Ericsson S868 User Manual

Download

Table of Contents

General Information ..............................................2

Operators & Subscription 2, GSM 900/1800 Dual Band 2, SIM & PIN 2

Preparing Your Phone for Use................................3

The SIM Card 3, The Battery 4

Turning On the Phone ...........................................7

When No Network Name Is Displayed 7, To Turn Off the Phone 7, Initial

When No Network Name Is Displayed 7, To Turn Off the Phone 7, Initial Settings 7

Settings 7

Making and Receiving Calls...................................9

Emergency Calls9, Making Calls 9,Receiving a Call 10,Redialling a Num-

Emergency Calls9, Making Calls 9,Receiving a Call 10,Redialling a Number 10, Calling Someone Who Has Called You 11, Unanswered Calls 11,

ber 10, Calling Someone Who Has Called You 11, Unanswered Calls 11, Hiding or Showing Your Number 12

Hiding or Showing Your Number 12

During a Call.......................................................13

To Change the Earpiece Volume 13, To Mute the Microphone 13, To Use

To Change the Earpiece Volume 13, To Mute the Microphone 13, To Use the Display as a Scratch Pad 13, To Send Tone Signals 13

the Display as a Scratch Pad 13, To Send Tone Signals 13

The Menu System................................................14

Moving through the Menu System 14, Display Text and Symbols 14

The Phone Book ..................................................15

Before You Start 15, Entering Characters 15, Creating Your Personal

Before You Start 15, Entering Characters 15, Creating Your Personal Phone Book 16, Recalling a Phone Number 17, Keeping Your Phone Book

Phone Book 16, Recalling a Phone Number 17, Keeping Your Phone Book Up to Date 19, Copying Phone Numbers between Positions and Memo-

Up to Date 19, Copying Phone Numbers between Positions and Memories 20

ries 20

Sending and Receiving Text Messages ................21

Two Memories 21, Setting the Phone for Text Messaging 21, Composing

Two Memories 21, Setting the Phone for Text Messaging 21, Composing and Sending Messages 22, Reading a Message 23, Replying toa Message

and Sending Messages 22, Reading a Message 23, Replying toa Message 24, Erasing a Message 24, Storing a Received Message 24, Reading

24, Erasing a Message 24, Storing a Received Message 24, Reading Stored Messages 24, Calling a Phone Number in a Message 25, Fre-

Stored Messages 24, Calling a Phone Number in a Message 25, Frequently Used Messages 25

quently Used Messages 25

Not for Commercial Use

Networks ............................................................26

Search Mode 26, Selecting a Network 26, List of Preferred Networks 27

Security...............................................................29

The Card Lock 29, The Phone Lock 30, Call Barring 30, The Keypad Lock

The Card Lock 29, The Phone Lock 30, Call Barring 30, The Keypad Lock 31, Fixed Dialling 32

31, Fixed Dialling 32

Diverting Incoming Calls .....................................33

Activating a Call Divert 33, Diverting when the Data Menus are On 33,

Activating a Call Divert 33, Diverting when the Data Menus are On 33, Checking the Divert Status 34, Cancelling Call Diverts 34

Checking the Divert Status 34, Cancelling Call Diverts 34

Handling More than One Call...............................35

The Call Waiting Service 35, Receiving a Second Call 35, Receiving a

The Call Waiting Service 35, Receiving a Second Call 35, Receiving a Third Call 36, To Make a Second Call 36, Connecting Two Calls – Explicit

Third Call 36, To Make a Second Call 36, Connecting Two Calls – Explicit Call Transfer 36, Conference Calls 36

Call Transfer 36, Conference Calls 36

Handsfree Calling................................................38

Selecting Answering Mode 38, Other Handsfree-Related Settings 38

Personalizing Your Phone....................................39

Personal Settings 39, The Ring Signal Level 41, Time and Date 41

Data Menus.........................................................43

To Activate the Data Menus 43

Other Useful Features..........................................44

The Answering Service 44, The Call Time/Call Cost 45, The Two Line

The Answering Service 44, The Call Time/Call Cost 45, The Two Line Service 46, Calling Card or Credit Card Calls 47, Area Information 48,

Service 46, Calling Card or Credit Card Calls 47, Area Information 48, The Alarm 50, The Calculator 50

The Alarm 50, The Calculator 50

Guidelines for Safe and Efficient Use ...................51

Warranty Conditions............................................54

Ericsson Mobile Communications AB

PTO for The Menu System

The Menu SystemThe Menu System

Press… to…

move clockwise or anticlockwise

select a menu or function

go back one level in the menu system

go back to the standby menu

Last call Tot calls

Info

Speech Speech/FAX FAX/Speech FAX Data

Networks

Select net Search mode Edit list New search

call type

MENU Next

Divert

All calls On busy No reply Unreachable Cancel all Check all

***

Start here

ERICSSON

12:35

Phone book

Mail

Voice mail Read messages Send message Area info Area messages Set Voice Mail Missed calls

* These menus appear only when you have turned on the ‘Data menus’. ** This menu appears only if your network operator offers the Two Line

service (also called Alternate Line Service) and you have subscribed to it (see chapter ‘The Two Line Service’).

*** These menu functions are slightly different if you have selected a ‘Next

call type’ other than speech.

Name recall Position recall Store Edit Erase Erase all from phone

Copy all

Keylock

On?

Set alarm Set clock Set date

Not for Commercial Use

Clock mode Date mode

Copy Call card numbers Fixed numbers Answered calls Dialled numbers

Clock

Ring level

Calculator

(

QQQqqq

Ear volume

Ring type Edit melody Mail alert Keylock Key sound Light Min minder Call info

)

Answering mode Greeting Phone no Language Data menus Line1 tag Master reset

then Fax

Settings

Speech

Change to

LINE 2?

Access

Barring Call Waiting Unlock card Change PIN code Change PIN2 code Phone lock Phone lock Change code Call cards security Fixed dial

Ericsson Mobile Communications AB

The Phone, Keypad and Display

Volume keys

Antenna

Earpiece

Key Functions

YES, used to:

• make calls, answer incoming calls, put calls on hold and switch between calls.

• confirm selections and inputs.

• enter a selected menu.

ON/OFF and NO, used to:

• turn the phone on or off.

• end calls, reject incoming calls and cancel selections.

• back up one level in the menu system.

NAVIGATION KEY, press LEFT or

RIGHT (or press and hold) to

access and move through the menu system.

CLR (Clear), used to

• erase digitsfromthe display.

• mute the telephone.

• return to standby from the menu system.

Display

Indicator light

Navigation key

Keypad

Indicators in the Display

Not for Commercial Use

Microphone

Connector (for charger and other accessories)

Signal strength.

The more bars that are shown,

the higher the signal strength.

Battery meter.

The fuller the icon, the more

power there is.

The keypad is locked.

All incoming calls are diverted

to another number.

The ring signal is turned off.

Tt B

NUMERIC KEYS, used to enter

the digits 0–9 and toenter text. The 0 key also enters the international prefix(+)if held down.

STAR, used to:

• enter the*character.

• enter a pause character (p)if held down.

HASH, used to:

• enter the characters # or ¤.

• recall a phone number from the Phone Book.

VOLUME KEYS on the side of the

phone, used to:

• change the earpiece volume during a call.

• reject an incoming call, if pressed twice.

You have received a text message.

You havereceiveda voice mail.

The alarm is set.

The linecurrently selected. (Requires that you have the Two Line Service.)

Ericsson Mobile Communications AB

Congratulations…

…and thank you for choosing the S 868, a mobile phone specially suited for the demanding user of communication tools. Retaining the slim, streamlined size that has become associated with the Ericsson family of phones, the S 868 sets a new standard for others to follow.

Apart from its unique toughness and extraordinary sound quality, the S 868 supports Dual band operation, which extends the potential for efficient network usage. Especially if you frequently use your phone in urban areas or travel abroad.

Like the other phones from Ericsson, the S 868 is produced to meet the highest quality standards.

This guide introduces you to your S 868 and shows you how to get the most out of it. Before you start, please read the ‘Guidelines for Safe and Efficient Use’.

Please note that some of the functions and services described in this user’s guide are depending on your choice of network operator. Should you needadditional information onhow to use them, contact your operator.

Mobile Internet

When you are on the move and in need of communication and information, Mobile Internet is the answer.

Mobile Internet is a service supplied by Ericsson to facilitate easy communications and rapid information retrieval, wherever you are. It gives you access to on-line customer services, on-line user manuals, and useful information when you are out travelling. It allows you to download various communication software which will ensure youachieve optimum resultsfrom your Ericsson products.

If you run into any problems, there are help texts connected to the different Mobile Internet pages.

The Internet address to Mobile Internet is

http://mobile.ericsson.com/mobileinternet

To get access to the service you also need a user id and a password. The first time you log on, please use the following:

User Id: mobile Password: internet Note that you must change user id and password the

first time you log on to Mobile Internet.

Not for Commercial Use

Press to enter the menu system. See inside the cover. 1

Ericsson Mobile Communications AB

General Information

Operators & Subscription

To be able to use your phone, you need to have a subscription to a network. This is obtained from the network operator.

The services included in your subscription depend on your choiceof operator and/or subscription. Therefore, some of the services and functions described in this manual may not be accessible to you. If you want a complete list of the services included in your subscription, please contact your network operator.

GSM 900/1800 Dual Band

The Ericsson S 868 is a dual band phone, which means that you can use your phone in two different kinds of networks – the GSM 900 and the GSM 1800 (also called PCN or DCS 1800) systems.

The GSM 1800 system is practically the same as the GSM 900 system. The difference between the two is that they use different frequencies. GSM 900 uses 900 MHz frequency, whereas GSM 1800 uses 1800 MHz.

A dual band phone that combines the two standards can use both frequencies. This considerably increases

Not for Commercial Use

capacity in densely populated urban areas, and consequently improves the coverage offered by your network operator. It will also offer you enhanced international roaming, thanks to the additional networks now available when you are out travelling.

The switching between the two systems is done automatically and seamlessly, which means that you can use your phone without ever having to consider which

system is best at the time. This is taken care of by the networks. However, you should note that the functions offered and the network coverage differ depending on your choice of operator and/or subscription.

SIM & PIN

You will obtain a SIM (Subscriber Identity Module) card with your subscription. The SIM card contains a computer chip that keeps track of your phone number, the services you have ordered from your network operator and yourPhone Book information, among other things.

Your SIM card is supplied with a security code or PIN (Personal Identity Number), which you need in order to gain access to the network. Your PIN may also be required when you want to change settings in your phone. Furthermore, some operators may have services that require a second PIN, your PIN2. You will find your PIN (and PIN2) in the information from your operator.

Every time you turn on your phone, it prompts you to enter your PIN. If the PIN is entered incorrectly three times in a row, the SIM card will be blocked. If this happens you can unlock it by using your PUK (Personal Unblocking Key code), which you also get from your operator.

You shouldbe careful with your PIN, since it is your protection against unauthorized use of your phone and subscription.

2 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Preparing Your Phone for Use

The SIM Card

When you register as a subscriber with a network operator, you obtain a SIM card.

SIM cards come in two sizes. One is the size of a credit card, and the other is considerably smaller (about the size of a regular stamp). The S 868 uses the smaller card. Many operators deliver credit card sized SIM cards which have a perforated smaller card that you can take out easily.

Before you can use your phone, you must insert the SIM card into the phone.

To Insert the SIM Card

To insert the SIM card, remove the battery (if attached) and follow these steps:

Not for Commercial Use



Release the SIM card holder by sliding it in the direction of the arrow.



Open the holder.



Slide the SIM card into the holder. Make certain that the cut corner is top right.

Press to enter the menu system. See inside the cover. 3

Ericsson Mobile Communications AB

The Battery

To Attach the Battery to the Phone:

Not for Commercial Use

 Close the holder.

 Lock the holder by

pressing it down and sliding it in the direction of the arrow in the picture.

Your mobile phone comes with a nickel metal hydride (NiMH) battery. The battery is not charged when you buy your phone, but there may be enough power to turn on the phone. We recommend that you charge the battery before you use the phone.

Place the battery on the back of the phone.

  Press the battery upwards and against the

phone until it snaps into place.

To Remove the Battery

Make sure that the phone is turned off before removing the battery (see next chapter). Then:

 Press the catch on

the bottom of the battery.

 Lift the battery up

and away from the phone.

To Charge the Battery

Make sure that the battery is attached to the phone. Then:

 Connect the charger to the mains. (The box may

contain more than one mains plug. In this case, use the one that fits the wall socket.)

4 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

A green indicator on the charger lights up. If not, make sure you have put the plug into the charger correctly. (You may have to press hard.)

 Connect the clear plastic plug on the charger

cable to the charger. It is correctly inserted when it snaps into place.

The phone will automatically start charging the battery when you attach the charger. To indicate charging:

• the battery meter in the display is continuously filled and emptied.

• the indicator on top of the phone shows a steady red light (green, if the phone is turned on).

When the battery is fully charged, the battery meter in the display will show full and the indicator on top of the phone will show a steady green light.

Note! It is possible to usethe phone while the battery is being

charged. This will, however, increase the charging time.

To Disconnect the Charger

 Connect the other

end of the cable to the phone according to the picture. The flash symbol on the plug must face upwards. Note that you

Not for Commercial Use

may have to press hard.

When to Charge the Battery

The nickel metal hydride battery that comes with your phone can be charged whenever you wish without losing performance. This is not the case with the cheaper nickel cadmium type batteries, often sold as accessories from other suppliers. For optimal talk and standby time in the long run, we recommend that you only use Ericsson original batteries with your S 868.

To remind you that the battery will soon need to be charged or replaced with a charged one:

l Twist the plug con-

nected to the phone upwards and pull it out.

Press to enter the menu system. See inside the cover. 5

Ericsson Mobile Communications AB

• an alarm signal (a long beep) sounds and the message ‘Battery low’ appears for ten seconds in the display.

• the indicator light on top of the phone starts blinking red.

Note! If the phone is left turned on, the low battery alarm will

be repeated several times and, finally, the phone will turn itself off when the battery is no longer able to power it satisfactorily. It might be possible to turn the phone on again, but you will not be able to make or receive any calls. You should charge the battery or replace it with a charged one.

Not for Commercial Use

6 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Turning On the Phone

To turn on the phone:

 Press and hold down the NO (ON/OFF) key until

you hear a click. The display prompts you to

Enter

****

enter your PIN.

 Enter your PIN. The digits appear as stars in the

display. If you make a mistake while entering your PIN, erase the wrong digit by pressing the

CLR key.

 Press YES.

ERICSSON

12:35

If youenter your PINcorrectly, ‘ERICSSON’ willappear in the display. The phone will then search for a network.

Note! If your PIN is entered incorrectly three times in a row,

the SIM card will be blocked and you will have to unblock it using your PUK code. See chapter ‘Security’.

When a network is found, the phone beeps three times. The indicator light on top of the phone flashes green once every second and your network operator’s name (in most cases abbreviated) is shown in the display. If you have the charger connected, the indicator will show a steady green light instead of a flashing one.

You can now make and receive calls. This is called standby mode.

Not for Commercial Use

When No Network Name Is Displayed

If the message ‘Emergency calls only’ is displayed, you are within range of a network but you are not allowed to use it. However, in an emergency, you can call the international emergency number 112. See chapter ‘Making and Receiving Calls’.

If the message ‘No network’ is displayed, there is no network within range or the received signal is too weak. You have to move to obtain a sufficiently strong signal.

To Turn Off the Phone

l In standby mode, press and hold the NO

(ON/OFF) key until the display is turned off.

Initial Settings

The first time you turn on your S 868, you may want to change the default language and ring level settings, and set the clock.

Display Language

Most modern SIM cards automatically set the display language to the language of the country where you bought your SIM card. If this is not the case, the default language is English.

To change the display language:

 Press the navigation key LEFT or RIGHT until the

‘Settings’ menu appears.

 Press YES to enter the ‘Settings’ menu.  Press the navigation key to the LEFT until the

‘Language’ menu appears.

 Press YES to enter the ‘Language’ menu.  Press the navigation key until you find the

desired language.

 Press YES to select the language.

Settings

SETTINGS Language

(Auto)

LANGUAGE

English

Press to enter the menu system. See inside the cover. 7

Ericsson Mobile Communications AB

Clock

CLOCK

Set clock

(16:36)

SET CLOCK

(16:36)

11:45

Ring level

(

QQQqqq

 Press CLR to return to standby mode.

Note! If by accident you end up with your phone displaying a

language youdo not understand,you can returnto English by pressing

LEFT 0000 RIGHT at any time.

Setting the Time

The time is shown at the bottom of the display. When you buy your phone, the time is normally not set.

If you want to set the time:

 Press YES to save the setting.  Press CLR to return to standby mode.

Tip! Use the volume keys on the side of the phone to change

the ring level silently.

Note! If you have your S 868 connected to external equip-

ment (for example handsfree equipment or a vibrating call alert device), the ring signal level will be set for this situation separately. See ‘Personalizing Your Phone’ for more information.

 Press the navigation key LEFT until the ‘Clock’

menu appears.

 Press YES to enter the ‘Clock’ menu.  Press the navigation key RIGHT until the ‘Set

clock’ menu appears.

 Press YES to enter the ‘Set clock’ function.  Enter the correct time in hours and minutes and

press YES.

 Press CLR to return to standby mode.

Note! The time is by default presented in the 24-hour format.

If you prefer the 12-hour format, you can change the default setting.

For more information, see ‘Personalizing Your Phone’.

To Set the Ring Signal Level

Press the navigation key RIGHT.



The text ‘Ring level’ and a bar representing the

)

ring signal level appears in the display.

Not for Commercial Use

 Press YES to enter the ‘Ring level’ menu.  Use the navigation key to set the ring signal

level.

• Pressing

• Pressing The phone rings once with the actual setting as

you press the navigation key, except for the ‘Off’ and ‘Step’ settings.

RIGHT increases the volume. LEFT decreases the volume.

8 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Making and Receiving Calls

The instructions in this chapter assume that you have turned onyour phone andthat you are within range of a network.

Emergency Calls

To make an emergency call:

 If the phone is not on, turn it on by pressing the

NO key until you hear a click.

 Enter 112 (the international emergency

number).

 Press YES. The display shows ‘Emergency’.

Note! Some operators may require that a SIM card has been

inserted into the phone and, in some cases, that the PIN has been entered as well.

Making Calls

ERICSSON

012345678

4 28

12:47

Domestic Calls



Not for Commercial Use

 Press YES to make the call. The display shows

0:07

Enter the area code and phone number. The digits are shown in the display.

• If you need to erase a digit, press

• To erase all digits, press and hold the

until all digits have been erased.

‘Calling’, followed by ‘Connecting’.

• When the call is answered, a call time meter

in the display shows how long you have been on the phone in minutes and seconds.

• If nobody answers your call or you cannot get

through, press

CLR.

CLR key

NO. The number is stored in a

memory which makes it easy to repeat the call. (See ‘Redialling a Number’ below.)

• If the number is busy, you can redial it auto-

ERICSSON

Last 1:31

12:49

7 8

Tip! It is possible to check the duration of the call later on.

matically. (See ‘Redialling a Number” below.)

 When you want to end the call, press NO. The

Call Time meter shows the duration of the call for three seconds.

See ‘Other Useful Features’.

International calls

Press and hold the 0 key until ‘+’ is displayed.



The (+) will automatically be replaced by the international dialling prefix for the country you

ERICSSON

+4640123456

Note! When you are abroad, your phone will automatically

are calling from.

 Enter the country code, the area code (without

any leading zero) and the phone number.

 Press YES to make the call.

search for a network that you are allowed to use. Which networks you can use depends on the agreements your operator has signed with the operators in the country you are visiting. See chapter ‘Networks’.

Checking the first characters

If you have entered more characters thancan be seen in the display,the first characters will be replaced by the symbol. To check the first characters:

l press the navigation key

RIGHT.

Press to enter the menu system. See inside the cover. 9

Ericsson Mobile Communications AB

Receiving a Call

When you receive a call, the phone rings and the indica-

When you receive a call, the phone rings and the indicator light on top of the phone blinks green rapidly. The

tor light on top of the phone blinks green rapidly. The display shows ‘Answer?’.

display shows ‘Answer?’. If your subscription includes the Calling Line Identifica-

If your subscription includes the Calling Line Identification service and the caller’s network sends the number,

tion service and the caller’s network sends the number, you will see the caller’s number at the bottom of the

you will see the caller’s number at the bottom of the display. If the number is stored with a name in the

display. If the number is stored with a name in the phone book, the name will be shown in the display.

phone book, the name will be shown in the display.

Note! The phone must be turned on and within coverage of a

network before a call can be received.

To Answer the Call

Press YES.



  When the call is finished, press NO.

 When the call is finished, press NO.

Tip! To mute the ring signal when you receive a call, press

CLR.

To Reject the Call

There are two ways of rejecting the call:

NO key.

• Press the

• Press the volume key on the side of the phone

• Press the volume key on the side of the phone twice.

twice.

The caller will hear a busy tone if the caller’s network

The caller will hear a busy tone if the caller’s network supports this function. If ‘Divert on busy’ is activated,

supports this function. If ‘Divert on busy’ is activated, the incoming call is diverted to the number you have

the incoming call is diverted to the number you have specified (see ‘Diverting Incoming Calls’).

specified (see ‘Diverting Incoming Calls’).

Not for Commercial Use

Redialling a Number

Your S 868 conveniently lets you redial the last phone

Your S 868 conveniently lets you redial the last phone numbers you have called (15 or more, depending on

numbers you have called (15 or more, depending on your SIM card). It can also redial a number auto-

your SIM card). It can also redial a number automatically ifthe connection failed when you first called.

matically ifthe connection failed when you first called.

NO key.

To Redial Previously Called Numbers

Press YES. The display now shows the last di-



alled number.

LAST DIALLED

046998877

Note! If you want to clear the last dialled numbers memory,

alled number.

 Press the navigation key RIGHT or LEFT until the

number you want to call is shown on the

number you want to call is shown on the bottom row of the display.

bottom row of the display.

 Press YES to make the call.

do the following:

 Press the navigation key LEFT. The ‘Phone book’

menu appears.

 Press YES to enter the ‘Phone book’ menu.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT until the ‘Dialled

 Press the navigation key LEFT until the ‘Dialled

numbers’ function appears.

 Press YES to select the ‘Dialled numbers’ func-

tion.

 Press and hold the CLR key. The question ‘Erase

all?’ appears.

 Press YES to erase the last dialled numbers from

the memory.

 Press CLR to return to standby mode.

The Automatic Redialling Function

If the connection fails and the receiver’s network

If the connection fails and the receiver’s network supports it, the display shows ‘Retry?’ on the top row

supports it, the display shows ‘Retry?’ on the top row and the reason for the failure on the second row.

and the reason for the failure on the second row. To redial the number automatically:

To redial the number automatically:

l Press YES.

• The number will automatically be redialled

• The number will automatically be redialled until the call is answered, up to 10 times.

until the call is answered, up to 10 times.

• If you press any key or receive a call, the re-

• If you press any key or receive a call, the redialling will be interrupted.

dialling will be interrupted.

• If the redialling is successful, the phone will

• If the redialling is successful, the phone will beep and then you will hear a ring signal.

beep and then you will hear a ring signal.

If you do not want to retry, press NO.

10 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Calling Someone Who Has Called You

If you subscribe to the Calling Line Identification service, and the caller’s network sends the number, the numbers of the last ten answered calls are stored in the phone.

Phone book

ANSWERED 1

+1234567890

ANSWERED 1

+1234567890

Unanswered Calls

ERICSSON

Calls:2

13:52

To recall one of the last ten answered numbers:

 Press the navigation key to the LEFT. The ‘Phone

book’ menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT repeatedly until

the ‘Answered calls’ function appears.

 Press YES to select the ‘Answered calls’ function.  Press the navigation key until you find the

number you want.

 Press YES to make the call.

To clear the answered calls memory:

 Press the navigation key to the LEFT. The ‘Phone

book’ menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT repeatedly until

the ‘Answered calls’ function appears.

 Press YES to select the ‘Answered calls’ function.  Press CLR. The question ‘Erase all?’ appears.  Press YES.

Not for Commercial Use

If you have received calls but have been unable to

answer, the number of unanswered calls will be shown in the display until you press CLR.

Information about the ten last missed calls is saved in your phone’s memory, which makes it possible for you to check when the calls were received. If your subscription includes the Calling Line Identification service and

Mail

MISSED CALLS

13:25

0246193000

MISSED CALLS

14-07-97

Unidentified

the caller’s network sends the number, you can also find out who called.

To Find Out Who Called and When

Press the navigation key to the LEFT repeatedly



until the ‘Mail’ menu appears.

 Press YES to enter the ‘Mail’ menu.  Press the navigation key repeatedly until the

‘Missed calls’ function appears.

 Press YES to enter the ‘Missed calls’ function.  The last caller’s number (if your subscription in-

cludes the Calling Line Identification service) is now shown in the display together with the time (or date) when the call was received. If no information about the caller’s number was received, the display will show one of the following:

• ‘Unidentified’, which means that no information was available.

• ‘Restricted’, which means that the caller wanted to withhold the number.

 To see your other unanswered calls, press the

navigation key repeatedly.

 Press CLR to return to standby mode.

Note! If you check a missed call within 24 hours, the time of

the call is displayed. Otherwise, the time is replaced by the date. You can toggle between date and time by pressing

To Erase a Number from the Missed Calls Memory

When the information about the call is shown,



press

CLR.

 Press YES.

Press to enter the menu system. See inside the cover. 11

Ericsson Mobile Communications AB

Hiding or Showing Your Number

With most common subscriptions, the caller’s number is sentwhen a callis made. Thismeans that the receiver can see your phone number when you make a call. However, some operators offer subscriptions where your phone number is normally hidden.

If you want to change the setting for a particular call, this is possible provided the network you use supports it.

To Hide Your Phone Number for a Particular Call

Enter the phone number you wish to call.

Special

functions

SPECIAL FUNC

Hide Id

0246193000

Special

functions

SPECIAL FUNC

Send Id

0246193000

  Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.  Press the navigation key repeatedly until ‘Hide

Id’ appears.

 Press YES to make the call.

To Show Your Number for a Particular Call

Enter the phone number you wish to call.

  Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.

Not for Commercial Use

 Press the navigation key until ‘Send Id’ appears.

 Press YES to make the call.

12 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

During a Call

Your S 868 has several functions which you might find helpful while you are on the phone.

To Change the Earpiece Volume

If youwant to change the earpiece volume during a call: l Press the volume keys on the side of the phone

up or down.

• Pressing

See also ‘Personalizing Your Phone’.

UP increases the volume. DOWN decreases the volume.

To Mute the Microphone

Mute

13:52

To mute the microphone temporarily during a call:

 Press and hold the CLR key. ‘Mute’ is shown in

the display.

 To resume conversation, release the CLR key.

To Use the Display as a Scratch Pad

If youneed to writedown a phonenumber during acall,

Not for Commercial Use

you can use the Scratch Pad function in the S 868. To do this:

l Enter the number using the numeric keys. When you end the call, the number remains in the dis-

play. You can now call the number by pressing YES or save it in the Phone Book (see chapter ‘The Phone Book’).

Note! If you press any numeric key while on the phone, the

person on the other end of the line will hear a tone.

To Send Tone Signals

To use telephone banking services or control a phone answering machine, you need to use codes. These codes are sent as tone signals (also known as DTMF tones or touch tones).

To send tone signals/codes during a call: l Press the appropriate keys (0–9,*and #).

Tip! You can also save the code together with a number in

the Phone Book. See ‘Creating Your Personal Phone Book’ in the ‘Phone Book’ chapter on how to do this.

Note! If you send tone signals while on the phone, the person

on the other end of the line will hear the tones.

Press to enter the menu system. See inside the cover. 13

Ericsson Mobile Communications AB

The Menu System

The menu system of your S 868 allows you to control the phone’s functions and to customize it to suit your personal preferences.

Each menu contains a list of options; some of these have submenus with additional options.

To help you find your way around the menus, we recommend that you use the fold-out on the inside of the cover.

Moving through the Menu System

The menus are arranged in a continuous loop (see the fold-out), which you move through with the

NAVIGATION, YES, NO and CLR keys.

Press… to…

move clockwise or anticlockwise.

select a menu or a function.

go back one level in the menu system and/or leave a setting unchanged.

Not for Commercial Use

To select a menu or make a setting:

 Press the navigation key LEFT or RIGHT until you

 Press YES to enter the menu or to select the

 Press the navigation key to find the desired sub-

go back to the standby menu.

reach the desired menu or function.

function.

menu or to select a setting alternative.

 Press YES to enter the submenu or to confirm

the setting.

Note! If you enter the menu system, but do not press any keys

in 60 seconds, the phone will return to standby mode.

Tip! Instead of pressing the navigation key repeatedly, you

can press and hold it down until you reach the desired menu or submenu.

Display Text and Symbols

SETTINGS

Ear volume

(

QQQqq

When you move through the menu system, the follow-

ing hints can help you:

)

• Capital letters are used to indicate the menu or function selected.

• When

• Text in brackets indicates the current setting of

andRare displayed, there are more options you can scroll through with the navigation key.

the function that is shown in the display.

14 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

The Phone Book

The Phone Book in your S 868 lets you store and recall phone numbers. This means that the phone can store all your important numbers. You do not have to remember them or carry your address book around.

The Phone Book also keeps track of your last dialled numbers and,if you subscribeto the CallingLine Identification service, the last answered numbers. Convenient if you have to call someone back.

When you receive a call and the caller’s number is in the Phone Book, you will see the name in the display.

Before You Start

Before you start creating your personal Phone Book, there area few things you need to know. In this section, you will learn about the two different memories and how tostore the numbers with the international prefix.

We also recommend that you at this stage read the section about entering characters, even though you might need to go back to this when you follow the instructions later on.

Phone Book Memories

You can store your phone numbers in two different

Not for Commercial Use

memories:

• the card memory on the SIM card,

• the phone memory. Storing yournumbers in thecard memory allows you to

use the numbers stored on the SIM card even when you change phones, i.e. when you insert your SIM card into another phone.

On the other hand, by storing your numbers in the phone memory, they are always available to you on your phone, even if you change SIM cards.

The memory positions in the card memory are numbered from 1 onwards. The actual number of memory positionsavailable depends on your SIM card.

The phone memory can hold up to 99 phone numbers. The memory positions are labelled ¤1–¤99.

Note! In the ‘Phone book’ menu, press # to enter the ¤ charac-

ter. Outside the ‘Phone book’ menu, you must press and hold down # to enter the ¤ character.

International Numbers

STORE 11 John, office +4646123456

If you intend to use your phone both at home and abroad, you should store all phone numbers as international phone numbers, that is with the ‘+’ sign – which automatically will be replaced by the international dialling prefix for the country you are calling from – followed by the country code, then the area code and the phone number.

• To enter the (+) sign, press and hold 0.

• Omit any leading zero in the area code.

Entering Characters

In the phone book you can accompany any number you store with a name. To enter the characters in the name, follow the instructions below.

l Press the appropriate key, 1–9, 0 or #,

repeatedly until the desired character appears in the display.

Press to enter the menu system. See inside the cover. 15

Ericsson Mobile Communications AB

Press… to get… 1 Space-?!,.:“'()1 2 ABCЕДЖаЗ2Γ 3 DEFèÉ3∆Φ 4 GHIì4 5 JKL5Λ 6 MNOÑÖØò6 7 PQRSß7ΠΣ 8 TUVÜù8 9 WXYZ9 0 0+&@/$%£ΘΞΨΩ

# # For example:

• To enter an A, press 2 once.

• To enter a B, press 2 twice.

Tip! To enter a digit, you can press and hold the numeric

key. To enterthe second letter on the numeric keys directly,

press and hold the upper volume key and press the desired numeric key. To enter the third letter, press the lower volume key instead.

Note! If there is a pause of more than 60 seconds between

entering characters, the phone will return to the standby menu.

To Enter Small Letters

l Enter the letter, for example an ‘A’, and then

Not for Commercial Use

. An ‘a’ appears.

press Small letters now appear until you press

again.

Creating Your Personal Phone Book

To Store a Phone Number

From the ‘Phone book’ menu, select ‘Store’.

  Enter a name to accompany the phone number.

STORE 33 Name: John Doe Enter no: _

STORE 33 Name: John Doe

08111222

STORE ¤16 Name: John Doe

08111222

Tip! If you enter a number in the scratch pad during a call,

Use the numeric keys as described above.

 Press the navigation key RIGHT.  Enter the phone number.  You now have four options:

– To save the number in the card memory, in the

first empty position (displayed in the top righthand corner):

YES.

• Press

– To save the number in the card memory, in a

position you decide:

• Press the navigation key

position and then press

– To save the number in the phone memory, in

the first empty position:

• Press the navigation key

key twice and then press YES.

– To save the number in the phone memory, in a

position you decide:

• Press the navigation key

key once, enter the position and then press

YES.

you can store it in the Phone Book by selecting ‘Store’ from the‘Phone book’ menuwhile you have the number in the display.

RIGHT, enter the

YES.

RIGHT, press the #

To Check the First Characters

If youenter more characters than can be seen inthe display, the first characters will be replaced by thelsymbol. To check the first characters you have entered:

l press the navigation key

LEFT.

STORE 2

Used

Overwrite?

Overwrite Protection

If you try to store a phone number in a position which already contains a phone number, the message ‘Used Overwrite?’ appears in the display. You then have two options.

16 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

STORE 34 e: Bankbyphone

040556677p_

To store the number in a different position:

 Press NO.  Enter the new position number.  Press YES

To store the number in the selected position, thus erasing the old number:

l Press

YES.

When the Memories are Full

• If you try to store a phone number when all the positions in the card memory are full, a position number in the phone memory will be suggested on the top row of the display.

• If both memories are full, no position number will be suggested. If you still wish to store the phone number, you have to erase the old number by entering a position that is already occupied.

Recalling a Phone Number

To make a call with tone signal codes, proceed as described in ‘Making and Receiving Calls’. When you make the call, the phone dials the number, waits until the call is answered and then sends the code. If you inserted another pause and another code, it will pause again, send the next code and so on.

The Speed Dialling Facility

You can call the phone numbers that you store in the positions 1–9 in the card memory by entering the position number and then pressing YES. Therefore, you should save positions 1–9 for important numbers.

For example: If youwant to callJohn, whose number is stored in position 3 in the card memory:

 Enter the digit 3.

To Store a Number With a Tone Signal

 Press YES.

Code

To use telephone banking services or control a phone answering machine, you will need to use codes. These codes are sent as tone signals (also called DTMF tones or touch tones).

If you want to save the phone number in the Phone Book with the codes:

 Follow the instructions on how to store a phone

number until you enter the number.

Not for Commercial Use

 After entering the phone number, press and

hold the appears.

 Enter the code.  If needed, insert another pause, another code

and so on.

key until the pause character ‘p’

Emma Limetree

+464612345

 Continue following the instructions on how to

store a phone number.

To Recall a Phone Number Using the Name

From the ‘Phone book’ menu, select ‘Name



recall’.

 Enter the name you want to recall (or the first

letters of it) using the numeric keys as described above.

You do not have to enter the entire name; the first few letters will do. The phone matches the letters with existing names in its memory.

 Press YES.

(7)

The best match between the letters you entered

and the names in the Phone Book is displayed. You can also see the storage position in brackets.

Press to enter the menu system. See inside the cover. 17

Ericsson Mobile Communications AB

Tip! You can also enter the name directly after pressing

POSITION

RECALL

Position: 7

Emma Limetree

(7)

+464612345

Tip! You can also enter the position directly in the standby

 If the name displayed is not the one you want,

press the navigation key until you find the correct name and number.

 Press YES to make the call.

from the empty standby display.

LEFT

To Recall a Phone Number Using the Position

If you know the memory position where you have stored a certain phone number, you can recall the number using the position.

 From the ‘Phone book’ menu, select ‘Position

recall’.

 Enter the position where the number is stored.

• For a position in the card memory, simply

enter the number.

• For a position in the phone memory, press

and hold the # key until the ‘¤’ character appears and then enter the number.

 Press YES.

The name and phone number now appear in the

display.

 If you entered the wrong position number, press

the navigation key repeatedly until you find the phone number.

 To call the number, press YES.

Not for Commercial Use

display and then press the # key to recall the phone number. Do not forget the ‘¤’ before the position if the number is stored in the phone memory (to get the ‘¤’ character, press and hold the # key).

Hiding or Showing Your Number When Making a Call

If you want to change the setting for a particular call, this is possible provided the network you use supports it.

To hide your phone number for a particular call, when you recall a number from the Phone book:

 Recall the phone number, but press NO instead

of YES. The number is now shown in the standby dis-

play.

 Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.  Press the navigation key repeatedly until ‘Hide

Id’ appears.

 Press YES to make the call.

To show your number for a particular call, when you recall a number from the Phone book:

 Recall the phone number, but press NO instead

of YES. The number is now shown in the standby

display.

 Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.  Press the navigation key until ‘Send Id’ appears.  Press YES to make the call.

18 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Keeping Your Phone Book Up to Date

As the people you know change jobs, move, marry etc., you might want to change the names and numbers in your Phone Book, or perhaps delete some of the entries.

To Edit an Entry in the Phone Book

There aretwo ways of finding the Phone Book entry you wish to edit. You can use either the storage position or the name.

To edit the entry using the position:

EDIT

Find pos

Position: 7

EDIT 7 Emma Limetree_

+464612345

 From the ‘Phone book’ menu, select ‘Edit’.  Enter the position number for the entry you

wish to edit.

• For a position in the card memory, simply

enter the number.

• For a position in the phone memory, press

and hold the # key until the ‘¤’ character appears and then enter the number.

 To select the entry, press YES.

You will now see:

• the name (displayed on the middle row),

• the phone number (displayed on the bottom

row),

• the storage position (displayed on the top

row).

 To select the row you wish to edit, press the

navigation key RIGHT.

Not for Commercial Use

You will see the cursor on the right of the row you selected.

 Edit the row by using:

CLR key to erase,

• the

• the numeric keys to enter letters or digits,

• the navigation key to move the cursor left (or

right when it is positioned in a row).

EDIT

Find name

Name: Emma_

Note! You can also select ‘Erase’ from the ‘Phone book’ menu

 If needed, press the navigation key RIGHT to

select another row and continue editing.

 To save the changes, press YES.

To edit the entry using the name:

 From the ‘Phone book’ menu, select ‘Edit’.  Press the navigation key LEFT.

The display now shows ‘Find name’ in the middle row.

 Enter the name for the entry you wish to edit,

using the numeric keys. The more letters you enter, the better the match.

To select the entry, press

YES.

 You can now continue from number 4 above.

Erasing a Phone Number

To erase a phone number from the Phone Book:

 Recall the number using ‘Name recall’ or ‘Posi-

tion recall’.

 Press and hold CLR. The question ‘Erase?’

appears.

 To erase the number, press YES.

and then enter the storage position. If you want to erase all numbers from the phone

memory (not possible for the card memory),you can do this as follows:

 From the ‘Phone book’ menu, select ‘Erase all

from phone’.

 To erase all phone numbers from the phone

memory, press YES.

Press to enter the menu system. See inside the cover. 19

Ericsson Mobile Communications AB

Copying Phone Numbers between Positions and Memories

As you fill up the Phone Book memories, you might want to move entries from one memory to another or between positions in the memories.

To Copy All Numbers from Card

COPY ALL

CardrPhone

COPY CARD From start position: _

COPY ALL

PhonerCard

COPY PHONE From start position: ¤_

COPY

CardrPhone

Memory to Phone Memory

From the ‘Phone book’ menu, select ‘Copy all’.

  Scroll to ‘Card

Phone’ and press YES.

 Enter the number of the first position in the card

memory you wish to copy and press YES.

 Enter the number of the first position in the

phone memory you wish to copy to and press

YES.

 To start the copying, press YES.

To Copy All Numbers from Phone Memory to Card Memory

From the ‘Phone book’ menu, select ‘Copy all’.

  Scroll to ‘Phone

Card’ and press YES.

 Enter the number of the first position in the

phone memory you wish to copy and press YES.

 Enter the number of the first position in the card

memory you wish to copy to and press YES.

 To start the copying, press YES.

Not for Commercial Use

To Copy Numbers from Card Memory to Phone Memory One by One

From the ‘Phone book’ menu, select ‘Copy’.

  Scroll to ‘Card

Phone’ and press YES.

 Enter the number of the first position in the

card memory you wish to copy and press

YES.

Eric Woods

Copy to ¤7?

 Enter the number of the first position in the

phone memory you wish to copy to and press

YES.

 To start copying, press YES.

The starting position in the card memory is displayed and the next empty position in the phone memory is suggested.

 For every entry on the card, from the start posi-

tion onwards, press:

YES to copy.

•

NO to go to the next position in the card

• memory.

CLR to copy to another position in either the

• card or phone memory. Enter the number of the position and press YES.

• Navigation key between positions in the card memory.

To interrupt copying: l Press

CLR twice.

LEFT or RIGHT to move

To Copy Numbers from Phone Memory to Card Memory One by One

From the ‘Phone book’ menu, select ‘Copy’.

  Scroll to ‘Phone

To copy from the phone memory to the card memory use the

YES, NO and CLR keys as described above.

Card’ and press YES.

20 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Sending and Receiving Text Messages

A very convenient feature of your Ericsson S 868 is the Short Message Service (SMS). This allows you to send and receive text messages consisting of up to 160 characters.

Using the Short Message Service, you do not have to worry about whether the people you want to reach check their answering machinesor not. As soon as they turn on their phone, the message will be waiting for them.

Text messages can be received when the phone is in standby mode, during a call or when incoming calls are diverted to another phone number. If the recipient’s phone is turned off when a message is sent, a notifying message will be displayed soon after the phone is turned on.

Apart fromsending standard messages to phones, your Ericsson S 868 is also prepared for sending fax messages (group 3 and 4), X400 messages, e-mails and telexes, via the Short Message Service. Check with your network operator which message types you can use and how.

Note! The Short Message Service may not be available in all

networks.

Two Memories

Not for Commercial Use

The Messages Memory

If you do not want to read an incoming message at once, it is automatically stored in the Messages memory in the phone. This allows you to read it later on.

If there are any unread incoming messages in the messages memory, a letter icon ( left at the bottom of the display.

The Messages memory can hold up to 10 messages. When all memory positions are full, the oldest read message will be overwritten when a new message is received.

If the Messages memory becomes full with unread messages, new messages will automatically be stored in the SIM card memory. If the SIM card memory becomes full, the letter icon (

Messages remain in the Messages memory until you erase them (see ‘Erasing a Message,), until you insert a different SIM card, or until the telephone needs the memory space to store new messages

) will appear to the

) starts blinking.

The SIM Card Memory

If you receive an important message and want to make sure it is not erased from the messages memory, you can store it in a memory on your SIM card. This means that you can retrieve the message regardless of which phone you use. Messages that are saved in the SIM card memory remain there until you erase them.

If the SIM card memory becomes full, the letter icon (

) starts blinking.

Setting the Phone for Text Messaging

If the phone number to your network service centre cannot be retrieved from your SIM card, you must specify the number yourself. Otherwise you cannot

Press to enter the menu system. See inside the cover. 21

Ericsson Mobile Communications AB

Message

MESSAGE

Options

OPTIONS

Valid per

(1 day)

reply to received messages or send your own

MAIL Send

messages.

 From the ‘Mail’ menu, select ‘Send message’.  Scroll to ‘Options’ and press YES.

 Scroll to ‘Serv cent’ and press YES.  If there is no number in the display, enter the

number of the service centre, including the international prefix, and press YES.

 To return to standby mode, press CLR.

Your phone is now ready to send and receive text messages.

Note! Some network operators may only allow SMS to be sent

within their own network.

Setting Duration of Message

If your message cannot be delivered because the recipient is not within reach of a network, you can instruct your Service Centre to repeat the message for one hour, 12 hours, one day, one week or the maximum period (determined by your service provider).

SEND

 From the ‘Mail’ menu, select ‘Send message’.

‘New’ appears.

 Scroll to ‘Options’, using the navigation key, and

press YES.

 Select the ‘Valid per’ option and press YES.

 Scroll to the desired duration and press YES.

Changing Message Types

Not for Commercial Use

The phone is prepared for sending other types of messages. Your network operator’s Service Centre may offer the facility to convert a text message into a format (fax, telex, voice, etc.) that suits the equipment that is going to receive the message.

Consult your operator for further information about the formats you can use.

To set the message type:

 From the ‘Mail’ menu, select ‘Send message’.  Scroll to ‘Options’, using the navigation key, and

OPTIONS

Msg type

(Standard)

Note! Standard means an ordinary text message (SMS) to

press YES.

 Scroll to the ‘Msg type’ option and press YES.

 Select the required format, using the navigation

key, and press YES.

other phones. Standard is the default message type.

Composing and Sending Messages

To Enter Letters

In order to compose your message, you have to know how to enter characters using the numeric keys.

l Press the appropriate key, 1–9, 0 or #, repeat-

edly until the desired character appears in the display.

Press… to get… 1 Space-?!,.:“'()1 2 ABCЕДЖаЗ2Γ 3 DEFèÉ3∆Φ 4 GHIì4 5 JKL5Λ 6 MNOÑÖØò6 7 PQRSß7ΠΣ 8 TUVÜù8 9 WXYZ9 0 0+&@/$%£ΘΞΨΩ

# #

For example:

• To enter an A, press 2 once.

• To enter a B, press 2 twice.

Tip! To enter a digit, you can press and hold down the

numeric key.

22 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

MAIL Send

Message

Request

reply?

SEND

MESSAGES

Enter no:

To enter the second letter on the numeric keys directly, press and hold the upper volume key and press the desired numeric key. To enter the third letter, press the lower volume key instead.

To enter small letters: l Enter the letter, for example an ‘A’, and then

press*. An ‘a’ appears.

sym-

Reading a Message

4 28

Small letters will now appear until you press again.

If youenter more characters than can be seen inthe display, the first characters will be replaced by the bol. To check the first characters you have entered:

l Press the navigation key

the characters you want to view.

Note! If there is a pause of more than 120 seconds between

entering characters, the phone will return to the standby menu.

LEFT until you reach

Sending Messages

From the ‘Mail’ menu, select ‘Send message’.



‘New’ appears.

 Press YES. An empty display appears.  Enter your message. (See ‘To Enter Letters’).

You can scroll through the message text with the navigation key and erase characters to the left of the cursor or insert characters in the cursor’s position.

 When you have completed your message, press

Not for Commercial Use

YES. ‘Request reply?’ appears.

From:l456807

Note! The same procedure is usedwith all types of messages,

NewMessage

Read Now?

New

12:54

 If you want the recipient to reply to the

message, press YES. If not, press NO.

 Enter the recipient’s phone number or recall it

from the phone book. To access the ‘Phone

book’ menu press LEFT.

 You now have two options:

• To send the message now, press

YES.

• To store the message for later use, press The message is now stored in the messages memory.

If you decide to send the message later, the message is labelled ‘To Send’ instead of ‘Sent’ when you access the message in the ‘Read messages’ menu.

for example e-mail, fax etc. Check with your network operator which message types you can use.

When you receive a message, you hear a sound and the display informs you of it. The indicator light on the top of the phone rapidly blinks green.

You now have two options:

• If you want to read the message at once, press .

• If you want to read the message later on, press

NO. The message will be stored in the Messages

memory and a letter icon (Mm) will appear on the left at the bottom of the standby display.

If you pressed the message, showing you who the message is from and when it was received. ‘New’ stands for a new unread message.

If the message is older than 24 hours, the time will be replaced with the date the message arrived. However, you can toggle between the date and time by pressing the

key.

• To read the first line of the message, press

• Scroll through the message using the navigation key.

RIGHT takes you forwards and LEFT takes you

backwards through the message.

• To move three lines forwards, press 3. To move three lines backwards, press 1.

NO.

YES

YES, you will see the first three lines of

YES.

Press to enter the menu system. See inside the cover. 23

Ericsson Mobile Communications AB

Goodbye!

Reply?

• To return to the beginning of the message, press and hold

The message ‘Reply?’ appears after the last line of the message. If the caller wants you to reply, the displayed message will say ‘Reply Requested Reply?’, provided your network supports this.

LEFT.

Replying to a Message

When you are reading a message, at the end you are asked if you want to reply to the message. If you want to do this:

l Press

New

If you do not want to reply: l Press NO.

YES.

Your display now looks like the picture in the margin.

• To enter your message, press

proceed as described in ‘Composing and Sending Messages’.

Erasing a Message

When you are reading a message, at the end you are asked if you want to reply to the message.

Goodbye!

Erase?

 Press NO.

The message ‘Erase?’ appears.

 To erase the message from the Messages

Not for Commercial Use

memory, press YES. The next message automatically appears in the

message list.

Note! You can press

handles your message to erase it. When ‘Erase?’ appears, press YES.

CLR anywhere within the menu that

YES and

Storing a Received Message

All incoming messages are stored temporarily in the messages memory until the memory space is needed for other purposes, such as storing new messages. Even so, sometimes you may receive an important message that you want to store more safely. This is better done in the SIM card memory.

When reading the message and the question ‘Erase?’ appears:

 Press NO.

The message ‘Store?’ appears.

 To store the message in the SIM card memory,

press YES. The message is automatically moved from the Messages memory to the SIM card memory.

The display now shows the position of the message. For example, if it is the third of five that the phone can store.

appears. In this case you will have to erase one or more messages, before you can store any new messages in the SIM card memory.

self on the SIM card. See the section ‘Sending Messages’ above.

Goodbye!

Store?

Stored

On card

3(5)

Note! If the card memory is full, the text ‘Not stored Mem full’

Tip! You can also store messages you have composed your-

Reading Stored Messages

messages

MAIL Read

 From the ‘Mail’ menu, select ‘Read messages’.  Scroll with the navigation key until you find the

message you are looking for.

• ‘New’ stands for a new unread message.

• ‘Old’ stands for a read message.

• ‘Sent’ stands for a sent message.

24 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

• ‘To Send’ stands for a composed, but not sent

message.

 Press YES.  Read the message as described in ‘Reading a

Message’.

Note! If there is a

is stored on the SIM card.

in front of the message, this means that it

Calling a Phone Number in a Message

To call a phone number found in a message: l Press

After the number has been called, the message is considered read and it remains in the Messages memory.

YES.

Frequently Used Messages

If you have one or more standard messages you use often, you can store them on the SIM card, to be reused whenever you want.

Storing Frequently Used Messages

To make sure your standard messages are not erased when the messages memory becomes full, you should store them in the SIM card memory. To do this:

 From the ‘Mail’ menu, select ‘Read messages’.

The messages saved in your Messages memory appear.

Not for Commercial Use

 Scroll to the message you wish to store in the

SIM card memory, using the navigation key, and press YES.

 Press YES again. ‘Erase?’ appears .  Press NO. ‘Store?’ appears.  Press YES. The message is now moved from the

phone memory to the SIM card memory.

SEND

MESSAGE

Enter no:

Sending Stored Messages

From the ‘Mail’ menu, select ‘Send message’.



‘New’ appears.

 Scroll to the message you wish to send, using

the navigation key, and press edit your message, if you wish.

YES. Now you can

 When the message is ready to be sent, press

YES. ‘Request reply?’ appears.

 If you want the recipient to reply to the

message, press YES. If not, press NO .

 Enter the recipient’s phone number or recall it

from the phone book. To access the ‘Phone book’ menu, press LEFT.

 To send the message now, press YES.

Press to enter the menu system. See inside the cover. 25

Ericsson Mobile Communications AB

Networks

When you turn on the phone, it searches for the last accessed network. If this is not within range, you may use another network, provided your home network has an agreement thatallows you to do so. This is called roam- ing.

The ‘Networks’ menu includes a number of functions which you can use to determine how the phone searches for a network. You may also select a network yourself from those within range.

Search Mode

Automatic Search Mode

The automatic search mode means that when you turn on your phone, it searches for the last accessed network. If this is not available, the phone will automatically search for another available network within range.

The Automatic search mode is normally the default setting when you buy your phone. However, if you need to activate the automatic search mode, do the

NETWORKS

Searchmode

(Auto)

following:

 Scroll to the ‘Networks’ menu, using the naviga-

Not for Commercial Use

 Scroll to ‘Searchmode’.

 Scroll to ‘Auto’ and press YES. The phone is now

 To return to standby mode, press CLR.

tion key, and press YES.

• If ‘(Auto)’ is visible on the bottom row of the

display, your phone is already set to Automatic search mode.

• If ‘(Auto)’ is not visible, press

set to Automatic search mode.

YES.

Note! The order of preference in which the phone selects a

network is determined by a list of preferred networks on your SIM card, which you can edit at any time.

Manual Search Mode

The manual search mode means that when you turn on your phone, it searches for the last accessed network . If this is not available, the question‘Select network?’ appears.

To activatethe manual search mode, do the following:

 From the ‘Networks’ menu, select ‘Searchmode’

and press YES.

 Scroll to ‘Manual’ and press YES.  To return to standby mode, press CLR.

To select a network, see below.

Selecting a Network

NETWORKS

Select net

 From the ‘Networks’ menu, choose ‘Select net’.

The message ‘Please wait’ is displayed briefly.

If there is more than one network within range, you can use the navigation key to scroll to the other network(s).

 When the network you wish to use is displayed,

press YES to select it.

Note! Together with the network name, you also get the

following information in the display:

• If the home network is within range and you are using it when you start your network selection, the name of the network is displayed with the message ‘Current’.

26 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

NETWORKS

New Search

• If you are using another network and your home network is available, the name of the home network is displayed with the message ‘Home’.

• Instead of the full name of a country and a network, an abbreviation is displayed when you use the ‘Networks’ menu. To see the full name of a network, press

• If the home network is not within range, the name of another network is displayed with the message ‘Current’, ‘Preferred’, ‘Available’ or ‘Forbidden’.

– ‘Current’ means that the network is currently

being used.

– ‘Preferred’ means that the name of the network is

included in a list of preferred networks on your SIM card.

– ‘Forbidden’ means that the name of the network

is included in a list of forbidden networks onyour SIM card and that you are not allowed to use it. You can, however, make emergency calls.

– ‘Available’ means that there is a network within

range, which is not on either the forbidden or preferred list on your SIM card.

• If there is no network within range, the message ‘No network’ is displayed.

List of Preferred Networks

NETWORKS

Edit list

To Start an Automatic Network Search

An automatic network search can be started at any time.

l From the ‘Networks’ menu, select ‘New search’.

The phone automatically starts searching for a network

Not for Commercial Use

according to the list of preferred networks stored on your SIM card.

Forbidden Networks

The names of the forbidden networks are stored on your SIM card. If such a forbidden network is within range, it will be omitted when the phone searches for a network (automatic search mode).

EDIT LIST

AA1

If your home network and a forbidden network come to an agreement that allows you to use the forbidden network, you can select this network even though the message ‘Forbidden’ is displayed.

You can create a list that defines in which order your phone will select a network during automatic network selection, whenyour home network is not within range.

The number of networks that can be stored in the list depends on your SIM card.

The ‘Edit list’ function lets you review the networks in the list. Apart from rearranging the order of the networks, you can add new networks to the list and delete networks from it.

Reviewing the List of Networks

From the ‘Networks’ menu, select ‘Edit list’.



• The message ‘Please wait’ is displayed briefly.

• The name of the first network is displayed. If a network is within range, a played.

 You can scroll through the other networks in the

list by using the navigation key.

Note! To see a network’s full name, press

Adding a Network to the List:

From the ‘Networks’ menu, select ‘Edit list’.

  Scroll to the first free position in the list and

press YES. The question ‘Add net?’ appears.

If you scroll to a position that is already occupied, you must press the navigation key until ‘Add net?’ appears.

 Press YES and scroll with the navigation key

until you find the desired network.

is also dis-

YES and then scroll with

Press to enter the menu system. See inside the cover. 27

Ericsson Mobile Communications AB

EDIT LIST

AA1

Erase?

EDIT LIST

AA1

Move?

If the desired network does not appear, press

YES when the question ‘Other?’ appears. Then

enter the three-digit country number and the two-digit network number.

 Finally, to add the network to the list, press YES.

Erasing a Network from the List

From the ‘Networks’ menu, select ‘Edit list’.

  Scroll to the network you wish to erase and

press YES.

 Scroll until ‘Erase’ appears.  To delete the network from the list, press YES.

Rearranging the List

From the ‘Networks’ menu, select ‘Edit list’.

  Scroll to the network you wish to move and

press YES.

 ’Move’ is displayed. Press YES and enter the new

position within the list.

Not for Commercial Use

28 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Security

The Card Lock

Your SIMcard is protected by acard lock. When you buy your SIM card, you obtain a PIN (Personal Identity Number).

Every time you turn the phone on, you have to enter your PIN and then press feature off (see below).

If you enter your PIN incorrectly three times in a row, the SIM card will be blocked. This is indicated by the message ‘Card blocked Unblock?’. If this happens, see ’If Your SIM Card Is Blocked’ below.

Note! If your PIN starts with the same digits as the inter-

national emergency number 112, they will appear in the display, when you enter your PIN.

To Change Your PIN

From the ‘Access’ menu, select ‘Change PIN



code’.

 Enter your old (current) PIN and press YES.  Enter your new PIN and press YES.  At the prompt ‘Repeat new PIN’, enter your new

PIN a second time and press YES.

Not for Commercial Use

The message ‘New PIN’ confirms that the PIN has been changed.

Note! If the message ‘Matching error’ appears, this means you

entered the new PIN incorrectly. If the message ‘Wrong PIN’ appears, followed by ‘Enter Old PIN’, you entered your old PIN incorrectly.

YES, unless you turn this

To Change Your PIN2

Depending on the network you use, some services require that you enter a second PIN, the PIN2.

l Select ‘Change PIN2 code’ from the ‘Access’

menu.

Follow the same procedure as described in ‘To Change Your PIN’ above.

To Lock the SIM Card

Select ‘Lock card’ from the ‘Access’ menu.

  Press YES.  Enter your PIN and press YES.

The message ‘Locked’ confirms that the card lock is now activated.

To Unlock the SIM Card

Select ‘Unlock card’ from the ‘Access’ menu.

  Press YES.  Enter your PIN and press YES.

The message ‘Unlocked’ confirms that the card lock is now deactivated.

Note! This function only applies if your SIM card allows you to

deactivate the card lock.

If Your SIM Card is Blocked

To unblock the SIM card if you have entered the wrong PIN (or PIN2) three times in a row:

 Press YES.  Enter your PUK (or PUK2) (which you will find in

the information from your network operator).

Press to enter the menu system. See inside the cover. 29

Ericsson Mobile Communications AB

 Enter a new four- to eight-digit PIN (or PIN2).  Press YES.  Re-enter the new PIN (or PIN2) to confirm it.  Press YES.

Warning! If you enter the wrong PUK ten times in succession,

your card will be permanently blocked. If this happens, you will have to contact your network operator.

The Phone Lock

The phone lock protects the phone against unauthorized use in the event of theft. It is not activated when you buy the phone. You should, however, activate it as soon as possible. You should also change the default security code 0000 to any three- to eight-digit personalized code.

There are two levels of locking the phone:

• Full Lock

• Autolock If the ‘Full Lock’ is activated, you see the message

‘Phone locked’ briefly, each time you turn on the phone. The message is followed by the prompt ‘Enter lock code’. You then have to enter a security code and press

YES to be able to use the phone.

If the ‘Autolock’ is activated, the message ‘Phone locked’ and the prompt ‘Enter lock code’ will not appear until a different SIM card is inserted in the phone. After the security code has been entered correctly, the phone

Not for Commercial Use

can be used with a new SIM card. You are not asked to enter the security code until the original SIM card or a different SIM card is inserted.

To Change the Security Code

l From the ‘Access’ menu, select ‘Phone lock

Change code’ and follow the steps described in ‘To Change Your PIN’.

To Lock/Unlock the Phone



 Select the required setting.  Enter the security code and press YES.

Call Barring

The ‘Call Barring’ service of the cellular network allows you to bar different types of outgoing and incoming calls. This means you can restrict the use of your phone.

Note! This service may not be available on all networks or

may require a separate subscription. The following calls can be barred:

• all outgoing calls,

• all outgoing international calls,

• all outgoing international calls except to your

• all incoming calls,

• all incoming calls when you are abroad (when

To ensure that a call bar is not changed by someone else, a password, which comes with your subscription, is necessary in order to activate or cancel a call bar.

To Change the Call Barring Status



 Scroll to the option you want, using the naviga-

From the ‘Access’ menu, select ‘Phone lock’. The current setting ‘Full lock’, ‘Autolock’ or

‘Unlocked’ is shown in brackets.

‘Phone Lock’ is displayed together with the new setting.

home country,

roaming).

From the ‘Access’ menu, select ‘Barring’. The first barring option is ‘All outgoing calls’. To

choose another barring option, use the navigation key.

tion key, and press YES.

30 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

 You now have three options:

• ‘Activate’, which sets a call bar,

• ‘Get status’, which lets you check the status of a call bar,

• ‘Cancel’, which cancels the call bar.

Confirm your selection by pressing

YES.

 Enter your password and press YES.

There may be a short delay before the network responds. In the meantime the message ‘Please wait’ is displayed. This is followed by a message which informs you whether the call bar is activated or not.

Note! If you divert incoming calls (see ‘Diverting Incoming

Calls’), you cannot activate some barring options. Likewise, if you bar calls, you cannot activate some call divert options.

To Cancel All Call Bars

From the ‘Access’ menu, select ‘Barring’.

  Scroll to ‘Cancel all’, using the navigation key,

and press YES.

The message ‘Please wait’ appears, followed by a message that confirms that all call bars are cancelled.

To Change the Barring Password

The password for the Barring service comes with your subscription. You can easily change the password as often as you like.

 From the ‘Access’ menu, select ‘Barring’.  Scroll to the ‘Change password’ option, using

Not for Commercial Use

the navigation key.

 Enter the old (current) password and press YES.  Enter the new password and press YES.  Enter the new password a second time and

press YES.

The message ‘Please wait’ appears, followed by a message that confirms that the password has been changed.

The Keypad Lock

The Keypad Lock feature helps you to avoid accidental dialling, which can happen if you keep your phone in your pocket. You can choose between manual and automatic keylock.

An icon in the shape of a key ( you that the keypad is locked.

Note! Calls to the international emergency number 112 can

be made when the keypad is locked. If the phone alarm rings, you can turn it off by pressing any key.

The keypad remains locked until you:

• answer an incoming call,

• replace the battery,

• unlock the keypad.

To Lock the Keypad Manually

Scroll to the ‘Keylock’ menu, using the naviga-



tion key.

 Press YES.

To Unlock the Keypad

l Press LEFT followed by YES.

The Automatic Keylock

Automatic keylock means that if no keys are pressed in 25 seconds, the keypad will be locked.

To set the automatic keylock:

 From the ‘Settings’ menu, select ‘Keylock’.  Choose ‘Auto’, using the navigation key.  To confirm your selection, press YES.

Note! The Keypad lock is always disabled if the phone is

connected to vehicle handsfree equipment.

) in the display informs

Press to enter the menu system. See inside the cover. 31

Ericsson Mobile Communications AB

Fixed Dialling

Fixed Dialling is a way of restricting outgoing calls. It requires a SIM card that allows fixed numbers to be stored. The fixed numbers are protected by the PIN2.

• The Fixed Dialling function allows calls to be made only to fixed numbers stored on the SIM card. If an attempt is made to call other numbers, the message ‘Number not permitted’ appears in the display.

• It is possible to store partial numbers, for example an area code, or an area code followed by the first digits common to several numbers. Storing 0123456 allows calls to be made to numbers from 012345600 to 012345699.

• Numbers beginning with the international ‘+’ sign and country code can also be stored, allowing you to make calls from abroad.

• Numbers including question marks can be stored. For example, storing 01234567?0 allows calls to be made to numbers ending with a zero from 0123456700 to 0123456790. To enter a question mark hold down #.

• The Fixed Dialling function does not prohibit calls to the international emergency number 112 and the Service Centre of your network operator. Network services such as Call Divert and Call Barring cannot be used.

• The maximum fixed numbers that can be stored depends on your SIM card.

Not for Commercial Use

To Activate Fixed Dialling

From the ‘Access’ menu, select ‘Fixed dial’.

  Enter the PIN2 and press YES.  Scroll to ‘On’, using the navigation key, and

press YES.

To Cancel Fixed Dialling

From the ‘Access’ menu, select ‘Fixed dial’.

  Enter the PIN2 and press YES.  Scroll to ‘Off’, using the navigation key, and

YES.

press

To Store Fixed Numbers

From the ‘Phone book’ menu, select ‘Fixed



numbers’.

 Scroll to ‘Store’, using the navigation key, and

press YES.

 Enter the PIN2 and press YES.  Enter the name (optional) and the fixed number

in the same way as when storing an ordinary phone number.

To Edit a Stored Fixed Number

From the ‘Phone book’ menu, select ‘Fixed



numbers’.

 Scroll to ‘Edit’, using the navigation key, and

YES.

press

After you have entered the PIN2, you can change the position number, the name or the fixed number in the same way as with an ordinary phone number.

32 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Diverting Incoming Calls

If you want to make certain that your incoming calls are taken care of when you are unable to answer them, you can use the Call Divert service to divert them to another phone number.

The Call Divert service lets you:

• divert calls if you are already on the phone.

• divert calls that you do not answer within a specified time limit (operator dependent).

• divert calls if your phone is turned off or if you are unreachable

• divert all incoming calls.

You can also use any combination of the above. The divert option ‘All calls’ means that all incoming

calls will be diverted to a number specified by you. If you choose to divert all calls, an arrow (l) is shown in the display.

Note! If you activate the ‘All calls’ divert, all other diverts will

automatically be cancelled. They will, however, be activated again when you cancel the ‘All calls’ divert.

Activating a Call Divert

 From the ‘Divert’ menu, scroll to the required

Not for Commercial Use

divert option, using the navigation key. The options are ‘All calls’, ‘On busy’, ‘No reply’ and ‘Unreachable’, depending on your operator.

 Scroll to the divert option you want, and press

YES.

 To select ‘Activate’, press YES.

 Enter the phone number to which you want your

calls to be diverted, including the area code, and then press YES.

Note! If you used the divert option earlier and then cancelled

it, the phone number to which the calls were diverted will be suggested. Press number and enter a new one.

There may be a short delay before the network responds. In the meantime, the message ‘Please wait’ is displayed. This is followed by the message ‘On busy’, ‘All calls’ or ‘No reply’ – ‘DivertON’, depending on which divert option you choose. The selected phone number is also displayed.

The display informs you of any activated call divert each time you turn the phone on.

CLR if you want to erase this

Diverting when the Data Menus are On

If you have turned on the ‘Data menus’, you can set call diverts for your phone, fax and data numbers respectively or for all three together. To divert, proceed as described above.

For the fax and data numbers, there are only two divert alternatives:

• all calls,

• unanswered.

Press to enter the menu system. See inside the cover. 33

Ericsson Mobile Communications AB

Checking the Divert Status

To Check the Status of a Certain Call Divert

From the ‘Divert’ menu, scroll to the call divert



you want, using the navigation key, and press

YES.

 Scroll to the ‘Get status’ option.  To check the status, press YES.

The message ‘Please wait’ appears, followed by either the phone number and ‘Active on’ if the call divert is activated, or ‘Active Off’ if it is not activated.

To Check the Status of All Call Diverts

l From the ‘Divert’ menu, select ‘Check all’. The message ‘Please wait’ appears, followed by infor-

mation about all call diverts, i.e. whether they are activated or not.

Cancelling Call Diverts

To Cancel a Certain Call Divert

From the ‘Divert’ menu, scroll to the required



call divert, using the navigation key, and press

YES.

 Scroll to ‘Cancel’.  To cancel the divert, press YES.

Not for Commercial Use

The message ‘Please wait’ appears followed by a message which informs you that the call divert has been cancelled.

To Cancel All Call Diverts

l From the ‘Divert’ menu, select ‘Cancel all’. The message ‘Please wait’ appears, followed by a

message which informs you that all call diverts have been cancelled.

34 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Handling More than One Call

Your Ericsson S 868 allows you to handle more than one call simultaneously. This means that you can put a call that is in progress on hold, while you make or answer a second call, and then switch between the two calls. See also ‘Conference Calls’ at the end of this chapter’.

The Call Waiting Service

To Activate the Call Waiting Service

To be able to receive a second call, you must activate the ‘Call Waiting’ service.

 From the ‘Access’ menu, select ‘Call Waiting’.  Scroll to ‘Activate’, using the navigation key.  To activate the call waiting service, press YES.

There may be a short delay before the network responds. In the meantime, the message ‘Please wait’ is displayed. This is followed by the message‘Call Waiting ON’.

To Cancel the Call Waiting Service

From the ‘Access’ menu, select ‘Call Waiting’.

  Scroll to ‘Cancel’, using the navigation key.

Not for Commercial Use

 To cancel ‘Call Waiting’, press YES.

With the ‘Get status’ option, you can check whether the call waiting service is activated or not.

Receiving a Second Call

If the ‘Call Waiting’ function is activated, you will hear a tone in the earpiece when a second call is received and the message ‘Call wait’ will appear in the display.

To End Current Call and Accept Waiting Call

Press NO to end the current call. The question



‘Answer?’ appears.

 To answer the waiting call, press YES.

To Put Current Call on Hold and Accept Waiting Call

l To put the current call on hold and to answer

the waiting call, press YES. The message ‘1 on hold’ appears.

To Reject Waiting Call

l To reject the waiting call and continue the

current call, press 0 followed by YES.

The waiting call is cleared. If the caller’s network supports it, the caller will hear a busy tone.

Note! If ‘Divert On busy’ is activated, the waiting call is

diverted to the number you have specified.

To Switch Between Two Calls

l To switch between the active call and the call on

hold, press YES.

Press to enter the menu system. See inside the cover. 35

Ericsson Mobile Communications AB

To End the Current Call

To end the current call, press NO. The message



‘Retrieve held call?’ appears and a beep sounds.

 Press NO to end the held call, or press YES to

return to the held call.

Note! If you do not press

message ‘Retrieve held call?’ disappears from the display. The held call is ended automatically.

Tip! You can automatically end the current call and retrieve

the held call by pressing 1 followed by

YES or NO within three seconds, the

Receiving a Third Call

Provided your ‘Call Waiting’ function is activated, you may receive a third call when you are engaged in one call and have a second call on hold. You will hear a tone in the earpiece and the message ‘Call Wait’ appears in the display.

To Accept the Call

Only one call at a time can be on hold. If you wish to accept the third call, you must end one of the existing calls.

To end the current call and accept the waiting call: l Press 1, followed by

The waiting call will become active and the held call will remain held.

Not for Commercial Use

How to Reject the Call

l Press 0, followed by YES. The third call is rejected. Provided the caller’s network

supports thisfunction, the caller will hear a busy tone.

Note! If ‘Divert On busy’ is activated, the waiting call is

diverted to the number you have specified.

YES.

To Make a Second Call

 While the first call is in progress, clear the

display by pressing CLR.

 To put the current call on hold, press YES. The

message ‘1 on hold’ is displayed.

 Enter the number you wish to call, or recall it

from the phone book, and press YES.

Connecting Two Calls – Explicit Call Transfer

If youhave one activecall and one on hold, it is possible to connect the two calls.

l Press 4 followed by The two calls arenow connected to each other, and you

are disconnected from both calls. This service may not be available in all networks.

Contact your operator to find out whether your network supports it.

YES.

Conference Calls

The Conference call service allows you to have a joint conversation with up to five people. You may put an individual or a group of conference members on hold while you add other people to the conference call. You may also put conference members on hold while you talk to someone privately.

The Conference Call service may not be available in all networks. Contact your operator to find out whether your network supports it.

36 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

To initiate a Conference Call

Call the first person you wish to include in the



conference call.

 Put this person on hold by pressing YES.  Call the second person you wish to include in

the conference call.

 Press 3, followed by YES, to include the two

persons in the conference.

You can put theconference group on hold and then add a third member by repeating steps 2 to 4. It is possible to add up to five members in this way.

Note! In the display, the last called number is referred to as

call number one, the one before as number two etc.

To Have a Private Conversation

If you wish to have a private conversation with one of the members, you can put the other members on hold. To do this:

 Press 2.  Press the number of the member you want to

have a private conversation with. For example, if you wish to talk to member number three, press 3.

 Press YES.

To join the member to the conference call again: l Press 3 and then

To Release one of the Members in a

Not for Commercial Use

Conference Call

Press 1.

  Press the number of the member you want to

release. For example, if you wish to release member number three, press 3.

 To release the member, press YES.

YES.

Making a Call while a Conference Call is in Progress

It is possible to make a call while you are participating in a conference call. To do this:

 To put the conference call on hold, pressYES.  Enter the number you wish to dial and press YES

To switchbetween the new call and the conference call: l Press

To end the new call and return to the conference call: l Press 1, then

To End a Conference Call

l To end the conference call, press NO.

YES.

Press to enter the menu system. See inside the cover. 37

Ericsson Mobile Communications AB

Handsfree Calling

By using the Ericsson portable or vehicle handsfree solutions, you can be on the phone without having to use your hands to hold it.

The S 868 allows you to change the default settings for the handsfree-related functions so that they fit your own requirements.

Selecting Answering Mode

The submenu ‘Answering mode’ includes two functions: ‘Any key’ and ‘Auto’, which are useful when you use the phone with handsfree equipment.

• The ‘Any key’ function: If you use the phone with handsfree equipment and this function is turned on, you can answer an incoming call by pressing any key, except the key.

• The ‘Auto’ function: If you choose the automatic answering mode, an incoming call will be answered automatically after one ring signal, if the phone is used with handsfree equipment.

To select Answering Mode:

 From the ‘Settings’ menu, select ‘Answering

Not for Commercial Use

mode’.

 Choose ‘Any key’ or ‘Auto’, using the navigation

key.

 To change the setting of the function you have

chosen, press YES.

 To confirm your setting, press YES again.

Other Handsfree-Related Settings

Apart from the settings mentioned above, you can change the following settings when using handsfree equipment:

• ‘Ring level’

• ‘Ear volume’

• ‘Ring type’

• ‘Light’ Each of these settings can be specified separately when

you have your S 868 connected to handsfree equipment and when you use the phone as a handheld unit. This means that ifyou make one of these settings when the phone is connected to handsfree equipment, the settings when it is handheld are not affected and vice versa.

To change a setting:

 Connect the phone to the handsfree equipment.  Change the setting according to the instructions

in the chapter ‘Personalizing Your Phone’.

Note! In the HF 6600 and HF 6300vehicle handsfree solutions

there are two plastic inserts at the inside bottom of the phone holder that have to be removed in order to make the holder fit your S 868.

38 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Personalizing Your Phone

The Ericsson S 868 is much more than just another mobile phone. It is your companion in both professional and private life. As such, you most certainly want to adjust the phone to your preferences.

You can do so by composing your own ring signal, changing the key sound or changing the message signal, among other things.

This chapter contains all the information you need to get that little extra out of your phone.

Personal Settings

The ‘Settings’ menu includes a number of functions which lets you adapt your phone to your own personal needs in different situations. Note that some of the settings depend on if you have external equipment (e.g. handsfree equipment) connected to your phone or not.

Changing the Earpiece Volume

From the ‘Settings’ menu, select ‘Ear volume’.

  Use the navigation key or the volume keys at

the side of the phone to adjust the volume.

 When you reach the desired volume, press YES .

Not for Commercial Use

Tip! During a call you can use the volume keys at the side of

the phone to adjust the volume.

Note! You can have independent volume settings when you

use the phone as a handheld unit and when you use it with various handsfree equipment. This means that if you set the earpiece volume when the phone is connected to handsfree equipment, the volume setting

when the phone is handheld is not affected and vice versa.

To Reset the Phone

It is possible to reset all menu settings to default. To do this:

 From the ‘Settings’ menu, select ‘Master reset’.  Enter the phone lock code. (The default code is

0000.)

 Press YES.

To Display Your Phone Number

When you turn on your phone, your phone number will be displayed, provided it can be retrieved from your SIM card. If not, you can enter it yourself.

 From the ‘Settings’ menu, select ‘Phone no’.  Enter the number.  Press YES.

Note! If your SIM card allows it, you can also enter your fax

and/or data number.

Changing the Greeting Text

When you turn on your phone, a greeting text appears in the display. Instead of the default greeting, you can have your phone display a welcome greeting that you write yourself. However, some operators may not allow the greeting text to be changed.

To enter your own greeting:

 From the ‘Settings’ menu, select ‘Greeting’.  Scroll to ‘New text’, using the navigation key.  Press YES.

Press to enter the menu system. See inside the cover. 39

Ericsson Mobile Communications AB

 Write your new greeting, using the numeric

keys. For information on how to enter letters, see chapter ‘ The Phone Book’.

 To confirm your new greeting, press YES.

Note! The greeting function also lets you turn the greeting

text off.

Setting the Minute Minder

When the minute minder is activated, you hear a beep once every minute, while you are on the phone.

To set the minute minder:

 From the ‘Settings’ menu, select ‘Min minder’.  Choose between ‘On’ and ‘Off’, using the

navigation key.

 To confirm your selection, press YES.

To Select Key Sound

You can choose whether to hear clicks, tones or nothing (silent) when you press the keys.

 From the ‘Settings’ menu, select ‘Key sound’.  Scroll to the desired key sound, using the

navigation key, and press YES.

Note! The only sound available for the side keys is the click

sound.

Changing the Message Signal

You can choose whether to hear clicks, tones or nothing (silent)when you receive a text message (SMS).

 From the ‘Settings’ menu, select ‘Mail alert’.  Scroll to the sound you want to hear when you

receive a message, using the navigation key.

 To confirm your selection, press YES .

To Change the Display Light

The display light can be set to automatic, turned off or turned on.

In automatic mode, the display light is turned off automatically 20 seconds after the last key is pressed. It is turned on again when a key is pressed or when a call or message is received.

To set the display light:

 From the ‘Settings’ menu, select ‘Light’.  Scroll to the desired display light setting, using

the navigation key, and press YES.

Not for Commercial Use

Note! You can have one setting when the phone is used as a

handheld unitand another when the phoneis used with a handsfree kit, powered from an external source. For example, if you place the phone in a vehicle handsfree holder, you can set the display light always to be on.

Changing the Ring Type

You can choose ring type from a list of different sounds and melodies. You can also compose your own melody (see below) by entering notes with the keypad.

To choose one of the pre-programmed ring types:

 From the ‘Settings’ menu, select ‘Ring type’ .  Scroll with the navigation key until you find the

ring signal that you want. If you do not wish to disturb other people, use the volume keys on the side of the phone to scroll silently.

 When you reach the desired ring type, press

YES.

Note! If the ‘Data menus’ are turned on you can set the ring

signal type for speech (the display shows ‘Phone’ in the middle row), fax and data calls respectively. If you have the Two Line service (Alternate Line service), you can also set different ring types for the two lines.

40 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Composing Your Own Ring Signal

From the ‘Settings’ menu, select ‘Edit Melody’.

  Clear the display by pressing CLR.

 Use the keypad to

enter notes. The keypad now works as a keyboard. Press and hold a key to enter a long note. Press 0 to increase the note one octave.

 Use the navigation key to set the ring signal

level.

• Pressing

• Pressing The phone will ring once with the actual setting

as you press the navigation key, except for the ‘Off’ and ‘Step’ settings.

 To save the setting, press YES.

Tip! Use the side keys to change the ring level silently.

Time and Date

The ‘Clock’ menu lets you set the time and date. It also lets you activate the alarm function.

The time is shown continuously at the bottom of the display when the phone is in standby mode.

RIGHT increases the volume. LEFT decreases the volume.

 To listen to your melody, press YES. If you want

to save it, press YES again. If not, press NO and continue editing.

The Clock

To change the time format:

 From the ‘Clock’ menu, select ‘Clock mode’.  Select the clock mode you want, using the navi-

The Ring Signal Level

The Ring level setting allows you to specify the level:

• when the phone is handheld.

• when the phone is connected to handsfree equipment.

Not for Commercial Use

• when the phone is connected to a vibrating call alert device.

To set the ring signal level:

 If necessary, connect the phone to the external

equipment.

 Scroll to the ‘Ring level’ menu, using the naviga-

tion key, and press YES.

Press to enter the menu system. See inside the cover. 41

gation key.

 Press YES.

To set the clock:

 From the ‘Clock’ menu, select ‘Set clock’.  Enter the time in hours and minutes.  Press YES.

If you select the 12-hour format in the ‘Clock mode’ function, you can alternate between am and pm by pressing #.

The Date

It is possible to have the date displayed in the middle of the display when the phone is in standby mode.

Ericsson Mobile Communications AB

To set the date format:

 From the ‘Clock’ menu, select ‘Date mode’.  Scroll to the date format you want, using the

navigation key.

 To select a date format, press YES.

To set the date:

 From the ‘Clock’ menu, select ‘Set date’.  Enter the year (two digits).  Press YES.  Enter the month and day in the same way.  To confirm your setting, press YES.

Not for Commercial Use

42 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Data Menus

The phone can be used with the Ericsson Mobile Office kit. This links the phone to a desktop or laptop PC, allowing you to use data communication and fax services from the PC, provided the ‘Data menus’ on your phone are turned on.

When you turn on the ‘Data menus’ two new menus will appear; the menu, ‘Speech then fax’ will appear before the ‘Info’ menu when you scroll with the navigation key. Themenu ‘Next calltype’ will appearafter the ‘Info’ menu.

See the User’s manual for the Mobile Office kit for further information about the use of the two menus.

To Activate the Data Menus

SETTINGS

~ Data menus 

(On)

 In the ‘Settings’ menu, scroll to ‘Data menus’.

The current status (on or off) is now shown on the bottom row of the display.

 Press YES to change the status if needed (that is

from off to on or vice versa). Then press YES again to confirm the setting.

Not for Commercial Use

Press to enter the menu system. See inside the cover. 43

Ericsson Mobile Communications AB

Other Useful Features

Today’s networks are full of advanced features that can help you in your daily life. You will access and benefit from all of them, easily and conveniently, with your Ericsson S 868, which is designed and prepared to be the best tool available for that kind of services.

This chapter guides you through these features. Please note that some of them are operator dependent. Contact your operator for information on which services you have access to.

The Answering Service

The Answering service of your network allows callers to leave a voice message when you cannot, or do not, wish to answer your calls.

Note! This service may not be available in all networks and

may require a separate subscription. The ‘Voice mail’ function makes it easy to call your

answering service to listen to recorded voice messages. You must activate the ‘Voice mail’ function before using it.

To Enable the Voice Mail Function

To enter the number to the answering service:

Not for Commercial Use

 From the ‘Mail’ menu, select ‘Set VoiceM’.  Scroll to ‘New number’, using the navigation

key, and press YES.

 Enter the new number and press YES.

To enable the Voice Mail function on your phone:

 From the ‘Mail’ menu, select ‘Set VoiceM’.

 Scroll to ‘On’, using the navigation key and

press YES .

 Enter the number of your answering service.  To enable the function, press YES.

To change the number of the answering service:

 From the ‘Mail’ menu, select ‘Set VoiceM’.  Scroll to ‘New number’, using the navigation

key, and press YES.

 Enter the new number and press YES.

To Call the Answering Service

Voicemail

Check?

ERICSSON

28 Tt

12:35

When you receive a voice mail, this is indicated in the display by the text ‘Voicemail Check?’. You can now check your message by pressing YES.

If you press any time later on to listen to your recorded messages. To do this:

l From the ‘Mail’ menu, select ‘Voice mail’ and

press The phone will automatically call your voice

mail. Follow the instructions given to you by your operator’s answering service.

Whenever you have a waiting voice mail, a symbol is shown at the bottom of the display.

Further information about the use of the answering service is found in the operating instructions supplied by your network operator.

Tip! You can also call your voice mail number by pressing

and holding the 1 key in standby mode.

NO, you can call the answering service at

YES.

44 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

To Turn Off the Voice Mail

From the ‘Mail’ menu, select ‘Set VoiceM’.

  Select ‘Off’ and press YES.

The Call Time/Call Cost

When you are on the phone, the display shows the duration of a call.

By using the ‘Call info’ function in the ‘Settings’ menu you can have the time displayed for all calls, both incoming and outgoing. You can also have the call cost or the number of call units displayed by selecting the ‘Cost’ option, provided your network and your SIM card support this feature.

Call Information

To select what call information you want to be displayed in the ‘Info’ menu:

 From the ‘Settings’ menu, select ‘Call info’.  Choose from ‘Time:Outg.’, ‘Time:All’ and ‘Cost’.  Confirm your selection by pressing YES.

To Check Time or Cost of the Last Call

You can check the time/cost of the last incoming (or outgoing) call with the ‘Last call’ option in the ‘Info’ menu.

 From standby, scroll to the ‘Info’ menu, using

the navigation key.

Not for Commercial Use

 Press YES.  Depending on the setting in the ‘Call info’ func-

tion in the ‘Settings’ menu, you can use the navigation key to check:

• The elapsed time of the last outgoing call.

• The elapsed time of the last incoming call

provided you have chosen the ‘Time:All’

option in the ‘Call info’ function in the ‘Settings’ menu.

To Check Total Call Time or Call Cost

From the ‘Info’ menu, select ‘Tot calls’.

  Press YES.

Depending on the settings in the ‘Call info’ function in the ‘Settings’ menu, you can check:

• The elapsed time of all outgoing calls.

• The elapsed time of all incoming and outgoing calls.

• The cost (or the number of call units) of all incoming and outgoing calls.

To Reset the Total Call Time/Cost Meter

From the ‘Info’ menu, select ‘Tot calls’.

  Press YES. The message ‘Reset?’ appears.  To reset the meter, press YES.

Note! If you choose the call cost option you must enter your

PIN2 to reset the meter.

To Determine the Call Cost

This function only appears if you have selected the ‘Cost’ option in the ‘Call info’ function in the ‘Settings’ menu.

l From the ‘Info’ menu, select ‘Price’. The ‘Units’ option means that the number of call units

will be displayed during a call, and in the ‘Last call’ and ‘Tot calls’ functions.

The ‘Price’ function letsyou enter and vary the price per call unit. The price entered is stored on your SIM card.

To Enter the Price per Call Unit

From the ‘Settings’ menu, select ‘Call info’.



Press to enter the menu system. See inside the cover. 45

Ericsson Mobile Communications AB

 Scroll to ‘Cost’, using the navigation key, and

press YES.

 To exit to standby mode, press CLR.  From the ‘Info’ menu, select ‘Price Units’ and

press YES. ‘New Price’ appears.

 Press YES.  Enter the code for the desired currency, for

example GBP for Pound Sterling, and press YES.

 Enter the price per call unit, for example 0.5,

and press #.

YES. To enter the decimal point, press

The Two Line Service

Two voice lines with different phone numbers, Line 1 and Line 2, may be assigned to your phone. This is useful if you, for example, want to have one number for your business calls and one for your private. The ability to receive and send text messages (SMS), is only available on Line 1.

The Two Line service (also called Alternate Line Service, ALS) may not be available on all networks and may require a separate subscription.

 Enter your PIN2. (The PIN2 prompt may not

appear in some networks.)

To Revert to Displaying Call Units

From the ‘Info’ menu, select ‘Price’.

  To select the ‘Units’ option, press YES.  To revert to displaying call units, press YES.

Change to

LINE 2?

To Set a Credit Limit for Calls

Provided both your network and your SIM card support this feature,you can enter a total amount of money that can be used for making calls. This could be useful when you, for example, lend your phone to someone, and do not want their call costs to exceed an amount specified by you. After a call is made, the cost is deducted from this amount. When the amount reaches zero, no more calls can be made.

 From the ‘Info’ menu, select ‘Credit’.

Not for Commercial Use

 To select ‘New credit’, press YES.  Enter the amount: for example, 30 pounds.  Press YES.  Enter your PIN2.  Press YES.

Selecting a Line

The line currently selected is indicated in the display with the letter ‘L’ and a digit. For example, if line two is selected, you will see ‘L2’ in the display.

To change to the line that is not currently selected:

 Scroll to the ‘Change to’ menu.

 To change to the line displayed in the bottom

row, press

From now on, all outgoing calls are made on the selected line. You can, however, receive calls on both lines.

Note! Instead of accessing the menu system, you can press

and hold the 2 key to change line, provided the phone is in standby mode. Clear the display first, using the

CLR key.

YES.

Receiving a Call on Line 1 or Line 2

When someone calls you, the question ‘Answer?’ is replaced by ‘Line1?’ or ‘Line2?’ depending on which line you have selected.

Note! If you are engaged in a call on one line, you must end

that callfirst before answering the call on the other line.

46 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Different Settings for Each Line

You can have different settings for each line: for example, the tone of the ring signal, call diverts, call bars and call waiting function.

The call meters in the ‘Info’ menu show the call times (call costs) for the line currently selected.

Changing the Name of the Two Lines

Your S 868 allows you to personalize the names of the two lines. You might, for example, want to call Line 1 ‘Private’ and Line 2 ‘Work’. To change the name of Line1:

 From the ‘Settings’ menu, select ‘Line 1 Tag’ and

YES.

press

 Enter the name (maximum twelve characters),

using the numeric keys and press YES.

To change the name of Line 2, select ‘Line 2 Tag’ instead.

Calling Card or Credit Card Calls

When making international or long distance calls, you may not want your operator to charge you for these calls on your normal account. If you have a credit card or a calling card, you may want to redirect the charges to one of those accounts instead. Your S 868 is all set for makingthis procedure as easy as possible for you.

You can store two separate card numbers in your

Not for Commercial Use

phone. These numbers are protected by a four- to eight-digit security code that you choose yourself. The default code is 0000.

In order to be able to make Calling card calls, you have to activate this function.

Activating the Calling Card Feature

From the ‘Access’ menu, select ‘Call cards



security’ and press

YES.

 Enter your security code and press YES. The

default code is 0000.

 Scroll to ‘Call cards’, using the navigation key,

and press YES.

 Scroll to ‘On’, using the navigation key, and

press YES.

The Call card function is now activated and the submenu ‘Call card numbers’ will be visible in the ‘Phone book’ menu.

To Change Security Codes

From the ‘Access’ menu, select ‘Call cards



security’ and press

YES.

 Enter your security code and press YES. The

default code is 0000.

 Scroll to ‘Change code’, using the navigation

key, and press YES.

 Enter your new code and press YES. The code

can consist of four to eight digits.

 Confirm your new code, when ‘Repeat new

code’ appears in the display, and press YES.

Your security code is now changed.

Storing Credit or Calling Card Numbers

Your Ericsson S 868 allows you to store two calling card numbers in the phone book menu.

This submenu is only visible if the Call card function is activated in the ‘Access’ menu.

To store a calling card number:

 From the ‘Phone book’ menu, select ‘Call card

numbers’ and press YES.

Press to enter the menu system. See inside the cover. 47

Ericsson Mobile Communications AB

 Enter your security code and press YES. The

default code is 0000. To change security codes, see above.

 Select card position (Card 1 or Card 2), using

the navigation key, and press

YES.

 Enter the access number (the phone number) to

the calling card server. The numbers are entered in the same way as in the ordinary Phone book.

 Press the navigation key RIGHT.  Enter the verification code to your calling card

server.

 To store the calling card number, press YES.

Note! Since the dialling order may vary between calling card

servers, you can change the order yourself. Use the or # key, when the ‘Called no.’ row flashes.

Dialling order means whether you have to dial your verification code before or after the number you want to dial.

Selecting the Card You Want To Use

If you have stored two card numbers, you must select which card you wish to use before making a Calling/Credit card call.

 From the ‘Phone book’ menu, select ‘Call card

numbers’.

Area Information

Making a Credit or Calling Card Call

Enter the number you wish to dial, or retrieve it



from the Phone book.

 To set up the call as a Credit/Calling Card Call,

press and hold YES.

The access number to the calling card server is called and during the connecting phase, you are prompted to send the called number (the number or the person you want to call) and the verification code, in the order chosen by you (see above).

To send the called number and the verification code during the connecting phase, press play shows ‘Send’, or wait a few seconds and your Ericsson S 868 will send them automatically.

The ordinary Short Message Service can be defined as a personal service with messages specifically and exclusively directed to you. The Area Information (AI) is another type of text message which is sent to all subscribers ina certain cell of a network at the same time.

For example,the information maybe a localroad report or a local taxi phone number.

Note! This feature may not be available in all networks.

 Enter your security code and press YES. The

default code is 0000.

 Scroll to the card you wish to use, using the

Not for Commercial Use

navigation key, and press YES Your settings for the card appear.

 To select the card, press YES.

Note! If you only use one card number, this selection will not

have to be repeated every time you wish to make a Calling/Credit card call.

To Turn On Area Information

From the ‘Mail’ menu, select ‘Area info’.

  Press YES.  Scroll to ‘On’, using the navigation key, and

press YES.

You can now see Area information messages in your display.

YES when the dis-

48 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

To Turn Off Area Information

From the ‘Mail’ menu, select ‘Area info’.

  Press YES.  Scroll to ‘Off’, using the navigation key, and

YES.

press

Area Information Message Types

Each type of Area Information message is identified by a three-digit code. At present, the following message types exist:

Code AI Message Type 000 Index 010 Flashes 020 Hospitals 022 Doctors 024 Pharmacy 030 Long-distance road reports 032 Local road reports 034 Taxis 040 Weather 050 District (base station identity) 052 Network information 054 Operator services 056 Directory enquiries (national) 057 Directory enquiries (international) 058 Customer care (national)

059

For information about the AI services you can use,

Not for Commercial Use

please refer to the information supplied by your network operator.

Customer care (international)

Area Information Message List

You can decide which types of area information messages you wish to receive. The phone’s ‘Area Info’ list can hold up to 20 codes.

To insert an Area Information code:

 From the ‘Mail’ menu, select ‘Area info’.  Press YES.  Scroll to ‘Edit list’, using the navigation key, and

press YES. The digits to the left indicate the position in the

list. You can scroll forwards and backwards through the list with the navigation key.

 To insert a code, scroll to the first empty

location, using the navigation key. Press

 Enter the new code. (You only need to enter 40

for 040, since the phone adds the leading zero automatically.)

To erase or replace a code:

 From the ‘Mail’ menu, select ‘Area info’.  Press YES.  Scroll to ‘Edit list’, using the navigation key, and

press YES.

 Scroll to the code you wish to erase, and press

YES.

 The message ‘Erase?’ appears.

• If you want to erase this code, press

• If you want to replace the code, press the

navigation key Then enter the new code and press YES.

RIGHT once, followed by YES.

To Receive Area Information

When you receive Area information, the message is stored in the phone memory. Please note that the phone only stores one message per code. This means that the message stored previously in a specific code will be erased.

Provided ‘Area info’ is turned on, you can read the messages with the ‘Area messages function in the mail menu.

 From the ‘Mail’ menu, select ‘Area messages’.

YES.

Press to enter the menu system. See inside the cover. 49

Ericsson Mobile Communications AB

The Alarm

Note! If you choose the 12-hour format in the ‘Clock mode’

 Scroll from one message to another by using the

navigation key.

 To select a message, press YES.

The phone has an alarm function. When it is activated, an icon in the shape of a bell (B) is shown next to the current time in the display.

The alarm rings at the set time even if the phone is turned off. The illumination of the keys and the display will flash. The volume of the alarm signal depends on the setting of the ring signal.

The alarm will ring for 60 seconds and will be repeated every nine minutes if you do not turn it off. After 60 minutes, the repeat function will be turned off.

To set the alarm:

 From the ‘Clock’ menu, select ‘Set alarm’.  Scroll to the ‘New time’ option, using the naviga-

tion key.

 Press YES.

The Calculator

The phone’s built-in calculator can add, subtract, divide and multiply.

An example of how to use the calculator: In this example we are going to divide 134 by 32.

 Scroll to the ‘Calculator’ menu and press YES.  Enter 134.  Scroll with the navigation key to the division

sign (/), and press YES.

 Enter 32.  Scroll with the navigation key to the equal sign

(=) and press YES to get the answer. You can also press # to get the answer.

 To clear the display, press CLR.

To enter a decimal point: l Press

To multiply: l Press

twice.

 Enter the time in hours and minutes.  Press YES.

function you can alternate between am and pm by pressing

To turn the alarm off:

Not for Commercial Use

 Press any key to turn the alarm off when it

sounds.

and #.

 If you do not want the alarm to be repeated,

press YES.

To turn the alarm function off:

 From the ‘Clock’ menu, select ‘Set alarm’.  Scroll to ‘Off’, using the navigation key.  Press YES.

50 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Guidelines for Safe and Efficient Use

General

Your mobile phone is a radio transmitter and receiver. When the phone is turned on, it receives and transmits radio frequency (RF) energy. Depending on the type of mobile phone you have bought, it operates in different frequency ranges and employs commonly used modulation techniques. The system that handles your call when you are using your phone, controls the power level at which your phone transmits.

Exposure to Radio Frequency Energy

The International Commission on Non-Ionizing Radiation Protection (ICNIRP), sponsored by the World Health Organization (WHO), published a statement in 1996 which sets limits for exposure to RF fields from handheld mobile phones. According to this statement, which is based on the available body of research, there is no evidence that mobile terminals meeting the recommended limits can cause any adverse health effects. All Ericsson telephones conform to the ICNIRP recommendations and international exposure standards, such as:

• CENELEC European Pre-standard ENV50166-2

Not for Commercial Use

• ANSI/IEEE C95.1-1992 (USA, Asia-Pacific) If you want to limit RF exposure even further, you may

choose to control theduration of your calls and operate your phone in the most power efficient manner.

Efficient Phone Operation

How to use your phone for optimum performance with minimum power consumption:

• Hold the phone as you would any other telephone. While speaking directly into the mouthpiece, angle the antenna in a direction up and over your shoulder. If the antenna is extendable/retractable, it should be extended during a call.

• Do not hold the antenna when the phone is in use. Holding the antenna affects call quality, may cause the phone to operate at a higher power level than needed and shorten talk and standby times.

Antenna Care and Replacement

• Do not bend the antenna since it is sensitive and this will reduce its performance.

• Do not use the phone with a damaged antenna. Take your phone to a qualified service centre for repair. Use only the designated Ericsson antenna.

• Do not use an antenna designed for any other type of telephone than the one you have bought. Unauthorized antennas, modifications, or attachments could damage the phone and may violate the appropriate regulations.

Driving

Check the laws and regulations on the use of telephones in the areas where you drive.

Press to enter the menu system. See inside the cover. 51

Ericsson Mobile Communications AB

If you are going to use your mobile phone while driving:

• Give full attention to driving.

• Use handsfree operation, if available.

• Pull off the road and park before making or answering a call if driving conditions so require.

RF energy may affect some electronic systems in motor vehicles. In addition, some vehicle manufacturers forbid the use of mobile phones in their vehicles. Check with your vehicle manufacturer's representative to be sure your phone will not affect the electronic systems of your vehicle.

Electronic Devices

Most modern electronic equipment, for example equipment in hospitals and cars, is shielded from RF energy. However, RF energy from telephones may affect some electronic equipment.

Turn off your phone in health care facilities when regulations posted in the areas instruct you to do so.

Do not use your mobile phone near medical equipment without requesting permission.

Mobile telephonesmay affect the operation of some implanted cardiac pacemakers, equipment for people with hearing impairments and other medically implanted equipment. Pacemaker patients should be aware that the use of a mobile phone very close to a

Not for Commercial Use

pacemaker may cause the device to malfunction. Avoid placing the phone over the pacemaker, i.e. in your breast pocket. When using the phone, place it at your ear opposite the pacemaker. If a minimum distance of 15 cm is kept between the phone and the pacemaker, the risk of interference is limited. Contact your cardiologist for more information.

Aircraft

• Turn off your phone before boarding any aircraft.

• Do not use it on the ground without crew permission.

To prevent interference with communication systems, you must not use your phone while the plane is in the air.

Power Supply

• Connect AC (Power supply) only to designated power sources as marked on the product.

• To reduce risk of damage to the electric cord, remove it from the outlet by holding onto the AC adapter rather than the cord.

• Make sure the cord is located so that it will not be stepped on, tripped over or otherwise subjected to damage or stress.

• To reduce risk of electric shock, unplug the unit from any power source before attempting any cleaning, then use a soft, damp cloth.

Children

Do not allow children to play with your phone since

they could hurt themselves or others or accidentally damage the phone.

Blasting Areas

Turn off your mobile phone when in a blasting area or

in areas posted ‘turn off two-way radio’ to avoid interfering with blasting operations. Construction crews often useremote control RF devices to set off explosives.

52 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

Potentially Explosive Atmospheres

Turn off your phone when in any area with a poten-

tially explosive atmosphere. It is rare, but your phone or its accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fuelling areas,such as petrol stations, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle which contains your phone and accessories.

Product Care

• Do not expose your mobile phone to moisture or extreme temperatures.

• Do not use any other accessories than Ericsson originals. Failure to do so may result in loss of performance, fire, electric shock or injury, and will void the warranty.

• Do not attempt to disassemble the product. Doing so will void warranty. This product does not contain consumer serviceable components. Service should only be performed by Authorized Service

Not for Commercial Use

Centres.

Press to enter the menu system. See inside the cover. 53

Ericsson Mobile Communications AB

Warranty Conditions

If your Ericsson product requires warranty service you should return the product to the dealer/retailer from whom it was purchased. If your Ericsson product requires warranty service when you are abroad, the service is available inthose countries listed on your International Warranty Certificate.

In the event of difficulty, details of our authorized service network are available from your local Ericsson subsidiary.

Our warranty

Ericsson warrants this product as being free of defects in material, design and workmanship at the time of original purchase and for a period of twelve (12) months immediately thereafter.

What We Will Do

If, during the period of the warranty, this product malfunctions innormal use andservice due to defective design, materials or workmanship Ericsson willrepair or replace, at its discretion, the product under the conditions stated below.

Not for Commercial Use

Ericsson subsidiaries, authorised distributors or authorised service centres in the countries listed on your International Warranty Certificate will repair or replace this product in accordance with the terms and conditions stipulated in these conditions of the warranty. Certain products may not be available in certain countries and in this event, a similar product will be delivered.

Conditions

 The warranty will be granted only if the original

warranty certificate issued to the purchaser by the dealer is presented, and if the said warranty certificate stipulates the serial number of the purchased product and the date of purchase of the product. Ericsson reserves the right to refuse warranty service if this information has been removed or amended after the original purchase of the product. The original receipt/invoice will only be accepted as a proof of purchase when presented to the dealer from whom the product was purchased.

 The warranty is not applicable in circumstances

other than defects in material, design and workmanship. The warranty does not cover the following:

• Periodic checks, maintenance, repair and replacement of parts due to normal wear and tear, exchange of faulty batteries or upgrading of software due to changes in network parameters.

• Damage to the product resulting from: – Abuse or misuse, including but not limited to

failure to use the product for its normal purposes or in accordance with Ericsson’s instructions for use and maintenance of the product, or the installation or use of the product in a manner inconsistent with the technical or safety standards in force.

– Repairs performed by non-authorised service

workshops, or opening of the product by nonauthorised persons.

54 Press to enter the menu system. See inside the cover.

Ericsson Mobile Communications AB

– Accidents, acts of Godor any cause beyond the

control of Ericsson, including but not limited to lightning, water, fire, public disturbances and improper ventilation.

 This product will not be considered defective in

materials, design or workmanship if it needs to be adapted, changed or adjusted to conform to national or local technical or safety standards in force in any country other than that for which the product was originally designed and manufactured. This warranty shall not reimburse such adaptations, changes or adjustments, or attempts to do so, whether properly performed or not, nor any damage resulting from them, nor any adaptation, change or adjustment to upgrade the product from its normal purpose as described in the product manual without the prior written consent of Ericsson.

 Repair or replacement under the terms of this

warranty shall not give a right to an extension to, or a new commencement of, the period of warranty. Repair or replacement under the terms of this warranty may be fulfilled with functionally equivalent reconditioned units. Replaced faulty parts or components will become the property of Ericsson.

 This warranty does not affect the purchaser’s ’s

statutory rights under applicable national legislation in force, nor the purchaser’s rights against the dealer arising from the sales/purchase contract.

Not for Commercial Use

In the absence of applicable national legislation this warranty will be the purchaser’s sole and exclusive remedy. Ericsson, its subsidiaries and distributors shall not be liable for any incidental or consequential damages for breach of any express or implied warranty relating to this product.

Press to enter the menu system. See inside the cover. 55

Ericsson Mobile Communications AB

Index

Aircraft, 52 Alarm, 50

set the alarm, 50 turn the alarm function off, 50 turn the alarm off, 50

Alternate line service (ALS), 46 answered calls memory, 11

Calling Line Identification service (CLI), 11 clear memory, 11 recall number, 11

Answering Mode, 38 Answering Service, 44

check voice mail, 44

antenna

care and replacement, 51

Area Information, 48

Message List, 49 Message Types, 49 Receive Area Information, 49

Battery, 4

Attach the Battery, 4 Charge the Battery, 4 low battery alarm, 6 nickel cadmium type batteries, 5 nickel metal hydride battery , 5 Remove the Battery, 4

Not for Commercial Use

Calculator, 50

Call Barring

cancel call bars, 31 change password, 31 change status, 30

Call Information, 45

Call Cost, 45 Call Time, 45 Credit Limit , 46 Price per Call Unit, 45

Call Waiting Service, 35

Activate Call Waiting Service, 35 Cancel Call Waiting Service, 35

Calling Line Identification (CLI) service, 12, 18

hide your phone number, 12, 18 show your phone number , 12, 18

calls, 9

answer, 10 domestic, 9 international, 9 making, 9 receiving, 10 rejecting, 10

capacity, 2 charger, 4

connect, 4 disconnect, 5

Children, 52 Clock, 41 Conference Calls, 36 Connecting Two Calls, 36 coverage, 2 Credit Card Calls, 47

Date, 41 Display, 0 Display Language, 7

Reset to English, 8

Display Light, 40 Display Your Phone Number, 39 Diverting Incoming Calls, 33

Activating a Call Divert, 33 Cancelling Call Diverts, 34 Checking the Divert Status, 34 Diverting when the Data Menus are On, 33

Driving, 51 DTMF tones, 13 Dual Band, 2

Earpiece Volume, 13, 39 Efficient Phone Operation, 51 Electronic Devices, 52 Emergency calls, 7, 9 Entering Characters

Check the First Characters, 16 Enter Small Letters, 16

Erasing a Message, 24 Erasing a Phone Number, 19 Exposure to Radio Frequency Energy, 51

Ericsson Mobile Communications AB

Fixed Dialling, 32

Activate, 32 Cancel, 32 Edit Fixed Numbers, 32 Store Fixed Numbers, 32

frequencies, 2

Greeting Text, 39 GSM 1800, 2 GSM 900, 2

Handsfree Calling, 38

Handsfree-Related Settings, 38

hiding your phone number, 12, 18

international emergency number, 9 International Numbers, 15

country code, 15 international dialling prefix, 15

Key Sound, 40 Keypad Lock, 31

Automatic, 31 Manual, 31 Unlock, 31

Not for Commercial Use

Language, 7 last dialled numbers, 10

Light, 40

Menu System, 14 Message Signal, 40 Minute Minder, 40 Missed calls, 11

Who Called, 11

Mute

microphone, 13 ring signal, 10

Networks, 26

Search, 26 Select, 26

Operators, 2

PCN, 2 Personal Identity Number (PIN), 2 Personal Unblocking Key (PUK), 2 Phone Book, 15

Edit, 19 Entering Characters, 15 name recall, 17 Phone Book Memories, 15 position recall, 18 Store a Phone Number, 16

PIN, 2

Change PIN, 29

PIN2, 2

Change PIN2, 29

Potentially Explosive Atmospheres, 53 Power Supply, 52 Product Care, 53 PUK, 2

Reading a Message, 23 Recalling a Phone Number, 17

Using the Name, 17 Using the Position, 18

Redialling a Number, 10

Automatic Redialling Function, 10 Redial Previously Called Numbers, 10

Replying to a Message, 24 Reset the Phone, 39 Ring signal

changing ring type, 40 Composing your own ring signal, 41

Ring Signal Level, 8, 41

handsfree equipment, 8 To mute the ring signal, 10 vibrating call alert device, 8

Roaming

International, 2

Scratch Pad, 13 Security, 29

Call Barring, 30 Card Lock, 29 Keypad Lock, 31 Phone Lock, 30

security code (PIN), 2 Sending Messages, 23

Ericsson Mobile Communications AB

SIM Card

If Your SIM Card is Blocked, 29 Insert the SIM Card, 3 Lock the SIM Card, 29 Unlock the SIM Card, 29

speed dialling, 17 Subscriber Identity Module (SIM), 2 Subscription, 2

Text Messages, 21

Changing Message Types, 22 Enter Letters, 22 Messages Memory, 21 Read, 24 Send, 25 Setting the Phone for Text Messaging, 21 SIM Card Memory, 21 Store, 24 Write, 22

Tone Signals, 13 touch tones, 13 Turning Off the Phone, 7 Turning On the Phone, 7 Two Line Service, 46

Selecting a Line, 46

Unanswered Calls, 11

Not for Commercial Use

Voice Mail, 44

To Turn Off the Voice Mail, 45

Ericsson Mobile Communications AB

Second edition (November, 1998) This user’s guide is published by Ericsson Mobile Communica-

tions AB, without any warranty. Improvements and changes tothis user’s guide due to typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.

The symbol on our productssignifies that they have been certified according to the EMC directive 89/336/EEC, the Telecommunications directive 91/263/EEC, and the Low Voltage directive 73/23/EEC when applicable. The products fulfil the requirements according to the following standards:

Cellular Phones and Accessories in Combination:

Not for Commercial Use

• ETS 300 342-1 EMC for European digital cellular telecommunications.

Accessories Without Direct Connection to a Cellular Phone:

• EN 50081 Electromagnetic compatibility, Generic Emission Standard

• EN 50082 Electromagnetic compatibility, Generic Immunity Standard.

Ericsson Mobile Communications AB

Ericsson S868 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
