Equator ED 620 User Manual

Dryer

ED 620

Owner’s Manual

TABLE OF CONTENTS

Warranty……………………………………………………………………………2-3

Introduction ………………………………………………………………………….4

Important Safety Instructions ………………………………………………………5

Helpful Hints & Dryer Efficiency……………………………………………………6

Pre-Installation……………………………………………………………………….7

Picture of the Dryer ………………………………………………8

Installation ………………………………………………………………………9-11

Control Panel……………………………………………………………………11-12

Operating Instructions …………………………………………………………….13

How to dry ………………………………………………………………………….14

Maintenance ……………………………………………………………………….15

Technical Data …………………………………………………………………….15

Troubleshooting. ………………………………………………….……………… 16

Company Information …………………………………………………………….17

Please read the Owner’s Manual carefully before using your

new Equator Dryer

1 Tumble Dryer Owner’s Manual

WARRANTY INFORMATION

Your Equator Appliance is protected by this warranty under normal,

personal, family or household use

(5 Year Limited Warranty - 1st year parts & labor, 2nd year parts,

3rd-5th year main motor), and limited commercial use (90 days)

in the USA and Canada.

WARRANTY

Manufacturer undertakes to the consumer-owner to repair or, at our option, to replace any
part of this product which proves to be defective in workmanship or material under normal
personal, family or household use, in the USA and Canada, for a period of one year from the
date of original purchase. For commercial use, the product is warranted for a period of 90
days. During this period, we will provide all labor and parts necessary to correct such defect,
free of charge, if the appliance has been installed and operated in accordance with Equator
Appliances’ written instructions with the appliance. Ready access to the appliance, for
service, is the responsibility of the consumer-owner. Equator Appliances will not be
responsible for the installation and uninstallation of the unit.

EXCLUSIONS

In no event shall Equator Appliances be liable for incidental or consequential damages or for
damages resulting from external causes such as abuse, misuse, incorrect voltage or acts
God. This warranty does not cover service calls which do not involve defective workmanship
or materials covered by this warranty or incorrect installation procedures. Accordingly,
diagnosis and repair costs for a service call which does not involve defective workmanship
or materials will be the responsibility of the consumer-owner.

Specifically, the following work is not covered under warranty and does not constitute warranty work:

 Installation – e.g. improper hook-up or leveling or non-removal of shipping bolts
 Maintenance – e.g. cleaning of air and/or water filter
 Damage – e.g. replacing broken door handle / damage to cabinet or external parts.
 RV’s / Boats – e.g. excessive movement caused by travel or movement of vehicle.

Most work is covered. The defining factor is, has the machine malfunctioned (manufacturer
is responsible) or has the customer omitted or done something to cause machine to
malfunction (customer is responsible). Some States do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply
to you.

REMOTE LOCATIONS

In case the area of service is in a remote location, Equator Appliances may have to request for the appliance to be taken to the nearest authorized service agent we can find in order to provide service.

2 Tumble Dryer Owner’s Manual

WARRANTY SERVICE

This warranty is given by:

Equator Appliances

2801 W Sam Houston Pkwy N, Suite 150

Houston, TX 77043-1611

Service under this warranty must be obtained by the following steps, in order:

Call a Equator Appliances Authorized Service Agent (obtain number of nearest agent
from your dealer or by calling Equator Service at 1-800-678-8002). Under normal
circumstances, Service will be provided during regular business hours (9:00 a.m. to 5:00
p.m. weekdays).

GENERAL

Since it is responsibility of the consumer-owner to establish the warranty period by verifying
the original purchase date, Equator Appliances recommends that a receipt, delivery slip or
some other appropriate payment record be kept for that purpose. Remember to send in your
Warranty Registration Card so that a proof of your purchase exists with Equator Appliances.
You can also register online or by calling Equator Appliances Customer Service at
1-866-218-6902. This warranty gives yo u s p e c i f i c l egal rights, and you may also have other
rights, which vary from State to State.

Corporate Office Equator Appliances

2801 W Sam Houston Pkwy N, Suite 150
Houston, TX 77043-1611
Phone [phone]
Fax [phone]
Toll Free: [phone]

European Testing Laboratories

US N°3094367 CANADA

The ETL Listed Mark is the legal equivalent to the UL and CSA Listed Marks

Equator CONTACTS

Website: www.equatorappliances.com

Service: 1-866-218-6903/ [e-mail]
Parts & Accessories: [e-mail]
Technical Support: [e-mail]

3 Tumble Dryer Owner’s Manual

INTRODUCTION

Congratulations on your new Equator Vented Tumble Dryer. In addition to its
unique design, this is a highly sophisticated product that will give you many
years of satisfaction. Please take the time to read this Owner’s Manual in order
to understand the machine and get the best use out of your valuable purchase.

Here are some of the best reasons for buying your Equator Dryer:

1. Energy Savings

This appliance is engineered to provide valuable energy savings when compared to other
dryers.

2. Space Savings

The Dryer is designed to utilize horizontal and vertical space effectively. By using the
stacking kit (available separately) this unit can be mounted onto the Equator Combo
Washer-Dryer or the Equator Washer.

3. Temperature Selection

Choose your drying temperature for the quantity and quality of clothes you place in the dryer.
High and low heat settings are available for cottons/mixed thread clothing and for delicates.

4. Meeting Standards

The dryer vent uses a standard 4" duct that fits dryer exhaust.

5. Convenient Lint Control

This unit does not use a lint filter and no cleaning is required after every load.

6. 110V operation

The dryer power cord plugs into a standard 110V outlet - available in most homes.

7. Safety

The dryer has a built in safety switch that reset when airflow is restricted. This lets the dryer
electronics remain unharmed by pausing the appliance till the conditions are corrected.

8. Easy Operation

Just set the dryer time based on type of clothing and press the Power button.

9. Convenience

This appliance can be permanently installed and be made portable with the installation of the
portability kit (sold separately) where needed.

4 Tumble Dryer Owner’s Manual

y

IMPORTANT SAFETY INSTRUCTIONS

Your safety and that of you children

Your machine has been built in compliance with safety regulations, to protect
you and all your family.

WARNING - To reduce the risk of fire, electric shock, or injury to persons when using

your appliance, follow basic precautions, including the following:

1. Read all instructions before using the appliance.

2. Do not dry articles that have been previously cleaned in, washed in, or spotted with
gasoline, dry-cleaning solvents, other flammable or explosive substances, as the
emit vapors that could ignite or explode.

3. Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is used near children.

4. Before the appliance is removed from service or discarded, remove the door.

5. Do not reach into the appliance if the tub or drum is moving.

6. Use caution as drum interior becomes hot after use.

7. Do not install or store this appliance where it will be exposed to the weather.

8. Do not tamper with controls.

9. Do not repair or replace any part of the appliance or attempt any servicing unless
specifically recommended in the user-maintenance instructions or in published user­repair instructions that you understand and have skills to carry out.

10. Do not use fabric softeners or products to reduce static unless recommended by the
Equator appliance of the fabric softener product.

11. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like
materials.

12. For vented dryers keep the exhaust opening and surrounding areas free from
accumulation of lint, dust, and dirt.

13. Do not place items exposed to cooking oils in your dryer. Item contaminated with

cooking oils may contribute to a chemical reaction that could cause a load to catch
fire.

SAVE THESE INSTRUCTIONS

5 Tumble Dryer Owner’s Manual
