ergoline opensun550 Operating Instructions Manual

OPERATING INSTRUCTIONS
INSTRUCTIONS DE SERVICE
OPEN SUN A.R.T. 550
Ergoline Open Sun
843137/ Index „_“ / us / fr / 11.2005
OPERATING INSTRUCTIONS INSTRUCTIONS D’UTILISATION
Open Sun 550 A.R.T. Turbo Power
2
Identify your tanning device . . . . . . . . . . . . . . . . . . . .3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Identifiez votre solarium . . . . . . . . . . . . . . . . . . . . . .89
Table de matières . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
3
Customer Service
Identify your tanning device
For contact with Customer Services, please write down the device number of your tanning device.
Global Service Division
#1 Walter Kratz Drive Jonesboro, Arkansas 72401
800-445-0624 870-935-9046
e-mail: support@jkamerica.com
5
4
Tanning times
Skin types
Skin types
For the recommended exposure schedule (see page 5).
Skin type I (Sensitive):
Invariably gets sunburn, accepts little natural sunlight and does not tan.
Skin type II (Fair):
This is the individual that usually burns easily and severely, tans minimally or lightly and peels.
Skin type III (Average):
Often referred to as “Average” complexion, burns moderately and tans about average.
Skin type IV (Brown):
This individual burns minimally, tans easily and above average with each exposure.
Skin type V (Dark Brown):
This individual’s system rarely burns, tans easily and substantially.
Tanning times
5
Tanning times
“This product is in conformity with performance standards for sunlamp products under CFR21 Part 1040.”
Note:
Description of skin types see Page 4.
6
Foreword
Foreword
Dear Customer,
The Ergoline device you have purchased is a technically advanced and powerful product. Your device was manufactured with the greatest care and precision. It went through numerous quality and safety checks in or­der to guarantee trouble-free, safe operation. Nonetheless, you can also make a significant contribution to your long-term satisfaction with your device. Following the tips and instructions in the instruction manual will ensure you enjoyment and pleasure with your device.
If you have any questions, we are always available to answer them.
1)
Yours sincerely
JK-Products, Inc.
• Read and observe the information in this instruction manual. This will enable you to prevent accidents and provide you with a reliable de­vice ready for use.
• Always observe current legal and other regulations and legal require­ments as well as the applicable environmental protection regulations.
1) (800) 643 0086
Note:
We reserve the right to make technical changes to the illus­trations and specifications in this instruction manual. Reprinting and reproduction, in whole or in part, of this man­ual is only permitted with our previous written approval and with the source specified.
Table of Contents
7
Table of Contents
Table of Contents
Skin types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tanning times. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Important safety notes and information. . . . . . . . . . . . . . . . .9
Safety notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Obligations of the studio operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Instructions pertaining to a risk of fire, electric shock, or injury . . . . . . 11
Instructions pertaining to a risk of damage to the machine . . . . . . . . . 13
Meaning of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Environmental protection information . . . . . . . . . . . . . . . . . . . . . . . . . 19
Use the sunbed – but use it properly! . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operation: overview. . . . . . . . . . . . . . . . . . . . . . . . . . .Fold-out page 22
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Tanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
To interrupt tanning session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Settings during start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Running time of accent lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
IR function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Regulating the facial tanners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Switching air condition off and on . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Regulating body cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Selecting music channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adjusting volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Maintenance instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
De-energize device and secure against being switched on again . . . 37
Maintenance: overview. . . . . . . . . . . . . . . . . . . . . . . . Fold-out page 38
Maintenance intervals, installed lamps and order numbers . . . . . . . . 39
Relamping/maintenance instructions . . . . . . . . . . . . . . . . . . . . . . . . . 43
Cleaning/replacing UV low-pressure lamps in the sunbed base . . . . 44
Cleaning/replacing UV low-pressure lamps in the side section . . . . . 46
Cleaning/replacing UV low-pressure lamps in the canopy . . . . . . . . . 47
Cleaning/replacing interior lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8
Table of Contents
Table of Contents
Cleaning/replacing UV high-pressure lamps and filter panels. . . . . . . 51
Cleaning/replacing accent light in the canopy . . . . . . . . . . . . . . . . . . . 55
Cleaning/replacing accent light in Ergoline writing . . . . . . . . . . . . . . . 57
Cleaning/replacing accent light in the frontpanel . . . . . . . . . . . . . . . . . 59
Cleaning filters in the sunbed base . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Cleaning filters in the canopy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Cleaning filters in the rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Air condition: Emptying the condensate container. . . . . . . . . . . . . . . . 65
Air condition: Cleaning/replacing the filter mat . . . . . . . . . . . . . . . . . . 68
Adjusting the closing mechanism of the canopy . . . . . . . . . . . . . . . . . 72
Presettings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Changing presettings with the control panel . . . . . . . . . . . . . . . . . . . . 73
Changing presettings with a hand-held unit. . . . . . . . . . . . . . . . . . . . . 75
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
JK-Products, Inc. – Limited Warranty. . . . . . . . . . . . . . . . . . 84
Timer operation. . . . . . . . . . . . . . . . . . . . see separate manual
Please read and observe ...
9
Safety notes
Important safety notes and information
Safety notices
Description of warning signs
Danger notices, damage to persons:
Warning notices, damage to persons:
Caution notices, damage to property:
Important information:
DANGER!
Type and source of danger, e.g. “DANGER – High volta­ge!”
Description of the consequences, e.g. “You can be killed or injured by an electric shock!“
Countermeasures: – Disconnect device from power supply before opening. – Do not reach into the inside with the device switched on.
WARNING!
Type and source of danger, e.g. “Warning – hot sur­face!”
Description of the consequences, e.g. “You can burn your hand (skin, face)!”
Countermeasures: – Do not touch hot parts and nearby surfaces. – Wait until hot parts and surfaces have cooled down.
Caution!
The word “Caution” with this label points out that danger for devices, materials and the environment can be expected here.
Note:
This symbol does not identify safety notices, but states in­formation for a better understanding of the processes.
10
Please read and observe ...
Safety notes
Intended use
The tanning device is intended exclusively for cosmetic tanning of the hu­man skin.
• The device is meant for commercial use only, not for home use.
• This device is used for tanning one adult person at a time.
• The user wears suitable eye protection that blocks UV radiation dur­ing tanning.
Any other use shall be considered improper. The manufacturer cannot be held liable for damage or injuries resulting from this. The operator bears the sole risk for this.
The proper use also includes compliance with the manufacturer’s instruc­tions, operating and maintenance conditions. This device may only be operated, maintained and repaired by persons familiar with these tasks and who have been informed of the dangers involved.
Obligations of the studio operator
• As the operator you are responsible for informing users on possible risks during tanning.
• All danger and safety labels attached to the device must be observed! Do not remove them!
• No safety equipment (e.g. panel switch) may be removed or deacti­vated which can impair the safe operation of the device!
• The device may only be operated in a serviceable condition!
• The operator is bound to ensure that the equipment is handled cor­rectly.
Please read and observe ...
11
Safety notes
Instructions pertaining to a risk of fire, electric shock, or injury
DANGER!
DANGER – High voltage!
You can be killed or injured by an electric shock! Assembly and electrical connection must comply with na-
tional and local regulations. – The device may only be assembled, installed, upgraded
or repaired by specially trained and instructed person­nel.
WARNING!
WARNING – ultraviolet radiation!
Unprotected tanning may result in eye injury and eye dis­eases.
The unprotected eye can become inflamed on the surface, and in certain cases the retina can be damaged by exces­sive radiation. Cataracts can form after frequently repeated exposure to radiation.
Inform users to use the included protective goggles
that block UV (Order No. 84592).
WARNING!
WARNING – ultraviolet radiation! Follow instructions!
Failure to use protective eyewear may result in severe burns or other eye injury. If discomfort develops, discontin­ue use and consult a physician.
– A person who does not tan in the sun most likely will not
tan from the use of this device. Persons with very sensi­tive skins (skin type I) must not use the unit, as with this skin type tanning is impossible without damaging the skin (e.g. sunburn).
– Individuals with acute sunburn, individuals who have
had or have skin cancer, or individuals who are at in­creased risk of skin cancer, must not use the system.
– UV devices must not be used without taking medical ad-
vice if unexpected effects, such as itching, occur within 48 hours of the first session.
– The sunbed must never be used if a filter panel is miss-
ing or damaged, or the timer is defective!
– UV light from the sun or UV systems can cause injuries
to the skin or eyes. This biological effect is dependent on the sensitivity of the individual's skin and on the type and amount of UV light.
– As with natural sunlight, overexposure can cause eye
and skin injury, sunburn, and allergic reactions.
12
Please read and observe ...
Safety notes
WARNING!
– Repeated exposure may cause premature aging of the
skin and skin cancer.
– Medications or cosmetics applied to the skin, may in-
crease sensitivity to ultraviolet light.
– A person having a history of skin problems should con-
sult a physician before use.
WARNING!
WARNING – ultraviolet radiation!
Danger of long-term consequences. – Overexposure should be avoided. – The elderly should not use this equipment. – Nursing infants and small children through age 7 years
may not use this device.
– The following applies to minors under the age of
18 years: Only use tanning devices in agreement with a parent or guardian, or after consulting a physician.
– While there is no immediate clinical evidence of UVA ex-
posure and its effects upon expectant mothers, it is strongly advised that expectant mothers be discouraged from using the tanning unit.
WARNING!
WARNING – risk of infection!
Infections can be transferred through skin contact. All items/equipment components, with which the user can
come into contact during tanning, must be disinfected after every tanning session:
• Protective goggles
• Headrest
• Acrylic sunbed
• Handles and control panel
Please read and observe ...
13
Safety notes
Instructions pertaining to a risk of damage to the machine
Note:
Occasionally, persons using the tanning device will experi­ence a slight reddening of the skin – usually in small patch­es – after the second or third session. This redness is often accompanied by an itching sensation. This may be nothing more than a heat “rash” caused by heat from the lamps within the device. It is generally very limited and caused by constant contact of the skin with the acrylic surface. It should go away within approximately 24 hours and should not reappear. This rashing can be lessened or prevented by applying moisturizer lotion to the affected area after the tan­ning session is completed.
– Follow instructions. – The time between the first two tanning sessions must be
at least 24 hours.
– Increasing tanning also requires an extension of the ex-
posure time (= radiation time) or after a certain degree of tanning has been achieved, a further intensification is not possible. However, the radiation time may not be ex­tended as desired within the scope of the permissible ra­diation doses! Therefore, only a certain degree of final tanning dependent on the skin type can be achieved without endangering your health.
– Inform users about proper tanning.
CAUTION – danger of overheating!
Danger of overheating by obstruction of the air routing. – Do not change, obstruct or block the air inflow and out-
flow area to the device or make any unauthorized changes to the device. The manufacturer shall bear no liability for damage or injuries resulting from such ac­tions.
– Before putting a tanning device into operation, the trans-
port pallet must be removed from under the device.
14
Please read and observe ...
Symbols
Meaning of symbols
General symbols
Inform Customer Services
Ergoline key
Do not touch, hot surface!
Suction cup
Low-pressure lamp(s)
UV low-pressure lamp(s)
Starter for low-pressure lamp(s)
UV high-pressure lamp(s)
Filter panels
Cleaning and disinfectant agents
Part/item number (for orders)
Operation
Display of tanning time
Display of run-on time (fan run-on)
Fault display (example), see separate manual
Please read and observe ...
15
Symbols
Display of Music Channel 1 (Channel 1) Factory setting: 1 channel Customer service can set up to 7 channels
Display when adjusting volume
Description
Accent lights
Press button
Press button for 2 seconds
Duration: 3 minutes
Loudspeaker
Headphone connection
e.g. 2s
0-3 mi
n
Technical Data
Maintenance
Caution, safety switch!
Unscrew/release screw
Tighten/lock screw
Two persons are required for this work step
Cleaning
Replacing
Clean or replace depending on soiling
16
Please read and observe ...
Guidelines / Export / …
Guidelines
This device was built conforming to UL STD 482, and is certified to CAN/ CSA STD C22.2 2 No. 224.
Export
We would like to point out that these devices are exclusively intended for use in the USA and Canada and may not be exported to other countries and operated there! The manufacturer assumes no liability whatsoever in the event of non-compliance! We explicitly emphasize that high liability risks may occur for the exporter and/or the operator in the event of non­compliance.
Accessories
Some accessory parts are taken into account in the maintenance sched­ule beginning on Page 39, however this does not automatically mean that your device is provided with this equipment.
An overview of the possible accessories is provided in the sales docu­mentation.
Draining
Visual inspection
Air condition
Filter
Filter and filter mats must not be damp.
Continuation of work steps on next page
End of work step
Presettings
Troubleshooting
...
Please read and observe ...
17
Maintenance and care
Product information
Acrylic glass panels
The acrylic glass panels for the tanning devices are produced of acrylic glass developed especially for this application. The acrylics used are characterized by a particularly high UV permeability and resistance, as well as an easy-care, hygienic surface that is gentle to the skin.
The acrylic glass panels are formed to their shapes for the specific devic­es in a technically complex production process. Despite state-of-the-art production know-how, the presence of minor spots, air bubbles or streaks in the acrylic panels is unavoidable. In addition, microfine hairline cracks can occur on the bed surface during operation.
These occurrences are material-dependent and are unavoidable in pro­cessing, however have no significant effect on the utility value and can therefore not be recognized as defects.
Maintenance and care
Maintenance and care play a major role in deciding whether the device meets the requirements placed on it in a satisfactory manner. The com­pliance with the specified maintenance intervals and the careful conduct­ing of the maintenance and care work are therefore absolutely necessary – see Page 38.
The current operating hours of the parts requiring maintenance can be displayed in the Presetting mode – see Page 73 ff.
CAUTION!
Cosmetics or sun screen products must be removed prior to tanning as they can cause damage (e.g. cracks on the sur­face) when used continuously.
DANGER!
Extreme danger! High voltage!
During maintenance work there is a risk of touching live parts and receiving a fatal electric shock.
– Disconnect device from power supply before opening –
also see Page 37.
– Do not reach behind covers and do not open the device
with the device switched on.
– Refit any safety devices (e.g. switches) after the work
has been completed.
CAUTION!
Only use genuine spare parts of the same type! The use of other parts voids the conformity! Any liability is excluded in case of damage or injury proven to be the result of the use of non-genuine spare parts.
18
Please read and observe ...
Cleaning
Cleaning
Acrylic glass surfaces Plastic surfaces
For cleaning the other plastic surfaces, it is best to use warm water and a leather cloth. Never use aggressive cleaning agents containing alcohol or essential oils. These may lead, in the long run, to damage not covered by the warranty.
During cleaning, a slight discoloration of the leather cloth by the rubber seals must be expected for production-related reasons.
CAUTION!
Do not rub with a dry cloth – danger of scratching! For fast, hygienic proper cleaning of acrylic glass surfaces,
use a specially developed fast disinfectant cleaner. Other cleaning agents, especially concentrated disinfec­tants or solvents (e.g. Lysoform, ethyl alcohol or other liq­uids containing alcohol) must never be used for cleaning.
Failure to observe this voids all warranty claims.
Note:
Prevent damage to plastic surfaces. Remove rings, watch­es, bracelets etc. before the start of cleaning work.
02756 / 0
Please read and observe ...
19
Environmental protection
information
Environmental protection information
Environmental Declaration – The JK Corporate Group
The JK corporate group is subject to the strict regulations of EC Directive 761/2001 and the ISO 14001 standard, and undergoes regular internal and external environment audits performed by trained auditors.
Environmental regulations – disposal of lamps
UV low-pressure lamps and UV high-pressure lamps contain fluorescent materials and other waste containing mercury.
According to the national waste disposal laws and in accordance with the municipal waste regulations, proof must be provided of the proper dis­posal of UV lamps.
Your local environmental agency will be happy to assist you with the dis­posal of UV lamps.
Packaging
All packaging consists of 100 % recyclable materials. Packaging brought into circulation by the JK Corporate Group that is no longer required can be returned to the JK Corporate Group. Your agency partner or dealer will be happy to advise you.
Disposal of recyclable materials
The device has been produced of recyclable materials. When being scrapped later, the device must be disposed of properly. Sun Ergoline will provide you with information on the content or potential hazards of the materials used.
21
Operation
Operation
Operation
Operation
Mandatory reading
Always read and follow all instructions for proper usage prior to allow anybody using a tanning device. The operating instructions included with this device must always be followed to prevent possible injuries or to re­duce them to a minimum.
Inform users
• to use provided UV-blocking protective eyewear whenever the equip­ment is energized.
• to follow the exposure schedule in accordance with their skin type. Failure to do so may result in overexposure.
A tanning system is not a toy. You cannot vary the strength of the lamps in your unit.
Should you have any questions regarding the proper use of your tanning system, contact Global Service Division at:
800 445 0624
7:00 a.m. to 7:00 p.m. (CT)
WARNING!
Warning – ultraviolet radiation!
Danger of skin injuries and skin diseases!
• The sunbed must never be used when a filter panel is missing or damaged, or the timer is defective!
Note:
When describing the operation, the tanning device is often shown with the canopy open. During tanning the canopy must always be closed.
Proper operation is not possible with the canopy open.
Please open this fold-out page.
22
73
75
20
Please read and observe ...
Use the sunbed properly
Use the sunbed – but use it properly!
A few things need to be noted to get maximum enjoyment from a sunbed. Here are some answers to some frequently asked questions.
Make-up on the sunbed?
Please don't. Clean skin absorbs UV light better. A wide variety of materials is found in cosmetics. Again, whether these
are emulsifiers, greases, or so-called scents – in conjunction with UV ra­diation, these can cause allergic reactions of the skin.
Accordingly, a must before using a sunbed is: Remove all make-up. This is essential. Make-up clogs the pores in the face. The UV light from a sunbed re-opens these clogged pores so that not only does the light pen­etrate the skin, but also the allergenic components of the make-up.
A further negative consequence of make-up is that the appearance of the skin deteriorates irreversibly over a period of time. However good a de­cent make-up might be – in conjunction with UV light, it causes more harm than good. Therefore: Remove all make-up before a session on your sunbed – it will be much better applied afterwards.
Showering after leaving the sunbed?
The browning is in the skin, not on it. Therefore you cannot wash it off. Treat your skin to a moisturizing cream after showering.
Are medications and the sunbed compatible?
It is known that some medications increase the skin's sensitivity to UV light. This probability is particularly high with antibiotics, sulphonamides, psychiatric drugs, tranquillizers, anti-diabetes treatments and diuretics. Sun creams which contain psorale or kumarin also increase skin sensi­tivity. If you are in any doubt, first ask your doctor - then you can enjoy the sun at no risk.
Contact lenses on the sunbed?
The answer is: Yes! Like any other sunbed user, contact lens wearers should also wear special protective goggles which protect the eyes against UV radiation. To guarantee better protection, wearers of specta­cles and contact lenses can ask their optician for exchange contact lens­es with UV protection. The UV-A and UV-B filters built into exchange contact lenses will protect the cornea and the internal parts of the eye against almost 100% of the energy in UV radiation.
This will benefit sunbed users not only in the open air, but on the sunbed itself. You can wear these contact lenses even on the sunbed without any restrictions. For more information, ask your optician or optometrist.
23
Operation
Accessories
24
Operation
Tanning
Start of tanning
The device is started automatically with an internal or external timer.
Preparation time
Before the UV lamps go on, you have a few minutes to prepare yourself. During the preparation time you can switch on the UV lamps at any time by pressing the START/STOP button.
– Remove your clothes and all jewelry. – Remove make-up and other cosmetics. – Remove glasses. Contact lenses can be worn under the protective
goggles. – Put on the protective goggles. – Lie down on the bed surface. – Close the canopy.
– Press the START/STOP button and follow the instructions of the
Voice Guide.
Note:
Timer instructions: see separate manual.
WARNING!
WARNING! Fire hazard!
There is a risk of setting fire to your hair or burning your skin. – Set all objects away from the facial tanners before start-
ing the treatment. It is particularly important not to place towels or long hair on top of the equipment.
...
25
Operation
Automatic switching off system (Advanced Control Feature)
Standby mode
The automatic switching off system ensures that a warning signal sounds and the face tanner's LEDs illuminate if, for example, a user's hand towel is left close to the face tanner.
The tanning unit will not start until the hand towel is removed. Press the START / STOP button and the tanner will return to standby mode.
Operating the tanner
The automatic switching off system ensures that a warning signal sounds and the face tanner's LEDs illuminate if, for example, a user's hair or hand towel is too close to the face tanner.
The tanner will be switched off after a few seconds if the object is not re­moved.
The face tanner can be switched back on after the cooling down time has expired (approx. 1 minute) by pressing the -button.
Note:
The face tanner will run up to the highest level automatically after being switched back and can then be switched down to a lower level as required.
...
26
Operation
Interrupt or end tanning session
The tanning session ends automatically after the preset time has run down. The internal fan continues to run for approx. three (3) minutes to sufficiently cool the device.
– To interrupt a tanning session, press button START/STOP for three
(3) seconds anytime during a session. – Press START/STOP again for three (3) seconds to restart the lamps.
Settings during start-up
27
Operation
Running time of accent lighting
The accent lights are automatically switched on at the end of the tanning timer after the set operating time and are switched off again at the beginning of the next tannings session.
The running time of the accent lights in the Standby mode can be changed with the preset­tings – see from Page 73 on.
Stand-by
73
IR Function
28
Operation
Regulating the facial tanners
Switching the face tanner OFF:
– Press button for two (2) seconds.
Switching the face tanner on again:
– Press button . It takes approx. one
(1) minute until the face tanners reach their
full output.
1
2
Press for two (2)
seconds.
3
...
29
Operation
1 min
4
One (1) minute
delay.
5
+ 1 min
30
Operation
Air condition
During start-up the air condition is active.
Switching the air condition OFF:
– Press button for two (2) seconds to
switch the air condition off.
Switching the air condition on again:
– Press the button. It takes approx. three
(3) minutes until the cooling effect of the air
condition is reestablished.
Press for two (2) seconds.
1
Three (3) minutes delay.
2
3
31
Operation
Surround cooling – Adjust speed
Two (2) minutes after the start the fans reach preset level 2.
– Press the plus or minus button to change
the intensity of the air stream.
1
2
3
32
Operation
CHANNEL
Selecting music channel
– Press button for five (5) seconds to ac-
tivate CHANNEL mode.
– Press the plus or minus button to select a
channel.
means: no Channel selected, there is
no sound, music is “OFF”.
CHANNEL
Press for five (5) se
-
conds to activate.
1
CHANNEL
2
CHANNEL
3
CHANNEL
4
33
Operation
VOLUME
Adjusting volume
– Press button for five (5) seconds to ac-
tivate VOLUME mode. – Press the plus or minus button to change
the volume.
Press for five (5) se
-
conds to activate.
VOLUME
1
73
VOLUME
2
VOLUME
3
34
Technical
Data
Technical data
Model:
Ergoline Open Sun A.R.T. 550
Turbo Power
Rated power consumption: 11100 W
Rated voltage: 230V
Rated frequency: 60 Hz
Rated fusing:
40 amp 3-pole 60 amp 2-pole
Conformity mark:
Powerinput 3-pole
(max. 50 amp)
230V AC 60 Hz
Powerinput 1-pole
(max. 90 amp)
230V AC 60 Hz
04045 / 1
35
Technical
Data
Bed tolerance in room
WARNING!
Warning – possible breakage of the acrylic panel!
Severe cuts from glass and burns from hot lamps may result.
– Only one adult person is al-
lowed at the same time.
– People with more than
300 lbs/135 kg must not use the device at all.
A= B= C= D= E= F=
69
11
/16 in
49 13/16 in
63 in
85
9
/16 in
90 1/2 in
42 5/16 in
1770 mm 1265 mm 1600 mm 2174 mm 2299 mm 1075 mm
? = 300 lb 135 kg BK =
TK =
8 ft
7
1
/2ft
2370 mm 2300 mm
37
Maintenance
Maintenance
Maintenance instructions
De-energize device and secure against being switched on again
• A strip of adhesive tape with the wording "DANGER do not switch ON!" may be applied over the actuation levers of circuit breakers which cannot be removed.
A prohibition sign with the text:
“Work in progress!”
• “Place: ..............................”
• “Sign may only be removed by: ............”
must always be securely mounted immediately.
DANGER!
Extreme danger!
If work is to be performed on the devices, they must be de-energized. That means that all power must be switched off. Switching off the device alone is insufficient, as certain points may remain energized. Therefore, switch off breakers before per­forming any work.
DANGER!
Extreme danger!
Severe accidents can occur if the device is mistakenly switched on again. Immediately after de-energizing, secure all switches or fus­es used for de-energizing against being switched on again.
– Lock the fuse box with a padlock.
04049 / 0
DANGER!
Extreme danger!
Prohibition signs must not be hung on or touch live parts.
01510 / 1
01511 / 1
Please open this fold-out page.
38
Scheduled cleaning
Note:
Clean after every use.
WARNING – risk of eye irritation!
Protective goggles may only be cleaned with an approved disinfectant.
Note:
Clean/drain if necessary!
 - 
WARNING!
36
Technical
Data
Maximum room temperature / Humidity
39
Maintenance
Scheduled cleaning – filters
/50 h
4 x
52104 61
1 x
51975 68
2 x
52099 63
2 x
52099 64
Attention! Risk of damage to the system
Check the filter mat (item 10) and the cooling fins on the air conditioner regularly and clean as necessary.
For cleaning of the cooling fins we recommend use of the special fin comb, art. no. 15720470.
40
Maintenance
Scheduled replacement – accent lights
a) 1 x white 8 W 11839 57
b) 1 x red 36 W 12968 59
magenta 842758
c) 1 x blue 36 W 11792 49
d) 1 x white 36 W 12969 55
light pink 842757
1,000 h
a) b) c) d)
4 x S10 10 047
49 55 57 59
41
Maintenance
Scheduled replacement – UV lamps, starters, filter panels Open Sun A.R.T. 550 Turbo Power
500 h
e) 2 x JK 800W OPEN SUN 800 W 12912 51
f) 18 x VHP™ 15 160 Turbo Power 160 W 12563 44
g) 9 x VHP™ 15 160 W Turbo Power 160 W 12563 46
h) 18 x VHP™ 15 160 W Turbo Power 160 W 12 563 47
1000 h
f) g) h)
45 x S12 10002 44, 46, 47
3000 h
e)
2 x SOLADUR open sun A.R.T. 52106 51
2 x 51791 51
Note:
The UV high-pressure lamps used,
JK 800W OPEN SUN
(face tanner), can be operated with different wattages.
UV low-pressure lamps: Clean with plain water (damp cloth).
Filter panels: Clean with plain water (damp cloth).
42
Maintenance
Scheduled replacement – acrylic sunbed
1500 h
734593 44
3000 h
842996 44
43
Maintenance
Relamping / maintenance instructions
It is imperative that you, the owner and/or operator, check all compo­nents for any signs of wear which may occur through normal use.
Observe the cleaning and maintenance schedule specified in the main­tenance table on Page 39 to 42.
Only replace UV low-pressure lamps with the original lamp type or with compatible lamps.
Only replace UV high-pressure lamps with the original lamp type or with compatible lamps.
Should you require any assistance or need additional information, please call Global Service Division at 800 445 0624, Monday through Friday 7:00 a.m. - 7:00 p.m. CT.
– Always comply with the specified maintenance intervals. – Follow the cleaning instructions. – If the maintenance intervals for the UV lamps are exceeded or incom-
patible UV lamps are installed, the share of harmful UVB radiation may increase. Sunburn and other skin damage may result.
CAUTION – Damage due to improper maintenance!
Improper maintenance can cause the device to be dam­aged or to become unusable.
WARNING!
Danger of burns from hot lamps and device parts!
If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot.
– Before replacing lamps or other spare parts, wait until
lamps and metal parts of the device have cooled down sufficiently.
Danger of pinching!
When opening and closing the tray, panels and covers, you can pinch your fingers.
44
Maintenance
Cleaning/replacing UV low-pressure lamps, sunbed base
Power Off!
1
2
3
4
2
1
03108 / 0
5
...
45
Maintenance
6
03099 / 0
7
8
Close:
9
46
Maintenance
Cleaning/replacing UV low-pressure lamps, side section
Power Off!
1
2
1
03108 / 0
2
3
03099 / 0
4
Close:
5
47
Maintenance
Cleaning/replacing UV low-pressure lamps, canopy
WARNING!
Danger of injury from the can­opy panel!
The canopy panel is heavy and falls down by itself after unscrew­ing the three (3) screws.
– Support canopy panel.
Power Off!
1
2
2
1
03108 / 0
3
4
...
48
Maintenance
03099 / 0
5
6
Close:
7
49
Maintenance
Cleaning/replacing interior lighting
WARNING!
Danger of injury from the can­opy panel!
The canopy panel is heavy and falls down by itself after unscrew­ing the three (3) screws.
– Support canopy panel.
08199 / 0
55
Power Off!
1
2
3
4
...
50
Maintenance
03099 / 0
5
6
Close:
7
51
Maintenance
Cleaning/replacing UV high-pressure lamps and filter panels
Power Off!
1
2
3
4
5
...
52
Maintenance
6
7
8
9
DANGER!
DANGER! Fire hazard!
High pressure lamps that have not been approved by Ergoline can explode. Hot lamp compo­nents can set other parts on fire. People can be killed or severely injured due to smoke and fume in­halation.
– Only fit high pressure lamps
recommended by Ergoline.
– Clean the inside of the device
regularly. Fluff is inflammable!
10
...
53
Maintenance
CAUTION!
Do not touch the glass bulbs of the UV high-pressure lamps with your bare fingers! Remove soiling thoroughly.
– Only touch new UV high-pres-
sure lamp with a cloth – see Figure 9.
11 12
13
14
15
...
54
Maintenance
16
17
18
Close:
19
55
Maintenance
Cleaning/replacing accent light, canopy
Power Off!
201
2
49
2
1
03350 / 0
3
07162 / 0
4
5
...
56
Maintenance
07165 / 0
6
07166 / 0
7
Close:
8
57
Maintenance
Cleaning/replacing accent light behind Ergoline writing
Power Off!
1
2
3
4
2
1
03350 / 0
5
...
58
Maintenance
6
7
Close:
8
59
Maintenance
Cleaning/replacing accent light, frontpanel
Power Off!
1
2
3
4
2
1
03350 / 0
5
...
60
Maintenance
07162 / 0
6
7
07165 / 0
8
07166 / 0
9
10
Close:
11
61
Maintenance
Cleaning filters, sunbed base
Power Off!
1
2
3
4
5
...
62
Maintenance
Attention! The system can be damaged by moisture!
When re-assembling, the cleaned filters and filter mats must be dry.
Hand-wipe lightly, dry or with water, or use a vacuum cleaner.
03319 / 0
6 7
8
9
Close:
10
63
Maintenance
Cleaning filters, canopy
1
Attention! The system can be damaged by moisture!
When re-assembling, the cleaned filters and filter mats must be dry.
Hand-wipe lightly, dry or with water, or use a vacuum cleaner.
05064 / 0
2 3
64
Maintenance
Cleaning filters, rear panel
Caution – the canopy is easily scratched!
– Protect canopy with blanket.
1
Hand-wipe lightly, dry or with water, or use a vacuum cleaner.
2
05064 / 0
Attention! The system can be damaged by moisture!
When re-assembling, the cleaned filters and filter mats must be dry.
3
65
Maintenance
Air condition, emptying the condensate container
Power Off!
1
2
3
4
...
66
Maintenance
5
6
7
8
9
10
...
67
Maintenance
11
Close:
12
68
Maintenance
Air condition, cleaning/replacing the filter mat, cleaning the cooling fins
Attention! Risk of damage to the system!
Check the filter mat and the cooling fins on the air conditioner regularly and clean as necessary.
Power Off!
1 2
3
...
69
Maintenance
4
5
6
7
8
Clean carefully (vacuum or wash) or replace.
9
...
70
Maintenance
Attention! The system can be damaged by moisture!
When re-assembling, the cleaned filters and filter mats must be dry.
Clean carefully.
10 11
12
13
03099 / 0
14
...
71
Maintenance
15
16
72
Maintenance
Adjusting the closing mechanism of the canopy
See Fig. 2:
• Turn in direction 1: canopy easier to open.
• Turn in direction 2: canopy more difficult to open.
1 2
73
Presettings
Changing presettings with the control panel
The setting mode enables you to call up operating states and make alte­rations to current settings.
Changing to Presetting mode
– Press the buttons and simultaneously for at least five
seconds outside a tanning process.
appears in the display. – Enter the code (see Page 74). – Press the START/STOP button four times when you run the Preset-
ting mode for the first time.
briefly appears in the display, then (Function 1)
and the presetting value are displayed alternately (see column "On delivery").
– By pressing the button you scroll up to the next function (from
-01- to -19-).
– By pressing the button you scroll down to the next function
(from -19- to -01-).
Changing presettings
Increase the preset value: – Press and hold the START/STOP button while simultaneously pres-
sing the button. Decrease the preset value: – Press and hold the START/STOP button while simultaneously pres-
sing the button. Reset to the last value set: – Press the START/STOP button. Reset to the delivered state: – See function .
Note:
The sunbed will automatically return to 'idle' mode 30 seconds after the last button was pressed.
The presettings are listed beginning on Page 76.
74
Presettings
Defining a code
– Select Function . – Press the START/STOP button for 3 seconds until appears. – Press the desired buttons consecutively: – Press the buttons in the same sequence when appears
again. – appears in the display. The set code has been saved. – Please note the code for Customer Service. If you know the old code, you can define a new code at any time. We re-
commend that you already set a new access code during the initial start­up.
75
Presettings
Changing presettings with a hand-held unit
Some data can also be displayed and changed with a commercially avai­lable hand-held unit (e.g. from Palm). For this purpose you require spe­cial software (available in German and English). Please call 1-866-243­9861 for more details.
Information on operating the hand-held unit is contained in the manufac­turer's documentation.
Caution!
The code for access via the infrared interface is preset in the software of the hand-held unit, and can therefore be used with any unit. Anyone, who downloads the software from the Inter­net can access the unit date with a hand-held unit. Please no­te that Customer Service changes the preset access code du­ring initial start-up – see software operating manual. Please note the new code for future use!
This code is independent of the access code for the preset­tings via the control panel.
Note:
Please read the operating manual for the Ergoline software for instructions on how to display or change data with a hand­held unit.
76
Presettings
No. Description on delivery Values from-to
Total number of operating hours 0 9999
Remaining operating time of UV low-pressure lamps (hours) 500 0000
Remaining operating time of UV high-pressure lamps (hours) 500 → 0
Remaining operating time of filter mats (hours) 50 → 0
Air conditioning operating hours 0 9999
Decorative lighting operating hours (minutes) When the maximum value is exceeded: Display = continuous
operation
1 1440
Fan run-on time (minutes) 3 10
To set the time
1 23
01 59
77
Presettings
To reset the device to ex-works setting (all functions)
To set the access authorisation code to enter setting mode (see page 74)
Adjust volume for music output (Sound System) 07 63
Ambient temperature setpoint value (°C) 15 30
Recycle air during fan run-on time (+ = on / – = OFF)
Lower temperature limit of air conditioner 15°C 25°C
No. Description on delivery Values from-to
78
Troubleshooting
In the case of a fault, fault codes appear on the display to simplify locali­zing of the fault cause:
• If a fault occurs, the fault code flashes in the display.
• If several faults occur, the fault messages are displayed alternately.
• The fault remedy is acknowledged by pressing the button. If the fault cannot be eliminated, inform Customer Service:
Global Service Division
#1 Walter Kratz Drive Jonesboro, Arkansas 72401
(800) 445 0624
79
Error Meaning Correction
Full condensation tank (only when using an original condensate container) Empty condensation container.
Fault in condensation pump
Temperature sensor for heating (air conditioner)
Temperature sensor for cooling (air conditioner)
Fault in temperature sensor for UV low-pressure lamps
Temperature sensor for room
Panel switch for shoulder tanner
Air-vane switch does not switch on with fan running
Air-vane switch does not switch off 1 minute after fan switches off
80
Fault in front face tanner
Fault in centre face tanner
Fault in face tanner rear
Fault in face tanner side section
Panel switch on decorative panel on canopy
Panel switch of acrylic glass panel on sunbed base section
Emergency switch-off time exceeded
I²C bus fault
Switching error in series circuit of safety switch
Auxiliary controller
Error Meaning Correction
81
Heating controller
Face tanner controller
Speed control 1
Speed control 2
Audio amplifier
Channel selection
Real-time clock
Parameter memory
Incorrect equipment of controller
Error Meaning Correction
82
Index
Index
Index
A
Accent lights
Cleaning/replacing ................. 55, 57, 59
Maintenance schedule ....................... 39
Accessories ................................................ 16
Acrylic glass, cleaning ................................ 18
Advance Control Feature............................ 25
Air condition
Condensate........................................ 65
Filter mat ............................................ 68
Automatic switching off system................... 25
B
Bed tolerance in room................................. 35
Body cooling, speed ............................. 30, 31
C
Care............................................................ 17
Channel ...................................................... 32
Cleaning...................................................... 18
Cleaning schedule ...................................... 38
Closing mechanism of canopy.................... 72
Condensate container, air condition ........... 65
Conformity mark ......................................... 34
Cooling fins, air condition............................ 68
D
De-energize device ..................................... 37
Description of tanning device...................... 22
Dimensions ................................................. 35
Disinfection.................................................. 18
Disposal of lamps........................................ 19
E
Environmental protection ............................ 19
Error codes..................................................78
F
Facial tanners
Maintenance....................................... 51
Regulating .......................................... 28
Fault codes..................................................78
Filter mat, air condition................................ 68
Filter panels, maintenance schedule........... 42
Filters
Canopy............................................... 63
Rear panel.......................................... 64
Sunbed base ......................................61
Frequency ................................................... 34
Fusing ......................................................... 34
G
Global Service Division, address...................3
Guidelines ................................................... 16
H
How to use the sunbed................................24
Humidity ...................................................... 35
I
Intended use................................................10
L
Lamps, disposal ..........................................19
M
Maintenance
Maintenance and care ........................17
Maintenance schedule........................39
Overview.............................................38
Safety information...............................43
Music channel .............................................32
O
Operator commitments................................10
Overview, operating elements.....................22
Index
83
Index
P
Permissible load ......................................... 35
Plastic surfaces........................................... 18
Power, switching off.................................... 37
Preparation time ......................................... 24
Proper use .................................................. 10
Protective goggles ...................................... 24
R
Relamping................................................... 43
Replacing UV low-pressure lamps
in canopy .................................................... 47
Room temperature...................................... 35
Running time of accent lighting................... 27
S
Safety information, maintenance ................ 43
Scheduled cleaning .................................... 38
Scheduled maintenance ............................. 39
Settings during start-up............................... 26
Skin types ..................................................... 4
Spare parts ................................................. 17
Starting tanning........................................... 24
Surround cooling, adjust speed ............ 30, 31
T
Tanning ....................................................... 24
Technical data............................................. 34
Troubleshooting .......................................... 78
U
UV high-pressure lamps.............................. 51
UV lamps, maintenance schedule............... 41
UV low-pressure lamps
Replacing, in canopy ..........................47
Replacing, in sunbed base ........... 44, 46
V
Voltage........................................................ 34
Volume........................................................33
84
Limited warranty
Warranty
JK-Products, Inc. – Limited Warranty
JK-Products, Inc. warrants its products to be free from defects in materi­als and workmanship under intended normal use as described in the unit's Operation and Instruction Manual, for a period of three (3) years from date of sale.
This Limited Warranty applies only to the original purchaser of the equip­ment through JK-Products, Inc. or its authorized dealer or distributor, and is not transferable.
Global Service Division obligations under this warranty are limited to re­pair or replacement of any defective part without charge for that part to the original purchaser, with the following exceptions:
A Fluorescent lamps are warranted against defects for a period of thirty
(30) days from date of sale.
B Only parts obtained through JK-Products, Inc., its authorized dealers
or distributors may be used. Transportation costs for parts shipped to the consumer and the return of defective parts to Global Service Di­vision are not included.
C Labor will be furnished without charge for ninety (90) days from date
of purchase only. All labor and related charges must be authorized by SUN Ergoline prior to start of repairs, and must coincide with Global
Service Division established rates and time allotment policy. D Acrylic: Refer to Manufacturer's Acrylic Warranty Policy. It is imperative that the original customer completes and returns the en-
closed warranty card within 10 days after purchase to insure valid regis­tration and coverage for potential claims.
If the warranty card is not registered, proof of purchase from JK-Prod­ucts, Inc. or its authorized dealer or distributor will be required prior to any consideration on warranty claims. This could result in service delays.
This warranty is extended to the individual or legal entity, whose name appears on the warranty registration card filed with Global Service Divi­sion, or whose name appears on the original sale document and may not be transferred to any other individual or legal entity.
This warranty does not apply to any failure of the product, or any parts of the product due to alterations, modifications, misuse, abuse, accident, improper maintenance, improper installation, acts of God or if the serial number on the product has been removed, altered or defaced. Adequate packaging must be used for returned goods to prevent freight damage.
There are no warranties which extend beyond the description on the face hereof. There is no express or implied warranty of fitness of merchantability.
The remedies provided in this limited warranty are the exclusive re­medies provided to the purchaser by Global Service Division and are provided in substitution of all other remedies. Consequential and incidental damages are excluded.
No person, firm or corporation is authorized to obligate JK-Products, Inc. for any liability in connection with the sale or use of these goods.
85
Limited warranty
Warranty
Limited Acrylic Warranty
Global Service Division warrants its acrylic sheets to be free from defects in material and workmanship, under intended normal use, for a period of one (1) year from date of sale of the tanning bed. Due to the tanning lo­tions, cosmetics, disinfectant and improper cleaners used on tanning sur­faces that cannot be controlled by Global Service Division, after the first thirty (30) days of warranty period. Acrylic will be subject to a prorated cost to the consumer on breakage.
Global Service Division obligations do not include transportation charges on replacement acrylic.
Global Service Division assumes no liability for the cost of removing de­fective sheets or installing replacement sheets, nor for damage to per­sons or property.
To make a claim, contact an authorized dealer or distributor of JK-Prod­ucts, Inc. or Global Service Division with the model number, the serial number, and the date of purchase of the bed in which the acrylic will be used.
There are no warranties which extend beyond the description on the face hereof. There is no express or implied warranty of fitness or merchantability.
The remedies provided in this limited warranty are the exclusive re­medies provided to the purchaser by Global Service Division and are provided in substitution of all other remedies. Consequential and incidental damages are excluded.
Global Service Division
#1 Walter Kratz Drive Jonesboro, Arkansas 72401
(800) 445 0624
Email: support@jkamerica.com Web: support.jkamerica.com
86
Warranty Claims
Warranty
Warranty Claims
Policy & Procedures
1. When to file a Warranty Claim: In the event that your tanning system is not functioning properly under in-
tended normal use as described in the unit's Operation an Instruction Manual, you may then have established cause to file a Warranty Claim.
2. Where to call to place a Warranty Claim: JK-Products, Inc. is supported nationwide by an extensive dealer/distrib-
utor network through whom the majority of our units are sold. These deal­ers/distributors are required by contract to stock sufficient parts to meet the various warranty and nonwarranty needs of their customers.
Therefore, in order for you to properly file a Warranty Claim, you must lo­cate the name and phone number of the dealer/distributor through whom you purchased your unit. Normally this information can be easily located either on your paid invoice or other proof of purchase documentation that you received when taking delivery of the unit.
Next, notify the dealer/distributor of the serial number, model number and date unit was purchased. This will initiate the Warranty Claim process.
Upon determination of the problem, your dealer/distributor can then sup­ply you with the part(s) and proper instructions to return your unit to work­ing order.
Each dealer/distributor has their own internal procedure for handling Warranty Claims and credits.
Parts Warranty Claim/Credit Review
1. Customer calls Global Service Division and notifies the Service De­partment of problem.
2. Global Service Division determines course of action.
3. Global Service Division ships part and R.A. to customer freight collect and bills customer on net 30 basis for part only.
4. Customer, within 15 days of receiving new part, returns defective part to Global Service Division along with R.A. number.
5. Upon receipt of defective part and R.A., Global Service Division is­sues customer a credit invoice which offsets original bill. Customer's account is returned to zero balance concerning this claim.
NOTE:
Both the tanning system and legal registered owner must meet the criteria established under Global Service Division Limited Warranty as described in this manual before any Warranty Claim will be considered.
NOTE:
JK-Products, Inc., the manufacturer, does not involve itself in the direct handling of a Warranty Claim except where mit­igating circumstances apply and where required by law.
87
Warranty Claims
Warranty
Acknowledgment of the Agreement is not required for acceptance of the foregoing stipulations.
Labor Warranty Claim/Credit Procedures
Global Service Division furnishes labor without charge for a period of 90 days from date of purchase. All labor and related charges must be autho­rized by Global Service Division prior to start or repairs, and must coin­cide with Global Service Division established rates and time allotment policy.
Please contact our Service Department for authorization and billing pro­cedures.
Limited Lifetime Warranty
Global Service Division warrants specific individual components of the tanning system against defects in materials and workmanship for the life of the product. Coverage is limited to units purchased after November 1,
1994.
This warranty is restricted by the following components only:
• Steel Back Panels
• Structural Steel Frame Components
• Exterior Steel Body.
Warranty coverage does not include cosmetic abnormalities such as scratches, nicks, dents, oxidation of paint or other cosmetic changes that do not interfere with the designed function of the unit.
This warranty does not include failure of the product due to alteration, modifications, misuse, abuse, improper maintenance, improper installa­tion or repair.
This warranty is not transferable and is only applicable to the original pur­chaser named on a completed and registered warranty record at JK­Products, Inc. headquarters.
Global Service Division obligations do not include transportation charged on the shipping of new components to the customer or on the return of
NOTE:
If part returned to Global Service Division proves to be op­erational and not defective, or if product code numbers on part do not correspond with individual unit date on file with Global Service Division, then a 30% restocking fee will be charged in addition to the retail purchase price of part.
NOTE:
Components are warranted on an individual basis and not as they may effect the complete product.
88
Warranty Claims
Warranty
defective components of the manufacturer. All freight charges must be paid by the customer.
There are no warranties which extend beyond the description on the face hereof. There is no express or implied warranty of fitness or merchant­ability.
The remedies provided in this limited warranty are the exclusive reme­dies provided to the purchaser by Global Service Division and are provid­ed in substitution of all other remedies. Consequential and incidental damages are excluded.
NOTE:
Any misuse, abuse, modification, alteration, improper main­tenance, improper installation, etc. of this product or its in­tended use will subject said party to direct responsibility and liabilities for any and all consequences resulting from such action. Furthermore, such actions will void all warranties and may relieve Global Service Division of any liabilities re­lating to said product.
89
Service après-vente
Identifiez votre solarium
Veuillez noter le numéro de série de votre solarium lorsque vous contactez le service après-vente.
Global Service Division
#1 Walter Kratz Drive Jonesboro, Arkansas 72401
800-445-0624 870-935-9046
e-mail: support@jkamerica.com
91
90
Temps de bronzage
Types de peau
Types de peau
Pour le plan d'exposition recommandé (cf. page 91).
Type de peau I (hypersensible) :
Type de personne qui est toujours sujet aux brûlures et ne bronze pas. Il est conseillé aux personnes à peau claire qui bronzant jamais de ne pas utiliser cet appareil.
Type de peau II (sensible) :
C'est le type de personne facilement et fortement sujet aux brûlures, qui bronze de façon minimale ou légère et qui pèle.
Type de peau III (moyenne) :
Souvent désigné par teint « moyen », brûlures modérées et bronzage moyen.
Type de peau IV (brune) :
Brûlures minimales, bronzage aisé et au-dessus de la moyenne à chaque exposition.
Type de peau V (brun foncé) :
Ce genre de personne n'est sujet que rarement à des brûlures, bronzant aisément et en profondeur.
Temps de bronzage
91
Temps de bronzage
« En termes de performances standard, ce produit est conforme aux exigences applicables aux appareils équipés de lampes à rayons ultraviolets selon la norme CFR21 Part 1040. »
Note :
Description des types de peau, voir page 90.
92
Avant-propos
Avant-propos
Cher client,
L'appareil Ergoline que vous avez acheté est un système de commande à ordinateur performant et intégrant les dernières avancées de la tech­nologie. La fabrication de votre appareil a fait l'objet d'un soin et d'une précision extrêmes. Il a été soumis à un contrôle qualité rigoureux et à de nombreux tests de sécurité afin d'en garantir le fonctionnement sûr et sans problèmes. Vous restez néanmoins un acteur important pour ga­rantir la longévité de votre appareil. Si vous suivez les conseils et les in­formations spécifiés dans les instructions d'installation, votre appareil vous apportera entière satisfaction.
Nous sommes toujours à votre disposition si vous avez des questions.
1)
Avec nos meilleures salutations
JK-Products, Inc.
• Lisez et observez les informations contenues dans ce manuel d'instructions. Elles vous permettent d'éviter les accidents et d'avoir un appareil en parfait état de fonctionnement.
• Tenez toujours également compte des réglementations et prescrip­tions légales générales ou autres, ainsi que les directives de protec­tion de l'environnement.
1) (800) 643 0086
Note :
Les illustrations et les informations fournies dans le présent mode d'emploi le sont sous réserve de modifications tech­niques. Toute reproduction ou duplication, partielle ou complète, de ce manuel n'est autorisée qu'après autorisation écrite préa­lable et avec référence à la source.
Table de matières
93
Table de matières
Table de matières
Types de peau . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Temps de bronzage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Consignes de sécurité et informations importantes. . . . . . 95
Notes relatives à la sécurité. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Utilisation conforme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Obligations de l'exploitant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Instructions relatives a un risque d'incendie, de choc électrique ou de
blessures corporelles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Instructions relatives à un risque de dommage matériel . . . . . . . . . . . 99
Signification des symboles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Directives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Exportation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Accessoires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Information sur le produit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Maintenance et entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Nettoyage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Information relative à la protection de l'environnement . . . . . . . . . . . 106
Bronzer – mais comme il faut ! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Tableau de service. . . . . . . . . . . . . . . . . . . . . . . . . . Page dépliable 110
Accessoires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Séance de bronzage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Fin de la séance de bronzage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Réglages pendant le démarrage . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Durée de fonctionnement des lampes décoratives. . . . . . . . . . . . . . .115
Fonction IR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Réglage des bronzeurs faciaux . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Allumage et extinction du système air conditionné. . . . . . . . . . . . . . .118
Réglage de ventilateur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Sélection des chaînes musicales . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Réglage du volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Caractéristiques techniques. . . . . . . . . . . . . . . . . . . . . . . . 122
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Couper la tension sur l’appareil et verrouiller contre
la remise en marche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Maintenance, vue d'ensemble . . . . . . . . . . . . . . . . Page dépliable 126
Intervalles de maintenance, lampes installées et numéros d'ordre . 127 Instructions relatives au remplacement des lampes / maintenance . 131 Nettoyage/remplacement des lampes UV basse pression
dans la partie inférieure du solarium. . . . . . . . . . . . . . . . . . . . . . . . . 132
94
Table de matières
Table de matières
Nettoyage/remplacement des lampes UV basse pression
dans la partie latérale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Nettoyage/remplacement des lampes UV basse pression dans
la partie supérieure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Nettoyage/remplacement de l'éclairage intérieur. . . . . . . . . . . . . . . . 137
Nettoyage/remplacement des lampes UV
haute pression/panneaux filtrants . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Nettoyage/remplacement de lampe décorative
dans la partie supérieure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Légende Ergoline : Nettoyer/changer l'éclairage de décoration . . . . 145
Nettoyage/remplacement des lampes décoratives dans le panneau
frontal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Nettoyage des filtres dans la partie inférieure du solarium . . . . . . . . 149
Nettoyage/remplacement des filtres
dans la partie supérieure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Nettoyer les filtres dans le panneau arrière . . . . . . . . . . . . . . . . . . . 152
Système d'air conditionné : Vider le réservoir de condensat. . . . . . . 153
Système d'air conditionné : Nettoyer/changer le feutre de filtre,
nettoyer les ailettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Régler le mécanisme de fermeture de la partie supérieure. . . . . . . . 160
Réglages préliminaires . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
Réglages préliminaires via le tableau de commande . . . . . . . . . . . . 161
Réglages préliminaires à l'aide d'un ordinateur de poche . . . . . . . . . 163
Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Index alphabétique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Garantie limitée JK-Products, Inc. . . . . . . . . . . . . . . . . . . . 172
Service avec minuterie . . . . . . . . . . . . . . . voir manuel séparé
Veuillez lire et observer …
95
Notes relatives à la sécurité
Consignes de sécurité et informations importantes
Notes relatives à la sécurité
Description des panneaux d'avertissement
Notes relatives aux dangers, blessures corporelles :
Notes d'avertissement, blessures corporelles :
Notes de prudence, dommages matériels :
Information importante :
ANGER !
Type et source de danger, par ex. « DANGER – haute tension ! »
Description des conséquences, par ex. « Danger de mort ou de blessures des suites d'un choc électrique ! »
Contre-mesures : – Débranchez l'appareil de l'alimentation secteur avant
l'ouverture.
– N'intervenez pas à l'intérieur et ne changez pas de lam-
pes quand l'appareil est sous tension.
AVERT. !
Type et source de danger, par ex. « Avertissement – surface chaude ! »
Description des conséquences, par ex. « Risque de brûlu­res aux mains (peau, visage) ! »
Contre-mesures : – Ne touchez pas aux lampes et aux surfaces
avoisinantes.
– Attendez que les lampes et les surfaces soient
refroidies.
ATTENTION !
Le mot « ATTENTION » sur cette étiquette indique un dan­ger potentiel pour les équipements, le matériel et l'environ­nement.
Note :
Ce symbole ne concerne pas les notes relatives à la sécurité ; il ne fournit que des informations pour mieux com­prendre les processus.
96
Veuillez lire et observer …
Notes relatives à la sécurité
Utilisation conforme
Le solarium est conçu exclusivement pour le bronzage cosmétique du corps humain.
• Cet appareil est exclusivement destiné à un usage professionnel.
• Cet appareil est utilisé pour le bronzage d'une personne adulte à la fois.
• L'utilisateur porte des lunettes de protection des yeux neutralisant les rayons UV pendant le bronzage.
Toute utilisation autre est considérée comme non conforme. Le construc­teur décline toute responsabilité pour les dommages ou blessures susceptibles d'en résulter. Lutilisateur est seul responsable.
Par utilisation conforme, on entend également le respect des remarques, conditions d'utilisation, d'entretien et des prescriptions du constructeur. Le service, l'entretien et la remise en état de l'appareil sont réservés aux personnes familiarisées avec ces tâches et instruites des risques éven­tuels.
Obligations de l'exploitant
• En tant qu'exploitant, vous êtes tenu d'informer les utilisateurs sur les risques éventuels pendant le bronzage.
• Toutes les indications relatives aux dangers et à la sécurité sur l'ap­pareil doivent être observées. Ne pas les enlever !
• Aucun équipement de sécurité (par ex. interrupteur de panneau) ne doit être enlevé ou désactivé pour ne pas nuire à un fonctionnement sûr de l'appareil !
• L'appareil ne doit être utilisé que lorsqu'il est en parfait état de fonctionnement !
• L'exploitant est tenu de s'assurer que l'équipement est utilisé correc­tement.
Veuillez lire et observer …
97
Notes relatives à la sécurité
Instructions relatives a un risque d'incendie, de choc électrique ou de blessures corporelles
1) Global Service Division – voir à page 89.
ANGER !
DANGER – haute tension !
Danger de mort ou de blessures des suites d'un choc électrique !
Le montage et les branchements électriques doivent être effectués de façon conforme aux réglementations nationa­les et locales.
– Le montage, l'installation, la mise à niveau et la
réparation de l'appareil doivent être exclusivement ré­servés à un personnel formé et instruit en conséquence.
AVERT. !
Avertissement – rayons ultraviolets !
Un bronzage sans protection peut entraîner des blessures et des dommages des yeux.
L'œil non protégé peut subir une inflammation en surface avec, dans certains cas, un endommagement de la rétine des suites d'un rayonnement excessif. Des cataractes peu­vent se former après une exposition fréquente aux rayons.
Informez les utilisateurs pour les prévenir d'utiliser
les lunettes de protection fournies contre les UV (n° de commande 84592
1)
).
AVERT. !
Avertissement – rayons ultraviolets ! Veuillez suivre les instructions suivantes !
Sans dispositif de protection des yeux, ce produit peut cau­ser des brûlures ou lesions oculaires graves. En cas de pro­blème arreter l’utilisation et consulter un médecin.
– Les pesonnes ne bronzant pas au soleil ne le feront pro-
bablement pas sur cet appareil. Les sujets à la peau très sensible (type de peau I) ne doivent pas utiliser l'appa­reil car aucun bronzage n'est possible sans coup de so­leil avec ce type de peau.
– Les personnes qui ont des coups de soleil, qui avaient
ou qui ont un cancer de la peau ou les personnes expo­sées à un risque accru de cancer, ne doivent pas utiliser cet appareil.
– Les appareils UV ne doivent pas être utilisés sans avis
médical en cas d’apparition de symptômes inattendus, tels que des démangeaisons, dans les 48 heures sui­vant la première exposition.
– Le solarium ne doit en aucun cas être utilisé s'il manque
un disque de filtre ou si les disques ou la minuterie sont endommagés !
– La lumière UV du soleil et des appareils UV peuvent
provoquer des dommages pour les yeux et la peau. Cet effet biologique dépend de la sensibilité de la peau de chacun, et du type et de la quantité de la lumière UV.
– Comme avec les rayons solaires naturels, une exposi-
tion trop longue peut causer coup de soleil ou brûlure.
98
Veuillez lire et observer …
Notes relatives à la sécurité
AVERT. !
– Une exposition répétée peut causer un vieillissement
prématuré de la peau ou un cancer de la peau.
– L’utilisation de certains médicaments ou produits appli-
qués sur la peau peut accroître la sensibilité aux ultra­violets.
– Toute personne ayant des problèmes de peau doit con-
sulter un médecin avant toute utilisation.
AVERT. !
Avertissement – rayons ultraviolets !
Danger de conséquences à long terme. – Eviter toutes surexposition. – Il est conseillé aux personnes agées de ne pas utiliser
cet appareil.
– Les nourrissons et les petits enfants jusqu'à 7 ans ne
doivent pas utiliser cet appareil.
– Ce qui suit concerne les mineurs de moins de 18 ans :
n'utilisez les solariums qu'avec l'autorisation d'un parent ou d'un tuteur, ou après avoir consulté un médecin.
– Bien qu'il n'existe pas de symptôme clinique immédiat
des suites de l'exposition aux UVA et de ses effets sur les femmes enceintes, il est fortement recommandé de déconseiller l'utilisation du solarium à ces femmes.
AVERT. !
Avertissement : Risque d'infection !
Les infections peuvent se propager par contact de la peau. Tous les articles et équipements avec lesquels l'utilisateur
peut entrer en contact pendant la séance de solarium doi­vent être désinfectés au terme de chaque séance de sola­rium :
• Lunettes de protection
• Repose-tête
• Partie inférieure du solarium en matériau acrylique
• Panneau de manipulation et de commande.
Veuillez lire et observer …
99
Notes relatives à la sécurité
Instructions relatives à un risque de dommage matériel
Note :
Les personnes utilisant le solarium pourront noter occa­sionnellement de légères rougeurs de la peau – normale­ment par petites taches – après la deuxième ou la troisième séance. Ces rougeurs s'accompagnent fréquemment de démangeaisons. Ceci ne peut être rien d'autre qu'une in­flammation due à la chaleur dégagée par les lampes dans l'appareil. Elle est en règle générale très limitée et causée par le contact constant de la peau et de la surface acrylique. Elle disparaît normalement au bout d'environ 24 heures et ne réapparaît pas. Cette éruption peut être réduite ou em­pêchée par l'application d'une lotion hydratante sur la zone affectée une fois la séance de bronzage terminée.
– Suivre les instructions. – L'intervalle entre les deux premières séances de bron-
zage doit être d'au moins 24 heures !
– L'augmentation du bronzage requiert également une
augmentation du temps d'exposition (= durée de radia­tion) ou une nouvelle intensification n'est plus possible une fois un certain degré de bronzage atteint. Toutefois la durée d'exposition au rayonnement ne doit pas être prolongée sans considération à l'intérieur des limites de rayonnement tolérable. En conséquence, les sujets ne peuvent parvenir qu'à un certain degré de bronzage en fonction de leur type de peau, sans risque pour leur san­té.
– Informer les utilisateurs sur le bronzage correct.
ATTENTION : danger de surchauffage !
Danger de surchauffage par obstruction de la sortie d’air. – Ne modifiez, bouchez ou bloquez pas l'entrée et la sor-
tie d'air vers l'appareil et ne procédez à aucune transfor­mation non autorisée de l'appareil. Le constructeur décline toute responsabilité pour les dommages ou les blessures susceptibles d'en résulter.
– L'appareil ne doit pas être installé ni exploité sur la pa-
lette de transport ! Risque de surchauffe due à la pertur­bation de la diffusion d'air.
Loading...
