ergoline SUN SELECT 1400 Operating Instructions Manual

S U N S E L E C T 1 4 0 0 I N T E L L I G E N T P E R F O R M A N C E

S

U

O

P

X

E

R

E

10 min

T

E

I

M

O P E R AT I N G I N S T R U C T I O N S

Face Cooling

Operating instructions

1014906-00 / us / 10.2013

SUN SELECT 1400

INTELLIGENT PERFORMANCE

Contact information

2/76

Contact information

Technical Service JK Products & Services, Inc.

#1 Walter Kratz Drive
Jonesboro, AR 72401

Phone: [phone] (toll-free)
Fax: [phone]
e-mail: [e-mail]
http://support.jkamerica.com

WARNING!

Read these operating instructions.
Failure to observe these instructions:

• may result in serious injury and death,

• can result in damage to the device and the
environment.

– For the safety of yourself and others, read and observe

all instructions contained herein before operating the
tanning system.

– Please make the instructions and additional information

available to anyone who operates or services the tan­ning system.

Copyright
The copyright remains with JK-Holding GmbH.
The contents may not be duplicated (in whole or part), distributed or utilized

for competition purposes without authorization or disclosed to other parties.
The right to make technical changes in regard to the figures and information

contained in this instruction manual is reserved!

Table of contents

10/2013 1014906-00 Operating instructions – 3/76

Table of contents

Contact information ....................................................................................... 2

Table of contents ........................................................................................... 3

1 Important information on tanning ................................................ 6

1.1 Skin types ....................................................................................... 6

1.2 Tanning times .................................................................................. 6

2 General ........................................................................................... 7

2.1 Definitions ....................................................................................... 7

2.2 Identify your tanning device ............................................................ 7

3 Safety notes ................................................................................... 8

3.1 Description of warning signs ........................................................... 8

3.2 Instructions pertaining to a risk of fire, electric shock, or injury ....... 9

3.3 Instructions pertaining to a risk of damage to the machine ........... 11

4 Information for the studio operator ........................................... 12

4.1 Intended use ................................................................................. 12

4.2 Foreseeable misuse ...................................................................... 12

4.3 Obligations of the studio operator ................................................. 12

4.4 Staff training .................................................................................. 13

4.5 Guidelines ..................................................................................... 13

4.6 Installation location ........................................................................ 13

4.6.1 Ventilation ..................................................................................... 13

4.7 Export ............................................................................................ 13

4.8 MP3 music .................................................................................... 14

4.9 Disposal ........................................................................................ 14

4.9.1 Environmental regulations – disposal of lamps ............................ 14

4.10 Instruction signs on the device ...................................................... 14

4.11 Technical modifications ................................................................. 14

5 Description .................................................................................. 15

5.1 Scope of delivery ........................................................................... 15

5.1.1 Optional ......................................................................................... 15

5.2 Equipment ..................................................................................... 15

5.3 Device description ......................................................................... 16

5.4 Accessories (optional) ................................................................... 17

5.5 Function description ...................................................................... 17

6 Operation ..................................................................................... 19

6.1 Mandatory reading ........................................................................ 19

6.2 Use the tanning device – but use it properly! ................................ 20

6.3 Operation overview ....................................................................... 21

6.3.1 Operating panel and operating handle .......................................... 21

Table of contents

4/76

6.3.2 Control Center ............................................................................... 22

6.3.3 Navigation ..................................................................................... 22

6.4 Operating structure ........................................................................ 24

6.5 Functions ....................................................................................... 24

6.5.1 Operating panel ............................................................................. 24

6.5.2 SUN SELECT ................................................................................ 26

6.5.3 SUNSELECT setting with the outer interface ................................ 27

6.6 Start ............................................................................................... 28

6.6.1 Preparation time ............................................................................ 28

6.6.2 Interrupt or end tanning session .................................................... 28

6.7 Connect MP3 player ...................................................................... 29

7 Cleaning and maintenance ......................................................... 30

7.1 Safety instructions for cleaning and maintenance ......................... 30

7.2 Faults ............................................................................................. 31

7.3 Cleaning ........................................................................................ 32

7.3.1 Disinfection .................................................................................... 32

7.3.2 Cleaning of surfaces ...................................................................... 32

7.3.3 Filter panels and lamps ................................................................. 33

7.4 Cleaning plan ................................................................................ 33

7.5 Maintenance .................................................................................. 34

7.5.1 Acrylic panel .................................................................................. 35

7.6 Maintenance plan .......................................................................... 35

7.7

Cleaning and maintenance work preparation ............................... 38

7.7.1 Service kit ...................................................................................... 38

7.7.2 Lift up the acrylic panel and remove the partition .......................... 39

7.7.3 Remove the canopy panel ............................................................. 40

7.7.4 Remove the side section panel ..................................................... 41

7.7.5 Open the bed base ........................................................................ 42

7.8 Instructions for replacing the lamps ............................................... 43

7.8.1 Changing the chip card ................................................................. 43

7.8.2 Low pressure lamps ...................................................................... 44

7.8.3 Starter ............................................................................................ 45

7.8.4 High pressure lamps and filter panels ........................................... 45

7.9 Cleaning or replacing UV lamps in the base ................................. 47

7.10 Cleaning or replacing the UV lamps in the side section ................ 47

7.11 Cleaning or replacing UV lamps and filter panels

in the canopy ................................................................................. 48

7.12 Cleaning or replacing the UV lamps and filter panels in the

shoulder tanner ............................................................................ 49

7.13 Cleaning the filters in the base ...................................................... 51

7.14 Cleaning the canopy filter mats ..................................................... 52

7.15 Air conditioning: Empty the condensation tank and

clean the filter ................................................................................ 53

7.16 AQUA / AROMA SYSTEM maintenance ....................................... 56

7.16.1 Changing the AROMA canister ..................................................... 56

Table of contents

10/2013 1014906-00 Operating instructions – 5/76

7.16.2 Replacing the AQUA SYSTEM canister ........................................ 57

8 Technical data ............................................................................. 59

8.1 Power rating, electrical specifications and noise level .................. 59

8.2 Dimensions ................................................................................... 60

8.3 Lamp configuration ........................................................................ 61

8.3.1 SUN SELECT 1400 INTELLIGENT PERFORMANCE ................. 61

8.4 Spare parts and accessories ......................................................... 62

9 JK-Products, Inc. – Limited Warranty ....................................... 63

9.1 Limited Acrylic Warranty ............................................................... 64

9.2 Warranty Claims ............................................................................ 64

9.2.1 Policy & Procedures ...................................................................... 64

9.2.2 Labor Warranty Claim/Credit Procedures ..................................... 65

9.3 Limited Lifetime Warranty ............................................................. 66

10 Appendix ...................................................................................... 69

10.1 Signs and stickers on the device ................................................... 69

11 Index ............................................................................................. 73

Important information on tanning

6/76

1 Important information on tanning

1.1 Skin types

Skin type I (Sensitive):

Invariably gets sunburn, accepts little natural sunlight and does not tan.

Skin type II (Fair):

Gets sunburn easily and severely, tans minimally or lightly and peels.

Skin type III (Average):

Often referred to as 'Average' complexion, gets moderate sunburns and tans
about average.

Skin type IV (Brown):

Seldom gets sunburns, tans easily and above average with each exposure.

Skin type V (Dark Brown):

This individual's system rarely gets sunburns, tans easily and substantially.

1.2 Tanning times

This product is in conformity with performance standards for sunlamp
products under 21 CFR 1040. Adhere to the following tanning times. The SUN
SELECT settings adjust only the exposure rate, see page 26.

Genera

l

10/2013 1014906-00 Operating instructions – 7/76

2 General

2.1 Definitions

Operator

People who provide tanning devices to users on a commercial basis. The
operator is responsible for the orderly operation of the device as well as com­pliance with the maintenance intervals.

User

A person who uses the tanning device at a commercial location.

Staff

People who are responsible for the operation, cleaning as well as general
maintenance work and who instruct the users in the operation of the devices.

Electrician

A person with suitable professional training, knowledge and experience which
enables them to identify and avoid the dangers which can arise from working
with electricity.

Authorized, trained and qualified staff

Qualified staff from an external company who have been trained and author­ized by the manufacturer for assembly and maintenance work with specific
tanning devices.

2.2 Identify your tanning device

For contact with Customer Services, please write down the device number of
your tanning device, see page 69.

Safety notes

8/76

3 Safety notes

3.1 Description of warning signs

Danger notices, damage to persons:

DANGER!

Type and source of danger, e.g. 'DANGER – High
voltage!'

Description of the consequences, e.g. 'You can be killed or
injured by an electric shock!'

Countermeasures:
– Disconnect device from power supply before opening.
– Do not reach into the inside with the device switched

on.

Warning notices, damage to persons:

WARNING!

Type and source of danger, e.g. 'WARNING – hot
surface!'

Description of the consequences, e.g. 'You can burn your
hand (skin, face)!'

Countermeasures:
– Do not touch hot parts and nearby surfaces.
– Wait until hot parts and surfaces have cooled down.

Caution notices, damage to property:

CAUTION!

The word 'Caution' with this label points out that danger for
devices, materials and the environment can be expected
here.

Important information:

NOTE:

This symbol does not identify safety notices, but states in­formation for a better understanding of the processes.

Safety notes

10/2013 1014906-00 Operating instructions – 9/76

3.2 Instructions pertaining to a risk of fire,
electric shock, or injury

DANGER – HIGH VOLTAGE!

You can be killed or injured by an electric shock!

Assembly and electrical connection must comply with
national and local regulations.

– The device may only be assembled, installed, upgraded

or repaired by specially trained and instructed person­nel.

WARNING!

Unprotected tanning may result in eye injury and eye
diseases!

The unprotected eye can become inflamed on the surface,
and in certain cases the retina can be damaged by exces­sive radiation. Cataracts can form after repeated exposure
to radiation.

– Inform users to use the included protective goggles

that block UV.

WARNING!

Follow instructions!

Failure to use protective eyewear may result in severe burns
or other eye injury. If discomfort develops, discontinue use
and consult a physician.

–

A

person who does not tan in the sun most likely will not
tan from the use of this device. Persons with very sensi­tive skins (skin type I) must not use the unit as their skin
may be too sensitive for the lowest dosage. Damage to
the skin (e.g. sunburn) may occur.

– Individuals with acute sunburn, individuals who have

had or have skin cancer, or individuals who are at in­creased risk of skin cancer, must not use the system.

– Seek medical advice if you experience any unexpected

effects, including itching, from using this UV device.

– The tanning device must never be used if a filter panel

is missing or damaged, or the timer is defective!

– UV light from the sun or UV systems can cause injuries

to the skin or eyes. This effect is dependent on the sen­sitivity of the individual's skin and on the type and
amount of UV light.

– As with natural sunlight, overexposure can cause eye

and skin injury, sunburn, and allergic reactions.

– Repeated exposure may cause premature aging of the

skin and skin cancer.

Safety notes

10/76

– Medications (taken internally or otherwise) or cosmetics

applied to the skin, may increase sensitivity to ultravio­let light.

– A person having a history of skin problems should con-

sult a physician before use.

WARNING!

Danger of long-term consequences!

– Overexposure should be avoided.
– Children may not use this device.
– The following applies to minors under the age of 18

years: Only use tanning devices in agreement with a
parent or guardian, or after consulting a physician.
Check with your state regarding tanning laws for mi­nors!

– While there is no immediate clinical evidence of UV

exposure and its effects upon expectant mothers, it is
strongly advised that expectant mothers be discouraged
from using the tanning unit.

WARNING!

Infections can be transferred through skin contact.

All items/equipment components, with which the user can
come into contact during tanning, must be disinfected after
every tanning session:

– Protective goggles
– Acrylic panel
– Handles and control panel
– MP3 cable
– Adjustable air nozzles
– Use only approved cleaners to disinfect the tanning

system and its components.

Safety notes

10/2013 1014906-00 Operating instructions – 11/76

NOTE:

Occasionally, persons using the tanning device will experi­ence a slight reddening of the skin – usually in small patches
– after the second or third session. This redness is often
accompanied by an itching sensation. This may be nothing
more than a very limited heat 'rash' caused by heat from the
lamps within the device and it should go away within
approximately 24 hours and not reappear. This rash can
be lessened or prevented by applying moisturizing lotion to
the affected area after the tanning session is completed.

 Follow instructions.

 The time between the first two tanning sessions must be

at least 24 hours.

 Increasing tanning also requires an extension of the

exposure time (= radiation time). After a certain degree
of tanning has been achieved a further intensification is
not possible. The session time may not be extended to
exceed the scope of the permissible radiation doses!
Only a certain degree of tanning, dependent on the skin
type, can be achieved without endangering your health.

 Inform users about proper tanning.

3.3 Instructions pertaining to a risk of
damage to the machine

CAUTION!

Danger of overheating by obstruction of the air routing!

– Do not change, obstruct or block the air inflow and

outflow area to the device or make any unauthorized
changes to the device. The manufacturer shall bear no
liability for damage or injuries resulting from such ac­tions.

– Before putting a tanning device into operation, the

transport pallet must be removed from under the de­vice. Danger of overheating by obstruction of the air
routing.

Information for the studio operator

12/76

4 Information for the studio operator

4.1 Intended use

The tanning device is intended exclusively for cosmetic tanning of the human
skin.

 This device is used for tanning one adult person at a time.
 The user must wear suitable eye protection to block UV radiation during

tanning.

Any other use shall be considered improper. The manufacturer cannot be
held liable for damage or injuries resulting from misuse. The operator bears
the sole risk for this.

The proper use also includes compliance with the manufacturer's instructions,
operating and maintenance conditions. This device may only be operated,
maintained and repaired by persons familiar with these tasks and who are
aware of the dangers involved.

4.2 Foreseeable misuse

The following uses of the device are explicitly prohibited:

 Multiple people may not use the device at the same time.
 People with body weight of more than 300 lb (135 kg) may not use the

device.

 Exceeding the specified tanning times may result in burns and long-term

skin damage.

 When the device is in use no other people may remain in the room. This

includes both children and adults.

4.3 Obligations of the studio operator

 As the operator you are responsible for informing users on possible risks

of tanning.

 All danger and safety labels attached to the device must be observed! Do

not remove them!

 No safety equipment (e.g. panel switch) may be removed, deactivated, or

otherwise bypassed as it can impair the safe operation of the device!

 The device may only be used when in completely operational condition!
 It is the operator's responsibility to ensure the tanning system is handled

properly.

Information for the studio operato

r

10/2013 1014906-00 Operating instructions – 13/76

4.4 Staff training

As the operator you are obligated to train your personnel and instruct them in
the established legal and accident prevention regulations. Ensure that your
staff have understood and observe these instructions. This includes:

 information regarding intended use and foreseeable misuse
 safety instructions
 operating instructions
 cleaning and maintenance instructions

– Please make the instructions and additional information from the manu-

facturer available to the staff at their workplace.

– Regularly check your staff's safety consciousness of the risks, taking into

account your operating instructions.

– Please ensure that the cleaning intervals are complied with, in particular

cleaning after every use.

– Please ensure that your staff provide your customers with appropriate

advice, in particular regarding tanning times, possible risks and the oper­ation of the device.

4.5 Guidelines

This product is in conformity with the performance standards for sunlamp
products under 21 CFR 1040.20, FDA and listed with ETL and CAN/CSA 22.2
No. 224.

4.6 Installation location

4.6.1 Ventilation

CAUTION!

Danger of failure!

Danger of overheating by obstruction of the air routing.
– Observe the ventilation information to avoid serious

system malfunctions.

You can obtain data regarding the air supply and ventilation from the custom­er service department (see page 2).

4.7 Export

This device is exclusively intended for use in the USA and Canada and may
not be exported to other countries and operated there! The manufacturer
assumes no liability whatsoever in the event of non-compliance. High liability
risks may occur for the exporter and/or the operator in the event of noncom­pliance.

Information for the studio operator

14/76

4.8 MP3 music

The personal use of an MP3 player or a smartphone during tanning is not a
public broadcast in copyright terms, so that there is no obligation for registra­tion or payment by the studio owner to the corresponding copyright owning
company. Copyright laws apply to the owner of the MP3 player or smart­phone.

The same regulations apply for the official use of MP3 music files as for other
music sources: As studio owner you are only allowed to use original audio
obtained from legal sources. Proof of the legitimacy of any MP3 audio used
should be available for viewing upon demand of any regulatory body. Please
refer to http://www.riaa.com for more information.

NOTE:

Pre-recorded SD cards which are delivered as accessories
for a JK audio system are also subject to payment obligation
for commercial usage.

4.9 Disposal

4.9.1 Environmental regulations –
disposal of lamps

UV low pressure lamps and UV high pressure lamps contain fluorescent ma­terials and other waste containing mercury.

According to the national waste disposal laws and in accordance with the
municipal waste regulations, proof must be provided of the proper disposal of
UV lamps.

Contact your local environmental agency for assistance with the disposal of
UV lamps.

4.10 Instruction signs on the device

See Appendix page 69.

4.11 Technical modifications

The device has been constructed in accordance with current safety regula­tions. The illustrations and specifications on these instructions are subject to
technical modifications which are required in order to improve the device.

Unauthorized modifications and changes to the device and its control unit are
prohibited.

Use only OEM spare parts.

Description

10/2013 1014906-00 Operating instructions – 15/76

5 Description

5.1 Scope of delivery

 Tanning device
 Lamps
 Shoulder tanner with audio system (with Voice Guide)
 Air conditioning system
 Connecting lead
 Protective goggles
 Suction cup for filter panels
 Allen-key
 Technical documentation (folder with instructions, brochures for error

codes and default settings and additional documentation)

5.1.1 Optional

 Central exhaust air socket

5.2 Equipment

Device equipment varies depending on the model.
In this description, all standard and optional components/functions are taken

into account which must be observed during operation and/or when perform­ing maintenance.

The control panel also differs according to the varying equipment:
Only those buttons that are visible can be operated, i.e. the corresponding
function must be included in the device's equipment.

Description

16/76

5.3 Device description

1. Adjustable air nozzles – Facial cooling

2. Facial tanner (UV high pressure lamps + UV low pressure lamps)

3. Shoulder tanner with audio system (with Voice Guide)

4. Headphones and MP3 connection

5. Acrylic panel base

6. Partition

7. UV low pressure lamps, base

8. Body cooling air nozzles, foot end

9. UV low pressure lamps, side section

10. UV low pressure lamps, canopy

11. Interior lighting (LED)

12. Nozzles AQUA / AROMA SYSTEM

13. Body cooling air nozzles

14. Operating handle

15. Display unit

16. Control center

17. Accent lighting, canopy (LED)

18. Accent lighting, front panel (LED)

19. Enclosed tanning tunnel

Description

10/2013 1014906-00 Operating instructions – 17/76

5.4 Accessories (optional)

1. Enclosed tanning tunnel

2. Central exhaust air socket

3. Shoulder tanner with audio system (with Voice Guide)

5.5 Function description

Tanning

The primary technical components of a tanning device are an artificial source
of UV radiation, a variety of filters and reflectors as well as a mechanical
structure with a defined active surface.

Different tanning results can be achieved in varying strength tanning devices.
This is due to the different strength UV lamps and the different UV-A and UV­B proportions of the UV radiation. The UV-A proportion primarily generates a
superficial tan, which appears rapidly and is intensive but also fades more
rapidly, the UV-B radiation is primarily responsible for more long-term tanning
results. The disadvantage of the UV-B radiation is that the tan does not be­come visible until one or two days after visiting the tanning salon. Therefore,
the appropriate tanning device is to be selected depending on the desired
tanning goal.

The tanning devices described here primarily emit UV-A radiation and are
equipped with additional UV-B lamps (low pressure UV lamps in the face
tanners).

Description

18/76

NFC CONNECT

Near field communication (NFC) is a communication standard between
smartphones and similar devices that allows contactless data exchange.
Communication is also possible between an NFC device and an unpowered
NFC chip.

The NFC point of this tanning device for example may be used to store basic
settings on a chipcard. These settings can be read for the next session and
may be changed if necessary.

Operation

10/2013 1014906-00 Operating instructions – 19/76

6 Operation

6.1 Mandatory reading

Always read and follow all instructions for proper usage prior to allowing any­one to use the tanning device. The operating instructions included with this
device must always be followed to prevent possible injuries.

Inform users

– to use provided UV-blocking protective eyewear whenever the equipment

is energized.

– to follow the exposure schedule in accordance with their skin type. Fail-

ure to do so may result in overexposure.

A tanning system is not a toy. You cannot vary the strength of the lamps in
your unit.

Should you have any questions regarding the proper use of your tanning
system, contact Global Service USA at:

Phone: [phone] (toll-free)
Mon - Fri. 8:00 a.m. to 7:00 p.m. (CT)
Sat. 8:00 a.m. to 3:00 p.m. (CT)

WARNING!

Danger of skin injuries and skin diseases.

– The tanning device must never be used when a filter

panel is missing or damaged, or the timer is defective!

NOTE:

When describing the operation, the tanning device is often
shown with the canopy open. During tanning the canopy
must always be closed.

Proper operation is not possible with the canopy open.

Operation

20/76

6.2 Use the tanning device – but use it
properly!

A few things need to be noted to in order to obtain maximum enjoyment from
a tanning device. Here are some answers to frequently asked questions.

Make-up in the tanning device?
Please do not wear make-up. Clean skin absorbs UV light better.
A wide variety of materials is found in cosmetics. Whether these are emulsifi-

ers, greases, or fragrances - in conjunction with UV radiation, these can
cause skin allergy reactions.

Remove all make-up. This is essential. Make-up clogs the pores in the face.
The UV light from a tanning device re-opens these clogged pores so that not
only does the light penetrate the skin, but also the allergenic components of
the make-up.

A further negative consequence of make-up is that the appearance of the skin
deteriorates irreversibly over a period of time. However good make-up looks ­in conjunction with UV light, it causes more harm than good. Therefore re­move all make-up before a session in your tanning device - it will be much
better applied afterwards.

Showering after leaving the tanning device?
The browning is in the skin, not on it. Therefore you cannot wash it off. Treat

your skin to a moisturizing cream after showering.

Are medications and the tanning device compatible?
It is known that some medications increase the skin's sensitivity to UV light.

This probability is particularly high with antibiotics, sulphonamides, psychiatric
drugs, tranquillizers, anti-diabetes treatments and diuretics. Sun creams
which contain psorale or kumarin also increase skin sensitivity. If you are in
any doubt, first ask your doctor - then you can enjoy the sun at no risk.

Contact lenses in the tanning device?
The answer is: Yes! Like any other tanning device user, contact lens wearers

should also wear special protective goggles which protect the eyes against
UV radiation. To guarantee better protection, wearers of glasses and contact
lenses can ask their optician for exchange contact lenses with UV protection.
The UV-A and UV-B filters built into exchange contact lenses will protect the
cornea and the internal parts of the eye against almost 100 % of the energy in
UV radiation.

This will benefit tanning device users not only in the open air, but on the tan­ning device itself. You can wear these contact lenses on the tanning device
without any restrictions. For more information, ask your optician or optome­trist.

Operation

10/2013 1014906-00 Operating instructions – 21/76

6.3 Operation overview

6.3.1 Operating panel and operating handle

1. START/STOP button

2. Navigation unit

3. Temptronic indicator

4. Body fan indicator

5. Facial fan indicator

6. Display – Functions …

7. Facial tanner indicator

8. AROMA indicator

9. AQUA SYSTEM indicator

10. Volume indicator

11. Audio system/channel indicator

12. Voice Guide indicator

Operation

22/76

6.3.2 Control Center

1. NFC-point (see page 17)

2. Navigation unit

3. Display

4. SUN SELECT tanning level 1-3 (see page 27)

5. SUN SELECT skin type I-III (see page 26)

6. Hidden reset button

6.3.3 Navigation

Navigation unit – Control Center

Acknowledge selection.
This button's availability is displayed on the Control Center,
depending on the function that has been selected.

Select device function.

Functions or settings can be activated, deactivated or
changed.

NFC point
Data transfer via near field communication – individual set-

tings may be stored on a chipcard and be reloaded for the
next session.

Information about the setting options can be found in the separate user man­ual ‘Control center’ (order no. 1014640-..).

Operation

10/2013 1014906-00 Operating instructions – 23/76

Navigation unit – operating handle

The tanning device is operated using the buttons mounted in the operating
handle in the canopy.

Switch tanning on and off, pause.

Confirm function.
This button's availability is displayed on the screen, depend­ing on the function that has been selected.

Select device function
(go to indicator).

Select the sub-function (if available).
Alter the setting (for progress bar display),
e.g. regulating the temperature.
Change music title or studio channel (from default mode).
The availability of these buttons is displayed on the screen,
depending on the function that was selected.

All of the indicators displayed on the screen are illuminated in default mode
after the tanning device starts up.

The relevant indicator will start to flash after a device function has been se­lected. The settings or selection options available for the selected function will
be displayed on the screen, see 'Operating structure' on page 22.

NOTE:

If a button is not pressed within 8 seconds, the settings re­turn to default mode.

Operation

24/76

6.4 Operating structure

6.5 Functions

6.5.1 Operating panel

Function Indicator selection /

key sequence

Description / Display Information

1. UV lamps

START/STOP
Switches the UV lamps on / off
during the tanning session

The tanning time continues to run
if the UV lamps are switched off
during tanning session.

3. Temptronic

Regulate the temperature,
levels 1 - 9

The acrylic panel will be cooled with­out adjustment control if the auto­matic air conditioning (Temptronic)
fails. The user can only switch the
cooling system on or off in this case.

3. Air conditioning
(Temptronic)
failure

Switch the air conditioning off:
hold button down

Switch the air conditioning on

4. Body fan

Regulate the body fan,
levels 1 - 9

5. Facial fan

Regulate the facial fan,
levels 1 - 9

The face cooling air

nozzles can be adjusted manually.

Operation

10/2013 1014906-00 Operating instructions – 25/76

Function Indicator selection /

key sequence

Description / Display Information

7. Facial tanner

Regulate the facial tanner,
levels 1 - 4

Switch the facial tanner off,
hold button down:
'Facial tanner off? OK'

Switch the facial tanner on

1 minute until up to maximum power,
then return to the previous setting
before switching off.

8. AROMA

Switch the AROMA on:
'Aroma on? OK'

Switch the AROMA off:
'Aroma off? OK'

9. AQUA
SYSTEM

Switch the AQUA SYSTEM
head nozzle on:
'Head on? OK'

Switch the AQUA SYSTEM
body nozzle on:
'Body on? OK'

Switch the AQUA SYSTEM
head and body nozzles on:
'Head + Body? OK'

Switch the AQUA SYSTEM off:
Off? OK'

With 'Switch AQUA SYSTEM off', the
individual program points can be
deactivated.

The AQUA SYSTEM head and body
nozzles can be switched on individu­ally one after another or both at the
same time with 'Head + Body'.

10. Volume

Volume control

11. Audio system

Select audio system:
A: Own music, MP3 player
B: Track selection,
'Music' SD-card
C: Studio channels,
externally connected system
(e.g. CD/DVD player)

Example:
Select the studio channel as
the audio system
'Studio channel on? OK'

Changing the music track or
studio music channel

Selecting a specific audio system
automatically deactivates the
others.

12. Voice Guide

Switch the Voice Guide off:
'Voice Guide off? OK'

Switch the Voice Guide on:
'Voice Guide on? OK'

The Voice Guide provides acoustic
device operating help and is only
available if an audio system is fitted.
Voice Guide is switched on as a
standard item during stand-by and
tanning.

Operation

26/76

6.5.2 SUN SELECT

SUNSELECT allows you to preselect your skin type and your preferred tan­ning level. The SUNSELECT control panel is part of the Control center (see
page 22).

A Voice Guide will assist you during operation.

NOTE:

Without selection the unit will automatically start with the
lowest tanning level and skin type fair.

The default setting after each tanning session is also tanning
level 1 and skin type fair.

NOTE:

The SUNSELECT setting can be changed within
two minutes after starting the tanning session.

The SUNSELECT settings adjust the exposure rate and not the tanning time.
The tanning time is set as usual and must correspond to the times given in
the exposure label, see page 6.

The unit emits the maximum exposure with the setting skin type brown and
tanning level 3. The distinction between the settings is very subtle.

Operation

10/2013 1014906-00 Operating instructions – 27/76

6.5.3 SUNSELECT setting with the outer interface

Skin type Tanning level

fair tanning level 1

average tanning level 2

brown tanning level 3

– Choose your skin type by pressing the button.
– Select the desired tanning level by pressing the button.

Example:

A person with average skin type but without existing tan chooses skin
type average and tanning level 1 to minimize the risk of sunburns.

After several tanning sessions the person may choose tanning level 3.

NOTE:

This unit is equipped with 'soft touch buttons'.

Reset SUNSELECT

– Press the hidden button next to

for more than 3 seconds.

Operation

28/76

6.6 Start

The device is started automatically with an internal or external timer.

NOTE:

Timer instructions see separate manual
(order no. 1008370-..).

6.6.1 Preparation time

Before the UV lamps turn on, you have a few minutes to prepare yourself.
During the preparation time you can switch on the UV lamps at any time by
pressing the START/STOP button.

– Remove your clothes and all jewelry.
– Remove make-up and other cosmetics.
– Remove glasses. Contact lenses can be worn under the protective

goggles.
– Put on the protective goggles.
– Lie down on the bed surface.
– Close the canopy.
– Press the START/STOP button.

Settings on start-up:

 UV lamps
 Facial tanner
 Shoulder tanner
 Body cooling
 Facial cooling
 Audio system
 Voice Guide

6.6.2 Interrupt or end tanning session

The tanning session ends automatically after the preset time has run down.
The internal body cooling fan continues to run for approx. three (3) minutes to
sufficiently cool the device.

– To interrupt a tanning session, press and hold button START/STOP any-

time during a session.
– Press START/STOP again to restart the lamps.

Operation

10/2013 1014906-00 Operating instructions – 29/76

6.7 Connect MP3 player

DANGER!

Danger of hearing damage!

Using earphones or headphones at high volume can result
in permanent hearing damage.

– Do not set the volume too high.

The user can connect their own private MP3 player or smartphone to the
device.

1. Jack plug (JK Part # 4630911001-..) provided for use by the studio opera­tor (2 x 3.5 mm stereo jack plug).

2. MP3 player or smartphone connection: see the documentation from the
manufacturer of the MP3 player or smartphone.

Connecting:

– Insert the MP3 cable (stereo jack plug) in the audio system.
– Plug the MP3 cable into the MP3 player or smartphone.
– Select the music title and then start.
– Where necessary, set the volume level on the MP3 player or smartphone

so that the sound signal from the MP3 player or smartphone is recog­nized by the audio system.

CAUTION!

The heat might damage your MP3 player or smartphone!

– Do not position the unit so that it receives direct tanning

radiation.

CAUTION!

Cable may be torn off, connectors may be damaged!

– Do not pull on cable when unplugging MP3 player or

smartphone.

Cleaning and maintenance

30/76

7 Cleaning and maintenance

7.1 Safety instructions for cleaning and
maintenance

DANGER – HIGH VOLTAGE!

You can be killed or injured by an electric shock!

During maintenance work there is a risk of touching live
parts and receiving a fatal electric shock.

– Disconnect device from power supply before opening.
– Do not reach behind covers and do not open the device

with the device switched on.

– Refit any safety devices (e.g. switches) after the work

has been completed.

If work is to be performed on the devices, they must be deenergized. That

means that all live cables must be switched off.
Switching off the device alone is insufficient, as certain points may remain

energized. Therefore, switch off fuses before performing any work and – if
possible – remove them.

Accidental reactivation can result in serious accidents. Immediately after
deenergizing, secure all switches or fuses used for deenergizing against be­ing switched on again.

– Lock the fuse box with a padlock.

In case of circuit breakers which cannot be unscrewed, a strip of adhesive

tape may be applied over the actuation lever with the wording 'Do not switch,
danger!'.

A prohibition sign with the text:
'Work in progress!'

'Place: ..............................'

'Sign may only be removed by: ............'

must always be securely mounted immediately.

It is imperative that you, the owner and/or operator, check all components for
any signs of wear which may occur through normal use.

– Observe the cleaning and maintenance schedule specified in the tables

in Chapter 7.4 and 7.6.

– Only replace UV low-pressure lamps with the original type or compatible

lamps.

Should you require any assistance or need additional information, please
call Global Service USA at 800-445-0624 (toll-free), Monday through Friday
8:00 a.m. - 7:00 p.m. CT, Saturday 8:00 a.m. to 3:00 p.m.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 31/76

WARNING!

Injuries and damage due to improper maintenance!

If the maintenance intervals for the UV lamps are exceeded
or incompatible UV lamps are installed, the share of UVB
radiation may increase. Sunburn and other skin damage
may result.

Improper maintenance can cause the device to be damaged
or to become unusable.

– Always comply with the specified maintenance inter-

vals.

– Follow the cleaning instructions.

WARNING!

Danger of burns from hot lamps and device parts!

If the tanning device was operated before being switched off
and opened, lamps and housing parts may be hot.

– Before replacing lamps or other spare parts, wait until

lamps and metal parts of the device have cooled down
sufficiently.

WARNING!

Danger of pinching!

When opening and closing the panels and covers, you can
pinch your fingers.

7.2 Faults

Error codes are output to the display to simplify troubleshooting:

 If a fault occurs, the error code flashes on the display.
 If several errors occur, the error messages are displayed alternately.
 Error elimination is acknowledged by pressing the START/STOP button.
 If the error cannot be cleared, contact Customer Service (see page 2) or

your local service provider.

More detailed information regarding the error description and solutions is
available in 'Error Codes' (order no. 1011831-..).

Cleaning and maintenance

32/76

7.3 Cleaning

WARNING!

Infections can be transferred through skin contact.

All items/equipment components, with which the user can
come into contact during tanning, must be disinfected after
every tanning session:

– Protective goggles
– Acrylic panel
– Handles and control panel
– MP3 cable
– Adjustable air nozzles
– Use only approved cleaners to disinfect the tanning

system and its components.

7.3.1 Disinfection

For hygienic proper disinfection, use a specially developed disinfectant clean­er (such as Lucasol).

NOTE:

For thorough disinfection, the product must be allowed to
remain in contact with the surface being disinfected for a
specified amount of time. Follow the manufacturer's instruc­tions for use.

7.3.2 Cleaning of surfaces

Acrylic panel

CAUTION!

Do not rub with a dry cloth – danger of scratching!

– For hygienic proper cleaning of acrylic surfaces, use a

specially developed disinfectant cleaner.
Other cleaning agents, especially concentrated disin­fectants or solvents (e.g. Lysoform, ethyl alcohol or oth­er liquids containing alcohol) must never be used for
cleaning.

Failure to observe this voids all warranty claims.

CAUTION!

Acrylic panels unusable due to soiling!

Soiling on the panels is burned in by the hot lamps and
results in the long term in unserviceable panels.

– Remove fingerprints and other soiling carefully.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 33/76

Plastic surfaces
For cleaning the remaining painted and unpainted plastic surfaces, it is best to

use warm water and a cloth. Never use aggressive cleaning agents contain­ing alcohol or essential oils. These may lead to damages not covered by the
warranty.

During cleaning a slight discoloration of the cloth by the rubber seals should
be expected for production-related reasons.

Prevent damage to the acrylic and plastic surfaces.

– Remove rings, watches, bracelets etc. before starting cleaning work.

7.3.3 Filter panels and lamps

 UV low pressure lamps and filter panels can be cleaned with a damp

cloth (without additional cleaning agents) where necessary.

 UV high pressure lamps can be cleaned with ethyl alcohol where neces-

sary.

7.4 Cleaning plan

Cleaning and maintenance

34/76

Component Interval Activity See page

After each

tanning session

When necessary

50 h

1 Adjustable air nozzles X Cleaning and disinfection 32

2 Acrylic panel X Cleaning and disinfection 32

14 Operating handle X Cleaning and disinfection 32

15 Display unit X Cleaning and disinfection 32

Control Center Cleaning and disinfection 32

Handle X Cleaning and disinfection 32

Protective goggles X Cleaning and disinfection 32

MP3 cable X Cleaning and disinfection 32

3 Condensation tank X Empty 53

8 Body cooling air nozzles, foot end X Clean 32

9, 11, 16 Surfaces X Cleaning and disinfection 32

12 Nozzles AQUA / AROMA SYSTEM X Clean 32

13 Body cooling air nozzles X Clean 32

4-6 Filter X Remove and clean filter 53

7 Filter X Remove and clean filter 51

10 Filter X Remove and clean filter 52

NOTE:

If desired, you may set the unit to require that cleaning be
confirmed after each tanning session by pressing the
START/STOP button (when the cool-down time for the main
fan has finished).

7.5 Maintenance

Maintenance and care play a major role in deciding the devices performance
and appearance over its useful life. Diligent compliance at the specified inter­vals is absolutely necessary to ensure the proper operation of your tanning
system.

The current operating hours of the parts requiring maintenance can be dis­played in the Presetting mode – see separate instructions 'Presettings' (order
no. 1011803-..).

Please note that the device must be inspected regularly by a JK authorized
representative every 12 months (from date of installation) to maintain its
proper condition!

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 35/76

7.5.1 Acrylic panel

CAUTION!

Cosmetics may cause cracks to form on the surface!

Over the long-term cosmetics or sunscreens cause damage
(e.g. crack formation on the surface).

– Ensure that cosmetics and sunscreens are removed

before tanning.

The acrylic panels for the tanning devices are produced of acrylic glass de­veloped especially for this application. The acrylics used feature a particularly
high UV permeability and resistance, as well as an easy-care, hygienic sur­face that is gentle on the skin.

The acrylic panels are formed to device-specific shapes in a technically com­plex production process. Despite state-of-the-art production know-how, the
presence of minor spots, air bubbles or streaks in the acrylic panels is una­voidable. In addition, hairline cracks can occur on the acrylic panel during
operation.

These occurrences are material-related and are unavoidable in processing.
However, they have no significant effect on use and are therefore not accept­ed as defects.

Over the course of time the acrylic panel will become discolored as a result of
usage and must be replaced by customer-service personnel on a regular
basis.

The optional partition (only for devices with an air conditioning unit) works as
a UV filter and must be replaced by customer-service personnel on a regular
basis.

7.6 Maintenance plan

CAUTION!

Only use OEM spare parts of the same type! The use of
other parts will void the manufacturer's warranty!

Any liability is excluded in case of damage or injury proven
to be the result of the use of non-genuine spare parts.

Cleaning and maintenance

36/76

Component Interval Activity See page

When necessary

300 h

500 h

750 h

1000 h

1500 h

3000 h

6 AQUA SYSTEM X Replace 56, 57

7a-7b AROMA canister X Replace 56

1 Facial tanner UV high pressure lamps

Facial tanner UV-B low pressure lamps
(TYPE B)

X

X

Replace

Replace

47, 48
47, 48

2 Shoulder tanner UV high pressure lamps X Replace 49

3 UV low pressure lamps, base X Replace 47

8 UV low pressure lamps, side section X Replace 47

9 UV low pressure lamps, canopy X Replace 48

1 Starter, UV low pressure lamps facial tan-

ner

X Replace 48

5 Acrylic panel X Replace 35

4 Partition X Replace 35

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 37/76

In addition to the maintenance plan on page 36, the following items should be
checked to ensure safe operation and use of your tanning system.

Component Interval1) Activity

250 h / 3 months

500 h / 6 months

2500 h / 1 year

5000 h / 5 years

10000 h / 10 years

1 Springs X Inspect and replace as necessary

Springs X Replace

2 Bolts and fasteners of the canopy

hinge mechanism

X Inspect and replace as necessary

Bolts and fasteners of the canopy lift

mechanism

X Inspect and replace as necessary

Bolts and fasteners of the canopy

hinge/lift mechanism

X Replace

3 Bolts and fasteners of the base/tank

hinge/lift mechanism

X Inspect and replace as necessary

Bolts and fasteners of the base/tank

hinge/lift mechanism

X Replace

4 Cylinders X Inspect and replace as necessary

Cylinders X Replace

5 Chassis and associated fasteners X Inspect and replace as necessary

Chassis and associated fasteners X Replace

6 Wiring and associated plugs / termi-

nal connections

X Inspect and replace as necessary

7 Acrylic panels2) X Inspect and replace as necessary

Acrylic panels2) X Replace

8 Acrylic support(s) X Inspect and replace as necessary

Acrylic support(s) X Replace

9 High pressure filter glass X Inspect and replace as necessary

High pressure filter glass X Replace

10 High pressure lamp holder X Inspect and replace as necessary

High pressure lamp holder X Replace

1) Interval must be repeated after each inspection or replacement
(i.e. 1st: 3 months, 2nd: 6 months, 3rd: 9 months, etc.)

2) The schedule for acrylic replacement listed refers only to the condition of
the acrylic relating to safety and does not address the efficacy of UV
transmission.

Cleaning and maintenance

38/76

7.7 Cleaning and maintenance work
preparation

7.7.1 Service kit

1. Allen-key

2. Suction cup for filter panels and partition

3. Scratch prevention for the entry area (canopy panel support cushion)

The service kit is fitted on the inside of the front panel.

– Opening the bed base: see page 42.

– Remove service kit from holder.

– Remove the Allen-key and suction cup.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 39/76

– Use the cushion to prevent scratches when opening the canopy panel.

7.7.2 Lift up the acrylic panel and remove the
partition

– Lift up the acrylic panel.

The acrylic panel will be held in place automatically by the acrylic sup­ports.

– Remove the lamp covers at the head and foot ends.

– Remove the partition.

The assembly is the same process in reverse order.

When assembling the device please note:

– You must ensure that the recesses are at the foot end when you fit the

partition.

– Remove fingerprints and other soiling carefully.

Cleaning and maintenance

40/76

– Lift the acrylic up slightly and then close it.

7.7.3 Remove the canopy panel

– Loosen the screws. Remove the outside screws first and then remove the

screw in the middle.

– Support the canopy panel with one hand so that it does not fall down.

– Carefully lower the canopy panel. Use foam or something similar to pro-

tect the base acrylic, see (1).

The assembly is the same process in reverse order.

When assembling the device please note:

– Support the canopy panel with one hand so that it does not fall down.
– Replace and retighten the screws. Replace the middle screw first and

then the outer screws.

– Remove fingerprints and other soiling carefully.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 41/76

7.7.4 Remove the side section panel

– Remove the screws.

– Open the panel and lay it down carefully.

When assembling the device please note:

– Replace and retighten the screws.
– Remove fingerprints and other soiling carefully.

Cleaning and maintenance

42/76

7.7.5 Open the bed base

– Press the bed base gently downwards.
– Release the lock at the head end.

– Lift up the bed base.

– Close the bed base. You should hear the bed base click into place.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 43/76

7.8 Instructions for replacing the lamps

WARNING!

Danger of being burned by an over-powered lamp!

If the old chip card is left in the device, the new lamp set will
be run at too high power and the user may suffer heavy
burns!

– The enclosed chip card must always be used when

changing the UV low pressure lamps!

The lamp's UV effect and therefore the tanning effect decrease over time. In
electronically controlled low pressure lamps, this loss of effect can be com­pensated. The chip card is used to control the changing periods. You must
adhere to the replacement intervals specified in the maintenance plan.

UV filters are used in order to control the UV radiation, e.g. the filter panels in
the facial tanner. However, the filter effect decreases over the course of time.
You must adhere to the replacement intervals specified in the maintenance
plan.

7.8.1 Changing the chip card

The chip card belongs to the long UV low pressure lamps fitted in the canopy,
the side panels and the device's base.

The chip card is located in the 'Part support control'.

– Opening the bed base: see page 42.

– Remove the chip card belonging to the old lamp set.
– Insert the new chip card with the text facing downwards and the arrow

pointing forwards.

– Close the bed base. You should hear the bed base click into place.

Cleaning and maintenance

44/76

7.8.2 Low pressure lamps

 Replace faulty UV low pressure lamps immediately. Install replacement

lamps to the outer edges of the tanning area.

 Always replace the entire set of lamps after the specified operating time.

– Turn 90° and carefully remove from the socket.

– UV low pressure lamps possess a reflector which directs the light out-

wards. The lamps must be mounted in such a way that the rear side of
the reflector is located on the device side.

– Push the pins vertically into the socket from above.

– Turn the lamp 90°.

The lettering must be oriented towards the outside (i.e. towards the tan­ning room or towards the user).

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 45/76

7.8.3 Starter

 Replace faulty starters immediately.

You can recognize a faulty starter by the blackened ends of the lamps or
when the lamps can no longer be started.

Operating a lamp with a faulty starter significantly shortens its service life. The
lamp loses power and may begin to flicker under certain circumstances.

The starters are located in either one of the two lamp sockets or are visible
when the lamps are removed.

– Turn 90° and carefully remove from the socket.

7.8.4 High pressure lamps and filter panels

UV high pressure lamps are used in the facial tanner and the shoulder tanner.

CAUTION!

Danger of overheating will exist if the wrong
UV high pressure lamps are used!

The danger of overheating will exist if the wrong UV high
pressure lamps are fitted in the shoulder tanner. The device
might be damaged.

– Never interchange the UV high pressure lamps used in

the facial tanner with those used in the shoulder tanner!

WARNING!

Fire hazard due to overheated lamps!

Non-approved high pressure lamps can explode. Hot lamp
components can set other parts on fire. People can be killed
or severely injured due to smoke inhalation and fire.

– Only fit the high pressure lamps specified by the manu-

facturer.

– Clean the inside of the device regularly. Dust particles

are flammable!

Cleaning and maintenance

46/76

– Release the clamping holder.
– Lift the filter panel, pull it out of the guide and remove it.

– Unplug the UV lamps.
– Clean the reflector.

– Only utilize original UV lamps.

– Only touch new lamps in the handling zone.

– Test the safety switch to ensure that it works.

The safety switch ensures that the device switches off in the event of a
faulty filter panel or when a filter panel is missing.

– Press the button.

If the button springs back automatically then it is functional.

– Replace the filter panel.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 47/76

7.9 Cleaning or replacing UV lamps in the
base

– Lift up the acrylic panel and then remove the lamp covers and the parti-

tion: see page 37.

Replacing lamps: see page 44.
Changing the chip card: see page 43.

The assembly is the same process in reverse order.

When assembling the device please note:

– You must ensure that the recesses are at the foot end when you fit the

partition.

– Lift the acrylic up slightly and then close it.

7.10 Cleaning or replacing the UV lamps in
the side section

– Removing the side section panel: see page 41.

– Remove the lamp cover.

Replacing lamps:
UV low pressure lamps: see page 44.
UV high pressure lamps and filter panels: see page 45.

Changing the chip card: see page 43.

Cleaning and maintenance

48/76

When assembling the device please note:

– Refit and retighten the screws.

7.11 Cleaning or replacing UV lamps and
filter panels in the canopy

– Removing the canopy panel: see page 40.

– Remove the screws and then remove the lamp cover.

The following components listed in the maintenance plan are fitted in the
canopy:

 UV low pressure lamps: see page 44.
 Facial tanner UV high pressure lamps and filter panels: see page 45.
 Facial tanner filter panels
 Facial tanner UV low pressure lamps and the associated starters

Changing the chip card: see page 43.

The facial tanner's UV low pressure lamps must be removed first so that the
UV high pressure lamps and the filter panels can be changed.

– Remove the lamps.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 49/76

– Remove the ninth low pressure lamp in the canopy so that you can then

access the facial tanner's low pressure lamp starter.

The assembly is the same process in reverse order.

When assembling the device please note:

– Support the canopy panel with one hand so that it does not fall down.
– Replace and retighten the screws. Replace the middle screw first and

then the outer screws.

7.12 Cleaning or replacing the UV lamps
and filter panels in the shoulder
tanner

– If an enclosed tanning tunnel is fitted: Remove the screws and then re-

move the tanning tunnel.

– Remove one screw from each one.
– Remove both housings and carefully lay them aside.

Changing the UV high pressure lamps: see page 45.

Cleaning and maintenance

50/76

CAUTION!

Danger of overheating will exist if the wrong
UV high pressure lamps are used!

The danger of overheating will exist if the wrong UV high
pressure lamps are fitted in the shoulder tanner. The device
might be damaged.

– Only Ergoline Ultra UV high pressure lamps

(1500384-..) are to be fitted in the shoulder tanner.

Each of the high pressure lamps in the shoulder tanner is fitted with 2 different
filter panels. The two filter panels are secured in place inside the housing.

– Remove the screws.

– Use the suction cup to lift the upper filter panel.
– Pull out the holder.

– Use the suction cup to remove the two filter panels.

CAUTION!

Do not interchange filter panels!

The shoulder tanner is fitted with different filter panels.
a) Ultra Performance 912 (blue), order no. 1500635-..
b) Non-coated, order no. 1500160-..

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 51/76

– Fit the new filter panels in the correct sequence.

The assembly is the same process in reverse order.

7.13 Cleaning the filters in the base

– Opening the bed base: see page 42.

– Remove the filters.

Cleaning and maintenance

52/76

– Cleaning the filters when wet or dry.

Dry cleaning: Vacuum cleaner (depending on the degree of soiling)
Wet cleaning: Use water and detergent or put in a dish-washer

CAUTION!

The device may be damaged by moisture!

The cleaned filters must be dry before they are replaced.

– Reinstall the cleaned and dried filters.
– Close the bed base. You should hear the bed base click into place.

7.14 Cleaning the canopy filter mats

– Remove the filter mats fitted at the back of the canopy.

– Dry or moist clean the filter mats or replace with new ones.

Dry cleaning: Vacuum cleaner (depending on the degree of soiling)
Moist cleaning: Water and detergent

– Do not clean in the dish-washer!

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 53/76

CAUTION!

The device may be damaged by moisture!

The cleaned filters must be dry before they are replaced.

– Reinstall the cleaned and dried filter mats.

7.15 Air conditioning: Empty the
condensation tank and clean the filter

CAUTION!

Damage to the device through soiled filters and cooling
fins!

Regularly check the filter grill and cooling fins on the air
conditioning system and clean if necessary.

We recommend using the specially manufactured fin comb,
art-no. 15720470, to clean the cooling fins.

– Opening the bed base: see page 42.

– Bring the condensation tank forwards.
– Disconnect the hose on the condensation tank.
– Empty the condensation tank.

Cleaning and maintenance

54/76

– Remove the cover.

– Remove the filter from the holder.

– Cleaning the filter when moist or dry.

Dry cleaning: Vacuum cleaner (depending on the degree of soiling)
Moist cleaning: Water and detergent

– Do not clean in the dish-washer!

– Remove the filters from the holder.

– Cleaning the filters when wet or dry.

Dry cleaning: Vacuum cleaner (depending on the degree of soiling)
Wet cleaning: Use water and detergent or put in a dish-washer

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 55/76

– Use a fin comb to clean the air conditioning's dirty cooling fins.

CAUTION!

The device may be damaged by moisture!

The cleaned filters must be dry before they are replaced.

– Reinstall the cleaned and dried filters.
– Ensure that the filters are correctly positioned in the holder.

– Attach the cover.

– Connect the condensation tank to the hose.
– Refit the condensation tank.
– Close the bed base. You should hear the bed base click into place.

Cleaning and maintenance

56/76

7.16 AQUA / AROMA SYSTEM maintenance

The AQUA SYSTEM function sprays a fine mist of AQUA SOLAR WITH
SKIN+ ADDITIVE into the interior of the device for body cooling (see 'AQUA
SYSTEM PRODUCT INFORMATION', order no. 1011201-..).

WARNING!

Customer health hazard!

Water that has been contaminated with bacteria can cause
skin rashes and other allergic reactions in device users.

– Therefore you must never fill the AQUA SYSTEM

canister with tap water or other liquids.

– Only replace the AQUA SYSTEM canister with a

genuine canister.

– Do not add any liquid that remains in the old canister to

the new canister!

– Ensure that the maximum temperature specified is not

exceeded during transport and storage.

– Note the expiration date on the canister.

This AQUA / AROMA SYSTEM also includes the 'RELAX' fragrance, which is
distributed through the head nozzles. Another fragrance called 'CABIN' is
distributed within the cubicle.

7.16.1 Changing the AROMA canister

– Opening the bed base: see page 42.

– Remove the AROMA canister.

Cleaning and maintenance

10/2013 1014906-00 Operating instructions – 57/76

– Unscrew the lid on the new canister.
– Write the date on the canister.

– Fit the canister in the holder.
– Close the bed base. You should hear the bed base click into place.

7.16.2 Replacing the AQUA SYSTEM canister

– Opening the bed base: see page 42.

– Remove the canister.
– Unscrew the lid on the new canister.
– Remove the lid with the hose from the old canister.

– Screw the lid with the hose onto the new canister.
– Push the hose well down so that it touches the bottom of the canister.
– Put the canister back in the device.
– Close the bed base. You should hear the bed base click into place.

Cleaning and maintenance

58/76

Venting

NOTE:

To ventilate, access to the Professional Setup Manager in
the Control Center is required.

– Go to the Professional Setup Manager.
– Activate the fill mode in the AQUA FRESH AROMA menu.

– Close the canopy.

The system will now be ventilated for 1 minute. AQUA SYSTEM liquid will be
released from the nozzles during this period.

– Test the AQUA SYSTEM function afterwards. Repeat the ventilation

process if it does not work.

Technical data

10/2013 1014906-00 Operating instructions – 59/76

8 Technical data

8.1 Power rating, electrical specifications
and noise level

SUN SELECT 1400 INTELLIGENT PERFORMANCE

Nominal power consumption: 17,800 W

Rated frequency: 60 Hz

Rated voltage: 230 V 3 phase 230 V 1 phase

Rated fuses: 70 amp 3-pole 110 amp 2-pole

Noise level at 1 m distance from
the device (without exhaust air):

62.9 dB(A)

Noise level in device: <81 dB(A)

Load on the acrylic panel: max. 300 lb / 135 kg

Weight: approx. 1500 lb / 680 kg

Technical data

60/76

8.2 Dimensions

B+ = 60 13/16 in 1,545 mm H = 58 11/16 in 1,491 mm

B = 59 14/16 in 1,521 mm H1 = 76 15/16 in 1,955 mm

B- = 59 11/16 in 1,516 mm H2 = 43 9/16 in 1,106 mm

B1 = 37 1/2 in 953 mm H4 = 17 11/16 in 450 mm

B2 = 8 1/16 in 205 mm H5 = 2 3/16 in 56 mm

L = 93 11/16 in 2,380 mm H6 = 74 in 1,879 mm

L1 = 86 5/8 in 2,200 mm H7 = 78 13/16 in 2,002 mm

L2 = 69 1/8 in 1,756 mm H8 = 87 3/16 in 2,215 mm

L3 = 9 1/4 in 235 mm H9 = 92 15/16 in 2,360 mm

L4 = 9 9/16 in 243 mm X = 50 4/16 in 1,277 mm

L5 = 34 1/8 in 867 mm Y = 28 1/16 in 712 mm

L7 = 44 1/8 in 1,120 mm Z = 88 3/16 in 2,240 mm

Ø = 11 13/16 in 300 mm

TK = 90 9/16 in 2,300 mm

BK = 98 7/16 in 2,500 mm

Technical data

10/2013 1014906-00 Operating instructions – 61/76

8.3 Lamp configuration

CAUTION!

The use of other UV lamps and filter panels voids the
operating license!

8.3.1 SUN SELECT 1400
INTELLIGENT PERFORMANCE

Installed lamps

Number Description Length Power Control Order no.

a) 4

4

UV high pressure lamps Ergoline ULTRA
C12645

Filter panels Ultra Performance 412

520 W 420 W / 360 W /

260 W / 0 W

12645-..

11526-..

b) 2

2
2

UV high pressure lamps Ergoline ULTRA
S1500384

Filter panels Ultra Performance 912 (blue)
Filter panels uncoated

250 W 250 W / 0 W 1500384-..

1500635-..
1500160-..

c) 3

3

UV low pressure lamps Ergoline
VHP B-POWER

Starter S10 (4-65 W)

12 3/16 in

0.31 m

8 W 8 W / 0 W 1507918-..

10047-..

d) 20 UV low pressure lamps Ergoline VHP10

INTELLIGENT PERFORMANCE 200 W

71 in

1.80 m

200 W 80-200 W 1507905-..

e) 8 UV low pressure lamps Ergoline VHP10

INTELLIGENT PERFORMANCE 200 W

71 in

1.80 m

200 W 80-200 W 1507905-..

f) 24 UV low pressure lamps Ergoline VHP10

INTELLIGENT PERFORMANCE 200 W

71 in

1.80 m

200 W 80-200 W 1507905-..

Technical data

62/76

8.4 Spare parts and accessories

Number Description Order no.

1 1 Acrylic panel 1013561-..

2 1 Partition 1500540-..

3 4 Filter 52104-..

4 1 Filter –

5 1 Filter 51937-..

6 1 Filter 55567-..

7 1 AQUA SYSTEM, 1.59 gal (6 l) 1010506-..

8
a)
b)

1 AROMA, 3.38 fl oz (100 ml)

CABIN
RELAX

701358-..
701357-..

9 2 Filter 843150-..

1 Protective goggles 0085006152-..

1 MP3 cable 4630911001-..

1 Allen-key 83828-..

1 Chipcard of lamp set 1507844-..

JK-Products, Inc. – Limited Warrant

y

10/2013 1014906-00 Operating instructions – 63/76

9 JK-Products, Inc. – Limited Warranty

JK-Products, Inc. warrants its products to be free from defects in materials
and workmanship under intended normal use as described in the unit's Oper­ation and Instruction Manual, for a period of three (3) years from date of sale.

This Limited Warranty applies only to the original purchaser of the equipment
through JK-Products, Inc. or its authorized dealer or distributor, and is not
transferable.

Global Service USA obligations under this warranty are limited to repair or
replacement of any defective part without charge for that part to the original
purchaser, with the following exceptions:

A Fluorescent lamps are warranted against defects for a period of thirty
(30) days from date of sale.

B Only parts obtained through JK-Products, Inc., its authorized dealers
or distributors may be used. Transportation costs for parts shipped to the
consumer and the return of defective parts to Global Service USA are not
included.

C Labor will be furnished without charge for ninety (90) days from date
of purchase only. All labor and related charges must be authorized by Global
Service USA prior to start of repairs, and must coincide with Global Service
USA established rates and time allotment policy.

D Acrylic: Refer to Manufacturer's Acrylic Warranty Policy.
It is imperative that the original customer completes and returns the enclosed

warranty card within 10 days after purchase to insure valid registration and
coverage for potential claims.

If the warranty card is not registered, proof of purchase from JK-Products, Inc.
or its authorized dealer or distributor will be required prior to any consideration
on warranty claims. This could result in service delays.

This warranty is extended to the individual or legal entity, whose name ap­pears on the warranty registration card filed with Global Service USA, or
whose name appears on the original sale document and may not be trans­ferred to any other individual or legal entity.

This warranty does not apply to any failure of the product, or any parts of the
product due to alterations, modifications, misuse, abuse, accident, improper
maintenance, improper installation, acts of God or if the serial number on the
product has been removed, altered or defaced. Adequate packaging must be
used for returned goods to prevent freight damage.

There are no warranties which extend beyond the description on the
face hereof. There is no express or implied warranty of fitness of mer­chantability.

The remedies provided in this limited warranty are the exclusive reme­dies provided to the purchaser by Global Service USA and are provided
in substitution of all other remedies. Consequential and incidental dam­ages are excluded.

No person, firm or corporation is authorized to obligate JK-Products, Inc. for
any liability in connection with the sale or use of these goods.

JK Products & Services, Inc. makes no guarantees on income, return on
investment, market conditions, performance, etc. with any undertaking using
its products and services. Past performance is not indicative of future results.

JK-Products, Inc. – Limited Warranty

64/76

9.1 Limited Acrylic Warranty

JK Products, Inc. warrants its acrylic sheets to be free from defects in material
and workmanship, under intended normal use, for a period of one (1) year
from date of sale of the tanning bed. Due to the tanning lotions, cosmetics,
disinfectant and improper cleaners used on tanning surfaces that cannot be
controlled by JK Products, Inc., after the first thirty (30) days of warranty peri­od acrylic will be subject to a prorated cost to the consumer.

JK Products, Inc. obligations do not include transportation charges on re­placement acrylic.

JK Products, Inc. assumes no liability for the cost of removing defective
sheets or installing replacement sheets, or for damage to persons or property.

To make a claim, contact an authorized dealer or distributor of JK-Products,
Inc. or Global Service USA with the model number, the serial number, and the
date of purchase of the bed in which the acrylic will be used.

There are no warranties which extend beyond the description on the
face hereof. There is no express or implied warranty of fitness or mer­chantability.

The remedies provided in this limited warranty are the exclusive reme­dies provided to the purchaser by Global Service USA and are provided
in substitution of all other remedies. Consequential and incidental dam­ages are excluded.

JK Products & Services, Inc.
#1 Walter Kratz Drive
Jonesboro, AR 72401

Phone: [phone] (toll-free)
Fax: [phone]
e-mail: [e-mail]
http://support.jkamerica.com

9.2 Warranty Claims

9.2.1 Policy & Procedures

1. When to file a Warranty Claim:
In the event that your tanning system is not functioning properly under intend-

ed normal use as described in the unit's Operation and Instruction Manual,
you may then have established cause to file a Warranty Claim.

NOTE:

Both the tanning system and legal registered owner must
meet the criteria established under JK Products, Inc. Limited
Warranty as described in this manual before any Warranty
Claim will be considered.

JK-Products, Inc. – Limited Warrant

y

10/2013 1014906-00 Operating instructions – 65/76

2. Where to call to place a Warranty Claim:
JK-Products, Inc. is supported nationwide by an extensive dealer/distributor

network through whom the majority of our units are sold. These deal­ers/distributors are required by contract to stock sufficient parts to meet the
various warranty and nonwarranty needs of their customers.

Therefore, in order for you to properly file a Warranty Claim, you must locate
the name and phone number of the dealer/distributor through whom you pur­chased your unit. Normally this information can be easily located either on
your paid invoice or other proof of purchase documentation that you received
when taking delivery of the unit.

Next, notify the dealer/distributor of the serial number, model number and
date unit was purchased. This will initiate the Warranty Claim process.

Upon determination of the problem, your dealer/distributor can then supply
you with the part(s) and proper instructions to return your unit to working or­der.

Each dealer/distributor has their own internal procedure for handling Warranty
Claims and credits.

NOTE:

JK-Products, Inc., the manufacturer, does not involve itself in
the direct handling of a Warranty Claim except where miti­gating circumstances apply and where required by law.

NOTE:

If part returned to Global Service USA proves to be opera­tional and not defective, or if product code numbers on part
do not correspond with individual unit date on file with Global
Service USA, then a 30% restocking fee will be charged in
addition to the retail purchase price of part.

Acknowledgment of the Agreement is not required for acceptance of the fore­going stipulations.

9.2.2 Labor Warranty Claim/Credit Procedures

Global Service USA furnishes labor without charge for a period of 90 days
from date of purchase. All labor and related charges must be authorized by
Global Service USA prior to start of repairs, and must coincide with Global
Service USA established rates and time allotment policy.

Please contact our Service Department for authorization and billing proce­dures.

JK-Products, Inc. – Limited Warranty

66/76

9.3 Limited Lifetime Warranty

Global Service USA warrants specific individual components of the tanning
system against defects in materials and workmanship for the life of the prod­uct. Coverage is limited to units purchased after November 1, 1994.

This warranty is restricted to the following components only:

 Steel Back Panels
 Structural Steel Frame Components
 Exterior Steel Body.

NOTE:

Components are warranted on an individual basis and not as
they may effect the complete product.

Warranty coverage does not include cosmetic abnormalities such as scratch­es, nicks, dents, rust, oxidation of paint or other cosmetic changes that do not
interfere with the designed function of the unit.

This warranty does not include failure of the product due to alteration, modifi­cations, misuse, abuse, improper maintenance, improper installation or repair.

This warranty is not transferable and is only applicable to the original pur­chaser named on a completed and registered warranty record at JK-Products,
Inc. headquarters.

JK Products, Inc. obligations do not include transportation charged on the
shipping of new components to the customer or on the return of defective
components of the manufacturer. All freight charges must be paid by the
customer.

There are no warranties which extend beyond the description on the face
hereof. There is no express or implied warranty of fitness or merchantability.

The remedies provided in this limited warranty are the exclusive remedies
provided to the purchaser by Global Service USA and are provided in substi­tution of all other remedies. Consequential and incidental damages are ex­cluded.

NOTE:

Any misuse, abuse, modification, alteration, improper
maintenance, improper installation, etc. of this product or its
intended use will subject said party to direct responsibility
and liabilities for any and all consequences resulting from
such action. Furthermore, such actions will void all warran­ties and may relieve Global Service USA of any liabilities
relating to said product.

JK-Products, Inc. – Limited Warrant

y

10/2013 1014906-00 Operating instructions – 67/76

JK-Products, Inc. – Limited Warranty

68/76

Appendi

x

10/2013 1014906-00 Operating instructions – 69/76

10 Appendix

10.1 Signs and stickers on the device

Signs which warn of danger areas are attached to the device. The signs
shown below are examples. Ensure that the instruction signs are always
clearly recognizable and easily legible. Any missing instruction signs or stick­ers must be replaced.

A

ppendix

70/76

1: Name plate

The name plate is attached to the interior side of the canopy. It contains
important information for identifying the device (e. g. the serial number =
Serial-No.) and the conformity mark.

2: Module plate

3: OEM Parts sticker (801138-..)

The sticker is mounted on the bottom edge at the front of the bed base.

Appendi

x

10/2013 1014906-00 Operating instructions – 71/76

4: Exposure label

5: Air conditioning sticker (1002243-..)

13435 / 0

The sticker is mounted on the air conditioning.

6: Ballast support warning sticker (1003399-..)

The sticker is mounted on the power unit support.

A

ppendix

72/76

7: Controller connections sticker (843147-..)

The sticker is mounted on the controller support.

8: USA mains connection sticker

The sticker is mounted on the rear panel at the left.

9: Canada warning sticker (801371-..)

The sticker is mounted on the rear panel.

Inde

x

10/2013 1014906-00 Operating instructions – 73/76

11 Index

A

Accessories ......................... 17, 63

Acrylic glass (maintenance) ...... 33

Acrylic panel

(product information) ................. 36

Acrylic panel, load ..................... 60

Adolescents ........................ 12, 19

AQUA / AROMA

SYSTEM maintenance .............. 57

Assembly .................................. 13

C

Changing the AROMA

canister ..................................... 57

Changing the chip card ............. 44

Changing the starter ................. 46

Cleaning .............................. 31, 33

Air conditioning .................... 54

Air conditioning filter ............ 54

Filter .................................... 52

Filter mats............................ 53

Lamps, filter panels ............. 34

Cleaning / replacing
the UV lamps

Base .................................... 48

Facial tanner ........................ 49

Shoulder tanner ................... 50

Side section ......................... 48

Cleaning intervals ..................... 34

Cleaning overview ..................... 34

Cleaning the filter ................ 52, 53

Connect MP3 player ................. 30

Contact lenses .......................... 20

Copy protection ......................... 14

D

Definitions ................................... 7

Description ................................ 16

Device description ..................... 16

Dimensions ............................... 61

Disinfection ............................... 33

Disposal .................................... 14

E

Electric shock .............................. 9

Electrical specifications ............. 60

Electrician ................................... 7

Empty the condensation

tank ........................................... 54

Equipment ................................. 15

Exhaust air ventilation ............... 13

Export........................................ 13

Eye damage .............................. 19

F

Facial tanner

Cleaning/replacing ............... 49

Fault codes ............................... 32

Faults ........................................ 32

Filter panels .............................. 46

Cleaning/

replacing .................. 48, 49, 50

Foreseeable misuse .................. 12

Functions .................................. 24

G

Glasses ..................................... 20

Guidelines ................................. 13

H

High pressure lamps,

danger of fire! ............................ 46

I

Injury ........................................... 9

Installed lamps .......................... 62

Instruction signs ........................ 14

Intended use ............................. 12

Itching ....................................... 19

L

Lamp configuration ................... 62

Lamps ....................................... 12

Lift up the acrylic panel ............. 40

Light sensitivity .......................... 19

Index

74/76

M

Maintenance ................. 31, 33, 35

Maintenance overview.............. 36

Make-up ................................... 20

Medications .............................. 19

MP3 music ............................... 14

O

Open the bed base ................... 43

Operating overview .................. 21

Operating structure .................. 24

Operator ..................................... 7

Operator's obligations .............. 12

P

Plastic surfaces

(maintenance) .......................... 33

Play rights ................................ 14

Power rating ............................. 60

Product information .................. 12

Protective measures
when performing

maintenance work .................... 31

Q

Qualified staff ............................. 7

R

Recycling .................................. 14

Remove the canopy panel ........ 41

Remove the side section

panel ........................................ 42

Replace the UV low

pressure lamps ......................... 45

Replacing the AQUA

SYSTEM canister ..................... 58

Replacing the lamps ................. 44

Risk of injury ............................. 19

S

Safety notices ............................. 9

Scope of delivery ...................... 15

Service kit ................................. 39

Setup ........................................ 13

Sickness ................................... 19

Skin types ................................... 6

Spare parts ......................... 36, 63

Staff ............................................ 7

Staff training ............................. 13

Start tanning ............................. 29

Start-up settings ....................... 29

Sunburn .................................... 19

SUNSELECT settings .............. 28

T

Tanning times ............................. 6

Technical Service ....................... 2

Transport .................................. 13

U

UV lamps .................................. 62

V

Ventilation ................................ 13

W

Warning signs, description ......... 8

Inde

x

10/2013 1014906-00 Operating instructions – 75/76

Index

76/76
