1.5 W Zener Diodes
BZY97C10 GP........ BZY97C200 GP
Dimensions in mm. DO-41
(Plastic)
± 0.2
5
±0.5
58.5
Mounting instructions
1. Min. distance from body to soldering point,
• Diffused junction
4 mm.
2. Max. solder temperature, 350 °C.
3. Max. soldering time, 3.5 sec.
4. Do not bend lead at a point closer than
2 mm. to the body.
• The plastic material carries
U/L recognition 94 V-0
• Terminals: Axial Leads
• Polarity: Color band denotes cathode
Maximum Ratings, according to IEC publication No. 134
Voltage
10 to 200 V
Power
1.5 W
P
tot
P
ZSM
T
j
T
stg
Power dissipation at Tamb = 60 oC
Non repetitive peak zener dissipation
(t = 10 ms.)
Operating temperature range
Storage temperature range
Electrical Characteristics at Tamb = 25°C
V
F
R
thj-a
Max. forward voltage drop at IF = 1.0 A
Max. thermal resistance at 10 mm.
lead length
1.5 W
40 W
– 55 to + 175 °C
– 55 to + 175 °C
1.1 V
50° C/W
Oct - 02
BZY97 GP
Type
BZY97C10 GP
BZY97C11 GP
BZY97C12 GP
BZY97C13 GP
BZY97C15 GP
BZY97C16 GP
BZY97C18 GP
BZY97C20 GP
BZY97C22 GP
BZY97C24 GP
BZY97C27 GP
BZY97C30 GP
BZY97C33 GP
BZY97C36 GP
BZY97C39 GP
BZY97C43 GP
BZY97C47 GP
BZY97C51 GP
BZY97C56 GP
BZY97C62 GP
BZY97C68 GP
BZY97C75 GP
BZY97C82 GP
BZY97C91 GP
BZY97C100 GP
BZY97C110 GP
BZY97C120 GP
BZY97C130 GP
BZY97C150 GP
BZY97C160 GP
BZY97C180 GP
BZY97C200 GP
Zener
Voltage
Range
V
at I
Z
ZT
9.4 - 10.6
10.4 - 11.6
11.4 - 12.7
12.4 - 14.1
13.8 - 15.8
15.3 - 17.1
16.8 - 19.1
18.8 - 21.2
20.8 - 23.3
22.8 - 25.6
25.1 - 28.9
28 - 32
31 - 35
34 - 38
37 - 41
40 - 46
44 - 50
48 - 54
52 - 60
58 - 66
64 - 72
70 - 79
77 - 88
85 - 96
94 - 106
104 - 116
114 - 127
124 - 141
138 - 156
153 - 171
168 - 191
188 - 212
Maximum
Zener
Impedance
Z
at I
ZT
ZT
4
7
7
10
10
15
15
15
15
15
15
15
15
40
40
45
45
60
60
80
80
100
100
200
200
250
250
300
300
350
350
350
Typical
Temperature
Coefficient
at I
ZT
o
(% /
C)(Ω)(V)
+ 0.070
+ 0.075
+ 0.075
+ 0.075
+ 0.075
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.085
+ 0.095
+ 0.095
+ 0.095
+ 0.095
+ 0.105
+ 0.105
+ 0.105
+ 0.105
+ 0.11
+ 0.11
+ 0.11
+ 0.11
+ 0.11
+ 0.11
+ 0.11
+ 0.11
+ 0.11
Test
Current
I
ZT
Min. Reverse
Voltage
at
IR
= 1µ A
V
(mA) (V)
50
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
5
5
5
5
5
5
5
5
5
5.0
5.0
7.0
7.0
10
10
10
10
12
12
14
14
17
17
20
20
24
24
28
28
34
34
41
41
50
50
60
60
75
75
90
90
R
Oct - 02
Characteristic Curves
BZY97C GP
MAXIMUM CONTINUOUS
POWER DISSIPATION
1.8
10mm. - 10mm.
1.5
1.2
0.9
0.6
0.3
0
90
80
60
40
20
0
25 75 125 175
50 100 150
Tamb, ambient temperature (°C)
THERMAL RESISTANCE
I
I
0
0 10 20 30 35
I, lead lenght (mm)
Oct - 02
BREAKDOWN CHARACTERISTICS
BZY97C GP
240
200
160
120
80
40
BZY10 GP
50mA
0
0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
V
Z , zener voltage (V)
60
BZY18 GP
BZY22 GP
BZY27 GP
BZY33 GP
10 mA
50
I = 50 mA
40
Test Current IZ
25 mA
30
20
BZY15 GP
Z
T = 25 °C
j
BZY12 GP
j
T = 25 °C
BZY39 GP
BZY47 GP
10
0
0 5 10 15 20 25 30 35 40 45 50
VZ , zener voltage (V)
20
Test Current IZ
10 mA
10
BZY56 GP
BZY68 GP
BZY82 GP
BZY100 GP
BZY120 GP
5mA
T = 25 °Cj
BZY150 GP
BZY180 GP
0
0 50 100 150 200
Z , zener voltage (V)
V
BZY200 GP
Oct - 02
BZY97C GP
∆
∆
V
V (t)
Z
Z
1
Tamb = 25°C
0.8
0.6
0.4
0.2
0
1 10 10 10
2 3
t (sec.)
Relative change of Zener
voltage versus turn-on time.
100
5
4
0.5
3
2
10
0.2
0.1
5
0.05
thU
r
Pulse thermal resistance
versus pulse duration. Valid
provided that leads are kept
at ambient temperature at a
distance of 10mm. from case.
4
3
0.02
2
0.01
1
5
0.1
4
3
2
10
-5
10
-4
10-310-210 10
-1
1
tp
t
p
V=
P
T
I
T
tp (sec.)
