Evoko Room Manager
System Administrator’s
Guide and Manual
1
Ver 8.0 – 2014-03-31
1. Contents
1. |
Contents.............................................................................................................................................................. |
2 |
||
2. |
Read this first! Introduction to this Guide........................................................................................... |
6 |
||
3. |
User Guide.......................................................................................................................................................... |
6 |
||
4. |
System Architecture Overview................................................................................................................... |
8 |
||
---- Please reference the section for the server/application you are using---- |
|
|||
5. |
For server Exchange 2003 & 2007 WebDAV.................................... |
9 |
||
5.1. |
Installation and System Requirement........................................................................................... |
9 |
||
|
5.1.1. |
Checklist ............................................................................................................................................ |
9 |
|
5.2. Create Room Accounts in Mailbox Server................................................................................ |
10 |
|||
5.3. |
Account definitions............................................................................................................................. |
10 |
||
5.4. Create standard user account........................................................................................................ |
10 |
|||
5.5. Configure user in MS Outlook....................................................................................................... |
10 |
|||
5.6. |
Test |
.............................................................................................................................................................. |
15 |
|
5.7. Installing the Evoko Control Panel (PC Application)............................................................ |
15 |
|||
5.8. |
Configure Settings in the Evoko Control Panel...................................................................... |
16 |
||
|
5.8.1. Using the Evoko Control Panel from a previous installation.................................. |
16 |
||
|
5.8.2. ...........................................Using The Evoko Control Panel from a new installation |
16 |
||
|
5.8.3. ........................................................Exporting settings from the Evoko Control Panel |
24 |
||
5.9. |
Install ......................................................................or upgrade your Evoko Room Manager |
25 |
||
|
5.9.1. ............................................................................................................................ |
First installation |
25 |
|
|
5.9.2. ...........................................................................Upgrade application and configuration |
25 |
||
|
5.9.3. .........................................Add a new Evoko Room Manager to an old installation |
26 |
||
|
5.9.4. ............................................................................................................................. |
Exit application |
26 |
|
6. |
For server ......Exchange 2007 EWS, 2010, 2013 and Office 365 |
28 |
||
6.1. |
Installation .........................................................................................and System Requirement |
28 |
||
2
Ver 8.0 – 2014-03-31
6.1.1. |
Checklist.......................................................................................................................................... |
28 |
|
6.2. Create Room Accounts in Mailbox Server................................................................................ |
29 |
||
6.3. |
Account definitions............................................................................................................................. |
29 |
|
6.4. |
Create resource account................................................................................................................... |
30 |
|
6.5. Create standard user account........................................................................................................ |
31 |
||
6.6. Configure user in MS Outlook....................................................................................................... |
31 |
||
6.7. |
Test.............................................................................................................................................................. |
35 |
|
6.8. Installing the Evoko Control Panel (PC Application)............................................................ |
35 |
||
6.9. Configure Settings in the Evoko Control Panel...................................................................... |
36 |
||
6.9.1. |
Using the Evoko Control Panel from a previous installation.................................. |
36 |
|
6.9.2. |
Using The Evoko Control Panel from a new installation........................................... |
36 |
|
6.9.3. |
Exporting settings from the Evoko Control Panel........................................................ |
48 |
|
6.10. |
|
Install or upgrade your Evoko Room Manager................................................................. |
50 |
6.10.1. |
First installation............................................................................................................................ |
50 |
|
6.10.2. |
Upgrade application and configuration manually....................................................... |
50 |
|
6.10.3. |
Add a new Evoko Room Manager to an old installation......................................... |
51 |
|
6.10.4. |
Exit application............................................................................................................................. |
51 |
|
6.11. |
|
Evoko Room Manager EVO Functionality.......................................................................... |
52 |
Remote upgrade.......................................................................................................................................... |
52 |
||
Remote monitoring.................................................................................................................................... |
52 |
||
Statistics............................................................................................................................................................ |
52 |
||
7. For Google Apps for business.......................................................... |
53 |
||
7.1. |
Installation and System Requirement......................................................................................... |
53 |
|
7.1.1. |
Checklist.......................................................................................................................................... |
53 |
|
7.2. Create Room Accounts in Mailbox Server................................................................................ |
54 |
||
7.3. |
Account definitions............................................................................................................................. |
54 |
|
3
Ver 8.0 – 2014-03-31
7.4. Create standard user account........................................................................................................ |
54 |
||
7.5. |
Create resource account................................................................................................................... |
55 |
|
7.6. |
Test |
.............................................................................................................................................................. |
56 |
7.7. Installing the Evoko Control Panel (PC Application)............................................................ |
57 |
||
7.8. Configure Settings in the Evoko Control Panel...................................................................... |
57 |
||
7.8.1. Using the Evoko Control Panel from a previous installation.................................. |
58 |
||
7.8.2. ...........................................Using The Evoko Control Panel from a new installation |
58 |
||
7.8.3. ........................................................Exporting settings from the Evoko Control Panel |
66 |
||
7.9. Install ......................................................................or upgrade your Evoko Room Manager |
67 |
||
7.9.1. ............................................................................................................................ |
First installation |
67 |
|
7.9.2. .......................................................Upgrade application and configuration manually |
67 |
||
7.9.3. .........................................Add a new Evoko Room Manager to an old installation |
68 |
||
7.9.4. ............................................................................................................................. |
Exit application |
68 |
|
|
|
----------------------------------------------------------------- |
|
8. Evoko Room ..................................................................................................Manager Functionality |
69 |
||
8.1. |
Users.......................................................................................................................................................... |
69 |
|
8.2. Feature ...........................................................................................list – Evoko Room Manager |
69 |
||
8.3. Book ........................................................................................a meeting room in MS Outlook |
70 |
||
8.4. |
Facility ..................................................................................................................................Managers |
71 |
|
8.4.1. ............................................................................................................. |
Facility manager menu |
71 |
|
8.5. |
System ........................................................................................................................administrators |
72 |
|
8.5.1. .................................................................................................................. |
Administrator menu: |
72 |
|
8.6. |
Lost .....................................................................................................................................connection |
73 |
|
4
Ver 8.0 – 2014-03-31
Copyright © 2012-2014 Evoko Unlimited AB
This document and any associated files are for the sole use of the intended recipient(s) and may contain confidential and privileged information. If you are not the intended recipient, please destroy all copies of the document. Any unauthorized review, use, disclosure, dissemination, forwarding, printing or copying of this document or any action taken in reliance on this document is strictly prohibited and may be unlawful.
Visit us at www.evoko.se
5
Ver 8.0 – 2014-03-31
2. Read this first! Introduction to this Guide
This document describes the installation process for the Evoko Room Manager and contains the overall installation and configuration instructions to get it up and running.
The Evoko Room Manager can communicate with Google apps for Business, MS Exchange Server and Office 365 in a way similar to MS Outlook. If you currently book conference rooms via any of the servers, you may have to make a few minor adjustments. Otherwise, this guide will take you through the procedure of setting up Users in MS Exchange.
The Evoko Control Panel (PC application) is only used by the System Administrator to set up the rooms in the Evoko Room Manager. The end user will only use either MS Outlook, web access or the Evoko Room Manager to book meetings.
It is important that these steps are followed in the correct order to ensure a clean and easy installation.
Add resource or user accounts in MS Exchange, Google apps for Business or Office 365.
Install the Evoko Control Panel.
Configure the room settings with the Evoko Control Panel.
Export settings to the Evoko Room Manager.
Start the Evoko Room Manager.
Please make sure that you run the latest software on the Evoko Room Manager, according to www.evoko.se/support
3. User Guide
The Evoko Room Manager is a system for booking and managing rooms. The Evoko Room Manager is mounted outside the room and display the booking status on beautiful touch-sensitive screens, the red or green background illumination of the screen allows you to see at a distance whether or not the room is free.
You book meetings just as you have always done in MS Outlook or in Google apps for Business. The Evoko Room Manager also makes it possible to create and manage bookings directly on the touch-sensitive screen.
6
Ver 8.0 – 2014-03-31
Please watch the short interactive User Guide at www.evoko.se/userguide to see how it works! We recommend that you watch all of the chapters before starting the installation.
N.B.! As a System Administrator, it is especially important to watch the chapter entitled “Book in MS Outlook”.
7
Ver 8.0 – 2014-03-31
4. System Architecture Overview
What follows is a diagram showing the three main components in the system:
1.Calendar client (like MS Outlook or web client)
2.Server (like MS Exchange server of Google Apps for Business server)
3.Evoko Room Manager
The users book their meeting as usual from their Outlook client or mailbox web access.
The MS Exchange Server processes meetings just as it always has.
The meeting information is displayed on the Evoko Room Manager.
An overview of the roles of the System Administrator and the Facility Manager:
System Administrator |
Facility Manager |
The System Administrator manages all issues related to IT infrastructure such as setting up room accounts, network settings, etc.
The Facility Manager receives reports regarding maintenance issues such as a broken light or equipment malfunction. The reports are made directly to Evoko Room Manager by the users.
8
Ver 8.0 – 2014-03-31
5. For server Exchange 2003 & 2007 WebDAV
5.1Installation and System Requirement
5.1.1Checklist
The following prerequisites must be met in order to secure full functionality of the Evoko Room Manager:
Direct http or https access to MS Exchange server.
Correct time and time zone settings on the MS Exchange server.
Make sure that no security functions or programs block or restrict a direct http/https communication between the server and the Evoko Room Manager (i.e. domain control, firewalls, proxies, network logins etc.)
If you are not sure if your environment is supported or not, you can download the Evoko Control Panel software and go through all the tests. If you are able to configure and pass the Evoko Control Panel tests the Evoko Room Manager should work in your environment, provided that you are doing the test from the same network that will be used by the Evoko Room Manager. You can also check http://www.evoko.se/support to get the latest information on supported systems.
If you need additional help you can always contact support@evoko.se for more information about Evoko Room Manager specialists in your area.
MS Exchange server 2003 and 2007-WebDAV needs to access:
https://<exchangeserver (ip or domain)>/exchweb/bin/auth/owaauth.dll (authentication) https://<exchangeserver (ip or domain)>Exchange/room@domain.com (read calendar)
9
Ver 8.0 – 2014-03-31
5.2 Create Room Accounts in Mailbox Server
The Evoko Room Manager is designed to work with standard user accounts.
N.B.! You need to have one user or resource account in your server for every Evoko Room Manager that you will use. Please make sure that this is done before you continue.
If you already have a set of accounts available for booking, please read these instructions anyway to see if you need to make any adjustment to make your current room accounts compatible with the Evoko Room Manager.
5.3 Account definitions
Regular user: A standard user in server with its own credentials that can be used to access the account. A room configured as a Regular user will behave exactly like a normal user account for real users.
5.4 Create standard user account
The procedure for creating a room user is identical to creating a normal user in MS Exchange. With admin login you can create room accounts.
5.5 Configure user in MS Outlook
After setting up the account that will correspond to the room in MS Exchange, the room user will need to be configured in MS Outlook in order to automatically accept/decline meetings. This is done by logging in as the room user using the room user credentials and completing the following steps in MS Outlook.
N.B.! These are general instructions based on a standard installation of MS Exchange 2003 and Outlook 2007. If this method does not work for you please find your version specific information directly from Microsoft.
10
Ver 8.0 – 2014-03-31
STEP 1: GO TO THE "TOOLS" MENU AND CLICK ON "OPTIONS"
11
Ver 8.0 – 2014-03-31
STEP 2: GO TO THE FIRST TAB, “PREFERENCES”, AND CLICK ON THE “CALENDAR OPTIONS BUTTON
12
Ver 8.0 – 2014-03-31
STEP 3: CLICK ON "RESOURCE SCHEDULING"
13
Ver 8.0 – 2014-03-31
STEP 4: CLICK THE BOX LABELLED "AUTOMATICALLY ACCEPT MEETING REQUESTS AND PROCESS
CANCELLATIONS" AND CHECK THE BOX LABELLED “AUTOMATICALLY DECLINE CONFLICTING MEETING
REQUESTS”.
N.B.! It is possible to prevent users from booking recurring meetings. To do so, check the box labelled “Automatically decline recurring meeting requests”.
STEP 5:CLICK ON THE “SET PERMISSIONS” BUTTON
CLICK ON “ADD” IN ORDER TO ADD THE USERS THAT WILL
BE ALLOWED TO USE THE RESOURCE.
ASSIGN “AUTHOR” PERMISSION FOR EACH USER.
CLICK ON “APPLY”.
You have now completed the necessary settings and may log out from Outlook.
14
Ver 8.0 – 2014-03-31
5.6 Test
Test the account to make sure it is working properly. It is recommended that you log in as a normal user and try to book meetings under the newly created user. The following cases should be tested to make sure your settings are correct.
Please check our online video on how properly to book rooms in MS Outlook before you start testing.
Please make sure that you have logged in at least once before you test resource or normal user account on Evoko Control Panel application.
Make sure users are able to view the free/busy status of the room according to your security settings.
Make sure that bookings made for available timeslots are automatically accepted.
Make sure bookings made for unavailable timeslots are automatically declined.
5.7Installing the Evoko Control Panel (PC Application)
Follow these steps to make sure that you install the latest available application for configuring your Evoko Room Manager system.
1.Go to www.evoko.se/support
2.Download the Evoko Control Panel to your PC (PC should run Windows XP or later Windows OS).
3.Run the Evoko Control Panel and follow the instructions on the screen.
4.Finish once the installation is complete and then run the application.
N.B.! Please make sure that your Evoko Room Manager is not in “sleep mode” when configuring it with the settings from the Evoko Control Panel. The Evoko Room Manager does not synchronize with MS Exchange server during sleep hours and this could interfere with application settings, such as time and time zone settings.
N.B.! Make sure that you install and run the latest available Evoko Control Panel from the Evoko web site.
15
Ver 8.0 – 2014-03-31
5.8 Configure Settings in the Evoko Control Panel
Select the Evoko Room Manager on the device selection page.
Now the Evoko Room Manager application needs to be configured with some basic information in order to be able to connect to the Exchange 2003 or 2007(WebDAV) server. This is done via the Evoko Control Panel.
N.B.! The Evoko Control Panel is only used by the System Administrator for the initial setup and is never employed by the end user.
5.8.1 Using the Evoko Control Panel from a previous installation
If you have installed a previous version of the Evoko Control Panel or Evoko Configurator and have exported these values to a USB stick, please click “Import“” button instead of selecting server.
Double check all settings to make sure they are correct. Depending on your previous version you may have to add more information.
5.8.2 Using The Evoko Control Panel from a new installation
The basic configuration needed in order to make Evoko Room Manager work has to be entered into the Evoko Control Panel and then exported to the Evoko Room Manager.
We recommend using the installation guide when configuring for the first time. These are the steps to follow:
Server |
Connection |
System |
Dashboard |
Export to |
|
Choice |
Settings |
Properties |
USB |
||
|
N.B.! Make sure that you install and run the latest available Evoko Control Panel from the Evoko web site.
N.B.! You always find the most updated instructions and help by clicking the ?-button in the Evoko Control Panel.
16
Ver 8.0 – 2014-03-31
Server choice
First of all you need to select your server. Exchange 2003 and 2007 (WebDAV) is only available without support for EVO functionality.
Then select ”Continue to connectivity settings”-button.
Connectivity settings
These settings are going to be used while communicating with server you have selected on first screen.
Server settings: Manually enter server settings by filling out the following settings.
You need to select correct “Protocol” and “Server name” for your Protocol and MS Exchange server: Normally you can find this information in the URL you use to connect to your MS Exchange server.
17
Ver 8.0 – 2014-03-31
N.B.! Please note that this address could be both an internal (.local) address or an external address. The configuration should reflect the actual position of the Evoko Room Manager in the network.
N.B.! In most installations you can make sure that correct value has been entered, by try putting this value into a browser. Doing this should open Outlook Web Access. («/exchange or /owa») may have to be added to the value in order for this test to be run.
N.B.! WebDAV connection string is built like this:
< protocol><MS Exchange server>/exchweb/bin/auth/owaauth.dll
Test connection: By pressing this button the Evoko Control Panel will try to create a connection with the Exchange server using the configuration provided.
Test account on this server:
N.B.! To avoid installation issues it is recommended to do this test during configuration. However, please note that connection method may be different between location of the machine running Evoko Control Panel and the Evoko Room Manager.
Exchange user: Enter the user name of one of the configured room accounts in MS Exchange.
N.B.! Enter the user name of the account that will be used to access the calendar and email functionality of the mailbox user.
18
Ver 8.0 – 2014-03-31
N.B.! Depending on the environment you may have to enter username with or without domain name. Often this is the same information as you do in the log in box for OWA.
Exchange password: Enter the password configured in for the configured room account in MS Exchange.
N.B.! Special characters like <, >, &, ‘ or ‘ ‘ are not allowed. Mailbox owner: MS Exchange account for the conference room. Normally you enter the full email of the room user@domain.com. If this does not work try entering username only.
Test Mailbox: Before moving on you should now test if it is possible to connect using the server details and user credentials given.
System properties
Time format: Select 12 or 24 hour clock. Default is 12. Evoko Room Manager will display time as per the selected format.
19
Ver 8.0 – 2014-03-31
Evoko language: The Evoko Room Manager has different languages pre-installed. Please choose which of the languages in the list you would like to use in the Evoko Room Manager.
System admin e-mail: Enter an email address of an account that will receive any error messages collected by the application.
System admin PIN code: Enter a 4-digit code for the admin area of the Evoko Room Manager. The code cannot be the same as the Facility Manager PIN code below. Make sure you keep your PIN code in a safe place as it is not possible to login to sys admin or facility manager levels without this PIN code.
Facility manager e-mail 1: Enter an email address of an account that will receive notifications pertaining to issues with room equipment reported by users.
Facility manager e-mail 2: Optional field to enter another email address of an account that will receive notifications pertaining to issues with room equipment reported by users.
Facility manager PIN code: Enter a 4-digit code for the Facility Manager Area of the Evoko Room Manager application. The code cannot be same as the Admin PIN code above. Make sure you keep your PIN code in a safe place as it is not possible to login to sys admin or facility manager levels without this PIN code.
Always on: Select “Yes” to prevent the Evoko Room Manager from going into sleep mode. If you select “No”, you need to provide going to sleep and wake up time for the Evoko Room Manager. If you choose ”Yes”, application will keep running 24/7.
Sleep and wake up time: Set the time for when the screen should descend into powersave mode at night and when you want to wake it up automatically in the morning. You can always easily wake it up by touching it once if you need a meeting even during sleep hours. We recommend you set this time a few hours
20
Ver 8.0 – 2014-03-31
Admin credentials
In this tab you enter all resource admin accounts at a central place and then in the dashboard you can point each room to the admin account that you want to use. When you need to update password you just change at this location and all rooms associated with that admin account will be updated.
N.B.! If you are upgrading from a previous version we will manage this change automatically and add all your previous admin credentials and set up references to the rooms in the dashboard." In the future when you need to update password you just change at this location and all rooms associated with that admin account will be updated.
Dashboard screen
Dashboard gives a quick look of all the groups and rooms in the Evoko Control Panel. These groups and rooms will be available to use in the Evoko Room Manager.
Groups are used to organize your room into smaller administrative units, for example different buildings. You should create your Groups before creating your rooms, but you can always move rooms between groups later.
After creating a room you can change time zone for that specific group if your groups are in different time zones.
21
Ver 8.0 – 2014-03-31
You add groups by using the “Add group” button.
N.B.! Groups make administration of many rooms easier, but please note that Evoko Room Managers in different groups will not be able to get booking information of rooms outside its own group for the Find free room function.
There are two ways of adding rooms in dashboard. There is a “Step by step” option that is recommended for setting up your first room.
It will guide you through the process step by step.
N.B.! Once the Room addition process in Step by Step is completed, you can always edit the same in Dashboard view.
When you are comfortable with the process you might like to use the “Quickly” way.
Room name: Enter the name that you want the Evoko Room Manager to display on the start screen. This name can be “Conference Room floor 1” or anything else. The maximum length of this field is 23 characters. Special characters like <, >, &, ’ or ’ ’ are not allowed.
22
Ver 8.0 – 2014-03-31
Mailbox owner: MS Exchange account for the conference room. Here normally you enter the full email of the room user@domain.com. If this does not work try entering username only.
Exchange user: Enter the user name of one of the configured room accounts in MS Exchange.
N.B.! Enter the user name of the account that will be used to access the calendar and email functionality of the mailbox user.
N.B.! Depending on the environment you may have to enter username with or without domain name. Most often this is the same information as you do in the log in box for OWA.
Exchange password: Enter the password configured in for the configured room account in any of the server. Special characters like <, >, &, ’ or ’ ’ are not allowed.
Test: Testing the room settings can verify the given parameters to prevent connection errors in the ERM.
Seats: Enter the number of chairs in the room.
Meeting Room Facilities: Select checkboxes as on the corresponding icons according to the equipment available in the room. Remove selection from checkbox to remove such equipment from the list. The facilities which you select will be displayed in the home screen of ERM.
Optional features on Evoko Room Manager Screen:
Book meeting: Enable instant booking on screen
End meeting: Enable end meeting function on screen
Report issue: Enable equipment issue reporting on screen
Extend meeting: Enable extending meeting on screen
Display subject: Displays meeting subject on screen
23
Loading...
