Extech BR80 Operating Manual

User Manual

Video Borescope Inspection Camera

Model BR80

Additional User Manual Translations available at www.extech.com

BR80-en-GB_v1.2 11/17

2

Introduction

Congratulations on your purchase of the Extech BR80 Video Borescope. This instrument was
designed for use as a remote inspection device. Typical applications include HVAC inspection,
automotive inspection, cable routing, and boat/aircraft inspection. This meter is shipped fully
tested and, with proper use, will provide years of reliable service.

Cautions

 Do not expose the handle and display to spraying water.

 Switch off the Camera if the system is not in use.
 Please dispose of the batteries responsibly.
 Remove the batteries when cleaning the unit.
 Remove the batteries before storing the unit for an extended period of time.
 When batteries need replacement, replace all four of the batteries.
 Use only the specified battery size and type.
 Be sure to install the batteries with the correct polarity as indicated in the battery

compartment.

 Exposure to high temperatures can cause the batteries to explode, therefore do not

dispose of the batteries in fire. Place tape over the terminals to prevent direct contact with
other objects. Please follow all applicable regulations.

Description

1 Camera tube connector
2 Battery status indicator
3 Display monitor
4 Cameral light intensity (+) button
5 Image rotation button
6 Flexible camera tube
7 Battery compartment (bottom of handle)
8 Camera and LED lights
9 Handle grip
10 Power button
11 Camera light intensity (-) button
