Ericsson LG EBTMU User Manual

E-BTMU
Quick User Guide

E-BTMU

Quick User Guide

E-BTMU
Quick User Guide

1. Introduction

E-BTMU is the External Bluetooth module that can offer greater wireless mobility to LIP­8000E/IP8800E.
LIP-8012E/LIP-8024E/LIP-8040E and IP8820E/IP8830E/IP8840E support Handset or
Speakerphone capability for Mobile Calls or WiFi(VoIP) Calls on smart phone as well as
Bluetooth headset. They will support these features with an E-BTMU.

• Support Bluetooth Headset

• Linked with Smartphone via Bluetooth

• Select contact information on IP Phone via Phonebook profile

2. Checking the Items

Check if the following items are in the package.

E-BTMU RJ9 cable Screw

3. Installing E-BTMU

Before you install E-BTMU, it is important that you read the following note.
Note:

1. You can’t install E-BTMU if DSS is using. You can install only E-BTMU or DSS; don’t
using both E-BTMU and DSS.

2. You select L or S before E-BTMU installs. You select L if you connect to LIP phone
(LIP-8000E series), select S if you connect to SIP phone (IP8800E series).

1

E-BTMU
Quick User Guide

The following steps are how to install E-BTMU

1) First, connect the cable to Phone with pushing Connector by finger securely.

2) Screw up E-BTMU to Phone.

3) Connect the RJ9 cable between E-BTMU and a Headset port at the rear of Phone.

1

3

2

LED Indications

Indication Color Description

Bluetooth RED Bluetooth dongle is connected to IP phone
Smart phone BLUE Smart phone is connected to BT dongle
Headset BLUE Headset is connected to BT dongle

2
