Page 1
ENGLISH
Page 2
Table of Contents
1. Introduction .......................................................................................................................... 3
1.1 Preface ......................................................................................................................... 3
1.2 Packing List .................................................................................................................. 4
1.3 Cautions ....................................................................................................................... 4
1.4 Connection ................................................................................................................... 6
1.5 View ............................................................................................................................. 11
1.6 First steps ................................................................................................................... 12
1.7 HDD Format ............................................................................................................... 12
2. About the Player ................................................................................................................ 13
2.1 Remote Control .......................................................................................................... 13
3. Main Functions .................................................................................................................. 15
3.1 Setup Menu ................................................................................................................ 15
3.2 Movie Library .............................................................................................................. 24
3.3 Photo Library .............................................................................................................. 26
3.4 Music Library .............................................................................................................. 27
3.5 3D Movie Playback ..................................................................................................... 30
3.6 File Manager............................................................................................................... 31
3.7 Playlist Management .................................................................................................. 35
3.8 Copy und Delete Function .......................................................................................... 37
3.9 Internet Media ............................................................................................................ 38
4. Network Server and Client ................................................................................................ 42
4.1 Samba (SMB) Server ................................................................................................. 42
4.2 FTP Server ................................................................................................................. 43
5. Movie JukeBox ................................................................................................................... 45
6. Upgrading the Firmware ................................................... Fehler! Textmarke nicht definiert.
7. Appendixes......................................................................................................................... 48
8. Frequently Asked Questions ............................................ Fehler! Text marke nicht definiert.
9. Copyrights and Trademarks ............................................................................................. 51
10. Warranty ........................................................................................................................... 52
11. GPL Statement ................................................................................................................. 52
ENGLISH
2 / 57
Page 3
1. Introduction
1.1 Preface
Thank you very much for purchasing the FANTEC 3DFHDL media player. We hope you will
enjoy using it as a great home entertainment partner. This player has the following
functionality.
A/V Output
• HDMI V1.4 for high-defin iti on video and di gital audio
• Composite & component video and stereo audio for analog audio-visual connection
• S/PDIF optical and coaxial interface for high-fidelity digital audio
• Adjustable video output resolution (NTSC, PAL, 480p, 576p, 720p, 1080i, 1080p,
1080p/24p)
Movie Playback
• Movie format: AVI, VOB, MKV, MOV, MP4, MPG, TS, WMV, DAT, IFO, RM, RMVB, ISO
(DVD & BluRay), AVCHD, MTS, M2TS, M4V , ASF, FLV, XviD, DivX 3/4/5, DVD menu
playback, H.264, resolution up to 720p/1080i/1080p
• 3D format: 3D Frame Packing (3D BD), 3D MVC (Multiview Video C oding), 3D SbS (Side
by Side) 3D TaB (Top and Bottom)
• Supports major audio formats (1080p HD video decoding)
• Fast forward/rewind
• View subtitle
• Subtitle control: color/offset/size
• SRT, SMI, SSA,SUB, IDX+SUB
Music Playback
• Music format: MP3, OGG, WMA, WAV, FLAC
• Audio Codecs: MP2/3, OGG Vorbis, WMA Standard (DRM, and Advanced Profile not
supported), PCM, LPCM, RA, DTS, Dolby Digital
• Fast forward/rewind
• Shuffle
• Repeat
Photo Playback
• Photo format: HD JPEG, JPG, BMP, GIF, TIF, PNG
• You can view photos in slide show mode with background music.
• Zoom in/out, Rotate
ENGLISH
3 / 57
Page 4
Network Feature
• A/V streaming/transmission via Ethernet (10M/100M/1000M) & Wi-Fi (802.11b/g/n,
optional)
• File sharing via Samba server
• A/V streaming via UPnP Media Server
• BitTorrent download
• Internet Radio (Please visit
File Copy
• Supports copying & moving files among USB dev ices , Loc al HDD , and Net wor k
USB 3.0 & USB 2.0 Support
• USB 3.0 DEVICE port (for computer connection, compatible to USB 3.0/2.0/1.1)
• USB HOST port x 2 (for USB storage devices),for connection of an USB DVD drive, an
USB Y-cable is recommended
Note: All the information contained in this manual was correct at the time of publication.
www.shoutcast.com for available stations)
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than presented in
this manual.
1.2 Packing List
Part Quantity
Player 1
USB 3.0 cable 1
Remote Control 1
Remote Control Battery 2
AC/DC adaptor 1
Quick start guide 1
Warranty card 1
Note: The actual contents in the package might be different from the packing list in the manual.
1.3 Cautions
The FANTEC 3DFHDL design and manufacture has your safety in mind. In order to safely and
effectively use this player, please read the following before usage.
1.3.1 Usage Cautions
User should not modify this player. If commercial hard disk is being used, the environmental
temperature should be within +5℃ ~ +35℃.
ENGLISH
4 / 57
