Fantec Full HD Media player User Manual

ENGLISH

Table of Contents

1. Introduction .......................................................................................................................... 3

1.1 Preface ........................................................................................................................ 3

1.2 Packing List ................................................................................................................. 4

1.3 Cautions ...................................................................................................................... 4

1.4 Connection .................................................................................................................. 6

1.5 Power On / Off ........................................................................................................... 1 1

1.6 Menu Language ......................................................................................................... 11

1.7 HDD Format .............................................................................................................. 12

2. About the Player ................................................................................................................ 13

2.1 Remote Control ......................................................................................................... 13

2.2 Front Panel ............................................................................................................... 15

2.3 Rear Panel ................................................................................................................ 15

2.4 Side Panel ................................................................................................................. 16

3. Setup Menu ........................................................................................................................ 16

3.1 Changing Audio Settings ........................................................................................... 17

3.2 Changing Video Settings .......................................................................................... 17

3.3 Changing Network Settings ...................................................................................... 19

3.4 Changing System Settings........................................................................................ 22

3.5 Miscellaneous ........................................................................................................... 24

4. Browser Menu .................................................................................................................... 25

4.1 Browsing All .............................................................................................................. 25

4.2 Browsing Music ......................................................................................................... 26

4.3 Browsing Photos ....................................................................................................... 26

4.4 Browsing Movies ....................................................................................................... 27

4.5 A/V Streaming via Network ....................................................................................... 28

4.6 A/V Streaming via UPnP-server ................................................................................ 30

4.7 Renaming / Deleting Files ......................................................................................... 32

4.8 Managing the Playlist ................................................................................................ 32

5. File Copy Menu .................................................................................................................. 33

6. Media Library ..................................................................................................................... 34

6.1 Music Library ............................................................................................................. 34

6.2 Photo Library ............................................................................................................. 37

6.3 Movie Library ............................................................................................................ 40

7. Internet Radio ..................................................................................................................... 43

8. Download ............................................................................................................................ 44

9. NAS Function (samba) ...................................................................................................... 46

10. IMS (Internet Multimedia Service) Menu ....................................................................... 47

11. Upgrading the Firmware ................................................................................................. 47

12. Appendixes....................................................................................................................... 48

12.1 Specifications .......................................................................................................... 48

12.2 Frequently Asked Questions ................................................................................... 49

12.3 Copyrights and Trademarks .................................................................................... 51

12.4 Warranty .................................................................................................................. 51

12.5 GPL Statement ........................................................................................................ 51

ENGLISH

2 / 56

1. Introduction

1.1 Preface

Thank you very much for purchasing FANTEC FULL HD MEDIA PLAYER. We h ope you will
enjoy using it as a great home entertainment partner. This player has the following
functionality.

A/V Output

• HDMI V1.3 for high-definition video and digital audio

• Composite & component video and stereo audio for analog audio-visual connection

• S/PDIF optical interface for high-fidelity digital audio

• Adjustable video output resolution (NTSC, PAL, 480p, 576p, 720p, 1080i, 1080p)

Multimedia Playback

• Supports major audio, video and image file formats (1 080p HD video decoding)

• Movie format: AVI/MKV/XVID/DIVX/TS/M2TS/MPG/MP4/M4V/MOV/VOB/ISO/IFO/DAT/

WMV/ASF/RM/RMVB/FLV/DVD MENU Playback/H.264

• Music format: MP3/OGG/WMA/WAV/A A C/FLAC/Dolby Digital/DTS/DTS downmix

• Photo format: HD JPEG/BMP/GIF/TIF/PNG

• Photo slide show with background music

Network Feature

• A/V streaming/transmission via Ethernet (10M/100M) & Wi-Fi (802.11b/g/n, optional)

• File sharing via Samba server

• A/V streaming via UPnP Media Server

• BitTorrent download

• Internet Radio (Please visit www.shoutcast.com

File Copy

• Supports copying & moving files among USB devices, Memory Card, Local HDD, and
Network

USB 2.0 Support

• USB DEVICE port (for computer connection)

• USB HOST port x 2 (for USB storage devices)

• SD / SDHC /MMC/ MS / MS Pro Card Reader

Note: All the information contained in this manual was correct at the time of publication.

for available stations)

However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified func tionality than presented in
this manual.

ENGLISH

3 / 56

1.2 Packing List

Part Quantity

Player 1
A/V cable 1
USB cable 1
Remote Control 1
Remote Control Battery 2
AC/DC adaptor 1
AC/DC adaptor Power Cord 1
User Manual (printed) 1
Driver CD (with User Manual) 1
Warranty card 1

Note:
The actual contents in the package might be different from the packing list in this manual.

1.3 Cautions

The FANTEC FULL HD MEDIA PLAYER design and manufacture has your safety in mind. In
order to safely and effectively use this player, please read the following before usage.

1.3.1 Usage Cautions

User should not modify this player. If commercial hard disk is bein g used, the environmental
temperature should be within +5℃ ~ +35℃.

1.3.2 Power

The player’s power voltage: DC 12V.
When using this player , please connect the supplied AC adapter or AC adapte r cable to the
player’s power jack. When placing the adapter cable, make sure it can not get damaged or be
subject to pressure. To reduce the risk of electric shock, unplug the adapter first before
cleaning it. Never connect the adapter to the player in a humid or dusty area. Do not replace
the adapter or cable’s wire or connector.

1.3.3 Radio Interference

- If not properly shielded, almost all electronic devices will get radio interference. Under some

conditions, your player might get interference.

- The design of this player has followed the FCC/CE standard, and has followed the following

rules:

(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that may
cause undesired operation.

1.3.4 Repair

If the player has a problem, you should take it to an appointed repair center and let the
specialists do the repair, never repair the player yourself, you might damage the player or
endanger yourself or your data.

ENGLISH

4 / 56

1.3.5 Disposing of the Player

When you dispose of the player, be sure to dispose it appropriately. Some countries may
regulate disposal of electrical device, please consult with your local authority.

1.3.6 Hard Disk Cautions

The player uses an internal hard disk for data storage, in normal case, format or repair is not
required.
You should carefully read the < Frequently Asked Questions > chapter, and check our website
for latest information before formatting the hard disk.

- Physical impact may create bad sector in the hard disk, you can use CHKDSK to fix the

problem.

- All data stored in the player may be lost due to physical impact, electrical shock, power lost,

HDD format etc. Please backup your data.

- It is suggested to do defragment after a long period of usage.

- Regularly backup the data in the hard disk so that it can be recovered in the event of data

corruption or loss. Our company takes no responsibility for loss of dat a stored on the hard disk.

1.3.7 Others

When using this player , please do not let the player come into cont act with water or other liqui d,
if water is accidentally spilled on the player, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the player, and
do not press the buttons too hard.

 Do not let the player come into contact with water or other liquid.
 Do not disassemble the player, repair the player or change the design of the player, any

damage done will not be included in the repair policy.

 Do not press the buttons of the player too hard.
 Avoid hitting the player with hard object, avoid shaking the player, and stay away from

magnetic fields.

 During electrostatic discharge and the strong electromagnetic field, the product will

malfunction, then unplug the power cable and the product will return to normal
performance next time it is powered on.

ENGLISH

5 / 56

1.4 Connection

1.4.1 Connecting the Power Supply

(1) Follow the picture and connect the AC adaptor to the player’s DC IN jack;
(2) Follow the picture and plug in the AC adaptor to the power outlet.

1.4.2 Connecting to a PC

(1) Make sure the player is powered on;
(2) Plug in the squarish connector of the USB cable to this player’s USB DEVICE port;
(3) Plug in the rectangular connector of the USB cable to computer.

In this way, you can manage content on the built-in HDD of the player on your local PC.

ENGLISH

6 / 56

1.4.3 Connecting a USB Device

(1) Make sure the player is powered on;
(2) Plug in the USB stick or USB HDD etc. to the USB HOST port of this player.

In this way, you can browse contents on the USB device.

1.4.4 Connecting a Memory Card

Memory card can be used by inserting to the card slot
(1) Follow the picture to insert the memory card to the card slot properly;
(2) Insert the card by following the arrow pointer in the picture.

In this way, you can browse contents on the memory card.

ENGLISH

7 / 56

1.4.5 Connecting to a TV

1.4.5.1 A/V OUT

(1) Follow the picture and plug in the 3 color connector to the player’s A/V OUT jack;
(2) Follow the picture and plug in the 3 color connector to the TV’ s A/V IN jack.
In this way, you can enjoy the content in the player on TV or other display devices.

1.4.5.2 Y/Pb/Pr Component OUT

(1) Follow the picture and plug in the 3 color connector to the player’s Y/Pb/Pr jack;
(2) Follow the picture and plug in the 3 color connector to the TV’ s Y/Pb/Pr jack.
Audio Connection while using Y/Pb/Pr Video out:
First method: use the audio output from the A/V OUT jack;
Second method: use the audio output from the S/PDIF Coaxial or Optical jack.

ENGLISH

8 / 56

1.4.5.3 HDMI OUT

(1) Follow the picture and plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV’s HDMI jack.
Note: The HDMI cable is an optional accessory sold separately.

In this way, you can have the highest quality video and audio via a single cable.

1.4.6 Connecting to an Digital Amplifier

(1) Follow the picture and plug in the Toslink connector on your optical fiber to the player’s
S/PDIF Optical jack;
(2) Follow the picture and plug in the other connector on your optical fiber to the digital audio
device (digital amplifier or decoder).

Note: Optical fiber cable is not supplied.

In this way, you can enjoy powerful Dolby Digital/ DTS or MPEG sound. (Please refer to ‘3.1
Changing Audio Settings’ for configuration)

ENGLISH

9 / 56

1.4.7 Connecting to a LAN

To connect to a LAN (Local Area Network) you require a cat5, cat5e or cat6 n etwork cable (not
supplied).
(1) Connect one of the crystal plugs on the cable to the player’s RJ45 LAN socket;
(2) Connect the other crystal plug on the cable to a RJ45 LAN port on your router, switch, or
hub devices.

1.4.8 Connecting to a WLAN

(1) Make sure the player is powered on;
(2) Plug the Wireless LAN USB Adapter (i.e. Wi-Fi USB Dongle) to the USB HOST port of the
player.

Note: The Wi-Fi Dongle is an optional accessory sold separately. (Please refer to ‘3.3
Changing Network Settings’ for more details about wireless setup)

ENGLISH

10 / 56

1.5 Power On / Off

Power On

After connecting the DC IN jack and press the power button on the front panel, the player will
soon enter the home screen, and the power indicator will turn blue.

Power Off

Press the power button on the front panel, the player will soon enter standby mode, and the
power indicator will turn red. Then unplug the power cord to cut of f the power supply.

1.6 Menu Language

The system language of this player can be set to English or other languages. Change the
language you wish in the setup menu, the selected language will take effect immediately.

ENGLISH

11 / 56

1.7 HDD Format

For users who wish to install a new SATA HDD into the player, please refer to the following
procedures to format the hard disk on the player before usage.
Note: This page can be also accessed via Setup->System->HDD Format menu.

- Step 1: Select OK on the Warning page, press ENTER to confirm.

- Step 2: Select Format, press ENTER, and then hard disk format will st art.

The formatting procedure will be finished within a few minutes. And then you can use the hard
disk properly on the player.

Note: HDD format will remove all data stored on the hard disk drive. Please take care and
backup your data in advance!

ENGLISH

12 / 56

2. About the Player

2.1 Remote Control

All procedures in this manual can be carried out using the remote control buttons.
See the following for details on each button and its function:

1. STANDBY 2. MUTE

3. TV SYSTEM 4. BROWSER

5. Numeric buttons 6. REPEAT

7. FR 8. VOL-

9. FF 10. PLAY

11. HOME 12. Navigational buttons

13. MENU 14. PAUSE/STEP

15. SLOW 16. INS REPLAY

17. CM SKIP 18. SELECT

19. CONFIRM 20. AUDIO

21. SUBTITLE 22. ZOOM IN

23. ZOOM OUT 24. A-B

25. ANGLE 26. SETUP

27. RETURN 28. ST OP

29. NEXT 30. VOL+

31. PREV 32. GOTO

33. COPY 34. MUSIC

35. INFO

No. Button Function

1
2

STANDBY
MUTE

Press to enter standby mode or wake up.
Press to mute audio output, and press again to resume.

3

TV SYSTEM

4

BROWSER

5

Numeric buttons

6

REPEAT

7

FR

Press to switch between NTSC, PAL, 480P, 576P, 720P, 1080I,
and 1080P.

Press to enter the browser menu.
Press to enter numeric input when changing settings.
Press to set repeat option: One, All and Shuffle.
Press to fast rewind the current playback. Press repeatedly to

select speeds.

ENGLISH

13 / 56

8

VOL-

9

FF

10

PLAY

11

HOME

12

Navigational
buttons

13

MENU

14

PAUSE/STEP

15

SLOW

Press to decrease the volume.
Press to fast forward the current playback. Press repeatedly to

select speeds.
Press to begin playback.
Press to enter the home screen.
Press the arrow buttons to select menu options, and the ENTER

button to confirm.
Press to activate tools menus:

z Press in the browser menu to rename and delete files.

z Press in My_Shortcuts in NET of the browser menu to

add shortcuts for network access.

Press to pause the current playback. Press again to step to the
next frame. Press the PLAY button to resume playback.

Press to play back in slow motion. Press the PLAY button to
resume regular playback.

16

INS REPLAY

17

CM SKIP

18

SELECT

19

CONFIRM

20

AUDIO

21

SUBTITLE

22

ZOOM IN

23

ZOOM OUT

24

A-B

25

ANGLE

26

SETUP

27

RETURN

28

STOP

Press to backward 10 seconds of the current playback, which
suitable for sport programs.

Press to advance 30 seconds of the current playba ck.
Press to select files in browser and file copy menu.
Press to confirm and add the selects to the playlist.
Press to select an audio track.
Press to set subtitle options.
Press to zoom in the image (photo or video).
Press to zoom out the image (photo or video).
Press to set the beginning and end points of a section to repeat.
Press to change the view angle during DVD (with multi-angle)

playback.
Press to enter the setup menu.
Press to return to the previous screen while navigating menus.

Press to stop playback.
29
30
31
32

33

NEXT
VOL+
PREV
GOTO

COPY

Press to view the next file / page down.

Press to increase the volume.

Press to view the previous file / page up.

Press to jump to a specific point on a title. Specify the point

using Title, Chapter and Time.

Press to enter the file copy menu.

ENGLISH

14 / 56

34

MUSIC

35

INFO

2.2 Front Panel

Press to start playing music in the music playlist.

Press to hide or display the information bar during playback.

1. Infrared receiver 2. USB/card indicator

3. Power indicator

2.3 Rear Panel

1. UPDATE button (see chapter 11.) 2. DC IN jack

3. Y/Pb/Pr OUT jack 4. A/V OUT jack

5. HDMI jack 6. RJ45 LAN socket

7. S/PDIF OPTICAL jack 8. USB HOST port (A-Type)

ENGLISH

15 / 56

2.4 Side Panel

1. USB DEVICE port (B-Type) 2. USB HOST port (A-Type)

3. Memory Card slot

3. Setup Menu

The Setup menu allows you to personalize and configure the preferences for your player.

To select a Setup option:

- Select the Setup icon on the home screen, or press the SETUP button on the remote
control.

- Use the LEFT/RIGHT navigational buttons to select an option, and then press ENTER.

There are five Setup options, including Audio, Video, Network, System, and MISC. Use the
UP/DOWN navigational buttons to select a menu. Press ENTER to confirm. Press RETURN to
cancel and display the previous menu screen.

ENGLISH

16 / 56

3.1 Changing Audio Settings

Use this menu to configure audio settings.

Night Mode

- Choose between Off / On / Comfort. If the option is turned on, the audio output volume
will be decreased to make you more comfortable.

Digital Output

- Choose between HDMI LPCM / HDMI RAW / SPDIF LPCM / SPDIF RAW. In raw mode,
Dolby Digital or MPEG sound can be bypa ssed to the HDMI TV or Digital amplifier.

3.2 Changing Video Settings

Use this menu to configure video settings.

Aspect Ratio

- Pan Scan 4:3: Display a wide picture on the entire screen and cuts off the redundant
portions. Select when a standard 4:3 TV is connected.

- Letter Box 4:3: Display a wide picture with two black borders on the top and bo ttom of 4:3
screen. Select when a standard 4:3 TV is conne cted.

- 16:9: Compress the image to convert the whole image. Select when a 16:9 TV is
connected.

ENGLISH

17 / 56

Zoom Out

- Turned on, the player will auto zoom out the video resolution to fix the TV screen.

Brightness

- Adjust the level of brightness.

Contrast

- Adjust the level of contrast.

Hue

- Adjust the level of hue.

Saturation

- Adjust the level of saturation.

Video System

- Select to adjust video output resolution: NTSC / PAL / 480P / 576P / 720P 50HZ / 720P
60HZ / 1080I 50HZ / 1080I 60HZ / 1080P 50HZ / 1080P 60HZ.

1080P 24FPS

- Choose this option to enable or disable 1080P 24HZ support. A TV set with 1080P 24HZ
(24P) mode is needed.

Screen Size

- Choose this option to adjust the screen size.

Seamless Playback

- Uninterrupted playback of video and audio files
(the naming of the files should be alike “abc01.AVI” and “abc02.AVI”, etc)

ENGLISH

18 / 56

3.3 Changing Network Settings

Use this menu to configure Ethernet and WLAN (Wireless Local Area Network) settings.

Wired LAN Setup

- DHCP IP (AUTO)
Select to obtain IP address automatically.

- FIX IP (MANUAL)
Select to manually input the IP Address, Subnet Mask, Default Gateway, and DNS Server

IP Address.

Wireless Setup

- Selecting a connection profile

This player can store up to three wireless network connections. Press ENTER to go to
next step, press RETURN to cancel, and press PLAY to connect.

ENGLISH

19 / 56

- Get Connection Mode

Choose between Infrastructure (AP) and Peer to Peer (Ad Hoc). Press ENTER to go to
next step, and press RETURN to cancel.

- Infrastructure (AP)
Infrastructure mode is used to connect computers with wireless network adapters, also
known as wireless clients, to an existing wired network with the help from wireless router
or access point.

Get SSID Name

Press ENTER to go to next step, press RETURN to cancel, and press SELECT to refresh
the SSID list.

Note: In the Security list, WEP (Wired Equivalent Privacy) and WPA (Wi-Fi Protected
Access) means the network is encrypted, i.e. an encryption key is needed to access the
network. NONE means it is an open system network.

ENGLISH

20 / 56

Input WEP / WPA Key

Encryption keys can be inputted via the virtual keyboard. Press the navigational buttons to
select, ENTER to input, CAPS to switch between uppercase and lowercase, <- to delete a
character, -> to insert a space, shift to make m ore symbols available, and OK to confirm.

Test connection

The testing process will take for a while, please be patient to wait. If the test is ok, the
network information (Profile Name, IP address, Subnet Mask, Gateway, etc.) will be
displayed on the screen.

- Peer to Peer (Ad Hoc)
Peer to Peer mode, which is also called Ad Hoc mode or computer-to-computer mode, is
used to connect wireless clients directly together, without the need for a wireless router or
access point.

ENGLISH

21 / 56

Ad-Hoc Setup

Press ENTER to go to next step, press RETURN to cancel, and press PLAY to connect.

Host Name

- Choose the network name of the player.

BitTorrent and SAMBA

- Turn on/off BitTorrent and Samba

3.4 Changing System Settings

Use this menu to configure system settings.

Menu Language

- Select to choose the OSD (On-Screen Display) language. (English, Espanol, French,
German, Italiano, Dutch, Russky, Polski, Cesky, Slovensky, Romania, Portugees, Hebrew,
Magyar, Slovenscina)

Text Encoding

- Select to set the text encoding option (subtitle display).

ENGLISH

22 / 56

System Update

- Select Extension Package Upgrade to update extension files for BT download, NAS, and
Web server.

- Select system upgrade to update the firmware via a USB stick.

1) Copy ‘install.img’ to the root directory of a USB stick, and connect it to the USB HOST

port of the player.

2) Press ENTER to confirm.

Time

- Select to set the system time.

HDD Format

- Select to format the built-in HDD.

Note: Please take care that all data on the hard disk will be removed after formatting.

System Info

- Select to view system information (firmware version, HDD info, Mac address, etc.)

Restore Default

- Select to restore factory defaults.

ENGLISH

23 / 56

3.5 Miscellaneous

Use this menu to adjust miscellaneous settings.

Resume Play

- Select to turn on / off resume playback (auto-bookmarking) feature for movies.

Slide Show Timing

- Select to set the interval time for photo slide show .

Transition Effec t

- Select to set the transition effect for photo slide show.

Ken Burns

- Slow zooming function during Photo playback.

Background Music

- Select to set the background music options while view pictures: Off / Folder / Playlist.

Screen Saver

- Select to turn on / off screen saver.

Movie Preview

- Select to turn on / off movie preview in the browser menu.

Subtitle on-off

- Turn on/off subtitle

ENGLISH

24 / 56

4. Browser Menu

The browser menu allows you to browse and play media files stored on USB devices, Local
HDD, Network, UPnP-server, and Playlist. To enter the menu, select the Browser icon on the
home screen, or press the BROWSER button on the remote control.

The following buttons can be used while navigating the browser menu.

Button Function

UP / DOWN

LEFT / RIGHT Select filter options: All, Music, Photos, and Movies.

PREV / NEXT

ENTER

SELECT Select files under Browser -> HDD menu.

CONFIRM

RETURN

4.1 Browsing All

Move cursor up / down to select devices, folders, or files.

Go to previous / next page.
Enter or confirm the selected item.

Add the selected files to the playlist.
Return to the previous menu.

In this mode, all folders and supported contents (music, photos, and movies) will be displayed.

Note:

• Please refer to chapter ‘9.1 Specifications‘for more about the supported content formats.

• Music tracks might not be able to played continously under All filter, please switch to the

Music filter instead.

ENGLISH

25 / 56

4.2 Browsing Music

In this mode, all folders and supported audio files in current directory will be displayed.

The following buttons can be used to control music playback.

Button Function

PLAY

PAUSE / STEP

FR / FF

REPEAT Set repeat options: One, All, and Shuffle.

INFO

STOP

Begin playback.
Pause playback.
Fast rewind or fast forward. Press repeatedly to select the speed.

Hide or display the information bar during playback.
Stop playback.

4.3 Browsing Photos

In this mode, all folders and supported image files in current directory will be displayed.

The following buttons can be used to control music playback.

Button Function

PLAY

PREV / NEXT

LEFT / RIGHT

ZOOM IN / OUT

INFO

STOP

You can view photos in slide show mode with background mu sic. When it is enabled, the slide
show starts automatically once you press PLAY button. (Please refer to Slide Show Timing,
Transition Effec t, and Bac kground Music in chapter ‘3.5 Miscellaneous’ for more details)

Begin playback.
View the previous or next photo.
Rotate a photo in any angle.
Zoom in / out the image.
Hide or display the information bar during playback.
Stop playback.

ENGLISH

26 / 56

4.4 Browsing Movies

In this mode, all folders and supported video files in current directory will be displayed.

The following buttons can be used to control video playback.

Button Function

PLAY

PAUSE / STEP

SLOW

FR / FF

PREV / NEXT

REPEAT Set repeat options: Title, Chapter, and All.

ZOOM IN / OUT

INFO

GOTO

A-B

ANGLE

MENU

INS REPLAY

CM SKIP

AUDIO

SUBTITLE

STOP

Begin playback.
Pause playback; Press again to step to next frame.
Play video in slow motion. Press repeatedly to select the speed.
Fast rewind or fast forward. Press repeatedly to select the speed.
View the previous or next movie.

Zoom in / out the image.
Hide or display the information bar during playback.
Display playback search menu.
Set the beginning and end points of a section to repeat.
Change the view angle during DVD (with multi-angle) playback.
Return to the root menu during DVD playback.
Backward 10 seconds of the curren t playback
Advance 30 seconds of the current playback.
Select an audio track while watching DivX video or DVD with
multiple audio tracks.
Set subtitle options.
Stop playback.

ENGLISH

27 / 56

4.5 A/V Streaming via Network

You can stream the media files shared on the home network (Ethernet or WLAN). Please refer
to ’3.3 Changing Network Settings’ for details about network settings.
There are two ways to locate media files shared on your local network in the Network menu.
One is to browse through Workgroup; the other way is to browse through ‘My_Shortcuts’.

4.5.1 Browsing through Workgroup

You can choose the workgroup which your PC belongs to from the workgroup list, find your PC
name, and press the ENTER button to confirm. Then you can select and play the shared
media files that you want to browse.

Note:

• While browsing high definition video files (resolution up to 720p / 1080i / 1080p) via
Ethernet or WLAN, the video might be buffering. It is normal due to the limit of network
speed or signal strength.

• Due to different network conditions, sometimes the workgroup might not be accessed or
shown in the list. And then you need to use ‘My_Shortcuts’ to browse shared files.

ENGLISH

28 / 56

4.5.2 Browsing through ‘My_Shortcuts’

You can also set ‘Specific File Server IP’ and access it from ‘My_Shortcuts’ in the menu.

- Press the MENU button and a popup menu appears.

- Select Add to open a popup menu where you can input Net User ID (Username), Net

Password, Domain, Host Name, and Specific File Server IP of destination PC. Select
OK to confirm, Cancel to cancel, and Simple / Detail to switch between simple and

advanced options.

- Select the shortcut you added and press the ENTER button to confirm. Then you can
select and play the shared media files on the destination computer.

ENGLISH

29 / 56

4.6 A/V Streaming via UPnP-server

A built-in UPnP (Universal Plug and Play) client has been integrated on the system, which
enables the player to auto-detect UPnP Media Servers on the network to browse and stream
media files from them.

4.6.1 Installing UPnP Media Server on your PC

There’re a lot of free and commercial UPnP Media Server software, such as Wi ndows Media
Connect, Windows Media Player 11, XBMC Media Center (Linux/Mac/Windows), MediaTomb
(Linux), etc. Please install one of them on you computer. In the fol lowing chapters, we will take
Windows Media Player 11 on Microsoft Windows XP SP2 for an example.

4.6.2 Sharing Media on your PC

The Media Sharing feature of Windows Media Player 11 lets you enjoy the contents of your
Windows Media Player library from anywhere in your home.

- Open Windows Media Player 11, click Library -> Add Library -> Advanced Options to
add or remove media files from the library.

- Click Library -> Media Sharing, then you can allow or deny devices to access the media
library. Click Allow to authorize your player.

ENGLISH

30 / 56

4.6.3 Streaming Media on your Player

- Connect your player to the home network (LAN or WLAN).

- Visit Browser - > UPnP menu on the player, select the UPnP-server, and press ENTER.

- Then you can browse the media library shared by Windows Media Player 11.

Note:

• Make sure your player and your computer are on the same local area network and subnet.

• Firewalls may prevent your player to communicating with your computer. Please open the

ports manually and add your player to the ‘trusted’ list, or disable the firewall temporarily.

ENGLISH

31 / 56

4.7 Renaming / Deleting Files

When navigating in the browser menu, you can press the MENU button to activate a popup
menu where you can rename and delete files or folders.

Press the UP / DOWN buttons to select from Return, Rename, and Delete. And press ENTER
to confirm.

4.8 Managing the Playlist

This player supports the playlist function, which allows you to add your favorite contents o n
local HDD to the playlists (All, Music, Photos, and Movies), and enjoy them at any time.

4.8.1 Adding files to the playlist

Select the favorite file you wish to add, press the SELECT button, and the file will be marked.
Press the CONFIRM button to confirm, and then an on-screen message ‘Add selects to list’ will
be shown. Multiple selections are allowed. See photo below.

ENGLISH

32 / 56

4.8.2 Browsing the playlist

Press the UP / DOWN buttons to select Play List in the browser menu. Press the LEFT /
RIGHT buttons to select between All, Music, Photos, and Movies. And press the ENTER

button to confirm. Then you will enter the playlist.

If you wish to delete a file from the playlist, press the SELECT button to select, and then press
the CONFIRM button to confirm.

5. File Copy Menu

Select the File Copy icon from the home screen to enter the File Copy menu, which allows
you to copy files between USB devices, Local HDD, and Network.

The following buttons can be used under the file copy menu.

Button Function

UP / DOWN

RIGHT

SELECT

STOP

ENTER

Move cursor up / down to select devices, folders
Go to the next step.
Select (or cancel) folders or files (The selected items will be
ticked).
Cancel all selections.
Confirm the selected options.

ENGLISH

33 / 56

Please refer to the following operations to copy / move folders / files between devices.

- Step 1: Select the source device and destination device.

- Step 2: Select the source files you want to copy.

- Step 3: Select the destination folder to store the above files.

- Step 4: Select Copy or Move to proceed.

6. Media Library

This is a powerful search engine. The media library menu allows you to search and browse
multimedia files stored on the internal HDD. To enter this menu, select the Media Library icon
on the home screen.

6.1 Music Library

Use the left / right button on the remote control to select the Music tab.

ENGLISH

34 / 56

Press the up / down button to select from Update, Search, All, Artist, Genre, and Album. And
press the enter button to confirm.

Update

Search

Select to update and synchronize all the music stored on the internal HDD
to the library.

Select to search for music files by their na mes.

Use the navigational buttons to select, and press the enter button to
confirm. Select OK and press the enter button, and then the files you
desired will be displayed on the screen.

ENGLISH

35 / 56

All

Artist

Select to list all the music files in the library.

Select to list all the music files by artist.

Genre

Press the up / down button to select the artist, and press the enter button
to confirm.

Select to list all the music files by genre.

Press the up / down button to select the genre, and press the enter
button to confirm.

ENGLISH

36 / 56

Album

Quick-Search

Select to list all the music files by album.

Press the up / down button to select the album, and press the enter
button to confirm.

You can also press the right button to turn on a Quick-Search bar while
browsing music files in the library.

Press the up / down button to select characters on the Quick-Search bar,
and press the enter button to confirm. The music files with the specific
characters will be displayed. Press the left button to delete characters,
and press the return button to close the Quick-Search bar. Finally press
the enter button to start playback.

6.2 Photo Library

Use the left / right button on the remote control to select the Photos tab.

ENGLISH

37 / 56

Press the up / down button to select from Update, Search, All, and Date. And press the enter
button to confirm.

Update

Search

Select to update and synchronize all the photos stored on the internal
HDD to the library.

Select to search for photos by their names.

Use the navigational buttons to select, and press the enter button to
confirm. Select OK and press the enter button, and then the files you
desired will be displayed on the screen.

ENGLISH

38 / 56

All

Date

Select to list all the photos in the library.

Select to list all the photos by date.

Quick-Search

Press the up / down button to select the date, and press the enter button
to confirm.

You can also press the right button to turn on a Quick-Search bar while
previewing photos in the library.

Press the up / down button to select characters on the Quick-Search
bar, and press the enter button to confirm. The photo files with the
specific characters will be displayed. Press the left button to delete
characters, and press the return button to close the Quick-Search bar.
Finally press the enter button to start playback.

ENGLISH

39 / 56

6.3 Movie Library

Use the left / right button on the remote control to select the Movies tab.

Press the up / down button to select from Update, Search, All, Actor, Genre, and Year. And
press the enter button to confirm.

Update

Search

Select to update and synchronize all the movies stored on the internal
HDD to the library.

Select to search for movies by their names.

Use the navigational buttons to select, and press the enter button to
confirm. Select OK and press the enter button, and then the files you
desired will be displayed on the screen.

ENGLISH

40 / 56

All

Actor

Select to list all the movies in the library.

Select to list all the movies by actor.

Genre

Press the up / down button to select the actor, and press the enter button
to confirm.

Select to list all the movies by genre.

Press the up / down button to select the genre, and press the enter
button to confirm.

ENGLISH

41 / 56

Year

Quick-Search

Select to list all the movies by year.

Press the up / down button to select the year, and press the enter button
to confirm.

You can also press the right button to turn on a Quick-Search bar while
previewing movies in the library.

Press the up / down button to select characters on the Quick-Search bar,
and press the enter button to confirm. The movie files with the specific
characters will be displayed. Press the left button to delete characters,
and press the return button to close the Quick-Search bar. Finally press
the enter button to start playback.

Note:

In order to use the search function more efficiently, you are encouraged to use the following
rules to name the movies stored on the internal HDD.

Syntax: [Name][Actor][Genre][Year].extension

Examples:
[Enchanted.CD1][Amy Adams][Love][2007].avi, [The.Dark.Knight.CD1][Christian
Bale][Action][2008].mpeg

ENGLISH

42 / 56

7. Internet Radio

This player integrates the SHOUTcast free Internet radio function. Select the Internet Radio
icon on the main interface to enter this menu.

Note:

• Make sure the player is connected properly to a LAN or WLAN with Internet access,
please refer to ‘3.3 Changing Network Settings’ for more details;

• When you enter the Digital Radio menu at the first time, it will take several seconds to
download data from the Internet, please be patient to wait.

The following buttons can be used under this menu.

Button Function

UP / DOWN

PREV / NEXT

ENTER

MENU Add / delete a station to / from Favorite while it is highlighted.

PLAY
STOP

RETURN

Move cursor up / down to select station, channel, and genre.
Page up / down.
Confirm and enter the selected menu.

Begin playback after a channel has been selected.
Stop playback.
Return to the previous menu.

Station

- All downloaded stations will be listed under this menu.

Genre

- You can search for stations by genre (pop, rock, ja zz, etc.) under this menu.

Favorite

- Your favorite stations can be kept under this menu.

Search

- You can search for radio stations. (Ple ase visit www.shoutcast.com

for available stations)

ENGLISH

43 / 56

8. Downloads

Select the P2P Share icon on the main menu. You can see the status of torrents download
progress and configure the BT download setting s in this menu. Press LEFT/RIGHT button to
enter into download menu and BT setup menu.

Add a new torrent

Locate your torrent file in Browser menu,then press MENU button to add the torrent to start
downloading.

Download Menu

After add the BT torrent files, the download progress can be display ed in this menu.

The following buttons can be used under this menu.

Button Function
UP / DOWN

Move cursor up / down.

ENGLISH

44 / 56

MENU

PAUSE
PLAY
STOP

press to adjust the priority of the download task

Press to pause the download.
Press to start download.
Press to stop the download.

RETURN

Return to the previous menu.

BT setup Menu

In the BT Setup menu, you can configure the following settings. Use UP/DOWN and ENTER
to change the settings.

- Set the maximum download rate.

- Set the maximum upload rate.

- Set the idle hours to start the next download automatically.

- Set the seeding hours.

- Set to delete the finished torrent files automatically or not.

- Set the maximum number of simultaneous download tasks.

ENGLISH

45 / 56

9. NAS Function (samba)

This player can be used as a NAS (Network-Attached Storage) device. It can be attached to
the home network via either Ethernet or WLAN. This feature allows storing and retrieving large
amounts of data more affordably than ever before.

When the network connection is done correctly, please enable BitTorrent and SAMBA in the
setup menu to use the NAS function (refer to 3.4 Changing System Settings for more details),
and then type: \\IP
of Internet Explorer on your PC (For example, if the IP address of the player is 192.168.0.9,
please type: \\192.168.0.9

Address in the Run window (click Run in the start menu) or the address bar

), and click OK or press the Enter button on the keyboard.

Under windows vista and windows 7, please type:\\192.168.0.9
Enter button on the keyboard.

Then you can view, and edit the files stored on the hard disk installed on the player. In this way,
you can also playback and copy files via network between your PC and the pla y er.

NOTE:

1. Please run SAMBA in the setup menu before using this function.

on search bar, then press the

ENGLISH

46 / 56

10. IMS (Internet Multimedia Service) Menu

This feature is additional function. All contents and services under this feature are provided by
third-party service providers, our company does not offer any contents and services of this
feature and is not responsible for any contents and services provided under this feature. Our
company is not responsible for any operational stability of the contents and services, for
example, if you cannot access certain web site for video streaming or news broadcast, or the
content of a web site has been changed etc, are all responsible and control by the third-party
service providers. If you find that these features cannot operate properly, please contact our
Customer service or visit our company website to obtain the relevant information.

11. Upgrading the Firmware

The firmware is the operating system (OS) installed on the device. Firmware upgrades can
bring new features, improvements and bug fixes.

Please refer to System Update in chapter ‘3.4 Changing System Settings’ for more details.

You can also use the following method to upgrade the firmware:

- Copy ‘install.img’ to the roo t directory of a USB key;

- Plug the USB key to the USB HOST port on the player;

- Press and hold the update button on the rear panel, and connect the player with power
supply;

- Wait for more than 30 seconds, and then loose your finger on the update button.

Then the upgrade process will start automatically. The LED indicator on the front panel will be
enlightened and flashing during installation. If it is connected to a TV set, an install page will
appear on the TV screen.

ENGLISH

47 / 56

12. Appendixes

12.1 Specifications

I/O INTERFACES SUPORTED:

z 3.5’’ SATA HDD
z USB 2.0 HOST port x 2 (compatible to USB 1.1)
z Card Reader (supports SD/SDHC/MMC/ MS/MS Pro)
z USB 2.0 DEVICE port (connecting to PC)
z Composite (CVBS) A/V jack
z Component Y/Pb/Pr jack
z HDMI V1.3 interface
z S/PDIF optical jack
z DC-IN 12V

FILE SYSTEM SURPORTED:

z FAT/FAT32/NTFS/EXT3

CONTENT FORMA TS SUPPORTED:

• AVI/MKV/XVID/DIVX/TS/M2TS/MPG/MP4/M4V/MOV/VOB/ISO/IFO/DAT/
WMV/ASF/RM/RMVB/FLV/DVD MENU Playback/H.264

z MP3/OGG/WMA/WAV/AAC/FLAC/DOLBY DIGITAL/DTS/DTS Downmix
z HD JPEG/JPG/BMP/GIF/TIF/PNG

VIDEO CODECS SURPORTED:

z MPEG-1
z HD MPEG-2
z HD MPEG-4 SP/ASP/AV C (H.264)
z WMV9 (VC-1)
z RealNetworks (RM/RMVB) 8/9/10, up to 720p

AUDIO CODECS SURPORTED:

z MP2/3, OGG Vorbis, WMA (DRM, and Advanced Profile not supported), PCM, LPCM,

MS-ADPCM, LC-AAC, HE-AAC, COOK, RA-Lossless

SUBTITLE FORMATS SURPORTED:

z SRT, SMI, SSA, ASS, IDX/SUB, SUB

NETWORK FEATURE

z 10/100Mbps Auto-Negotiation Ethernet

802.11b/g/n WLAN, up to 300Mbps (supported by optional Fantec WLAN USB
Adapter)

Note: The specifications and design of this product are subject to change without notice.

ENGLISH

48 / 56

12.2 Frequently Asked Questions

Question 1. When I try to disconnect the USB device, I keep on getting “The device
‘Generic volume’ cannot be stopped right now. Try stopping the device ag ain later.”
message, what should I do?

Answer:
Close any program that might be accessing data on the player, including Windows® Explorer.
If it does not work, close all programs and wait for another 20 seconds, then try the green
arrow icon again. If it still does not work, you should shut down the player and disconnect the
USB cable.

Question 2. I find new file names and folder names that I never created before or they
have strange gibberish names.

Answer:
Most likely, the player’s file allocation table (F AT) has been corrupted. This might be due to the
player shutting down (due to low battery power) while reading or writing to your computer by
the USB connection. Windows and Macintosh often write extra files to the hard disk such a s
finder.def or System volume info. These are normal and will not do any harm to the player.

Question 3. I used my player to transfer files back and forth between different
computers. Will defragmenting the player hard disk do any harm to it?

Answer:

Defragmenting the player hard disk may be useful after having transferred many files to and
from the player. It is never harmful to use the defragment on the player. Make sure no oth er
programs are running while using the Windows® defragment utility. Make sure you have
connected the player with the external power adapter during this procedure.

Question 4. My files have disappeared from the player.

Answer:

Make sure that you browse your files via the correct browser mode which means correct
filtered views such as Photos, Music, or Movies.

Question 5. During power on, why does the TV will have a short flashing, blue screen or
screensaver?

Answer:

This is normal, when the system initializes, it will setup the co rrespo nding parame ters so it can
output the correct video signal to the TV, during the initializing time, the TV will receive
incorrect signals or the signals will not be stable and will cause the TV screen to flash, some
TV’s will treat this as no signal, and will display a blue screen or screensaver.

Question 6. Why when I switch to Y/Pb/Pr 480p, 576p, 720p, 1080i, and 1080p, does the
TV screen display an unwatchable picture?

Answer:

ENGLISH

49 / 56

Please check if your TV supports Y/Pb/Pr 480p, 576p, 720p, 1080i, and 1080p output, if your
TV does not support, please use the A/V signal display instead, press the TV SYSYEM button
on the remote control, then switch the TV’s video input to NTSC or PAL.

Question 7. Why is there no sound on movie or music playback when using Y/Pb/Pr
component output?

Answer:

Y/Pb/Pr output is a video output only, and does not include sound signals. When using Y/Pb/Pr
output, please plug the A/V OUT or the S/PDIF jack to output sound.

Question 8. I cannot get SSID name, the screen always displays: ‘Can’t get any SSID!!’

Answer:
When the WLAN USB Adapter is connected to the player, it needs some time to get initialized.
Please wait for about 1~2 minutes and try refreshing the SSID list again.

Question 9. I cannot see files shared on my computer via Browser->Network menu.
Answer:

Please check following items:

1) Connect the player to network and obtain an IP address first;

2) Please enable NetBIOS of TCP/IP on computer;

3) Please check your PC’s firewall settings;

4) Please enable your PC’s ‘Guest’ account;

5) Please share the folders which you wish to browse on your PC, and make sure that
‘Everyone’ or ‘Guest’ has the right to access.

Question 10. I configured everything correctly, but still cannot get the wireless network
or UPnP function to work.

Answer:
Are you using a firewall such as Norton Internet Security, McAfee Personal Firewall, Zone
Alarm, etc. or even the built-in firewall of Windows XP? (Don’t forget that Service Pack 2 for
Windows XP automatically upgrades your firewall and turn it on by default)

If you have a firewall, it may need to be configured or have exceptions created to allow you to
see and communicate with the player on the network. To test if your firewall is preventing
network communication (including PING and access shared folders), try disabling it to see if
you can connect. If you can connect with the firewall disabled, you may need to add the player
to the ‘Trusted’ list or configure the firewall for local intranet access. Worst-case, disable your
firewall long enough to use the player, then enable it again when done.

Question 11. I am using the 802.11n Wi-Fi dongle with an 802.11n wireless router, why
the speed is still 802.11g 54Mbps rather than 300Mbps?

Answer:
The IEEE 802.11n Draft standard prohibits using high throughput with WEP or TKIP as the
unicast cipher. If you use these encryption methods (e.g. WEP, WPA-TKIP), your data rate will
drop to 54 Mbps. You may contact the Access Point or router manufacturer to download the

ENGLISH

50 / 56

latest firmware, or try other encryption methods (WPA2-AES or WPA2-TKIP), or choose to
configure an unsecured profile, but this option is not recommended.

12.3 Copyrights and Trademarks

Copyrights
All rights reserved. No part of this manual may be reprod uced, or transmitted in any form or

by any means, whether by electronically or mechanically, without the express written
permission from the copyright holder.
Copyrighted materials, such as software, music files, or movies, are protected by local law, and
may not be illegally copied or used without permission from the copyright owner.

Trademarks

Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks are property of their respective holders.

12.4 Warranty

What your warranty does not cover:

-Acts of nature, such as fire, static discharge.

-Damage from unauthorized repair, alteration or accident.

-Damage from misuse or neglect.

-A unit that has been modified or incorporated into other products or is used for institutional or

other commercial purposes.

-Loss of customer’s software, firmware, information, or memory data.

-Improper handling or installation.

12.5 GPL Statement

This product contains free software which is licensed under the GNU General Public License.
After you purchase this product, you may procure, modify or distribute the source code of the
GPL/LGPL software that is use d in this p rodu ct.

To obtain a copy of our open source software, please contact our support center and we will
provide you with a CD-ROM of the source code that is used, charging only the actual expense
involved. However, please be noted that we can not provide guarantee with the source code,
and there is also no technical support for the source code from us.

TECHNICAL INFORMATI ON

License information for the software used in the unit.

This product contains Free Software whi ch is lice nsed unde r the G NU Gen eral Public Li cense.
After you purchase this product, you may procure, modify or distribute the source code of the
GPL/LGPL software that is use d in this p rodu ct.

If you contact our Support Center, we will provide you with a CD-ROM of the source code that

ENGLISH

51 / 56

is used, charging only the actual expensed involved. However, please be noted that we can
not provide guarantee with the source code, and there is also no technical support for the
source code from us.

GNU GENERAL PUBLIC LICENSE

Version 2, June 1991

Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Bosto n, MA 02110-1301, USA

Everyone is permitted to copy and distribute verbatim copies
of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to sha re and change it.
By contrast, the GNU General Public License is intended to guarantee your freedom to share
and change free software--to make sure the software is free for all its users. This General
Public License applies to most of the Free Software Foundation's software and to any other
program whose authors commit to using it. (Some other Free Software Foundation software is
covered by the GNU Lesser General Public License instead.) You can apply it to your
programs, too.

When we speak of free software, we are referring to freedom, not price. Our Gen eral Public
Licenses are designed to make sure that you have the freedom to distribute copies of free
software (and charge for this service if you wish), that you receive source code or can get it if
you want it, that you can change the software or use pieces of it in new free programs; and that
you know you can do these things.

To protect your right s, we need to m ake rest rictions t hat forbid any one to deny you the se rights
or to ask you to surrender the rights. These restrictions translate to certain responsibilities for
you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must
give the recipients all the rights that you have. You must make sure that they, too, receive or
can get the source code. And you must show them these terms so they know their rights.

We protect your rights with two steps: (1) copyright the software, and (2) offer you this license
which gives you legal permission to copy, distribute and/or modify the software.

Also, for each author's protection and ours, we want to make certain that everyone
understands that there is no warranty for this free software. If the software is modified by
someone else and passed on, we want its recipients to know that what they have is not the
original, so that any problems introduced by others will not reflect on the original authors'

ENGLISH

52 / 56

reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the
danger that redistributors of a free program will individually obtain patent licenses, in effect
making the program proprietary. To prevent this, we have made it clear that any patent must be
licensed for everyone's free use or not licensed at all.

The precise terms and conditions for copying, distribution and modification follo w.
TERMS AND CONDITIO NS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the

copyright holder saying it may be distributed under the terms of this General Public License.
The "Program", below, refers to any such program or work, and a "work based on the
Program" means either the Program or any derivative work under copyright law: that is to say,
a work containing the Program or a portion of it, either verbatim or with modifications and/or
translated into another language. (Hereinafter, translation is included without limitation in the
term "modification".) Each licensee is addressed as "you".

Activities other than copying, distribution and modification are not covered by this License;
they are outside its scope. The act of running the Program i s not restricted, and the output from
the Program is covered only if its contents co nstitute a work based on the Program
(independent of having been made by running the Program). Whether that is true depend s on
what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it,

in any medium, provided that you conspicuously and appropriately publish on each copy an
appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refe r to
this License and to the absence of any warranty; and give any other recipients of the Program
a copy of this License along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option
offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work

based on the Program, and copy and distribute such modifications or work under the terms of
Section 1 above, provided that you also meet all of these conditions:

a) You must cause the modified files to carry prominent notices stating that you changed the
files and the date of any change.
b) You must cause any work that you distribute or publish, that in whole or in part contain s or is
derived from the Program or any part thereof, to be licensed as a whole at no charge to all third
parties under the terms of this License.
c) If the modified program normally reads command s intera ctively when run, yo u must ca use it,
when started running for such interactive use in the most ordinary way, to print or display an
announcement including an appropriate copyright notice and a notice that there is no warranty
(or else, saying that you provide a warranty) and that users may redistribute the program under

ENGLISH

53 / 56

these conditions, and telling the user how to view a copy of this License. (Exception: if the
Program itself is interactive but does not normally print such an announcement, your work
based on the Program is not required to print an announcement.)

These requirements apply to the modified work as a whole. If identifiable sections of that work
are not derived from the Program, and can be reasonably considered independent and
separate works in themselves, then this License, and its terms, do not apply to those sections
when you distribute them as separate works. But when you distribute the same sections as
part of a whole which is a work based on the Program, the distribution of the whole must be on
the terms of this License, whose permissions for other licensees extend to the entire whole,
and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written
entirely by you; rather, the intent is to exercise the right to control the distribution of derivative
or collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Program (or
with a work based on the Program) on a volume of a storage or distribution medium does not
bring the other work under the scope of this License.

3. You may copy and distribute the Program (or a work ba sed on it, under Section 2) in object

code or executable form under the terms of Sections 1 and 2 above provided that you also do
one of the following:

a) Accompany it with the complete corresponding machine-readable source code, which must
be distributed under the terms of Sections 1 and 2 above on a medium customarily used for
software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a
charge no more than your cost of physically performing source distribution, a complete
machine-readable copy of the corresponding source code, to be distributed under the terms of
Sections 1 and 2 above on a medium customarily used for software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding
source code. (This alternative is allowed only for noncommercial distribution and only if you
received the program in object code or executable form with such an offer, in accord with
Subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it.
For an executable work, complete source code means all the source code for all modules it
contains, plus any associated interface definition files, plus the scripts used to control
compilation and installation of the executable. However, as a special exception, the source
code distributed need not include anything that is normally distributed (in either source or
binary form) with the major components (compiler, kernel, and so o n) of the operating system
on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by offering access to copy from a
designated place, then offering equivalent access to copy the source code from the same

ENGLISH

54 / 56

place counts as distribution of the source code, even though third parties are n ot compelled to
copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly

provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute
the Program is void, and will automatically terminate your rights under this License. However,
parties who have received copies, or rights, from you under this License will not have their
licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not sign ed it. However, nothing

else grants you permission to modify or distribute the Program or its derivative works. These
actions are prohibited by law if you do not accept this License. Therefore, by modifying or
distributing the Program (or any work based on the Program), you indicate your acceptance of
this License to do so, and all its terms and conditions for copying, distributing or modifying the
Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient

automatically receives a license from the original licensor to copy, distribute or modify the
Program subject to these terms and conditions. You may not impose any further restrictions on
the recipients' exercise of the rights g ranted herein. You are not responsible for enforcing
compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other

reason (not limited to patent issues), conditions are imposed on you (whether by court order,
agreement or otherwise) that contradict the conditions of this License, they do not excuse you
from the conditions of this License. If you cannot distribute so as to satisfy simultaneously your
obligations under this License and any other pertinent obligations, then as a conse quence you
may not distribute the Program at all. For example, if a patent license would not permit
royalty-free redistribution of the Program by all those who receive copies directly or indirectly
through you, then the only way you could satisfy both it and this License would be to refrain
entirely from distribution of the Program.

If any portion of this section is held invalid or unenforceable under any particular circumstance,
the balance of the section is intended to apply and the section as a whole is intended to apply
in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right
claims or to contest validity of any such claims; this section has the sole purpose of protecting
the integrity of the free software distribution system, which is implemented by public license
practices. Many people have made generous contributions to the wide range of software
distributed through that system in reliance on consistent application of that system; it is up to
the author/donor to decide if he or she is willing to distribute software through any other system
and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the
rest of this License.

ENGLISH

55 / 56

8. If the distribution and/or use of the Program is restricted in certain countries either by

patents or by copyrighted interfaces, the original copyright hold er who places the Program
under this License may add an explicit geographical distribution limitation excludi ng those
countries, so that distribution is permitted only in or among countries not thus excluded. In
such case, this License incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General

Public License from time to time. Such new versions will be similar in spirit to the present
version, but may differ in detail to address new problems o r co ncerns.

Each version is given a distinguishing version number. If the Program specifies a version
number of this License which applies to it and "any later version", you have the option of
following the terms and conditions either of that version or of any later version publish ed by the
Free Software Foundation. If the Program does not specify a version number of this License,
you may choose any version ever published by the Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution

conditions are different, write to the author to ask for permission. For software which is
copyrighted by the Free Software Foundation, write to the Free Software Foundation; we
sometimes make exceptions for this. Our decision will be guided by the two goals of preserving
the free status of all derivatives of our free software and of prom oting the sharing and reuse of
software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO

WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW.
EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR
OTHER P AR TIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS
WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF
ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN

WRITING WILL ANY COP Y RIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY
AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU
FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE
PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING
RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A
FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF
SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.

ENGLISH

56 / 56
