6-PLACE SETTING
COUNTERTOP DISHWASHER
Model: FCD06ABBWHA
Read these instructions carefully before using your
dishwasher, and to maintain its upkeep. If you
follow the instructions, your unit will provide you
with many years of good service.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
(rev. 07/24/19) MD
Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© 2019 Farberware Licensing Company, LLC. All rights reserved.
2
Tables of Contents
SAFETY INFORMATION����������������������������������������������������������������������������������������������������������������������� 4
OPERATION INSTRUCTION ����������������������������������������������������������������������������������������������������������������� 6
FIRST TIME USE ���������������������������������������������������������������������������������������������������������������������������������� 7
LOADING THE DISHWASHER������������������������������������������������������������������������������������������������������������� 10
STARTING A WASHING PROGRAM��������������������������������������������������������������������������������������������������� 13
MAINTENANCE & CLEANING����������������������������������������������������������������������������������������������������������� 15
INSTALLATION �������������������������������������������������������������������������������������������������������....��������������.������� 19
TROUBLESHOOTING������������������������������������������������������������������������������������������������������������������������ 23
TECHNICAL INFORMATION �����������������������������������������������������������������������������������������������������������.� 26
WARRANTY INFORMATION �����������������������������������������������������������������������������������������������������.������ 27
3
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk
of electric shock by providing a path of least resistance of electric current. This appliance is equipped with a
cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is installed and grounded in accordance with all local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a
qualified electrician or service representative if you are in doubt whether the appliance is properly grounded.
Do not modify the plug provided with the appliance; If it is not fit for the outlet. Have a proper outlet installed
by a qualified electrician.
WARNING! PROPER USE
-Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
-Do not touch the heating element during or immediately after use. (This instruction is only applicable to
machines with a visual heating element.)
-Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very
carefully if the dishwasher is operating, there is a risk of water squirting out. Do not place any heavy objects of
stand on the door when it is open. The appliance could tip forward.
-When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door seal;
2) Warning: Knives and other utensils with sharp points must be loaded in the basket with their points
down or placed in a horizontal position.
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are
known to the State of California to cause cancer,
birth defects and other reproductive harm.
For more information, visit
www.P65Warnings.ca.gov
4
-When using your dishwasher, you should prevent plastic items from coming into contact with heating
element. (This instruction is only applicable to machines with a visual heating element.)
-Check that the detergent dispenser is empty after completion of the wash cycle.
-Do not wash plastic items unless they are marked dishwasher safe or the equivalent. For plastic items not
marked, check the manufacturer's recommendations.
-Use only detergent and rinse additives designed for an automatic dishwasher.
-Never use soap, laundry detergent, or hand washing detergent in your dishwasher. Keep these products out
of the reach of children.
-Keep children away from detergent and rinse aid, keep children away from the open door of the dishwasher
as there could still be some detergent left inside.
-This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
-Children should be supervised to ensure that they do not play with the appliance.
-Dishwasher detergents are strongly alkaline, they can be extremely dangerous if swallowed. Avoid contact
with skin and eyes and keep children away from the dishwasher when the door is open. The door should not
be left in the open position since this could present a tripping hazards.
-If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
-Remove the door to the washing compartment when removing an old dishwasher from service or discarding
it.
-Please dispose of packing materials properly. Use the dishwasher only for its intended function. During
installation, the power supply must not be excessively or dangerously bent or flattened. Do not tamper with
controls.
-The appliance is to be connected to the water mains using new hose sets and that old hose-sets should not be
reused.
-The maximum number of place settings to be washed is 6. The maximum permissible inlet water pressure is
1Mpa. The minimum permissible inlet water pressure is 0.04Mpa.
5
OPERATION INSTRUCTION
CONTROL PANEL
Power Button: To turn on/off the power
1
supply.
Washing Program Selector: Press the button
2
to select wash cycles.
3
Program.
4
Delay Button : To press t he button to delay.
DISHWASHER FEATURES
3
Start/Pause Button: Press this button to
5
start or pause the dishwasher.
Display screen: to show the reminding
6
time and the state (running state, delay
time etc).
7
Rinse aid function indicator.
8
Program ending indicator.
2 4 5
6
8
7
Bac k View
1
1
Front view
2
8 9
Cup She lf
1
3
4
6
5
7
Cutle ry Bask et
5
6
Rinse Ai d Dispe nser
6
2
Baske t
Deter gent Dispe nser
3
4
Filte r assembly
Spray Ar ms
7
Inlet p ipe con nector
8
Drain p ipe
9
conne ctor
PRIOR TO USING FOR THE FIRST TIME
A. Fill the Rinse Aid Dispenser
Rinse Aid Dispenser
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes. That can
leave spots and streaks. It also improves drying by allowing water to sheet off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent
dispenser. To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator
turns completely black. The volume of the rinse aid container is about 110ml.
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free
drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color
indicator will be dark. As the rinse-aid diminishes, the size of the dark dot decreases. You should never let the
rinse aid get below 1/4 full.
As the rinse ai d diminishes, the size of the bl ack dot
on the rinse ai d level indicator changes, a s illustrat ed below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should r e
Empty
1
fill to elimi nate spotti ng
2
3
7
C (Rinse-Aid indicator)
To open the dispenser, turn the cap to the
"open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being
careful not to overfill.
Replace the cap by inserting it aligned with
"open" arrow and turning it to the closed
(right) arrow.
NOTE: Clean up any rinse aid split during
filling with an absorbent cloth to avoid
excessive foaming
Adjusting Rinse Aid Dispenser
Adjust l eve r
(Rins e)
MAX
Increase the dose if there are drops of water or lime spots on the dishes after washing. Reduce it if there
are sticky whitish stains on your dishes or a bluish film on glassware or knife blades.
The rinse aid dispenser has four settings.The recommended setting is on "3". If the dishes
still are not drying properly or are spotted, adjust the dial to the next higher number on
"4".
NO TE:
B. Function of Detergent
Proper Use of Detergent
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the
dishwasher. Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
Don't put powder detergent into the dispenser until you're ready to wash dishes.
Detergents
There are 3 sorts of detergents: 1. With phosphate and with chlorine. 2. With phosphate and without clorine.
3. Without phosphate and without clorine.
Normally new pulverized detergent is without phosphate. The water softener function of phosphate is not
given. In this case we recommend to fill salt in the salt container even when the hardness of water is only 6 °
dH. If detergents without phosphate were used in case of hard water often white spots appear at dishes and
glasses. In this case please add more detergent to reach better results. Detergents without chlorine do only
bleach a little. Strong and colored spots will not removed completely. In this case please choose a program
with higher Temperature.
Concentrated Detergent
Based on their chemical composition, dishwasher can be split in two basic types: Conventional, alkaline
detergents with caustic components AND low alkaline concentrated detergents with natural enzymes.
The use of “normal” washing programs in conjunction with concentrated detergents reduces pollution and is
good for your dishes; these wash programs are specially matched to the dirt-dissolving properties of the
enzymes of the concentrated detergent. For this reason “normal”wash programs in which concentrated
detergents are use d can achieve t he same results that can otherwise only be achieved using “heavy”
program.
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent tablets
cannot dissolve and develop their full cleaning power during short programs. Therefore please use long
programs when using detergent tablets, to ensure the complete removal of detergent residuals.
8
Detergent Dispenser
The dispenser must be refilled before the start of each wash cycle following the instructions provided in the
Wash Cycle Table . Your dishwasher uses less detergent and rinse aid then conventional dishwasher.
Generally, only one tablespoon of detergent is needed for a normal wash load. Also, more heavily soiled
items need more detergent. Always add the detergent just before starting the dishwasher, otherwise it could
get damp and will not dissolve properly.
Amount of Detergent to use
NOTE: If the lid is closed: press release button. The lid springs open. Always add the detergent just before
starting each wash cycle. Only use branded detergent aid for dishwasher.
WARNING! Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
1
Push latch to open
Fill in Detergent
Fill the detergent dispenser with detergent. The marking
indicates the dosing levels, as illustrated on right:
A. The place can load 15g detergent.
B. The place can load 25g detergent.
2
B
A
Deter gent po wder
Deter gent ta blet
Please observe the manufacturers dosing and storage
recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This
detergent will take effect during the pre-wash phase.
NOTE: You find information about the amount of
detergent for the single program on the last page.
Please be aware, that according to the level soiling
and the specific hardness of water differences are
possible. Please observe the manufacturer's
recommendations on the detergent packaging.
9
LOADING THE DISHWASHER BASKETS
Recommendation
A. Consider buying utensils which are identified as dishwasher-proof.
B. Use a mild detergent that is described as 'kind of dishes'. If necessary, seek further information from
detergent manufacturers.
C. For particular items, select a program with as low a temperature.
D. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program
has ended.
For washing in the dishwasher the following cutlery/dishes
Are not suitable
A. Cutlery with wooden, horn china or mother-of-
pearl handles.
B. Plastic items that are not heat resistant Older
cutlery with glued parts that is not temperature
resistant.
C. Bonded cutlery items or dishes Pewter or
cooper items.
D. Crystal glass.
E. Steel items subject to rusting.
F. Wooden platters.
G. Items made from synthetic fibers.
Are of limited suitability
A. Some types of glasses can become dull after a
large number of washes.
B. Silver and aluminum parts have a tendency to
discolor during washing.
C. Glazed patters may fade if machine washed
frequently
Attention before or after loading the Dishwasher Baskets
(For best performance of the dishwasher, follow these loading guidelines. Features and appearance of
baskets and cutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans It is not necessary to
rinse the dishes under running water.
Place objects in the dishwasher in following way:
1. Items such as cups, glasses, pots/pans, etc. are face down.
2. Curved items, or those with recesses, should be loaded at a slant so that water can run off.
3. All utensils are stacked securely and can not tip over.
4. All utensils are placed in the way that the spray arms can rotated freely during washing.
10
NOTE: Very small items should not be washed in the dishwasher as they could easily fall out of the
basket.
A. Load hollow items such as cups, glasses, pans etc. With the opening downwards so that water cannot
collect in the container or a deep base.
B. Dishes and items of cutlery must not lie inside one another, or cover each other.
C. To avoid damage to glasses, they must not touch.
D. Load large items which are most difficult to clean into the basket.
E. Long bladed knives stored in an upright position are a potential hazard!
F. Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the basket.
G. Please do not overload your dishwasher. This is important for good results and for
reasonable energy consume.
Loading the basket
Position the dishes and cookware so that they will not get moved by the spray of water.
IN
1
1
4
4
3
3
1
1
2
2
5
5
2
2
4
4
6
6
7
7
8
8
1
Cups
3
Glasses
5
Fruit bowl
7
Dinner plat es
Cutlery bas ket
Serving bow l
Saucers
Oval platte r
Bread and
butter plat
9
2
4
6
8
es
9
11
Plate racks of Basket
The baske t is fitted w ith plate racks wh ich
can be stow ed horizo ntal if required .
Cutlery Basket
Cutlery should be placed in the cutlery basket with handles at the bottom. If the rack has side baskets,
the spoon should be loaded individually into the appropriate slots, especially long utensils should be
placed in the horizontal position at the front of the upper basket as shown.
1
4
1
4
3
4
Dinner forks
1
1
1
1
2 Salad forks
3
Knives
Teaspoons
4
Serving spoons
5
IN
1
6
3
3
4
4
4
4
3
4
3
4
4
Serving forks
1
Warning! Do not let any item extend through bottom. Always load sharp utensils with the sharp
point down! For personal safety and a top quality clean, place the silverware in the basket.
3
4
2
4
5
6
12
Heavy
P1
Normal
P2
Baby Care
P3
Light
P4
Glass
P5
Speed 45Min
P6
Self Clean
P7
Turning on the appliance
Starting a wash cycle:
1. Draw out the basket(see the section entitled "Loading the Dishwasher " );
2. Pour in the detergent (see the section entitled "Detergent and Rinse Aid " );
3. Insert the plug into the socket. The power supply is 120V/60 Hz;
4. Make sure that the water supply is turned on to full pressure;
5. Close the door and press the on/off button to turn on the power supply;
6. Press the program button to select wash program you need
Heavy->Normal->BabyCare->ECO->Glass->Speed->Rinse
7. Then press the Start/Pause button, the dishwasher begins to start.
NOTE: When you press the Start/Pause button to pause during washing, the display time will
stop blinking and the program will pause and remain this cycle till you restart it again.
Change the program
Premise: You can modify the washing program, When the dishwasher just runs for a short time.
Otherwise, the detergent may have already been released, and the appliance may have already drained
the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled "
Loading the Detergent " ).
To change the washing program, press the Start/pause button to pause the machine, then press the
program button more than three seconds the machine will be in stand by state, then you can change
the program to the desired cycle setting (see the section entitled " Starting a wash cycle"). The lights
show the state of the dishwasher:
A. All phase lights off----------------------------On stand by
B. The display no blinking----------------------Being paused
C. The display blinking--------------------------Running
NOTE: If you open the door when washing, the machine will pause. When you close the door,
you need press start/pause button to keep the machine working.
Forget to add a dish?
A forgotten dish can be added any time before the detergent cup opens.
1. Press the start/pause button
2. Open the door a little to stop the washing.
3. After the spray arms stop working,you can open the door completely.
4. Add forgotten dishes.
5. Close the door
6. Press the start/pausebutton, the dishwasher will run after 10 seconds.
14
At the end of a wash cycle
When the working cycle has finished, the buzzer of dishwasher will sound 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while
they are still hot and more susceptible to breakage. They will also dry better.
Since the appliance is standing by, it will power off automaticly after 30 minutes without any operation.
1. Switch off the dishwasher
All the phase lights are off , only in this case the programme has ended.
-Switch off the dishwasher by pressing the ON/OFF button.
-Turn off the water tap!
2. Open the door carefully
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down
around 15 minutes before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this
way they will be cooler and the drying will be improved.
3. Unloading the dishwasher
It is normal that the dishwasher is wet inside.
WARNING! It is dangerous to open the door when washing, because the hot water may scald
you.
MAINTENANCE AND CLEANING
Filtering System
The filter prevent larger remnants
of food or other objects from getting
inside the pump.
C
B
A
The filter system consists of a coarse filter, a flat (Main filter)
and a micro filter (fine filter).
A: MAIN FILTER
Food and soil particles trapped by this filter are
pulverized by a special jet on the spray arm and washed down
to drain.
B: FINE FILTER
This filter holds soil and food residue in the sump
area and prevents it from being deposited on the dishes during
wash cycle.
C: COARSE FILTER
Larger items, such as pieces of bone or glass, that
could block the drain are trapped in the coarse filter. To
remove the items caught by the filter, gently squeeze the tap
on the top of this filter and lift out.
15
Filter assembly
The filter efficiently removes food particles from the wash water, allowing it to be re-cyclated during the
cycle. For best performance and results, the filter assembly must be regularly. For this reason, it is a good
idea to remove the larger food particles trapping in the filter after each wash cycle by rinsing the filter
and cup under running water. To remove the filter assembly, pull on the cup handle in the upward
direction.
WARNING! Never run the dishwasher without the filters in place. The dishwasher must never be used
without the filters. Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
Open
STEP 1: Contrarotate the filter assembly (A,B
and C), then lift it all up.
C
B
NOTE:
STEP 2: Lift B and C up from A.
A
C
B
STEP 3: The End.
A
If do it from step1 to step 3, the filter system will be removed; while if do it from Step 3 to Step 1,
the filter system will be installed.
16
Remarks:
-Inspect the filters for blocking every time the dishwasher has been used.
-By unscrewing the coarse filter. you can remove the filter system. Remove any food remnants and clean
the filters under running water.
NOTE: The entire filter assembly should be cleaned once a week.
Cleaning the Filter:
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in
the figures in the last page and reinsert the entire assembly in the dishwasher, positioning in its seat and
pressing downward.
WARNING! When cleaning the filters, don't knock on them. Otherwise, the filters could be contorted
and the performance of dishwasher could be debased.
CARING FOR THE DISHWASHER
The control panel can be cleaned by using a lightly dampened cloth and dry thoroughly. The exterior use
a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the
dishwasher.
Cleaning the Door
To clean the edge around the door, you should use
only a soft warm, damp cloth. To avoid penetration of
water into the door lock and electrical components,
do not use a spray cleaner of any kind.
WARNING! Never use a spray cleaner to clean the door panel as it may damage the door lock and
electrical components. Abrasive agent or some paper towel should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
17
Protect Against Freezing:
Please take frost protection measures on dishwasher in winter. Each time after washing cycles, please
operate as follows:
1. Cut off electrical power to the dishwasher.
2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
3. Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4. Reconnect the water inlet pipe to the water valve.
5. Remove the filter at the bottom of the tub and use a sponge to use up water in sump.
NOTE: If your dishwasher cannot work because of the ice, please contact professional service persons.
Cleaning the Spray Arms:
The spray arms can be easily removed for periodic cleaning
of the nozzles, to prevent possible clogging. Wash them
under running water and carefully replace them in their seats,
checking that their rotary movement is in no way impeded.
Grasp the middle of the spray arm, pull it upwards to remove
it. Wash the arms under a jet of running water and return
them
carefully to their seat. After reassembly, check that the spray
arms turn freely. Otherwise, check that they have been
installed correctly.
18
Protect against freezing:
After every wash: After every wash, turn off the water supply to the appliance and leave the door
slightly open so that moisture and odors are not trapped inside.
Remove the plug: Before cleaning or performing maintenance, always remove the plug from the
socket.
No solvents or abrasive cleaning: To clean the exterior and rubber parts of the dishwasher, do
not use solvents or abrasive cleaning products. Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the interior, use a cloth dampened with water with a little
vinegar, or a cleaning product made specifically for dishwashers.
When it is not in need for a long time: It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from the socket, turn off the water supply and leave the door
of the appliance slightly open. This will help the door seals to last longer and prevent odors from forming
within the appliance.
Moving the appliance: If the appliance must be moved, try to keep it in the vertical position. If
absolutely necessary, it can be positioned on its back.
Seals: One of the factors that cause odors to form in the dishwasher is food that remains trapped in the
seals. Periodic cleaning with a damp sponge will prevent this from occurring.
INSTALLATION INSTRUCTIONS
Warning
Attention:
The installation of the pipes and electrical
equipments should be done by
professionals.
Electrical Shock Hazard
Disconnect electrical power before installing
dishwasher.
Failure to do so can result in death or
electrical shock.
19
Installation Preparation:
The installation position of dishwasher should be near the existing inlet and drain hoses and power
cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of the
dishwasher.
Positioning the Appliance:
Position the appliance in the desired location. The back should rest against the wall behind it, and the
sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain
hoses that can be positioned to the right or the left to facilitate proper installation.
About Power Connection:
For personal safety: DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS
APPLIANCE. DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING CONNECTION
FROM THE POWER CORD.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher to the
appropriate power supply. Use the required fuse 10 amp, time delay fuse or circuit breaker
recommended and provide separate circuit serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the rating plate. Only
insert the plug into an electrical socket which is earthed properly. If the electrical socket to which the
appliance must be connected is not appropriate for the plug , replace the socket, rather than using a
adapters or the like as they could cause overheating and burns.
Insure proper ground
exists before use
20
Grounding Instructions:
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk
of electric shock by providing a path of least resistance for the electric current. This appliance is
equipped with a cord having an equipment-earthing conductor and an earthing plug. The plug must be
plugged into an appropriate outlet that is installed and earthed in accordance with all local standards and
requirements.
WARNING! Improper connection of the equipment earthing conductor can result in the risk of an
electric shock. Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly earthed. Do not modify the plug provided with the appliance. If the plug does not fit
properly to the outlet, please have a qualified electrician to install a proper outlet.
Water Connection
Cold water connection
Please take frost protection measures on dishwasher in winter. Each time after washing cycles, please
operate as follows:
Connect the cold water supply hose to a threaded 3/4(inch) connector and make
sure that it is fastened tightly in place. If the water pipes are new or have not been
used for an extended period of time, let the water run to make sure that the
water is clear and free of impurities. If this precaution is not taken, there is a risk
that the water inlet can get blocked and damage the appliance.
Please Note: If the supplied hose does not fit your tap, please contact your local
plumbing supply center where adapters are available for purchase.
WARNING! please close the faucet after using.
1. Screw the faucet adapter onto (or into) the faucet tap. Check for leaks (use Teflon tape to eliminate
if necessary).
2. Connect the six-sided connection of the drain hose to the drain port connection on the back of the
dishwasher cabinet. Do not over-tighten (to avoid damage to threads).
3. Connect the star-shaped connection of the inlet hose to the inlet port on the back of the
dishwasher cabinet. Do not over-tighten (to avoid damage to threads).
4. Connect the circular connection of the drain hose onto the longer (bottom) male connection on the
quick connect.
5. Connect the circular connection of the inlet hose onto the shorter (top) male connection on the
quick connect.
21
6. Attach the quick connect onto the faucet adapter, by pulling down the outer locking collar on
the quick connect, while pushing the quick connect upward onto the faucet adapter.
7. When the quick connect snaps onto the faucet adapter, release the locking collar. Verify the
connection is secure.
8. Slowly open the hot water line and check for any sign of water leaks at all hose connections. If
leaks are located, immediately close the water supply and repair the hose connections.
IMPORTANT:
1. Once you open the water supply line, (even if it is closed immediately thereafter), the inlet
hose will be pressurized.
2. To relieve water pressure from inside the inlet hose, (make sure the water line (faucet) is
closed): press and hold the red pressure relief button on the quick connect until the flow of water
stops.
WARNING! FAILURE TO RELIEVE WATER PRESSURE, BEFORE DISCONNECTING THE QUICK-
CONNECT FROM THE FAUCET, WILL RESULT IN BACK-PRESSURE OVER-SPRAY. THE TEMPERATURE
OF INCOMINGWATER CAN BE VERY HOT, AND BACK-PRESSURE OVER-SPRAY COULD CAUSE
SEVERE BURNS AND/OR SCALDING.
DANGER: DO NOT LET CHILDREN DISCONNECT THE DISHWASHER; CLOSE SUPERVISION OF
CHILDREN IS ALWAYS IMPORTANT AROUND APPLIANCES.
NOTE: Hard water conditions will adversely affect the washing performance of your dishwasher.
Hard water conditions will also contribute to 'lime' (white film substance) deposits and/or 'scaling'
on the stainless steel surface of the dishwasher tub and heater element, located in the sump
underneath the removable filter screen. To assist in minimizing these conditions, it is
recommended to periodically operate/rinse the inside of the dishwasher (empty) using 1 cup of
white vinegar at least once a week.
Disconnecting your dishwasher:
1. Shut off the water supply at the faucet.
2. Disconnect the power supply cord
22
Start of Dishwasher
The following things should be checked before starting the dishwasher.
1. The dishwasher is level and fixed properly
2. The inlet valve is open
3. There is a leakage at the connections of the conducts
4. The wires are tightly connected
5. The power is switched on
6. The inlet and drain hoses are knotted
7. All packing materials and printings should be taken out from the dishwasher
ATTENTION: After installation, please make sure to keep this manual. The content of this manual
is very helpful to the users.
TROUBLESHOOTING TIPS
Before Calling for Service
Review the charts on the following pages may save you from calling for service.
Technica l
p
roblem s
Problem
Dishwasher doesn't
star
t
Water not pumped
from dishwasher
Possible Causes What To Do
Fuse blown, or the
circuit breaker tripped.
Power supply is not
turned on.
Door of dishwasher
not properly closed.
Kink in drain hose
Filter clogged.
Kitchen sink clogged.
Replace fuse or reset circuit breaker. Remove any other
appliances sharing the same circuit with the dishwasher
Make sure the dishwasher is turned on and the door is
closed securely.
Make sure the power cord is properly plugged into the
wall socket.
Closed dishwasher making sure that door latches.
Check drain hose.
Check the coarse filter.
(see section titled " Cleaning The Filter ")
Check kitchen sink to make sure it is draining well.
If problem is kitchen sink not draining ,you may need
a plumber rather than a serviceman for dishwasher.
23
Suds in the tub
Improper detergent
Use only the special dishwasher detergent to avoid
suds. If this occurs, open the dishwasher and let suds
evaporate. Add 1 gallon of cold water to the tub. Close
and l
atch the dishwasher, then Start the "soak" wash
cycle to drain out the water . Repeat if necessary.
General
problems
Noise
Stained tub interior
White film on
inside surface
There are rust
stains on cutlery
Knocking noise
in the wash cabinet
Rattling noise
in the wash cabinet
Spilled rinse-aid
Detergent with
colourant was used.
Hard water minerals
The affected items are
not corrosion resistant.
A programme was not
run after dishwasher
salt was added.
Traces of salt have
got into the wash cycle.
The lid of softer
is loose.
The spray arm is
knocking against
an item in a basket.
Item of crockery
are insecure
in the wash cabinet.
Always wipe up rinse-aid spills immediately.
Make sure that the detergent is the one without
colourant.
To clean the interior, use a damp sponge with
dishwasher detergent and wear rubber gloves.
er use any other cleaner than dishwasher
Nev
detergent for the risk of foaming or suds.
Always run the Quick wash programme .
without any crockery in the dishwasher and
without selecting the Turbo function (if present),
after adding dishwasher salt.
Check the lip .Ensure the fix is fine.
Interrupt the programme, and rearrange the items
which are obstructing the spray arm.
Interrupt the programme,
and rearrange the items of crockery.
Unsatisfactory
washing result
Knocking noise
in the water pipes
This may be caused
by on-site installation
or the cross-section of
the piping.
This has no influence on dishwasher function.
if in doubt, contact a suitably qualified plumber.
Problem Possible Causes What To Do
The dishes
are not clean
The dishes were not
loaded correctly.
The programme was
not powerful enough.
Not enough detergent
was dispensed.
Item are blocking
the path of spray arms.
The filter combination in
the base of wash cabinet
is not clean or is not
correctly fitted. This may
cause the spray arm jets
to get blocked.
24
See notes in " Loading the Dishwasher Baskets ".
Select a more intensive programme.
See" Wash Cycle Table ".
Use more detergent, or change your detergent.
Rearrange the items so that the spray can rotate freely.
Clean and/or fit the filter combination correctly.
Clean the spray arm jets. See "Cleaning the Spray
s".
Arm
Unsatisfactory
drying result
Cloudiness
on glassware
Black or gray
marks on dishes
Detergent left in
dispenser cups
The dishes
are not drying
Combination of soft
water a
nd too much
detergent.
Aluminum utensils
have rubbed against
dishes.
Dishes block
detergent cups.
Improper loading
Too little rinse-aid
Dishes are removed
too soon.
Wrong programme
selection
Using cutlery with
a low-quality coating
Use less detergent if you have soft water and select
a shortest cycle to wash the glassware and to get
them clean.
Use a mild abrasive cleaner to eliminate those marks.
Re-loading the dishes properly.
Load the dishwasher as suggested in the directions.
Increase the amount of rinse-aid/Refill the rinse-aid
dispenser.
Do not empty your dishwasher immediately after
washing. Open the door slightly so that the steam can
e. Begin unloading the dishwasher only once t
escap
he dishes are barely warm to the touch. Empty the low
basket first. This prevents water form dropping off
dishes in the upper basket.
In short programmes the washing temperature is lower.
This also lowers cleaning performance. Choose a
programme with a long washing time.
Water drainage is more difficult with these items.
Cutle
ry or dishes of this type are not suitable for
ng in the dishwasher.
washi
Error codes
When some malfunctions come on, the appliance will display error codes to warn you:
Codes
EI
E4
WARNING! If overflow occurs, turn off the main water supply before calling a service. If there is
water in the base pan because of an overfill or small leak, the water should be removed before
restarting the dishwasher.
Meanings
Longer inlet time.
Overflow.
Possible Causes
Faucets is not opened, or water intake is restricted,
or water pressure is too low.
Some element of dishwasher leaks .
25
Technical Information
550mm
438mm
8
Height:
Width:
Depth:
Voltag
e connected Load :d:
438mm
550mm
500mm
see rating labe
Water pressure: .04-1.0MPa
Hot water connection :n :
Power supply:
Capacity:
should be 120 °F
see rating label
6 place settings
500mm
12mm
l
26
ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S. and Canada.
This is the only expressed warranty for this product and is in lieu of any other warranty or
condition.
This product is warranted to be free from defects in material and workmanship for a period of
one (1) year from the date of original purchase. This warranty is valid for the original retail
purchaser or gift recipient from the date of initial retail purchase and is not transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty claim.
IMPORTANT: This warranty does not cover damages resulting from use not in conformity with
the printed directions, accident, misuse or abuse, alternation, the affixing of any attachments not
provided with the product, loss of parts, or subjecting the appliance to any but the specified
voltage. (Read directions carefully.) This warranty is void if the product is used for other than
single-family household use or subjected to any voltage and waveform other than as specified on
the rating label (e.g., 120V ~ 60 Hz).
Englewood Marketing LLC excludes all claims for special, incidental, and consequential
damages caused by breach of express or implied warranty. All liability is limited to the amount
of the purchase price. Every implied warranty, including any statutory warranty or condition of
merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited
by law, in which case such warranty or condition is limited to the duration of this written
warranty. This warranty gives you specific legal rights. You may have other legal rights that vary
depending on where you live. Some states or provinces do not allow limitations on implied
warranties or special, incidental, or consequential damages, so the foregoing limitations may not
apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVICE
NUMBER.
For faster service, please have the model, type, and series numbers ready for the operator to
assist you.
Customer Service Number
Englewood Marketing LLC
In the US 844-918-0509
Email: CustomerService@emllc-USA.com
27
Loading...
