Feig Electronic LRU1002A User Manual
ID ISC.LRU1002 (EU: 4127.001.00; FCC: 4128.001.00)
UHF Long Range Reader
INSTALLATION
final – public (B)
2017-05-16 – M61110-2e-ID-B.docx
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 2 of 32
M61110-2e-ID-B.docx
Note
Copyright 2017 by
FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg
Tel.: +49 6471 3109-0
http://www.feig.de
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document, and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments and does not give
any guaranty for the functionality of the complete system which incorporates the subject of this document.
FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed
with components and testing methods for a level of reliability suitable for use in or in connection with surgical
implants or as critical components in any life support systems whose failure to perform can reasonably be
expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application
designer must take reasonably prudent steps to protect against system failures.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this document and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does
not convey any license under its patent rights nor the rights of others.
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 3 of 32
M61110-2e-ID-B.docx
Contents
1. Safety Instructions / Warning - Read before start-up ! 5
2. Performance Features of Reader Family ID ISC.LRU1002 6
2.1. Performance features .......................................................................................................... 6
2.2. Available reader types ......................................................................................................... 6
3. Installation 7
4. Terminals 8
4.1. Antenna Connection ............................................................................................................ 9
4.2. Power Supply ...................................................................................................................... 10
4.2.1. Power Supply via connection X2 .................................................................................. 10
4.3. Interfaces ............................................................................................................................ 11
4.3.1. Ethernet Interface on connector X1 .............................................................................. 11
4.3.2. USB Mini Interface on connector X3 ............................................................................. 11
4.3.2.1. USB-Stick Service-Functions ........................................................................... 12
4.3.2.2. Reading of Log and Service Data..................................................................... 12
4.3.2.3. Storing the reader configuration on a USB flash drive ..................................... 13
4.3.2.4. Copy the configuration onto the reader (Config-Cloning) ................................. 13
4.3.3. RS232 Interface on connector X4 ................................................................................. 15
4.3.4. Data-Clock Interface on connector X4 .......................................................................... 16
4.4. Inputs and Outputs on connector X4 ............................................................................... 18
4.4.1. 24 V DC voltage on connector X4 ................................................................................ 18
4.4.2. Digital Inputs on connector X4 ...................................................................................... 19
4.4.3. Digital outputs on connector X4 .................................................................................... 20
4.4.4. Relay output on connector X4 ...................................................................................... 21
5. Operating and Display Elements 22
5.1. Status LED .......................................................................................................................... 22
5.2. Reset Push Button T1 ........................................................................................................ 23
5.3. Reader Power Adjustment ................................................................................................. 24
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 4 of 32
M61110-2e-ID-B.docx
5.3.1. EU reader according to EN302 208 .............................................................................. 24
5.3.2. FCC-Reader according to FCC 47 Part 15 ................................................................... 25
6. Technical Data 26
7. Radio Approvals 29
7.1. Europe (CE) ......................................................................................................................... 29
7.2. USA (FCC) and Canada (IC) ............................................................................................... 30
7.2.1. USA (FCC) and Canada (IC) warning notices .............................................................. 30
7.2.2. Label Information .......................................................................................................... 31
7.2.3. Installation with FCC / IC Approval ............................................................................... 31
7.2.4. USA (FCC) and Canada (IC) approved antennas ........................................................ 31
ANNEX A - Accessories 32
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 5 of 32
M61110-2e-ID-B.docx
1. Safety Instructions / Warning - Read before start-up !
The device may only be used for the intended purpose designed by for the manufacturer.
The operation manual should be conveniently kept available at all times for each user.
Unauthorized changes and the use of spare parts and additional devices which have not been
sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such
unauthorized measures shall exclude any liability by the manufacturer.
The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid
for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,
or omissions in the manual or automatically set parameters for a device or for an incorrect
application of a device.
Repairs may only be executed by the manufacturer.
Installation, operation, and maintenance procedures should only be carried out by qualified
personnel.
Use of the device and its installation must be in accordance with national legal requirements
and local electrical codes .
When working on devices the valid safety regulations must be observed.
This device is not suitable to be used in places where children are present. Prevent children
access to the device.
Equipment is intended for use only in restricted access area.
Special advice for carriers of cardiac pacemakers:
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep
a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in
an immediate proximity of the device respective the antenna for some time.
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 6 of 32
M61110-2e-ID-B.docx
Order Number
Reader type
Description
4127.001.00
ID ISC.LRU1002-EU
Device version for Europe
4128.001.00
ID ISC.LRU1002-FCC
Device version for North America
4861.000.00
ID ISC.LRU1002-MA
Device version for Morocco
2. Performance Features of Reader Family ID ISC.LRU1002
2.1. Performance features
The reader has been developed for reading passive data carriers, so-called „Smart Labels“, using
an operating frequency in the UHF range. The output power is configurable in the range between
100 mW and 2 W. This allows read ranges of up to 12 m.
2.2. Available reader types
The following readers are available:
Table 1: Available Reader Types
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 7 of 32
M61110-2e-ID-B.docx
3. Installation
The Reader is designed for wall-mount, including outdoors. Outdoors the reader should be
mounted like shown in the picture below to ensure the watertightness of the device.
Holes for mounting on a wall with countersunk head screws are provided in the housing. The
maximum head screw diameter should not exceed 8,0 mm. The thread diameter is 5,3 mm (M5
screws). The screws must have a minimum length of 45 mm depending on the installation
situation. It is not necessary to open the reader housing for installation.
Figure 1: Installation Drawing
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 8 of 32
M61110-2e-ID-B.docx
Connector
Description
ANT 1-4
Connection of the external antennas (Impedance 50)
X1
10/100Tbase network connection with RJ-45
X2
Power supply 24VDC ± 20%
X3
USB Mini Interface
X4
Digital input, digital output, relay output and RS232 interface
Push button
Description
T1
Internal push button for complete configuration reset
ANT 1 - 4
X2
X3
X1
X4
T1
4. Terminals
On the lower side of the reader housing different connectors are positioned. Figure 2 shows the
arrangement of the connectors and Table 2: Connection terminals gives an overview on the available interfaces and signals. Table 3: Push button function shows the available push buttons.
Figure 2: Connection Overview
Table 2: Connection terminals
Table 3: Push button function
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 9 of 32
M61110-2e-ID-B.docx
Terminal
Description
ANT 1 - 4
Connection for external antennas (input impedance 50)
4.1. Antenna Connection
The external SMA antenna connectors are positioned on the lower side of the reader.
The maximum tightening torque for the SMA sockets is 0.45 Nm (4.0 lbf in).
For supplying a DC voltage to external components e.g. the UHF antenna multiplexer ID
ISC.ANT.UMUX, it is possible to enable a supply voltage (24 V DC / max. 500mA) on the antenna
cable. This need to be configured in the reader.
Table 4: External antenna connection
Figure 3: External antenna connection ANT1-4
CAUTION:
Exceeding the tightening torque will destroy the plug.
The activation of the DC voltage on the antenna cable can damage the antennas from other
manufacturers. It is recommend to use high resistance UHF antennas. For any further questions please contact the technical support.
IDENTIFICATION
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 10 of 32
M61110-2e-ID-B.docx
Terminal
Abbreviation
Description
X2 / Pin 1
VDC
Supply voltage 24 V DC ±20 %
X2 / Pin 2
GND
Ground – supply voltage
Conductor Cross-section
Validation procedure
from 0,5 mm
2
or bigger
IEC 60332-1-2 and IEC 60332-1-3
smaller than 0,5 mm2
IEC 60332-2-1 and IEC 60332-2-2
4.2. Power Supply
4.2.1. Power Supply via connection X2
The supply voltage of 24 V DC has to be connected to Terminal X2.
Figure 4: Connector X2 Pin assignment for power supply
Table 5: Pin assignment for power supply
CAUTION:
The reader has to be supplied by a limited power supply according EN 62368-1 Chapter Q.1,
or with a NEC Class 2/LPS certified power supply.
Each reader has to be supplied by a separate external power supply.
Reversing the polarity of the supply voltage on X2 may destroy the device.
External wiring for the power supply must fulfil the following norms/validation procedure:
