Tri-logic
Bass Preamp II
First made popular by Xotic Effects, the Tri-Logic is back!
Renewed and Reincarnated by EWS, the "Tri-Logic Bass Preamp 2" is significantly
smaller in size and more affordable. With all the same features of the former Tri-Logic,
18-volts & 3-band EQ, the Tri-Logic Bass Preamp 2 has evolved with improved sound
quality and usability.
Volume Gain
Adjusts the volume. to control +20db boost.
Mid Selector Switch
Allows you to enhance the
High-Mid or Low-Mid frequencies.
Spec
Size(W/D/H)
Weight
True Bypass Switch ing
Power Consumption
Battery Type
AC Adapter
(Optional)
INPUT
Treble
Middle
Bass
112mm /65mm/50mm
320g
18VDC /4.3mA
9VDC( 006P) x2
9〜18VDC ,Negative Tip s
Pa ssi ve -1M Ω
Ac tiv e- 100 KΩ
10KHz +/-13dB
Hi-Mi d 800Hz+/-10d B
Low-M id 400Hz+/-12 dB
90Hz+ /-15dB
3 Band EQ
Allows you to cut or boost
Treble, Bass and Middle
frequencies.
Pedal is compatible with both
passive and active bass input.
With the slide switch on right
side, you can switch between
the 2 input type.
By Implementing
18-volt DC, we were
able to maintain plenty
of headroom. The new
circuit uses half the
power of the previous
model, doubling
battery life.
