eXact PipeCut 280E System Operating Instructions Manual
PipeCut 280E
System
EN
Operating Instructions
patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113
Exact PipeCut 280 System
Blade information for Exact PipeCut saws
TCT (tungsten carbide tip) saw blades are for cutting steel, copper, aluminium and all kind of plastics.
TCT blades can be sharpened.
Cermet (ceramic alloy tip) saw blades are for cutting stainless steel, acid proof materials, steel,
copper, aluminium and all kind of plastics. Cermet blades can be sharpened.
Diamond blades are for cutting cast iron only. Diamond blades can not be sharpened.
2
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
A
3
Declaration of Conformity
We declare under our sole responsibility that the pipe cutting machine, Exact PipeCut280E described
under “Technical Data” are in conformity with the following standards or standardization documents:
EN60745 according to the provisions of the directives 2004/108/EC, 2006/42/EC.
For more information, please contact Exact Tools at the following address.
The technical fi le is available at the address underneath.
The person authorized to compile the technical fi le:
Mika Priha, R&D manager (mika.priha@exacttools.com)
Helsinki, 1.1.2010
Seppo Makkonen, Managing Director
Exact Tools Oy
Särkiniementie 5 B 64
FI-00210 Helsinki
Finnland
4
5
Information
The original language of this manual is english english
Contents
6. Technical data
7. Package contents
Safety
8. Safety instructions
Operation
10. Functional description
10. Product features
11. Before operating the tool
11. Connection to the mains power supply
11. Precise setting of the cutting point
11. Setting the pipe on supports
12. Attaching the pipe saw to the pipe
12. Piercing the pipe wall
12. Sawing around a pipe
13. Overload protection and rotation speed control
13. Straightness of cut and adjusting wheel
14. Installing and changing the saw blade
14 Service and maintenance instructions
16. Environment/Disposal
16. Guarantee/Guarantee conditions
16. Tips for users
Exploded view (separate attachment)
Defi nitions: Safety guidelines
The defi nitions below describe the level of severity for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result
in property damage.
Denotes risk of electric shock.
