Fat Shark V2 CE User Manual
Fat Shark 1 RC Vision Systems
PREDATOR V2 CE
RTF FPV KIT
USER MANUAL
Revision B 09/21/2013
For more product information, please visit:
www.fatshark.com
All Rights Reserved
Fat Shark 2 RC Vision Systems
Contents
Product contents ..................................................................................................... 3
Controls Diagram .................................................................................................... 4
Controls ................................................................................................................... 5
Downlink Overview (Camera, TX, Power) ............................................................... 5
Transmitter .......................................................................................................... 6
Camera ................................................................................................................ 6
Power (via discharge filter supply) ....................................................................... 6
AV in/out Port .......................................................................................................... 6
Recording Video .................................................................................................. 6
Using an external receiver: .................................................................................. 7
Battery Charging ..................................................................................................... 7
Accessories ............................................................................................................. 8
Diopter lens ......................................................................................................... 8
Tiny Telemetry from ImmersionRC ...................................................................... 8
Specifications .......................................................................................................... 9
Headset Specifications ........................................................................................ 9
Camera Specifications: ...................................................................................... 10
Transmitter Specifications: ................................................................................ 10
Downlink Kit ....................................................................................................... 10
Operational advice ................................................................................................ 11
Trouble shooting .................................................................................................... 12
Warranty ................................................................................................................ 12
Introduction
Congratulations on purchasing the Fat Shark Predator RTF FPV video piloting
system with goggles, transmitter and camera. To ensure your continued
enjoyment, please take the time to thoroughly read through this operating manual
before using.
Product Compatibility
The Predator has been designed to adhere to established video standards and is
compatible with any product also adhering to accepted video standards. Due to
the high number of different manufacturers and variation in quality, it’s impossible
to for us to have tested with every product combination and some troubleshooting
may be required if mix/matching components. The Predator has been thoroughly
tested with ImmersionRC gear. For best results and no compatibility issues, Fat
Shark recommends ImmersionRC gear for your accessory products.
IMPORTANT!!!! Product Warning!!!!!
DO NOT LEAVE HEADSET EXPOSED TO DIRECT
SUNLIGHT. SUNLIGHT WILL MAGNIFY THROUGH THE
OPTICS AND BURN HOLES IN THE LCD COLOR FILTER
THIS WILL NOT BE COVERED BY WARRANTY. KEEP
GOGGLES IN PROTECTIVE CASE WHEN NOT IN USE
Fat Shark 3 RC Vision Systems
Product contents
Carry case
Predator Headset
FPV Downlink
(camera, TX, filter)
AV cable
5G8 Antenna (2p)
(headset and transmitter)
Battery
(with discharge adapter)
Manual
Fat Shark 4 RC Vision Systems
Controls Diagram
