Ericsson I 888 WORLD User Manual

General Information 2

Operators & Subscription 2, GSM 900/1900 Dual Band 2, SIM & PIN 2

Preparing Your Phone for Use 3

The SIM Card 3, The Battery 4

Turning On the Phone 7

When No Network Name Is Displayed 7, To Turn Off the Phone 7, Initial Settings 7

Making and Receiving Calls 9

Emergency Calls 9, Making Calls 9, Receiving a Call 10, Redialling a Number 10, Calling Someone Who Has Called You 11, Unanswered Calls 11, Hiding or Showing Your Number 12

During a Call 13

To Change the Earpiece Volume 13, To Mute the Microphone 13, To Use the Display as a Scratch Pad 13, To Send Tone Signals 13

The Menu System 14

Moving through the Menu System 14, Display Text and Symbols 14

The Phone Book 15

Before You Start 15, Entering Characters 16, Creating Your Personal Phone Book 16, Recalling a Phone Number 17, Keeping Your Phone Book Up to Date 19, Copying Phone Numbers between Positions and Memories 20

Sending and Receiving Text Messages 21

Two Memories 21, Setting the Phone for Text Messaging 22, Composing and Sending Messages 22, Reading a Message 23, Replying to a Message 24, Erasing a Message 24, Storing a Received Message 24, Reading Stored Messages 25, Calling a Phone Number in a Message 25, Frequently Used Messages 25

Communicating via the Modem 26

Before you Start 26, The Data Menus 26, Installing the Infrared Modem 27, To Connect Using the IR Link 30, To Connect Using the RS232 Cable 30, Making Fax and Data Calls 30, Receiving Fax and Data Calls 31

The Mobile Office Suite 32

Installing the Mobile Office Suite 32, Uninstalling the Mobile Office Suite33

Networks 34

Search Mode 34, Selecting a Network 34, List of Preferred Networks 35

Security 37

The Card Lock 37, The Phone Lock 38, Call Barring/Restrict Calls 38, The Keypad Lock 39, Fixed Dialling 40

Diverting Incoming Calls 41

Activating a Call Divert 41, Diverting when the Data Menus are On 41, Checking the Divert Status 42, Cancelling Call Diverts 42

Handling More than One Call 43

The Call Waiting Service 43, Receiving a Second Call 43, Receiving a Third Call 44, To Make a Second Call 44, Connecting Two Calls – Explicit Call Transfer 44, Conference Calls 44

Handsfree Calling 46

Selecting Answering Mode 46, Other Handsfree-Related Settings 46

Personalizing Your Phone 47

Personal Settings 47, The Ring Signal Level 49, Time and Date 49

Other Useful Features 51

The Answering Service 51, The Call Time/Call Cost 52, The Two Line Service 53, Calling Card or Credit Card Calls 54, Area Information 55, The Alarm 57, The Calculator 57

Guidelines for Safe and Efficient Use 58

Warranty Conditions 61

Contents

General Information 2

Operators & Subscription 2, GSM 900/1900 Dual Band 2, SIM & PIN 2

Preparing Your Phone for Use 3

The SIM Card 3, The Battery 4

Turning On the Phone 7

When No Network Name Is Displayed 7, To Turn Off the Phone 7, Initial Settings 7

Making and Receiving Calls 9

Emergency Calls 9, Making Calls 9, Receiving a Call 10, Redialling a Number 10, Calling Someone Who Has Called You 11, Unanswered Calls 11, Hiding or Showing Your Number 12

During a Call 13

To Change the Earpiece Volume 13, To Mute the Microphone 13, To Use the Display as a Scratch Pad 13, To Send Tone Signals 13

The Menu System 14

Moving through the Menu System 14, Display Text and Symbols 14

The Phone Book 15

Sending and Receiving Text Messages 21

Communicating via the Modem 26

The Mobile Office Suite 32

Installing the Mobile Office Suite 32, Uninstalling the Mobile Office Suite33

Networks 34

Search Mode 34, Selecting a Network 34, List of Preferred Networks 35

Security 37

The Card Lock 37, The Phone Lock 38, Call Barring/Restrict Calls 38, The Keypad Lock 39, Fixed Dialling 40

Diverting Incoming Calls 41

Activating a Call Divert 41, Diverting when the Data Menus are On 41, Checking the Divert Status 42, Cancelling Call Diverts 42

Handling More than One Call 43

The Call Waiting Service 43, Receiving a Second Call 43, Receiving a Third Call 44, To Make a Second Call 44, Connecting Two Calls – Explicit Call Transfer 44, Conference Calls 44

Handsfree Calling 46

Selecting Answering Mode 46, Other Handsfree-Related Settings 46

Personalizing Your Phone 47

Personal Settings 47, The Ring Signal Level 49, Time and Date 49

Other Useful Features 51

The Answering Service 51, The Call Time/Call Cost 52, The Two Line Service 53, Calling Card or Credit Card Calls 54, Area Information 55, The Alarm 57, The Calculator 57

Guidelines for Safe and Efficient Use 58

Warranty Conditions 61

PTO for The Menu System

The Menu SystemThe Menu System

Start here

ERICSSON

12:35

Ring level

(

QQQqqq

)

Change to

LINE 2?

Divert

Mail

Keylock

On?

Clock

Settings

Calculator

Phone book

Ear volume

Ring type Edit melody Mail alert Keylock Key sound Light Min minder Call info

Answering mode Greeting Phone no Language Data menus Line1 tag Master reset

Name recall Position recall Store Edit Erase Erase all from phone Copy all

Copy Call card numbers Fixed numbers Answered calls Dialled numbers

Voice mail Read messages Send messages Area info Area messages Set Voice Mail Missed calls

All calls On busy No reply Unreachable Cancel all Check all

Barring Call Waiting Unlock card Change PIN code Change PIN2 code Phone lock Phone lock Change code Call cards security Fixed dial

Set alarm Set clock Set date Clock mode Date mode

Select net Search mode Edit list New search

Last call Tot calls

MENU Next

call type

Networks

Access

Activate

IR port

Info

Speech FAX Data

move clockwise or anticlockwise

select a menu or function

go back one level in the menu system

go back to the standby menu

* This menu appear only when you have turned on the ‘Data menus’ (see

chapter ‘Communicating via the Modem’).

** This menu appears only if your network operator offers the Two Line

service (also called Alternate Line Service) and you have subscribed to it (see chapter ‘The Two Line Service’).

*** These menu functions are slightly different if you have selected a ‘Next

call type’ other than speech.

***

Press… to…

Note! The default display language is English. The English display texts may differ from the US Englsih texts.

The Phone, Keypad and Display

Key Functions

YES, used to:

• make calls, answer incoming calls, put calls on hold and switch between calls.

• confirm selections and inputs.

• enter a selected menu.

ON/OFF and NO, used to:

• turn the phone on or off.

• end calls, reject incoming calls and cancel selections.

• back up one level in the menu system.

NAVIGATION KEY, press LEFT or

RIGHT (or press and hold) to

access and move through the menu system.

CLR (Clear), used to

• erase digitsfrom the display.

• mute the telephone.

• return to standby from the menu system.

NUMERIC KEYS, used to enter

the digits 0–9 and to enter text. The 0 key also enters the international prefix(+) if held down.

STAR, used to:

• enter the*character.

• enter a pause character (p)if held down.

HASH, used to:

• enter the characters # or ¤.

• recall a phone number from the Phone Book.

VOLUME KEYS on the side of the

phone, used to:

• change the earpiece volume during a call.

• reject an incoming call, if pressed twice.

• temporarily disable the active flip

FLIP, used to answer and end calls.

Indicators in the Display

Signal strength. The more bars that are shown, the higher the signal strength.

Battery meter. The fuller the icon, the more power there is.

The keypad is locked.

All incoming calls are diverted to another number.

The ring signal is turned off.

You have received a text message.

You havereceived a voice mail.

The alarm is set.

The linecurrently selected. (Requires that you have the Two Line Service.)

7 8

Antenna

Indicator light

Earpiece

Keypad

Microphone

Connector (for charger and other accessories)

Display

Volume keys

Infrared (IR) port

Navigation key

Active Flip

Congratulations…

…and thank you for choosing the I 888 WORLD, a mobile phone specially suited for the demanding user of communication tools. Retaining the slim, streamlined size that has become associated with the Ericsson family of phones, the I 888 WORLD sets a new standard for others to follow.

Apart from its unique toughness and extraordinary sound quality,the I 888 WORLD comes packed with features that will help you stay ahead. These are just some of the highlights:

• With the in-built modem, you can forget all about PC Cards. It is already inside your phone, guaranteeing you instant access to your PC, laptop or handheld communicator. Wireless if you prefer, thanks to its infrared capabilities.

• Dual band operation allows you to use your phone on the European continent as well as in Africa, the Asia/Pacific region and in the Americas.

Like the other phones from Ericsson, the I 888 WORLD is produced to meet the highest quality standards.

This guide introduces you to your I 888 WORLD and shows you how to get the most out of it. Before you start, please read the ‘Guidelines for Safe and Efficient Use’.

Please note that some of the functions and services described in this user’s guide are depending on your choice of network operator. Should you need additional information onhow to use them, contact your operator.

Mobile Internet

When you are on the move and in need of communication and information, Mobile Internet is the answer.

Mobile Internet is a service supplied by Ericsson to facilitate easy communications and rapid information retrieval, wherever you are. It gives you access to on-line customer services, on-line user manuals, and useful information when you are out travelling. It allows you to down load various communication software which will ensure youachieve optimum results from yourEricsson products.

If you run into any problems, there are help texts connected to the different Mobile Internet pages.

The Internet address to Mobile Internet is

http://mobile.ericsson.com/mobileinternet

To get access to the service you also need a user id and a password. The first time you log on, please use the following:

User Id: mobile Password: internet Note that you must change user id and password the

first time you log on to Mobile Internet.

Press to enter the menu system. See inside the cover. 1

General Information

Operators & Subscription

To be able to use your phone, you need to have a subscription to a network. This is obtained from the network operator.

The services included in your subscription depend on your choiceof operator and/or subscription. Therefore, some of the services and functions described in this manual may not be accessible to you. If you want a complete list of the services included in your subscription, please contact your network operator.

GSM 900/1900 Dual Band

The Ericsson I 888 WORLD is a dual band phone, which means that you can use your phone in two different kinds of networks – the GSM 900 and the GSM 1900 systems.

The GSM 1900 system is used in the US and other parts of the Americas, and the GSM 900 system is used in Europe, the Asia/Pacific region and in some parts of Africa. This means that you can use your I 888 WORLD on six continents.

Consequently, the I 888 WORLD offers you enhanced international roaming, thanks to the additional networks now available when you are out travelling.

The switching between the two systems is done automatically, which means that you can use your phone without ever having to consider which system is being used. This is taken care of by the networks. However, you should note that the functions offered and the net-

work coverage differ depending on your choice of operator and/or subscription.

SIM & PIN

You will obtain a SIM (Subscriber Identity Module) card with your subscription. The SIM card contains a computer chip that keeps track of your phone number, the services you have ordered from your network operator and yourPhone Book information, among other things.

Your SIM card is supplied with a security code or PIN (Personal Identity Number), which you need in order to gain access to the network. Your PIN may also be required when you want to change settings in your phone. Furthermore, some operators may have ser-vices that require a second PIN, your PIN2. You will find your PIN (and PIN2) in the information from your operator.

Every time you turn on your phone, it prompts you to enter your PIN. If the PIN is entered incorrectly three times in a row, the SIM card will be blocked. If this happens you can unlock it by using your PUK (Personal Unblocking Key code), which you also get from your operator.

You shouldbe careful with your PIN, since itis your protection against unauthorized use of your phone and subscription.

2 Press to enter the menu system. See inside the cover.

Preparing Your Phone for Use

The SIM Card

When you register as a subscriber with a network operator, you obtain a SIM card.

SIM cards come in two sizes. One is the size of a credit card, and the other is considerably smaller (about the size of a regular stamp). The I 888 WORLD uses the smaller card. Many operators deliver credit card sized SIM cardswhich have a perforated smallercard that you can take out easily.

Before you can use your phone, you must insert the SIM card into the phone.

To Insert the SIM Card

To insert the SIM card, remove the battery (if attached) and follow these steps:

 Release the SIM card

holder by sliding it in the direction of the arrow.

 Open the holder.

 Slide the SIM card

into the holder. Make certain that the cut corner is top right.

Press to enter the menu system. See inside the cover. 3

 Close the holder.

 Lock the holder by

pressing it down and sliding it in the direction of the arrow in the picture.

The Battery

Your mobile phone comes with a nickel metal hydride (NiMH) battery. The battery is not charged when you buy your phone, but there may be enough power to turn on the phone. We recommend that you charge the battery before you use the phone.

To Attach the Battery to the Phone:



Place the battery on the back of the phone.

 Press the battery upwards and against the

phone until it snaps into place.

To Remove the Battery

Make sure that the phone is turned off before removing the battery (see next chapter). Then:

 Press the catch on

the bottom of the battery.

 Lift the battery up

and away from the phone.

To Charge the Battery

Make sure that the battery is attached to the phone. Then:

 Connect the charger to the mains. (The box

contains several plugs. Use the one that fits the wall socket.)

4 Press to enter the menu system. See inside the cover.

A green indicator on the charger lights up. If not, make sure you have put the plug into the charger correctly. (You may have to press hard.)

 Connect the clear plastic plug on the charger

cable to the charger. It is correctly inserted when it snaps into place.

 Connect the other

end of the cable to the phone according to the picture. The flash symbol on the plug must face upwards. Note that you may have to press hard.

The phone will automatically start charging the battery when you attach the charger. To indicate charging:

• the battery meter in the display is continuously filled and emptied.

• the indicator on top of the phone shows a steady red light (green, if the phone is turned on).

When the battery is fully charged, the battery meter in the display will show full and the indicatoron topof the phone will show a steady green light.

Note! It is possible to use the phone while the battery is being

charged. This will, however, increase the charging time.

To Disconnect the Charger

l Twist the plug con-

nected to the phone upwards and pull it out.

When to Charge the Battery

The nickel metal hydride battery that comes with your phone can be charged whenever you wish without losing performance. This is not the case with the cheaper nickel cadmium type batteries, often sold as accessories from other suppliers. For optimal talk and standby time in the long run, we recommend that you only use Ericsson original batteries with your I 888 WORLD.

To remind you that the battery will soon need to be charged or replaced with a charged one:

Press to enter the menu system. See inside the cover. 5

• an alarm signal (a long beep) sounds and the message ‘Battery low’ appears for ten seconds in the display.

• the indicator light on top of the phone starts blinking red.

Note! If the phone is left turned on, the low battery alarm will

be repeated several times and, finally, the phone will turn itself off when the battery is no longer able to power it satisfactorily. It might be possible to turn the phone on again, but you will not be able to make or receive any calls. You should charge the battery or replace it with a charged one.

6 Press to enter the menu system. See inside the cover.

Turning On the Phone

To turn on the phone:

 Press and hold down the NO (ON/OFF) key until

you hear a click. The display prompts you to enter your PIN.

 Enter your PIN. The digits appear as stars in the

display. If you make a mistake while entering your PIN, erase the wrong digit by pressing the

CLR key.

 Press YES.

If youenter your PIN correctly, ‘ERICSSON’will appear in the display. The phone will then search for a network.

Note! If your PIN is entered incorrectly three times in a row,

the SIM card will be blocked and you will have to unblock it using your PUK code. See chapter ‘Security’.

When a network is found, the phone beeps three times. The indicator light on top of the phone flashes green once every second and your network operator’s name (in most cases abbreviated) is shown in the display. If you have the charger connected, the indicator will show a steady green light instead of a flashing one.

You can now make and receive calls. This is called standby mode.

When No Network Name Is Displayed

If the message ‘Emergency calls only’ is displayed, you are within range of a network but you are not allowed to use it. However, in an emergency, you can call the international emergency number 112 (or 911). See chapter ‘Making and Receiving Calls’.

If the message ‘No network’ is displayed, there is no network within range or the received signal is too weak. You have to move to obtain a sufficiently strong signal.

To Turn Off the Phone

l In standby mode, press and hold the NO

(ON/OFF) key until the display is turned off.

Initial Settings

The first time you turn on your I 888 WORLD, you may want to change the default language and ring level settings, and set the clock.

Display Language

Most modern SIM cards automatically set the display language to the language of the country where you bought your SIM card. If this is not the case, the default language is English.

To change the display language:

 Press the navigation key LEFT or RIGHT until the

‘Settings’ menu appears.

 Press YES to enter the ‘Settings’ menu.  Press the navigation key to the LEFT until the

‘Language’ menu appears.

 Press YES to enter the ‘Language’ menu.  Press the navigation key until you find the

desired language.

 Press YES to select the language.

Press to enter the menu system. See inside the cover. 7

Enter

****

ERICSSON

12:35

ERICSSON

Settings

SETTINGS

Language

(Auto)

LANGUAGE

English

 Press CLR to return to standby mode.

Note! If by accident you end up with your phone displaying a

language youdo not understand, you canreturn to English by pressing

LEFT 0000 RIGHT at any time.

Setting the Time

The time is shown at the bottom of the display. When you buy your phone, the time is normally not set.

If you want to set the time:

 Press the navigation key LEFT until the ‘Clock’

menu appears.

 Press YES to enter the ‘Clock’ menu.  Press the navigation key RIGHT until the ‘Set

clock’ menu appears.

 Press YES to enter the ‘Set clock’ function.  Enter the correct time in hours and minutes and

press YES.

 Press CLR to return to standby mode.

Note! The time is by default presented in the 24-hour format.

If you prefer the 12-hour format, you can change the default setting.

For more information, see ‘Personalizing Your Phone’.

To Set the Ring Signal Level



Press the navigation key RIGHT. The text ‘Ring level’ and a bar representing the

ring signal level appears in the display.

 Press YES to enter the ‘Ring level’ menu.  Use the navigation key to set the ring signal

level.

• Pressing

RIGHT increases the volume.

• Pressing

LEFT decreases the volume.

The phone rings once with the actual setting as you press the navigation key, except for the ‘Off’ and ‘Step’ settings.

 Press YES to save the setting.  Press CLR to return to standby mode.

Tip! Use the volume keys on the sideof the phone to change

the ring level silently.

Note! If you have your I 888 WORLD connected to external

equipment (for example handsfree equipment or a vibrating call alert device), the ring signal level will be set for this situation separately. See ‘Personalizing Your Phone’ for more information.

8 Press to enter the menu system. See inside the cover.

Clock

CLOCK

Set clock

(16:36)

SET CLOCK

(16:36)

11:45

Ring level

(

QQQqqq

)

Making and Receiving Calls

The instructions in this chapter assume that you have turned onyour phone and that youare within range of a network.

Emergency Calls

To make an emergency call:

 If the phone is not on, turn it on by pressing the

NO key until you hear a click.

 Enter the international emergency number 112,

(or 911 if you are in the Americas).

Note! 911 can also be used in areas that use 112 as the inter-

national emergency number, and vice versa.

 Press YES. The display shows ‘Emergency’.

Note! Some operators may require that a SIM card has been

inserted into the phone and, in some cases, that the PIN has been entered as well.

Making Calls

Domestic Calls



Enter the area code and phone number. The digits are shown in the display.

• If you need to erase a digit, press

CLR.

• To erase all digits, press and hold the

CLR key

until all digits have been erased.

 Press YES to make the call. The display shows

‘Calling’, followed by ‘Connecting’.

• When the call is answered, a call time meter in the display shows how long you have been on the phone in minutes and seconds.

• If nobody answers your call or you cannot get through, press

NO. The number is stored in a

memory which makes it easy to repeat the call. (See ‘Redialling a Number’ below.)

• If the number is busy, you can redial it automatically. (See ‘Redialling a Number” below.)

 When you want to end the call, press NO. The

Call Time meter shows the duration of the call for three seconds.

Tip! It is possible to check the duration of the call later on.

See ‘Other Useful Features’.

International calls



Press and hold the 0 key until ‘+’ is displayed. The (+) will automatically be replaced by the

international dialling prefix for the country you are calling from.

 Enter the country code, the area code (without

any leading zero) and the phone number.

 Press YES to make the call.

Note! When you are abroad, your phone will automatically

search for a network that you are allowed to use. Which networks you can use depends on the agreements your operator has signed with the operators in the country you are visiting. See chapter ‘Networks’.

Press to enter the menu system. See inside the cover. 9

0:07

12:47

ERICSSON

Last 1:31

12:49

ERICSSON

012345678

ERICSSON

+4640123456

Checking the first characters

If you have entered more characters than can be seen in the display,the first characters will be replaced by the

symbol. To check the first characters: l press the navigation key

RIGHT.

Receiving a Call

When you receive a call, the phone rings and the indicator light on top of the phone blinks green rapidly. The display shows ‘Answer?’.

If your subscription includes the Calling Line Identification service and the caller’s network sends the number, you will see the caller’s number at the bottom of the display. If the number is stored with a name in the phone book, the name will be shown in the display.

Note! The phone must be turned on and within coverage of a

network before a call can be received.

To Answer the Call



Open the flip. If the flip is already open; press

YES.

 When the call is finished, press NO;

or close the flip.

Tip! To mute the ring signal when you receive a call, press

CLR.

To Reject the Call

There are two ways of rejecting the call:

• Press the

NO key.

• Press the volume key on the side of the phone twice.

The caller will hear a busy tone if the caller’s network supports this function. If ‘Divert on busy’ is activated,

the incoming call is diverted to the number you have specified (see ‘Diverting Incoming Calls’).

Redialling a Number

Your I 888 WORLD conveniently lets you redial the last phone numbers you have called (15 or more, depending on your SIM card). It can also redial a number automatically ifthe connection failed when you first called.

To Redial Previously Called Numbers



Press YES. The display now shows the last dialled number.

 Press the navigation key RIGHT or LEFT until the

number you want to call is shown on the bottom row of the display.

 Press YES to make the call.

Note! If you want to clear the last dialled numbers memory,

do the following:

 Press the navigation key LEFT. The ‘Phone book’

menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT until the ‘Dialled

numbers’ function appears.

 Press YES to select the ‘Dialled numbers’ func-

tion.

 Press and hold the CLR key. The question ‘Erase

all?’ appears.

 Press YES to erase the last dialled numbers from

the memory.

 Press CLR to return to standby mode.

The Automatic Redialling Function

If the connection fails and the receiver’s network supports it, the display shows ‘Retry?’ on the top row and the reason for the failure on the second row.

10 Press to enter the menu system. See inside the cover.

Checking the first characters

If you have entered more characters than can be seen in the display,the first characters will be replaced by the

symbol. To check the first characters: l press the navigation key

RIGHT.

Receiving a Call

When you receive a call, the phone rings and the indicator light on top of the phone blinks green rapidly. The display shows ‘Answer?’.

Note! The phone must be turned on and within coverage of a

network before a call can be received.

To Answer the Call



Open the flip. If the flip is already open; press

YES.

 When the call is finished, press NO;

or close the flip.

Tip! To mute the ring signal when you receive a call, press

CLR.

To Reject the Call

There are two ways of rejecting the call:

• Press the

NO key.

• Press the volume key on the side of the phone twice.

The caller will hear a busy tone if the caller’s network supports this function. If ‘Divert on busy’ is activated,

the incoming call is diverted to the number you have specified (see ‘Diverting Incoming Calls’).

Redialling a Number

To Redial Previously Called Numbers



Press YES. The display now shows the last dialled number.

 Press the navigation key RIGHT or LEFT until the

number you want to call is shown on the bottom row of the display.

 Press YES to make the call.

Note! If you want to clear the last dialled numbers memory,

do the following:

 Press the navigation key LEFT. The ‘Phone book’

menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT until the ‘Dialled

numbers’ function appears.

 Press YES to select the ‘Dialled numbers’ func-

tion.

 Press and hold the CLR key. The question ‘Erase

all?’ appears.

 Press YES to erase the last dialled numbers from

the memory.

 Press CLR to return to standby mode.

The Automatic Redialling Function

If the connection fails and the receiver’s network supports it, the display shows ‘Retry?’ on the top row and the reason for the failure on the second row.

LAST DIALLED

046998877

To redial the number automatically: l Press

YES.

• The number will automatically be redialled

until the call is answered, up to 10 times.

• If you press any key or receive a call, the re-

dialling will be interrupted.

• If the redialling is successful, the phone will

beep and then you will hear a ring signal.

If you do not want to retry, press

NO.

Calling Someone Who Has Called You

If you subscribe to the Calling Line Identification service, and the caller’s network sends the number, the numbers of the last ten answered calls are stored in the phone.

To recall one of the last ten answered numbers:

 Press the navigation key to the LEFT. The ‘Phone

book’ menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT repeatedly until

the ‘Answered calls’ function appears.

 Press YES to select the ‘Answered calls’ function.  Press the navigation key until you find the

number you want.

 Press YES to make the call.

To clear the answered calls memory:

 Press the navigation key to the LEFT. The ‘Phone

book’ menu appears.

 Press YES to enter the ‘Phone book’ menu.  Press the navigation key LEFT repeatedly until

the ‘Answered calls’ function appears.

 Press YES to select the ‘Answered calls’ function.  Press CLR. The question ‘Erase all?’ appears.  Press YES.

Unanswered Calls

If you have received calls but have been unable to answer, the number of unanswered calls will be shown in the display until you press CLR.

Information about the ten last missed calls is saved in your phone’s memory, which makes it possible for you to check when the calls were received. If your subscription includes the Calling Line Identification service and the caller’s network sends the number, you can also find out who called.

To Find Out Who Called and When



Press the navigation key to the LEFT repeatedly until the ‘Mail’ menu appears.

 Press YES to enter the ‘Mail’ menu.  Press the navigation key repeatedly until the

‘Missed calls’ function appears.

 Press YES to enter the ‘Missed calls’ function.  The last caller’s number (if your subscription in-

cludes the Calling Line Identification service) is now shown in the display together with the time (or date) when the call was received. If no information about the caller’s number was received, the display will show one of the following:

• ‘Unidentified’, which means that no information was available.

• ‘Restricted’, which means that the caller wanted to withhold the number.

 To see your other unanswered calls, press the

navigation key repeatedly.

 Press CLR to return to standby mode.

Note! If you check a missed call within 24 hours, the time of

the call is displayed. Otherwise, the time is replaced by the date. You can toggle between date and time by pressing

Press to enter the menu system. See inside the cover. 11

Phone book

ANSWERED 1

+1234567890

ANSWERED 1

+1234567890

ERICSSON

Calls:2

13:52

Mail

MISSED CALLS

13:25

0246193000

MISSED CALLS

14-07-97

Unidentified

To Erase a Number from the Missed Calls Memory



When the information about the call is shown, press CLR.

 Press YES.

Hiding or Showing Your Number

With most common subscriptions, the caller’s number is sentwhen a call is made.This means that the receiver can see your phone number when you make a call. However, some operators offer subscriptions where your phone number is normally hidden.

If you want to change the setting for a particular call, this is possible provided the network you use supports it.

To Hide Your Phone Number for a Particular Call



Enter the phone number you wish to call.

 Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.  Press the navigation key repeatedly until ‘Hide

Id’ appears.

 Press YES to make the call.

To Show Your Number for a Particular Call



Enter the phone number you wish to call.

 Press the navigation key RIGHT.

The ‘Special functions’ menu now appears.

 Press YES to enter the ‘Special functions’ menu.

 Press the navigation key until ‘Send Id’ appears.  Press YES to make the call.

12 Press to enter the menu system. See inside the cover.

Special

functions

SPECIAL FUNC

Hide Id

0246193000

Special

functions

SPECIAL FUNC

Send Id

0246193000

During a Call

Your I 888 WORLD has several functions which you might find helpful while you are on the phone.

To Change the Earpiece Volume

If youwant to change the earpiece volume during acall: l Press the volume keys on the side of the phone

up or down.

• Pressing

UP increases the volume.

• Pressing

DOWN decreases the volume.

See also ‘Personalizing Your Phone’.

To Mute the Microphone

To mute the microphone temporarily during a call:

 Press and hold the CLR key. ‘Mute’ is shown in

the display.

 To resume conversation, release the CLR key.

To Use the Display as a Scratch Pad

If youneed to write down aphone number during a call, you can use the Scratch Pad function in the I 888 WORLD. To do this:

l Enter the number using the numeric keys. When you end the call, the number remains in the dis-

play. You can now call the number by pressing YES or save it in the Phone Book (see chapter ‘The Phone Book’).

Note! If you press any numeric key while on the phone, the

person on the other end of the line will hear a tone.

To Send Tone Signals

To use telephone banking services or control a phone answering machine, you need to use codes. These codes are sent as tone signals (also known as DTMF tones or touch tones).

To send tone signals/codes during a call: l Press the appropriate keys (0–9,*and #).

Tip! You can also save the code together with a number in

the Phone Book. See ‘Creating Your Personal Phone Book’ in the ‘Phone Book’ chapter on how to do this.

Note! If you send tone signals while on the phone, the person

on the other end of the line will hear the tones.

Press to enter the menu system. See inside the cover. 13

Mute

13:52

The Menu System

The menu system of your I 888 WORLD allows you to control thephone’s functions and to customize it to suit your personal preferences.

Each menu contains a list of options; some of these have submenus with additional options.

To help you find your way around the menus, we recommend that you use the fold-out on the inside of the cover.

Moving through the Menu System

The menus are arranged in a continuous loop (see the fold-out), which you move through with the

NAVIGATION, YES, NO and CLR keys.

Press… to…

move clockwise or anticlockwise.

select a menu or a function.

go back one level in the menu system and/or leave a setting unchanged.

go back to the standby menu.

To select a menu or make a setting:

 Press the navigation key LEFT or RIGHT until you

reach the desired menu or function.

 Press YES to enter the menu or to select the

function.

 Press the navigation key to find the desired sub-

menu or to select a setting alternative.

 Press YES to enter the submenu or to confirm

the setting.

Note! If you enter themenu system, but do notpress any keys

in 60 seconds, the phone will return to standby mode.

Tip! Instead of pressing the navigation key repeatedly, you

can press and hold it down until you reach the desired menu or submenu.

Display Text and Symbols

When you move through the menu system, the following hints can help you:

• Capital letters are used to indicate the menu or function selected.

• When

andRare displayed, there are more options you can scroll through with the navigation key.

• Text in brackets indicates the current setting of the function that is shown in the display.

14 Press to enter the menu system. See inside the cover.

SETTINGS

Ear volume

(

QQQqq

)

The Phone Book

The Phone Book in your I 888 WORLD lets you store and recall phone numbers. This means that the phone can store all your important numbers. You do not have to remember them or carry your address book around.

The Phone Book also keeps track of your last dialled numbers and,if you subscribe to theCalling Line Identification service, the last answered numbers. Convenient if you have to call someone back.

When you receive a call and the caller’s number is in the Phone Book, you will see the name in the display.

Tip! Your I 888 WORLD comes with the Ericsson Mobile Of-

fice Suite software. When installed on your computer,

the Mobile Office Suite lets you manage your Phone Book from your computer in a simple way.

You can find more information about the Mobile Office Suite in the chapter ‘The Mobile Office Suite’.

Before You Start

Before you start creating your personal Phone Book, there area few things you need to know.In this section, you will learn about the two different memories and how tostore the numbers with the international prefix.

We also recommend that you at this stage read the section about entering characters, even though you might need to go back to this when you follow the instructions later on.

Phone Book Memories

You can store your phone numbers in two different memories:

• the card memory on the SIM card,

• the phone memory.

Storing yournumbers in the card memory allows you to use the numbers stored on the SIM card even when you change phones, i.e. when you insert your SIM card into another phone.

On the other hand, by storing your numbers in the phone memory, they are always available to you on your phone, even if you change SIM cards.

The memory positions in the card memory are numbered from 1 onwards. The actual number of memory positionsavailable depends on your SIM card.

The phone memory can hold up to 99 phone numbers. The memory positions are labelled ¤1–¤99.

Note! In the ‘Phone book’ menu, press # to enter the ¤ charac-

ter. Outside the ‘Phone book’ menu, you must press and hold down # to enter the ¤ character.

International Numbers

If you intend to use your phone both at home and abroad, you should store all phone numbers as international phone numbers, that is with the ‘+’ sign – which automatically will be replaced by the international dialling prefix for the country you are calling from – followed by the country code, then the area code and the phone number.

• To enter the (+) sign, press and hold 0.

• Omit any leading zero in the area code.

Press to enter the menu system. See inside the cover. 15

STORE 11 John, office +4646123456

Entering Characters

In the phone book you can accompany any number you store with a name. To enter the characters in the name, follow the instructions below.

l Press the appropriate key, 1–9, 0 or #,

repeatedly until the desired character appears in the display.

Press… to get… 1 Space-?!,.:;"'<=>( )1 2 ABCЕДЖаЗ2Γ 3 DEFèÉ3∆Φ 4 GHIì4 5 JKL5Λ 6 MNOÑÖØò6 7 PQRSß7ΠΣ 8 TUVÜù8 9 WXYZ9 0 +&@/¤%$£¥§¿¡0ΘΞΨΩ

# #

For example:

• To enter an A, press 2 once.

• To enter a B, press 2 twice.

Tip! To enter a digit, you can press and hold the numeric

key. To enterthe second letter on the numeric keys directly,

press and hold the upper volume key and press the desired numeric key. To enter the third letter, press the lower volume key instead.

Note! If there is a pause of more than 60 seconds between

entering characters, the phone will return to the standby menu.

To Enter Small Letters

l Enter the letter, for example an ‘A’, and then

press*. An ‘a’ appears.

Small letters now appear until you press

again.

To Check the First Characters

If youenter more characters than can be seen in the display, the first characters will be replaced by thelsymbol. To check the first characters you have entered:

l press the navigation key

LEFT.

Creating Your Personal Phone Book

To Store a Phone Number



From the ‘Phone book’ menu, select ‘Store’.

 Enter a name to accompany the phone number.

Use the numeric keys as described above.

 Press the navigation key RIGHT.  Enter the phone number.  You now have four options:

– To save the number in the card memory, in the

first empty position (displayed in the top righthand corner):

• Press

YES.

– To save the number in the card memory, in a

position you decide:

• Press the navigation key

RIGHT, enter the

position and then press YES.

– To save the number in the phone memory, in

the first empty position:

• Press the navigation key

RIGHT, press the #

key twice and then press YES.

– To save the number in the phone memory, in a

position you decide:

• Press the navigation key

RIGHT, press the #

key once, enter the position and then press

YES.

16 Press to enter the menu system. See inside the cover.

STORE 33 Name: John Doe Enter no: _

STORE 33 Name: John Doe

08111222

STORE ¤16 Name: John Doe

08111222

Tip! If you enter a number in the scratch pad during a call,

you can store it in the Phone Book by selecting ‘Store’ from the‘Phone book’ menu while you have the number in the display.

Overwrite Protection

If you try to store a phone number in a position which already contains a phone number, the message ‘Used Overwrite?’ appears in the display. You then have two options.

To store the number in a different position:

 Press NO.  Enter the new position number.  Press YES

To store the number in the selected position, thus erasing the old number:

l Press

YES.

When the Memories are Full

• If you try to store a phone number when all the positions in the card memory are full, a position number in the phone memory will be suggested on the top row of the display.

• If both memories are full, no position number will be suggested. If you still wish to store the phone number, you have to erase the old number by entering a position that is already occupied.

To Store a Number With a Tone Signal Code

To use telephone banking services or control a phone answering machine, you will need to use codes. These codes are sent as tone signals (also called DTMF tones or touch tones).

If you want to save the phone number in the Phone Book with the codes:

 Follow the instructions on how to store a phone

number until you enter the number.

 After entering the phone number, press and

hold the*key until the pause character ‘p’ appears.

 Enter the code.  If needed, insert another pause, another code

and so on.

 Continue following the instructions on how to

store a phone number.

To make a call with tone signal codes, proceed as described in ‘Making and Receiving Calls’. When you make the call, the phone dials the number, waits until the call is answered and then sends the code. If you inserted another pause and another code, it will pause again, send the next code and so on.

Recalling a Phone Number

The Speed Dialling Facility

You can call the phone numbers that you store in the positions 1–9 in the card memory by entering the position number and then pressing YES. Therefore, you should save positions 1–9 for important numbers.

For example: If youwant to call John, whose number is stored in position 3 in the card memory:

 Enter the digit 3.  Press YES.

To Recall a Phone Number Using the Name



From the ‘Phone book’ menu, select ‘Name recall’.

Press to enter the menu system. See inside the cover. 17

STORE 2

Used

Overwrite?

STORE 34 e: Bankbyphone

040556677p_

+ 49 hidden pages
