ETS SM1-U, SM1-WBM Specsheet
Electronic Technical Services Inc.
211 Conchas SE
Albuquerque, NM 87123
PH 505-888-3923 FAX 505-888-3926
Website: www.etsnm.com
SM1-WP Weather Proof Microphone
Completely weather proof microphone for
hostile environments such as on board
ships, rooms that are washed down daily
with high pressure water, etc.
• Low noise MOSFET pre-amplifier.
• Adjustable gain.
• Line level unbalanced output.
• Limiter circuit selectable on/off.
• Easy cable run termination.
• Power: 12VDC @ 10mA.
Microphones
Caution
It is the responsibility of the installation company and end
user to comply with state and federal privacy laws regarding the use of audio surveillance equipment. If you are
unfamiliar with these laws, consult a qualified attorney. In
most cases, posting the provided warning label in plain
view is all that is required.
SM1-T Conference Table Microphone
The SM1-T is an omni-directional microphone
designed to sit on a table top. Built in weight
and 4 rubber feet help minimize unwanted
movement of the microphone.
• Low noise MOSFET pre-amplifier.
• Adjustable gain.
• Line level unbalanced output.
• Limiter circuit selectable on/off.
• Easy cable run termination.
• Power: 12VDC @ 10mA.
SM1-W Outdoor Microphone
Weather resistant omni-directional microphone.
Selectable on/off treble boost circuit enhances
time-lapse recordings. Mounts on single gang
“bell box”, gasket included.
• Low noise MOSFET pre-amplifier.
• Adjustable gain.
• Line level unbalanced output.
• Limiter circuit selectable on/off.
• Easy cable run termination.
• Power: 12VDC @ 10mA.
