Fat Shark FSV1123 User Manual

Fat Shark 1

DOMINATOR HDO2

MODEL FSV1123

USER MANUAL

Revision C 10/26/2019

For more product information, please visit:

www.fatshark.com

All Rights Reserved

Fat Shark 2

Table of Contents

Product Compatibility 3

Product Contents 4

HDO2 Headset Overview 5

Setup 6

General Operation 8

Specifications 11

Technical Support 12

Fat Shark 3

Introduction

Congratulations on purchasing the Fat Shark HDO2 modular UVGA OLED FPV goggles with
integrated DVR for analog recording. To ensure your continued enjoyment, please take the time
to read through this operating manual thoroughly before using.

There are many feature changes from the previous generations of the Dominator google line.
Even if you are a long-time Dominator user, it is recommended that you read this manual to
understand what features have been changed and added.

Product Compatibility

The HDO2 has been designed to adhere to established video standards and is compatible with
any product also adhering to accepted video standards. Due to the high number of different
manufacturers and variation in quality, it’s impossible to for us to have tested with every product
combination and some troubleshooting may be required if mix/matching components. The
Dominator HDO2 has been thoroughly tested with ImmersionRC gear. For best results and no
compatibility issues, Fat Shark recommends ImmersionRC gear for your accessory products.

IMPORTANT!!!! Product Warning!!!!!

DO NOT LEAVE HEADSET EXPOSED TO DIRECT SUNLIGHT.
SUNLIGHT WILL MAGNIFY THROUGH THE OPTICS AND
BURN HOLES IN THE OLED COLOR FILTER (appears as
white open areas).

THIS WILL NOT BE COVERED BY WARRANTY. KEEP
GOGGLES IN PROTECTIVE CASE WHEN NOT IN USE.

Fat Shark 4

Carrying Case
Dominator HDO2 Headset

7.4V 18650 Battery Case

Lens Cleaning Cloth

Product Contents
