Epson S1C33 User Manual

MF1200-02

CMOS 32-BIT SINGLE CHIP MICROCOMPUTER

S1C33 Family

Debug Monitor Operation Manual

NOTICE

No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko
Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any
liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or
circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such
as medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there
is no representation or warranty that anything made in accordance with this material will be free from any patent or copyright
infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic
products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from
the Ministry of International Trade and Industry or other approval from another government agency.

Windows 95, Windows 98 and Windows NT are registered trademarks of Microsoft Corporation, U.S.A.
PC/AT and IBM are registered trademarks of International Business Machines Corporation, U.S.A.
All other product names mentioned herein are trademarks and/or registered trademarks of their respective owners.

© SEIKO EPSON CORPORATION 2001 All rights reserved.

The information of the product number change

Starting April 1, 2001, the product number will be changed as listed below. To order from April 1,
2001 please use the new product number. For further information, please contact Epson sales
representative.

Configuration of product number

Devices

S1 C 33104 F 0A01

Development tools

S5U1

∗1: For details about tool types, see the tables below. (In some manuals, tool types are represented by one digit.)
∗2: Actual versions are not written in the manuals.

C 33L01 D1 1

00

Packing specification
Specification
Package (D: die form; F: QFP)
Model number
Model name (C: microcomputer, digital products)
Product classification (S1: semiconductor)

00

Packing specification
Version (1: Version 1 ∗2)
Tool type (D1: Development Tool ∗1)
Corresponding model number (33L01: for S1C33L01)
Tool classification (C: microcomputer use)
Product classification
(S5U1: development tool for semiconductor products)

Comparison table between
new and previous number

S1C33 Family processors

Previous No.
E0C33A104
E0C33202
E0C33204
E0C33208
E0C33209
E0C332T01
E0C332L01
E0C332L02
E0C332S08
E0C332129
E0C33264
E0C332F128

Previous No.
CC33
CF33
COSIM33
GRAPHIC33
HMM33
JPEG33
MON33
MELODY33
PEN33
ROS33
SOUND33
SMT33
TS33
USB33
VOX33
VRE33

New No.
S1C33104
S1C33202
S1C33204
S1C33208
S1C33209
S1C33T01
S1C33L01
S1C33L02
S1C33S01
S1C33221
S1C33222
S1C33240

New No.
S5U1C33000C
S5U1C330C1S
S5U1C330C2S
S5U1C330G1S
S5U1C330H1S
S5U1C330J1S
S5U1C330M2S
S5U1C330M1S
S5U1C330P1S
S5U1C330R1S
S5U1C330S1S
S5U1C330S2S
S5U1C330T1S
S5U1C330U1S
S5U1C330V1S
S5U1C330V2S

Comparison table between new and previous
number of development tools

Development tools for the S1C33 Family

Previous No.
ICE33
EM33-4M
PRC33001
POD33001
ICD33
DMT33004
DMT33004PD
DMT33005
DMT33005PD
DMT33006LV
DMT33006PDLV
DMT33007
DMT33007PD
DMT33008LV
DMT33008PDLV
DMT332S08LV
DMT332S08PDLV
DMT33209LV
DMT33209PDLV
DMT332F128LV
DMT33MON
DMT33MONLV
DMT33AMP
DMT33AMP2
DMT33AMP3
DMT33AMP4
DMT33CF
DMT33CPLD400KLV

New No.
S5U1C33104H
S5U1C33104E
S5U1C33104P1
S5U1C33104P2
S5U1C33000H
S5U1C33104D1
S5U1C33104D2
S5U1C33208D1
S5U1C33208D2
S5U1C33L01D1
S5U1C33L01D2
S5U1C33208D3
S5U1C33208D4
S5U1C33T01D1
S5U1C33T01D2
S5U1C33S01D1
S5U1C33S01D2
S5U1C33209D1
S5U1C33209D2
S5U1C33240D1
S5U1C330M1D1
S5U1C330M2D1
S5U1C330A1D1
S5U1C330A2D1
S5U1C330A3D1
S5U1C330A4D1
S5U1C330C1D1
S5U1C330C2D1

Previous No.
DMT33LIF
DMT33SMT
DMT33LCD26
DMT33LCD37
EPOD33001
EPOD33001LV
EPOD33208
EPOD33208LV
EPOD332L01LV
EPOD332T01
EPOD332T01LV
EPOD33209
EPOD33209LV
EPOD332128
EPOD332128LV
EPOD332S08LV
MEM33201
MEM33201LV
MEM33202
MEM33202LV
MEM33203
MEM33203LV
MEM33DIP42
MEM33TSOP48
EPOD176CABLE
EPOD100CABLE
EPOD33SRAM5V
EPOD33SRAM3V

New No.
S5U1C330L1D1
S5U1C330S1D1
S5U1C330L2D1
S5U1C330L3D1
S5U1C33208E1
S5U1C33208E2
S5U1C33208E3
S5U1C33208E4
S5U1C33L01E1
S5U1C33T01E1
S5U1C33T01E2
S5U1C33209E1
S5U1C33209E2
S5U1C33220E1
S5U1C33220E2
S5U1C33S01E1
S5U1C33001M1
S5U1C33001M2
S5U1C33002M1
S5U1C33002M2
S5U1C33003M1
S5U1C33003M2
S5U1C330D1M1
S5U1C330T1M1
S5U1C33T00E31
S5U1C33S00E31
S5U1C33000S
S5U1C33001S

TABLE OF CONTENTS

Preface

Written for those who develop applications using the S1C33 Family of microcomputers, this manual describes how to
implement the S1C33 Family debug monitor library S5U1C330M2S and how to debug the target program.

Table of Contents

1 S5U1C330M2S Package ................................................................................................1

1.1 Features......................................................................................................................................................................1

1.2 Components of S5U1C330M2S Package......................................................................................................2

1.3 Installation...................................................................................................................................................................2

2 Implementing the Debug ..............................................................................................4

2.1 Resources Required for the Debug Monitor..................................................................................................4

2.2 Starting Up the Debug Monitor...........................................................................................................................5

2.3 Building an Application Program........................................................................................................................6

2.4 Creating Communication Control Routines...................................................................................................7

3 Target Program and Debugging..................................................................................10

3.1 Notes for Creating Target Programs.............................................................................................................10

3.2 Parameter File for Debugging..........................................................................................................................10

3.3 Starting Up and Terminating Procedure of Debugging..........................................................................11

3.4 Debugging Method...............................................................................................................................................12

3.5 Precautions for Debugging................................................................................................................................14

3.5.1 Restriction on Debugging Command..........................................................................................14

3.5.2 Other Precautions ..............................................................................................................................14

Appendix S5U1C330MxD1 Board ................................................................................15

A.1 Outline of S5U1C330MxD1 Board.................................................................................................................15

A.2 Names and Functions of Each Part..............................................................................................................15

A.3 Connecting the System......................................................................................................................................16

A.4 S5U1C330MxD1 Block Diagram....................................................................................................................17

A.5 Program Debugging with a S5U1C33xxxDx Board and S5U1C330M2S.......................................18

A.6 Indispensable Signal Pins of S5U1C330MxD1.........................................................................................21

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

i

1 S5U1C330M2S PACKAGE

1 S5U1C330M2S Package

The Debug Monitor S5U1C330M2S is a middleware designed for S1C33 Family single-chip
microcomputers.
It provides program-debugging functions on the user target board or for the actual product.

1.1 Features

The following lists the features of S5U1C330M2S:

• It is provided as a library file that can be linked to the user program.

This package also contains source codes of all the modules.

• S5 U1 C33 0M2 S u se s a pp r ox . 1 0KB RO M, a pp r ox . 2 .5K B RA M a nd a c ha n ne l o f s er i a l i nt er f a c e o n t he S1 C33

chip. It allows direct program debugging via the S5U1C330MxD1 board using the debugger db33 on the personal
computer.

• Allows debugging of the target program in the RAM, ROM or Flash memory on the target board.

• Supports the following debugging functions:

- Successive execution and step execution of the program

- PC break and data break

- Memory/register operation

- Flash memory writing

A configuration of the debugging system is shown in Figure 1.1.1.

Target board

S1C33xxx

Serial

interface

External

RAM

External

ROM

Figure 1.1.1 Configuration of debugging system

FLASH

memory

S5U1C330MxD1
interface board

RS232C

115,200 bps

Debugger

db33

EPSON

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

1

1 S5U1C330M2S PACKAGE

1.2 Components of S5U1C330M2S Package

The following lists the contents of S5U1C330M2S Package:
When unpacking, make sure that all of the following components are included.
(1) Tool disk (3.5' FD for PC/AT, 1.44MB) 1
(2) S1C33 Family Debug Monitor Operation Manual (this manual) 2 (1 English/1 Japanese)
(3) Warranty 2 (1 English/1 Japanese)

1.3 Installation

S5U1C330M2S needs to be linked with the user program as it is implemented. Therefore, make sure all tools of the
"S1C33 Family C Compiler Package" have been installed in the personal computer and are ready to run before
installing the S5U1C330M2S files. The basic system configuration is described below.

• Personal computer:
IBM PC/AT or compatible
(PC with Pentium 90 MHz or higher and 32MB or more memory recommended)
One channel of the serial port is used to communicate with the debug monitor.

• OS:

Windows95, Windows NT 4.0 or higher version (English version or Japanese version)

All the S5U1C330M2S files are supplied on one floppy disk. Execute the self-extract file "mon33vXX.exe" on the
FD to install the files. ("XX" in the file name represents the version number, for example, "mon33v10.exe" is the
file name of S5U1C330M2S ver. 1.0.)
When "mon33vXX.exe" is started up by double-clicking the file icon, the following dialog box appears.

Enter a path/folder name in the text box then click
[Unzip]. The specified folder will be created and all the
files will be copied to the folder.

When the specified folder already exists on the specified
path, the folder will be overwritten without prompting if
[Overwrite Files Without Prompting] is checked.

The following lists the configuration of directories and files after copying.
(root)\ (default: C:\E0C33\MON33\)

readme.txt Supplementary explanation (in English)
readmeja.txt Supplementary explanation (in Japanese)

lib\ ..... MON33 library

mon33ch0.lib S5U1C330M2S library that uses the serial I/F Ch.0 on the S1C33xxx
mon33ch1.lib S5U1C330M2S library that uses the serial I/F Ch.1 on the S1C33xxx
mon33.lib S5U1C330M2S library that does not use a serial I/F on the S1C33xxx

... These libraries cannot be used with the ICE or ICD.

Normally, either "mon33ch0.lib" or "mon33ch1.lib" is used according to
the serial I/F channel used. Use "mon33.lib" when providing a serial I/O
circuit separately and when not using the S5U1C330MxD1 board.

mon33ice.lib Library that does not use a serial I/F on the S1C33xxx for debugging the

S5U1C330M2S using the ICE or ICD

2

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

1 S5U1C330M2S PACKAGE

mon33ch0.mak Make file for building mon33ch0.lib
mon33ch1.mak Make file for building mon33ch1.lib
mon33.mak Make file for building mon33.lib
mon33ice.mak Make file for building mon33ice.lib

src\ ..... MON33 source files

m33_def.h S5U1C330M2S definition file
m3c_brk.c C source file for break functions
m3c_exe.c C source file for program execution
m3c_flsh.c C source file for Flash memory operation
m3c_main.c S5U1C330M2S main C source file
m3c_mem.c C source file for memory operation
m3c_othe.c C source file for other functions
m3c_sci.c C source file for sending/receiving messages
m3s_exe.s Assembly source file for program execution
m3s_flsh.s Assembly source file for Flash memory operation
m3s_init.s Assembly source file for S5U1C330M2S initial set-up
m3s_mem.s Assembly source file for memory operation
m3s_sci.s Assembly source file for sending/receiving messages

dmt33xxx\ ..... Sample source files for the S5U1C33xxxDx, MON33 build files and related files

A sample program for blinking the LED on the S5U1C33xxxDx, a source for the on­board Flash memory write/erase routines and the make files are included in each
dmt33xxx folder. The source files can be modified to use in the application program if
necessary. Refer to "readme.txt" or "readmeja.txt" for the contents of the dmt33xxx
folder.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

3

2 IMPLEMENTING THE DEBUG MONITOR

2 Implementing the Debug Monitor

This chapter describes how to implement the debug monitor and how to start it from the application

program.

2.1 Resources Required for the Debug Monitor

The debug monitor uses the following resources:

• Approximately 10KB of ROM area for the program code of the debug monitor.

• Approximately 2.5KB of RAM area for the work and stack area.

• Since the debug monitor uses the debugging exception of the CPU, addresses 0x0 to 0xF of the built-in RAM area

are used as the vector and stack for processing debugging exceptions. Furthermore, addresses 0x10 to 0x2F are
reserved for extending functions.

• One channel (Ch.0 or Ch.1) of the serial interface (8-bit asynchronous mode) is used for communicating with the

debugger db33 on the personal computer.
Figure 2.1.1 shows a connection diagram.

S1C33xxx

VSS

SOUT0/1

SIN0/1

SCLK0/1

Target board

S5U1C330MxD1

Connected to the personal computer
using the RS232C cable

(Baud rate: 115,200 bps)

Figure 2.1.1 RS232C connector diagram

• Communication via RS232C is performed by a software polling method without any interrupt related resource.

• A serial I/O device outside the S1C33 chip can be used by customizing the serial I/O routine (see Section 2.4).

• S5U1C330M2S uses the TXD, RXD and status registers of the corresponding serial interface channel exclusively.

Therefore, do not access these control registers.
Furthermore, fix the I/O pins for the channel at the serial interface pins using the port function select register. For
example, the sample program "m3s_sci.s" writes 0x07 to the P0 function select register (0x402D0) when Ch.0 is
used or 0x70 when Ch.1 is used to set the serial interface pins.

4

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

2 IMPLEMENTING THE DEBUG MONITOR

2.2 Starting Up the Debug Monitor

The debug monitor starts by jumping to m_mon_start( ).
Normally, provide a select switch outside the S1C33 chip for selecting either starting up the debug monitor or a
normal execution and create the program that can jump to m_mon_start( ) from the boot routine after an initial reset.
Furthermore, start the debug monitor after initializing the BCU if necessary. In case the debug monitor is started
before the BCU is initialized, downloaded data cannot be written to a 8-bit device or in DRAM. However, when the
S5U1C330M2S itself is placed on the 16-bit ROM and the 16-bit SRAM is used as a work area, it can be operated
even in the default setting (7-wait state) when operating in 20 MHz. In the following example, the initial set-up
statements are described as comments so that the BCU operates by default. By decreasing the wait cycle number
(2-wait setting in the example below), the file loading and other operations may improve the response time
(approximately 5 to 10%).

Example: boot routine of "dmt33004\m3s_boot.s"

;******************************************************************************
;
; BOOT program
;
;******************************************************************************
BOOT:

xld.w %r0,0x800

ld.w %sp,%r0
; xld.w %r5,BCU_A10_ADDR ;area9-10 (0x800000-0xffffff)
; xld.w %r4,0b0000000000010010 ;Device 16 bits,delay 1.5, wait 2
; ld.h [%r5]+,%r4
; xld.w %r5,BCU_A8_ADDR ;area8 (0x600000-0x7fffff)
; xld.w %r4,0b0000000000010010 ;Device 16 bits,delay 1.5, wait 2
; ld.h [%r5]+,%r4
; xld.w %r5,BCU_A5_A6_ADDR ;area5-6 (0x200000-0x3fffff)
; xld.w %r4,0b0001001000010010 ;Device 16 bits,delay 1.5, wait 2
; ld.h [%r5]+,%r4

xbtst [K6XD],0x3 ;K63 (debug SW check) 0:MON33 1:USER

xjreq m_mon_start ;MON33 start

jp USER
USER:

xld.w %r4,TBRP

xld.w %r6,0x59

xld.b [%r4],%r6 ;TTBR writable 0x59

xld.w %r4,TTBR

xld.w %r6,0x200000

ld.w [%r4],%r6 ;TTBR set 0x200000

ld.w %r4,[%r6]

jp %r4 ;user application(flash) start

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

5

2 IMPLEMENTING THE DEBUG MONITOR

2.3 Building an Application Program

The S5U1C330M2S modules are provided as a library file "mon33*.lib" in the directory "lib\". Link this library to
the user modules.
When using the serial interface on the S1C33 chip and the S5U1C330MxD1 board, link "mon33ch0.lib" (Ch.0 is
used) or "mon33ch1.lib" (Ch.1 is used) accordingly. When not using the serial interface on the S1C33 chip and the
S5U1C330MxD1 board, create serial I/O routines separately and link "mon33.lib".
Specify the "lib\" directory of the S5U1C330M2S as a library path in the linker command file when linking.

Example: "dmt33004\dmt33004.cm"

;Map set

-code 0x0c00000 ; set relative code section start address

-bss 0x06ff640 ; set relative bss section start address

;Library path

-l c:\CC33\lib .... CC33 standard library path

-l ..\lib .... S5U1C330M2S library path (c:\E0C33\mon33\lib)

;Executable file

-o dmt33004.srf

;Object files
m3s_boot.o

;Library files
string.lib
ctype.lib
idiv.lib

mon33ch1.lib .... S5U1C330M2S library to be linked

Since all the source codes of the debug monitor are provided in the directory "src\", it is possible to customize the
debug monitor if necessary. In this case, rebuild the library using "mon33*.mak" (make file for creating
"mon33*.lib") in the directory "lib\".

S5U1C330M2S allows the debugger db33 to write the target program to be debugged in the RAM or Flash memory
on the target board. In this case, it is not necessary to create a target object linked to the debug monitor. When the
S5U1C33xxxDx board (S5U1C33104D1, S5U1C33209D1, etc.) is used, the target program can be downloaded to
the RAM or Flash memory and can be debugged by writing S5U1C330M2S and a simple boot program to the ROM.
When executing the target program in the external ROM on the target board, link the debug monitor to the target
program and create an object that is mapped to the external ROM.

6

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

2 IMPLEMENTING THE DEBUG MONITOR

2.4 Creating Communication Control Routines

For communicating with the debugger, the debug monitor calls the following four RS232C routines (1 to 4).
"mon33chX.lib" that contains these routines can be used when using the serial interface Ch.0 or Ch.1 on the S1C33
chip and the S5U1C330MxD1 board. Otherwise, it is necessary to create these routines according to the system
since "mon33.lib" must be used. The sample program "m3s_sci.s" that uses the serial interface Ch.0/Ch.1 of the
S1C33104/S1C33209 is provided in "src\", so use it after modifying if necessary.

(1) void m_io_init( )

This is an initial set-up routine of the serial interface. Return value is not necessary.
Set up I/O terminals, input clock, baud rate and a data format. Select 8-bit asynchronous mode, no parity and 1
stop bit. The baud rate should be set to a value supported by the debugger db33 and the personal computer.
Refer to the "S1C33XXX Technical Manual" for the serial interface and for setting the clock.
The sample program "m3s_sci.s" assumes use of the S5U1C330MxD1 board. It sets the baud rate to 115.2 kbps
when a 1.843 MHz external clock is used.

Example: "m_io_init( ) of "m3s_sci.s"

#define MON_VER 0x11 ;monitor firm-ware version

#ifdef SIO0

#define STDR 0x000401e0 ;transmit data register(ch0)

#define SRDR 0x000401e1 ;receive data register(ch0)

#define SSR 0x000401e2 ;serial status register(ch0)

#define SCR 0x000401e3 ;serial control register(ch0)

#define SIR 0x000401e4 ;IrDA control register(ch0)

#define PIO_SET 0x07 ;port function register

#else

#define STDR 0x000401e5 ;transmit data register(ch1)

#define SRDR 0x000401e6 ;receive data register(ch1)

#define SSR 0x000401e7 ;serial status register(ch1)

#define SCR 0x000401e8 ;serial control register(ch1)

#define SIR 0x 000401e9 ;IrDA control register(ch1)

#define PIO_SET 0x70 ;port function register

#endif

#define SIR_SET 0x0 ;SIR set(1/16 mode)
#define SCR_SET 0x7 ;SCR set(#SCLK input 1.843MHz 115200bps)
#define SCR_EN 0xc0 ;SCR enable
#define PIO 0x000402d0 ;IO port (P port) register

.code

;******************************************************************************
;
; void m_io_init()
; serial port initial function
;
;******************************************************************************

.global m_io_init

m_io_init:

ld.w %r0,SIR_SET ;1/16 mode

xld.b [SIR],%r0 ;SIR set

ld.w %r0,SCR_SET

xld.b [SCR],%r0 ;SCR set(#SCLK input 1.843MHz)

xld.w %r0,PIO_SET

xld.b [PIO],%r0 ;IO port set

xld.w %r0,SCR_EN|SCR_SET

xld.b [SCR],%r0 ;SCR set

ret

In addition to the sample program above, "dmt33001\m3s_sci.s " is provided. This program sets the baud rate to
38,400 bps based on the 20 MHz S1C33104 internal clock. Refer to it if necessary.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

7

2 IMPLEMENTING THE DEBUG MONITOR

(2) void m_snd_1byte(unsigned char)

This is a routine that sends 1-byte data. This routine receives 1-byte data as the argument (R12 register) and
sends it via the serial interface. Return value is not necessary.

Example: m_snd_1byte( ) of "m3s_sci.s"

;******************************************************************************
;
; void m_snd_1byte( sdata )
; 1 byte send function
; IN : uchar sdata (R12) send data
;
;******************************************************************************

.global m_snd_1byte

m_snd_1byte:

pushn %r3 ;save r3-r0

snd000:

xbtst [SSR1],0x1 ;TDBE1(bit1) == 0(full) ?
jreq snd000 ;if full, jp snd000
xld.b [STDR1],%r12 ;write data
popn %r3 ;restore r3-r0
ret

(3) unsigned char m_rcv_1byte( )

This is a routine that receives 1-byte data. Store received 1-byte data into m_rcv_data. It returns following
error codes (unsigned char) as the return value:
0: received normally
1: framing error
2: parity error
3: overrun error

Example: m_rcv_1byte( ) of "m3c_sci.s"

;******************************************************************************
;
; uchar m_rcv_1byte()
; 1 byte receive function
; OUT : 0 receive OK
; 1 receive ERROR (framing err)
; 2 (parity err)
; 3 (over run err)
;
;******************************************************************************

.global m_rcv_1byte

m_rcv_1byte:

pushn %r3 ;save r3-r0

rcv000:

xbtst [SSR1],0x0 ;RDBF1(bit0) == 0(empty) ?
jreq rcv000 ;if empty, jp rcv000
ld.w %r10,0x0
xbtst [SSR1],0x4 ;FER1(bit4) == 0 ?
jreq rcv010
xbclr [SSR1],0x4 ;FER1(bit4) 0 clear
ld.w %r10,0x1 ;return 1

rcv010:

xbtst [SSR1],0x3 ;PER1(bit3) == 0 ?
jreq rcv020
xbclr [SSR1],0x3 ;PER1(bit3) 0 clear
ld.w %r10,0x2 ;return 2

rcv020:

xbtst [SSR1],0x2 ;OER1(bit2) == 0 ?
jreq rcv030
xbclr [SSR1],0x2 ;OER1(bit2) 0 clear
ld.w %r10,0x3 ;return 3

rcv030:

xld.b %r0,[SRDR1] ;read data
xld.b [m_rcv_data],%r0 ;read data set
popn %r3 ;restore r3-r0
ret

8

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

2 IMPLEMENTING THE DEBUG MONITOR

(4) void m_dummy_rd( )

This is a dummy read routine. It reads data from the receive buffer and clears the buffer. Return value is not
necessary.

Example: m_dummy_rd( ) of "m3s_sci.s"

;******************************************************************************
;
; void m_dummy_rd()
; dummy read function
;
;******************************************************************************

.global m_dummy_rd

m_dummy_rd:

xld.b %r4,[SRDR] ;read data

ret

(5) void m_ver_rd( )

This is a version read routine. Modifying the constant MON_VER can change the S5U1C330M2S version
number. It returns MON_VER as the return value.

Example: m_ver_rd( ) of "m3s_sci.s"

;******************************************************************************
;
; void m_ver_rd()
; mon firmware version read function
;
;******************************************************************************

.global m_ver_rd

m_ver_rd:

xld.w %r10,MON_VER ;mon firmware version

ret

(6) Sample command file for building

When the above routines are newly created, create a linker command file as the following example and link
"mon33.lib" to the user modules.

Example: dmt33001\dmt33001.cm

;Map set

-code 0x0c00000 ; set relative code section start address

-bss 0x081f640 ; set relative bss section start address

;Library path

-l c:\CC33\lib

-l ..\lib

;Executable file

-o dmt33001.srf

;Object files
m3s_boot.o
m3s_bcu.o

m3s_sci.o .... Originally created SIO routine

;Library files
string.lib
ctype.lib
fp.lib
idiv.lib

mon33.lib .... Link "mon33.lib" that does not include SIO routine

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

9

3 TARGET PROGRAM AND DEBUGGING

3 Target Program and Debugging

This chapter describes precautions for debugging using the debug monitor.

3.1 Notes for Creating Target Programs

Follow the instructions below when creating the target program to be debugged:

• Since the debug monitor uses the debugging exception of the CPU, addresses 0x0 to 0xF of the built-in RAM area

are used as the vector and stack for processing debugging exceptions. Therefore, the target program cannot use this
area. Furthermore, do not use addresses 0x10 to 0x2F.

• Wh e n d eb ug gi ng t he t ar g e t p ro gr a m b y wr i ti ng i n t he RA M o r Fl as h me mor y o n t he t ar g e t b oa r d, ma p t he

program to that address.

• Th e d eb ug mo ni to r d oe s n ot a ll ow f or c e d b re a k f un c ti on s s uc h a s k ey b re a k s. Fo rc e d b re a k f un c ti on s s ho ul d b e

ma de i n t he t ar g e t p ro gr a m u si ng a k ey i np ut i nt er r u pt o r a n NMI i np ut . Se tt in g a h ar d wa r e PC b re a k i n t he
interrupt processing routine makes it possible to execute a forced break.

3.2 Parameter File for Debugging

A debug-parameter file is required to start the debugger. Create the file according to the memory configuration of
the target system. When using the debug monitor, the debugger ignores all the settings for the ICE emulation
memory.
When using a Flash memory, specify it as a RAM.

Example: "dmt33004\sample\33104_m.par"

CHIP 33104 ; chip name (33XXX)
IROM 1000 ; internal ROM is 80000 to 80FFF
FOPT 0000 ; f option size
PRC VER 00 ff ; allow any PRC board
PRC STATUS **************** ; allow any PRC board status
MPU ; 0xC00000 external boot address
VER 1 ; this file version

; Emulation memory allocation (max 8 areas, 1MB/area, 1MB boundary)
EMROM c00000 cfffff ; external ROM 1MB

; Map allocation (max 31 areas, 256bytes boundary)

RAM 0 7FF ; internal RAM area 2KB
IO 40000 4ffff ; internal IO area 64KB
RAM 200000 2fffff ; external FLASH 1MB
RAM 600000 6fffff ; external SRAM 1MB
EROM c00000 cfffff ; external ROM 1MB
; Stack area except internal RAM area (max 8 areas, 256bytes boundary)

STACK 600000 6fffff ; external stack area 1MB

END

10

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

3 TARGET PROGRAM AND DEBUGGING

3.3 Starting Up and Terminating Procedure of Debugging

Follow the procedure below to start debugging.

1. Make sure the power of the target board and personal computer are off.

2. Connect the S5U1C330MxD1 board to the target board in which the debug monitor is implemented and connect

the S5U1C330MxD1 board to the personal computer with the RS232 cable.

3. Turn the target board on and then start the debug monitor.

4. Turn the personal computer on and start the debugger db33 in debug monitor mode from the work bench wb33 or

DOS prompt.
Example: db33 -mon -b 115200 -p 33104_m.par

Follow the procedure in order from Step 4 to Step 1 to terminate debugging and for power off.

Note:When connecting and disconnecting the RS232C cable, make sure the target board and the

personal computer are off.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

11

3 TARGET PROGRAM AND DEBUGGING

3.4 Debugging Method

The following three methods are available for debugging the target program.

1. Debugging in the ROM

Map the target program in the ROM after linking to the debug monitor. The target program can be executed and
debugged in the ROM.
Since the [Source] window of the debugger displays the disassembled content of the ROM on the target system,
it is not necessary to load the target program with the lf command. To display the source, load the same
absolute object file as the one written to the ROM. In this case, by using the ld command instead of the lf
command, the db33, except for the object code, loads only the debugging information.
After starting the debugger, follow the process below before starting to debug:

1. Load the debugging information (when displaying the source or using symbols).

2. Set up a hardware PC break point for the forced break function.
Example: command file example of the above description

ld sample.srf ; Load the debugging information of the target program
bh ESC ; Set up a hardware PC break point at the label ESC (for forced break)*

* For example, an NMI input switch can be used for the forced break function.

Example: NMI processing routine example for forced break function

NMI: ; nmi

nop
.global ESC

ESC: ; Label set as a hardware PC break point for the forced break function

reti

Note:When debugging the target program in the ROM, the software PC break function (bs command)

cannot be used.

2. Debugging in the RAM

Load the target program into the RAM of the target system with the lf command to debug the program in the
RAM.
After starting the debugger, follow the process below before starting to debug:

1. Set the trap table base address (only when placing the trap table in the RAM).

2. Load the target program.

3. Reset the CPU.

4. Set up a hardware PC break point for the forced break function.
The following shows a debug-command file example in which the above process is described.
Example: "dmt33004\sample\led.cmd"

eb 4812d ; Set up TBRP (TTBR write protection register)
59 ; Remove TTBR write protection
q
ew 48134 ; Set up TTBR (trap table base register)
600000 ; Set up the base address to 0x600000 (external RAM)
q
lf led.srf ; Load the target program (0x600000~)
rsth ; Reset the CPU (reset vector at 0x600000 is set to the PC)
bh ESC ; Set up a hardware PC break at the label ESC (for forced break)

12

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

3 TARGET PROGRAM AND DEBUGGING

3. Debugging in the Flash memory

In the target system in which a Flash memory has mounted, the target program can be debugged by writing it
into the Flash memory using the debugger.

Notes: • When debugging the target program in the Flash memory, the software break function (bs

command) cannot be used.

• The debugger db33 ver. 1.72 or later version supports data writing to the Flash memory on the
target board. To debug using the Flash memory, create Flash erase and Flash write routines in
the user program and write the program following the instructions below:

After starting the debugger, follow the process below before starting to debug:

1. Load and initialize the Flash erase/write routines.

2. Erase the Flash memory.

3. Set up the trap table base address.

4. Load the target program.

5. Reset the CPU.

6. Set up a hardware PC break point for the forced break function.
The following shows a debug-command file example in which the above process is described.
Example: "dmt33004\sample\led2.cmd"

lf ..\sample\flsh\am29f800.srf ; Load the Flash erase/write routines to the built-in RAM
fls ; Flash set up command
1 ; 1: Set up 2: Clear
200000 ; Flash memory start address = 0x200000 (∗2)
2fffff ; Flash memory end address = 0x2fffff (∗2)
FLASH_ERASE ; Flash erase routine start address (∗1)
FLASH_LOAD ; Flash load routine start address (∗1)
fle ; Flash memory erase command
0x200000 ; Flash control register = 0x200000
0 ; Erase start block, 0 = All area, 1–19 = Start section
0 ; Erase end block, 1–19 = End section, 0 = Ignored
eb 4812d ; Set up TBRP (TTBR write protection register)
59 ; Remove TTBR write protection
q
ew 48134 ; Set up TTBR (trap table base register)
200000 ; Set up base address to 0x200000 (Flash memory start address)
q
lf led2.srf ; Load the target program (0x200000~)
rsth ; Reset the CPU (reset vector at 0x200000 is set to PC)
bh ESC ; Set up a hardware PC break at the label ESC (for forced break)

*1: "am29f800.srf" is created so as to operate by loading into the built-in RAM (2KB).

When using this source for the S1C33104 after modifying, use the patch tool "cc33\utility\filter".

* 2 : Th i s s a mp l e ( " d mt 3 3 0 0 4 \ s a mp l e \ l e d 2 .s r f " ) a s s u me s t h a t a Fl a s h me mo r y o f 1 MB i s l o c a t e d a t

0 x 2 0 0 0 0 0 – 0 x 2 f f f f f .

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

13

3 TARGET PROGRAM AND DEBUGGING

3.5 Precautions for Debugging

3.5.1 Restriction on Debugging Command

When the debug monitor is used for debugging, the following debugging functions/commands are not available or
allowed to be used.

When the following commands/functions are used, an error message will be displayed.

Error: Command is not supported at present mode.

• Trace function (tm, td, ts and tf commands)

• Sequential break function (bsq command)

• ICE Flash memory function (lfl, sfl and efl commands)

• Option related function (lo and od commands)

• ICE emulation memory

The following commands/ functions are not available even though no error message will be displayed.

• File loading via a parallel port (lf and lh commands)

• Map break function

• On-the-fly function

• Execution time measurement function

• Key break function

In addition to the functions above, the following functions cannot be used when the program in the ROM or Flash
memory is debugged.

• Software PC break functions (bp, bs and bc commands)

• Commands that use the software PC break function internally (stdin and stdout commands)

• Memory edit functions (eb, eh and ew commands)

• Memory fill functions (fb, fh and fw commands)

• Memory move functions (mv, mvh and mvw commands)

3.5.2 Other Precautions

• Th e d eb ug mo ni to r u se s a dd r e ss e s 0 x0 t o 0 x2 F i n t he b ui lt -i n RA M a nd a pp r ox ima t e ly 2 .5K B ( de s c r ib e d l at e r )

p ar t o f t he e xt e r na l RA M. Do n ot r e wr i te t hi s a r e a wi th a me mor y o pe r a ti on c omma n d. Wh e n t hi s a r e a i s
modified, the debug monitor cannot be executed normally.

• The cold reset sequence is the same as the hot reset sequence.

1) The vector value indicated by TTBR is set to the PC.

2) Initial setting: general purpose/special registers = 0xAAAAAAAA, PSR = 0x0, SP = 0xAAAAAA8
In the debug monitor, cold reset is simulated as hot reset.

• The S5U1C33104H and S5U1C33000H halt all the peripheral functions after a break occurs except for the DRAM

r e f r e sh o pe r a ti on . I n t he d eb ug mo ni to r, t he p er i ph e r a l f un c ti on s h al t i ns ta nt a ne o us ly wh e n a b re a k o c c u r s o r
s uc c e ss iv e /s te p e xe c u ti on s ta r ts , h owe v e r t he y r e st a r t i mmed ia t e ly . I nt e r r up ts wh il e t he t ar g e t p ro gr a m i s
suspended are disabled according to the IE-bit status of the PSR.

14

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

APPENDIX S5U1C330MXD1 BOARD

Appendix S5U1C330MxD1 Board

This chapter describes how to use the S5U1C330MxD1 board.

A.1 Outline of S5U1C330MxD1 Board

The S5U1C330MxD1 board provides the interface for the debug
monitor to the demonstration tools such as the S5U1C33104Dx or the
user target board. The S5U1C330MxD1 allows on-board debugging
using the debugger (db33.exe) on a personal computer by connecting
it to the target board in which the S1C33 Family debug monitor
(S5U1C330M2S) has been implemented.
Two types of boards are available: S5U1C330M1D1 board for 5 V
operation and S5U1C330M2D1 for 3.3 V operation.

A.2 Names and Functions of Each Part

The following describes the parts layout on the S5U1C330MxD1 board as well as the functions of the connectors and
switches:

SW1

(RESET)

SW2

(NMI)

Figure A.2.1 S5U1C330MxD1 board layout

SW3 (DEBUG switch)

Sets up the status of the DEBUG pin at the S5U1C33xxxDx/target board I/F connector. When the
S5U1C33104Dx/S5U1C33209Dx board is connected, the switch signal is input to the K63 port and can be used
to start up the debug monitor from the boot routine.
ON: DEBUG (K63) = "0" OFF: DEBUG (K63) = "1"
When the switch is ON, the S5U1C33104Dx/S5U1C33209Dx will start the debug monitor. When the switch is
OFF, the S5U1C33104Dx/S5U1C33209Dx will start executing the program stored in the Flash memory. The
S5U1C33104Dx/S5U1C33209Dx works assuming the debug switch is OFF when the S5U1C330MxD1 is not
connected.

RS232 connector

ONOFF

112

S5U1C33xxxDx/target board I/F connector

ONOFF
SW3
(DEBUG)

SW1 (RESET switch)

Sets up the status of the RESET pin at the S5U1C33xxxDx/
target board I/F connector. When a S5U1C33xxxDx board is
connected, this switch can reset the CPU on the board.
ON: RESET = "0" OFF: RESET = "1"

SW2 (NMI switch)

Sets up the status of the NMI pin at the S5U1C33xxxDx/target
board I/F connector. When a S5U1C33xxxDx board is
connected, a NMI request can be input to the CPU on the
board.
ON: NMI = "0" OFF: NMI = "1"

Figure A.1.1 S5U1C330MxD1 board

RS232C connector

This is a Dsub 9-pin connector for connecting a personal computer. Use the RS232C cable supplied with the
S5U1C330MxD1 package for connection.

S5U1C33xxxDx/target board I/F connector

This connector is used for connecting the S5U1C33xxxDx board. The pin layout is as follows:

Table A.2.1 S5U1C33xxxDx/target board connector pin layout

No. Signal name No. Signal name ( ) indicates the CPU pin corresponding to the signal

1VCC [+5 V, +3.3 V] 7 N.C. when the S5U1C33104Dx/S5U1C33209Dx is
2VCC [+5 V, +3.3 V] 8 DEBUG (K63) connected.
3 RESET (#RESET) 9 VCC [+5 V, +3.3 V] Since the corresponding signals on the
4 TxD (P05) 10 SCLK (P06) S5U1C33xxxDx may differ depending on the
5 RxD (P04) 11 GND board, refer to the pin layout table provided in
6 NMI (#NMI) 12 GND the specifications of each S5U1C33xxxDx board.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

15

APPENDIX S5U1C330MXD1 BOARD

A.3 Connecting the System

Note:When connecting and disconnecting the system, make sure to turn off the power of the

S5U1C33xxxDx/ target board and the personal computer.

Connecting to the S5U1C33xxxDx board/user target board

S5U1C33xxxDx/target board I/F connector

S5U1C33xxxDx

S5U1C330MxD1 I/F connector

Figure A.3.1 Connecting to the S5U1C33xxxDx board

S5U1C33xxxDx/target board I/F connector

User target board

V

CC

SINx

SOUTx

SCLKx

#RESET

#NMI

(K63)

V

SS

S1C33xxx

The S5U1C33xxxDx board has a connector used
for connecting with the S5U1C330MxD1.
Connect the S5U1C330MxD1 to the
S5U1C33xxxDx board with the
S5U1C33xxxDx/target board I/F connector.

When connecting to the user target board, attach
the S5U1C330MxD1 I/F connector (supplied
with the S5U1C330MxD1 package) to the target
board. See Table A.2.1 for the pin layout of the
S5U1C33xxxDx/target board I/F connector.

S5U1C330MxD1 I/F connector

(supplied with the S5U1C330MxD1 package)

Figure A.3.2 Connecting to the user target board

Connecting to a personal computer

Connect the S5U1C330MxD1 board to the COMx port connector (the port used for debugging) of the personal
computer with the RS232C cable supplied with the S5U1C330MxD1 package.

S5U1C33xxxDx/

target board

RS232C connector (female)

(supplied with the S5U1C330MxD1 package)

Figure A.3.3 Connecting to a personal computer

RS232C cable

(male) (female)

COMx

EPSON

16

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

A.4 S5U1C330MxD1 Block Diagram

APPENDIX S5U1C330MXD1 BOARD

RS232C connector

(Dsub 9 pins)

RXD

TXD
RTS

CTS
DTR
DSR

SG

3
2
7
8
4
6
5

V

CC

UPD4724

V

CC

1.843MHz
crystal

oscillator

S5U1C33xxxD1/target board I/F connector (12 pins)

1, 2, 9

5
4

10

V

CC

SW1

(RESET)

SW2

(NMI)

SW3

(DEBUG)

3
6
8

11, 12

Figure A.4.1 S5U1C330MxD1 block diagram

V

CC

RxD (SINx)
TxD (SOUTx)
SCLK (SCLKx)
RESET (SW1: ON = L, OFF = H)
NMI (SW2: ON = L, OFF = H)
DEBUG (SW3: ON = L, OFF = H)
GND

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

17

APPENDIX S5U1C330MXD1 BOARD

A.5 Program Debugging with a S5U1C33xxxDx Board

and S5U1C330M2S

This section describes the debugging procedure of the program on the target system configured with the
S5U1C330MxD1 board and the S5U1C33104Dx/S5U1C33209Dx board using the S5U1C330M2S. The sample
program for the S5U1C33104Dx/S5U1C33209Dx is used for the explanation. Further, the development tools in the
"S1C33 Family C Compiler Package" including the debugger (db33 ver. 1.72 or later) that supports S5U1C330M2S
should be installed for debugging.
The debugging function of the debug monitor can be tested using the sample file even when using a user target board
as well as the S5U1C33xxxDx board. Use the sample file after modifying the necessary parts such as the mapping
condition and the communication routines (refer to Section 2.4) according to the target system.

S5U1C33104Dx/S5U1C33209Dx address map

Figure A.5.1 shows the S5U1C33104Dx/S5U1C33209Dx memory map and the area used by the debug
monitor.

CPU: S1C33104/S1C33209

0xC1FFFF External ROM

128KB 0xC021FF Boot routine

0xC00000 0xC00000 S5U1C330M2S library

0x6FFFFF External RAM

1MB

0x600000

0x2FFFFF Flash memory 0x2FFFFF

1MB Free area

0x200000 0x200000

0x04FFFF Built-in I/O 0x04FFFF

0x040000 0x040000

∗ Built-in RAM

S5U1C33104Dx: 6KB∗0x000030
S5U1C33209Dx: 8KB 0x00002F

0x000000 0x000000 Debugging vector

Figure A.5.1 S5U1C33104Dx/S5U1C33209Dx memory map

Sample program

"\dmt33004\sample\led.srf" and "dmt33004\sample\led2.srf" are sample programs for the S5U1C33104Dx
that blinks the LED on the S5U1C33104Dx board. "led.srf" and "led2.srf" are created to be able to debug in
the RAM (0x600000~) and in the Flash memory (0x200000~), respectively.
For the contents of the program, refer to the source file (\dmt33004\sample\led.s).
Sample programs for the S5U1C33209Dx are also provided in the "\dmt33005\sample\" directory.

0x6FFFFF
0x6FF640

0x6FF63F
0x600000

0x000010
0x00000C R0 stack area
0x000008 PC stack area

S5U1C330M2S work area

Free area

Control registers of built-in I/O

Free area
∗: 0x17FF(S5U1C33104Dx), 0x1FFF(S5U1C33209Dx)

Reserved area for S5U1C330M2S

Boot routine and implementing the debug monitor

A boot routine and the debug monitor are written in the external ROM (0xC00000~) on the
S5U1C33104Dx/S5U1C33209Dx in advance. Therefore, a sample program/target program can be debugged
by loading from the debugger db33 to the RAM or the Flash memory on the S5U1C33104Dx/S5U1C33209Dx.
It is not necessary to link the S5U1C330M2S library to the program to be debugged.
The S5U1C330M2S library implemented in the S5U1C33104Dx is "mon33ch1.lib" that uses the built-in
serial interface Ch.1. The S5U1C33209Dx uses "mon33ch0.lib" that supports the built-in serial interface Ch.0.
Refer to "\dmt33004\m3s_boot.s" and "\dmt33005\m3s_boot.s" for the boot routine, "\dmt33004\
dmt33004.cm" and "dmt33005\dmt33005.cm" for the linker commands to implement the debug monitor.

18

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

APPENDIX S5U1C330MXD1 BOARD

Building the sample program

It is not necessary to execute Make when modification of the source is not needed since the executable object
files ("led.srf," "led2.srf") are provided in the "sample\" folder.
When the source is modified, execute Make using the make file provided.

Make execution procedure

1) Set "\dmt33004\sample\" (or "\dmt33005\sample\") as the current directory.

2) Enter the following command at the DOS prompt.

C:\...\SAMPLE\>make -f led.mak ... when creating "led.srf"
C:\...\SAMPLE\>make -f led2.mak ... when creating "led2.srf"

Make can also be executed from the work bench wb33 (refer to the "S1C33 Family C Compiler Package
Manual").

Starting up the debug monitor

The boot routine mapped from address 0xC00000 on the S5U1C33104Dx/S5U1C33209Dx starts the debug
monitor when the K63 input port is set to "0".
Start up the debug monitor following the procedure below after connecting the target system and a personal
computer.

1) Turn SW3[DEBUG] of the S5U1C330MxD1 on.

2) Turn the power of the S5U1C33104Dx/S5U1C33209Dx on.

3) Reset the S5U1C33104Dx/S5U1C33209Dx (S5U1C330MxD1 SW1 [RESET] ON→OFF).

4) Turn the personal computer on and start up Windows.

5) Start up the debugger db33 (start-up method is described later).

Note:When the power of the S5U1C33104Dx/S5U1C33209Dx is turned on while the SW3 [DEBUG] of

the S5U1C330MxD1 is off, the debug monitor does not start up.
The S5U1C33104Dx/S5U1C33209Dx sets TTBR at the beginning of the Flash memory
(0x200000~), so the program sequence branches to the boot address. In this case, turn the SW3
[DEBUG] on and reset the S5U1C33104Dx/S5U1C33209Dx with the SW1 [RESET] to start up the
debug monitor.

Debugging in the RAM

The sample program for debugging in the RAM (0x600000~) of the S5U1C33104Dx/S5U1C33209Dx is
"led.srf". When starting up the debugger, specify the debug command file "led.cmd" with the -c option.
"led.cmd" sets the trap table address to the start address of the RAM and loads "led.srf" to the RAM.
Operating procedure is as follows:

1) Start up the debug monitor as described above.

2) Set "\dmt33004\sample\" (or "\dmt33005\sample\") as the current directory.

3) Set a path to db33.exe.

4) Start up the debugger with the following command at the DOS prompt.
C:\...\SAMPLE\>db33 -mon -b 115200 -p 33104_m.par -c led.cmd

The debugger starts in debug monitor mode and is ready to debug "led.srf". For example, the LED on the
S5U1C33104Dx/S5U1C33209Dx board will start blinking by executing the g command.
Refer to "2. Debugging in the RAM" in Section 3.4, "Debugging Method", for the contents of the command
file.

Note:The debugger db33 ver. 1.0 does not support the debug monitor. Use ver. 1.72 or a later version.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

19

APPENDIX S5U1C330MXD1 BOARD

Debugging in the Flash memory

The sample program for debugging in the Flash memory (0x200000~) of the S5U1C33104Dx/S5U1C33209Dx
is "led2.srf".
The debugger db33 ver. 1.72 or later version supports debugging in the Flash memory. Refer to the
"Debugger" section of the "S1C33 Family C Compiler Package Manual" for details of operations.
To write the sample program to the Flash memory, first load the Flash erase/write routine "am29f800.srf". Then
initialize the Flash memory functions using the fls and fle commands and load the sample program into the
Flash memory using the lf command. Refer to the sample debug command file "led2.cmd" for executing
procedure.

When starting up the debugger, specify the debug command file "led2.cmd" with the -c option. "led2.cmd"
contains debug commands for loading the Flash erase/write routine, setting the trap table address and loading
"led2.srf" to the Flash memory.
Operating procedure is as follows:

1) Start up the debug monitor as described above.

2) Set "\dmt33004\sample\" (or "\dmt33005\sample\") as the current directory.

3) Set a path to db33.exe.

4) Start up the debugger with the following command at the DOS prompt.
C:\...\SAMPLE\>db33 -mon -b 115200 -p 33104_m.par -c led2.cmd

The debugger starts in debug monitor mode and is ready to debug "led2.srf". For example, the LED on the
S5U1C33104Dx/S5U1C33209Dx board will start blinking by executing the g command.
Refer to "3. Debugging in the Flash memory" in Section 3.4, "Debugging Method", for the contents of the
command file.

When debugging in the Flash memory, be aware that the software PC break function (bs command), memory
edit/fill/move commands and commands not supported by the debug monitor cannot be used.

Forced break

The debug monitor does not support forced break functions such as key break.
In the sample program, the label ESC is described in the NMI processing routine of the source ("led.s"). When
the debug command file ("led.cmd", "led2.cmd") is executed, a hardware PC break point is set at the ESC
location after the program has been loaded.
When the SW2 of the S5U1C330MxD1 is turned on, a NMI is generated and it suspends the program
execution forcibly.

Notes on debugging the user program on the S5U1C33104Dx/S5U1C33209Dx board

• Wh e n d eb ug gi ng t he u se r p ro gr a m o n t he S5 U1 C33 10 4D x/ S5U 1C3 32 09 Dx b oa r d, c r e a te t he p ro gr a m s o

t ha t i t c a n b e l oa de d a nd e xe c u te d i n t he f r e e a r e a o f t he RA M o r t he Fl as h me mor y i n t he s ame wa y a s t he
sample file. (See Figure A.5.1)

• Th e d eb ug mo ni to r o n t he S5 U1 C33 10 4D x h as b ee n i mpl eme n te d b y l in ki ng wi th t he " mon 33 c h1 .li b" .

Therefore, the built-in serial interface Ch.1 cannot be used from the user program.

• Th e d eb ug mo ni to r o n t he S5 U1 C33 20 9D x h as b ee n i mpl eme n te d b y l in ki ng wi th t he " mon 33 c h0 .li b" .

Therefore, the built-in serial interface Ch.0 cannot be used from the user program.

20

EPSON S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

APPENDIX S5U1C330MXD1 BOARD

A.6 Indispensable Signal Pins of S5U1C330MxD1

When using the S5U1C330M2S it is not absolutely necessary to connect the NMI, RESET and DEBUG
switches/signals on the S5U1C330MxD1 board. If these switches are not used, the target board can be connected to
the S5U1C330MxD1 using only the five signals as shown below.

Example: Connecting the target board to S5U1C330MxD1 with five wires

User target board

12
10

5
4

1

The wire length must be within 10 cm.

GND
SCLK

SIN
SOUT

V

CC

Figure A.6.1 Connection example using indispensable pins

The NMI, RESET and/ or DEBUG signals should be connected if necessary.

S1C33 FAMILY DEBUG MONITOR EPSON
OPERATION MANUAL

21

International Sales Operations

AMERICA

EPSON ELECTRONICS AMERICA, INC.

- HEADQUARTERS -

1960 E. Grand Avenue
EI Segundo, CA 90245, U.S.A.
Phone: [phone] Fax: [phone]

- SALES OFFICES ­West

150 River Oaks Parkway
San Jose, CA 95134, U.S.A.
Phone: [phone] Fax: [phone]

Central

101 Virginia Street, Suite 290
Crystal Lake, IL 60014, U.S.A.
Phone: [phone] Fax: [phone]

Northeast

301 Edgewater Place, Suite 120
Wakefield, MA 01880, U.S.A.
Phone: [phone] Fax: [phone]

Southeast

3010 Royal Blvd. South, Suite 170
Alpharetta, GA 30005, U.S.A.
Phone: +1-877-EEA-0020 Fax: [phone]

EUROPE

EPSON EUROPE ELECTRONICS GmbH

- HEADQUARTERS -

Riesstrasse 15
80992 Munich, GERMANY
Phone: [phone] Fax: [phone]

ASIA

EPSON (CHINA) CO., LTD.

28F, Beijing Silver Tower 2# North RD DongSanHuan
ChaoYang District, Beijing, CHINA
Phone: [phone] Fax: [phone]

SHANGHAI BRANCH

4F, Bldg., 27, No. 69, Gui Jing Road
Caohejing, Shanghai, CHINA
Phone: [phone] Fax: [phone]

EPSON HONG KONG LTD.

20/F., Harbour Centre, 25 Harbour Road
Wanchai, Hong Kong
Phone: [phone] Fax: [phone]
Telex: 65542 EPSCO HX

EPSON TAIWAN TECHNOLOGY & TRADING LTD.

10F, No. 287, Nanking East Road, Sec. 3
Taipei
Phone: [phone] Fax: [phone]
Telex: 24444 EPSONTB

HSINCHU OFFICE

13F-3, No. 295, Kuang-Fu Road, Sec. 2
HsinChu 300
Phone: [phone] Fax: [phone]

EPSON SINGAPORE PTE., LTD.

No. 1 Temasek Avenue, #36-00
Millenia Tower, SINGAPORE 039192
Phone: [phone] Fax: [phone]

SEIKO EPSON CORPORATION KOREA OFFICE

50F, KLI 63 Bldg., 60 Yoido-dong
Youngdeungpo-Ku, Seoul, 150-763, KOREA
Phone: [phone] Fax: [phone]

SALES OFFICE

Altstadtstrasse 176
51379 Leverkusen, GERMANY
Phone: [phone] Fax: [phone]

UK BRANCH OFFICE

Unit 2.4, Doncastle House, Doncastle Road
Bracknell, Berkshire RG12 8PE, ENGLAND
Phone: [phone] Fax: [phone]

FRENCH BRANCH OFFICE

1 Avenue de l' Atlantique, LP 915 Les Conquerants
Z.A. de Courtaboeuf 2, F-91976 Les Ulis Cedex, FRANCE
Phone: [phone] Fax: [phone]

BARCELONA BRANCH OFFICE
Barcelona Design Center

Edificio Prima Sant Cugat
Avda. Alcalde Barrils num. 64-68
E-08190 Sant Cugat del Vallès, SPAIN
Phone: [phone] Fax: [phone]

SEIKO EPSON CORPORATION
ELECTRONIC DEVICES MARKETING DIVISION

Electronic Device Marketing Department
IC Marketing & Engineering Group

421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] Fax: [phone]

ED International Marketing Department Europe & U.S.A.

421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] Fax: [phone]

ED International Marketing Department Asia

421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] Fax: [phone]

In pursuit of “Saving” Tec hnology, Epson electronic devices.

Our lineup of semiconductors, liquid crystal displays and quartz devices

assists in creating the products of our customers’ dreams.

Epson IS energy savings.

S1C33 Family

Debug Monitor Operation Manual

ELECTRONIC DEVICES MARKETING DIVISION

EPSON Electronic Devices Website

http://www.epson.co.jp/device/

Printed February, 2001 in Japan A

First issue April, 1999

M
