) Battery compartment:

Use special screwdriver to open (Type: ID MS.SSD-A).

2.1. Locking the megalock-l

1. Push rotary knob

megalock-l is activated for 8 sec. (no indicator)

2. Present megaKey:

The green LED flashes for a max. of 8 sec. As long
as the green LED is flashing, the rotary knob can be
turned 90° and the megalock-l locked.

3. Rotate knob 90°

Turning the knob locks the megalock-l, which
acknowledges this by turning on the green LED for
several seconds.

2.2. Unlocking the megalock-l

1. Push rotary knob

megalock-l is activated for 8 sec. (no indicator)

2. Present megaKey:

As soon as a valid megaKey is recognized by the
megalock-l the green LED begins to flash and the rotary
knob turns itself back to „unlocked“ position.

FEIG ELECTRONIC GmbH Page 5 of 14 megalock-l-manual.DOC
