Page 1
Following the very well received Brute Drive, we are proud to introduce the newest pedal
from EWS, t he Little Brute Dri v e (LBD). F r o m its sma l l body, ju m p s out an i n tense
distortion similar to its big brother, the Brute Drive.
Its compact design takes up very little real estate. It will fit anywhere you desire on your
pedal board. But don’ t let the small size fool you, this simple one-knob powerhouse
produces heavy crunch to fiery distortion tones. Output level and treble control can be
adjusted with 2 trimmers located inside the pedal.
This is an overdrive/distortion pedal that is compact in size, user-friendly and surely to
become your work-ready weapon!
And of course, it's true-bypass.
Gain
Adjust the amount of gain.
For crunch-tone, set the gain knob
between unity and 12 o’clock.
For more moderate to extreme
distortion sounds, turn knob past
the 12 o’clock position.
Spec
Size (W/D/H)
Weight
True Bypass Switching
Power
Consumption
Batter Type
AC Adapter
(Optional)
LBD does comply with external power supply
ranging from 9~18V, but it is designed to work
best with 9V. Using 12~18V power supply
should not cause damage to LBD, but please be
aware that it may cause the gain to drastically
decrease at a certain point when adjusting the
Gain knob. It may also alter the feel of the
distortion, and increase the level of the noise.
Additionally, please note that if you use a
switching type external power supply with LBD,
switching noise may mix into the effect sound.
38.5mm /92.5mm /55mm
300g
9VDC/6.4mA
9VDC(006P)×1
9VDC, Negative Tips
(Regulated recommended)
You can set the Treble
cut level with the
internal trimmer.
Output level
Adjusts the amount of
volume. Open the bottom
cover: 0 at 10 o’clock, 10
at 2 o’clock.
(Default setting is
between 7~8 o’clock.)
www.ews-us.com
distributed by Prosound Communications Inc.
www.prosoundcommunications.com
On/Off Switch
This pedal is true-bypass to
minimize the degradation of
sound quality.
Treble cut level
Adjusts the amount of t re bl e.
Open the bottom cover: 0 at 2
o’clock,10 at 10 o’cloc k.
(Default setting is be tw ee n
3~4 o’clock.)
