Introduction

About this Manual

This manual contains information about the Extron XPA Ultra Series of power amplifiers:

• XPA U 358 eight channel low impedance power amplifier

• XPA U 358-70V eight channel 70 volt power amplifier

• XPA U 358-100V eight channel 70 volt power amplifier

• XPA U 358C-70V eight channel combination low impedance and 70 volt power amplifier

• XPA U 358C-100V eight channel combination low impedance and 70 volt power

amplifier

• XPA U 1004 four channel low impedance power amplifier

• XPA U 1004-70V four channel 70 volt power amplifier

• XPA U 1004-100V four channel 100 volt power amplifier

• XPA U 1004C-70V four channel combination low impedance and 70 volt power

amplifier

• XPA U 1004C-100V four channel combination low impedance and 100 volt power

amplifier

• XPA U 1002 two channel low impedance power amplifier

• XPA U 1002-70V two channel 70 volt power amplifier

• XPA U 1002-100V two channel 100 volt power amplifier

Terms Used in this Manual

Features

The terms “amplifier” and “power amplifier” are used interchangeably in this manual to refer to all of the XPA Ultra models.

• Output Power

• XPA U 358 models — 35 watts rms output power per channel, all channels driven.

• XPA U 1004 models — 100 watts rms output power per channel, all channels

driven.

• XPA U 1002 models — 100 watts rms output power per channel, all channels

driven.

• ENERGY STAR® qualified amplifiers — The XPA Ultra Series are ENERGY STAR

qualified amplifiers and energy efficient products that conserve energy and reduce costs.

XPA Ultra Series Power Amplifiers • Introduction 1

• Extron Patented CDRS - Class D Ripple Suppression — CDRS is an Extron

Patented technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifier designs. CDRS eliminates the high frequency switching ripple characteristics of Class D amplifiers, a source of RF emissions which can interfere with sensitive AV equipment such as wireless microphones.

• Convection cooled, fanless operation - can be stacked without extra rack

space for ventilation — The XPA Ultra Series amplifiers do not require internal fans or vents for cooling, ensuring quiet, reliable operation. They generate substantially less heat than conventional power amplifiers, making them ideal for rack-mount applications where space is at a premium.

• Eight channels (XPA U 358 models), four channels (XPA U 1004 models), or two

channels (XPA U 1002 models) in a 1U, half rack width enclosure - single and dual rack mount hardware included — The channel density of the XPA Ultra Series

amplifiers reduce rack space requirements for many installations. The included single and side by side rack mount hardware simplifies planning and saves cost.

• Defeatable auto-standby with fast wake up — The XPA Ultra Series amplifiers

meet ENERGY STAR qualification requirements with an auto-standby feature that automatically places the amplifier into standby after 25 minutes of inactivity, dramatically reducing power consumption. The XPA Ultra Series amplifiers quickly return to full power status in less than 100 ms upon signal detection, with minimal inrush current. Auto-standby can be disabled if required.

• UL 2043 plenum rated when used with optional Flexible Conduit Adapter

Kit — The XPA Ultra Series amplifiers meet UL 2043 for smoke and heat release for installation within a plenum airspace above a drop ceiling when used with the optional Flexible Conduit Adapter Kit. Above-the-ceiling placement conceals the amplifier to prevent theft, and is convenient for installing equipment when space inside the room is limited.

• Professional grade signal-to-noise and THD+N performance — The

XPAUltraSeries amplifiers deliver professional grade performance, featuring 100 dB signal-to-noise ratio and THD+N of less than 0.1%.

• Ultra low inrush current at power up - no need for power sequencing —

Allows multiple XPA Ultra Series amplifiers to be powered on simultaneously without overloading power circuits. This eliminates the need for power sequencing.

• Power factor correction - removes harmonic content on AC line — The

XPAUltraSeries amplifiers feature power factor correction technology that smooths out the high peak currents of the amplifiers’ current draw, minimizing the presence of high frequency harmonics on the AC power line, preventing audible artifacts from being transmitted to other audio equipment in the system.

• Rear panel recessed, detented level controls — Provides attenuation of input

signals for adjusting audio system gain staging. These controls are located on the rear panel to prevent tampering with level adjustments. Laser etched markings provide enhanced visibility of settings for ease of configuration.

• Automatic clip limiter — Detects actual onset of clipping. Gain is automatically

reduced without audible artifacts to protect speakers from clipping distortion.

• Multiple protection circuits — Active during output shorts, thermal overload, or DC

faults to prevent damage to the amplifier and speakers.

• Remote standby port — Enables the XPA Ultra Series amplifiers to be remotely

powered down when not in use, reducing operating cost.

XPA Ultra Series Power Amplifiers • Introduction 2

• High pass filter for high impedance models — This selectable filter, available on the

XPA Ultra Series high impedance models, rolls off frequencies below 80 Hz to prevent saturation of speaker transformers.

• 5 mm screw-lock captive screw speaker connectors — Enable simple, secure

connections with 22 to 12 AWG speaker cables.

• Front and rear-mounted signal and protection indication LEDs — Provide

convenient indication of input signal presence and protection circuit activation from both sides of an equipment rack.

• Front panel over-temperature LED — Provides visual indication that the amplifier

temperature has exceeded the optimal value, well in advance of the onset of thermal protection circuitry.

• Internal Extron Everlast Power Supply — Provides worldwide power compatibility,

with high-demonstrated reliability and low power consumption for reduced operating cost.

• Extron Everlast Power Supply is covered by a 7-year parts and labor warranty.

XPA Ultra Series Power Amplifiers • Introduction 3

Installation

Conference Room

This section discusses how to install the XPA Ultra Series of audio power amplifiers. Topics covered include:

• Application Examples

• Mounting the XPA Ultra Series Amplifiers

• Flexible Conduit Adapter Kit Installation

Application Examples

The following illustrations are application examples for the XPA Ultra Series power amplifiers.

RS-232

HDMI

Display

Extron SF 3C LP

Ceiling Speakers

Doc

Tuner

1 2 3

VCRLaptop PC DVD

Cam

Volume

Display

Tuner

Channel

Presets

321

Off

654

Mute

987

Room

Last

Control

More Presets

Enter

Screen

System

Audio

Lighting

December 15, 2013 - 7:58 AM

Help

Control

Off

Extron

Ethernet/PoE

AV LAN

OVER DTP

RS-232

TxRx TxRxG

Extron

DTP HDMI 230 Rx

DTP HDMI 4K 230 Rx

Receiver

CATx Cable up to 230' (70 m)

VoIP

AV LAN

Ethernet

OVER TEMP

7654321

LIMITER/PROTECT

SIGNAL

Table Microphones

•

• H

•

AudioAudio

•

Audio

INPUTS OUTPUTS

ACTIVITY

EXP LAN USB

CONFIG

Extron DMP 128 Plus C V AT

Digital Matrix Processor

OUTPUTS

Extron DTP CrossPoint 82 4K IPCP SA

Scaling Presentation Matrix Switcher

1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 89 10 11 12

CLIP

SIGNAL

INPUTS

CLIP

SIGNAL

LOGO

SELECT

ENTER PRESET

CONTROL I/O

VIEW

Figure 1. XPA U 358 Application Example

AudioAudio

AUDIO

ESC

VIDEO

CONFIG

AV Sources

Extron

POWER AMPLIFIERS

XPA U 358

XPA U 358 SERIES

Power Amplifer

Table Microphones

• H

•

Audio

DMP EXP

COM

RTS

eBUS

IR/S I/O

CTS

SLIMIT

112

OVER

12 23341234

MIC VOLUME VOLUME

DTP CROSSPOINT 4K SERIES

DIGITAL PRESENTATION SWITCHER

HDMI

•

RELAYS

• H

DMP 128 Plus

DIGITAL MATRIX PROCESSOR

Extron TLP Pro 720C

Cable Cubby TouchLink Pro Touchpanel

•

AV LAN

Ethernet

LAN

XPA Ultra Series Power Amplifiers • Installation 4

Extron

Room A

Room B

Wireless Microphone Syst

TLP Pro 725M

TouchLink Pro Touchpanel

Ethernet/PoE

AV LAN

Extron TLP Pro 725M

TouchLink Pro Touchpanel

Ethernet/PoE

AV LAN

Lectern

Extron SF 3CT LP

(Zone A1)

Ceiling Speaker

Extron SF 3CT LP

Ceiling Speaker

(Zone A3)

Extron SF 3CT LP

Ceiling Speaker

(Zone A4)

Extron

Microphones

XPA U 358-70V

Power Amplifer

Extron

sync

select ready

audio

power

muteselect

sync

select ready

audio

muteselect

DMP 128 Plus C V AT

Digital Matrix Processor

power

CONFIG

(Zone A2)

ACTIVITY

EXP LAN USB

OVER TEMP

1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 89 10 11 12

CLIP

SIGNAL

7654321

LIMITER/PROTECT

SIGNAL

INPUTS OUTPUTS

CLIP

SIGNAL

Lectern

XPA U 358 SERIES

AudioAudio

(Zone B1)

POWER AMPLIFIERS

Extron SF 3CT LP

Ceiling Speaker

Extron SF 3CT LP

Ceiling Speaker

(Zone B3)

Extron SF 3CT LP

Ceiling Speaker

(Zone B4)

Ethernet

DMP 128 Plus

DIGITAL MATRIX PROCESSOR

Ethernet

(Zone B2)

VoIP

AV LAN

Figure 2. XPA U 358-70V Application Examples

Ethernet

DMP EXP

INPUTS

OUTPUTS

LOGO

SELECT

ENTER PRESET

Extron DTP CrossPoint 84 4K IPCP SA

Scaling Presentation Matrix Switcher

XPA Ultra Series Power Amplifiers • Installation 5

CONTROL I/O

ESC

VIEW

AV Sources

COM

RTS

eBUS

IR/S I/O

RELAYS

CTS

SLIMIT

112

AUDIO

VIDEO

OVER

12 23341234

MIC VOLUMEVOLUME

CONFIG

DTP CROSSPOINT 4K SERIES

DIGITAL PRESENTATION SWITCHER

Ethernet

LAN

HDMI

Mounting the XPA Ultra Series Amplifiers

The XPA Ultra Series amplifiers can be mounted in a rack using included rack ears, set on a table, mounted on a rack shelf, or mounted in the plenum space above a ceiling-mounted projector. Additionally, two XPA Ultra Series amplifiers can be connected using the included bridging plate to create a full rack-width unit.

Tabletop Use

Four self-adhesive rubber feet are included with the audio amplifier. For tabletop use, attach one foot at each corner on the bottom side of the amplifier and

place the unit in the desired location.

UL Guidelines for Rack Mounting

The following Underwriters Laboratories (UL) guidelines pertain to the installation of the equipment in a rack.

1. Elevated operating ambient — If installed in a closed or multi-unit rack assembly,

the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consider installing the equipment in an environment compatible with the maximum ambient temperature specified by the manufacturer [Tma = +32 to +122°F (0 to +50 °C)].

2. Reduced air flow — Installation of the equipment in a rack should be such that the

amount of air flow required for safe operation of the equipment is not compromised.

3. Mechanical loading — Mounting of the equipment in the rack should be such that a

hazardous condition is not achieved due to uneven mechanical loading.

4. Circuit overloading — Consideration should be given to the connection of the

equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

5. Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment

should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (such as the use of power strips).

XPA Ultra Series Power Amplifiers • Installation 6

Rack Mounting

The XPA Ultra Series amplifiers can be rack mounted using one of the following methods.

Rack Ear Rack Mounting

The XPA Ultra Series amplifiers ship with a set of rack ears so the half rack-width amplifiers can be installed in a full rack-width space.

Mount the amplifier with the rack ears as follows:

1. If feet were installed on the bottom of the amplifier, remove them.

2. Attach the included rack ears to the sides of the amplifier with the four provided #6

3. Insert the amplifier into the rack, align the holes in the rack ears with the holes on the

4. Secure the amplifier to the rack using four provided 10-32 x 3/4” screws (see

machine screws (see figure3, 1).

OVER TEMP

1 2 3 4

LIMITER/PROTECT

SIGNAL

POW

ER AMPL

IFIERS

XPA U 1004 SERIES

Figure 3. Install XPA Ultra Rack Ears

rack.

figure4, 2).

OVER TEMP

1 2 3 4

LIMITER/PROTECT

SIGNAL

POWER

AMPL

IFIERS

XPA U 1004 SERIES

Figure 4. Secure XPA Ultra Amplifier to Rack

XPA Ultra Series Power Amplifiers • Installation 7

Bridge Plate Rack Mounting

The XPA Ultra Series amplifiers ship with a bridge plate connector for connecting two XPA Ultra Series amplifiers together to form a full rack-width unit.

Connect and mount two XPA Ultra Series amplifiers as follows:

1. If feet were installed on the bottom of the amplifiers, remove them.

2. Position the two amplifiers upside down and next to each other.

3. Use the bridge plate connector and four provided #4 machine screws to connect the

two amplifiers together (see figure5, 1).

4. Attach the two short rack ears to the amplifiers with four provided #6 machine screws

(2).

Machine screws (4)

004 SERIES

XPA U 1

POWER AMPLIFIE

SIGNAL

LIMITER/PROTE

1 2 3 4

TEMP OVER

XPA U 1004 SERIES

S R

MPLIFIE

OWER A

OTE

IGNAL

IMITER/PR

1 2 3 4

TEMP OVER

Figure 5. Install XPA Ultra Series Bridge Plate

5. Insert the amplifiers into the rack, align the holes in the rack ears with the holes on the

rack.

6. Secure the amplifiers to the rack using four provided 10-32 x 3/4” screws (see

figure6, 1).

OVER TEMP

1 2 3 4

LIMITER/PROTECT

SIGNAL

POWER AMPLIFIERS

XPA U 1004 SERIES

OVER TEMP

1 2 3 4

LIMITER/PROTECT

SIGNAL

POWER

AMPL

IFIERS

XPA U 1004 SERIES

Figure 6. Secure Connected XPA Ultra Amplifiers to Rack

XPA Ultra Series Power Amplifiers • Installation 8

Rack Shelf Mounting

(2) 4-40 x 3/16" Screws

RSU 129 1U Universal Rack Shelf

False faceplate uses 2 screws.

Use 2 mounting holes on opposite corners.

XPA U 1004 SERIES

2 3 4

OVER TEMP

LIMIT

ER/PROTECT

SIGNAL

POWER AMPLIFIERS

The XPA Ultra Series can be mounted in a shelf using the optional RSU 129 1U Universal Rack Shelf Kit or the RSB 129 1U Basic Rack Shelf.

Mount the amplifier with the shelf as follows:

1. If feet were installed on the bottom of the amplifier, remove them.

2. Place the amplifier on one half of the rack shelf.

3. Align the front of the amplifier with the front of the shelf, and align the threaded holes on

the bottom of the amplifier with the holes in the rack shelf.

4. Attach the amplifier to the rack shelf with the two provided 4-40 x 3/16” machine

screws.

ATTENTION:

• Using screws longer than 3/16” will damage the unit and void the warranty.

• L’utilisation de vis plus longues que 3/16” endommagera l’unité et annulera la

garantie.

5. Insert the screws from the underside of the shelf, and securely fasten them into

diagonally-opposite corners.

Figure 7. Mounting the Amplifier onto a Rack Shelf

6. Attach the false front panel (provided with the rack shelf) to the unoccupied side of the

rack, or install a second half rack-width device in that side by repeating steps 1 through

7. Attach the rack shelf to the rack using four 10-32 x 3/4” screws (provided). Insert the

screws through #10 beveled washers, then through the holes in the rack (see figure7).

XPA Ultra Series Power Amplifiers • Installation 9

Rack Mounting Ventilation Recommendations

Excessive heat can decrease the optimal lifetime of the power amplifier. An over temp indicator LED on the front panel of the amplifier lights red whenever the recommended operating temperature has been exceeded.

To reduce the chances of an over temp condition, the XPA Ultra amplifiers should be arranged in a rack environment such that the environment around the amplifier does not reach or exceed +122 °F (+50 °C). No more than four stacks of XPA Ultra amplifiers should be arranged one-on-top-of-the-other in a rack without an open space between the stacks (see figure8 below).

The XPA Ultra can also be arranged above or below another non-XPA Ultra device. In this case, the environment around the amplifier should not reach or exceed +122 °F (+50 °C).

Vent Space

Figure 8. Vent Space Example

XPA Ultra Series Power Amplifiers • Installation 10

Flexible Conduit Adapter Kit Installation

WARNING:

AVERTISSEMENT :

• The circuit breaker used for this connection should be rated no lower than 20 amps

and no greater than 30 amps.

• Le disjoncteur utilisé pour cette connexion devrait avoir une cote comprise entre 20

et 30amps.

• This unit must be installed in accordance with the National Electrical Code and with

all local codes.

• L’unité doit être installée conformément au NationalElectricCode et aux normes

électriques et de sécurité locales.

• An ALL-POLE MAINS SWITCH with a contact separation of at least 3 mm in each

pole shall be incorporated in the electrical installation of the building. The installation shall be carried out in accordance with all applicable installation rules.

• Un interrupteur omnipolaire avec une séparation contact d’au moins 3mm dans

chaque pôle, devra être incorporée dans l’installation électrique du bâtiment. L’installation doit être réalisée conformément à toutes les règles d’installation applicables.

• Installation and service must be performed by a qualiﬁed electrician only.

• L’installation et l’entretien doivent être effectués uniquement par un électricien

qualiﬁé.

• Make sure that the source device and the XPA are turned off and disconnected

from the power source before you begin.

• Éteindre tous les appareils d’entrée et de sortie puis retirer les câbles

d’alimentation. Vériﬁez que le XPA soit déconnecté de la source d’alimentation avant de procéder.

• To reduce the risk of ﬁre or electric shock, do not expose this apparatus to rain or

moisture.

• Aﬁn de réduire les risques d’incendie ou de choc électrique, protégez cet appareil

de la pluie ou de l’humidité.

• The Product is a Class I product, which must be connected only to a mains socket

outlet with a protective earthing (grounding) connection.

• Ce produit est un produit de ClasseI, qui doit être connecté seulement à une prise

femelle secteur équipée d’une connexion de mise à la terre.

• The mains plug/appliance coupler is used as the disconnect device and shall

remain readily operable.

• La ﬁche secteur ou le coupleur est un système de déconnexion dont le

fonctionnement immédiat constitue un facteur essentiel.

ATTENTION:

• A UL-listed electrical distribution box is required for the termination of the conduit

opposite the XPA (see UL Requirements on the next page).

• Un boîtier de distribution électrique listé UL est recommandé pour la terminaison du

conduit à l’opposé du XPA.

XPA Ultra Series Power Amplifiers • Installation 11

The optional Flexible Conduit Adapter Kit consists of:

100-240V

--A, 50-60 Hz

CLASS 2 WIRING

∞

18 26

∞

STANDBY

SIGNAL

LIMITER/ PROTECT

ATTENUATION

INPUTS

REMOTE

OUTPUTS

XPA U 1004

8Ω/4Ω

Remove (8) screws

Slide cover forward and lift straight up.

• One conduit adapter plate (pre-attached), for PS 124 and XPA 1002/2001 amplifiers

• One conduit adapter plate for XPA Ultra Series amplifiers (not attached)

• One 6-foot long electrical conduit

• Three 7.5-foot, 18-gauge spade connector power wires

• One UL-rated zip tie wrap

• Three auxiliary crimp style spade connectors designed for 14- to 16-gauge wires

NOTE: If needed, Extron recommends using a UL-rated crimp tool to terminate the

spade connectors. One recommended choice is Molex crimp tool.

The kit provides a convenient means to replace the IEC power cord of the XPA Ultra with conduit, where required by local codes.

UL Requirements

The UL requirements listed below pertain to the installation of the flexible conduit onto an XPAUltra Series product.

• This unit is not to be used beyond its rated voltage range

• This unit must be wired to a UL-listed distribution box

NOTE: The UL-approved electrical distribution box is not included with either

the XPA Ultra or the Flexible Conduit Adapter Kit. The installer is responsible for obtaining and installing the box.

Installing the Flexible Conduit Adapter Kit

ATTENTION:

• Electrostatic discharge (ESD) can damage IC chips even though you cannot feel it.

You must be electrically grounded before touching anything inside the XPA Ultra. A grounding wrist strap is recommended.

• Les décharges électrostatiques peuvent endommager les puces de circuit

même si vous ne pouvez pas les sentir, les voir ou les entendre. Vous devez être électriquement relié à la terre avant de toucher quoique ce soit à l’intérieur du XPA Ultra. Un bracelet de mise à la terre est recommandé.

To install the flexible conduit to the XPA Ultra:

1. Unplug the IEC power cord from the amplifier.

2. Remove the 8 screws from the top, bottom, and sides of the XPA and lift off the cover

(see figure9 below).

Figure 9. Removing the Cover

XPA Ultra Series Power Amplifiers • Installation 12

3. Remove the 2 screws holding the blue hot (line) and brown neutral wires from the

Disconnect cables and r connector

Separate adapter plate and washer fr

Washer-B

PA Ultra Series Conduit Adapter Plate

Place the adpater plate

terminal block on the PCB (see the figure below). Place the screws aside to be used later.

4. Remove the ground wire nut from the grounding stud on the bottom of the enclosure,

as shown below. Place the wire nut with the other screws to be used later.

5. Remove the wires attached to the IEC connector from the body of the XPA Ultra and

slide the IEC connector and attached wires up and out of the XPA Ultra enclosure (see figure10 below).

emove IEC

100-240V 1.3A

50-60Hz

Blue Wire

Brown Wi

Remove nut

Figure 10. Removing the IEC Connector

6. Remove the washer at the end of the conduit (Washer-B in figure11 below) and remove

the conduit adapter plate that ships with the kit.

om conduit.

Washer-A

Figure 11. Remove the Existing Adapter Plate

7. Place the adapter plate that ships with the conduit kit on the conduit with the flat side of

the plate facing the hexagonal nut and secure the new adapter plate to the conduit with the washer removed in step 6 (see figure12).

Figure 12. Secure XPA Ultra Series Adapter Plate to Conduit

8. Thread the blue, brown, and green 18-gauge power wires included with the flexible

conduit adapter kit through the length of the electrical conduit.

with the at side against washer-A and secure with washer-B.

XPA Ultra Series Power Amplifiers • Installation 13

9. Install the conduit with the new conduit plate attached into the opening from which the

IEC connector was removed in step 5 (see figure13 below).

10. Connect the blue hot (line) and brown neutral wires to the terminal block on the PCB

using the 2 screws that were removed in step 3. Use the included zip tie wrap to secure the two wires together close to the terminals (see figure13 below).

WARNING: Ensure that you observe correct wire polarity. The following

illustration shows the location of the hot (line) and neutral terminals.

AVERTISSEMENT : Respecter la polarité correcte des câble. L’illustration suivante

indique l’emplacement des bornes de ligne et de neutre.

Slide the conduit assembly into the enclosue.

100-240V 1.3A

Tie Wrap

50-60Hz

Blue Wire

Brown Wire

Figure 13. Install the Conduit Assembly

11. Connect the ground wire, as shown above, to the grounding stud on the bottom of the

enclosure using the nut that was removed in step 4.

12. Replace the cover of the XPA Ultra by attaching the 8 screws that were removed in

step2.

XPA Ultra Series Power Amplifiers • Installation 14

Operation

This section discusses how to operate the XPA Ultra Series half-rack audio power amplifiers. Topics covered include:

• Front Panel Features and Operation

• Rear Panel Features and Operation

• Troubleshooting

Front Panel Features and Operation

OVER

12345678

TEMP

POWER AMPLIFIERS

LIMITER/PROTECT

SIGNAL

XPA U 358 SERIES

A B

Power Indicator LED

Over Temp Indicator LED

Limiter/Protect Indicator LEDs

Signal Indicator LEDs

Figure 14. XPA Ultra Series Front Panel

NOTE: XPA U 358 front panel displayed above, other XPA U Series front panels function

identically.

Power Indicator LED — This LED lights:

• Green when the amplifier is receiving full power.

• Amber when the amplifier is in standby mode. Standby mode turns off all outputs

from the amplifier, although the amplifier is still receiving power.

NOTE: Power indicator LED may remain lit amber for a time after the removal of

AC power. This is normal.

Over Temp Indicator LED — This LED lights red when the amplifier exceeds the

recommended operating temperature for optimal lifetime. The LED will turn off after the amplifier has sufficiently cooled down.

Should the LED light, check the following:

• Verify that the placement of the amplifier allows for adequate ventilation and airflow.

• Avoid placing other equipment on top of or below the amplifier.

• Verify that the operating temperature is within the specified range (see Rack

Mounting Ventilation Recommendations on page10).

XPA Ultra Series Power Amplifiers • Operation 15

Limiter/Protect Indicator LEDs — These LEDs (representing their respective output

channels) light red under three circumstances:

• When the output wiring is shorted together.

• When audio clipping occurs, the LED of the corresponding channel blinks once per

clip occurrence.

• When an amplifier channel overheats, the corresponding LED lights. The LEDs do

not light after the amplifier recovers from the overheated condition.

NOTE: These LEDs are also located on the rear panel.

Signal Indicator LEDs — These LEDs (representing their respective output channels)

light green only when an input signal is detected on the corresponding channel.

NOTE: These LEDs are also located on the rear panel.

Rear Panel Features and Operation

A B

G H

∞

5678

∞

1234

ATTENUATION

100-240 0.5A, 50-60 Hz

XPA U 358

LIMITER/ PROTECT

SIGNAL

LIMITER/ PROTECT

SIGNAL

∞

LIMITER/

PROTECT

∞

100-240V 0.5A, 50-60 Hz

XPA U 358-70V

AC Power Connector

Limiter/Protect Indicator LEDs

Signal Indicator LEDs

Attenuation Potentiometers

SIGNAL

LIMITER/ PROTECT

SIGNAL

∞

5678

∞

1234

ATTENUATION

∞

5678

∞

1234

∞

INPUTS

STANDBY

REMOTEOUTPUTS

CLASS 2 WIRING

8Ω/4Ω

∞

5678

∞

1234

∞

INPUTS

E F G H

G OFF

HPF

STANDBY

REMOTE

CLASS 2 WIRING

3 4

OUTPUTS

70V

Audio Input High Pass Filter Control Port Remote Port Speaker Outputs

Figure 15. XPA Ultra Series Rear Panel

NOTE: XPA U 358 rear panels displayed above, other XPA U Series rear panels function

identically.

AC Power Connector — Connect a standard IEC AC power cord here for power input

(100 VAC to 240 VAC, 50-60 Hz) to the internal, autoswitching power supply. This connector may be replaced by the Flexible Conduit Adapter Kit (see Flexible Conduit

Adapter Kit Installation on page11).

Limiter/Protect Indicator LEDs — These LEDs light red under certain circumstances

(see Front Panel Signal Indicator LEDs at the top of this page).

XPA Ultra Series Power Amplifiers • Operation 16

Balanced Stereo Input

Tip

Slee

Unbalanced Stereo Input

the wires!

Balanced Dual Mono Input

Unbalanced Dual Mono Input

Ring

ves Tip

Ring

Signal Indicator LEDs — These LEDs light green only when an input signal is detected

on the corresponding channel (see figure15, C on the previous page).

Attenuation Potentiometers — Use a small screwdriver (such as the provided Extron

Tweeker) to adjust the audio input level for the corresponding channel. The analog potentiometers control the level from ∞ (full attenuation) to 0 dB.

To adjust the attenuation level of the XPA Ultra amplifier, do the following:

1. If connecting to a source device with a volume control (variable output), ensure

that the volume on the source device is set to its lowest point, then adjust the attenuation of the XPA Ultra fully counterclockwise.

2. Set the volume of the source device to its maximum volume level. No sound should

come out.

3. Return to the XPA Ultra amplifier and raise the attenuation until a sound distortion

occurs, then lower the level slightly until any distortion disappears. This setting ensures that, whatever the source device volume setting may be, no clipping occurs.

NOTE: When setting volume control through a source device, ensure that the

volume of the device is set to variable out. Consult the user manual of the device for detailed instructions on its calibration.

Audio Input — Wire the amplifier input connectors as shown in the following diagram.

Tip

Sleeve

Tip

Sleeve

Ring

Sleeve (s)

Ring

Tip

Sleeve

Tip

Sleeve

Do not tin

Figure 16. Audio Input Wiring

High Pass Filter Control Port — On XPA U models with high-impedance outputs,

jumper the OFF and G pins together to disable the internal 80 Hz high-pass filter. This function should only be used when high-pass filtering is applied to the signal before it reaches the amplifier.

Remote Port — The 3.5 mm 2-pole captive screw port is used to remotely place the

amplifier into standby. Connecting the Standby pin to the Ground pin places the amplifier in standby mode. Standby mode turns off all output, although the amplifier is still receiving power. Use the included 3.5 mm 2-pole captive screw connector to remotely ground the Standby pin. The power indicator LED lights amber when the amplifier is in standby mode.

NOTE: A 10k ohm resistor is included in the box. If this resistor is connected

between the standby pin and ground, the auto-standby timer is defeated. The standby pin can still be shorted to the ground pin to force the amplifier into standby.

XPA Ultra Series Power Amplifiers • Operation 17

Speaker Outputs — Wire the included 5 mm, 4-pole screw lock captive screw

70V OUTPUTS

100V OUTPUTS

connector to output audio. Observe the correct polarities for each channel (see figure17).

8Ω/4Ω OUTPUTS

Figure 17. Speaker Output Connectors

ATTENTION:

• Do not tie channel output pins to each other or to ground. Doing so will short

out the outputs, damage the ampliﬁer, or both.

• Ne pas lier les sorties 1 et 2 des canaux entre elles ou à la terre. Les sorties

pourraient être court-circuitées et/ou l’ampliﬁcateur pourrait être endommagé.

• To avoid risk of damage to the ampliﬁer or the speakers, always connect low-

impedance speaker loads (8Ω/4Ω) and high-impedance speaker loads (70V) to the appropriately marked output connectors on the ampliﬁer.

• Pour éviter tout risque de détérioration de l’ampliﬁcateur ou des enceintes,

connectez toujours les charges de l’enceinte faible impédance (8 Ω/ 4 Ω) et les charges de l’enceinte haute impédance (70 V) aux connecteurs de sortie correctement identiﬁés sur l’ampliﬁcateur.

NOTE: You must use Class 2 wiring for this output to comply with UL requirements.

To wire the stereo audio output: Step 1: Strip and insert the speaker wires into the connector and tighten the captive

screws. Be sure to observe correct polarity.

Do not tin the wires!

Figure 18. Securing Speaker Wires with Captive Screws

Step 2: Insert the wired connector into the amplifier output and secure the locking

screws on either side.

CLASS 2 WIRING

8Ω / 4 Ω OUTPUTS

Figure 19. Securing Speaker Connector to XPA Ultra with Screw Locks

XPA Ultra Series Power Amplifiers • Operation 18

Bridged Mono Output (8 ohm/4 ohm outputs only)

100-240V

0.6A, 50-60 Hz

CLASS 2 WIRING

∞

14 18 26

∞

STANDBY

SIGNAL

LIMITER/ PROTECT

ATTENUATION

INPUTS

REMOTE

OUTPUTS

XPA U 1004

8Ω/4Ω

Set levels identically per channel pair.

Input

Balanced Wiring

From Mono Source

To 8/16 Ohm Speaker Load

3.5 mm

Captive Screw

5 mm

Captive Screw

Un-Balanced Wiring

Amplified Output

The power output to a speaker can be doubled by bridging the output.

NOTE: The minimum load impedance when bridging is 8 ohms.

To bridge the output, follow these steps and refer to the diagram below:

1. Unplug the IEC power cord from the power amplifier.

2. Fully attenuate the potentiometers.

3. Wire the output as shown in figure20 below.

4. Wire the input as shown in figure20 below.

5. Connect the IEC power cord and power up the amplifier.

6. Adjust the input levels of channel pair identically (see in figure15, D on page16).

NOTE: During bridged mono output, the + output from the odd channel becomes

the positive terminal and the + output from the even channel becomes the negative terminal.

Figure 20. Bridging the Output

XPA Ultra Series Power Amplifiers • Operation 19

Troubleshooting

Amplifier Fails to Exit Standby Mode Promptly

The front and rear panels have LED warning indicators, as described in the following diagnostic information.

The input channel signal LED lights green per indicated input channel when an input signal is detected.

Power LED Color

Amber Not lit No output signal No input detected, verify the

Green or Amber

Amber Lit No output signal Amplifier has been placed in

Amber Lit DC Fault is detected.

Signal LED State

Lit intermittently Unit does not

Problem Description Problem Solution

promptly exit standby mode when input signal is present

Unit does not exit standby

input signal. If input signal is present, raise input level until signal LED lights.

The output signal level of the source may be too low to cross the signal detection threshold of the amplifier (see amplifier specifications for details). Increase the signal level of the source until the signal LED lights consistently, or defeat the standby timer.

standby mode and output has been turned off. Check remote port. DC Fault may have been detected (see below).

Disconnect power then disconnect the remote port (if connected). Next, reconnect power to the unit to determine if the unit immediately goes into standby upon power up. In such a case, service the unit.

XPA Ultra Series Power Amplifiers • Operation 20

Amplifier Enters Standby Mode Too Early

The input channel signal LED lights green per indicated input channel when an input signal is detected.

Power LED Color

Green or Amber

Signal LED State

Lit intermittently Enters standby mode

Problem Description Problem Solution

early

Limiter/Protect LED Warning Indicators

The output channel Limiter/Protect LED lights red per indicated output channel as shown in the following diagnostic information.

LED State Problem Description Problem Solution

Blinks Audio clipping is occurring at the

rate of one blink per clip

Lights steadily The amplifier may be overheating Determine the reason for the

Output channel leads are shorted Check speakers and speaker wiring

Reduce the power output to avoid overdriving the amplifier and causing clipping.

overheated state and allow the amplifier to cool. The LED will not be lit after the amplifier recovers from the overheated state.

for shorts.

Over Temp Indicator LED

This indicator does not represent a hard failure of the unit. It is meant as a warning that the amplifier has exceeded the recommended operating temperature for optimal product lifetime.

LED State Problem Description Problem Solution

Lights steadily Amplifier has exceeded the

recommended operating temperature. The LED turns off after the amplifier cools down sufficiently

XPA Ultra Series Power Amplifiers • Operation 21

• Verify that the placement of the

amplifier allows for adequate ventilation and airflow.

• Avoid placing equipment on top

of or below the amplifier.

• Verify that the operating

temperature is within the specified range.

Extron Warranty

Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:

USA, Canada, South America, and Central America:

Extron Electronics 1230 South Lewis Street Anaheim, CA 92805 U.S.A.

Europe and Africa:

Extron Europe Hanzeboulevard 10 3825 PH Amersfoort The Netherlands

Asia:

Extron Asia Pte Ltd 135 Joo Seng Road, #04-01 PM Industrial Bldg. Singapore 368363 Singapore

This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical or mechanical abuse, abnormal operating conditions, or if modiﬁcations were made to the product that were not authorized by Extron.

Japan:

Extron Electronics, Japan Kyodo Building, 16 Ichibancho Chiyoda-ku, Tokyo 102-0082 Japan

China:

Extron China 686 Ronghua Road Songjiang District Shanghai 201611 China

Middle East:

Extron Middle East Dubai Airport Free Zone F13, PO Box 293666 United Arab Emirates, Dubai

NOTE: If a product is defective, please call Extron and ask for an Application Engineer to receive an RA (Return

Authorization) number. This will begin the repair process.

USA: 714.491.1500 or 800.633.9876 Europe: 31.33.453.4040 Asia: 65.6383.4400 Japan: 81.3.3511.7655

Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage during shipment. Returned units must include the serial number and a description of the problem, as well as the name of the person to contact in case there are any questions.

Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or ﬁtness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.

Please note that laws vary from state to state and country to country, and that some provisions of this warranty may not apply to you.

Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92905, 800.633.9876

Extron electronics XPA U 358, XPA U 358-100V, XPA U 358-70V, XPA U 1004, XPA U 1004-70V User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
