OPERATION, MAINTENANCE

AND SAFETY INSTRUCTIONS

FOR EVERDURE PANEL CONVECTION HEATERS NPE1500W, NPE2000W & NPE2400W

HEAT LIVE RELAX

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT: Read the safety precautions of this booklet carefully before attempting to assemble, install, operate or

maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with instructions could result in personal injury and/or property damage. If you are unsure
about anything regarding your heater or these instructions, please contact Everdure on 1300 766 066 in
Australia or [phone] in New Zealand before operating your appliance.

1. Read all instructions carefully before using the panel convection heater.

2. Use this heater only as described in this manual. Any other use not recommended by the manufacturer
may cause fire, electrical shock, or injury to persons.

3. Remove the package and ensure that the heate r i s u n d a maged. In case of doubt do not use the h e a t e r a nd
contact Everdure Service. Do not let children play with any parts of the package.

4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.

5. Before you use the heater, check if the voltage marked on the rating label corresponds to the mains in your
home.

6. When first operated, a slight burning smell may be experienced. This is normal.

7. Avoid using extension cords as the extension cord may overheat and cause a risk of fire.

8. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Always use the control
panel or castor supports when moving the heater (when not wall mounted). Keep combustible materials such
as furniture, pillows, bedding, papers, clothes and curtains at least 1 meter from the front & top of the heater
and keep them at least 0.5 meters from the sides and rear. Do not cover.

9. Do not pull the power cord to disconnect with the power source. Always grasp the plug to pull it out.

10. Do not insert any objects into the heater as it may cause an electric shock or fire or damage to the heater. Do
not block or tamper with the heater in any manner while it is in operation. To prevent a possible fire, do not
block the air inlet or outlet in any manner. Do not place on soft surfaces, like a bed or long pile carpet, where
openings may become blocked.

11. Do not leave the heater unattended. Always unplug the heater when not in use. Always let the heater cool
down before moving or storing away.

12. The heater has hot parts inside. It must NOT be used in potentially dangerous locations such as flammable,
explosive, chemical-laden or wet atmospheres. This heater is intended for general indoor domestic use
ONLY.

13. This heater is not intended for use in wet or damp locations, such as a bathroom or any area containing a
bath, shower, wash basin or close to water or damp items. Never locate a heater where it may fall into a
bathtub or other water container. It must be positioned or installed so that the controls cannot be touched by
a person in a bath or shower. Do not immerse the power cord in any liquid (including water).

14. This heater is for use indoors only.

15. This heater includes an overheat protection safeguard that will turn the unit off should it overheat. If this
occurs, remove the plug from the mains socket & allow to cool for 45 minutes, at which point it can be
restarted. Check for the reason for the overheating, such as blocked vents, prior to starting up again.

16. Never install or use the heater directly below a wall socket.

17. When fixing on a wall, the heater must be level, securely fixed & at the correct height (check with local
authorities if unsure). There must be at least 150mm between it and any barrier/wall to the sides, bottom or
top to prevent overheating or damage.

18. Always use the heater with the castors supplied on level floors or attached to a wall with the supplied brackets.

WARNING: The Main Power Switch and the On/Off switch should not be used as the sole means of

disconnecting power. Always unplug the power cord before servicing or moving the unit.

WARNING: To avoid danger of electric shock, unplug from outlet when not in use and before cleaning. If the

supply cord is damaged, it must be replaced by a special cord or assembly available from an
authorized person. In order to avoid overheating, do not cover the heater. The heater must NOT
be located immediately below a socket outlet. Do not use the heater in the immediate
surrounding of a bath, shower or swimming pool.

HEAT LIVE RELAX

CONTROL FUNCTIONS

A1. POWER BUTTON
A2. INCREASE SETTING BUTTON
A3. DECREASE SETTING BUTTON
A4. LOW POWER (ECONOMY) BUTTON
A5. TIMER BUTTON
A6. FULL POWER BUTTON
A7. ANTI-FROST BUTTON
B1. NUMERIC DISPLAY
B2. LOW POWER INDICATOR
B3. HIGH POWER INDICATOR
B4. ANTI-FROST INDICATOR
B5. TIMER SET INDICATOR

GETTING STARTED

1. Carefully remove the heater from packaging and the carton, and unwind the cord to its full length.

2. Either fit the castors & place the heater onto a stable, flat and dry surface, or fit the mounting brackets to a stable
wall & hang from the wall in a dry position away from open or running water. See installation sections for
details.

3. Turn the heater off at the power switch (on the top right hand side of the unit). Plug the cord set into a
220-240V~A.C. 50Hz electrical outlet. Turn the power on at the electrical outlet.

4. Turn the heater on at the power switch (on the right hand side of the unit). Depending on the last setting, either
the numeric display will light up showing the previous temperature setting (the appliance will start to operate), or
the numeric display decimal point will light up (the appliance in stand-by mode). If in stand-by mode, press the
power button to start the appliance, and press again to put back to stand-by mode.

NOTE: Heater must have castors fitted or be attached to a wall before use.

FILTERS

The main filter can be fitted by pushing it into the slots mounted at the
bottom of the appliance. It is designed to stop hair and dust from entering
the appliance and collecting where it is hard to clean as well as removing
them from air circulation. Remover the filter and clean with a vacuum
cleaner periodically to keep the appliance working efficiently. NOTE:
Allowing dust & hair to build up can create a potential fire hazard. The

small filter inserts can be used to
disperse fragrance oils. Place one or
2 drops of the fragrance oil in each
filter insert, and place in the rear
corners of the main filter. Place the
main filter under the appliance as
described above. The heating effect and natural air convection will draw the
scent through the heater and help distribute it throughout the room. NOTE:
Do not overload the filter inserts with oils as they could be potentially
flammable.
