Extech 461825 Operating Manual

User’s Guide
Combination Photo-Tachometer Stroboscope
Model 461825
Introduction
Meter Description
1. Tachometer Light Source
2. LCD Display
3. Measure trigger button
4. Memory Recall button
5. FINE adjust knob
6. COARSE adjust knob
7. Range/Function select switch
8. Stroboscope flash tube Note: Battery compartment is on rear of
meter
1
2
3
4
5
6 7
8
2 461825 Ver. 1.2 03/05
