This description is focused on the IEEE 802.15.4TM Keyfob remote control from FALCOM GmbH. It contains short information about purpose and use of the Keyfob concept.
The Keyfob remote control contains an IEEE 802.15.4 GHz ISM-Band. It uses 16-channels in interval of 5 MHz (2405–2480 MHz).
The Keyfob supports an over-the-air data rate of 250 kb/s by using the O-QPSK (offset quadrature phase-shift keying) modulation type. The duty-cycle with the PHD100 device is:
- 1 ms transmit (Tx)
- 300 ms receive (Rx)
- 5 s sleep
Based on these features, the Keyfob will spend most of its operational life in a sleep state that favor the AAA-batteries a long lifetime; however, the Keyfob periodically listens to the RF channel in order to determine whether a message is pending.
The Keyfob has an internal Multi-Layer-Ceramics antenna from Murata with the gain
TM
of –1 dB. The IEEE 802.15.4
module works with a chipset from Freescale called
MC13192 (Transceiver), MC9S08GT60 (8-bit Processor).
The keyfob operates with the help of three buttons. It supports 3 LEDs, a buzzer and a vibrator for signal indication.
TM
module that works on the 2.4
0.2 Circuit concept
The Keyfob architecture includes the following major functional components:
ARCHITECTURE INTEGRATES:
high-performance IEEE802.15.4 wireless module for communication
1 x Buzzer
1 x Vibrator
MC9S08GT60 Processor (8-bit) that controls all functions of the system
Power Control for AAA Batteries
IEEE antenna
PHYSICAL INTERFACES:
3 x push-buttons.
3 x LEDs
2 X AAA batteries
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 4
KEYFOB HARDWARE DESCRIPTION VERSION 1.00
Figure 1: Architecture of the Keyfob remote control
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 5
KEYFOB HARDWARE DESCRIPTION VERSION 1.00
1 TECHNICAL DATA
1.1 General specifications of Keyfob
Power supply:
perating voltage from 2.4 V to 3.3 VDC
OPowered by 2 x AAA batteries
Temperature range:
ormal operation: -25 °C to +55 °C
N
Physical characteristics:
S
ize: 66 mm x 46 mm x 20 mm
eight: approx. 55 g
W
Audio:
x Buzzer
1
Vibration:
Connectivity:
Channels:
1
x Vibrator
TM
IEEE 802.15.4
connectivity.
16 channels
Channel Frequency
1 2.405 GHz
2 2.410 GHz
3 2.415 GHz
4 2.420 GHz
5 2.425 GHz
6 2.430 GHz
7 2.435 GHz
8 2.440 GHz
9 2.445 GHz
10 2.450 GHz
11 2.455 GHz
12 2.460 GHz
13 2.465 GHz
14 2.470 GHz
15 2.475 GHz
16 2.480 GHz
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 6
KEYFOB HARDWARE DESCRIPTION VERSION 1.00
2 BI-DIRECTIONAL KEYFOB, REMOTE OPERATION
The Keyfob gives you remote operation of your security system. This Keyfob operates with the push of one button or buttons combination. It also gives you direct feedback on its operation with a blinking light as well as with voice prompts, so you can be sure that your security system is operating as you intended. The communication to the Keyfob unit is based on the IEEE 802.15.4 wireless network systems.
Figure 2: Keyfob control with allocated Buttons and LEDs names
Buttons common functionalities
Items Buttons overview Using the marked Button(s) Description/Functionalities
1 Button 1 B1 Tests the range of remote control
2 Button 2 B2 Sets the alarm active
3 Button 2 B2
4 Button 3 B3 Checks the status of the internal batteries
5 Button 1 + 3 B1+ B3 Switches the Keyfob on.
6 Button 1 + 3 + 2 B1+ B3 + B2 Switches the Keyfob and connected device off.
7 Button 1 + 2 + 3 B1+ B2 + B3 Pairs the Keyfob with external device.
Table 1: Button description
If no alarm activated, activates the alarm, otherwise returnes activated alarm to inactive (see also Item 2).
LEDs lighting colours
Items LEDs overview LEDs marked Colour of light
1 LED 1 L1 Orange
2 LED 2 L2 Red
3 LED 3 L2 Yellow
Table 2: LED description
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 7
KEYFOB HARDWARE DESCRIPTION VERSION 1.00
Actions and Reactions of the Keyfob while performing activations
Items Buttons
Short pressing = press the button for less then 2 seconds
Long pressing = press the button for longer then 2 seconds
1
B1 short pressing
2
3 Long pressing
B2
4
5
6
7
8 B1 + B3
9 B1+B3+(B2)
10 B1+B2+B3
11 - -
12 B2
13 - -
B3 Long pressing
Actions generated by
Key combination
Within 6 seconds two times short pressing.
Simultaneously the B1 and B3 short pressing.
Simultaneously, press and hold the B1 and B3 for longer than 2 seconds. Release when the L1 and L3 light. Then
the B2 long pressing.
Simultaneously the B1, B2 and B3 long pressing.
Within 3 seconds two times short pressing
Table 3: Description of Actions and Reactions
Reaction Possibilities Meaning
while the B1 is pressed the L1 blinks one time, after the B1 is released, each of L1 and L3 blinks one time in sequence and two beep tones are respectively genereated.
simultaneously generates three beep tones, and three times blinking of L1 and L3.
lights the L1 for longer than 2 seconds
simultaneously generates two beep tones and two times blinging of L1.
lights the L1+L2+L3 while the B3 is pressed.
lights the L1+L2 while the B3 is pressed.
lights the L1 while the B3 is pressed.
-
simultaneously generates three beep tones, and three times blinking of L1 and L3.
the L2 lights untill the B2 is released.
causes lighting of L1, L2 and L3 in series (one LED after another in sequence)
If the L1 and L3 light and a beep tone is generated as well as the L2 lights and Keyfob vibrates (in sequence, one after another, not simultaneously)
- Turns off the incoming alarm.
If simultaneously are generated, a long beep tone (high to low tone) and L2 lights for a long time.
Indicates that the external device and Keyfob are within the wavelength of communication systems.
Indicates that the external device and Keyfob are out of the wavelength of communication systems.
Indicates that the alarm is set active (arm)
Indicates that the activated alarm is
returned to inactive (disarm) or no alarm is already set.
Indicates that the battery is full charged.
Indicates that the batteries is half-full charged, they can be recharged (if
rechargeable).
Indicates that the batteries reach the
low level, they must be replaced or recharged (if rechargeable).
Indicates that the Keyfob is switched on.
Indicates that the external device and Keyfob are out of the wavelength of communication systems or they are already not paired (enter the key
number by using the
HARLEY.KEY<index> parameter
Indicates that the external device and Keyfob are shut down. The external device will be shut down and set itself into one of sleep modes based on the user defined alarm (e.g. into SleepIgnition, SleepMotion, SleepAll or SleepWakeup supported
by the SYSTEM action type).
Indicates that the external device and Keyfob are paired (remote communication is set up and both devices are ready for use).
Indicates an incoming alarm sent by the Black box. To turn the Reaction off perform the action on the Item 12.
Indicates that the external device and Keyfob are longer than 5 seconds out of the wavelength of communication systems. The Keyfob is going into the sleep mode.
