User's Guide
Page 2
Contents
2
Notations Used in This Guide 6
Using the Manual to Search for Information .....................................7
Searching by Keyword ......................................................................................7
Jumping Directly from Bookmarks .....................................................................7
Printing Only the Pages You Need ..................................................................... 7
Getting the Latest Version of the Documents ................................... 8
Introduction to Your Projector 9
Projector Features ............................................................................. 10
Quick and Easy Setup ......................................................................................10
Easy Wireless Projection ..................................................................................10
Linking with Apple Devices ............................................................................. 11
Projector Parts and Functions .......................................................... 12
Projector Parts - Front
Projector Parts - Rear .......................................................................................13
Projector Parts - Base ...................................................................................... 14
Projector Parts - Control Panel ......................................................................... 14
Projector Parts - Remote Control ......................................................................15
.....................................................................................12
Setting Up the Projector 17
Projector Placement ..........................................................................18
Projector Setup and Installation Options .......................................................... 19
Projection Distance .........................................................................................19
Projector Connections .......................................................................21
Connecting to a Computer
Connecting to a Computer for HDMI Video and Audio ....................................21
Connecting to Video Sources ...........................................................................21
Connecting to an HDMI Video Source ............................................................22
Connecting to External USB Devices .................................................................22
USB Device Projection ..................................................................................22
..............................................................................21
Connecting to a USB Device ......................................................................... 23
Disconnecting a USB Device .........................................................................23
Connecting to a Streaming Media Player ..........................................................23
Connecting to a Document Camera ................................................................. 24
Connecting to External Devices ....................................................................... 24
Connecting to External Speakers .................................................................. 24
Installing Batteries in the Remote Control ...................................... 26
Remote Control Operation ............................................................... 27
Opening the Lens Cover ....................................................................28
Using Basic Projector Features 29
Turning On the Projector .................................................................. 30
Home Screen ................................................................................................. 31
Turning O the Projector ..................................................................33
Setting the Date and T
Selecting the Language for the Projector Menus ........................... 36
Projection Modes ...............................................................................37
Changing the Projection Mode Using the Remote Control ................................. 37
Changing the Projection Mode Using the Menus ...............................................37
Displaying a Test Pattern ..................................................................39
Adjusting the Image Height ............................................................. 40
Image Shape .......................................................................................41
Auto V-Keystone .............................................................................................41
Correcting the Image Shape with the Horizontal Keystone Slider ........................41
Correcting the Image Shape with the Keystone Buttons .....................................42
Correcting the Image Shape with Quick Corner .................................................43
Resizing the Image with the Zoom Ring .......................................... 45
Focusing the Image Using the Focus Ring .......................................46
ime ................................................................ 34
Page 3
Contents
3
Selecting an Image Source ................................................................47
Image Aspect Ratio ............................................................................48
Changing the Image Aspect Ratio
Available Image Aspect Ratios .........................................................................48
Projected Image Appearance with Each Aspect Mode ....................................... 49
....................................................................48
Adjusting Image Quality (Color Mode) ............................................ 50
Changing the Color Mode ............................................................................... 50
Available Color Modes .................................................................................... 50
Setting Auto Iris ..............................................................................................50
Controlling the Volume with the Volume Buttons ......................... 52
Adjusting Projector Features 53
HDMI Link Features ........................................................................... 54
Operating the Connected Devices Using the HDMI Link Features ....................... 54
Projecting a PC Free Presentation ....................................................56
Supported PC Free File Types
Precautions on PC Free Projection ....................................................................56
Starting a PC Free Slide Show .......................................................................... 57
Starting a PC Free Movie Presentation ..............................................................58
PC Free Display Options ..................................................................................59
Shutting O the Image and Sound Temporarily .............................61
Shutting O the Sound Temporarily ................................................62
Stopping Video Action Temporarily ................................................ 63
Zooming In/Zooming Out of Images (E-Zoom) ............................... 64
Zooming Into Images ......................................................................................64
Zooming Out of Images .................................................................................. 64
Saving a User's Logo Image .............................................................. 66
Saving a User Pattern ........................................................................ 68
.......................................................................... 56
Color Dierence Correction when Projecting from Multiple
Projectors ........................................................................................... 69
Setting the Projector ID ...................................................................................69
Selecting the Projector You want to Operate .................................................... 69
Matching Multiple-Projector Display Quality .....................................................70
Projector Security Features .............................................................. 72
Password Security Types .................................................................................72
Setting a Password ...................................................................................... 72
Selecting Password Security Types ................................................................73
Entering a Password to Use the Projector .......................................................74
Locking the Projector's Buttons ....................................................................... 74
Unlocking the Projector's Buttons .................................................................75
Installing a Security Cable ................................................................................75
Using the Projector on a Network 77
Wireless Network Projection ............................................................ 78
Safety Instructions for Built-in Wireless LAN Module ..........................................78
Connection Methods for Wireless Network Projection ....................................... 78
Selecting Wireless Network Settings Manually .................................................. 79
Selecting Wireless Network Settings in Windows ...............................................81
Selecting Wireless Network Settings in Mac ...................................................... 82
Setting Up Wireless Network Security when Simple AP Mode is Set to On ........... 82
Setting Up Wireless Network Security when Simple AP Mode is Set to O ........... 82
Supported Client and CA Certicates .............................................................85
Using a QR Code to Connect a Mobile Device ....................................................85
Using a USB Key to Connect a Windows Computer ............................................86
Wireless Network Projection from a Mobile Device (Miracast) ..... 87
Selecting Miracast Settings
Connecting Using Miracast ..............................................................................88
Connecting Using Miracast in Windows 10 .................................................... 89
Connecting Using Miracast in Windows 11 .................................................... 90
Using AirPlay ......................................................................................91
Settings for AirPlay ......................................................................................... 91
..............................................................................87
Page 4
Contents
4
Streaming/Mirroring Media with an AirPlay Connection .................................... 93
Secure HTTP ....................................................................................... 95
Importing a Web Server
Supported Web Server Certicates ................................................................96
Certicate Using the Menus .........................................95
Monitoring and Controlling the Projector 97
Epson Projector Management ..........................................................98
Controlling a Networked Projector Using a Web Browser ............. 99
Web Control Options
Registering Digital Certicates from a Web Browser ................... 103
Setting Up Projector Network E-Mail Alerts ..................................104
Network Projector E-mail Alert Messages ........................................................104
Setting Up Monitoring Using SNMP ...............................................106
Setting Projector Event Schedules .................................................107
Web API ............................................................................................ 110
Enabling Web API ......................................................................................... 110
.................................................................................... 100
Network Menu - Basic Menu .......................................................................... 123
Network Menu - Wireless LAN Menu ...............................................................124
Network Menu - Notications Menu ...............................................................127
Network Menu - Others Menu ........................................................................128
Network Menu - Reset Menu ..........................................................................129
Projector Setup Settings - ECO Menu ............................................ 131
Projector Information Display - Info Menu ................................... 133
Info Menu - Projector Info Menu .....................................................................133
Event ID Code List ......................................................................................134
Projector Reset Options - Reset Menu ........................................... 136
Copying Menu Settings Between Projectors (Batch Setup) .........137
Transferring Settings From a USB Flash Drive .................................................. 137
Transferring Settings From a Computer ..........................................................138
Batch Setup Error Notication .....................................................................139
Maintaining the Projector 140
Projector Maintenance ....................................................................141
Cleaning the Lens ............................................................................ 142
Adjusting the Menu Settings 111
Using the Projector's Menus ...........................................................112
Using the Displayed Keyboard .......................................................113
Available Text Using the Displayed Keyboard
Image Quality Settings - Image Menu ............................................114
Input Signal Settings - Signal Menu ...............................................116
Projector Feature Settings - Settings Menu .................................. 117
Projector Setup Settings - Extended Menu ................................... 119
Projector Network Settings - Network Menu ................................ 122
..................................................113
Cleaning the Projector Case ...........................................................
143
Air Filter and Vent Maintenance .................................................... 144
Cleaning the Air Filter and Vents ....................................................................144
Replacing the Air Filter ..................................................................................144
Projector Lamp Maintenance ......................................................... 147
Replacing the Lamp ......................................................................................147
Resetting the Lamp Timer ..............................................................................150
Updating the Firmware ...................................................................151
Updating Firmware Using a USB Storage Device ..............................................151
Updating the Firmware over the Network .......................................................152
Page 5
Contents
5
Solving Problems 154
Projection Problems ........................................................................155
Projector Indicator Status ...............................................................156
Using the Projector Help Displays ..................................................
Solving Image or Sound Problems .................................................160
Solutions When No Image Appears ................................................................ 160
Solutions When "No Signal" Message Appears .................................................160
Displaying From a Laptop ...........................................................................161
Displaying From a Mac Laptop ....................................................................161
Solutions When "Not Supported" Message Appears .........................................161
Solutions When Only a Partial Image Appears ................................................. 161
Solutions When the Image is not Rectangular ................................................. 162
Solutions When the Image Contains Noise or Static .........................................162
Solutions When the Image is Fuzzy or Blurry ................................................... 163
Solutions When the Image Brightness or Colors are Incorrect ...........................163
Solutions to Sound Problems .........................................................................163
Solutions When Image File Names are not Displayed Correctly in PC Free ..........164
Solving Projector or Remote Control Operation Problems ......... 165
Solutions to Projector Power or Shut-O Problems ..........................................165
Solutions to Problems with the Remote Control ..............................................165
Solutions to Password Problems .................................................................... 166
Solution When "The Battery that Saves Your Clock Settings is Running Low"
Message Appears ..........................................................................................166
Solving Network Problems ............................................................. 167
Solutions When Wireless Authentication Fails ................................................. 167
Solutions When You Cannot Access the Projector Through the Web .................167
Solutions When Network Alert E-Mails are not Received ...................................167
Solutions When the Image Contains Static During Network Projection ..............168
Solutions When You Cannot Connect Using Miracast .......................................168
Solutions When the Image or Sound Contains Static During Miracast Connection
....................................................................................................................168
Solutions When You Cannot Connect Using AirPlay .........................................169
Solutions When the Image or Sound Contains Static During AirPlay Connection 169
159
Solutions When HDMI Link does not Function ............................. 170
Appendix 171
Optional Accessories and Replacement Parts ...............................172
Screens ........................................................................................................172
Mounts ........................................................................................................172
External Devices ........................................................................................... 172
Replacement Parts ........................................................................................172
Screen Size and Projection Distance ..............................................173
Supported Monitor Display Resolutions .......................................
Projector Specications .................................................................. 176
Connector Specications ...............................................................................177
Wireless Channels Supported Frequency ........................................................177
External Dimensions ....................................................................... 178
List of Safety Symbols and Instructions ........................................ 179
Warning Label ..................................................................................181
Glossary ............................................................................................182
Notices ..............................................................................................184
For Canadian Users .......................................................................................184
Indication of the manufacturer and the importer in accordance with requirements
of EU directive ..............................................................................................184
Restriction of Use ..........................................................................................184
Operating System References ........................................................................184
Trademarks ..................................................................................................184
Copyright Notice .......................................................................................... 185
Copyright Attribution ....................................................................................185
175
Page 6
Notations Used in This Guide
ety Symbols
Saf
e projector and its manuals use graphical symbols and labels to indicate content that tells you how to use the projector safely.
Read and carefully follow the instructions that are marked with these symbols and labels to avoid injury to persons or damage to property.
is symbol indicates information that, if ignored, could possibly result in personal injury or even death.
Warning
Caution
is symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.
General Information Notations
Attention
[B
utton name] Indicates the name of the buttons on the remote control or the projector.
Menu/Setting name Indicates projector menu and setting names.
s
Related Links
g
•
•
g the Manual to Search for Information" p.7
"Usin
"Getting the Latest Version of the Documents" p.8
is label indicates procedures that may result in damage or injury if sucient care is not taken.
is label indicates additional information that may be useful to know.
Exam
ple: [Esc] button
Example:
Select the Image menu
s Image > Advanced
is label indicates links to the related pages.
s label indicates the projector's current menu level.
i
Page 7
Using the Manual to Search for Information
e PDF manual allows you to search for information you are looking for by
eyword, or jump directly to specic sections using the bookmarks. You can
k
also print only the pages you need. is section explains how to use a PDF
manual that has been opened in Adobe Reader X on your computer.
Related Links
g
•
"Searching by Keyword" p.7
•
"Jumping Directly from Bookmarks" p.7
•
"Printing Only the Pages You Need" p.7
7
Searching by Keyword
Click Edit > Advanced Search. Enter the keyword (text) for information you
want to nd in the search window, and then click Search. Hits are displayed as a
list. Click one of the displayed hits to jump to that page.
Jumping Directly from Bookmarks
Click a title to jump to that page. Click + or > to view the lower level titles in
t
at section. To return to the previous page, perform the following operation on
h
your keyboard.
•
Windows: Hold down Alt, and then press ←.
•
Mac OS: Hold down the command key, and then press ←.
Printing Only the Pages You Need
You can extract and print only the pages you need. Click Prin
and then specify the pages you want to print in Pages in Pages to Print.
•
To specify a series of pages, enter a hyphen between the start page and the
end page.
Example: 20-25
•
To specify pages that are not in series, divide the pages with commas.
Example: 5, 10, 15
t in the File menu,
Page 8
Getting the Latest Version of the Documents
8
You can get the latest version of the manuals and sp
Web site.
Visit epson.sn, and enter your projector's name.
ecications on the Epson
Page 9
Introduction to Your Projector
er to these sections to learn more about your projector's features and part names.
Ref
Related Links
g
•
"Projector Features" p.10
•
"Projector Parts and Functions" p.12
Page 10
Projector Features
10
is projector comes with these special features. Refer to these sections for more
ails.
det
Related Links
g
•
"Quick and Easy Setup" p.10
•
"Easy Wireless Projection" p.10
•
"Linking with Apple Devices" p.11
Quick and Easy Setup
•
Direct Power On feature to turn on the projector as soon as you plug it in.
•
Auto Power On feature to turn on the projector when the projector detects an
image signal from the port you specied as the Auto Power On source.
•
Home screen feature to easily select an input source and useful functions.
•
Automatic vertical keystone correction always displays a rectangular screen
( Auto V-Keystone).
•
Horizontal keystone slider allows you to quickly correct horizontal distortion
in the projected image.
Easy Wireless Projection
•
Mirac
ast to connect your projector and mobile device wirelessly using
Miracast technology.
•
Epson iProjection (Windows/Mac) to project up to four images at the same
time by splitting the projected screen. You can project images from computers
on the network, or from smartphones or tablet devices.
See the Epson iProjection Operation Guide (Windows/Mac) for details.
Related Links
g
•
"T
ning On the Projector" p.30
ur
•
"Projector Setup Settings - Extended Menu" p.119
•
"Correcting the Image Shape with the Horizontal Keystone Slider" p.41
•
"Auto V-Keystone" p.41
Page 11
Projector Features
•
Yo
u can download the necessary soware and manuals from the
following Web site:
http://www.epson.com/
•
Epson iProjection (iOS/Android) to connect your projector and mobile
device wirelessly using the app available on the App Store or Google Play.
•
egistering the projector with Apple HomeKit on your Apple device, you
By r
can control the projector using your Apple device.
11
Any fees incurred when communicating with the App Store or Google
ay are the responsibility of the customer.
Pl
•
Epson iProjection (Chromebook) to connect your projector and
Chromebook device wirelessly using the app available on the Chrome Web
Store.
Any fees incurred when communicating with the Chrome Web Store
he responsibility of the customer.
are t
Related Links
g
•
g the Projector on a Network" p.77
"Usin
Linking with Apple Devices
•
Wi
th AirPlay, you can stream media such as videos, music, and photos to this
projector using Apple devices that support AirPlay.
Use of the Works with Apple AirPlay badge means that an accessory has been
ed to work specically with the technology identied in the badge and
design
has been certied by the developer to meet Apple performance standards.
Use of the Works with Apple badge means that an accessory has been designed
to work specically with the technology identied in the badge and has been
certied by the developer to meet Apple performance standards. Apple is not
responsible for the operation of this device or its compliance with safety and
regulatory standards.
Controlling this HomeKit-enabled accessory automatically and away from
home requires a HomePod, HomePod mini, or Apple TV set up as a home
hub. It is recommended that you update to the latest soware and operating
system.
Page 12
Projector Parts and Functions
12
e following sections explain the projector parts and their functions.
Related Links
g
•
rojector Parts - Front" p.12
"P
•
"Projector Parts - Rear" p.13
•
"Projector Parts - Base" p.14
•
"Projector Parts - Control Panel" p.14
•
"Projector Parts - Remote Control" p.15
Projector Parts - Front
Name Function
Warning
Do n
ot look into the vents. If the lamp
explodes, gases may escape and small
fragments of glass may be scattered which
could cause an injury. Contact a doctor if any
fragments of broken glass are inhaled or get
into the eyes or mouth.
Caution
Whi
le projecting, do not put your face or hands
near the air exhaust vent, and do not place
objects that may become warped or damaged
by heat near the vent. Hot air from the air
exhaust vent could cause burns, warping, or
accidents to occur.
A/V Mute slide lever Slide the knob to open and close the lens cover.
B
Foot release lever Press the foot release lever to extend and retract the
C
Lens cover Close when not using the projector to protect the lens.
D
fr
ont adjustable foot.
By c
losing it during projection you can hide the image
and the sound.
Name Function
Air exhaust vent Exhaust vent for air used to cool the projector internally.
A
Front adjustable foot When the projector is set up on a surface such as a desk,
E
Lens Images are projected from here.
F
Remote receiver Receives signals from the remote control.
G
Horizontal keystone
H
s
lider
Air intake vent (air
I
lt
er)
Air lter cover Open to access the air lt
J
exten
d the foot to adjust the position of the image.
orrects horizontal distortion in the projected image.
C
Takes in air to cool the projector internally.
er.
Page 13
Projector Parts and Functions
13
Name Function
Security slot e security slot is compatible with the Microsaver
K
Control panel Operates the projector.
L
Zoom ring Adjusts the image size.
M
Focus ring Adjusts the image focus.
N
Lamp cover Open to access the projector's lamp.
O
Related Links
g
•
"R
•
"Focusing the Image Using the Focus Ring" p.46
•
"Projector Indicator Status" p.156
•
"Correcting the Image Shape with the Horizontal Keystone Slider" p.41
g the Image with the Zoom Ring" p.45
esizin
ecurity System manufactured by Kensington.
S
Projector Parts - Rear
Name Function
Remote receiver Receives signals from the remote control.
B
Audio Out port Outputs audio from the current input source to an
C
Speaker Outputs audio.
D
HDMI1, HDMI2
E
po
rts
USB-B port Use this to copy menu settings when using the batch
F
USB-A (
G
o
rt
p
external speaker.
Inputs video signals from HDMI compatible video
equipment and computers.
is projector is compatible with HDCP.
set
tings function.
Connects a USB memory device or a digital camera and
)
projects movies or images using PC Free.
Connects the optional document camera.
Provides a connection for a commercially available
streaming media player allowing you to power it.
Name Function
Power inlet Connects the power cord to the projector.
A
Page 14
Projector Parts and Functions
14
Projector Parts - Base
Name Function
Rear feet When the projector is set up on a surface such as a
C
Front adjustable foot When the projector is set up on a surface such as a desk,
D
Related Links
g
•
"In
stalling a Security Cable" p.75
urn to extend and retract the feet to adjust the
desk, t
horizontal tilt.
exten
d the foot to adjust the position of the image.
Projector Parts - Control Panel
Name Function
Ceiling mount xin
A
oints (three points)
p
Security cable
B
att
achment point
Use all the xing points to attach the optional ceiling
g
mount here when suspending the projector from a
ceiling.
Pass a commercially available wire lock through here
and lock it in place.
You can also attach the optional safety wire here to
prevent the projector from falling from the ceiling or
wall.
Name Function
[Source Search]
A
b
tton
u
[Enter] button [
B
Switches to the next input source.
Enters the current selection and moves to the next level
]
le displaying the projector's menu or help.
whi
Page 15
Projector Parts and Functions
15
Name Function
Keystone adjustment
C
buttons and arrow
buttons
[Esc] button Stops the current function.
D
Volume buttons and
E
arr
ow buttons
[Menu] button Displays and closes the projector's menu.
F
[Home] button Displays and closes the Home screen.
G
H
Power button [
Displays the Keystone screen allowing you to correct
keystone distortion.
Selects menu items while displaying the projector's
menu or help.
Moves back to the previous menu level while displaying
the projector's menu.
: Decreases the volume.
: Increases the volume.
rrects keystone distortion in the horizontal direction
Co
when the Keystone screen is displayed.
Selects menu items while displaying the projector's
menu or help.
Turns the projector on or o.
]
Projector Parts - Remote Control
I
ndicators Indicates the projector's status.
I
Related Links
g
•
put Signal Settings - Signal Menu" p.116
"In
•
"Home Screen" p.31
•
"Projector Indicator Status" p.156
•
"Correcting the Image Shape with the Keystone Buttons" p.42
Page 16
Projector Parts and Functions
16
Name Function
A
Power button [
MI] button Switches the image source between the HDMI ports.
[HD
B
[Wireless] button Switches the image source to a device connected over
C
Numeric buttons Enters numbers in the projector's menu.
D
[Customize] button Performs the function set for the Cus
E
[Menu] button Displays and closes the projector's menu.
F
Arrow buttons Selects menu items while displaying the projector's
G
[Enter] button [
H
[Home] button Displays/exits the home screen.
I
[Volume] up/down
J
bu
ttons
[A/V Mute] button Turns the video and audio on or o
K
[Mute] button Mutes the audio temporarily.
L
Turns the projector on or o
]
e wireless LAN network.
th
the Settings menu.
men
u.
Enters the current selection and moves to the next level
]
whi
le displaying the projector's menu.
Adjusts the speaker volume.
.
tomize Button in
temporarily.
Name Function
[ID] button Hold down this button and press the numeric buttons to
R
[0/All] button Allows you to operate all projectors regardless of the
S
[Computer/
T
HDB
aseT] button
[USB] button Switches the image source to the USB-A port.
U
[Source Search]
V
bu
tton
Remote control light
W
emit
ting area
Related Links
g
•
put Signal Settings - Signal Menu" p.116
"In
•
"Projector Setup Settings - Extended Menu" p.119
•
"Projecting a PC Free Presentation" p.56
•
"Using the Projector on a Network" p.77
•
"Home Screen" p.31
lect the ID for the projector you want to operate using
se
the remote control.
Pr
ojector ID setting.
is button is not available.
Switches to the next input source.
Outputs remote control signals.
Playback control
M
bu
ttons
[Freeze] button Pauses or resumes images.
N
[E-Zoom] +/– buttons Resizes the projected image.
O
[Default] button Returns the selected setting to its default value.
P
[Esc] button Stops the current function.
Q
Controls devices that comply with the HDMI CEC
standard.
Controls media being streamed with AirPlay.
M
ves back to the previous menu level while displaying
o
the projector's menu.
Page 17
Setting Up the Projector
llow the instructions in these sections to set up your projector.
Fo
Related Links
g
•
"Projector Placement" p.18
•
"Projector Connections" p.21
•
"Installing Batteries in the Remote Control" p.26
•
"Remote Control Operation" p.27
•
"Opening the Lens Cover" p.28
Page 18
Projector Placement
18
You can place the projector on almost any at sur
face to project an image.
You can also install the projector in a ceiling mount if you want to use it in
a xed location. An optional ceiling mount is required when suspending the
projector from a ceiling.
Note the following points when selecting a projector location:
•
Place the projector on a sturdy, level surface or install it using a compatible
mount.
•
Leave plenty of space around and under the projector for ventilation, and do
not place it on top of or next to anything that could block the vents.
•
Place the projector so it squarely faces the screen, not at an angle.
If you cannot install the projector squarely facing the screen, correct
any r
esulting keystone distortion using the projector controls. For the
best quality images, we recommend adjusting the installation position
of the projector to achieve the correct image size and shape.
Warning
•
Yo
u must install a ceiling mount when suspending the projector from a ceiling. If
you do not install the projector correctly, it could fall and cause damage or injury.
•
Do not use adhesives on the ceiling mount xing points to prevent the screws
from loosening, or use lubricants, oils, or similar substances on the projector; the
projector case may crack causing it to fall from its ceiling mount. is could cause
serious injury to anyone under the ceiling mount and could damage the projector.
•
Improper installation of the ceiling mount and projector could cause the projector
to fall. Secure the ceiling mount using all of the ceiling mount xing points
specied in the projector's User's Guide. Also, use a wire or other item that is
strong enough to secure the projector and the mount. Use only mounts specied
by Epson that are compatible with this projector.
•
Do not install the projector in a location subject to high levels of dust or humidity,
or in a location subject to smoke or steam. Otherwise, it could cause a re
or electric shock to occur. e projector's case could also deteriorate and be
damaged causing the projector to fall from the mount.
Examples of environments that could cause the projector to fall due to case
deterioration
•
Locations subject to excessive smoke or airborne oil particles, such as factories
or kitchens
•
Locations containing volatile solvents or chemicals, such as factories or
laboratories
•
Locations where the projector could be subjected to detergents or chemicals,
such as factories or kitchens
•
Locations in which aroma oils are oen used, such as relaxation rooms
•
Near devices that produce excessive smoke, airborne oil particles, or foam at
events
Page 19
Projector Placement
19
Warning
•
Do n
ot cover the projector's air intake or air exhaust vents. If the vents are
covered, the internal temperature could rise and cause a re.
•
Do not use or store the projector in locations where it will be subject to dust or
dirt. Otherwise, the quality of the projected image may decline, or the air lter
may become clogged, resulting in a malfunction or re.
•
Do not install the projector on an unstable surface or in a location beyond the
weight specications of the projector. Otherwise, it could fall or topple causing an
accident and injury.
•
When installing the projector in a high position, take measures to prevent falling
by using wires to ensure safety in an emergency, such as an earthquake, and to
prevent accidents. If it is not installed correctly, it could fall causing an accident
and injury.
•
Do not install in locations where salt damage could occur, or in locations subject
to corrosive gas such as sulphuric gas from hot springs. Otherwise, corrosion
could cause the projector to fall. It could also cause the projector to malfunction.
Attention
•
Do n
ot operate the projector on its side. is may cause the projector to
malfunction.
•
If you are using the projector at altitudes above 1,500 m, set the High Altitude
Mode setting to On in the projector's menu to ensure the projector's internal
temperature is regulated properly.
s Extended > Operation > High Altitude Mode
•
Try not to setup the projector in locations subject to high humidity and dust, or in
locations subject to smoke from res or tobacco smoke.
Projector Setup and Installation Options
You can set up or install your projector in the following ways:
Fr
ont/Rear
Front Ceiling/Rear Ceiling
Make sure you select the correct Pr
menu according to the installation method being used.
Related Links
g
•
"Projection Modes" p.37
ojection option in the projector's Extended
Related Links
g
•
"Pr
ojector Setup and Installation Options" p.19
•
"Projection Distance" p.19
•
"Image Shape" p.41
•
"Projector Setup Settings - Extended Menu" p.119
Projection Distance
e distance at which you place the projector from the screen determines the
ap
proximate size of the image. e image size increases the farther the projector
Page 20
Projector Placement
is from the screen, but can vary depending on the zoom factor, aspect ratio, and
her settings.
ot
See the Appendix for details about how far to place the projector from the
screen based on the size of the projected image.
When correcting keystone distortion, your image is slightly smaller.
20
Related Links
g
•
"Screen Size and Projection Distance" p.173
Page 21
Projector Connections
21
See these sections to connect the projector to a variety of projection sources.
Attention
Ch
eck the shape and orientation of the connectors on any cable you plan to connect.
Do not force a connector into a port if it does not t. e device or your projector
could be damaged or could malfunction.
See the Quick Start Guide for a list of cables supplied with your projector.
chase optional or commercially available cables when necessary.
Pur
Related Links
g
•
"Connecting to a Computer" p.21
•
"Connecting to Video Sources" p.21
•
"Connecting to External USB Devices" p.22
•
"Connecting to a Streaming Media Player" p.23
•
"Connecting to a Document Camera" p.24
•
"Connecting to External Devices" p.24
Connecting to a Computer
To connect a Mac that does not have an HDMI port, you need an adapter
th
at allows you to connect to the projector's HDMI port. Contact Apple
for compatible adapter options. Older Mac computers (2009 and earlier)
may not support audio through the HDMI port.
Connect the HDMI cable to your computer's HDMI output port.
a
Connect the other end to the projector's HDMI port.
b
Connecting to Video Sources
Follow the instructions in these sections to connect a computer to the projector.
Related Links
g
•
"Co
nnecting to a Computer for HDMI Video and Audio" p.21
Connecting to a Computer for HDMI Video and Audio
If your computer has an HDMI port, you can connect it to the projector using
an HDMI cable and send the computer's audio with the projected image.
Follow the instructions in these sections to connect video devices to the
ojector.
pr
•
If t
he port on the device you connect has an unusual shape, use the
cable supplied with the device or an optional cable to connect to the
projector.
•
e cable diers depending on the output signal from the connected
video devices.
•
Some video devices are capable of outputting dierent types of signals.
See your video device manual to conrm what type of signals can be
output.
Page 22
Projector Connections
Related Links
g
•
nnecting to an HDMI Video Source" p.22
"Co
Connecting to an HDMI Video Source
f y
our video source has an HDMI port, you can connect it to the projector
I
using an HDMI cable and send the image source's audio with the projected
image.
Attention
Do n
ot turn on the video source before connecting it to the projector. Doing so could
damage the projector.
Connect the HDMI cable to your video source's HDMI output port.
a
Connect the other end to the projector's HDMI port.
b
Connecting to External USB Devices
Follow the instructions in these sections to connect external USB devices to the
pr
ojector.
Related Links
g
•
"USB Device Projection" p.22
•
"Connecting to a USB Device" p.23
•
"Disconnecting a USB Device" p.23
USB Device Projection
You can project images and other content without using a computer or video
device by connecting any of these devices to your projector:
•
USB ash drive
•
Digital camera or smartphone
•
USB hard drive
22
Related Links
g
•
"Pr
ojector Setup Settings - Extended Menu" p.119
•
tal cameras or smartphones must be USB-mounted devices, not
Digi
TWAIN-compliant devices, and must be USB Mass Storage Classcompliant.
•
USB hard drives must meet these requirements:
•
USB Mass Storage Class-compliant (not all USB Mass Storage Class
devices are supported)
•
Formatted in FAT16/32
•
Self-powered by their own AC power supplies (bus-powered hard
drives are not recommended)
•
Avoid using hard drives with multiple partitions
You can project slide shows from image les o
nnected USB device.
n a co
Page 23
Projector Connections
Related Links
g
•
ojecting a PC Free Presentation" p.56
"Pr
Connecting to a USB Device
Disconnecting a USB Device
en you have nished presenting with a connected USB device, disconnect
Wh
the device from the projector.
23
o
u can connect your USB device to the projector's USB-A port and use it to
Y
project images and other content.
If your USB device came with a power adapter, plug the device into an
a
ele
ctrical outlet.
Connect the USB cable or USB ash
b
shown.
Attention
•
Us
e the USB cable supplied with or specied for use with the device.
•
Do not connect a USB hub or a USB cable longer than 3 meters, or the
device may not operate correctly.
drive to the projector's USB-A port as
Turn o and unplug the device, if necessary.
a
Di
b
sconnect the USB device from the projector.
Connecting to a Streaming Media Player
You can connect your streaming media player to the projector's HDMI port. By
connecting the power supply USB cable, you can power the streaming media
player from the projector.
e connection method and operating environment for the streaming
edia player vary depending on the model you are using. For details, see
m
the documentation supplied with your streaming media player; otherwise,
it may not operate properly.
Connect your streaming media player to the projector's HDMI port.
a
Connect the other end to your device, if necessary.
c
Connect the power supply USB cable to the projector's USB-A port.
b
Page 24
Projector Connections
24
Connect the other end to the streaming media player.
c
Connecting to a Document Camera
You can connect a document camera to your projector to project images viewed
he camera.
by t
e connection method varies depending on your Epson document camera
model. See the document camera manual for details.
Connecting to External Devices
Follow the instructions in these sections to connect external devices to the
pr
ojector.
Connecting to External Speakers
hance the sound from your presentation, you can connect the projector to
To en
external self-powered speakers. You can control the volume using the projector's
remote control.
•
If y
ou want to output audio from the external speakers when the
projector is turned o, select Always On as the A/V Output setting in
the projector's Extended menu.
s Extended > A/V Settings > A/V Output
•
You can also connect the projector to an amplier with speakers.
•
e projector's built-in speaker system is disabled when you connect
external speakers.
Make sure your computer or video source is connected to the projector
a
wi
th both audio and video cables as necessary.
Locate the appropriate cable to connect your external speakers, such as a
b
st
ereo mini-jack-to-pin-jack cable, or another type of cable or adapter.
Connect one end of the cable to your external speakers as necessary.
c
Connect the stereo mini-jack end of the cable to your projector's Audio
d
O
t port.
u
Related Links
g
•
"Connecting to External Speakers" p.24
Page 25
Projector Connections
Related Links
g
•
ojector Setup Settings - Extended Menu" p.119
"Pr
25
Page 26
Installing Batteries in the Remote Control
26
e remote control uses the two AA batteries that came with the projector.
Attention
Mak
e sure you read the Safety Instructions before handling the batteries.
Remove the battery cover as shown.
a
Remove the old batteries, if necessary.
b
Dispose of used batteries according to local regulations.
Insert the batteries with the + and – ends facing as shown.
c
Warning
eck the positions of the (+) and (–) marks inside the battery holder to
Ch
ensure the batteries are inserted the correct way. If the batteries are not used
correctly, they could explode or leak causing a re, injury, or damage to the
product.
Replace the battery cover and press it down until it clicks into place.
d
Page 27
Remote Control Operation
e remote control lets you control the projector from almost anywhere in the
oom.
r
Make sure that you aim the remote control at the projector's receivers within the
distance and angles listed here.
27
Avoid using the remote control in conditions with bright uor
or in direct sunlight, or the projector may not respond to commands. If
you are not going to use the remote control for a long time, remove the
batteries.
escent lights
Page 28
Opening the Lens Cover
To open the projector's lens cover, slide the A/V Mute slide lever until it
a
clic
ks.
To cover the lens or temporarily turn o the projected image and sound,
b
close the lens cover.
28
e projector's power automatically turns o 30 minutes aer A/V Mute is
abled. You can disable this feature.
en
s ECO > Lens Cover Timer
Page 29
Using Basic Projector Features
llow the instructions in these sections to use your projector's basic features.
Fo
Related Links
g
•
"Turning On the Projector" p.30
•
"Turning O the Projector" p.33
•
"Setting the Date and Time" p.34
•
"Selecting the Language for the Projector Menus" p.36
•
"Projection Modes" p.37
•
"Displaying a Test Pattern" p.39
•
"Adjusting the Image Height" p.40
•
"Image Shape" p.41
•
"Resizing the Image with the Zoom Ring" p.45
•
"Focusing the Image Using the Focus Ring" p.46
•
"Selecting an Image Source" p.47
•
"Image Aspect Ratio" p.48
•
"Adjusting Image Quality (Color Mode)" p.50
•
"Controlling the Volume with the Volume Buttons" p.52
Page 30
Turning On the Projector
30
Turn on the computer or video equipment you want to use aer yo
projector.
Connect the power cord to the projector's power inlet and plug it into an
a
ele
ctrical outlet.
e projector's power indicator turns blue. is indicates that the
p
rojector is receiving power, but is not yet turned on (it is in standby
mode).
Press the power button on the control panel or remote control to turn on
b
th
e projector.
e projector beeps and the status indicator ashes blue as the projector
warms up. Once the projector is warmed up, the status indicator stops
ashing and turns blue.
u turn on the
Open the projector's lens cover.
c
Try the following if you do not see a projected image.
•
ify the lens cover is open all the way.
Ver
•
Turn on the connected computer or video device.
•
Change the screen output from the computer when using a laptop computer.
•
Insert a DVD or other video media, and press play (if necessary).
•
Press the [Source Search] button on the control panel or remote control to
detect the source.
•
Press the button for the desired video source on the remote control.
•
If the Home screen is displayed, select the source you want to project.
Page 31
Turning On the Projector
Warning
•
Never look into the projector lens when the lamp is on. is can damage your
eyes and is especially dangerous for children.
•
When turning on the projector at a distance using the remote control, make sure
there is no one looking into the lens.
•
During projection, do not block the light from the projector with a book or
other objects. If the light from the projector is blocked, the area on which the
light shines becomes hot which could cause it to melt, burn, or start a re. Also,
the lens may get hot due to the reected light which could cause the projector
to malfunction. To stop projection, use the A/V Mute function, or turn o the
projector.
•
A mercury lamp with high internal pressure is used as the projector's light source.
If the lamp is subjected to vibrations or shocks, or if it is used for an overly
extended length of time, the lamp may break or it may not turn on. If the lamp
explodes, gases may escape and small fragments of glass may be scattered which
could cause an injury. Be sure to observe the instructions below.
•
Do not disassemble or damage the lamp or subject it to any impacts.
•
Do not bring your face close to the projector while it is in use.
•
Particular care should be taken when the projector is installed to a ceiling, as
small pieces of glass may fall down when the lamp cover is removed. When
cleaning the projector or replacing the lamp yourself, be very careful not to
allow such pieces of glass to get into the eyes or mouth.
If the lamp breaks, ventilate the area immediately, and contact a doctor if any
fragments of broken glass are inhaled or get into the eyes or mouth.
•
Wh
en the Direct Power On setting is set to On in the projector's
Extended menu, the projector turns on as soon as you plug it in. Note
that the projector also turns on automatically in cases such as recovery
from a power outage.
s Extended > Operation > Direct Power On
•
If you select a specic port as the Auto Power On setting in the
projector's Extended menu, the projector turns on as soon as it detects
a signal or cable connection from that port.
s Extended > Operation > Auto Power On
Related Links
g
•
"Ho
me Screen" p.31
•
"Projector Setup Settings - Extended Menu" p.119
Home Screen
e Home screen feature allows you to easily select an image source and
acces
s useful functions. You can display the Home screen by pressing the
[Home] button on the control panel or remote control. e Home screen is
also displayed when you turn on the projector and no signal is being input.
Press the arrow buttons on the control panel or remote control to select a menu
item, and then press [Enter].
31
Page 32
Turning On the Projector
Selects the source you want to project.
A
Displays the Connection Guide. You can select the wireless connection methods
B
C
D
E
F
G
H
ding to the devices you are using, such as smartphones or computers.
accor
Removes all devices from the block list. e block list contains devices that are
automatically denied Miracast projection.
is message is displayed when a device has been added to the block list.
Displays the Help screen.
Displays the projector's menu.
Performs menu options assigned to Home Screen in the projector's Extended
menu.
Displays the Info menu.
Corrects the shape of an image that is an uneven rectangle.
Related Links
g
•
age Shape" p.41
"Im
•
"Projector Setup Settings - Extended Menu" p.119
•
"Using the Projector's Menus" p.112
•
"Using the Projector Help Displays" p.159
•
"Projector Information Display - Info Menu" p.133
32
e H
ome screen disappears aer 10 minutes of inactivity.
Page 33
Turning O the Projector
Turn o the projector aer use.
•
Tur
n o this product when it is not in use to prolong the life
of the projector. Lamp life varies depending on the mode selected,
environmental conditions, and usage. Brightness decreases over time.
•
Since the projector supports the direct shutdown feature, it can be
turned o directly using the breaker.
Press the power button on the control panel or remote control.
a
e pr
ojector displays a shutdown conrmation screen.
33
Press the power button again. (To leave it on, press any other button.)
b
e p
ojected image disappears, the projector beeps twice, and the status
r
indicator turns o.
With Epson's Instant O te
so you can pack up the projector for transport right away.
To transport or store the projector, make sure the power indicator is blue
c
d
t not ashing) and the status indicator is o, then unplug the power
(bu
cord.
Close the projector's lens cover.
chnology, there is no cool-down period
Page 34
Setting the Date and Time
34
You can set the date and time for the projector.
Turn on the projector.
a
Press the [Menu] button on the control panel or remote control.
b
c
d
e
Select the E
elect the Operation setting and press [Enter].
S
S
elect the Date & Time setting and press [Enter].
Y
ou see this screen:
xtended menu and press [Enter].
Select Date, press [Enter], and use the displayed keyboard to enter today's
g
d
ate.
Select Time, press [Enter], and use the displayed keyboard to enter the
h
c
urrent time.
Select Time Dierence (UTC), press [Enter], and set the time dierence
i
f
rom Coordinated Universal Time.
When you are nis
j
To activate daylight saving time, select the D
k
and press [Enter]. en select settings.
hed, select Set and press [Enter].
light Saving Time setting
ay
Select the Date & Time setting and press [Enter].
f
Y
ou see this screen:
When you are nis
l
hed, select Set and press [Enter].
Page 35
Setting the Date and Time
To update the time automatically through an Internet time server, select
m
th
e Internet Time setting and press [Enter]. en select settings.
35
When you are nis
n
Press [Menu] or [Esc] to exit the menus.
o
hed, select Set and press [Enter].
Page 36
Selecting the Language for the Projector Menus
If you want to view the projector's menus and messages in another language,
u can change the Language setting.
yo
Turn on the projector.
a
Press the [Menu] button on the control panel or remote control.
b
36
Select the E
c
Select the L
d
elect the language you want to use and press [Enter].
S
e
Press [Menu] or [Esc] to exit the menus.
f
xtended menu and press [Enter].
anguage setting and press [Enter].
Page 37
Projection Modes
37
Depending on how you positioned the projector, you may need to change the
ojection mode so your images project correctly.
pr
•
Front lets you project from a table in front of the screen.
•
Front/Ceiling ips the image over top-to-bottom to project upside-down
from a ceiling or wall mount.
•
Rear ips the image horizontally to project from behind a translucent screen.
•
Rear/Ceiling ips the image over top-to-bottom and horizontally to project
from a ceiling or wall mount and behind a translucent screen.
Related Links
g
•
"Changing the Projection Mode Using the Remote Control" p.37
•
"Changing the Projection Mode Using the Menus" p.37
•
"Projector Setup and Installation Options" p.19
Changing the Projection Mode Using the Remote Control
You can change the projection mode to ip the image over top-to-bottom.
T
c
o change projection back to the original mode, hold down the [A/V
te] button for 5 seconds again.
Mu
Changing the Projection Mode Using the Menus
You can change the projection mode to ip
and/or le-to-right using the projector menus.
Turn on the projector and display an image.
a
Press the [Menu] button on the control panel or remote control.
b
c
Select the E
xtended menu and press [Enter].
the image over top-to-bottom
Turn on the projector and display an image.
a
Hold down the [A/V Mute] button on the remote control for 5 seconds.
b
e image disappears briey and reappears ipped top-to-bottom.
Page 38
Projection Modes
Select Projection and press [Enter].
d
S
e
f
elect a projection mode and press [Enter].
Press [Menu] or [Esc] to exit the menus.
38
Page 39
Displaying a Test Pattern
You can display a test pattern to adjust the projected image without connecting
puter or video device.
a com
To set menu items that cannot be set while the test pattern is being
dis
played or to ne-tune the projected image, project an image from the
connected device.
Turn on the projector.
a
Press the [Menu] button on the control panel or remote control.
b
39
Select the S
c
Select Pattern > Test Pattern, and press [Enter].
d
e test pattern is displayed.
Adjust the image as necessary.
e
Press [Esc] to clear the test pattern.
f
ettings menu and press [Enter].
Page 40
Adjusting the Image Height
If you are projecting from a table or other at sur
or low, you can adjust the image height using the projector's adjustable feet.
e larger the angle of tilt, the harder it becomes to focus. Locate the projector
so that it only needs to be tilted at a small angle.
face and the image is too high
Extend the rear foot
A
Retract the rear foot
B
If the projected image is unevenly rectangular, you need to adjust the image
ape.
sh
40
Turn on the projector and display an image.
a
To adjust the front foot, pull up on the foot release lever and li t
b
of the projector.
e foot extends from the projector.
ou can adjust the position up to approximately 12 degrees.
Y
Release the lever to lock the foot.
c
If the image is tilted, rotate the rear feet to adjust their height.
d
e front
h
Related Links
g
•
"Image Shape" p.41
Page 41
Image Shape
41
You can project an even, rectangular image by placing the projector directly in
ont of the center of the screen and keeping it level. If you place the projector at
fr
an angle to the screen, or tilt it up or down, or o to the side, you may need to
correct the image shape.
Aer correction, your image is slightly smaller.
For the best quality images, we recommend adjusting the installation position of
the projector to achieve the correct image size and shape.
Related Links
g
•
"Auto V-Keystone" p.41
•
"Correcting the Image Shape with the Horizontal Keystone Slider" p.41
•
"Correcting the Image Shape with the Keystone Buttons" p.42
•
"Correcting the Image Shape with Quick Corner" p.43
Auto V-Keystone
When the projector is moved or tilted, Auto V-Keystone automatically corrects
any vertical keystone distortion.
Auto V-Keystone can correct the projected image distortion in these
conditions:
•
Projection angle is about 30º up or down
•
e Projection setting is set to Front in the projector's Extended menu
•
ou do not want to use the Auto V-Keystone function, set Auto
If y
V-Keystone to O in the projector's menu.
s Settings > Keystone > H/V-Keystone > Auto V-Keystone
Correcting the Image Shape with the Horizontal Keystone Slider
You can use the projector's horizontal keystone slider to correct the shape of
an imag
placed to the side of the projection area.
You can make eective corrections when the projection angle is about 30º right
or le.
a
b
e that is an uneven horizontal rectangle, such as when the projector is
Turn on the projector and display an image.
Adjust the slider until the image is an even rectangle.
Aer correction, your image is slightly smaller.
•
When you use the horizontal keystone slider, set H-Keystone
Adjuster to On in the projector's Settings menu.
s Settings > Keystone > H/V-Keystone > H-Keystone
Adjuster
•
You can also correct the shape of the image in the horizontal
direction in the projector's Settings menu.
s Settings > Keystone > H/V-Keystone
Related Links
g
•
"Pr
ojection Modes" p.37
•
"Projector Setup Settings - Extended Menu" p.119
•
"Projector Feature Settings - Settings Menu" p.117
Related Links
g
•
ojector Feature Settings - Settings Menu" p.117
"Pr
Page 42
Image Shape
42
Correcting the Image Shape with the Keystone Buttons
You can use the projector's keystone correction buttons to correct the shape of
an imag
You can use keystone buttons to correct images up to 30º right, le, up, or down.
a
b
e that is unevenly rectangular.
Turn on the projector and display an image.
Press one of the keystone adjustment buttons on the control panel to
di
play the Keystone adjustment screen.
s
Press a keystone button to adjust the image shape.
c
•
he projector is installed out of your reach, you can also correct the
If t
shape of the image using the remote control.
s Settings > Keystone > H/V-Keystone
Related Links
g
•
"P
ojector Feature Settings - Settings Menu" p.117
r
Page 43
Image Shape
43
Correcting the Image Shape with Quick Corner
You can use the projector's Qui
of an image that is unevenly rectangular.
Turn on the projector and display an image.
a
Press the [Menu] button on the control panel or remote control.
b
c
Select the S
ettings menu and press [Enter].
ck Corner setting to correct the shape and size
Select Keystone and press [Enter].
d
S
e
f
elect Quick Corner and press [Enter]. en press [Enter] again if
n
ecessary.
You see the area selection screen.
Use the arrow buttons to select the corner of the image you want to adjust.
en p
ess [Enter].
r
Press the arrow buttons to adjust the image shape as necessary.
g
To return to the area selection screen, press [Enter].
Page 44
Image Shape
•
•
If y
ou see this screen, you cannot adjust the shape any further in
the direction indicated by the gray triangle.
To r
eset the Quick Corner corrections, hold down [Esc] for
about 2 seconds while the Quick Corner adjustment screen is
displayed, and select Reset Quick Corner. Select Switch to H/
V-Keystone to switch the image shape correction method to
H/V-Keystone.
Related Links
g
•
ojector Feature Settings - Settings Menu" p.117
"Pr
44
Repeat steps 6 and 7 as needed to adjust any remaining corners.
h
When you are ni
i
e Keystone setting is now set to Quick Corner in the projector's Settings
menu. e next time you press the keystone adjustment buttons on the control
panel, the area selection screen is displayed.
shed, press [Esc].
Page 45
Resizing the Image with the Zoom Ring
You can resize the image using the projector's zoom ring. (Available only for
dels that have the zoom ring.)
mo
Turn on the projector and display an image.
a
Rotate the zoom ring to enlarge or reduce the image.
b
45
Page 46
Focusing the Image Using the Focus Ring
You can correct the focus using the focus ring.
Turn on the projector and display an image.
a
Rotate the focus ring to adjust the focus.
b
46
Page 47
Selecting an Image Source
When multiple image sources are connected to the projector, such as a
puter and DVD player, you can switch from one image source to the other.
com
Available sources vary depending on the projector model.
Make sure the connected image source you want to use is turned on.
a
For video image sources, insert a DVD or other video media and press
b
p
ay.
l
Do one of the following:
c
•
Pr
ess the [Source Search] button on the control panel or remote control
until you see the image from the source you want.
•
ess the button for the source you want on the remote control. If there
Pr
is more than one port for that source, press the button again to cycle
through the sources.
•
Press the [Home] button on the control panel or remote control.
en select the source you want to use from the screen displayed.
47
is screen is displayed when no image signal is detected. Check
the cable connections between the projector and image source.
Page 48
Image Aspect Ratio
48
e projector can display images in dierent width-to-height ratios called
pect ratios. Normally, the input signal from your video source determines
as
the image's aspect ratio.
If you always want to use a particular aspect ratio for a certain video input
source, you can select it using the projector's Signal menu.
Related Links
g
•
"Changing the Image Aspect Ratio" p.48
•
"Available Image Aspect Ratios" p.48
•
"Projected Image Appearance with Each Aspect Mode" p.49
•
"Input Signal Settings - Signal Menu" p.116
Changing the Image Aspect Ratio
You can change the aspect ratio of the displayed image.
Turn on the projector and switch to the image source you want to use.
a
Press the [Menu] button on the control panel or remote control.
b
Select S
c
Select Aspect and press [Enter].
d
Select one of the displayed aspect modes and press [Enter].
e
Press [Menu] or [Esc] to exit the menus.
f
ignal and press [Enter].
Related Links
g
•
"I
put Signal Settings - Signal Menu" p.116
n
Available Image Aspect Ratios
You can select the following image aspect ratios, depending on the input signal
from your image source.
Page 49
Image Aspect Ratio
•
e avail
•
Note that using the aspect ratio function of the projector to reduce,
enlarge, or split the projected image for commercial purposes or for
public viewing may infringe upon the rights of the copyright holder of
that image based on copyright law.
Aspect mode Description
able aspect ratio setting varies depending on the input signal.
49
Aspect mode Aspect ratio for input signals
16:10 16:9 4:3
Auto
Full
Auto Automatically sets the aspect ratio according to the
inp
ut signal.
Full Displays images using the full size of the projection
are
a, but does not maintain the aspect ratio.
Zoom Displays images using the full width of the projection
area and maintains the aspect ratio of the image.
Native Displays images as is (aspect ratio and resolution are
maintained).
Projected Image Appearance with Each Aspect Mode
Black bands and cropped images may project in certain aspect ratios, depending
on t
he aspect ratio and resolution of your input signal. See the following table to
conrm the position of black bands and cropped images.
e image for Native varies depending on the input signal.
Zoom
Native
Page 50
Adjusting Image Quality (Color Mode)
50
e projector oers dierent color modes to provide optimum brightness,
ntrast, and color for a variety of viewing environments and image types.
co
You can select the mode designed to match your image and environment, or
experiment with the available modes.
Related Links
g
•
"Changing the Color Mode" p.50
•
"Available Color Modes" p.50
•
"Setting Auto Iris" p.50
Changing the Color Mode
You can change the projector's Color Mode to optimize the image for your
viewing environment.
Turn on the projector and switch to the image source you want to use.
a
Press the [Menu] button on the control panel or remote control.
b
c
Select I
mage and press [Enter].
Select Color Mode and press [Enter].
d
S
e
f
g
•
elect one of the displayed color modes and press [Enter].
Press [Menu] or [Esc] to exit the menus.
Related Links
"I
age Quality Settings - Image Menu" p.114
m
Available Color Modes
You can set the projector to use these color modes, depending on the input
so
urce you are using:
Color mode Description
Dynamic is is the brightest mode. Best for prioritizing
b
rightness.
Vivid Best for enjoying various content in a bright
environment.
Cinema Best for enjoying content such as movies.
Natural Best for faithfully reproducing the color representation
of t
he content.
Setting Auto Iris
You can turn on Au
brightness of the content.
Turn on the projector and switch to the image source you want to use.
a
to Iris to automatically optimize the image based on the
Page 51
Adjusting Image Quality (Color Mode)
Press the [Menu] button on the control panel or remote control.
b
51
Select the I
c
Select Auto Iris and press [Enter].
d
C
e
hoose one of the following options and press [Enter]:
mage menu and press [Enter].
•
rmal for standard brightness adjustment.
No
•
High Speed to adjust brightness as soon as the scene changes.
Press [Menu] or [Esc] to exit the menus.
f
Page 52
Controlling the Volume with the Volume Buttons
e volume buttons control the projector's internal speaker system.
ou can also control the volume of any external speakers you connected to the
Y
projector.
You must adjust the volume separately for each connected input source.
Turn on the projector and start a presentation.
a
To lower or raise the volume, press the [Volume] buttons on the control
b
p
el or remote control as shown.
an
52
A volume gauge appears on the screen.
To set the volume to a sp
c
the projector's Settings menu.
ecic level for an input source, select Volume in
Caution
ot start a presentation at a high volume setting. Sudden loud noises may cause
Do n
hearing loss.
Always lower the volume before powering o, so that you can power on and then
gradually increase the volume.
Related Links
g
•
"Pr
ojector Feature Settings - Settings Menu" p.117
Page 53
Adjusting Projector Features
llow the instructions in these sections to use your projector's adjustment features.
Fo
Related Links
g
•
"HDMI Link Features" p.54
•
"Projecting a PC Free Presentation" p.56
•
"Shutting O the Image and Sound Temporarily" p.61
•
"Shutting O the Sound Temporarily" p.62
•
"Stopping Video Action Temporarily" p.63
•
"Zooming In/Zooming Out of Images (E-Zoom)" p.64
•
"Saving a User's Logo Image" p.66
•
"Saving a User Pattern" p.68
•
"Color Dierence Correction when Projecting from Multiple Projectors" p.69
•
"Projector Security Features" p.72
Page 54
HDMI Link Features
54
When an audio/video source that meets the HDMI CEC standard is connected
he projector's HDMI port, you can use the projector's remote control to
to t
control certain features of the linked device.
Example: Projector, audio/video system, and multi-media players connection
•
As lo
ng as the connected device meets the HDMI CEC standard,
you can use the HDMI Link features even if the audio/video system
in-between does not meet the HDMI CEC standard.
•
Up to 3 multi-media players that meet the HDMI CEC standard can be
connected at the same time.
Related Links
g
•
"Operating the Connected Devices Using the HDMI Link Features" p.54
•
Wh
en you use the HDMI Link features, set the HDMI Link setting to
On in the projector's Settings menu.
s Settings > HDMI Link > HDMI Link
•
You must also congure the connected device. See the documentation
supplied with the device for more information.
•
Some connected devices or functions of those devices may not
operate properly even if they meet the HDMI CEC standard. See the
documentation supplied with the device for more information.
•
Use a cable that supports the HDMI standard.
Press the [Menu] button on the control panel or remote control.
a
Select S
b
S
c
On t
Select Device Connections and press [Enter].
d
ettings and press [Enter].
elect HDMI Link and press [Enter].
he screen displayed, make sure that HDMI Link is set to On.
Operating the Connected Devices Using the HDMI Link Features
You can select the connected device that is available for HDMI Link and control
th
e selected device using the HDMI Link features.
Page 55
HDMI Link Features
55
Select the device you want to control and project the image from, and
e
press [Enter].
•
•
Press [Esc] to select the HDMI Link options as necessary.
f
•
A
dio Out Device: Select the device for audio output.
u
•
Po
wer On Link lets you control what happens when you turn on the
projector or linked device.
ed device is indicated by a blue mark.
A link
e device name is le blank if it cannot be acquired.
•
S
lect Projector to output audio from the projector itself.
e
•
Select AV System to output audio from an AV amplier that is
connected using an HDMI cable.
•
lect PJ -> Device or Bidirectional to turn the linked device
Se
on when the projector is turned on.
•
Select Device -> PJ or Bidirectional to turn the projector on
when the linked device is turned on.
You can use the projector's remote control to control the linked device, such as
p
ayback, stop, fast forward, and rewind.
l
Related Links
g
•
"Projector Feature Settings - Settings Menu" p.117
•
o
wer O Link lets you control whether linked devices are turned o
P
when the projector is turned o.
•
•
Press [Esc] to exit the menus.
g
Po
wer O Link only works when the connected device's CEC
power link function is enabled.
Note that depending on the status of the connected device (for
example, if it is recording), the device may not be turned o.
Page 56
Projecting a PC Free Presentation
56
You can use your projector's PC Free feature whenever you connect a USB
ice that contains compatible presentation les. is lets you quickly and
dev
easily display a presentation and control it using the projector's remote control.
Related Links
g
•
pported PC Free File Types" p.56
"Su
•
"Precautions on PC Free Projection" p.56
•
"Starting a PC Free Slide Show" p.57
•
"Starting a PC Free Movie Presentation" p.58
•
"PC Free Display Options" p.59
Supported PC Free File Types
You can project these types of les usin
•
o
r best results, place your les on media that is formatted in
F
FAT16/32.
•
If you have trouble projecting from media formatted for non-Windows
le systems, try formatting the media for Windows instead.
g the projector's PC Free feature.
File contents File type
(exten
Image .jpg Make sure the le is n
.bmp Make sure the le is not:
.gif Make sure the le is n
.png Make sure the le is not:
Movie .avi
(Mo
tion
JPEG)
Details
sion)
•
CMYK format
•
Progressive format
•
Highly compressed
•
Above 8192 × 8192 resolution
•
Above 1280 × 800 resolution
•
Above 1280 × 800 resolution
•
Animated
•
Interlaced
•
Above 1920 × 1200 resolution
•
Interlaced
Supports only AVI 1.0.
Make sure the le is not:
•
Saved with an audio codec other than PCM or
ADPCM
•
Above 1280 × 720 resolution
•
Larger than 2 GB
ot:
ot:
Precautions on PC Free Projection
Note the following precautions when using PC Free features.
•
You cannot use a USB key for PC Free features.
•
Do not disconnect the USB storage device while it is being accessed;
otherwise, PC Free may not operate correctly.
Page 57
Projecting a PC Free Presentation
•
u may not be able to use the security features on certain USB storage
Yo
devices with PC Free features.
•
When connecting a USB device that includes an AC adapter, connect the AC
adapter to an electrical outlet when you use the device with your projector.
•
Some commercially available USB card readers may not be compatible with
the projector.
•
e projector can recognize up to 5 cards inserted into the connected card
reader at one time.
•
You cannot correct keystone distortion while projecting in PC Free, so correct
the image shape before you begin your presentation.
•
You can use the following functions while projecting in PC Free.
•
Freeze
•
A/V Mute
•
E-Zoom
Related Links
g
•
"Stopping Video Action Temporarily" p.63
•
"Shutting O the Image and Sound Temporarily" p.61
•
"Zooming In/Zooming Out of Images (E-Zoom)" p.64
Starting a PC Free Slide Show
Aer connecting a USB device to the projector, you can switch to the USB input
source and start your slide show.
•
u can change the PC Free operation options or add special eects by
Yo
highlighting Option at the bottom of the screen and pressing [Enter].
Press the [USB] button on the remote control.
a
e PC Fr
ee le list screen is displayed.
•
If t
he Select Drive screen is displayed, press the arrow buttons to
select the drive and press [Enter].
•
To display images on the other USB drive, highlight Select Drive
at the top of the le list screen and press [Enter].
Do one of the following to locate your les:
b
•
If y
ou need to display les inside a subfolder on your device, press the
arrow buttons to highlight the folder and press [Enter].
•
To move back up a folder level on your device, highlight Back to Top
and press [Enter].
Do one of the following:
c
•
To di
splay an individual image, press the arrow buttons to highlight the
image and press [Enter]. (Press the [Esc] button to return to the le list
screen.)
•
To display a slide show of all the images in a folder, press the arrow
buttons to highlight the Slideshow option at the bottom of the screen
and press [Enter].
57
Page 58
Projecting a PC Free Presentation
•
Yo
u can change the image switching time by highlighting Option
at the bottom of the screen and pressing [Enter].
•
If any le names are longer than the display area or include
unsupported symbols, the le names may be shortened or
changed only on the screen display.
Related Links
g
•
"PC Free Display Options" p.59
•
"Connecting to a USB Device" p.23
Starting a PC Free Movie Presentation
58
While projecting, use the following commands to control the display:
d
•
To r
otate a displayed image, press the up or down arrow button.
•
To move to the next or previous image, press the le or right arrow
button.
Aer connecting a USB device to the projector, you can switch to the USB input
source and start your movie.
•
u can change the PC Free operation options by highlighting Option
Yo
at the bottom of the screen and pressing [Enter].
Press the [USB] button on the remote control.
a
e PC Fr
ee le list screen is displayed.
To stop the display, follow the on-screen instructions or press the [Esc]
e
bu
tton.
You return to the le list screen.
Turn o the USB device, if necessary, and then disconnect the device from
f
t
he projector.
•
If the Select Drive screen is displayed, press the arrow buttons to
select the drive and press [Enter].
•
To display movie les on the other USB drive, highlight Select
Drive at the top of the le list screen and press [Enter].
Page 59
Projecting a PC Free Presentation
Do one of the following to locate your les:
b
•
If y
ou need to display les inside a subfolder on your device, press the
arrow buttons to highlight the folder and press [Enter].
•
To move back up a folder level on your device, highlight Back to Top
and press [Enter].
To play back a movie, press the arrow buttons to highlight the le and
c
p
ress [Enter].
•
If an
y le names are longer than the display area or include
unsupported symbols, the le names may be shortened or
changed only on the screen display.
•
If you want to play back all the movies in a folder in sequence,
select the Slideshow option at the bottom of the screen.
59
Setting Options Description
Display Order Name Order Displays les in name order
To stop movie playback, press the [Esc] button, highlight Exi
d
[Enter].
You return to the le list screen.
Turn o the USB device, if necessary, and then disconnect the device from
e
t
he projector.
Related Links
g
•
"PC Free Display Options" p.59
•
"Connecting to a USB Device" p.23
t, and press
PC Free Display Options
You can select these display options when using PC Free. To access this screen,
light Option at the bottom of the PC Free le list screen and press [Enter].
high
Date Order Displays les in dat
Sort Order In Ascending Sorts les in rs
In Descending Sorts les in las
Continuous Play On Displays a slide show continuously
O Displays a slide show once
Screen Switching
Tim
e
Eect No No eect
No Does not display the next le
automatically
1 Second to 60 Seconds Displays les fo
switches to the next le automatically;
high resolution images may switch at
a slightly slower rate
W
ipe Transitions between images using a
wi
pe eect
Dissolve Transitions between images using a
dis
solve eect
e order
t-to-last order
t-to-rst order
r the selected time and
Page 60
Projecting a PC Free Presentation
Setting Options Description
Random Transitions between images using a
random variety of eects
60
Page 61
Shutting O the Image and Sound Temporarily
61
You can temporarily turn o
redirect your audience's attention during a presentation. Any sound or video
action continues to run, however, so you cannot resume projection at the point
that you stopped it.
If you want to display an image such as a company logo or picture when
th
e [A/V Mute] button is pressed, you can select the screen displayed in
the A/V Mute setting in the projector's Extended menu.
s Extended > Display > A/V Mute
Press the [A/V Mute] button on the remote control to temporarily stop
a
pr
ojection and mute any sound.
the projected image and sound if you want to
•
Yo
u can also stop projection using the A/V Mute slide lever on the
projector.
•
e projector's power automatically turns o 30 minutes aer A/V
Mute is enabled. You can disable this feature.
s ECO > A/V Mute Timer
•
e lamp is still operating during A/V Mute, so the lamp hours
continue to accumulate.
Related Links
g
•
"Pr
ojector Setup Settings - Extended Menu" p.119
•
"Projector Setup Settings - ECO Menu" p.131
To turn the image and sound back on, press [A/V Mute] again.
b
Page 62
Shutting O the Sound Temporarily
You can temporarily mute the audio.
Press the [Mute] button on the remote control to mute the audio.
a
To unmute, press [Mute] again.
b
62
Page 63
Stopping Video Action Temporarily
You can temporarily stop the action in a video or computer presentation and
ep the current image on the screen. Any sound or video action continues to
ke
run, however, so you cannot resume projection at the point that you stopped it.
Press the [Freeze] button on the remote control to stop the video action.
a
To restart the video action in progress, press [Freeze] again.
b
63
Page 64
Zooming In/Zooming Out of Images (E-Zoom)
You can zoom in or zoom out of the projected image using the [E-Zoom] button
he remote control.
on t
e size and the position of the zoomed image remain even aer switching the
input source or turning o the projector.
Related Links
g
•
"Zo
oming Into Images" p.64
•
"Zooming Out of Images" p.64
Zooming Into Images
Press the [E-Zoom] + button on the remote control.
a
•
To pan around the zoomed image, use the arrow buttons.
•
To zoom out of the image, press the [E-Zoom] – button.
•
To return to the original image size, press the [Default] button.
When projecting images from an Epson document camera, you can
enl
arge the image from one to eight times its size in 57 incremental steps
using the [E-Zoom] + button on the document camera.
When the zoom ratio display disappears, the size and the position of the
zoomed image will be saved. Press the [E-Zoom] +/- buttons to make
adjustment again.
Zooming Out of Images
Press the [E-Zoom] - button on the remote control.
a
64
e projected image is enlarged focusing around the center of the image.
Y
ou can enlarge the image between one to four times in 25 incremental
steps.
Use the following buttons on the remote control to adjust the zoomed
b
imag
e while the zoom ratio is displayed:
•
Press the [E-Zoom] + button repeatedly to zoom into the image.
e projected image is reduced. You can reduce the image between 100%
t
o 50% in incremental steps.
Use the following buttons on the remote control to adjust the zoomed-out
b
imag
e while the zoom ratio is displayed:
•
Press the [E-Zoom] - button repeatedly to zoom out of the projected
image.
Page 65
Zooming In/Zooming Out of Images (E-Zoom)
65
•
•
•
When the zoom ratio display disappears, the size and the position of the
med image will be saved. Press the [E-Zoom] +/- buttons to make
zoo
adjustment again.
ove the zoomed-out image in the projection area, use the arrow
To m
buttons.
To zoom into the image, press the [E-Zoom] + button.
To return to the original image size, press the [Default] button.
When projecting image from an Epson document camera, you can also
re
duce the image using the [E-Zoom] - button on the document camera.
Page 66
Saving a User's Logo Image
66
You can save an image on the projector and display it whenever the projector
ns on. You can also display the image when the projector is not receiving an
tur
input signal. is image is called the user's logo screen.
You can select a photo, graphic, or company logo as the user's logo, which is
useful in identifying the projector's owner to help deter the. You can prevent
changes to the user's logo by setting up password protection.
•
If t
he User's Logo Protection setting in the Password Protection
setting menu is set to On, set to O before saving the user's logo.
•
When you copy the menu settings from one projector to another using
the batch setup feature, user's logo is also copied. Do not register the
information that you do not want to share between multiple projectors
as a user's logo.
•
You cannot save content that is protected by HDCP.
•
is function is unavailable if the input source is AirPlay, LAN, or
Miracast.
Display the image you want to project as the user's logo.
a
Press the [Menu] button, select the E
b
ended menu, and press [Enter].
xt
Select User's Logo > Start Setting and press [Enter].
c
You see a prompt asking if you want to use the displayed image as a user's
logo.
Adjustments such as Keystone, E-Zoom, or Aspect are temporarily
celed when you select User's Logo.
can
Select Yes and press [Enter].
d
C
e
f
g
h
i
heck the displayed image, and then select Yes
e user's logo is overwritten and a completion message is displayed.
Press [Esc] to exit the message screen.
Select the E
elect Display and press [Enter].
S
S
elect when you want to display the User's Logo screen:
•
To di
Background and set it to Logo.
s Extended > Display > Display Background
•
To display it whenever you turn the projector on, select Startup Screen
and set it to On.
s Extended > Display > Startup Screen
•
To display it whenever you press the [A/V Mute] button, select A/V
Mute and set it to Logo.
s Extended > Display > A/V Mute
xtended menu and press [Enter].
splay it whenever there is no input signal, select Display
to save it as the user's logo.
Page 67
Saving a User's Logo Image
67
To prevent anyone from changing the User's Logo settings without rs
a password, set the User's Logo Protection setting to On in the Password
Protection setting menu and set the password.
Related Links
g
•
"Shutting O the Image and Sound Temporarily" p.61
•
"Selecting Password Security Types" p.73
t entering
Page 68
Saving a User Pattern
68
ere are four types of patterns pre-registered in the projector, such as ruled
es and grid patterns. You can project these patterns to aid in presentations
lin
using the Pattern Display settings.
You can also save the image that is currently being projected as a User Pattern.
Once you save a User Pattern, the pattern cannot be returned to the
fact
ory default.
Project the image you want to save as the User Pattern, and then press the
a
[Menu] button on the control panel or remote control.
Select the Settings menu and press [Enter].
b
•
Ad
temporarily cancelled when you select User Pattern.
•
You cannot save digital images protected by HDCP technology as
a User Pattern.
Select Yes and press [Enter].
d
P
e
f
ress [Enter].
Yo
u see a prompt asking if you want to save the image as the User Pattern.
Select Yes and press [Enter].
Y
ou see a completion message.
justments such as Keystone, E-Zoom, or Aspect are
Select Pattern > User Pattern and press [Enter].
c
Y
ou see a prompt asking if you want to use the displayed image as a User
Pattern.
Page 69
Color Dierence Correction when Projecting from Multiple Projectors
69
When lining up multiple projectors to project images, you can correct the
ightness and color tone of each projector's image so that the images match
br
closely.
You can set a unique projector ID for each projector to operate them
individually using a remote control, and then correct the brightness and color
for each projector.
•
In s
ome cases the brightness and color tone may not match completely
even aer correction.
•
If brightness and color tone dierences become more noticeable over
time, repeat the adjustments.
Related Links
g
•
"Set
ting the Projector ID" p.69
•
"Selecting the Projector You want to Operate" p.69
•
"Matching Multiple-Projector Display Quality" p.70
Setting the Projector ID
To control multiple projectors from a remote control, give each projector a
unique ID
.
U
c
d
e
se the arrow buttons to select the identication number you want to use
for the projector. en press [Enter].
Press [Menu] or [Esc] to exit the menus.
Repeat these steps for all the other projectors you want to operate from
o
e remote control.
n
Selecting the Projector You want to Operate
Press the [Menu] button, select the Ext
a
Select Projector ID and press [Enter].
b
ended menu, and press [Enter].
Aer setting the projector's ID, select the ID for the projector you want to
o
perate using the remote control.
Page 70
Color Dierence Correction when Projecting from Multiple Projectors
70
Aim the remote control at the target projector and press the [ID] button.
a
urrent Projector ID is displayed on the projected screen. It
e c
di
sappears aer about 3 seconds.
While holding the [ID] button, press the number button that matches the
b
ID of t
he projector you want to operate.
•
Wh
en you select [0/All] on the remote control, you can operate
all projectors regardless the Projector ID setting.
•
When you set the Projector ID setting to O, you can operate
the projector using the remote control whichever ID you select
on the remote control.
•
e projector ID setting is saved in the remote control. Even if
the remote control batteries are removed to replace them and
so on, the saved ID setting is retained. However, if the batteries
are le out of the remote control for an extended period, the ID
returns to its default setting ( 0/All).
•
When you use multiple remote controls at the same time, you
may not be able to operate projectors as intended due to infrared
interference.
Matching Multiple-Projector Display Quality
You can match the display quality of multiple projectors that will project next to
ac
h other.
e
Turn on all the projectors on which you want to match the display quality.
a
Set ID numbers on each projector.
b
e projector you want to operate is selected.
Make sure all the projectors are using the same Color Mode setting.
c
Select the remote control ID to match the r
d
t projector.
s
Page 71
Color Dierence Correction when Projecting from Multiple Projectors
Press the [Menu] button, select the Image menu, and press [Enter].
e
Select settings as necessary.
f
71
Select the remote control ID to match the next projector, then repeat
g
Im
age menu adjustments as necessary to match the projectors' displays.
Page 72
Projector Security Features
72
You can secure your projector to deter th
setting up the following security features:
•
Password security to prevent people who do not know the password from
using the projector, and prevent changes to the startup screen and other
settings.
is acts as an anti-the function as the projector cannot be used even if it is
stolen, and you can limit who can use the projector.
•
Button lock security to block operation of the projector using the buttons on
the control panel.
is is useful at events or shows when you want to deactivate all buttons
during projection or at schools when you want to limit button operation.
•
Security cabling to physically secure the projector in place.
Related Links
g
•
"Password Security Types" p.72
•
"Locking the Projector's Buttons" p.74
•
"Installing a Security Cable" p.75
e or prevent unintended use by
Password Security Types
•
g
•
•
•
dule Protection password prevents anyone from changing the
Sche
projector's schedule settings.
Related Links
"Setting a Password" p.72
"Selecting Password Security Types" p.73
"Entering a Password to Use the Projector" p.74
Setting a Password
o
r the rst time you use the projector, you must set a password.
F
No password is set by default. You must set a password.
Hold down the [Freeze] button on the remote control for about 5 seconds.
a
You can set up the following types of password security using one shared
password:
•
Power On Protection password prevents anyone from using the projector
without rst entering a password. When plugging the power cord and turning
on the projector at rst time, you must enter the correct password. is also
applies to Direct Power On and Auto Power On.
•
User's Logo Protection password prevents anyone from changing the custom
screen displayed when the projector turns on, when no signal is being input,
or when you use the A/V Mute feature. e custom screen discourages the
by identifying the projector's owner.
•
Network Protection password prevents anyone from changing the projector's
Network settings.
You see the Password Protection setting menu.
•
If no password has been set, a screen prompting you to set
a password is displayed before you can view the Password
Protection setting menu.
•
If Password Protection is already activated, you must enter the
correct password to display the Password Protection setting
menu.
Page 73
Projector Security Features
73
Select Password and press [Enter].
b
You see the prompt Chan
Select Yes and press [Enter].
c
If you select No
again.
Use the numeric buttons on the remote control to set a four-digit
d
p
sword.
as
ge the password?.
, the Password Protection setting menu is displayed
Enter the password again.
e
f
g
Selecting Password Security Types
Aer
security types you want to use.
u see the message Password accepted. If you enter the password
Yo
incorrectly, a message is displayed prompting you to re-enter the
password.
Press [Esc] to return to the menu.
Make a note of the password and keep it in a safe place.
setting a password, you see this menu, allowing you to select the password
e password displays as **** as it is entered. A conrmation prompt is
di
splayed when you enter the fourth digit.
If you do not see this menu, hold down the [Freeze] button on the remote
trol for 5 seconds until the menu appears.
con
•
To prevent unauthorized use of the projector, select On as the Power On
Protection setting.
•
To prevent changes to the User's Logo screen or related display settings, select
On as the User's Logo Protection setting.
•
To prevent changes to network settings, select On as the Network Protection
setting.
Page 74
Projector Security Features
74
•
You can attach the password protect sticker to the projector as an additional
the deterrent.
revent changes to the projector's schedule settings, select On as the
To p
Schedule Protection setting.
Be sure to keep the remote control in a safe place; if you lose it, you will
no
t be able to enter the password.
Entering a Password to Use the Projector
en the password screen is displayed, enter the correct password.
Wh
e password screen closes.
f the password is incorrect, you see a message and a prompt to try again.
I
b
Ent
er the correct password to proceed.
Attention
•
•
•
correct password is entered three times in succession, the message
If an in
e projector's operation will be locked. is displayed for approximately
5 minutes, and the projector switches to standby mode. If this happens,
disconnect the power plug from the electrical outlet, reinsert it, and turn
the projector back on. e projector displays the password entry screen
again so that you can enter the correct password.
If you have forgotten the password, make a note of the " Request Code:
xxxxx" number that appears on the screen and contact Epson for help.
If you continue to repeat the above operation and input the wrong
password 30 times in succession, the message e projector's operation
will be locked. Contact Epson as described in your documentation. is
displayed and the projector does not accept any more password entries.
Contact Epson for help.
Use the numeric buttons on the remote control to enter the password.
a
Locking the Projector's Buttons
You can lock the buttons on the control panel to prevent anyone from using the
ojector. e projector can still be operated using the remote control.
pr
Page 75
Projector Security Features
75
Press the [Menu] button on the control panel or remote control.
a
Select the S
b
Select Lock Setting > Control Panel Lock, and press [Enter].
c
S
d
e
elect one of these lock types and press [Enter]:
•
To lo
•
To lock all buttons except the power button, select Partial Lock.
You see a conrmation prompt.
Select Yes and press [Enter].
e
Control Panel Lock setting takes eect.
ettings menu and press [Enter].
ck all of the projector's buttons, select Full Lock.
Unlocking the Projector's Buttons
he projector's buttons have been locked, do one of the following to unlock
If t
them.
•
Hold down the [Enter] button on the control panel for 7 seconds. A message
is displayed and the lock is released.
•
Select O as the Control Panel Lock setting in the projector's Settings menu.
s Settings > Lock Setting > Control Panel Lock
Related Links
g
•
"Projector Feature Settings - Settings Menu" p.117
Installing a Security Cable
You can install the security cable on the projector to deter the.
•
Use the security slot on the projector to attach a Kensington Microsaver
Security system.
For more details on the Microsaver Security System, visit the
sington Web site.
Ken
https://www.kensington.com/
•
Us
e the security cable attachment point on the projector to attach a wire cable
and secure it to a room xture or heavy furniture.
Related Links
g
•
"Unlocking the Projector's Buttons" p.75
Page 76
Projector Security Features
76
You can use a commercially available th
the documentation supplied with the wire lock for locking instructions.
e-prevention wire lock. See
Page 77
Using the Projector on a Network
llow the instructions in these sections to set up your projector for use on a network.
Fo
Related Links
g
•
"Wireless Network Projection" p.78
•
"Wireless Network Projection from a Mobile Device (Miracast)" p.87
•
"Using AirPlay" p.91
•
"Secure HTTP" p.95
Page 78
Wireless Network Projection
You can send images to your projector through a wireless network.
u can connect the projector to your wireless network by conguring the
Yo
connection manually using the projector's Network menus.
Aer setting up the projector, download and install the necessary network
soware. Use the following soware and documentation to set up and control
wireless projection.
•
Epson iProjection (Windows/Mac) soware allows you to hold interactive
meetings by projecting the computer screens of users over a network. See the
Epson iProjection Operation Guide (Windows/Mac) for instructions.
•
Epson iProjection (iOS/Android) app allows you to project from iOS or
Android devices.
You can download Epson iProjection from the App Store or Google Play. Any
fees incurred when communicating with the App Store or Google Play are the
responsibility of the customer.
•
Epson iProjection (Chromebook) app allows you to project from
Chromebook devices.
You can download Epson iProjection from the Chrome Web Store. Any
fees incurred when communicating with the Chrome Web Store are the
responsibility of the customer.
•
et
ting Up Wireless Network Security when Simple AP Mode is Set to On"
"S
p.82
•
"Setting Up Wireless Network Security when Simple AP Mode is Set to O"
p.82
•
"Using a QR Code to Connect a Mobile Device" p.85
•
"Using a USB Key to Connect a Windows Computer" p.86
Safety Instructions for Built-in Wireless LAN Module
is projector contains built-in wireless LAN modules. Be sure to follow these
im
portant guidelines when using a wireless LAN connection.
Warning
•
•
ot use the device near medical equipment such as pace makers. Furthermore,
Do n
when using the device, make sure there is no medical equipment such as pace
makers, in the surrounding area. Electromagnetic interference may cause medical
equipment to malfunction.
Electromagnetic interference may cause automatically controlled equipment
to malfunction which could cause an accident. Do not use the device near
automatically controlled equipment such as automatic doors or re alarms.
78
•
f t
he Web Control Password has not been set, a screen prompting
I
you to set a password is displayed when you save the network settings.
Follow the on-screen instructions to set the password.
•
When using the Moderator function in Epson iProjection to display the
projector screen on a computer, you cannot capture the screen on that
computer.
Related Links
g
•
"Safet
y Instructions for Built-in Wireless LAN Module" p.78
•
"Connection Methods for Wireless Network Projection" p.78
•
"Selecting Wireless Network Settings Manually" p.79
•
"Selecting Wireless Network Settings in Windows" p.81
•
"Selecting Wireless Network Settings in Mac" p.82
Caution
e sure you keep a distance of at least 20 cm between the device and your body.
Mak
Otherwise, it could cause you to feel unwell.
Connection Methods for Wireless Network Projection
Choose a connection method for connecting your computer and projector over
work based on your network environment.
a net
•
Turning on simple AP mode lets you directly connect to smartphones, tablets,
or computers using your projector as an access point. When you use this
Page 79
Wireless Network Projection
79
method, connect the projector using Qui
iProjection soware or use Miracast.
ck Connection Mode of the Epson
Selecting Wireless Network Settings Manually
Before you can project from your wireless network, you need to select network
set
tings for the projector.
Press the [Menu] button, select the Network menu, and press [Enter].
a
Select On as th
b
Select Network Conguration and press [Enter].
c
S
d
elect the Basi
e Wireless LAN Power setting.
c menu and press [Enter].
You can use the wireless LAN even when the projector is o. To do so,
follow the steps below to congure the wireless LAN, and then set A/V
Output to Always On in A/V Settings from the Extended menu.
s Extended > A/V Settings > A/V Output
Page 80
Wireless Network Projection
80
Select the basic options as necessary.
e
•
Projector Name lets you enter a name up to 16 alphanumeric
characters long to identify the projector over the network.
•
Remote Password lets you enter a password between 8 and 32
alphanumeric characters long for accessing the projector using Basic
Control. (e user name is EPSONREMOTE. No password is set by
default.)
•
Web Control Password lets you enter a password between 8 and 32
alphanumeric characters long for accessing the projector over the Web.
(e user name is EPSONWEB. No password is set by default.)
•
Monitor Password lets you enter a password up to 16 alphanumeric
characters long when using Epson Projector Management Ver.5.30
or earlier, or when monitoring the projector in combination with a
switcher or controller. (No password is set by default.)
•
Moderator Password lets you enter a four-digit number password for
accessing the projector as a moderator using Epson iProjection. (No
password is set by default.)
•
Projector Keyword lets you turn on a security password to prevent
access to the projector by anyone not in the room with it. You must
enter a displayed, randomized keyword from a computer using Epson
iProjection to access the projector and share the current screen.
•
Display Keyword lets you select whether to display a projector keyword
on the projected image when accessing the projector using Epson
iProjection.
•
Display LAN Info. lets you set the display format for the projector's
network information.
Use the displayed keyboard to enter numbers and characters. Press
the arrow buttons on the remote control to highlight characters and
press [Enter] to select them.
Select the Wireless LAN menu and press [Enter].
f
Select the connection method.
g
•
To connect in simple AP mode, set the Simple AP setting to On and go
to step 11.
You must set the Pass
for the rst time. Follow the on-screen instructions to set the
passphrase.
•
I
ou are not using simple AP mode and want to connect using a
f y
wireless LAN access point, go to the next step.
Select Search Access Point to select the access point you want to connect
h
t
o.
If you need to assign the SSID manually, select SS
SSID.
phrase when using simple AP mode
ID
to enter the
Page 81
Wireless Network Projection
Assign the IP settings for your network as necessary.
i
•
If your network assigns addresses automatically, select IP Settings to set
the DHCP setting to On.
•
If you must set addresses manually, select IP Settings to set the DHCP
setting to O, and then enter the projector's IP Address, Subnet Mask,
and Gateway Address as necessary.
To prevent the SSID or IP address from being displayed on the LAN
j
st
andby screen and Home screen, set the SSID Display setting or the IP
Address Display setting to O.
81
When you nis
k
screen instructions to save your settings and exit the menus.
Press the [Wireless] button on the remote control until you see the LAN
l
s
andby screen.
t
e wireless network settings are complete when you see the correct IP
address on the LAN standby screen.
h selecting settings, select Complete and follow the on-
If no Web Control Password has been set, a screen prompting
ou to set a password is displayed before you can save the settings.
y
Follow the on-screen instructions to set the password.
When you have nis
select the wireless network on your computer. en start the network soware
to send images to your projector through a wireless network.
hed making wireless settings for your projector, you need to
Selecting Wireless Network Settings in Windows
Before connecting to the projector, select the correct wireless network on your
computer.
To access your wireless utility so
a
Windows taskbar.
Select the network name (SSID) of the network the projector is connecting
b
t
.
o
Click Connect.
c
ware, click the network icon on the
Page 82
Wireless Network Projection
Selecting Wireless Network Settings in Mac
Before connecting to the projector, select the correct wireless network in Mac.
Click the Wi-Fi icon on the menu bar at the top of the screen.
a
Make sure Wi-Fi is turned on and select the network name (SSID) of the
b
n
etwork the projector is connecting to.
Setting Up Wireless Network Security when Simple AP Mode is Set to On
You can set up security for your projector to use on a wireless network with
simp
le AP mode. You can use WPA2-PSK security.
Contact your network administrator for guidance on entering the correct
info
rmation.
S
c
d
e
elect the Wireless LAN menu and press [Enter].
Select Simple AP and press [Enter].
S
elect Passphrase, press [Enter], and enter a passphrase from 8 to 63
c
haracters long. To enter more than 32 characters, use your Web browser.
82
Press the [Menu] button, select the N
a
Select Network Conguration and press [Enter].
b
twork menu, and press [Enter].
e
When you have nis
f
on-screen instructions to save your settings and exit the menus.
hed making settings, select Complete and follow the
Setting Up Wireless Network Security when Simple AP
Mode is Set to O
You can set up security for your projector to use on a wireless network. Set
up o
ne of the following security options to match the settings used on your
network.
•
WPA3-PSK security
•
WPA2/WPA3-PSK security
Page 83
Wireless Network Projection
83
•
WPA3-EAP s
•
WPA2/WPA3-EAP security
When setting WPA3-EAP or WPA2/WPA3-PSK security, store the
a
certicate in a format that is compatible with the projector in the root
directory of the USB storage device.
Press the [Menu] button, select the Ne
b
Select Network Conguration and press [Enter].
c
S
d
elect the Wireless LAN menu and press [Enter].
ecurity
Contact your network administrator for guidance on entering the correct
info
rmation.
twork menu, and press [Enter].
Select the Security setting and press [Enter].
e
Select the security settings to match your network settings.
f
Do one of the following according to the security you selected.
g
•
WP
and enter a passphrase from 8 to 63 characters long. To enter more than
32 characters, use your Web browser. en go to step 16.
•
WPA3-EAP or WPA2/WPA3-EAP: Select EAP Method and press
[Enter].
K or WPA2/WPA3-PSK: Select Passphrase, press [Enter],
A3-PS
Page 84
Wireless Network Projection
84
Select the protocol for authentication as the EAP Type setting.
h
To import your cert
i
•
Client Certicate for the EAP-TLS type
•
CA certicate for all EAP types
You can also register the digital cert
However, be sure to register just once or the certicate may not
install correctly.
icate, select the certicate type and press [Enter].
icates from your Web browser.
Select the cert
m
A message is displayed prompting you to enter the password for the
certicate.
Enter a password and press [Enter].
n
e cert
Select your EAP settings as necessary.
o
•
Us
er name lets you enter a user name using up to 64 alphanumeric
characters. To enter more than 32 characters, use your Web browser.
When importing a client certicate, the name the certicate was issued
to is automatically set.
•
Password lets you enter a password using up to 64 alphanumeric
characters for authentication when using the PEAP type. To enter more
than 32 characters, use your Web browser.
•
RADIUS Serv.Name lets you enter the server name to be veried.
icate to import using the displayed list.
icate is imported and a completion message appears.
Select Register and press [Enter].
j
Follow the on-screen instructions to connect a USB storage device to the
k
pr
ojector's USB-A port.
Press [Enter] to display the cert
l
icate list.
When you have nished selecting settings, select Complete and follow the
p
on-screen instructions to save your settings and exit the menus.
Page 85
Wireless Network Projection
Related Links
g
•
pported Client and CA Certicates" p.85
"Su
•
"Network Menu - Wireless LAN Menu" p.124
Supported Client and CA Certicates
o
u can register these types of digital certicates.
Y
Client Certicate (EAP-TLS)
Specication Description
Format PKCS#12
Extension PFX, P12
Using a QR Code to Connect a Mobile Device
Aer selecting the wireless network settings for your projector, you can display
a Q
R code on the screen and use it to connect a mobile device using the Epson
iProjection (iOS/Android) app.
•
e sure you have installed the latest version of Epson iProjection on
Mak
your device.
•
You can download Epson iProjection for free from the App Store or
Google Play. Any fees incurred when communicating with the App
Store or Google Play are the responsibility of the customer.
•
When using Epson iProjection in Quick connection mode, we
recommend making security settings.
85
Encryption RSA
Hashes MD5/SHA-1/SHA-256/SHA-384/SHA-512
Key length 512/1024/2048/4096 bit
Password * Up to 64 alphanumeric characters; required
CA Certicate (PEAP/EAP-TLS)
Specication Description
Format X509v3
Extension DER/CER/PEM
Encryption RSA
Hashes MD5/SHA-1/SHA-256/SHA-384/SHA-512
Key length 512/1024/2048/4096 bit
Encoding BASE64/Binary
* You can set a password using up to 64 alphanumeric characters. However, you
ne
ed to use your Web browser to enter more than 32 characters.
Press the [Wireless] button on the remote control.
a
e QR code is displayed on the projected surface.
•
ou do not see the QR code, set the Display LAN Info. setting
If y
to Text & QR Code in the projector's Network menu.
s Network > Network Conguration > Basic > Display LAN
Info.
•
To hide the QR code, press [Esc].
•
When the QR code is hidden, press [Enter] to display the code.
Start Epson iProjection on your mobile device.
b
Page 86
Wireless Network Projection
86
Read the projected QR code using Epson iProjection to connect it to the
c
projector.
To correctly read the QR code, make sure you face the screen
uarely and closely enough so that the projected code ts into the
sq
guide of the mobile device's QR code reader. If you are too far from
the screen, the code may not be read.
When a connection is established, select Co
th
en select the le you want to project.
ntents menu from
Using a USB Key to Connect a Windows Computer
You can set up your USB ash
projector to a wireless LAN supported Windows computer. Aer creating the
USB key, you can quickly project images from the network projector.
Set up the USB key using Epson iProjection (Windows) so
a
See the Epson iProjection Operation Guide (Windows/Mac) for
structions.
in
drive as a USB key to quickly connect the
ware.
, and
Connect the USB key to the projector's USB-A port.
d
Yo
u see a projected message that the network information update is
complete.
Remove the USB key.
e
Connect the USB key to a USB port on your computer.
f
Follow the on-screen instructions to install the necessary application.
g
•
he Windows Firewall message is displayed, click Yes to disable
If t
the rewall.
•
You need administrator authority to install the soware.
•
If it is not installed automatically, double-click MPPLaunch.exe
in the USB key.
Aer a few minutes, your computer image is displayed by the projector.
hen you have nis
W
h
Hardware option in the Windows taskbar, and then remove the USB key
from your computer.
hed projecting wirelessly, select the Safely Remove
Turn on the projector.
b
Press the [Wireless] button on the remote control until you see the LAN
c
s
andby screen.
t
e LAN standby screen is displayed. Verify that an SSID and IP address
are displayed.
You may need to restart your computer to reactivate your wireless
LAN co
nnection.
Page 87
Wireless Network Projection from a Mobile Device (Miracast)
87
You can send image to your projector from mobile devices such as laptops,
tphones, and tablets using Miracast technology.
smar
If your device supports Miracast, you do not need to install any additional
soware. When using a Windows computer, make sure the necessary adapter
for the Miracast connection is available.
Note the following limitations when using Miracast features.
•
You cannot play an interlaced image.
•
You cannot play multi-channel audio over 3ch (channel 3).
•
You cannot project images with a resolution above 1920 × 1080 and a frame
rate above 30 fps.
•
You cannot play 3D video.
•
e projector cannot play copyright-protected content using a Miracast
connection.
•
Do not change the projector's Miracast settings during Miracast projection.
Doing so may cause the projector to disconnect and it may take a while to
re-connect.
s Network > Network Conguration > Wireless LAN > Miracast
•
Do not turn o the projector directly by the breaker during Miracast
projection.
Selecting Miracast Settings
You must select Miracast settings for your projector to project images from your
mo
bile device.
Press the [Menu] button, select the Ne
a
b
Select N
etwork Conguration and press [Enter].
twork menu, and press [Enter].
•
M
bile devices with Android installed or Windows 8.1 or later installed
o
mainly support Miracast.
Support for Miracast varies depending on the mobile device. See your
mobile device manual for details.
•
If the Web Control Password has not been set, a screen prompting
you to set a password is displayed when you save the network settings.
Follow the on-screen instructions to set the password.
Related Links
g
•
"Se
lecting Miracast Settings" p.87
•
"Connecting Using Miracast" p.88
elect Wireless LAN and press [Enter].
S
c
S
d
e
f
elect Simple AP and press [Enter].
S
elect On as th
Go back to the W
e Simple AP setting.
If no Passphrase has been set, a screen prompting to set the
assphrase appears. Follow the on-screen instructions to set the
P
Passphrase.
eless LAN screen, select Miracast and press [Enter].
ir
Page 88
Wireless Network Projection from a Mobile Device (Miracast)
88
Select On as the Miracast setting.
g
Change the following settings as needed.
h
•
A
cess Control lets you select whether or not to connect to another
c
mobile device during Miracast projection.
•
Secondary Connections lets you select the connection behavior for
devices attempting to connect during a Miracast connection.
•
Adjust Image Quality lets you adjust the Miracast speed/quality. Select
a small number to improve the quality and select large number to
increase the speed.
•
Miracast Info. lets you select whether or not to display Miracast
information.
When you have ni
i
on-screen instructions to save your settings and exit the menus.
If no Web Control Password has been set, a screen prompting
ou to set a password is displayed before you can save the settings.
y
Follow the on-screen instructions to set the password.
Press the [Home] button on the remote control. e s
j
when you see the Display Name on the Home screen.
hed selecting settings, select Complete and follow the
s
tings are complete
et
Connecting Using Miracast
If your mobile device such as a smartphone supports Miracast, you can connect
it t
o the projector wirelessly and project images. You can play audio through the
projector's speaker system by connecting using Miracast.
Select Miracast settings on your projector as necessary.
a
P
b
c
d
ress the [Wireless] button on the remote control to switch to the Miracast
so
urce.
You see the Miracast standby screen.
On your mobile device, use your Miracast function to search for the
pr
ojector.
You see a list of available devices.
Select the projector's Display Name from the list.
If y
ou see the screen asking if you allow the projection using Miracast on
the projector, check the device name displayed and select if you allow the
projection or not.
e projector displays the image from your mobile device.
Page 89
Wireless Network Projection from a Mobile Device (Miracast)
P
•
It m
ay take some time until the connection is established. While
connecting, do not disconnect the projector's power cord. Doing
so may cause your device to freeze or malfunction.
Depending on the mobile device, you may need to delete a device
when connecting. Follow the on-screen instructions on your
device.
•
To add a device to the block list, select Add to Block List on the
Miracast projection conrmation screen and then select No. is
registers the device name to the block list.
•
When a device registered to the block list attempts to connect
using Miracast, the standby screen remains displayed, and the
images are not projected. e block list cannot be displayed as a
list. Use the following method to delete the entire block list.
•
Select Delete Block List on the home screen.
•
Turn o the projector.
•
Update the network settings.
•
Press the [Enter] button on the standby screen, and then select
Yes on the screen displayed.
b
c
ress the [Wireless] button on the remote control to switch to the Miracast
urce.
so
You see the Miracast standby screen.
Display Action Center, and then select Connect.
You see a list of available devices.
89
Related Links
g
•
"Co
nnecting Using Miracast in Windows 10" p.89
•
"Connecting Using Miracast in Windows 11" p.90
Connecting Using Miracast in Windows 10
u can set up your computer for wireless projection and play audio through
Yo
the projector's speaker system by connecting using Miracast.
Select Miracast settings on your projector as necessary.
a
Select the projector's Display Name from the list.
d
Page 90
Wireless Network Projection from a Mobile Device (Miracast)
90
If you see the screen asking if you allow the projection using Miracast on
e
the projector, check the device name displayed and select if you allow the
projection or not.
e projector displays the image from your computer.
It may take some time until the connection is established. While
ecting, do not disconnect the projector's power cord. Doing so
conn
may cause your device to freeze or malfunction.
Connecting Using Miracast in Windows 11
Yo
u can set up your computer for wireless projection and play audio through
the projector's speaker system by connecting using Miracast.
Select the Mirac
a
Press the [Wireless] button on the remote control to switch to the Miracast
b
so
urce.
You see the network information screen.
ast settings on your projector as necessary.
If you see the screen asking if you allow the projection using Miracast on
f
t
he projector, check the device name displayed and select if you allow the
projection or not.
e projector displays the image from your computer.
It may take some time until the connection is established. While
ecting, do not disconnect the projector's power cord. Doing so
conn
may cause your device to freeze or malfunction.
Click the speaker icon on your computer's taskbar.
c
Click C
d
You see a list of available devices.
Select the projector's Projector Name from the list.
e
ast.
If Cast is not displayed or another message is displayed, see the
anual supplied with the computer.
m
Page 91
Using AirPlay
91
You can stream media such as videos, music, and photos to the projector using
ple devices that support AirPlay. You can also mirror the entire screen of
Ap
your Apple device.
is projector is compatible with HomeKit. When you register the projector
with HomeKit on your Apple device, you can control the projector using the
Apple Home app on your Apple device.
•
Wh
en connected to a network by wireless LAN and A/V Output is set
to Always On from A/V Settings in the Extended menu, you can make
AirPlay connections even if the projector is in standby mode (when the
power is o).
•
You need to connect to the internet to enable AirPlay. Make network
settings in the Network menu. If you have never connected to the
internet before, a screen is displayed indicating that you need to make
network settings when you try to connect using AirPlay.
•
You need to congure a DNS server to use AirPlay. Depending on
your network, set DHCP to On in IP Settings from the Wireless LAN
menu. If DHCP is set to O, or if you want to specify a DNS server
address, enter the IP address in DNS Server 1 or DNS Server 2.
s Network > Network Conguration > Wireless LAN
•
e maximum display resolution is 1920 × 1080.
•
You may not be able to use AirPlay to view copyright-protected
content.
•
e audio supports up to 2 channels with a maximum sampling
frequency of 44.1 kHz.
Settings for AirPlay
When using AirPlay, make sure your Apple device and the projector are using
th
e same network.
You can make AirPlay settings from the AirPlay and HomeKit settings screen.
•
If the date and time are not set on the projector, or if there is a
time discrepancy, the AirPlay connection may be disconnected while
projecting. Set the correct date and time in Date & Time from the
Extended menu.
s Extended > Operation > Date & Time
•
When using AirPlay, if there are no operations for about 10 minutes on
the standby screen, the screen may turn black to prevent burn-in.
Change the source to something other than AirPlay.
a
Press the [Menu] button, select the Ne
b
twork menu, and press [Enter].
Related Links
g
•
"Settings for AirPlay" p.91
•
"Streaming/Mirroring Media with an AirPlay Connection" p.93
c
Select A
e
irPlay and HomeKit in the Network menu and press [Enter].
AirPlay and HomeKit settings screen is displayed.
Page 92
Using AirPlay
•
Wh
HomeKit from the Network menu. If you want to change the
settings, stop playback on your Apple device. Display the AirPlay
and HomeKit settings screen from the following screen that is
displayed.
en the source is AirPlay, you cannot select AirPlay and
Set AirPlay to On.
d
Change the other settings as needed.
e
To r
egister with HomeKit, scan the projected QR code using your Apple
device.
Once registered with HomeKit, you can control the projector and change
the device name from the Home app on your Apple device.
92
•
Wh
en AirPlay is O, the AirPlay and HomeKit settings screen is
displayed when you set the source to AirPlay.
Page 93
Using AirPlay
93
When changing the device name in the Home app, only characters
th
at can be entered using the so keyboard are available. You
cannot use other characters.
Related Links
g
•
"Avai
lable Text Using the Displayed Keyboard" p.113
Streaming/Mirroring Media with an AirPlay Connection
When using an Apple device that supports AirPlay, you can stream media such
as vide
os, music, and photos to the projector. You can also mirror and display
the entire screen of your Apple device.
When using AirPlay, if there are no operations for about 10 minutes on
the standby screen, the screen may turn black to prevent burn-in.
On your Apple device, select the media you want to play using AirPlay
a
an
elect the AirPlay icon (
d s
ror, open the Control Center and select the screen mirroring icon
To mir
).
(
or ).
Select the projector's device name from the list displayed on your Apple
b
de
vice.
•
heck the projector's device name, stop media playback on
To c
your Apple device and press the [Wireless] button on the remote
control until the following screen is displayed. You can also check
it on the Home screen or LAN standby screen.
•
en AirPlay is o, the projector's device name is not displayed
Wh
in the list on your Apple device. Use one of the following
operations to display the AirPlay and HomeKit settings screen,
and then turn on AirPlay.
•
Press the [Wireless] button until the AirPlay and HomeKit
settings screen is displayed.
•
Select AirPlay and HomeKit in the Network menu and press
[Enter].
Page 94
Using AirPlay
If the projector prompts you for a 4-digit PIN code, enter it on your Apple
c
de
ice.
v
Media streaming or mirroring of your Apple device screen starts.
When streaming, you can play, pause, fast-forward, rewind, change
th
e volume, and mute using the projector's remote control.
94
To end the AirPlay connection, press [Esc].
d
e screen that was displayed before the connection started is projected.
•
u can also end the AirPlay connection by switching to a
Yo
dierent target device or by canceling mirroring on your Apple
device.
•
e AirPlay connection ends if you switch from the screen on
which AirPlay is playing to another display, such as displaying
the projector's home screen.
Page 95
Secure HTTP
95
You can use the HTTPS protocol to increase security between the projector and
b browser communicating with it. To do this, you create a server certicate,
a We
install it on the projector, and turn on the Secure HTTP setting in the projector
menus to verify the reliability of the Web browser.
s Network > Network Conguration > Others > Secure HTTP
Even if you do not install a server certicate, the projector automatically
creates a self-signed certicate and allows communication. However, because
the self-signed certicate cannot verify reliability from a Web browser, you see a
warning about the server's reliability when you access the projector from a Web
browser. is warning does not prevent communication.
Related Links
g
•
"Importing a Web Server Certicate Using the Menus" p.95
Importing a Web Server Certicate Using the Menus
You can create your Web server certicate, and import it using the projector
menus and a USB ash drive.
You can also register the digital cert
However, be sure to register just once or the certicate may not install
correctly.
icates from your Web browser.
S
d
e
f
g
h
elect the O
Set the Secure HTTP setting to On.
Select Web Server Cert. and press [Enter].
S
elect Register and press [Enter].
F
ollow the on-screen instructions to connect a USB storage device to the
pr
ojector's USB-A port.
thers menu and press [Enter].
Make sure your digital cer
a
registration and directly placed on the USB storage device.
Press the [Menu] button, select the Ne
b
Select Network Conguration and press [Enter].
c
icate le is compatible with projector
t
twork menu, and press [Enter].
Press [Enter] to display the cert
i
Select the cert
j
A message is displayed prompting you to enter the password for the
certicate.
Enter a password and press [Enter].
k
e cer
icate to import using the displayed list.
icate is imported and a completion message appears.
t
icate list.
Page 96
Secure HTTP
Related Links
g
•
pported Web Server Certicates" p.96
"Su
Supported Web Server Certicates
o
u can register these types of digital certicates.
Y
Web Server Certicate (Secure HTTP)
Specication Description
Format PKCS#12
Extension PFX, P12
Encryption RSA
Hashes MD5/SHA-1/SHA-256/SHA-384/SHA-512
Key length 512/1024/2048/4096 bit
Common name Network host name
96
Organization Optional
Password * Up to 64 alphanumeric characters; required
* You can set a password using up to 64 alphanumeric characters. However, you
ed to use your Web browser to enter more than 32 characters.
ne
Page 97
Monitoring and Controlling the Projector
llow the instructions in these sections to monitor and control the projector over a network.
Fo
Related Links
g
•
"Epson Projector Management" p.98
•
"Controlling a Networked Projector Using a Web Browser" p.99
•
"Registering Digital Certicates from a Web Browser" p.103
•
"Setting Up Projector Network E-Mail Alerts" p.104
•
"Setting Up Monitoring Using SNMP" p.106
•
"Setting Projector Event Schedules" p.107
•
"Web API" p.110
Page 98
Epson Projector Management
98
Epson Projector Management so
ware (Windows only) lets you monitor
and control your projector through the network. See the Epson Projector
Management Operation Guide for instructions.
You can download Epson Projector Management from the following Web site.
epson.sn/
•
e aut
hentication method when registering projectors varies
depending on the version of the Epson Projector Management soware
you are using.
•
Ver.5.30 or earlier: Monitor Password
•
Ver.5.40 or later: Web Control Password
For the best results, we recommend that you use the latest version of
the Epson Projector Management.
s Network > Network Conguration > Others
•
To monitor and control the projector using Epson Projector
Management, set A/V Output to Always On from A/V Settings in
the Extended menu.
If A/V Output is set to While Projecting, you cannot monitor and
control the projector using Epson Projector Management when the
projector is in standby mode.
Page 99
Controlling a Networked Projector Using a Web Browser
Once you have connected your projector to your network, you can select
ojector settings and control projection using a compatible Web browser. is
pr
lets you access the projector remotely.
•
Mak
e sure the computer and projector are connected to the network.
When projecting images using a wireless LAN, connect using a wireless
LAN access point.
•
You can use the following Web browsers.
•
Microso Edge (Windows)
•
Safari (Mac, iOS)
•
Chrome (Android)
•
While using the Web browser, do not connect using a proxy server. You
cannot select all of the projector menu settings or control all projector
functions using a Web browser.
•
When A/V Output is set to Always On from A/V Settings in the
Extended menu, you can use a Web browser to select settings and
control projection even if the projector is in standby mode (when the
power is o).
s Extended > A/V Settings > A/V Output
Make sure the projector is turned on.
a
A
B
C
D
Controls the projector remotely.
Displays a test pattern.
Sets detailed projector settings.
Operates the projector's menu settings with your ng
99
er or mouse.
Make sure your computer or device is connected to the same network as
b
t
e projector.
h
Start your Web browser on the computer or device.
c
Go to the Epson Web Control screen by entering the projector's IP address
d
in
o the browser's address box.
t
You see the Epson Web Control screen.
Page 100
Controlling a Networked Projector Using a Web Browser
100
Select the option corresponding to the projector function you want to
e
control.
You may need to log in to access some of the options on the Eps
Web Control screen. Set the following passwords rst.
•
To access the Basic Control option, you need to log in using
EPSONREMOTE as the user name and your Remote Password.
(No password is set by default.)
Set Basic Control to On in the projector's Network menu, and
then set the password.
s Network > Network Conguration > Others > Basic
Control
•
To access other options and save settings, you need to log in
using EPSONWEB as the user name and your Web Control
Password. (No password is set by default.)
Set the password in the projector's Network menu.
s Network > Network Conguration > Basic > Web Control
Password
Related Links
g
•
"W
b Control Options" p.100
e
•
"Projector Setup Settings - ECO Menu" p.131
•
"Network Menu - Basic Menu" p.123
on
Web Control Options
Basic Control
Returns to the Epson Web Control screen.
A
Turns the projector on or o.
B
S
elects the input source.
C
Turns the video and audio on or o temporarily.
D
Pauses or resumes images.
E
Displays the QR code.
F
Adjusts the speaker volume.
G
Searches for sources.
H
Loading...
