Ericsson W2x User Manual

W2x Series

Fixed Wireless Terminals for WCDMA/HSDPA Mobile Networks

Technical Product Description

Contents

1 W2X SERIES OVERVIEW.........................................................5

1.1 INTRODUCTION ............................................................................5

1.2 ERICSSON W20/W21 - DATA TERMINAL .......................................5

1.3 ERICSSON W25 – DATA AND VOICE TERMINAL..............................6

1.4 ERICSSON W2X FEATURE SUMMARY ............................................6

2 HARDWARE ARCHITECTURE ................................................8

2.1 POWER SUPPLY...........................................................................8

2.1.1 Power Adapter...........................................................................8

2.1.2 Battery Backup (W25 only)........................................................8

2.2 UMTS/GSM RADIO INTERFACES .................................................8

2.2.1 UMTS.........................................................................................8

2.2.2 GPRS/EDGE..............................................................................8

2.2.3 HSDPA Throughput Rates.........................................................9

2.2.4 Data Transmission...................................................................10

2.2.5 Frequency Bands (W20)..........................................................11

2.2.6 Frequency Bands (W21/W25)..................................................12

2.2.7 Standard UMTS/GSM Antenna................................................12

2.2.8 UMTS/GSM Window Antenna .................................................12

2.2.9 UMTS/GSM Roof Antenna.......................................................12

2.2.10 SIM/USIM Interface..................................................................12

2.3 WIRELESS LAN (WLAN) INTERFACE ..........................................13

2.3.1 Wireless Radio Channels.........................................................13

2.3.2 Internal WLAN Antennas .........................................................13

2.4 USB INTERFACE ........................................................................14

2.5 ETHERNET INTERFACE ...............................................................14

2.5.1 Built-in LED indicators..............................................................14

2.6 TELEPHONY INTERFACE (W25)...................................................14

2.7 CONNECTORS............................................................................14

2.7.1 W20/W21 Connectors..............................................................14

2.7.2 W25 Connectors......................................................................15

2.8 LED INDICATORS .......................................................................15

2.8.1 W20/W21 LED Indicators.........................................................16

2.8.2 W25 LED Indicators.................................................................16

3 DATA FEATURES AND FUNCTION ......................................17

3.1 LAYER 2 FUNCTIONS..................................................................17

3.1.1 Bridging LAN and WLAN .........................................................17

3.1.2 WLAN Whitelist........................................................................17

3.2 INTERNET PROTOCOL SERVICES ................................................17

3.2.1 IP Forwarding...........................................................................17

3.2.2 DNS .........................................................................................17

3.2.3 DHCP Server...........................................................................17

3.2.4 SNTP .......................................................................................17

3.2.5 NAT..........................................................................................17

3.2.6 IP Quality of Service ................................................................18

3.2.7 UPnP........................................................................................18

3.2.8 VPN Pass-Through..................................................................18

3.2.9 PPP Clients..............................................................................18

2 221 02-FGB 101 327 Uen C - December 2006

3.2.10 SIP (W25 only).........................................................................18

3.3 USB SERVICES .........................................................................18

3.4 AUTHENTICATION.......................................................................19

4 TELEPHONY FEATURES (W25 ONLY).................................20

4.1 LINE INTERFACE ........................................................................20

4.1.1 Ringing Signal..........................................................................20

4.1.2 CLIP, CWI and Voice Mail Alert...............................................20

4.1.3 Hook Flash...............................................................................20

4.2 UMTS/GSM SUPPLEMENTARY SERVICES ..................................20

4.3 DIAL PROCESS ..........................................................................21

4.3.1 Dialed Number Modification.....................................................21

4.3.2 Local Call Prefix.......................................................................21

4.3.3 Fixed Number Dialing ..............................................................21

4.3.4 Fax Dialing...............................................................................21

4.3.5 Supplementary Services..........................................................21

4.4 DTMF TRANSMISSION ...............................................................22

4.5 EMERGENCY CALLS ...................................................................22

5 FAX SUPPORT (W25 ONLY)..................................................23

5.1 SIGNALING.................................................................................23

5.2 SECURITY.................................................................................. 23

5.3 MEDIA STREAM..........................................................................23

5.3.1 Jitter Buffer...............................................................................23

5.3.2 Echo Canceller.........................................................................23

5.3.3 QoS..........................................................................................23

6 WIRELESS LAN (WLAN)........................................................24

6.1 SSIDS.......................................................................................24

6.2 WIRELESS SECURITY ................................................................. 24

6.2.1 WEP.........................................................................................24

6.2.2 WPA / WPA2............................................................................24

6.2.3 Whitelist ...................................................................................24

7 CONFIGURATION AND MANAGEMENT...............................25

7.1 WEB USER INTERFACE...............................................................25

7.2 COMMAND LINE INTERFACE........................................................25

7.3 ACCESS CONTROL.....................................................................25

7.4 MANAGEMENT TOOLS ................................................................26

7.4.1 Software Update......................................................................26

7.4.2 System Log..............................................................................26

7.4.3 Fault Management...................................................................26

7.4.4 Security Management..............................................................27

7.4.5 TEMS Investigation Support....................................................27

8 SECURITY...............................................................................28

8.1 OPERATOR LOCK.......................................................................28

8.2 PIN LOCK..................................................................................28

8.3 MECHANICAL ANTI-THEFT KIT ....................................................28

9 REGULATORY APPROVALS ................................................29

9.1 ROHS DIRECTIVE ......................................................................29

9.2 WEEE MARKING .......................................................................29

9.3 SAR..........................................................................................29

221 02-FGB 101 327 Uen C – December 2006 3

9.4 ENVIRONMENTAL .......................................................................29

9.5 INTENDED USE ..........................................................................29

10 ACRONYMS AND ABBREVIATIONS.....................................30

4 221 02-FGB 101 327 Uen C - December 2006

1 W2x Series Overview

1.1 Introduction

The Ericsson Fixed Wireless Terminal (FWT) W2x product series is the base for Ericsson WCDMA/HSDPA FWTs. The W2x product series is based on a platform concept aiming at providing a set of differentiated terminals from well-defined technical platforms.

The W2x product series consist of different types of terminals. Currently there are three terminals in the W2x product series:

• Ericsson W20 – Data Terminal

- W20a for 850/1900 MHz frequency bands

- W20e for 2100 MHz frequency bands

• Ericsson W21 – Data Terminal

• Ericsson W25 – Data and Voice Terminal

With WCDMA/HSDPA WAN radio access capability the W2x products are well suited to provide broadband data access with data speeds similar to fixed line DSL services.

1.2 Ericsson W20/W21 - Data Terminal

The Ericsson W20/W21 provide data capabilities such as data access (e.g. Internet) in the respect that it allows multiple computers to be connected to the terminal using Ethernet or wireless LAN (WLAN).

Figure 1 - Overview of Interfaces for the Ericsson W20/W21

221 02-FGB 101 327 Uen C – December 2006 5

1.3 Ericsson W25 – Data and Voice Terminal

The Ericsson W25 data and voice terminal incorporates the same set of data features as the Ericsson W20/W21. Additionally, this model also includes voice and fax capabilities over standard analog telephone interfaces. A broad range of network services such as Prepaid Subscription, CLI (Calling Line Identification), Call Waiting, Call Barring, Call Forwarding, Multiparty Conference Calls are supported. WCDMS/HSDPA radio access is well suited for combined and efficient data and voice transmission over the mobile network.

Figure 2 - Overview of Interfaces for the Ericsson W25

1.4 Ericsson W2x Feature Summary

The main features of the Ericsson W2x terminals are:

• Multimode broadband WAN connectivity

WCDMA/HSDPA (850/1900/2100 MHz) as primary access and

GSM/GPRS/EDGE (850/900/1800/1900 MHz) as fall-back. Peak

download data rates 1.8 Mbps for Ericsson W20 and 3.6 Mbps for the Ericsson W21/W25. (The Ericsson W21/W25 is software upgradeable to 7.2 Mbps).

• Four ports Ethernet switch;

Routing, NAT, ALG, DHCP and DNS Server.

• Two USB 2.0 ports;

File and printer sharing.

6 221 02-FGB 101 327 Uen C - December 2006

• Wireless LAN Access Point; IEEE 802.11b/g (Wi-Fi)

• Wireless security;

WEP, WPA-PSK, WPA2-PSK, MAC Association Control.

• Analogue voice services (W25 only);

Via a telephony line interface with high speech quality.

• Analogue fax services (W25 only);

Using T.38 Fax over IP protocol.

• Local Administration;

Built-in web based configuration tool with wizard support.

• SW auto update

• Remote Management Capability

Via SSH

221 02-FGB 101 327 Uen C – December 2006 7

2 Hardware Architecture

2.1 Power Supply

The W2x terminals can be powered from:

• AC Mains via an external AC/DC power adapter (10-28 VDC)

• Battery backup (Ericsson W25).

2.1.1 Power Adapter

The provided power adapter has the following characteristics:

Input: 100-240V AC, 50-60 Hz, 3 pole AC inlet connector (IEC 320 power inlet). Output: 12 VDC. Power consumption: 7.0 W (typical) and 11.4 W (maximum) for Ericsson W20/21 and 9.0 W (typical) and 16.2 W (maximum) for Ericsson W25.

National power plugs are available for EU, UK, US and AU.

2.1.2 Battery Backup (W25 only)

The Ericsson W25 can be fitted with a rechargeable battery to provide redundancy in case of an AC Mains power failure. The battery is available as an accessory and is facilitated within the unit. Additionally there is an internal battery charger that can recharge the battery.

2.2 UMTS/GSM Radio Interfaces

The W2x terminals support UMTS and GSM/GPRS/EDGE radio interfaces where UMTS is the primary interface.

2.2.1 UMTS

The W2x terminals support UMTS 850/1900 MHz and 2100 MHz frequency bands.

The UMTS interface supports the following characteristics:

• WCDMA

• HSDPA Category 11 and 12 (W20)

• HSDPA Category 1-6 and 11 (W21/W25)

The Ericsson W21/W25 is software upgradeable to 7.2 Mbps which means support for HSDPA Category 7 and 8.

2.2.2 GPRS/EDGE

The W2x terminals support GSM/GPRS/EDGE 850/900/1800/1900 MHz frequency bands.

8 221 02-FGB 101 327 Uen C - December 2006

2.2.3 HSDPA Throughput Rates

The peak download speed is rated up to 1.8 Mbps for the Ericsson W20 and 3.6 Mbps for the Ericsson W21 and Ericsson W25. The peak up-link speed is 384 kbps. The rated HSDPA peak download speeds will eventually evolve up to 14.4 Mbps with enhanced radio performance (increased modulation and coding schemes) according to the table below (current W2x rated peak speeds highlighted):
