Factory Direct Hardware 13412 User Manual
Installation Instructions / Warranty
Interaktiv
13412XX1
Retroaktiv
06088XX0
Interaktiv
06959XX1
Retroaktiv
06089XX0
Interaktiv Tub Spouts Retroaktiv Tub Spouts
13412XX1
Requires 1/2” male threaded nipple extending
4 1/2” - 4 3/4” outside the surface of the
finished wall.
Requires 1/2” male threaded nipple extending
3” - 3 1/4” outside surface of finished wall.
06959XX1
Requires 1/2” male threaded nipple extending
5/8” outside surface of finished wall.
Requires 1/2” male threaded nipple extending
3” - 3 1/4” outside surface of finished wall.
Installation: 06959XX1 only
Wrap the threads on the nipple with Teflon tape. Seal the
wall around the nipple with waterproof sealant.
Screw the mounting piece to the nipple. A 12mm Allen
wrench (not included) is useful. Slide the spout over the
mounting piece. Tighten the set screw with a 3 mm Allen
wrench.
06888XX0
06089XX0
Installation: All other models
Wrap the threads on the nipple with Teflon tape. Seal the
wall around the nipple with waterproof sealant.
Screw the spout onto the nipple, taking care not to cross
thread. If a final turn by wrench is desired, use a strap
wrench.
Turn on the water, flush, and check for leaks.
User Instructions - Diverter Tub Spouts
When the water is turned on, it will flow through the spout. To divert the water to the showerhead, push the diverter knob downward. When the water is turned off, the diverter will reset to
the spout position.
