Eton FR100 User Guide

www.etoncorp.com

OPERATION MANUAL

POWER FAILURE PLUG-IN RADIO,

LIGHT, AND CLOCK FOR EMERGENCY

& EVERYDAY USE

BLACKOUT BUDDY OPERATION MANUAL

NEED HELP? HERE’S HOW TO
CONTACT US:

• From the United States: [phone]

• From Canada: [phone]

• From Everywhere Else: [phone]

• Email: [e-mail]

• Internet: www.etoncorp.com

2

TABLE OF CONTENTS

CONTROL LOCATION .......................................................

1

CLOCK .............................................................................

2

AUTOMATIC POWER FAILURE LIGHT & RADIO

3

OPERATION ......................................................................

4

MANUAL LIGHT OPERATION ............................................

5

MANUAL RADIO OPERATION ...........................................

6

SERVICE INFORMATION ....................................................

7

ONE YEAR LIMITED WARRANTY ........................................

8

IMPORTANT SAFETY INSTRUCTIONS ........................................

page

4

6

6

7

7

8

9

12

3

1 CONTROL LOCATION

Antenna

1

Radio Alert/Off/On Switch

2

LED Light

3

Light Alert/Off Switch

4

AM/FM Switch

5

FM Antenna Socket

6

Tuning Knob

7

Volume Knob

8

Hour

9

Minute

10

Alarm On/Off

11

Alarm Set

12

Time Set

13

External Wire Antenna

14

BLACKOUT BUDDY OPERATION MANUAL

9 10 11 12 13

1

2

3

7

4

8

5

6

14

4

5

2 CLOCK

BLACKOUT BUDDY OPERATION MANUAL

Time Setting

• Hold HOUR button, press TIME SET button to set
the hour.

• Hold MINUTE button, press TIME SET button to set
the minute.

Alarm Setting

• Hold ALARM SET button, press HOUR button to set
the alarm hour.

• Hold ALARM SET button, press MINUTE button to
set the alarm minute.

Alarm ON/OFF Setting

• Hold ALARM SET button, press HOUR button to set
the alarm hour.

• Hold ALARM SET button, press MINUTE button to
set the alarm minute.

3 AUTOMATIC POWER FAILURE

LIGHT AND RADIO OPERATION

• Press the LIGHT switch to “Alert” mode. When AC
fails, the LED light turns on automatically. Press the
LIGHT switch to “Off” mode to turn off the light.

• Press the RADIO switch to “Alert” mode. When AC
fails, the radio activates automatically. Press the RADIO
switch to “Off” mode to turn off the radio.

6

• When AC is connected, press the RADIO switch to “On”
mode to turn on the radio. Press the RADIO switch to
“Off” mode to turn off the radio.

Note: LED light won’t turn on/off when AC is connected.

4 MANUAL LIGHT OPERATION

Press LIGHT switch to “Alert” mode to turn on the light.
Press LIGHT switch to “Off” mode to turn off the light.

5 MANUAL RADIO OPERATION

• Press RADIO switch to “Alert” or “On” mode to turn
on the radio. Press RADIO switch to “Off” mode to
turn off the radio.

• Adjust volume with VOLUME KNOB.

• Set BAND SWITCH to desired position.

• Select desired broadcasting station with TUNING KNOB.

Note: To obtain the best FM reception, pull up the
ANTENNA or plug in an EXTERNAL WIRE ANTENNA into
FM ANT SOCKET.

7

BLACKOUT BUDDY OPERATION MANUAL

5 PORTABLE RADIO OPERATION

Specifications:

Power:AC120V

Radio:

AM: 520 ~ 1710kHz
FM: 87.5 ~ 108MHz

continued

6 SERVICE INFORMATION

You may contact the Etón Service Department for additional
information:

[e-mail]

Contact us for a Return Authorization prior to shipping
your unit. Should you want to return your unit for service,
pack the receiver carefully using the original carton or
other suitable container. Write your return address clearly
on the shipping carton and on an enclosed cover letter
describing the service required, symptoms or problems.
Also, include your daytime telephone number and a copy
of your proof of purchase. The receiver will be serviced
under the terms of the Etón Limited Warranty and returned
to you.

8

7 ONE YEAR LIMITED WARRANTY

Etón warrants to the original purchaser this product shall be
free from defects in material or workmanship for one year
from the date of original purchase. During the warranty peri­od Etón or an authorized Etón service facility will provide,
free of charge, both parts and labor necessary to correct
defects in material and workmanship.At their option, Etón
may replace a defective unit.

1. Complete and send in the Warranty Registration Card

within ten (10) days of purchase.

2. Call Etón or the nearest authorized service facility, as

soon as possible after discovery of a possible defect.

Have ready:
(a) the model and serial number.
(b) the identity of the seller and the approximate date

of purchase.

(c) a detailed description of the problem, including

details on the electrical connection to associated
equipment and the list of such equipment.

3. Etón will issue a Return Authorization number and the

address to which the unit can be shipped. Ship the unit
in its original container or equivalent, fully insured and
shipping charges prepaid.

9

BLACKOUT BUDDY OPERATION MANUAL

7 ONE YEAR LIMITED WARRANTY

Correct maintenance, repair, and use are important to obtain
proper performance from this product. Therefore carefully
read the Instruction Manual. This warranty does not apply to
any defect that Etón determines is due to:

1. Improper maintenance or repair, including the installation

of parts or accessories that do not conform to the quality
and specification of the original parts.

2. Misuse, abuse, neglect or improper installation.

3. Accidental or intentional damage.

4. Battery leakage.

All implied warranties, if any, including warranties of mer­chantability and fitness for a particular purpose, terminate
one (1) year from the date of the original purchase.
The foregoing constitutes Etón entire obligation with respect
to this product, and the original purchaser shall have no
other remedy and no claim for incidental or consequential
damages, losses, or expenses.Some states do not allow limi­tations on how long an implied warranty lasts or do not
allow the exclusions or limitation of incidental or conse­quential damages, so the above limitation and exclusion
may not apply to you. This warranty give you specific legal
rights and you may also have other rights which vary from
state to state.

10

continued

For service information contact:

Etón Corporation

1015 Corporation Way
Palo Alto, CA 94303
U.S.A.

11

8 IMPORTANT SAFETY INSTRUCTIONS

1.

Read these instructions

2.

Keep these instructions

3.

Heed all warnings

4.

Follow all instructions

5.

Do not use this apparatus near water

6.

Clean only with dry cloth

7.

Do not block any ventilation openings. Install in
accordance with the manufacture’s instructions.

8.

Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

9.

Only use attachments/accessories specified by the
manufacture.

10.

Unplug this apparatus during lightning storms or when
unused for long periods of time.

11.

Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way,such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normal­ly, or has been dropped.

BLACKOUT BUDDY OPERATION MANUAL

WARNING: To reduce the risk of fire or shock hazard,
do not expose this product to rain or moisture.

CAUTION

RISK OF ELECTRIC

SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER OR BACK. NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.

The lightning symbol is intended to alert
you to the presence of uninsulated dan­gerous voltage within this product’s
enclosure that might be of sufficient
magnitude to constitute a risk of electric
shock. Do not open the product’s case.

The exclamation symbol is intended to
inform you that important operating and
maintenance instructions are included in
the literature accompanying this product.

12
