ESI IVX128 INSTALLATION INSTRUCTIONS

Appendix II: IVX 128 installer worksheets

Function 1: System parameters

Important:

Before programming, make sure you initialize the system!

F11 — Initialization

See page D.1 for details.

F12: Installer

Range: 2–8 digits. Default: 789.

F13: Administrator

Range: 2–8 digits. Default: 456.

F14 — Set time/date

F15 — System timing parameters

See page D.2 for details.

F151: Flash hook duration

Range: 2–20 (0.2–2.0 sec). Default: 15 (1.5 sec).

F152: Transfer/forward recall timer

Range: 1–9 rings. Default: 3.

F153: Hold/park recall timer

Range: 5–960. Default: 60.

F154: ACD exit timer

Range: 0,5–600 (0 = no limit). Default: 180.

F155: ACD wrap timer

Range: 0,5–600 (0 = no limit). Default: 0.

F156: Cell phone delay

Range: 0–50 (0.0–5.0 sec). Default: 10.

F16 — Recording alert tone

Options: Enabled, disabled. Default: Disabled.

F17 — System speed-dial

(Use the worksheet on the following page.)

F18 — Serial port baud rate

(SMDR port is fixed at 1200 baud.)

Maintenance port

Options:300, 1200, 2400, 4800, 9600, 19200, 38400. Default: 38400.

ESI (Estech Systems, Inc.) • 2601 Summit Ave., Plano, TX 75074 • 972 422-9700 • fax: [phone]-0116
e-mail: [e-mail] • Web: www.esi-estech.com Rev. C

Appendix II: IVX 128 installer worksheets

F17 — System speed dial

See page D.4 for details.

Loc. Name Number

600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625

(Use a blank sheet for additional speed dial numbers 626–699.)

Appendix II: IVX 128 installer worksheets

Function 2: CO lines

If the system has one or two DLC12 cards, also consult “Special settings: DLC12 (T1)-

Note:

related functions” at the end of this worksheet.

F21 — CO line programming

See page E.1 for details.

Mode: ____________ (day, night).

CO Line group Ring 1 Ring 3 Ring 5 Ring 9

Make copies of this sheet for additional lines.

Appendix II: IVX 128 installer worksheets

F22 — Access codes/toll restriction

See page E.4 for details.

F221: Centrex/ PBX access codes Line group 9

Default: 0.

Line group 8

Default: 0.

Line group 7

Default: Disabled.

F222: Toll restriction exception tables

Allow numbers:

Deny numbers:

F23 — CO line parameters

See page E.5 for details.

F231: Line receive volume

Range: 0- 12. Default: 10.

F232: Line disconnect

Range: 1-255. Default: 6.

F24 — Caller ID

See page E.5 for details.

Appendix II: IVX 128 installer worksheets

Options: Enabled, disabled. Default: Disabled.

Local – 7:

Local – 10:

Appendix II: IVX 128 installer worksheets

Function 3 : Extension programming

F31 — Extension definition and routing

See page F.1 for details.

Ext.

0

Make copies for additional extensions.

Typ e Name Line groups CF day CF night Pg zone Ext.

Operator

Appendix II: IVX 128 installer worksheets

F32 – Extension feature authorization

See page F.5 for details.

Ext.

Default

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Name

Call

wait DND

Y Y N Y N Y Y

AA

block Rec.

Ser.

ob.

Tol l

allow

System

speed dial

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Ser. ob. list:

Make copies of this sheet for additional extensions.

Appendix II: IVX 128 installer worksheets

F33 – Department programming

See page F.7 for details.
Dept. types: In Order, All, UCD, ACD, Pick-Up.

Dept.

ext.

Name

Typ e

CF day

290

Ext. List:

291

Ext. List:

292

Ext. List:

293

Ext. List:

294

Ext. List:

295

Ext. List:

296

Ext. List:

297

CF night

Ext. List:

298

Ext. List:

299

F35 – Extension button mapping

See page F.9 for button default based on the system configuration.

Appendix II: IVX 128 installer worksheets

Function 4 : Auto attendant programming

F41 – Auto attendant branch programming

See page G.1 for details.

ID11 ID12 ID13 ID14 ID15 ID16 ID17 ID18

ID 1

Appendix II: IVX 128 installer worksheets

F42 — Announce extension number

Options: Enabled, disabled. Default: Enabled

F43 — Automatic day/night tables

See page G.4 for details.

Program using 24-hour format

Note:

.

Example MON TUE WED THU FRI SAT SUN

0800 D

1200 N

1300 D

1730 N

Appendix II: IVX 128 installer worksheets

Function 5: Voice mail programming

See page H.1 for details.

F51 — Maximum message length

Message length.

Range 1–30 min. Default: 10

Record length.

Range 1–120 min. Default: 60

F52 — Message purge control

Range: 0–365 days (0 = no purge). Default: No purging.

New messages

Old messages

Group messages

Recordings messages

F53 — Guest / info mailboxes

See page H.2 for details.

Use form on following page to record entries.

Appendix II: IVX 128 installer worksheets

F53 — Guest/info mailboxes

Name Type CFWD Day * CFWD Night *

MB

Make copies for additional mailboxes.

CFWD Day and CFWD Night do not apply to guest mailboxes.

*

Appendix II: IVX 128 installer worksheets

F54 — Group mailboxes

See page H.3 for details.

501 502 503 504 505 506 507 508

Members

Members

509 510 511 512 513 514 515 516

Appendix II: IVX 128 installer worksheets

F55 — Message notification

See page H.4 for details.

F551: Station delivery options

Mailbox

Range Phone Up to 30 digits 0–500 0–99 10–1,440 None None
Range Pager Up to 30 digits 0–500 N/A 10–1,440

Default Phone None 30 3 60 None None
Default Pager None

Phone

Pager

Phone

Pager

Phone

Pager

Phone

Pager

Phone

Pager

Phone

Pager

Number Delay Attempts Interval Quiet on Quiet off

N/A 0

Phone

Pager

Phone

Pager

Phone

Pager

Make copies for additional mailboxes

F552: Delivery/paging parameters

See page H.5 for details.

CO line access

Range: 9,8,7. Default: 9.

Maximum lines

Range: 1–12. Default: 1.

Pager dialing pause

Range: 0–20. Default: 6.

Appendix II: IVX 128 installer worksheets

F56 — Cascade paging mailboxes

See page H.5 for details.

F561 — Cascade paging mailbox options

Mailbox 1st number Attempts 2nd number Attempts 3rd number

520
521
522
523
524
525
526
527
528
529

F562: Cascade paging parameters

See page H.6 for details.

Paging interval

Range: 10–1440. Default: 0.

F57 — Q & A mailboxes

Name

Mailbox

Default

490
491
492
493
494
495
496
497
498
499

CFWD

Day

CFWD
Night

ID9999

Appendix II: IVX 128 installer worksheets

Function 6: Recordings

See page I.1 for details.

F61 — Re-recordable prompts

Prompt

530 Busy
531 No answer
532 Hold
534 Q/Z
535 No names matched
537 End of recording
538 ACD queue
539 ACD hold
540 Holiday main greeting

Typ e Default Re-recorded

F62 — Record directory names

See page I.2 for details.

Extension

Recorded name Keys

F63 — Message-on hold-programming

See page I.3 for details.

F631 — MOH source

Range: 590–598. Default: 592

F633 — MOH volume

Range: 1–12. Default: 6

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

See pages K.1–K.10 for details.

F21 — CO line programming

Options: Analog CO line (1) , T1 CO line (2).
Default answer ring assignment for CO lines: ID1

F211 : Analog CO line programming

Mode: ____________ (day, night).

CO Line group Ring 1 Ring 3 Ring 5 Ring 9

Make copies of this sheet for additional lines.

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

F2121: T1 CO line programming

Trunk type emulation default: E&M DNIS/DID.

Circuit Line format Trunk emulation

Programming of E&M trunks

See pages K.1–K.10 for details.

Outgoing signal type

Default: Wink start.

Incoming signal type

Default: Wink start.

Trunk mode

Default: 2-way traffic.

Dial tone transmit

Default: Off.

Ringback transmission

Default: Off.

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

See pages K.1–K.10 for details.

Important: Ring assignments are used for loop, ground and plain E & M.

For E &M DID only, use the translation table (Function 224).

Mode: ____________ (day, night).

CO Line group Ring 1 Ring 3 Ring 5 Ring 9

Make copies of this sheet for additional lines.

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

See pages K.1–K.10 for details.

F2122: T1 frame format and line coding

Default: ESF/B8ZS.

F2123: Line build-out

Default: 1.

F2124: CSU emulation

Default: Off. (See page K.5 for further details.)

F22 — Access codes/toll restriction

F221: Centrex/ PBX access codes Line group 9

Default: 0.

Line group 8

Default: 0.

Line group 7*

Default: Disabled.

Line group 71

Default: Disabled.

Line group 72

Default: Disabled.

Line group 73

Default: Disabled.

Line group 74

Default: Disabled.

Line group 75

Default: Disabled.

Line group 76

Default: Disabled.

* Line group 7 is not available if you use any of line groups 71–76.

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

See pages K.1–K.10 for details.

F222: Toll restriction exception tables

Allow numbers:

Deny numbers:

F223 — Automatic route selection (ARS)

Enabled/disabled

Default: Disabled.

If enabled:

ARS table OCC Numbers

3
4
5
6
7
8
9

10

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

See pages K.1–K.10 for details.

F224 — DID and DNIS/ANI translation table

DID or DNIS/ANI digits Name Day translation Night translation

Exception

Make copies of this sheet for additional lines.

Appendix II: IVX 128 installer worksheets

Special settings: DLC12 (T1)-related functions

F23 — CO line parameters

See pages K.1–K.10 for details.

F231: Line receive volume

Range: 1- 12. Default: 10.

F232: Line disconnect

Range: 1-255. Default: 6.

F233: T1 line receive volume

Digital pad default: -2 db.

Circuit Vol ume

Circuit Vol ume

Circuit Vol ume

Circuit Vol ume
