SKU # 1001093976
Model # ZE00802A
USE AND CARE GUIDE
NON-SUBMERSIBLE WATER TRANSFER PUMP
Questions, problems, missing parts? Before returning to the store call
Everbilt Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-844-241-5521
HOMEDEPOT.COM
Rev. 05/20/17
THANK YOU
We appreciate the trust and confidence you have placed in Everbilt through the purchase of this non-submersible sump pump. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Everbilt!
Table of Contents
Table of Contents .......................................................... 2
Performance .................................................................. 2
Safety Information ......................................................... 2
Warranty ......................................................................... 3
Pre-Installation .............................................................. 4
Installation ..................................................................... 5
Care and Cleaning ........................................................ 7
Troubleshooting ............................................................ 8
Performance
SKU HP
1001093976 1/10 360 318 264 198 132 42 ft.
0 ft. 10 ft. 20 ft. 30 ft. 40 ft.
GPH of Water @ Total Feet Of Lift
Safety Information
Max. Lift
DANGER: Do not pump flammable or explosive liquids
such as oil, gasoline, kerosene, ethanol, etc. Do not use in
the presence of flammable or explosive vapors. Using this
pump with or near flammable liquids can cause an
explosion or fire, resulting in property damage, serious
personal injury, and/or death.
DANGER: ALWAYS disconnect the power to the pump
before servicing.
DANGER: Do not touch the motor housing during
operation. The motor is designed to operate at high
temperatures. Do not disassemble the motor housing.
DANGER: Do not handle the pump or pump motor with
wet hands or when standing on a wet or damp surface, or
in water before disconnecting the power.
WARNING: Release all pressure and drain all water
from the system before servicing any component.
WARNING: Secure the discharge line before starting the
pump. An unsecured discharge line will whip, possibly
causing personal injury, and/or property damage.
WARNING: Extension cords may not deliver sufficient
voltage to the pump motor. Extension cords present a life
threatening safety hazard if the insulation becomes
damaged or the connection ends fall into water. We
recommend the pump be plugged directly into an outlet.
WARNING: Wear safety goggles at all times when
working with pumps.
WARNING: This unit is designed only for use on 115
volts (single phase),60 Hz, and is equipped with an
approved 3-conductor cord and 3-prong grounded plug. Do
not remove the ground pin under any circumstances. The
3-prong plug must be directly inserted into a properly
installed and grounded 3-prong, grounding-type
receptacle. Do not use this pump with a 2-prong wall
outlet. Replace the 2-prong outlet with a properly
grounded 3-prong receptacle (a GFCI outlet) installed in
accordance with the National Electrical Code and local
codes and ordinances. All wiring should be performed by a
qualified electrician.
WARNING: Protect the electrical cord from sharp
objects, hot surfaces, oil, and chemicals. Avoid kinking the
cord. Do not use damaged or worn cords.
WARNING: Failure to comply with the instruction and
designed operation of this unit may void the warranty.
ATTEMPTING TO USE ADAMAGED PUMP can result in
property damage, serious personal injury, and/or death.
WARNING: Ensure that the electrical circuit to the pump
is protected by a 5-amp minimum (15-amp max.) fuse or
circuit breaker.
CAUTION: Do not lift the pump by the power cord.
2 For Professional Technical Support call 1-844-241-5521
Safety Information (continued)
CAUTION: Know the pump and its applications,
limitations, and potential hazards.
CAUTION: Periodically inspect the pump and system
components to ensure the pump suction screen is free of
mud, sand, and debris. Disconnect the pump from the
power supply before inspecting.
CAUTION: Follow all local electrical and safety codes,
along with the National Electrical Code (NEC). In addition,
all Occupational Safety and Health Administration (OSHA)
guidelines must be followed.
IMPORTANT: The motor of this pump has a thermal
protector that will trip if the motor becomes too hot. The
protector will reset itself once the motor cools down and
an acceptable temperature has been reached. The pump
may start unexpectedly if it is plugged in.
Warranty
IMPORTANT: Ensure the electrical power source is
adequate for the requirements of the pump.
IMPORTANT: Before using the pump, check the hose
for holes or excess wear, which could cause leaks, and
ensure the hose is not kinked or making sharp angles. A
straight hose allows the pump to move the greatest
amount of water quickly, and also check that all hose
connections are tight to minimize leaks.
IMPORTANT: This pump is made of high-strength,
corrosion-resistant materials. It will provide trouble-free
service for a long time when properly installed,
maintained, and used. However, inadequate electrical
power to the pump, dirt, or debris may cause the pump to
fail. Please carefully read the manual and follow the
instructions regarding common pump problems and
remedies.
The manufacturer warrants the products to be free from defects in materials and workmanship for a period of one year from date of
purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If within one
year this product is found upon examination by the manufacturer to be defective in materials or workmanship, the manufacturer’s only
obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the
product has not been damaged through misuse, abuse, accident, modifications, alterations, neglect or mishandling. Your original receipt of
purchase is required to determine warranty eligibility.
The purchaser must pay all labor and shipping charges necessary to replace the product covered by this warranty.
This Limited Warranty does not cover products which have been damaged as a result of an accident, misuse, abuse, negligence, alteration,
improper installation or maintenance, or failure to operate in accordance with the instructions supplied with the products, or operational
failures caused by corrosion, rust, or other foreign materials in the system.
Requests for service under this warranty shall be made by returning the defective product to the manufacturer as soon as possible after the
discovery of any alleged defect. The manufacturer will subsequently take corrective action as promptly as reasonably possible.
The manufacturer does not warrant and especially disclaims any warranty, whether express or implied, of fitness for a particular purpose,
other than the warranty contained herein. This is the exclusive remedy and any liability for any and all indirect or consequential damages or
expenses whatsoever is excluded.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
For Professional Technical Support call 1-844-241-5521 or visit HOMEDEPOT.COM.
For warranty registration please go to www.gppumpsus.com
3 For Professional Technical Support call 1-844-241-5521
