98/99

™

Series Exit Devices

98/99™ Finishes

Finishes*

Color US Number BHMA Number

Chromium, Polished US26 625

Anodized, Aluminum US28 628

Chromium, Dull US26D 626

Brass, Polished US3 605

Brass, Dull US4 606

Bronze, Dull US10 612

Anodized Duranodic (Dark Bronze) 313AN 710

Anodized Black 315AN ––

Pushpad Options — Knurled

Embossed “Push” Braille (Caution-Stairwell), satin stainless steel only SS – (EMERGENCY EXIT – PUSH TO OPEN AND SOUND ALARM) – Red Silkscreen lettering on US32D

* NOTE: Durable powder coated finishes available at specific special request. PLEASE CONTACT FACTORY.

98/99™ Exit Devices

Index

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Exit Hardware • Rim Devices

• 98/99™ Rim Exit Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• 98/99™ Rim Exit Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

• Mortise Lock Device

• 9875/9975 Mortise Lock Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

• 9875/9975 Mortise Lock Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Surface Mounted Vertical Rod Devices

• 9827/9927 Surface Mounted Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

• 9827/9927 Surface Mounted Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

• Three-Point Latching Device

• 9857/9957 Three-Point Latching Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

• 9857/9957 Three-Point Latching Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Concealed Vertical Rod Device

• 9847/9947 Concealed Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

• 9847/9947 Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

• 9848/9948 Concealed Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

• 9848/9948 Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

• Wood Door Concealed Vertical Rod Device

• 9847/9947 Wood Door Concealed Vertical Rod Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

• 9847/9947 Wood Door Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Fire Exit Hardware • Fire Exit Rim Devices

• 98-F/99-F Rim Exit Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

• 98-F/99-F Rim Exit Device Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

• Fire Exit Mortise Lock Device

• 9875-F/9975-F Fire Exit Mortise Lock Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

• 9875-F/9975-F Fire Exit Mortise Lock Device Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

• Fire Exit Surface Mounted Vertical Rod Devices

• 9827-F/9927-F Surface Mounted Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

• 9827-F/9927-F Surface Mounted Vertical Rod Device Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

• Fire Exit Three-Point Latching Device

• 9857-F/9957-F Three-Point Latching Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• 9857-F/9957-F Three-Point Latching Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• Fire Exit Concealed Vertical Rod Devices

• 9847-F/9947-F Concealed Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• 9847-F/9947-F Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

• 9848-F/9948-F Concealed Vertical Rod Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

• 9848-F/9948-F Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

• Fire Exit Wood Door Concealed Vertical Rod Device

• 9847-F/9947-F Wood Door Concealed Vertical Rod Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

• 9847-F/9947-F Wood Door Concealed Vertical Rod Device Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Trim Selection • Optional Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-34

• Lever Designs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

• Operation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

• HL Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

• Vandal Resistant Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

• CM993 and PRO993 Exit Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• How To Order CM993 and PRO993 Exit Trim. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Strike Selection • Strikes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

• Strike/Stile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

98/99™ Exit Devices

Index, pg. 2

Device Electrical Options • EL Electric Latch Retraction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

• E - Electric Rim Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

• E7500 Mortise Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

• Chexit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

• ALK Exit Alarm Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

• SS Signal Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

• LX Latch Bolt Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

• RX - Request to Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

• RX2 - Double Request to Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Device Accessories • Glass Bead Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

• Dummy Push Pad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

• Cylinders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

• Cover Plate Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

• RG-27 Vertical Rod and Latch Guard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Device Options • Braille, Embossed and Knurled Touchpads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• Cylinder Dogging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• CDK, HDK Cylinder Dogging and Hex Key Dogging Kits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• Pnuematic Controlled Exit Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• Double Cylinder Exit Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• LBR, Less Bottom Rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

• PL, Pullman Latch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Device Electrical Accessories • Power Supplies

• PS9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

• PS861. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

• PS873. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• EPT Electric Power Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Additional Information • ANSI Grade, Type & Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

• Device Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

• UL Fire Labeling and Opening Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

• Finishes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

• Handing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

• How-To-Order Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

• Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

• Popular Double Door Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

98/99™ Exit Devices

Introduction

Exit devices are a critical part of the Fire and Life Safety egress system and will provide safe and reliable service when properly applied and maintained. Von Duprin designs and manufactures exit devices in accordance to ISO 9001 Quality Management System and meets or exceeds accepted U.S. domestic and International standards. All 98 and 99 series exit devices are UL listed for Panic Hardware or Fire Hardware, and are certified to ANSI A156.3, 2001, Grade 1. Many models are also certified for Hurricane Resistant Applications. Consult your local IR Security & Safety consultant or the Von Duprin factory for current listings.

It is intended that the information included in this publication, when properly used, will provide clear and reliable guidelines to the proper general selection and application. However, the scope of the information is necessarily limited.

Unusual operating conditions and environments and other external influences can affect the proper application of the products represented. Modifications of these products will also affect UL listings. It is recommended that whenever an unusual application condition exists, or when any modification of a product is considered, that our engineers review the application.

Application engineering services are available to help ensure proper selection or to review any areas where users of Von Duprin products may have questions.

Von Duprin push pad exit devices are available in two external surface styles, designated 98 Series and 99 Series. The two styles are mechanically and dimensionally identical and provide a wide selection of appearance options.

Latch Bolt

Deadlocking latchbolt provides security and improved performance at standard device cost.

The Quiet One

A fluid dampener decelerates the pushpad on its return stroke and eliminates most noise associated with exit device operations. Furnished on all 98/99™ series exit devices.

99 Series features grooved mechanism case.

98 Series features smooth mechanism case.

Latch Bolt

(98 Rim device shown)

98/99™ Rim Exit Device

299 Strike

98 and 99 rim exit devices for all types of single and double doors with mullion, UL listed for Panic Exit

Hardware. Devices are ANSI A156.3 – 2001 Grade 1. The 98 device has a smooth mechanism case and the 99 device has a grooved case. The rim device is non-handed except when the following device options are used: SD (Special Dogging), -2 (Double Cylinder) or SS (Signal Switch). See Opposite page for available outside trim and device functions. Covers stock hollow metal doors with 86 or 161 cutouts on single doors (may cover cutouts on pairs – consult template).

The 98/99 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 98 device only. See page 52 for component finishes and the inside cover for finish chips.

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL

drive screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes 299 – Dull Black

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

RX Pushpad Monitor Switch see page 42 RX2 Double Pushpad Monitor Switch see page 42 E Electric Locking & Unlocking see page 44 EL Electric Latch Retraction see page 43 SS Signal Switch see page 43 CX Chexit Delayed Exit see page 45 ALK Alarm Exit Kit see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

-2 Double Cylinder see page 48 GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking, ³₄" (19mm) throw

Device Centerline from 39 ¹³₁₆" (1011 mm)

Finished Floor 39 ¹¹₁₆" (1008 mm) with Mullion

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

98/99™ Rim Exit Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt

Optional Pull Required

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

98EO 98DT 98NL 98NL-OP 99EO 99DT 99NL 99NL-OP

110NL-MD

110NL-WD

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"

(76x360x2mm) (76x360x2mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– 2"

(51mm) 2" (51mm) ––

01 02 03 03 –– –– Rim Rim

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6

–– 990DT 990NL-R/V

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

98L 98L-NL 98L-BE 98L-DT 99L 99L-NL 99L-BE 99L-DT

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-R/V

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

98-F/99-F Rim Fire Exit Device

98-F and 99-F rim fire exit devices for all types of single doors up to 4´ x 10´ (1219mm x 3048mm) or 8´ x 10´ (2438mm x 3048mm) double doors with 9954 or 9854 mullion, UL listed for Fire Exit Hardware. See

page 41 for detailed information on UL listed fire exit hardware label and door opening size information.

Devices are ANSI A156.3 – 2001 Grade 1. The 98-F device has a smooth mechanism case and the 99-F device has a grooved case. The rim device is non-handed except when the following device options are used: -2 (Double Cylinder) or SS (Signal Switch). See Opposite page for available outside trim and device functions.

The 98-F/99-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 98-F device only. See page 52 for component finishes and the inside cover for finish chips.

299F Strike

499F Strike

With 9854/9954

Mullion

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL

drive screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes 299F – Dull Black, 499F with Mullions

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

-2 Double Cylinder see page 48 GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking, ³₄" (19mm) throw

Device Centerline from 39 ¹³₁₆" (1011 mm)

Finished Floor 39 ¹¹₁₆" (1008 mm) with Mullion

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

98-F/99-F Fire Exit Rim Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt

(Not recommened for Fire Device) Optional Pull Required

Product Description

Trim Description Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg. #825 SNB Req.

WD w/o SLM Pkg. #425 SNB Req. w/ 499F

98EO-F –– 98NL-F 98NL-OP-F 99EO-F –– 99NL-F 99NL-OP-F

110NL-MD

110NL-WD

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"

(76x360x2mm) (76x360x2mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– 2"

(51mm) 2" (51mm) ––

01 02 03 03 –– –– Rim Rim

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22 2 2

22 2 2

–– 990DT 990NL-R/V

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommened for Fire Device)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type Optional Trim

(See pages 32 – 34) #425 SNB optional-

HMD

Req. WD w/o SLM Pkg. #825 SNB Req.

WD w/o SLM Pkg. #425 SNB Req. w/ 499F

98L-F 98L-NL-F 98L-BE-F –– 99L-F 99L-NL-F 99L-BE-F ––

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-R/V

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

––

–– –– ––

2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2 22 2 2

22 2 2

For optional trims and functions see pages 32-34

9875/9975 Mortise Lock Device

9875/9975 mortise lock device for all types of single or double doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 ³₄" (121mm). The 9875 device has a smooth mechanism case and the 9975 device has a grooved case. The mortise lock device is non-handed except when the following device options are used: -2 (Double Cylinder) or SS (Signal Switch). See Opposite page for available outside trim and device functions.

The 9875/9975 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9875 device only. See page 52 for component finishes and the inside cover for finish chips.

The 7500 Mortise lock is equipped with a ³₄" (19mm) anti-friction latch bolt which is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel.

575 Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L adjust NL drive

screw in mortise lock

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes 575 – Dull Black

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

LD Less Dogging see page 48

Electric Option RX Pushpad Monitor Switch see page 42

RX2 Double Pushpad Monitor Switch see page 42 E Electric Locking & Unlocking see page 44 EL Electric Latch Retraction see page 43 SS Signal Switch see page 43 CX Chexit Delayed Exit see page 45 ALK Alarm Exit Kit see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

-2 Double Cylinder see page 48 GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Device Centerline from 39 ⁵₈" (1006 mm)

Finished Floor

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9875/9975 Mortise Lock Device Standard Trim

Exit only Dummy Trim Night Latch Hospital Latch

Pull when Dogged Key Retracts Latchbolt Key Locks & Unlocks

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9875EO 9875DT 9875NL 9875HL 9975EO 9975DT 9975NL 9975HL

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2⁹₁₆"x 5¹₂"x 2⁵₈"

(76x360x2mm) (76x360x2mm) (65x140x67mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– 2"

(51mm) 2" (51mm) 2⁵₈"(67mm)

01 02 03 –– –– ––

1¹₄" Mortise 1¹₄" Mortise

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 2

–– 990DT 990NL-M HL6M

––

Lever Lever – Night Latch Lever – Blank Escutceon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9875L 9875L-NL 9875L-BE 9875L-DT 9975L 9975L-NL 9975L-BE 9975L-DT

996L-M 996L-NL-M 996L-BE-M 996L-DT -M

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

1¹₄"

Mortise 1¹₄" Mortise –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9875-F/9975-F Mortise Lock Fire Exit Device

9875-F/9975-F fire exit mortise lock devices for all types of single doors up to 4´ x 10´ (1219mm x 3048mm) or 8´ x 10´ (2438mm x 3048mm) double doors installations, UL listed for Fire Exit Hardware; See page 41 for detailed information on UL listed fire exit hardware label and door opening size information. Devices are ANSI A156.3 – 2001 Grade 1. Fits door stiles as narrow as 4 ³₄" (121mm). The 9875-F device has a smooth mechanism case and the 9975-F device has a grooved case. The mortise lock device is non-handed except when the following device options are used: -2 (Double Cylinder) or SS (Signal Switch) devices. See Opposite page for available outside trim and functions.

The 9875-F/9975-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9875-F device only. See page 52 for component finishes and the inside cover for finish chips.

575 Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL

drive screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes 575 – Dull Black

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options RX Pushpad Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

-2 Double Cylinder see page 48 GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg. specified

Device Centerline from 39 ⁵₈" (1006 mm)

Finished Floor

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9875-F/9975-F Mortise Lock Fire Exit Device Standard Trim

Exit only Dummy Trim Night Latch Hospital Latch

Pull when Dogged Key Retracts Latchbolt Key Locks & Unlocks

(Not recommened for Fire Device)

Product Description

Trim Description Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9875EO-F –– 9875NL-F 9875HL-F 9975EO-F –– 9975NL-F 9975HL-F

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2⁹₁₆"x 5¹₂"x 2⁵₈"

(76x360x2mm) (76x360x2mm) (65x140x67mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– 2"

(51mm) 2" (51mm) 2⁵₈"(67mm)

01 02 03 –– –– –– 1¹₄" Mortise 1¹₄" Mortise

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 2

–– 990DT 990NL-R/V HL6M

––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type Optional Trim

(See pages 32 – 34) #425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9875L-F 9875L-NL-F 9875L-BE-F –– 9975L-F 9975L-NL-F 9975L-BE-F ––

996L-M 996L-NL-M 996L-BE-M 996L-DT -M

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

1¹₄" Mortise 1¹₄" Mortise –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9827/9927 Surface Mounted Vertical Rod Device

9827/9927 surface mounted vertical rod device for all types of single or double doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. Covers stock hollow metal doors with 86 or 161 cutouts. The 9827 device has a smooth mechanism case and the 9927 device has a grooved case. The surface vertical rod device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9827/9927 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9827 device only. See page 52 for component finishes and the inside cover for finish chips.

Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors. Refer to page 49

299 Top Strike

248L4

Bottom Strike

for use with

flat threshold

Top Latch

Bottom Latch

304L

Bottom Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 299 – Dull Black, Bottom – 248L4 & 304L - Unfinished

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

RX Pushpad Monitor Switch see page 42 RX2 Double Pushpad Monitor Switch see page 42 EL Electric Latch Retraction see page 43 SS Signal Switch see page 43 CX Chexit Delayed Exit see page 45 ALK Alarm Exit Kit see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49 GBK Glass Bead Kit see page 49 PL Pullman Latch see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) SNB furnished for top & bottom latches

Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈ " (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm)

Finished Floor Door Undercut ¹₄" (7mm)

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods ¹₂" square tubing, standard rods accommodate 7’ (2134mm) door

Top rod length is 34 ¹⁵₁₆" (887mm) Bottom rod length is 31 ¹₄" (794mm) Extension rods available, 1’ (205mm) or 3’ (914mm) for doors over 7’ One piece top rod available for 8’ (2438mm) – 10’ (3048mm) door

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9827/9927 Surface Mounted Vertical Rod Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

Optional Pull Required (Use with DT Trim) Always Operable

(No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9827EO 9827DT 9827NL 9827NL-OP 9827TL 9827TL-BE 9927EO 9927DT 9927NL 9927NL-OP 9927TL 9927TL-BE

–– 990DT 990NL-R/V 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2⁹₁₆"x 5¹₂"x 2⁵₈"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (65x140x67mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9827L 9827L-NL 9827L-BE 9827L-DT 9927L 9927L-NL 9927L-BE 9927L-DT

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-RV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

110NL-MD 110NL-WD

9827-F/9927-F Surface Mounted Vertical Rod Fire Device

9827-F/9927-F fire exit surface mounted vertical rod device pairs of doors up to 8´ x 10´ (2438mm x 3048mm) , UL listed for Fire Exit Hardware.See page 41 for detailed information on UL listed fire exit

hardware label and door opening size information. Devices are ANSI A156.3 – 2001 Grade 1. The 9827-F device has a smooth mechanism case and the 9927-F device has a grooved case. The surface vertical rod device is non-handed except when the following device options are used: SS (Signal Switch). See Opposite page for available outside trim and device functions.

The 9827-F/9927-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9827-F device only. See page 52 for component finishes and the inside cover for finish chips.

Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors. Rod and latch guards can be used on hollow metal or tin clad composite fire doors. Refer to page 49

299F

Top Strike

Top Latch

Bottom Latch

304L

Bottom Strike

499F

Top Strike - LBR

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top – 299F (499F LBR) – Dull Black, Bottom – 304L - Unfinished

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) SNB furnished for top & bottom latches

Optional SNB available for device, see next page for quantities Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈ " (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm)

Finished Floor Door Undercut ¹₄" (7mm)

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods ¹₂" square tubing, standard rods accommodate 7’ (2134mm) door

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9827-F/9927-F Surface Mounted Vertical Rod Fire Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

(Not recommended for Optional Pull Required (Use with DT Trim) Always Operable

Fire Device) (No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9827EO-F –– 9827NL-F 9827NL-OP-F 9827TL-F 9827TL-BE-F 9927EO-F –– 9927NL-F 9927NL-OP-F 9927TL-F 9927TL-BE-F

–– 990DT 990NL-R/V 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type Optional Trim

(See pages 32 – 34) #425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9827L-F 9827L-NL-F 9827L-BE-F –– 9927L-F 9927L-NL-F 9927L-BE-F ––

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-RV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

110NL-MD 110NL-WD

9857/9957 Three-Point Latching Device

9857/9957 three-point latching device for all types of single or double doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. Covers stock hollow metal doors with 86 or 161 cutouts. The 9857 device has a smooth mechanism case and the 9957 device has a grooved case. The three-point latching device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9857/9957 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9857 device only. See page 52 for component finishes and the inside cover for finish chips.

Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors. Refer to Page 49.

Top Latch

Bottom Latch

299

Top & Middle

Strike

248L4

Bottom Strike

for use with

threshold

304L

Bottom Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top & Middle-299–Dull Black, Bottom–248L4 & 304L-Unfinished

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49 GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) SNB furnished for top & bottom latches

Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈" (16mm) throw

Deadlocking Rim Bolt, ³₄" (19mm) throw

Device Centerline from 39 ¹³₁₆" (1011 mm)

Finished Floor Door Undercut ¹₄" (7mm)

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods ¹₂" square tubing, standard rods accommodate 7’ (2134mm) door

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9857/9957 Three-Point Latching Device Standard Trim

Exit only Dummy Trim Night Latch Night Lacth Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

Optional Pull Required (Use with DT Trim) Always Operable

(No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9857EO 9857DT 9857NL 9857NL-OP 9857TL 9857TL-BE 9957EO 9957DT 9957NL 9957NL-OP 9957TL 9957TL-BE

–– 990DT 990NL-R/V 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9857L 9857L-NL 9857L-BE 9857L-DT 9957L 9957L-NL 9957L-BE 9957L-DT

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-RV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

110NL-MD 110NL-WD

9857-F/9957-F Three-Point Latching Fire Device

9857-F/9957-F fire exit three-point latching device for all types of single doors up to 4´ x 8´ (1219mm x 2438mm) or up to 8´ x 8´(2438mm x 2438mm) double doors with 9954 or 9854 mullion, UL listed for Fire Exit Hardware. See page 41 for detailed information on UL listed fire exit hardware label and door opening size information. Devices are ANSI A156.3 – 2001 Grade 1. The 9857-F device has a smooth mechanism case and the 9957-F device has a grooved case. The three-point latch device is non-handed except when the following device option is used: SS (Signal Switch). See Opposite page for available outside trim and device functions.

The 9857-F/9957-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9827-F device only. See page 52 for component finishes and the inside cover for finish chips.

Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors. Refer to Page 49.

Top Latch

Bottom Latch

299F

Top & Middle

Strike

304L

Bottom Strike

499F

Rim Strike

For Mullion

Applications

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top & Middle-299F–Dull Black, Bottom–304L-Unfinished

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) SNB furnished for top & bottom latches

Optional SNB available for device, see next page for quantities Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈" (16mm) throw

Deadlocking Rim Bolt, ³₄" (19mm) throw

Device Centerline from 39 ¹³₁₆" (1011 mm)

Finished Floor Door Undercut ¹₄" (7mm)

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods ¹₂" square tubing, standard rods accommodate 7’ (2134mm) door

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9857-F/9957-F Three-Point Latching Fire Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

(Not recommended for Optional Pull Required (Use with DT Trim) Always Operable

Fire Device) (No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg. #425 SNB Req. w/ 499F

9857EO-F –– 9857NL-F 9857NL-OP-F 9857TL-F 9857TL-BE-F 9957EO-F –– 9957NL-F 9957NL-OP-F 9957TL-F 9957TL-BE-F

–– 990DT 990NL-R/V 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22 22 2 2 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type Optional Trim

(See pages 32 – 34) #425 SNB optional-

HMD

Req. WD w/o SLM Pkg. #425 SNB Req. w/ 499F

9857L-F 9857L-NL-F 9857L-BE-F –– 9957L-F 9957L-NL-F 9957L-BE-F ––

996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-RV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

––

–– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2 22 2 2

For optional trims and functions see pages 32-34

110NL-MD 110NL-WD

9847/9947 Concealed Vertical Rod Device

9847/9947 concealed vertical rod device for use on single or double metal doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. The 9847 device has a smooth mechanism case and the 9947 device has a grooved case. The concealed vertical rod device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch). See Opposite page for available outside trim and device functions.

The 9847/9947 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9847 device only. See page 52 for component finishes and the inside cover for finish chips.

See page 53 for How to Order specification

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49 GBK Glass Bead Kit see page 49 PL Pullman Latch see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking Top & Bottom Bolt, ⁵₈" (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 ⁵₈" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

9847/9947 Concealed Vertical Rod Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

Optional Pull Required (Use with DT Trim) Always Operable

(No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9847EO 9847DT 9847NL 9847NL-OP 9847TL 9847TL-BE 9947EO 9947DT 9947NL 9947NL-OP 9947TL 9947TL-BE

–– 990DT 990NL-R/V 110NL-MD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9847L 9847L-NL 9847L-BE 9847L-DT 9947L 9947L-NL 9947L-BE 9947L-DT

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9847-F/9947-F Concealed Vertical Rod Fire Device

9847-F/9947-F fire exit concealed vertical rod device for use on pairs of doors up to 8´ x 10´(2438mm x 3048mm) , UL listed for Fire Exit Hardware. See page 41 for detailed information on UL listed fire exit

hardware label and door opening size information. Devices are ANSI A156.3 – 2001 Grade 1. The 9847-F device has a smooth mechanism case and the 9947-F device has a grooved case. The concealed vertical rod device is non-handed except when the following device option is used: SS (Signal Switch) devices. See Opposite page for available outside trim and functions.

The 9847-F/9947-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9847-F device only. See page 52 for component finishes and the inside cover for finish chips.

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈" (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 ⁵₈" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 ¹₈" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9847-F/9947-F Concealed Vertical Rod Fire Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

(Not recommended for Optional Pull Required (Use with DT Trim) Always Operable

Fire Device) (No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9847EO-F –– 9847NL-F 9847NL-OP-F 9847TL-F 9847TL-BE-F 9947EO-F –– 9947NL-F 9947NL-OP-F 9947TL-F 9947TL-BE-F

–– 990DT 990NL-R/V 110NL-MD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type Optional Trim

(See pages 32 – 34) #425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9847L-F 9847L-NL-F 9847L-BE-F –– 9947L-F 9947L-NL-F 9947L-BE-F ––

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

––

–– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9848/9948 Concealed Vertical Rod Device

9848/9948 Concealed vertical rod device for use on single or double metal doors, UL listed for Panic Exit Hardware. Covers stock hollow metal doors with 86 or 161 cutouts. Devices are ANSI A156.3 – 2001 Grade 1. The 9848 device has a smooth mechanism case and the 9948 device has a grooved case. The concealed vertical rod device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9848/9948 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9848 device only. See page 52 for component finishes and the inside cover for finish chips.

See page 53 for How to Order specification

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking Top Bolt, ³₄" (19mm) throw

Deadlocking Bottom Bolt, 1 ¹₂" (38mm) throw

Device Centerline from 39 5/8" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 5/8" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 1/8" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

9848/9948 Concealed Vertical Rod Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

Optional Pull Required (Use with DT Trim) Always Operable

(No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9848EO 9848DT 9848NL 9848NL-OP 9848TL 9848TL-BE 9948EO 9948DT 9948NL 9948NL-OP 9948TL 9948TL-BE

–– 990DT 990NL-R/V 110NL-MD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9848L 9848L-NL 9848L-BE 9848L-DT 9948L 9948L-NL 9948L-BE 9948L-DT

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9848-F/9948-F Concealed Vertical Rod Fire Device

9848-F/9948-F concealed vertical rod device for use on pairs of doors up to 8´ x 10´(2438mm x 3048mm), UL listed for Fire Exit Hardware. See page 41 for detailed information on UL listed fire exit hardware label and door opening size information. Devices are ANSI A156.3 – 2001 Grade 1. The 9848-F device has a smooth mechanism case and the 9948-F device has a grooved case. The concealed vertical rod device is non-handed except when the following device option is used: SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9848-F/9948-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9848-F device only. See page 52 for component finishes and the inside cover for finish chips.

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking Top Bolt, ³₄" (19mm) throw

Deadlocking Bottom Bolt, 1 ¹₂" (38mm) throw

Device Centerline from 39 5/8" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 5/8" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 1/8" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9848-F/9948-F Concealed Vertical Rod Fire Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

(Not recommended for Optional Pull Required (Use with DT Trim) Always Operable

Fire Device) (No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9848EO-F –– 9848NL-F 9848NL-OP-F 9848TL-F 9848TL-BE-F 9948EO-F –– 9948NL-F 9948NL-OP-F 9948TL-F 9948TL-BE-F

–– 990DT 990NL-R/V 110NL-MD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type Optional Trim

(See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9848L-F 9848L-NL-F 9848L-BE-F –– 9948L-F 9948L-NL-F 9948L-BE-F ––

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9847/9947 Wood Door Concealed Vertical Rod Device

9847WDC/9947WDC concealed vertical rod device for use on single or double wood doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. The 9847WDC device has a smooth mechanism case and the 9947WDC device has a grooved case. The concealed vertical rod device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9847WDC/9947WDC devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9847WDC device only. See page 52 for component finishes and the inside cover for finish chips.

Scalp Plate Device is furnished standard with an 8" (203mm) long scalp plate for easy access to rods. Note: Do not

use on pair of doors with 9975.

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

283

Top Strike

For use with

Wood Frames

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature Hex key dogging standard

Dogging Options CD Cylinder Dogging see page 48

SD Special Center Case Dogging see page 48 LD Less Dogging see page 48

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

GBK Glass Bead Kit see Page 49 PL Pullman Latch see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Latch Bolt Deadlocking Top & Bottom Bolt, ⁵₈" (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 ⁵₈" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 1/8" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9847/9947 Wood Door Concealed Vertical Rod Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

Optional Pull Required (Use with DT Trim) Always Operable

(No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9847WDC-EO 9847WDC-DT 9847WDC-NL 9847WDC-NL-OP 9847WDC-TL 9847WDC-TL-BE

9947WDC-EO 9947WDC-DT 9947WDC-NL 9947WDC-NL-OP 9947WDC-TL 9947WDC-TL-BE

–– 990DT 990NL-R/V 110NL-WD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder)

Product Description

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

Optional #425 Sex Bolt Quantity for Device

9847WDC-L 9847WDC-L-NL 9847WDC-L-BE 9847WDC-L-DT 9947WDC-L 9947WDC-L-NL 9947WDC-L-BE 9947WDC-L-DT

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

9847WDC-F/9947WDC-F Wood Door Concealed Vertical Rod Fire Device

9847WDC-F/9947WDC-F fire exit concealed vertical rod device for use on pairs of doors up to 8’ x 9’ 3”

(2438mm x 2819mm) double wood doors, UL listed for Fire Exit Hardware. See page 41 for detailed information on UL listed fire exit hardware label and door opening size information. Devices are

ANSI A156.3 – 2001 Grade 1. The 9847WDC-F device has a smooth mechanism case and the 9947WDC-F device has a grooved case. The concealed vertical rod device is non-handed except when the following device options are used: SS (Signal Switch). See Opposite page for available outside trim and functions.

The 9847WDC-F/9947WDC-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28, 313AN, 315AN and US32D for the 9847WDC-F device only. See page 52 for component finishes and the inside cover for finish chips.

Scalp Plate Device is furnished standard with an 8" (203mm) long scalp plate for easy access to rods. Note: Do not

use on pair of doors with 9975.

Top Latch

Bottom Latch

385A

Bottom Strike

338

Top Strike

283

Top Strike

For use with

Wood Frames

Specifications

Device Functions Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive

screw from device

Device Lengths 3’ 2’4" to 3’ (711mm to 914 mm) Door Size

4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size

Strikes Top - 338 – Unfinished, Bottom – 385A - Unfinished

Optional Strikes – see page 39

Dogging Feature No Mechanical Dogging, EL option available

Electric Options LX Latchbolt Monitor Switch see page 42

Miscellaneous Options PN Pneumatic Latch Retraction see page 48

LBR Less Bottom Rod see page 49

GBK Glass Bead Kit see page 49

Fasteners & Includes 1 ³₄" (19mm) – 2 ¹₄" (57mm) Wood & Metal Doors

Sex Bolts (SNB) Optional SNB available for device, see next page for quantities

Optional SLM Blocking Pkg for wood doors with SLM blocking SNB required for wood doors, unless SLM Blocking Pkg specified

Latch Bolt Deadlocking Anti-friction Top & Bottom Bolt, ⁵₈" (16mm) throw

Device Centerline from 39 ⁵₈" (1006 mm) Standard, Adjustable from 35 ⁵₈" (905mm) to

Finished Floor 49 ⁵₈" (1260mm) Door Undercut ¹₄" (7mm) maximum

Center Case Dimensions 8" x 2 ³₄" x 2 ³₈" (203mm x 70mm x 60mm)

Mechanism Case Dimensions 2 ¹₄" x 2 ¹₄" (57mm x 57mm)

Top & Bottom Latch Case 4 ¹₂" x 2 1/8" x 1 ¹₂" (114mm x 54mm x 38mm)

Vertical Rods Round 2 piece adjustable rods

Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm) Bottom rod adjustable 35 ⁵₈" (905 mm) to 49 ⁵₈" (1260 mm) Extension rod kits available for doors over 8’4" (2533mm)

Projection Pushbar Neutral – 3 ¹³₁₆" (97 mm)

Pushbar Depressed – 3 ¹₁₆" (78 mm)

See page 53 for How to Order specification

9847WDC-F/9947WDC-F Wood Door Concealed Vertical Rod Fire Device Standard Trim

Exit only Dummy Trim Night Latch Night Latch Thumbturn Thumbturn

Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt Key Locks & Unlocks Blank Escutcheon

(Not recommended for Optional Pull Required (Use with DT Trim) Always Operable

Fire Device) (No Cylinder)

(Use with DT Trim)

Product Description

Trim Description

Escutcheon Plate Size Pull Center to Center

Projection ANSI Function Cylinder Type

Optional Trim (See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9847WDC-EO-F –– 9847WDC-NL-F 9847WDC-NL-OP-F 9847WDC-TL-F 9847WDC-TL-BE-F 9947WDC-EO-F –– 9947WDC-NL-F 9947WDC-NL-OP-F 9947WDC-TL-F 9947WDC-TL-BE-F

–– 990DT 990NL-R/V 110NL-WD 374T x 990DT 374T-BE x 990DT

3" x 14³₁₆"x ³₃₂"3"x 14³₁₆"x ³₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(76x360x2mm) (76x360x2mm) (70x273x21mm) (70x273x21mm)

–– 5¹₂" (140mm) 5¹₂" (140mm) –– –– –– –– 2"

(51mm) 2" (51mm) –– 3¹₄"(83mm) 3¹₄"(83mm)

01 02 03 03 11 –– –– ––

Rim Rim 1¹₄" Mortise ––

x990EO x991K-DT x991K-NL x992EO x992L-DT x992L-NL x994EO x994L-DT x994L-NL x996EO x996L-DT x996L-NL

x696DT x696NL x697DT x697NL

62 2 6 22

–– ––

Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim

Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Product Description

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type Optional Trim

(See pages 32 – 34)

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

9847WDC-L-F 9847WDC-L-NL-F 9847WDC-L-BE-F –– 9947WDC-L-F 9947WDC-L-NL-F 9947WDC-L-BE-F ––

996L-CV 996L-NL-CV 996L-BE-CV 996L-DT -CV

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

––

–– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

x992L x992L-NL x992L-BE x992L-DT x994L x994L-NL x994L-BE x994L-DT

22 2 2

For optional trims and functions see pages 32-34

98/99™ Optional Trim

Knob Knob – Night Latch Knob – Blank Knob – Dummy Trim Thumbpiece Thumbpiece

Key Locks Key Retracts Latchbolt Escutcheon Pull when Dogged Key Locks Blank Escutcheon

& Unlocks Alwaya Operable & Unlocks Always Operable

(No Cylinder) (No Cylinder)

Trim Description

Escutcheon Plate Size

Pull Center to Center

Projection ANSI Function

Cylinder Type

Rim or

Vertical Rod Device Mortise Lock

Device

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg. #825 SNB Req.

WD w/o SLM Pkg. F Rim device ONLY

#425 SNB Req. w/ 499F

991K 991K-NL 991K-BE 991K-DT 990TP 990TP-BE

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂" (70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– ––

–– 5¹₂"

(140mm) 5¹₂" (140mm)

3¹₄"(83mm) 3¹₄"(83mm) 3¹₄"(83mm) 3¹₄"(83mm) 2" (51mm) 2" (51mm)

08 09 –– 02 05 05

Rim Rim –– –– Rim ––

1¹₄" Mortise

1¹₄"

Mortise

1¹₄"

Mortise

––

22 2 2 22

Knob and Thumbpiece Trim

Lever Design Options

#01 #02 #03 #05 #06

Standard

#07 #12 #16 #17 #18

Handed

98/99™ Optional Lever Trim

Lever Lever – Night Latch Lever – Blank Escutcheon Lever – Dummy Trim

Key Locks and Unlocks Key Retracts Latchbolt Always Operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Trim Description

Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type

Rim or

Vertical Rod Device Mortise Lock

Device

992L 992L-NL 992L-BE 992L-DT

2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"2³₄"x 10³₄"x ²⁷₃₂"

(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)

–– –– –– ––

2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

1¹₄" Mortise 1¹₄" Mortise –– ––

Optional Lever Trims – 992

Optional Lever Trims – 994

Lever Lever – Night Latch Lever – Blank Escutcheon Lever – Dummy Trim

Key Locks and Unlocks Key Retracts Latchbolt Always Operable Pull when Dogged

(No Cylinder) (Not recommended for Fire Device)

Trim Description Escutcheon Plate Size Pull Center to Center

Projection ANSI Function

Cylinder Type

Rim or

Vertical Rod Device Mortise Lock

Device

994L 994L-NL 994L-BE 994L-DT

2³₄"x 9¹₄"x ²⁷₃₂"2³₄"x 9¹₄"x ²⁷₃₂"2³₄"x 9¹₄"x ²⁷₃₂"2³₄"x 9¹₄"x ²⁷₃₂" (70x235x21mm) (70x235x21mm) (70x235x21mm) (70x235x21mm)

–– –– –– ––

2⁷₈"(

73mm) 2⁷₈"(73mm) 2⁷₈"(73mm) 2⁷₈"(73mm)

08 09 –– 02

Rim Rim –– ––

1¹₄" Mortise 1¹₄" Mortise –– ––

The new 996L Breakaway™ trim has become the standard lever trim offering on the 98L/99L series devices. The 996L trim blends two successful Von Duprin designs; the look of the traditional 992L lever trim and the security and durability of the Von Duprin Breakaway™ design. The Breakaway™ design is especially effective in areas where vandalism to door hardware is a problem. The design intent is to discourage costly repairs from becoming necessary. The Breakaway

™

feature is not available on the NL (night-latch) or DT (dummy trim) versions.

996L Trim

The 992L trim series provides the traditional Von Duprin escutcheon design. Special versions available for doors of over 2 ¹₄"(57mm) thicknesses. Additionally available in an RX and E-locking/unlocking version.

98/99™ Exit Rim Device

696DT 697DT 696NL 697NL

1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"

(41x343x5mm) (41x343x5mm) (41x343x5mm) (41x343x5mm)

5¹₂"(140mm) 5¹₂"(140mm) 5¹₂"(140mm) 5¹₂"(140mm)

2¹₆"(52mm) 3" (76mm) 2¹₆"(52mm) 3" (76mm)

02 02 03 03

–– –– Rim Rim

–– ––

1¹₄" Mortise 1¹₄" Mortise

22 2 2

Optional Lever Trims – 696/697

Thumbpiece Thumbpiece Thumbpiece - Blank Escutcheon Thumbpiece - Blank Escutcheon

Key Locks & Unlocks Key Locks & Unlocks Always Operable Always Operable

(No Cylinder) (No Cylinder)

Fire Device)

Trim Description Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type

Rim or

Vertical Rod Device Mortise Lock

Device

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

#825 SNB Req.

WD w/o SLM Pkg.

#425 SNB Req. w/ 499F

696TP 697TP 696TP-BE 697TP-BE

1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"1⁵₈"x 13¹₂"x ³₁₆"

(41x343x5mm) (41x343x5mm) (41x343x5mm) (41x343x5mm)

5¹₂"(140mm) 5¹₂"(140mm) 5¹₂"(140mm) 5¹₂"(140mm)

2¹₆"(52mm) 3" (76mm) 2¹₆"(52mm) 3" (76mm)

05 05 05 05

Rim Rim –– ––

1¹₄" Mortise 1¹₄" Mortise –– ––

22 2 2

Optional Lever Trims – 696/697

Dummy Trim Dummy Trim Night Latch Night Latch

Pull when Dogged Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt

(Not recommended for (Not recommended for

Fire Device) Fire Device)

Trim Description Escutcheon Plate Size

Pull Center to Center Projection

ANSI Function Cylinder Type

Rim or

Vertical Rod Device Mortise Lock

Device

#425 SNB optional-

HMD

Req. WD w/o SLM Pkg.

#825 SNB Req.

WD w/o SLM Pkg.

#425 SNB Req. w/ 499F

98/99™ Trim Operation Selection

Operation Options

HL6 Exit Device Trim Option

Vandal Resistant Trim VR910 & VR914 Series

Features:

• Stainless Steel construction, 11 gage (0.120"thick)

• Thru-bolts and rugged mounting screws for maximum fastening strength.

•

10-24 screws supplied with VR910 & VR914 models.

• Built-in lock protector prevents vandalism to mortise latchbolt (available on certain models).

• Extra-tough stainless steel cylinder collar prevents pipe wrench or similar tool from damaging cylinder. Tapered design prevents side impacts from transferring directly to cylinder. Collar spins freely.

• Furnished with mounting screws for door thicknesses of 1³₄"to 2¹₄"

• Finish: US32D

• VR910 grip coated in black plastisol for softer touch and resilience to temperature extremes. Grip designed for comfortable operation.

• VR914 grip in all stainless steel.

• Meets ANSI/BHMA 156.13, Trim Security Test and California State Accessibility Standards Title 24.

•

1¹₂" (38mm) clearence from grip to door

•

1⁷₈" (48mm) total projection from door

• Consult IVES catalog for specification/ordering information.

Standard operation, key locks and unlocks thumbturn. Optional operation, key unlocks thumbturn, re-locks when key is removed. This operation is created by changing the cylinder plate included with control. Use 1¹₄" mortise cylinder with a straight cam. Schlage cam reference

B502-191.

Standard operation, key locks and unlocks lever or knob. e.g., 996L (Classroom)

Night latch, key retracts latch bolt. Lever or knob is rigid. Use NL suffix, e.g. 996LNL. (Storeroom)

Blank escutcheon, lever or knob always active. Use BE suffix, e.g., 996L-BE. (Passage)

Dummy trim, lever or knob rigid for pull operation. Use DT suffix, e.g., 996L-DT.

Lever and Knob Operations

374T/376T Series Thumbturn Control

(Shown with 990DT Trim)

Von Duprin and Glynn-Johnson have collaborated on an exit device trim that answers the problem of accessibility and performance.Using the Von Duprin 98/9975 mortise lock exit device along with the Glynn-Johnson HL6 Push/Pull latch, Ingersoll-Rand has created an exit device with mortise lock durability that utilizes a fully ADA compliant Pull paddle trim. The 98/9975HL device is available in all standard architectural finished and can be found in the Von Duprin device price list for easy ordering.

Model For Use With Size

VR910DT & VR914DT 98/99 Rim or Vert. Rod Device 5¹₄" (133mm) w x 11" (279mm) h VR910NL & VR914NL 98/99 Rim or Vert. Rod Device 5¹₄" (133mm) w x 11" (279mm) h VR910M-DT & 9875/9975 Mortise Device 7¹₄" (184mm) w x 11" (279mm) h

VR914M-DT VR910M-NL & 9875/9975 Mortise Device 7¹₄" (184mm) w x 11" (279mm) h

VR914M-NL

98/99™ CM993 and PRO993 Exit Trim

The Von Duprin Computer Managed CM993 Exit Trim is a stand-alone, battery-powered exit trim for use on doors where an exit device is required for egress. The CM993 is designed to be used with Von Duprin 98/99™ Rim and Vertical Rod exit devices for unmatched access control and ease of use. It can be programmed with LockLink

™

or LockLink™Express access control management software. The same software can also manage the Schlage CM Locks and the Locknetics Universal Controllers, which provide intelligent access control for electrified or battery-powered products such as magnets, strikes and cabinet locks.

Multiple users, Multiple access points. Multiple credential. One way to manage them.

Provides Unmatched Access Control

• Manages up to 1,000 users and provides audit trail for last 1,000 events

• SmarTime feature allows for time functionality:

– 16 time zones – 16 time schedules – 32 holidays – first person in – time expiration – time activation

• Full-swipe mag stripe card reader for maximum readability and reliability

• Optional audit trail of mechanical key override

• Optional auto card updating feature disables a lost or stolen card when the reissued card is presented at the lock

• LED status indicators

Easy To Retrofit...Easy To Operate And Architecturally Designed For New Construction

• Directly retrofits existing trim

• Fits doors from 1³₈" to 2¹₄" thick

• Comes with Schlage Everest 1¹₄" cylinder, but can adapt to other existing key systems

• LockLink software that programs the locks is Windows

-based and menu-driven. It can be

operated with minimal training.

For use with Von Duprin 98/99™ Series Exit Devices including Rim, Surface Vertical, Concealed Vertical and Three-Point latching models. (Not for use with mortise devices).

NOT FOR USE WITH CHEXIT DEVICES

Conversion to New Card System Not Necessary

• Our exit device trims most likely work with your existing mag card and HID prox cards

Von Duprin Programmable PRO993 Exit Trim For Manual Programming

• Manually program up to 120 keycodes right at the trim

• Similar mechanical features as CM993

• Complements Schlage PRO and Locknetics PRO series products

How To Order CM993 and PRO993 Exit Trim

1. Select Model

2. Select Access Credential Option (CMs only)

3. Select Lever

4. Select Handing

RH Right Hand LH Left Hand

Note: Handing is field-reversible

5. Select Key Cylinder Option

KD Schlage Everest Cylinder LC Less Cylinder

Note: Master keyed cylinders order separately

6. Select Finish:

605 Bright Brass 625 Bright Chrome 612 Satin Bronze 626 Satin Chrome (Standard) 613 Oil-Rubbed Bronze 695 Duranodic Dark Bronze

7. Select Trim Options

ATK Audit trail of mechanical key override, includes ATR (Requires

computer programming).

T3 ABA Track 3 Mag Card Reader (ABA Track 2 is standard for MGI

and MGK Series only).

EXT is now standard. Specify if for interior use.

Mag Card Reader for exterior use (for MGI and MGK Series only).

CM993 – MGK – 06 – LH – KD – 695 – EXT

Select Model Select Access Credential Option Select Lever Select Handing Select Key Cylinder Option Select Finish Select Trim Options

IBA iButton (adhesive backed) IBF iButton on Fob MAG1 Magnetic Stripe Card – Blank MAG2 Magnetic Stripe Card – Pre-encoded PRX1 Prox Card – Standard .070" thick PRX2 Prox Card – Adhesive backed for photo

application, .070" thick

PRX3 Prox Card – ISO – credit card size and

thickness, .031" thick

PRX4 Prox Card – Dual Technologies, magnetic

stripe and Prox, .031" thick

PF1 Prox Fob

Select Credentials

PRO993 Manually

programmed exit trim

CM993 Computer managed exit trim

KPI

Keypad iButton Reader

IBO

iButton Reader

MGK

Mag Card Reader Keypad iButton Reader

MGI

Mag Card Reader iButton Reader

PXK

HID prox Reader Keypad iButton Reader

PXI

HID prox Reader iButton Reader

#03 #06

Standard

#17

Door Thickness State door thickness. Available from 1³₈" to 2³₄"in

¹₈" increments

98/99™ Strike/Stile Information

DEVICE TYPE

98/99

98-F/99-F 9875

9975 9875-F

9975-F

9857 9957

9857-F 9957-F

9827 9927 LATCH RETRACTION

PL9827/PL9927 PULLMAN LATCH

9827-F 9927-F

9847 9947 9848 9948

9847-F 9947-F 9848-F 9948-F

9847WDC 9947WDC

9847WDC-F 9947WDC-F

STANDARD STANDARD OPTIONAL OPTIONAL

SINGLE DOOR DOUBLE DOOR SINGLE DOOR DOUBLE DOOR

STRIKE TRIM/STILE STRIKE W/MULLION* TRIM/STILE STRIKE TRIM/STILE STRIKE W/MULLION* TRIM/STILE

990/992 696/697 994/996

299 x 5654 4-7/16" 4-1/4"

3-13/16" 3-13/16" (113mm) (108mm)

299 4-1/2" 4-3/8" 299 x 4954 4-7/8" 4-3/4" (97mm) (97mm) 1408 x 5754 3-13/16" 3-13/16"

(114mm) (111mm) (124mm) (121mm) (97mm) (97mm)

1606 4-1/16" 3-15/16" 1606 x 1654 4-7/16" 4-1/4"

(103mm) (100mm) (113mm) (108mm)

4-3/4" 4-3/4" 4-3/4" 4-3/4" (121mm) (121mm) (121mm) (121mm)

299 x 4954 4-7/16" 4-1/4"

3-13/16" 3-13/16" (113mm) (108mm)

4-1/2" 4-3/8" 4-7/8" 4-3/4" (97mm) (97mm) 1408 x 5754 3-13/16" 3-13/16" (114mm) (111mm) (124mm) (121mm) (97mm) (97mm)

1606 4-1/16" 3-15/16" 1606 x 1654 4-7/16" 4-1/4"

(103mm) (100mm) (113mm) (108mm)

4-1/2" 4-3/8" 4-7/8" 4-3/4" (114mm) (111mm) (124mm) (121mm)

STRIKE APPLICATION TRIM/STILE OPTIONAL STRIKE APPLICATION TRIM/STILE

299 (Top) 304L/248L-4 (Bottom)

299 (Top) 260U (Stainless) 304L (Bottom) 385A (Bottom)

338 (Top) 385A (Bottom)

4-1/2" 4-3/8" 4-7/8" 4-3/4" 499F x 9 8 54 (114mm) (111mm) (124mm) (121mm) KR9954

*Mullion information–refer to the General and Auxiliary catalog.

990/992 696/697 994/996

1439

1410

299F 499F x 9954 –– –– –– –– ––

575 575-2 –– –– –– –– –– 576A-576B

499F x 9954 –– –– –– –– –– ––

299 x 4954

299 (Top) 299 (Middle) 304L/284-L (Bottom)

299F (Top) 299F (Middle) 304L (Bottom)

1439

1410

990/992 696/697 994/996

Single Door

Two Vertical Rod Devices

Vertical Rod with Mortise Lock Device

Two Vertical Rods

Vertical Rod with Mortise Lock Device

Single Door Two Vertical Rod Devices

Vertical Rod with Mortise Lock Device

Two Vertical Rod Devices

Single Door

Two Vertical Rod Devices

Vertical Rod with Mortise Lock Device

Two Vertical Rods

Vertical Rod with Mortise Lock Device

Single Door Two Vertical Rod Devices

Vertical Rod with Mortise Lock Device

Two Vertical Rod Devices

3-11/16" 3-5/8" (94mm) (92mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/8" (108mm) (105mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/4" (108mm) (108mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/4" (108mm) (108mm)

260U (Top) 385A (Bottom)

304L (Bottom)

304L

3-11/16" 3-5/8" (94mm) (92mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/8" (108mm) (105mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/4" (108mm) (108mm)

4-3/4" 4-3/4" (121mm) (121mm)

4-1/4" 4-1/4" (108mm) (108mm)

299F 304L

98/99™ Strike Information

Strikes for rim devices

264 299 299F 499F

Projection 9/16" (14mm) Projection 13/16" (21mm) Projection 13/16" (21mm) Projection 15/16" (24mm)

1408 1439–Blade Stop 1410–Integral Stop

One per pair of doors Projection 1/2" (13mm) Projection 1/2" (13mm)

1606 1609

Projection 3/8" (10mm) • Requires Coordinator

Panic Devices Only • For Fire Rated Application, consult factory

Strikes for vertical rod devices

248L-4 260U–Flush Transom Only 299 299F

Projection 3/8" (10mm) Projection 3/8" (10mm) Projection 13/16" (21mm) Projection 13/16" (21mm)

For Fire Rated Application, consult factory

304L 338 385A 283

Mortise 13/16" (21mm) Mortise 5/8" (16mm) Mortise 2-1/2" (64mm) For use with WDC devices

when used with wood frames

Strikes for mortise lock devices

575 575-2 576A 576B

• Not for use with astragals

• Not for use on wood doors

• Acceptable for 90 minute pair of hollow metal doors

Grade, Type, Function Options and Dimensions

ANSI Grade, Type & Function

Function Grade 1, Type 1 Grade 1, Type 2 Grade 1, Type 3 Grade 1, Type 7 Grade 1, Type 8 Grade 1, Type 9

98EO, 98EO-F 9827EO, 9827EO-F 9875EO, 9875EO-F 9847WDC-EO & EO-F 9847EO, 9848EO-F 9857EO, 9857EO-F 99EO, 99EO-F 9927EO, 9927EO-F 9975EO, 9975EO-F 9947WDC-EO & EO-F 9947EO, 9947EO-F 9957EO, 9957EO-F

98DT 9827DT 9875DT 9847WDC-DT* 9848DT 9857DT 99DT 9927DT 9975DT 9947WDC-DT 9948DT 9957DT

98NL, 98NL-F 9827NL, 9827NL-F 9875NL, 9875NL-F 9847WDC-NL & NL-F 9847NL, 9847NL-F 9857NL, 9857NL-F

99NL,99NL-F 9927NL, 9927NL-F 9975NL, 9975NL-F 9947WDC-NL & NL-F 9947NL, 9947NL-F 9957NL, 9957NL-F 98TP, 98TP-F 9827TP, 9827TP-F 9875TP, 9875TP-F 9847WDC-TP & TP-F 9847TP, 9847TP-F 9857TP, 9857TP-F

99TP, 99TP-F 9927TP, 9927TP-F 9975TP, 9975TP-F 9947WDC-TP & TP-F 9947TP, 9947TP-F 9957TP, 9957TP-F

98TP-2, 98TP-F-2 –– –– –– –– –– 99TP-2, 99TP-F-2 –– –– –– –– ––

98K, 98K-F 9827K, 9827K-F 9875K, 9875K-F 9847WDC-K & WDC-K-F 9847K, 9847K-F 9857K, 9857K-F 99K, 99K-F 9927K, 9927K-F 9975K, 9975K-F 9947WDC-K & WDC-K-F 9947K, 9947K-F 9957K, 9957K-F

98L, 98L-F 9827L, 9827L-F 9875L, 9875L-F 9847WDC-L & WDC-L-F 9847L, 9847L-F 9857L, 9857L-F 99L, 99L-F 9927L, 9927L-F 9975L, 9975L-F 9947WDC-L & WDC-L-F 9947L, 9947L-F 9957L, 9957L-F

98K-NL, 98K-NL-F 9827K-NL, 9827K-NL-F 9875K-NL, 9875K-NL-F

9847WDC-K-NL & WDC-K-NL-F 9847K-NL, 9847K-NL-F 9857K-NL, 9857K-NL-F

99K-NL, 99K-NL-F 9927K-NL, 9927K-NL-F 9975K-NL, 9975K-NL-F

9947WDC-K-NL & WDC-K-NL-F 9947K-NL, 9947K-NL-F 9957K-NL, 9957K-NL-F

98L-NL, 98L-NL-F 9827L-NL, 9827L-NL-F 9875L-NL, 9875L-NL-F

9847WDC-L-NL & WDC-L-NL-F 9847L-NL, 9847L-NL-F 9857L-NL, 9857L-NL-F

99L-NL, 99L-NL-F 9927L-NL, 9927L-NL-F 9975L-NL, 9975L-NL-F 9947WDC-L-NL & WDC-L-NL-F 9927L-NL, 9947L-NL-F 9957L-NL, 9957L-NL-F

98K-2, 98K-F-2 –– –– –– –– –– 99K-2, 99K-F-2 –– –– –– –– ––

–– 9827TL, 9827TL-F –– 9847WDC-TL & TL-F 9847TL, 9847TL-F –– –– 9927TL, 9927TL-F –– 9947WDC-TL & TL-F 9947TL, 9947TL-F ––

08*

09*

10*

11-12

*Device is Grade 1, 991K trim is Grade 2.

Dimensions

UL Listing for Fire Exit Hardware

UL Listed Fire Exit Hardware Label and Opening Size

Double Door

With 9954 With 9854 With KR9954 With KR9854 VR/VR VR/Mortise VR/VR

Exit Device Door Material Single Door Mullion Mullion Mullion Mullion Same Direction Same Direction Double Egress

98-F 3 Hour 3 Hour 3 Hour 3 Hour 3 Hour

99-F 4’ x 10’ 8’ x 10’ 8’ x 10’ 8’ x 8’ 8’ x 8’ 9875-F 3 Hour 3 Hour 9975-F 4’ x 10’ 8’ x 10’ 9827-F 90 Minute* 3 Hour 3 Hour 9927-F 8’ x 10’ 8’ x 10’ 8’ x 10’

9827LBR-F 90 Minute* 3 Hour 9927LBR-F 8’ x 10’ 8’ x 10’

9857-F 3 Hour 3 Hour 3 Hour 3 Hour 3 Hour 9957-F 4’ x 8’ 8’ x 8’ 8’ x 8’ 8’ x 8’ 8’ x 8’ 9847-F 90 Minute* 3 Hour 3 Hour 9947-F 8’ x 10’ 8’ x 10’ 8’ x 10’

9847LBR-F 90 Minute* 3 Hour 9947LBR-F 8’ x 10’ 8’ x 10’

9848-F 90 Minute* 3 Hour 3 Hour 9948-F 8’ x 10’ 8’ x 10’ 8’ x 10’

Metal –– –– ––

Metal –– –– –– –– –– ––

Metal –– –– –– –– ––

Metal –– –– –– –– –– ––

Metal –– –– ––

Metal –– –– — –– ––

Metal –– –– –– –– –– ––

Metal –– –– –– –– ––

* Currently, no door manufacturers offer a listing over 90 minutes with doors swinging same direction.

Consult wood door manufacturers for current UL listings.

98/99™ Electrical Options

Alarm Kit – ALK

The ALK battery alarm kit is a simple yet effective way to deter unauthorized use of an opening. While the exit device is still a means of egress, the ALK kit contains an internal horn. When the touch bar is depressed, the horn sounds to provide an audible means of signaling that the opening has been violated. The alarm kit can be armed or disarmed by key. Thus allowing the exit device to be set in an armed or disarmed mode. The horn is rated at 85 decibel.

The key switch uses a standard 1¹₄" (32mm) mortise cylinder with a straight cam (Schlage Cam reference B502-191). The unit operates on one standard 9-volt alkaline battery. When the battery is weak, the horn will emit an intermittent low battery alert signal.

Also can be powered using the PS9 Power Supply. See PS9 for additional information.

Alarm kits are available with a choice of two switch kits, RX or LX. RX monitors the touchpad and is furnished standard. LX optional latch bolt monitoring is recommended for use with surface vertical rod exit devices. Specify ALK-LX.

Note: For latch bolt monitoring on a 98/9975 with ALK,

specify a SS7500 lock. LX switch not available for 98/9975 devices.

The ALK is available in two styles, 33A/99ALK, grooved cover and 35A/98ALK, smooth cover.

The ALK includes “EMERGENCY EXIT ONLY. ALARM WILL SOUND” decal for application on door, or the SS push bar trim can be used instead of the door decal,specify SS push bar trim.

The ALK is available with 2 optional circuit boards. External Inhibit (EI) allows for the use of external switch to be used to arm, disarm and reset the alarm. Auto Reset (AR) rearms the alarm after a preset time. AR is available in three factory set times – 1¹₂, 3 or 6 minutes.

To Order, Specify:

1. External Inhibit – ALK-EI

2. Auto Reset – ALK-AR3 When the ALK is used, standard dogging is removed. If cylinder dogging

is required there are two choices. Special center case dogging is available or for 3’ or 4’ doors the ALK can be moved to the hinge side of the device and standard cylinder dogging can be added.

To Order, Specify:

1. Standard, 98NL ALK

2. Cylinder Dogging, CD98NL ALK

3. Special Center Case Dogging, SD98NL ALK

Minimum Door Opening Sizes on ALK Applications

Device 3' (914mm) 4' (1219mm)

Length Length

98/98-F/99/99-F 2'9" (838mm) 3'3" (991mm) 9875/9875-F/9975/9975-F 2'9" (838mm) 3'3" (991mm) 9827/9827-F/9927/9927-F 2'8" (813mm) 3'2" (966mm) 9857/9857-F/9957/9957-F 2'8" (813mm) 3'2" (966mm) 9847/9847-F/9947/9947-F 2'8" (813mm) 3'2" (966mm) 9848/9848-F/9948/9948-F 2'8" (813mm) 3'2" (966mm)

Request to Exit — RX

The RX (Request to Exit) feature is used to signal the use of an opening. This device is equipped with one internal SPDT switch which monitors the pushpad.

The device can be connected to a security console, or may be used as a single door alarm when used with a horn and power supply. A continuous current electric transfer must be used for transferring power from the frame to the door.

The RX switch option should not be used to control a load, but as a signalling switch (0.5 amps. resisitive maximum).

The RX switch is available in a low current (LC) switch. Most commonly used in computer operated monitoring systems.

To Order, Specify:

• Standard – Use prefix RX, example RX99EO

• Low Current – Use prefix RX-LC, example RX-LC98EO

Double Request to Exit — RX2

The RX2 feature uses 2 RX switches. Also available with the Low Current (LC) switch.

To Order, Specify:

• Standard – Use prefix RX2, example RX299EO

• Low Current – Use prefix RX2-LC, example RX2-LC98EO

Latch Bolt Monitoring — LX

The LX feature is used to signal the use of an opening. This device is equipped with one internal SPDT switch which monitors the latch bolt.

The LX switch option should not be used to control a load, but as a signalling switch (0.5 amps. resistive maximum).

The LX switch is available in a low current (LC) switch. Most commonly used in computer operated monitoring systems.

To Order, Specify:

• Standard – Use prefix LX, example LX99EO

• Low Current – Use prefix LX-LC, example LX-LC98EO

Electrical Rating for all Switches:

• Standard – up to 0.5 Amp @ 24VDC Maximum

• Low Current (LC) - up to .05 Amp @ 24VDC Maximum

Note: All Switches can be either factory or field installed

4343

98/99™ ELectrical Options

Electric Latch Retraction — EL

The EL feature allows for the remote unlatching of exit devices. A control station operator can flip a switch to retract the latch bolt and immediately change an exit door to push-pull operation. A powerful, continuous duty solenoid retracts the latch bolt, either for momentary unlatching, or for extended periods of time. The EL feature is an alternative to manual dogging.

If manual hex-key dogging is required, specify HD-EL. If cylinder dogging is required, the standard cylinder dogging is not available, but special center case dogging is available, specify SD-EL. SD-EL is not available on the 9875 or 9975 devices.

EL devices are also useful with automatic door operators, and may be applied to fire-rated applications when under the control of an automatic

fire alarm system.

UL approved for Class IIcir cuit applications. The EL option does not include the power transfer from door to frame, the

power supply, or the control operator. Refer to EPT-2 power transfer and the PS873 power supply.

The PS873 with the 871-2 option card is minimum option card required. Other option cards available for other functions, see PS873 power supply for additional information.

Solenoid Specifications:

Continuous Duty –– 24 VDC Current Inrush –– 16 Amps Current Holding –– 0.3 Amps

To order, specify:

Standard –– Use prefix EL, example EL99L. Hex Key dogging –– Use prefix HD-EL, example HD-EL99L Special Center Case Dogging –– Use prefix SD-EL, example SD-EL99L

Popular EL Application

Signal Switch — SS

Monitors pushpad and latch bolt

The SS feature is used to signal the unauthorized use of an opening. This device is equipped with two internal SPDT switches. One switch monitors both the pushpad and the latch bolt assembly, making the latch bolt tamper resistant, for positive security. An additional SPDT switch is connected to the 1 ¹₄" (32mm) mortise with straight cam for alarm “bypass.” (Schlage cam reference B502-191). The device can be connected to a security console, or may be used as a single door alarm when used with a horn and power supply. A continuous current electric transfer must be used for transferring power from the frame to the door.

Pushpad reads: “EMERGENCY EXIT ONLY – PUSH TO OPEN AND SOUND ALARM.” Pushpad is only available in US32D finish with red silk-screened lettering.

The SS mortise lock device is furnished with both the signal switch device and the SS7500 mortise lock. The SS7500 mortise lock has the versatility and advantages of the 7500 lock with the addition of signalling functions to monitor latch bolt operation and the trim locking function. The SS7500 mortise lock is supplied standard with the SS mortise lock device.

To Order, Specify:

1. Prefix SS, example SS99L.

2. Handing Required, LHR or RHR.

Electrical Ratings:

Up to 2.0 AMPS @ 24VDC

Popular SS Application

Unauthorized use of this opening will activate the local horn. The key switch permits inhibiting this system for authorized entry.

Power Supply PS873-2

120 VAC

EL #2

EL #1

SC I1 O1 I2 O2 GND

EPT-2

Input #2

(Required for independent operation only).

Input #1

Run Length EL Device w/EPT or Door Loop

0-100 ft. 14 gauge 100-200 ft. 12 gauge

Run Length EL Device w/Electric Hinge/Pivot

0-75 ft. 14 gauge 75-150 ft. 12 gauge

EL Device Wire Selection Size

Wire Selection Switch Wire Size

1200 ft. Max. 18 gauge

EPT-2 or EPT-10

871-2 option Card

Input #2

(Required for independent operation only).

Electric Power Transfer EPT-2 or EPT-10

98/99™ Electrical Options

Electric Mortise Lock Device — E

The electric mortise lock device has all the versatility and advantages of the standard mortise lock device, plus the advantage of being electrically controlled by a remote switching device, an access control system or an automatic fire alarm system. The device features the E7500 mortise lock. The E7500 controls the locking of the outside trim. When unlocked, the door remains latched, preserving the fire rating of the door and making it particularly useful where codes permit locking but require unlocking during a fire emergency. The outside trim cylinder retracts the latch bolt for mechanical override, night latch function. Only available with TP, K or L functions.

The E7500 lock contains a SPDT signal to monitor the outside trim condition (locked or unlocked) and a second SPDT signal switch to monitor the latch bolt.

Standard Features:

• Field reversible handing

• 24 VDC continuous duty solenoid

Optional Features:

• Fail safe (locked when energized, unlocked when de-energized or during power failure). Specify with suffix “FS.”

• Fail secure (unlocked when energized, locked when de-energized or during power failure). Specify with suffix “FSE”

• 24 VAC (with SO option)

• 12 VDC

• 12 VAC (with SO option)

Note: Some Fire codes will require “Fail Safe” (FS) operation for stairwell doors.

Be sure to specify the correct operation for your application.

Electrical Specifications:

• Solenoid –– .60 AMPS @ 12VDC

.30 AMPS @ 24VDC

• Each switch –– Up to 2.0 AMPS @ 24VDC Maximum

The E option does not include the power transfer from door to frame, the power supply or the control operator. (Refer to EPT-10 and PS861 or PS873 power supply)

To Order, Specify:

1. Use prefix “E,” example E9975.

2. FS or FSE

3. Voltage and current.

Electric Rim Device — E

The electric rim device provides remote locking and unlocking capabilities. A control station operator can flip a switch to lock or unlock the outside trim condition. The 24 VDC solenoid assembly contains a SPDT signal switch to monitor the outside trim condition (locked or unlocked), and a second SPDT signal switch to monitor the latch bolt.

The device is standard as fail safe (FS). When power is off, the trim is unlocked. The trim may then be relocked electrically by applying power. The device is field convertible for fail secure (FSE) applications.

The outside trim cylinder retracts the latch bolt for mechanical override, night latch function. Only available in TP, K or L function.

This feature does not include the power transfer from doors to frame, the power supply or control operator. Refer to the EPT-10 and PS861 or PS873 power supply.

NOTE: LX switch not required for E99 rim device when latch bolt

monitoring is required. E99 Rim has standard latch bolt monitoring feature.

Specifications:

• Solenoid – 0.25 AMPS @ 24VDC

• Each switch – Up to 2.0 AMPS @ 24VDC Maximum

UL listed FVSR SA163 panic hardware And GXHX R4504(N) fire exit hardware

To Order, Specify:

1. Use prefix “E,” example E99TP.

2. Handing Required, LHR or RHR.

Electric Mortise Lock Device or Electric Rim Device

Adaptable for openings where continuous latching is required while the trim may be electrically locked or unlocked from a remote location—stairwells, exterior doors, etc.

Minimum System Requirements:

• PS861

• EPT-10

454545

98/99™ Electrical Options

The Chexit

Designed for use on delayed exit applications, the Chexit system is ideal for controlled areas.

All controls, auxiliary locking, local alarm, and remote signalling are self-contained in the Chexit, providing safe, secure, easy to install and simple to operate door control and exit hardware.

Chexit controlled exit device for use on Panic or Fire Exit hardware applications.

This concept in delayed exit systems combines life safety with the needs of security and meets all requirements of NFPA 101 for “Special Locking Arrangement.”

The Chexit device includes decal for application on door. “PUSH UNTIL ALARM SOUNDS. DOOR CAN BE OPENED IN 15 SECONDS”

Solenoid Specifications:

• Continuous Duty – 24VDC

• Current Inrush – 16 amperes

• Current Holding – .3 amperes

Requires PS873 Power Supply

Request to Exit Switch:

Built into the device to detect when someone attempts to exit. Pushing the push pad when the device is armed will cause this switch to start an irreversible alarm cycle.

Nuisance Alarm:

When a Chexit is located in a public area, it can be desireable to limit false alarms. If the Nuisance Delay options are set to off, the device will go into alarm as soon as the push pad is touched (when armed). Turning the Nuisance Delay on will require the push pad to be pressed for 2 seconds before the Chexit goes into alarm. If the Nuisance Audible and Nuisance Delay are both on, the alarm will sound as soon as the push pad is pressed, but the alarm sequence will stop unless the push pad is held for 2 seconds or more.

Remote Alarm:

A set of relay contact are provided to give external alarm indication. These contact close when the device is in an irreversible alarm condition. These contact can be used to drive a horn, lamp, or other indicative device.

Key Switch:

The Key Switch provides the means to arm, disarm or reset the Chexit. The key can be removed in either the Arm or Disarm position.

Indicator Lamp:

The status of the Chexit can be determined by the indicator lamp. When the lamp is off, this indicates the device is disarmed and is functioning as a normal exit device (no delay). A continuously on lamp indicates the device has just been armed and as soon as the selectable rearm timer expires, the device will arm. A slow flashing lamp indicates the device is armed. A fast flashing indicator lamp indicates the device is in alarm.

Internal Horn:

Whenever the device is in alarm or the push pad is pressed the internal horn will sound. The volume level of this horn exceeds 85 db at 6 feet.

Door Position Input:

An external door position switch can be connected to the Chexit.

External Inhibit Input:

This optional input is provided to allow remote override of the Chexit in the armed condition. It also allows remoe reset of the Chexit in an alarmed condition.

Fire Alarm Input:

This input disables the Chexit immediately upon a fire alarm.

Internal Auxiliary Lock:

The Auxiliary Lock is engaged when the Chexit is armed. The locking mechanism is specifically designed to hold securely even when the exit device is struck with forceful blows.

User Defineable Rearm Time:

The Rearm time is the amount of time after the device is activated before it arms. It is designed to give someone time to pass through the door before rearming oocurs. Timing can be changed by the user for any time between 2 and 28 seconds in two second increments. There is also an infinite rearm setting that requires the use of an external door position switch. In this setting the door remains in the rearm mode until the door is closed. This can be useful on jet way doors in an airport.

Factory Defineable Delay Time:

Most jurisdictions allow 15 seconds of delay before allowing egress. In those cases where 15 seconds is not appropriate, Von Duprin can set the Chexit for any delay time between 0 and 60 seconds on 2 second increments. For delays greater than 15 seconds a letter from the local authority is required.

98/99™ Electrical Accessories

Power Supplies

SERIES PS873

The series PS873 power supply is designed to operate a wide variety of electrical products. EL panics require 871-2 PCB minimum. The regulated output power is field selectable for either 24VDC @ 2 ampere or 12VDC @ 4 ampere. Standard input 120VAC @ 1.0 ampere or 240VAC @ 0.5 ampere available. Enclosure is 10" high x 12

⁄2" wide x 5" deep (254mm x 323mm x 127mm), gray with a hinged cover and constructed of heavy 19 gauge steel. Five

⁄2" x 3⁄4" (13mm x19mm) knockout holes are provided for conduit connection. Terminal block will accept up to 12 gauge wire.

The PS873 can be ordered with three standard options: Key lock secures the cover to eliminate tampering and provides safety; Battery backup provides two hours backup power at full load during a A.C. power failure. Batteries will automatically recharge when failed power is restored. Fire Alarm provides input for a normally closed fire alarm contact. When the fire alarm contact is “open”, power to locks or other component is removed. Restoring power is field selectable for automatic or manual.

Eight standard configurations:

PS873 Standard PS873K With keylock PS873B With batter y PS873BK With battery and keylock PS873FA With fire alarm PS873K-FA With keylock and fire alarm PS873B-FA With battery and fire alarm PS873BK-FA With batter y, keylock and fire alarm

The series PS873 is available with several optional circuit cards to provide system flexibility. The power supply will accept one or a combination of any two cards.

Factory or Field Installed Circuit Cards: 871-2, Two Zone controller provides two inputs and two

outputs. Will operate one or two EL exit devices. Use suffix “-2” for factory installed, example PS873-2.

873-AL, Alarm function monitors 1 or 2 zones and provides alarm output, upon detecting a door in the open position. Delayed alarming is selectable from 5 to 75 seconds. Use suffix “-AL” for factory installed, example PS873-AL

873-AO, Auto Operator function coordinates the release of one or two locks and signals an auto-operator to open a door. Signaling the auto operator can be performed in two methods; by receiving a signal from a monitoring switch that the lock is unlatched, or upon expiration of a time delay triggered by a “RX” type input switch. Use suffix “-AO” for factory installed, example PS873-AO

873-SI, Security/Safety Interlock provide interlock function for two zones. When combined with a second 873-SI card, the inter-locking of groups are available in two, three or four zones. Safety interlock is available, consult factory for additional information. Use suffix “-SI” for factory installed, example PS873-SI

873-4TD, Four Zone controller with Time Delay provides four inputs and four outputs with time delay. Time delay is field selectable from 0 to 75 seconds, in intervals of 5 seconds. Will operate up to 4 EL devices. Use suffix “-4TD” for factory installed, example PS873-4TD

873-AC, Access Control provides supervision of one zone using an electromagnetic lock. Input signals required are: access control contact, motion detector contact, and motion detector override contact. FA, Fire Alarm option is required. Use suffix “-AC” for factory installed, example PS873-AC

Factory Installed Only Circuit Card 873-DE, Delayed Egress provides 15 second delay release from

pushbar activation to electro-magnetic lock release. Ideal function for use with Locknetics electromagnetic locks, will operate two zones simultaneously. To operate two separate zones, a second 873-DE card is required. UL listed component, when used as part of a Von Duprin delayed egress system. Use suffix “- DE”, example, PS873-DE.

Note: “DE” cards CANNOT

be combined with any other optional cards.

Electrical Accessories

47474747

Power Supplies PS861 Power Supply

Standard UL Listed Class 2, Power Supply UL1012 UL1310

The series PS861 power supply is designed for electric locking or monitoring on single or double door applications. The output power is field selectable for either 24 VDC@1 ampere or 12 VDC @ 2 ampere. Standard input 120 VAC@ 0.6 ampere and 240 VAC@ 3.0 ampere available. The terminal block will accept up to 14 gauge stranded wire.

The gray enclosure is 10" x 10" x 4" (254mm x 254mm x 102mm), has a hinged cover, and is constructed of heavy 19 gauge steel. Six ¹₂" (13mm) knockout holes are provided for conduit connection.

Options include keylock cover or Battery Backup. The pair of batteries, which are sealed lead acid battery packs, will provide back-up power for three hours at full load or seven hours at half load. Batteries will automatically recharge when failed power is restored.

Four Models:

PS861 Standard supply PS861K Standard supply

with keylock cover PS861B Battery backup PS861FA Fire Alarm PS861BK Battery backup and

keylock cover PS861BKFA Battery backup and

keylock cover with

FA board (24VDC only)

PS9 Power Supply

The PS9 is an AC power supply that provides 9 VDC power to operate the ALK alarm kit. The unit will power one or two alarm kits. Included is a 9-volt sealed battery that provides backup power in case of an AC power failure.

Electrical Power Transfer –– EPT Pneumatic Transfer – PNT

Electric Power Transfer provides a means of transferring electrical power from a door frame to the edge of a swinging door. The units are completely concealed when the door is in the closed position, and are ideally suite for installations involving abuse or heavy traffic.

Two models are available; EPT-2, two 18 gauge wires and EPT-10, ten 24 gauge wires. The EPT-2 and EPT-10 are U/L listed as

“miscellaneous door accessory”.

Pneumatic Controls

PNT-1 is available for pneumatic latch retraction exit devices. Appearance and dimensions are identical to EPT models.

UL Listed for use on firedoors

Door applications:

up to 5" butt hinges – 180˚ swing, 5¹₂"butt hinges – 130˚ swing, 6" butt hinges – 110˚ swing, ³₄"butt offset pivots 180˚ swing.

Not for use with swing clear hinges or center-hung pivots.

Finishes

SP28 (sprayed aluminum) SP313 (sprayed duranodic).

Dimensions

Housing 9" x 1 ¹₄"x 1⁵₈"(229mm x 32mm x 38mm) EPT-2 Two 18 gauge wires,

Up to 2 AMPS @ 24VDC, with a 16 AMPS Maximum Surge

EPT-10 Ten 24 gauge wires, Up to 1 AMPS @ 24VDC, with a

16 AMPS Maximum Surge

PNT-1 ⁵₃₂" Tubing

To order, specify:

1. EPT-2 ,EPT-10 or PNT-1.

2. Finish, SP28 or SP313.

98/99™ Electrical Accessories

Electrical Accessories

Pneumatic Controlled Exit Devices–PN

The PN feature provides remote latch bolt retraction in hazardous areas where electrically operated devices would not be permitted. The pneumatic solenoid will retract the latch bolt for momentary or prolonged periods. PN exit devices are particularly suited for use with automatic door operators. The PN feature is available on both Panic and Fire Exit Hardware devices.

The PN feature includes a special actuating linkage that gives building owners the option of mechanically or pneumatically dogging the exit device. If manual hex-key dogging is required, specify HD-PN (Dogging the device, whether mechanically or pneumatically, makes the device function as a push/pull unit and reduces the wear on its moving parts.) If cylinder dogging is required, the standard cylinder dogging is not available, but special center case dogging is available, specify SD-PN. SD-PN is not available on the 9875 or 9975 devices.

When activated pneumatically, the latch bolt(s) of the exit device retract in ¹₂ to 1 ¹₂ seconds. This pneumatic operation uses air pressure ranging from 50 to 100 pounds per square inch.

This product will function only when it is part of a pneumatic system (air compressor, air lines, pneumatic system, etc.). Contact LCN for correct control boxes

To Order, Specify:

• Standard –– Use prefix PN, example PN99NL

• Hex Key Dogging –– Use prefix HD-PN, example HD-PN99NL

• Special Center Case Dogging –– Use prefix SD-PN, example SD-PN99NL

Double Cylinder – 2

Double cylinder features an inside key cylinder which locks or unlocks the outside trim and an outside key cylinder which retracts the latch bolt only(Night Latch Function) . Available on rim or mortise lock device.

Rim requires two rim type cylinders. Mortise device requires 1 rim cylinder and 1 mortise cylinder 1¹₄" with a straight cam. (Schlage cam reference B502-191.)

Available functions are thumbpiece, knob or lever.

To Order, Specify:

1. Suffix-2 with device/trim number, example 99TP-2.

2. Handing required, LHR or RHR.

Less Dogging – LD

Less Dogging is available in all 98/99™ Panic Exit devices to remove the dogging option.

To Order, Specify:

• Use prefix LD, example LD99L

Special Center Case Dogging – SD

Special cylinder dogging in the center case is available for Chexit, EL, ALK panic devices to allow for mechanical push/pull operation. With this option, the latchbolt is held retracted and pushbar is still operable. Specify handing –– RHR or LHR.

SD requires 1 ¹₄"(32mm) mortise cylinder with a straight cam. (Schlage cam reference B502-191.)

Note: Available on Rim and Vertical Rod Panic Exit Devices only.

To Order, Specify:

• Use prefix SD, example SD99L

Cylinder Dogging — CD

Cylinder dogging is available on all 98/99™ Panic Exit devices to replace the standard hex key dogging. Unit requires a standard 1¹₄" (32mm) mortise cylinder with a straight cam (Schlage Cam B502-191 reference).

To Order, Specify:

• Use prefix, CD, example CD99L

Cylinder Dogging Kit — CDK

For field conversion, a cylinder dogging conversion kit is available. Cannot be added to fire exit hardware.

Order: 33A/99CDK or 35A/98CDK, specify finish.

Hex Key Dogging Kit — HDK

For field conversion, a hex key dogging conversion kit is available. Cannot be added to fire exit hardware.

Order: 33A/99HDK or 35A/98HDK, specify finish.

Braille, Embossed and Knurled Touchpads

Braille touchpad is embossed with the message “CAUTION STAIRWELL” in braille and raised letters provides assistance to person with impaired vision. Letters are ¹₂" (13mm) high and braille is #2, raised height is ³₃₂" (2mm). Other messages are available on special order, limited to 20 characters per line.

Embossed touchpad is embossed with the word “PUSH” Knurled touchpad is to provide warning to person with impaired vision.

98/99™ Options

49494949

98/99™ Options & Accessories

Vertical Rod and Latch Guard — RG-27

Series RG-27 Vertical Rod and Latch Guards protect the bottom rods of exit devices from the damaging impacts of carts or gurneys passing through doors. (If bottom rods become damaged, the exit device will not function as intended and can jeopardize the ability to exit safely during an emergency.)

In addition to protecting the vertical rod, the guard provides a smooth, unobstructed surface so the door can be pushed open easily with the bumpers of a wheelchair. The latch guard portion is 10" high. The standard latch guard features a 45° ramp. The extended latch guard offers a continuous ramp in 3' or 4' widths.

All stainless steel construction in US32D finish. Latch guards can cover latches as large as 1¹₄"W x 10"H x 1⁷₈"projection.

Models RGO — Rod guard only (Projection 1³₁₆").

RG-27 — Rod and latch guard. RG-27-3 — 3' (914mm) Rod Guard

and Extended Latch Guard.

RG-27-4 — 4' (1219mm) Rod Guard

and Extended Latch Guard.

Extended Latch Guard

LGO — Latch guard only. LGO-3 — 3' (914mm) Extended latch guard only. LGO-4 — 4' (1219mm) Extended latch guard only.

Note: Not for use on wood fire doors

To Order, Specify:

1. Model number.

2. Handing (except on RGO).

3. Door material if other than Hollow Metal.

4. Optional sex bolt mounting available.

Less Bottom Rod – LBR

LBR option is available, using a spring loaded auxiliary latch bolt installed in the lower door edge. When exposed to heat the auxiliary latch bolt releases, keeping the doors in alignment and closed during a fire. UL listed 3 hours on hollow metal doors double egress, 90 minute swinging same direction, and 20 minutes wood doors (consult wood door manufacturer). Fits door stiles as narrow as 3⁵₈".

LBR devices must be ordered in pairs or must be used in conjunction with an approved automatic or constant latching flush bolt.

Pullman Latch – PL

When PL is specified the standard latches are replaced with pullman style latches. Pullman latches are always extended and are most commonly used in conjunction with electric strikes and LBR-less bottom rod application. Not available with Fire rated devices. Not recommended where security is of the utmost since latches do not deadlock.

Glass Bead Kit – GBK

Glass bead conversion kits are available for all 98/99™ Series devices for use on doors with raised glass beads. Each kit consists of ¹₄" (6mm) shim sets. GBK for Surface Vertical Rod ships with ¹₈" shims for rod guides.

To order, specify:

1. 99GBK

2. Device type (Rim, Mortise, Surface Vertical Rod, Concealed Vertical Rod)

3. Wood Door, when used with Concealed Vertical Rod

997 Cover Plate Kit

36"

10´´

4 ³₈"

33¹₈" – 3' door 45¹₈" – 4' door

2 ¹₄"

12"

Rod Guard

Latch Guard

For 99 rim device, kit contains inside and outside plates for hinge stile cutouts, an inside plate for the lock stile, and necessary screws. Plates are designed to cover cutouts required by most existing exit device installations. Specify finish.

Cylinders

Cylinders are not furnished with device or trim and must be specified when ordering. Refer to trim pages for cylinder type.

Mortise — 3215 (Schlage B502-191 cam) Rim 3216

98/99™ Accessories and Door Handing

Dogged (Inverted) Cam Undogged Cam

(Standard Operations)

For Cylinder Dogging For Standard Trim Functions

Door Handing

Dummy Pushpad

The 330 dummy pushpad is designed as a companion unit for all 99 devices. The 350 dummy pushpad is a companion unit for all 98 devices. The pushpad is rigid or nonfunctioning. A push/pull operation can be accomplished by using 990DT, 996DT trim or any Ives Pull.

The 330/350 can be equipped with a functional pushpad and will accommodate an RX switch. Specify RX-330. May also be equipped with the RX2, double RX switch. Specify RX2-330

To order, specify:

1. 330 or 350.

2. Size 3' or 4' (914mm or 1219mm)

3. Finish, US3, US4, US10, US26, US26D, US28, 313AN, 315AN, 350 Only US32D.

51515151

98/99™ Popular Double Door Applications

Mortise lock and surface mounted or Concealed Vertical rod device combination—same direction

Two vertical rods—double egress

Two rim devices with mullion— same direction

Two surface mounted vertical rod devices—same direction (do not use with overlapping astragal)

Popular Double Door Applications

Two FEH vertical rods with auxiliary fire latch— LBR option

Auxiliary Fire Latch

98/99™ Finishes

Finishes

Color US Number BHMA Number A, B, E C D & F

Brass, Polished US3 605 Plated Brass, Polished US3, 605 Buffed Anodized Brass, Satin US4 606 Plated Brass, Dull US4, 606 Anodized Bronze, Satin US10 612 Plated/Anodized Bronze, Dull US10, 612 Anodized Chrome, Polished US26 625 Plated Stainless Steel, Polished US32, 629 Buffed Anodized Chrome, Satin US26D 626 Plated Stainless Steel, Satin US32D, 630 Anodized Stainless Steel, Satin* US32D 630 Stainless Steel Stainless Steel, Satin US32D, 630 Anodized Aluminum, Anodized US28 628 Powder Coat Stainless Steel, Satin US32D, 630 Anodized Duranodic Dark Bronze 313AN 710 Powder Coat Brown Wrinkle Powder Coat Anodized Black Anodized 315AN – Powder Coat Black Wrinkle Powder Coat Anodized

Special Finishes

Color US Number BHMA Number A, B, E C D & F

Bronze, Oil-Rubbed Satin US10B 613 Plated Bronze, US10B, 613 Anodized Powder Coat RAL # – Powder Coat Stainless Steel, Satin US32D, 630 Powder Coat Bronze, Polished US9 611 Plated Bronze, Polished US9, 611 Buffed Anodized Nickel, Satin US15 619 Plated Stainless Steel, Satin US32D Anodized

Touch Bar Trim Options:

Knurled Embossed “Push” Braille, US32D Only, Embossed “Caution Stairwell” SS, US32D Only, Red silk screen lettered “EMERGENCY EXIT ONLY – PUSH TO OPEN AND SOUND ALARM.”

*US32D Finish—available on Series 98 only

A. Center Case Cover

B. Touch Bar End Cap

C. Touch Bar Trim

D. Cover Plate

F. Mechanism Case

E. Mechanism End Cap

5353535353

98/99™ Additional Information

Nomenclature – How To Order

SD –– Special Dogging - Panic Only CD — Cylinder Dogging - Panic Only CX –– Chexit E –– Electric Locking (Rim or Mortise) EL — Electric Latch Retraction LX — Latch Bolt Monitoring PL — Pullman Latch PN –– Pneumatic Latch Retraction RX — Request to Exit RX2 –– Double Request to Exit SS –– Signal Switch

98 — Series 98-smooth 99 — Series 99-grooved

None — Rim Device 27 — Surface Mounted Vertical Rod Device 47 — Concealed Vertical Rod Device 47WDC –– Concealed Vertical Rod Wood Door Device 48 — Concealed Vertical Rod Device 57 –– Three Point Latch Device 75 –– Mortise Lock Device

DT — Dummy Trim EO — Exit Only K –– Knob (Classroom) K-BE –– Knob-Blank Escutcheoon K-DT –– Knob-Dummy Trim K-NL –– Rigid Knob - NightLatch (Key retracts Latchbolt) L — Lever (Classroom) L-BE –– Lever-Blank Escutcheon L-DT –– Lever-Dummy Trim L-NL –– Rigid Lever - Night Latch (Key retracts Latchbolt) NL –– Night Latch (Key retracts Latchbolt) NL-OP — Night Latch Cylinder Assembly –– Optional Pull TL — Turn Lever TL-BE –– Turn Lever-Blank Escutcheon TP –– Thumbpiece TP-BE –– Thumbpiece-Blank Escutcheon

XX –– Lever Style 06 standard

optional –– 01, 02, 03, 05, 07, 12, 16, 17, 18 F — Fire Exit Device LBR — Less Bottom Rod

2 –– Double Cylinder (Rim & Mortise Only) ALK –– Standard Alarm Kit ALK-EI –– External Inhibit Alarm Kit ALK-AR1 –– Auto-Reset 1¹₂ minute Alarm Kit ALK-AR3 –– Auto-Reset 3 minute Alarm kit ALK-AR6 –– Auto-Reset 6 minute Alarm Kit

3’ –– 3’ Device (2’ 4” –– 3’ Door Size) 4’ –– 4’ Device (2’ 10” –– 4’ Door Size)

US3, US4, US10, US26, US26D, 313AN, 315AN US32D – 98 ONLY

– HR –– Handing – RHR or LHR

EL 99 27 -L -16 -F LBR 3’ US3 RHR

98/99™ Notes

VON DUPRIN

Administrative Offices 2720 Tobey Dr. Indianapolis, IN 46219 317-613-8944 317-613-8302 Fax

Customer Service 800-999-0408 800-999-0328 Fax

Technical Support 888-371-7331 317-613-8509 Fax

Canada / Latin America

IR Security & Safety 1076 Lakeshore Road East Mississauga, Ontario, L5E 1E4, Canada (905) 403-1800 (905) 278-1413 FAX (877) 590-4734

North-East Asia

IR Security & Safety 23/F, 625 King’s Road Northpoint, Hong Kong +(852) 2235-0600 +(852) 2565-1409 FAX

South-East Asia / Australia / NZ

IR Architectural Hardware Ltd. P.O. Box 19-347 437 Rosebank Road, Avondale, Auckland, New Zealand +64 (0) 9-829-0550 +64 (0) 9-829-0552 FAX www.irarchitecturalhardware.co.nz

Mexico

IR Security & Safety Blvd. Centro Industrial No. 11 Puentas de Vigag, Tlalnepantla Estado de Mexico, 54070 Mexico +525-5-8503-6614

Europe / Middle-East / Africa

IR Security & Safety Ltd. Bescot Crescent Walsall, West Midlands WS1 4DL United Kingdom +44 (0)1922 707400 +44 (0)1922 646303 FAX www.irsecurityandsafety .co.uk

Visit Von Duprin on the web

www.vonduprin.com

or contact an

IR Security & Safety Consultant

1-877-840-3621

International Offices

98/99

™

Series Exit Devices

Factory Direct Hardware 9957EO26D3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
