Epson V11H840041 Product Data Sheet

EB-W05

DATASHEET

For home or work, this easy-to-use, 3,300-lumen WXGA
projector with optional Wi-Fi can create a 320-inch display.

Do you love the big-screen experience, but also need a projector that will deliver
striking presentations? This WXGA projector with 3,300 lumens of brightness
and 3LCD technology has the tools for the job. Designed with portability in mind,
it's easy to transport and set up. It’s competitive too, with a fantastic range of
features and a long lamp life providing 15 years' worth of entertainment1.

Bigger is better

Whether you’re watching blockbusters or delivering a presentation, this projector
can achieve an impressive 320-inch display. It's great quality too, with 3LCD
technology that makes the display up to three times brighter than competitor
products2. In addition to its bright and vivid colours, the 15,000:1 contrast ratio
produces defined shadows and deep blacks. From family and friends to
business colleagues and clients, it's sure to get everyone’s attention.

High-quality, bright images

Even in bright rooms, this powerful yet affordable WXGA projector delivers
exceptionally bright yet colourful images with clear details. It's all thanks to 3LCD
technology, which produces an equally high White and Colour Light Output of
3,300 lumens.

Long-lasting solution

Looking for a long-term, hassle-free and affordable solution for your projection
needs? With this model's long-lasting lamp light source, you could watch a film
every day for 15 years1.

KEY FEATURES

Create the big screen experience

From box sets to business
presentations, capture everyone's
attention

Bright even with ambient light

Equally high White and Colour Light
Output of 3,300 lumens

Affordable, high-tech equipment

Enjoy this WXGA projector

Long-lasting solution

Watch a film every day for 15 years

Portable and quick to set up

Easy to position with keystone slider

1

Stress-free set up

Here’s a projector that’s designed with portability and quick set up in mind.
Position the image with keystone correction and access content simply with the
HDMI inputs. Thanks to the optional ELPAP10 adapter, it offers Wi-Fi
connectivity allowing you to share content from a smart device using the
iProjection app.

PRODUCT SPECIFICATIONS

TECHNOLOGY

Projection System 3LCD Technology, RGB liquid crystal shutter
LCD Panel 0.59 inch with MLA (D9)


Colour Light Output 3,300 lumen- 2,050 lumen (economy) In accordance with IDMS15.4
White Light Output 3,300 lumen - 2,050 lumen (economy) In accordance with ISO 21118:2012
Resolution WXGA, 1280 x 800, 16:10
Contrast Ratio 15,000 : 1
Lamp UHE, 210 W, 6,000 h durability, 10,000 h durability (economy mode)
Keystone Correction Auto vertical: ± 30 °, Manual horizontal ± 30 °
Colour Reproduction Upto 1.07 billion colours
High Definition HD ready

OPTICAL

Projection Ratio 1.30 - 1.56:1
Zoom Manual, Factor: 1.2
Image Size 33 inches - 320 inches
Projection Distance Wide/Tele 1.68 m - 2.02 m ( 60 inch screen)
Projection Lens F Number 1.49 - 1.72
Focal Distance 16.9 mm - 20.28 mm
Focus Manual
Offset 10 : 1

CONNECTIVITY

USB Display Function 2 in 1: Image / Mouse
Interfaces USB 2.0 Type A, USB 2.0 Type B, VGA in, HDMI in, Composite in, Cinch audio in, Wireless LAN

IEEE 802.11b/g/n (optional)

Epson iProjection App Ad-Hoc / Infrastructure

ADVANCED FEATURES

Security Kensington lock, Security cable hole, Wireless LAN unit lock, Password protection
3D No
Features AV Mute Slide, Automatic keystone correction, Built-in speaker, Horizontal and vertical

keystone correction, Long lamp life, Quick Corner

Video Colour Modes Blackboard, Cinema, Dynamic, Presentation, sRGB

GENERAL

Energy Use 282 W, 203 W (economy), 0.2 W (standby), On mode power consumption as defined in JBMS-

84 257 W
Product dimensions 302 x 237 x 82 mm (Width x Depth x Height)
Product weight 2.5 kg
Noise Level Normal: 37 dB (A) - Economy: 28 dB (A)
Loudspeaker 2 W
Colour White

OTHER

Warranty 24 months Carry in, Lamp: 12 months or 1,000 h

EB-W05

WHAT'S IN THE BOX

Main unit
Power cable
Quick Start Guide
Remote control incl. batteries
User manual (CD)
Warranty card
