User’s Manual

Wide Range Mini InfraRed Thermometer

with Laser Pointer

MODEL 42510

Introduction

Congratulations on your purchase of the Model 42510 IR Thermometer. This thermometer
measures and displays non-contact (infrared) temperature readings at the touch of a
button. The built-in laser pointer increases target accuracy while the backlit LCD and
handy push-buttons combine for convenient, ergonomic operation. Proper use and care of
this meter will provide years of reliable service.

Safety

• Use extreme caution when the laser pointer beam is on

• Do not point the beam toward anyone's eye or allow the

beam to strike the eye from a reflective surface

• Do not use the laser near explosive gases or in other
potentially explosive areas

Specifications

Infrared Thermometer Specifications

Range / Resolution

Accuracy ± 1% of reading or ±1oC (1.8oF) whichever is greater, from 15 to

Emissivity 0.95 fixed value
Field of View D/S = Approx. 8:1 ratio (D = distance; S = spot)
Laser power Less than 1mW
Spectral response

General Specifications

Display Backlit LCD display with function indicators
Display update rate 1 second approx.
Operating Temperature

Operating Humidity Max. 80 % RH.
Power Supply 9V battery
Automatic Power Off Meter shuts off automatically after 6 seconds
Weight 180g / 6.4 oz.
Dimensions 82 x 42 x 160mm (3.2 x 1.6 x 6.3”)

-50 to 200
200

50
± 2% of reading or ±2

of range: -50 to 537
Note: Accuracy is specified for the following ambient temperature

range: 18 to 28°C (64 to 82°F)

6 to 14 μm (wavelength)

ºC (-58 to 200ºF)

ºC to 538°C (200°F to 1000°F)

o

C (60 to 113oF)

0

ºC to 50ºC (32ºF to 122ºF)

o

C (4oF) whichever is greater, for remainder

o

C (-58 to 1000oF)

0.1

º

1°

2
