Page 1
Starck
10410XX1
Terrano
37410XX1
Uno
38410XX1
Citterio
39410XX1
39411XX1
Starck X
10426XX1
Axor Tub Spouts
Installation Instructions / Warranty
Phoenix/Carlton
17420XX1
Page 2
2
Terrano
37410XX1
Uno
38410XX1
Available in Chrome and Satinox
Phoenix / Carlton
17420XX1
Starck X
10426XX1
Starck
10410XX1
Citterio
39410XX1
Page 3
3
Product Specification
Requires 1/2" NPT male threaded pipe fitting
recessed 3/8" behind surface of finished wall.
The 7/16" allen wrench shown is not included.
7/16" allen wrenches are available at hardware
and auto parts stores.
Citterio
39411XX1
Product Specification
Requires 3/4" female threaded pipe fitting recessed
3/8" behind surface of finished wall.
The 7/16" allen wrench shown is not included.
7/16" allen wrenches are available at hardware
and auto parts stores.
Installation Examples
Page 4
4
Cleaning Recommendation for Hansgrohe Products
Modern faucetry and shower products utilize a combination of materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment
is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
• To remove lime scale, use only products made specifically for that purpose. Always follow the manufacturer’s
instructions when using.
• Do not use cleaners that contain hydrochloric, formic, acetic, or phosphoric acids, as these will cause
considerable damage to finishes and to plastic components.
• Never mix cleaning materials.
• Never use cleaners containing abrasives. Do not use abrasive cleaning cloths, pads, or sponges.
Cleaning Procedures
• Clean your faucets and shower products as and when required. Regular cleaning will prevent scale
buildup and water spotting.
• Follow the label instructions. Do not allow any cleaner to remain on the product for longer than necessary.
• When using spray cleaners, spray first onto a sponge or cloth – do not spray directly onto the product.
• After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
•
Soap and shampoo residue can also cause damage to the product. Rinse well with clean water after use.
• If the surface is already damaged, harsh cleaning materials will cause further damage.
Page 5
5
Limited Lifetime Consumer Warranty
This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc.
(„Hansgrohe“). This warranty is limited to Hansgrohe products which are purchased by a consumer in the
United States after March 1, 1996, and installed in either the United States or Canada.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original consumer purchaser only.
WHAT IS COVERED BY THE WARRANTY
This warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product
against defects in material or workmanship as follows: Hansgrohe will repair at no charge for parts only
or, at its option, replace any product or part of the product which proves defective because of improper
workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is
unable to provide a replacement and repair is not practical or cannot be timely made, Hansgrohe may
elect to refund the purchase price in exchange for the return of the product.
LENGTH OF WARRANTY
Replacement or repaired parts of products will be covered for the term of this warranty as stated in the
following two sentences. If you are a consumer who purchased the product for use primarily for personal,
family, or household purposes, this warranty extends for as long as you own the product and the home
in which the product is installed. If you purchased the product for use primarily for any other purpose,
including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect
to Interaktiv and Retroaktiv products, and (ii) for 5 years, with respect to AXOR, ShowerPower and Pharo
products.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance,
misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents
or „no rinse“ cleaning products, or the use of the product in any manner contrary to the product
instructions.
C. Labor or other expenses for the disconnection or return of the product for warranty service, or for
installation or reinstallation of the product.
D. Accessories or related products not manufactured by Hansgrohe.
Page 6
6
TO OBTAIN WARRANTY SERVICE
Contact your Hansgrohe retailer, or write to Technical Service at:
Hansgrohe Inc.
1492 Bluegrass Lakes Parkway
Alpharetta GA 30004
Or, call Hansgrohe toll-free at (800) 334-0455.
In requesting warranty service, you will need to provide
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to
Hansgrohe Inc. 1492 Bluegrass Lakes Parkway, Alpharetta, Georgia 30004, Attention: Technical
Service, if required by Hansgrohe.
When warranty service is completed, any repaired or replacement product or part will be returned to
you postage prepaid.
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE
PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO
CREATE FOR IT ANY OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY PERSON FOR ANY
INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES, ARISING OUT OF BREACH OF
THIS WARRANTY OR ANY IMPLIED WARRANTY (INCLUDING MERCHANTABILITY).
Some States do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may have other rights which vary from State to
State.
You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply
before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
PRODUCT INSTRUCTIONS AND QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any damage
or visible defect. Prior to installing, always carefully study the enclosed instructions on the proper
installation and the care and maintenance of the product. If you have questions at any time about the
use, installation, or performance of your Hansgrohe product, or this warranty, please call or write to us
at the toll-free number and address printed above.
Page 7
7
Page 8
8
10/2006
9.08920.07
Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004
Tel. 770 360-9880 • Fax 770 360 9887
www.hansgrohe-USA.com
