Page 1
Evo Elite Series Circular Cooktops
Indoor
The natural way to cook
®
Page 2
Evo Affinity Elite Series
The Most Versatile Cooking
The Affinity 25E is an
electric cooktop with a
25" diameter ceramicclad cooking surface
and dual heat zones.
The Affinity 30Ge
is an electronically
controlled indoor gas
cooktop with a 30"
diameter ceramic-clad
cooking surface and
dual heat zones.
Entertaining family and friends
is a delight. Everyone agrees.
With simply prepared foods
from recipes handed down
generation upon generation, we
savor our kitchens as a place to
bring people together.
At Evo, bringing people together
around food is our passion. It's
also what inspired us to design
and build a new kind of cooking
appliance that lets people share
the joys of cooking.
Built in America and solidly
constructed, Evo’s unique
circular seasoned cooking
surface, dual heat zones and
wide range of controllable
surface temperatures makes it
perfect for cooking virtually any
meal from any angle.
Whether cooking for two or
hosting a party for ten, Evo is
center stage, helping you create
memorable experiences.
Page 3
Appliance You'll Ever Use
Bring out the goodness of food with an Evo circular flattop
cooking appliance. Prepare and share everything from a
delicious pancake, sausage and egg breakfast to the most
flavorful seared steaks, seafood and grilled vegetables you've
ever tasted. Sear, steam, grill, toast and stir-fry directly on Evo's
traditional non-stick oil-seasoned cooking surface to capture
and keep your food's natural flavors, or use your everyday pots
or pans to boil, braise, poach, sauté or fry. Enjoy fresh prepared
foods with family and friends around the most versatile cooking
appliance you'll ever use.
No other appliance is this social. No other appliance lets you
be this creative.
DIRECT COOKING TECHNIQUES: (1) Sear (2) Steam (3) Grill (4) Toast (5) Stir-Fry
Evo is easy to clean.
Simply scrape the
cook surface with your
Evo scraper, scour
with Evo’s cleaning
pad, and wipe clean
with a paper towel.
Evo is now ready for
your next creation.
1
6
INDIRECT COOKING TECHNIQUES: (6) Boil (7) Braise (8) Poach (9) Sauté (10) Fry
2
7
3
8
4
9
5
10
Page 4
DUAL ELECTRIC HEATER
Independently-controlled
heater provides two heat
zones across the cooking
surface for edge-to-edge
variable heat.
SPILLOVER TRAYS
Extend from drawers at
each right and left side of
the control panel.
Affinity 25E Elite Electric
The Affinity 25E is an electric cooktop designed for indoor kitchens. It features a 25"
diameter ceramic-clad cooking surface with an independently-controlled heater
providing two circular heat zones. Temperatures are variable from 150˚F to 525˚F
(66˚C to 274˚C).
The 25E is built to fit standard dimensions of residential kitchen countertops and
islands. All controls are conveniently positioned up front on a curved control panel
with an elevated cooking surface.
Stainless Steel Drip Pan
surrounds cooking
surface to contain
spillovers
Heavy Gauge 304
Stainless Steel Construction
at all contact surfaces
Removable Spillover Trays
concealed behind slide out
drawers at each right and
left side of control panel;
removable, dishwasher safe
Digital Electronic Display
provides On/Off and Mode
functions, and displays
temperatures at both inner
and outer cook surface zones
Cooking Surface
ceramic-clad steel that's
25 inches in diameter, 450
sq. inches total. A dual
zone heater provides
two independent heat
zones with variable
temperatures from 150˚F
to 525˚F (66˚C to 274˚C)
Inner and Outer
Temperature Control Knobs
command a variable
range of temperature
across two circular heat
zones for edge-to-edge
variable heat
TRIM KIT
Stainless steel square insert
for easy installation into
counter (optional).
Page 5
23-7/8”
1-7/8”
The Affinity 25E installs to a counter surface leaving only the
cooking surface, drip pan and control panel exposed. A zero
clearance tolerance allows flush installation to any wood, rock,
concrete, and tiled counter surface.
21-3/16”
Mounting
Locations
22-7/8”
25”
17-3/4”
Electrical
Conduit
Default Location
Affinity 25E Elite Cooktop
The Affinity 25E Elite
Cooktop is designed
to transform the
indoor kitchen into
a social cooking
space. With its
circular design and
versatile flattop
cooking surface,
meals are easier to
prepare with less
cleanup, making
this an appliance
everyone will enjoy.
32-3/16”
11-3/8”
6-1/2”
7-5/8”
6-15/16”
21-3/16”
12”
3-1/2”
1-13/32”
6-3/8”
1-1/2”
23-7/8”
Removable Spillover Trays x2
31-5/8”
Page 6
DUAL GAS BURNERS
Independently-controlled
circular burners provide
two heat zones across
the cooking surface for
edge-to-edge heat.
SPILLOVER TRAYS
Extend from drawers at
each right and left side of
the control panel.
Affinity 30Ge Elite Gas
The Affinity 30Ge is an electronically-controlled gas cooktop designed for indoor
kitchens. It features a 30" diameter ceramic-clad cooking surface with two
independently-controlled gas burners and two circular heat zones. Temperatures
are variable from 225˚F to 625˚F (107˚C to 330˚C).
The 30Ge is built to fit standard dimensions of residential indoor kitchen countertops
and islands. All controls are conveniently positioned up front on a curved control
panel with an elevated cooking surface.
Stainless Steel Drip Pan
surrounds cooking
surface to contain
spillovers
Flame Viewing Portals
located just below
cook surface provide a
convenient view of burners
Removable Spillover Trays
concealed behind slide out
drawers at each right and
left side of control panel;
removable, dishwasher safe
Digital Electronic Display
provides On/Off and Mode
functions, and displays
temperatures at both inner
and outer cook surface zones
Cooking Surface
ceramic-clad steel that's
30 inches in diameter,
650 sq. inches total. Dual
burners provide variable
temperatures from 225˚F
to 625˚F (107˚C to 330˚C),
with 40,000 BTU's
Heavy Gauge 304
Stainless Steel Construction
at all contact surfaces
Inner and Outer
Temperature Control Knobs
command variable
temperatures across two
circular heat zones for
edge-to-edge heat
TRIM KIT
Stainless steel square insert
for easy installation into
counter (optional).
Page 7
Gas Pipe
Gas Pipe
Inlet
120V Line
Input
Inlet
13-1/16”
27-17/32”
15/32”
120V Line
Input
1-27/32”
The Affinity 30Ge installs to a counter surface leaving only the
cooking surface, drip pan and control panel exposed. Minimum
3/8" clearance to combustible surfaces allows installation to
wood, rock, concrete and tiled counter surfaces.
26-1/4”
23-11/16”
Mounting
Locations
26-9/16”
30"
20-5/8”
Affinity 30Ge Elite Cooktop
3-17/32”
1-3/16”
1-19/32”
The Affinity 30Ge
Elite Cooktop is
the ultimate social
cooking appliance
for any indoor
kitchen. The unique
style captures
attention, while the
highly functional
design encourages
participation, all to
the delight of your
onlooking audience
.
7-21/32”
8-15/32”
1-3/8”
7-3/8”
7-27/32”
(R18-7/16”)
24-7/8”
18-3/32”
5-1/32”
6-9/32”
27-17/32”
Removable Spillover Trays x2
36-5/32”
Page 8
the natural way to cookthe natural way to cook
®
®
Included With Your Evo
All Evo Indoor Elite Series appliances ship with utensils, cooking accessories, cleaning supplies, and a cookbook.
Get The Most From Your Evo
Visit our website at www.evoamerica.com and find what you need from recipes to cooking techniques and videos, all designed to
help you get the most from your Evo. To connect with other Evo home chefs and share your creations, link to our Facebook page
at www.facebook.com/evocooks. For all other questions, just give us a call or send us an email.
“ When we
build…let
it be such
work as our
descendants
will thank us
for.”
John Ruskin,
19th century
social thinker
and artist
PRODUCTS
Find information
on Evo cooking
appliances.
RECIPES
Search our recipe site
for appetizers, or a
main course.
Evo, Inc. | 8140 SW Nimbus Ave., Bldg 5 | Beaverton, Oregon 97008
Toll Free 866.626.1802 | P 503.626.1802 | F 503.213.5869 | [email protected] | www.evoamerica.com
Evo is protected under U.S. Patents 6,189,530, 6,488,022, and 7,926,417 and U.S. Patents Pending.
Evo is a registered trademark of Evo, Incorporated. © 2013. All rights reserved.
Evo Elite Series Grills are for residential use only.
SUPPORT
Visit us online, or call
toll-free 866.626.1802
or direct 503.626.1802.
Evo's circular cooking surface is manufactured from a solid piece of
steel that's slightly crowned and formed with a fl anged edge to trap heat.
Next we apply a black food-safe ceramic top layer and kiln fi re the
surface to 1600
Each surface is then oil-seasoned yielding a glossy, non-stick
cooking platform that rivals the world's fi nest cookware.
˚
F to give the steel added protection and integrity.
ACCESSORIES
Purchase Evo cooking
accessories and cleaning
supplies online.
CONTACT
Call toll-free 866.626.1802, or
direct 503.626.1802, or email at
[email protected].
MADE IN
AMERICA
Form BR-R-RE v2 06/2013
