Table of Contents .......................................................................2
Model
HP
GPH of Water @ Total Feet Of Lift
Max. Lift
0 ft
10 ft.
20 ft.
30 ft.
40 ft.
50 ft.
SPP15002
1 1/2
5300
5000
3920
3720
2700
1800
66
Performance ...............................................................................2
Warranty .....................................................................................2
Safety Information ......................................................................3
Pre-Installation ..........................................................................5
Installation ................................................................................. 6
Operation& Storage .................................................................. 10
Maintenance............................................................................. 11
Troubleshooting ....................................................................... 13
The manufacturer warrants the products to be free from defects in materials and workmanship for a period of one year from date of purchase. This
warranty applies only to the original consumer purchaser and only to products used in normal use and service. If within one year this product is found
upon examination by the manufacturer to be defective in materials or workmanship, the manufacturer’s only obligation, and your exclusive remedy,
is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse,
accident, modifications, alterations, neglect or mishandling. Your original receipt of purchase is required to determine warranty eligibility.
The purchaser must pay all labor and shipping charges necessary to replace the product covered by this warranty.
This Limited Warranty does not cover products which have been damaged as a result of an accident, misuse, abuse, negligence, alteration, improper
installation or maintenance, or failure to operate in accordance with the instructions supplied with the products, or operational failures caused by
corrosion, rust, or other foreign materials in the system.
Requests for service under this warranty shall be made by returning the defective product to the manufacturer as soon as possible after the discovery
of any alleged defect. The manufacturer will subsequently take corrective action as promptly as reasonably possible.
The manufacturer does not warrant and especially disclaims any warranty, whether express or implied, of fitness for a particular purpose, other than
the warranty contained herein. This is the exclusive remedy and any liability for any and all indirect or consequential damages or expenses
whatsoever is excluded.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
For Professional Technical Support call 1-844-241-5521 or visit HOMEDEPOT.COM.
2 For Professional Technical Support call 1-844-241-5521
：Risk of suction entrapment. Always turn off
all power to the pool pump before installing the cover or
working on any suction outlet.
This pump produces high levels of suction and creates a
strong vacuum at the main drain at the bottom of your pool or
spa. This suction is so strong that it can trap adults or
children under water if they come in close proximity to a pool
or spa drain or a loose or broken drain cover or grate.
Stay off the main drain and away from all suction outlets!
：Risk of hazardous pressure. Stand clear of
pump and filter during start-up. Pool and spa circulation
systems operate under high pressure. When any part of the
circulating system (i.e. locking ring, pump, filter, valves,
etc.) is serviced, air can enter the system and become
pressurized.
Pressurized air can cause the pump housing cover filter
lid and valves to violently separate which can result in
severe personal injury or death.
Filter tank lid and strainer cover must be properly
secured to prevent violent separation.
Stand clear of all circulation system equipment when
turning on or starting up pump.
Before servicing pool and spa equipment, make note of
the filter pressure. Be sure that all controls are set to
ensure the system cannot inadvertently start during
service. Turn off all power to the pump.
Place filter manual air relief valve in the open position
and wait for all pressure in the system to be relieved.
Before starting the system, fully open the manual air
relief valve and place all system valves in the “open”
position to allow water to flow freely from the pool and
spa back to the pool or spa. Stand clear of all pool and
spa equipment and start the pump.
Do not close filter manual air relief valve until all
pressure has been discharged from the valve and a
steady stream of water appears. Observe filter pressure
gauge and be sure it is not higher than the pre-service
condition.
：Risk of suction entrapment. The use of
unapproved covers or allowing use of the pool or spa when
covers are missing, cracked or broken can result in body or
limb entrapment, hair entanglement, body entrapment,
evisceration and/or death.
Limb Entrapment: When a limb is sucked or inserted
into an opening resulting in a mechanical bind or
swelling. This hazard is present when a drain cover is
missing, broken, loose, cracked or not properly secured.
Hair Entanglement: When the hair tangles or knots in
the drain cover, trapping the swimmer underwater. This
hazard is present when the flow rating of the cover is too
small for the pump or pumps.
Body Entrapment: When a portion of the body is held
against the drain cover trapping the swimmer
underwater. This hazard is present when the drain cover
is missing, broken or the cover flow rating is not high
enough for the pump or pumps.
Evisceration/Disembowelment: When a person sits on
an open pool (particularly a child wading pool) or spa
outlet and suction is applied directly to the intestines,
causing severe intestinal damage. This hazard is present
when the drain cover is missing, loose, cracked, or not
properly secured.
Mechanical Entrapment: When jewelry, swimsuit, hair
decorations, finger, toe or knuckle is caught in an
opening of an outlet or drain cover. This hazard is present
when the drain cover is missing, broken, loose, cracked,
or not properly secured.
NOTICE: All suction plumbing must be installed in
accordance with the latest national and local codes for
swimming pools, spas and hot tubs, including NSPI
standards and CPSC guidelines.
ALWAYS disconnect the power to the pump
before servicing.
：Risk of harm. A clearly labeled emergency
shut-off switch for the pool pump and spa jet pump must
be in an easily accessible, obvious place near the pool or
spa. Make sure bathers know where it is and how to use it in
case of emergency.
：Risk of harm. To reduce the risk of injury, do
not permit children to use this product unless they are
closely supervised at all times.
：Risk of hazardous pressure. Pool and spa
circulation systems operate under high pressure.
Incorrectly installed or tested equipment may fail, causing
severe injury or property damage. Read and follow
instructions in owner’s manual when installing and
operating equipment. Have a trained pool professional
perform all pressure tests.
Do not connect system to a high pressure or city water
system.
Use equipment only in a pool or spa installation.
Trapped air in system can cause explosion. BE SURE all
air is out of system before operating or testing
equipment. See hazardous pressure warning below. Do
not use compressed air to clean, test, or purge
equipment for winter.
：Risk of electric shock. Can shock, burn or kill.
Connect only to a branch circuit protected by a ground-fault
circuit-interrupter (GFCI). Contact a qualified electrician if
you cannot verify that the circuit is protected by a GFCI. This
unit must be connected only to a supply circuit that is
protected by a ground fault circuit-interrupter (GFCI). Such a
GFCI should be provided by the installer and should be tested
on a routine basis. To test the GFCI, push the test button. The
GFCI should interrupt power. Push the reset button. Power
should be restored. If the GFCI fails to operate in this manner,
the GFCI is defective. If the GFCI interrupts power to the
pump without the test button being pushed, a ground current
is flowing, indicating the possibility of an electric shock. Do
not use this pump. Disconnect the pump and have the
problem corrected by a qualified service representative
before using.
3 For Professional Technical Support call 1-844-241-5521
：All work must be performed by a qualified
pool professional, and must conform to all national, state,
and local codes.
Follow all local electrical and safety codes,
along with the National Electrical Code (NEC). In addition, all
Occupational Safety and Health Administration (OSHA)
guidelines must be followed.
：Risk of harm. Pumps improperly sized or
installed or used in applications other than for which the
pump was intended can result in severe personal injury or
death. These risks may include but not be limited to electric
shock, fire, flooding, suction entrapment or severe injury or
property damage caused by a structural failure of the pump
or other system component.
：To minimize the risk of injury due to
suction entrapment hazard:
Pools and spas should utilize a minimum of two drains
per pump.
A properly installed and secured ANSI/ASMEA112.19.8
approved anti-entrapment suction cover must be used
for each drain.
Each suction cover must be installed at least three (3’)
feet apart, as measured from the nearest point to nearest
point.
Regularly inspect all covers for cracks, damage and
advanced weathering.
If a cover becomes loose, cracked, damaged, broken or is
missing, close the pool or spa immediately, shut off the
pump, post a notice and keep the pool or spa closed until
an appropriate certified cover is properly installed.
Replace drain covers as necessary. Drain covers
deteriorate over time due to exposure to sunlight, pool
chemicals and weather.
Avoid getting hair, limbs or body in close proximity to any
suction cover, pool drain or outlet.
Disable suction outlets or reconfigure into return inlets.
：Install to provide drainage of compartment for
electrical components.
：These instructions contain information for a
variety of pump models and therefore some instructions
may not apply to a specific model. All models are intended
for use in swimming pool applications. The pump will
function correctly only if it is properly sized to the specific
application and properly installed.
：Electrical controls such as on/off switches,
timers, and control systems, etc. should be properly
installed to allow the operation (start-up, shut-down, or
servicing) of any pump or filter without requiring the user to
place any portion of his/her body over or near the pump
strainer lid or filter lid. Such installation should allow the
user to stand clear of the filter and pump during system
start-up, shut down or servicing of the system.
Never open the inside of the drive motor enclosure.
There is a capacitor bank that holds a 230 VAC charge
even when there is no power to the unit.
The pump is not submersible. The pump is designed for
use with chlorinated pools only. For use with other
applications, contact customer service.
The pump is capable of high flow rates; use caution
when installing and programming to limit pumps
performance potential with old or questionable
equipment.
This appliance is not intended for use by persons
(including children) of reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a
person responsible for their safety.
：Before pressure testing, make the
following safety checks:
Check all clamps, bolts, lids, and system accessories
before testing.
Release all air in system before testing.
Tighten pump trap lids to 30 ft. lbs. (4.1 kg-m) torque for
testing.
Water pressure for test must be less than 25 PSI (7.5
kg/cm2).
Water temperature for test must be less than 100° F
(38 ° C).
Limit test to 24 hours. After test, visually check system to
be sure it is ready for operation. Remove trap lid and
retighten hand tight only.
NOTICE: These testing parameters apply only to the models
described here in. For other equipment, consult the
manufacturer.
4 For Professional Technical Support call 1-844-241-5521
Phillips
Screwdriver
Flathead
Screwdriver
Wrench
Safety
Pipe wrench
Hacksaw
Tape Measure
Thread Tape
PVC glue
APPLICATION
This pump is for use with permanently installed pools and may also be used with hot tubs and spas if so marked. Do not use with storable pools. A
permanently installed pool is constructed in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool
is constructed so that it may be readily disassembled for storage and reassembled to its original integrity.
TOOLS REQUIRED
Goggles
5 For Professional Technical Support call 1-844-241-5521
Loading...
