Epson CX37DNF User Manual

Reference Guide

NPD4497-00 EN

Epson AcuLaser CX37 Series Reference Guide

Copyright Notice

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation and its affiliates shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

EPSON is a registered trademark and Epson AcuLaser is a trademark or a registered trademark of Seiko Epson Corporation.

Software License Agreement

This package contains the following materials provided by Seiko Epson Corporation (Epson): software included as part of the printing system, the digitally-encoded machine-readable outline data encoded in the special format and in the encrypted form (“Font Programs”), other software which runs on a computer system for use in conjunction with the Printing Software (“Host Software”), and related explanatory written materials (“Documentation”). The term “Software” shall be used to describe Printing Software, Font Programs and/or Host Software and also include any upgrades, modified versions, additions, and copies of the Software. The Software is being licensed to you under the terms of this Agreement. Epson grants to you a non-exclusive sublicense to use the Software and Documentation, provided that you agree to the following:

1. You may use the Printing Software and accompanying Font Programs for imaging to the licensed output device(s), solely for your own internal business purposes.

2. In addition to the license for Font Programs set forth in Section 1 (“Printing Software”) above, you may use Roman Font Programs to reproduce weights, styles, and versions of letters, numerals, characters and symbols (“Typefaces”) on the display or monitor for your own internal business purposes.

Epson AcuLaser CX37 Series Reference Guide

3. You may make one backup copy of the Host Software, provided your backup copy is not installed or used on any computer. Notwithstanding the above restrictions, you may install the Host Software on any number of computers solely for use with one or more printing systems running the Printing Software.

4. You may assign its rights under this Agreement to an assignee of all of Licensee’s right and interest to such Software and Documentation (“Assignee”) provided you transfer to Assignee all copies of such Software and Documentation Assignee agrees to be bound by all of the terms and conditions of this Agreement.

5. You agree not to modify, adapt or translate the Software and Documentation.

6. You agree that you will not attempt to alter, disassemble, decrypt, reverse engineer or decompile the Software.

7. Title to and ownership of the Software and Documentation and any reproductions thereof shall remain with Epson.

8. Trademarks shall be used in accordance with accepted trademark practice, including identification of the trademark owner’s name. Trademarks can only be used to identify printed output produced by the Software. Such use of any trademark does not give you any rights of ownership in that trademark.

9. You may not rent, lease, sublicense, lend or transfer versions or copies of the Software that the Licensee does not use, or Software contained on any unused media, except as part of the permanent transfer of all Software and Documentation as described above.

10. In no event will Epson or its licensor be liable to you for any consequential, incidental INDIRECT, PUNITIVE or special damages, including any lost profits or lost saving, even if Epson has been advised of the possibility of such damages, or for any claim by any third party. Epson or its licensor disclaims all warranties with regard to the software, express or implied, including, without limitation implied warranties of merchantability, fitness for a particular purpose, title and non-infringement of third party rights. Some states or jurisdictions do not allow the exclusion or limitation of incidental, consequential or special damages, so the above limitations may not apply to you.

11. Notice to Government End Users: The Software is a “commercial item,” as that term is defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consistent with 48 C.F.R.

12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all U.S. Government End Users acquire the Software with only those rights set forth herein.

Epson AcuLaser CX37 Series Reference Guide

12. You agree that you will not export the Software in any form in violation of any applicable laws and regulations regarding export control of any countries.

About Adobe Color Profile

ADOBE SYSTEMS INCORPORATED COLOR PROFILE LICENSE AGREEMENT

NOTICE TO USER: PLEASE READ THIS CONTRACT CAREFULLY. BY USING ALL OR ANY PORTION OF THE SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF THIS SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE WITH THE TERMS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE.

1. DEFINITIONS In this Agreement, “Adobe” means Adobe Systems Incorporated, a Delaware corporation, located at 345 Park Avenue, San Jose, California 95110. “Software” means the software and related items with which this Agreement is provided.

2. LICENSE Subject to the terms of this Agreement, Adobe hereby grants you the worldwide, non-exclusive, nontransferable, royalty-free license to use, reproduce and publicly display the Software. Adobe also grants you the rights to distribute the Software only (a) as embedded within digital image files and (b) on a standalone basis. No other distribution of the Software is allowed; including, without limitation, distribution of the Software when incorporated into or bundled with any application software. All individual profiles must be referenced by their ICC Profile description string. You may not modify the Software. Adobe is under no obligation to provide any support under this Agreement, including upgrades or future versions of the Software or other items. No title to the intellectual property in the Software is transferred to you under the terms of this Agreement. You do not acquire any rights to the Software except as expressly set forth in this Agreement.

Epson AcuLaser CX37 Series Reference Guide

3. DISTRIBUTION If you choose to distribute the Software, you do so with the understanding that you agree to defend, indemnify and hold harmless Adobe against any losses, damages or costs arising from any claims, lawsuits or other legal actions arising out of such distribution, including without limitation, your failure to comply with this Section 3. If you distribute the Software on a standalone basis, you will do so under the terms of this Agreement or your own license agreement which (a) complies with the terms and conditions of this Agreement; (b) effectively disclaims all warranties and conditions, express or implied, on behalf of Adobe; (c) effectively excludes all liability for damages on behalf of Adobe; (d) states that any provisions that differ from this Agreement are offered by you alone and not Adobe and (e) states that the Software is available from you or Adobe and informs licensees how to obtain it in a reasonable manner on or through a medium customarily used for software exchange. Any distributed Software will include the Adobe copyright notices as included in the Software provided to you by Adobe.

4. DISCLAIMER OF WARRANTY Adobe licenses the Software to you on an “AS IS” basis. Adobe makes no representation as to the adequacy of the Software for any particular purpose or to produce any particular result. Adobe shall not be liable for loss or damage arising out of this Agreement or from the distribution or use of the Software or any other materials. ADOBE AND ITS SUPPLIERS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE, EXCEPT FOR ANY WARRANTY, CONDITION, REPRESENTATION OR TERM TO THE EXTENT TO WHICH THE SAME CANNOT OR MAY NOT BE EXCLUDED OR LIMITED BY LAW APPLICABLE TO YOU IN YOUR JURISDICTION, ADOBE AND ITS SUPPLIERS MAKE NO WARRANTIES, CONDITIONS, REPRESENTATIONS OR TERMS, EXPRESS OR IMPLIED, WHETHER BY STATUTE, COMMON LAW, CUSTOM, USAGE OR OTHERWISE AS TO ANY OTHER MATTERS, INCLUDING BUT NOT LIMITED TO NON-INFRINGEMENT OF THIRD PARTY RIGHTS, INTEGRATION, SATISFACTORY QUALITY OR FITNESS FOR ANY PARTICULAR PURPOSE. YOU MAY HAVE ADDITIONAL RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION. The provisions of Sections 4, 5 and 6 shall survive the termination of this Agreement, howsoever caused, but this shall not imply or create any continued right to use the Software after termination of this Agreement.

Epson AcuLaser CX37 Series Reference Guide

5. LIMITATION OF LIABILITY IN NO EVENT WILL ADOBE OR ITS SUPPLIERS BE LIABLE TO YOU FOR ANY DAMAGES, CLAIMS OR COSTS WHATSOEVER OR ANY CONSEQUENTIAL, INDIRECT, INCIDENTAL DAMAGES, OR ANY LOST PROFITS OR LOST SAVINGS, EVEN IF AN ADOBE REPRESENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSS, DAMAGES, CLAIMS OR COSTS OR FOR ANY CLAIM BY ANY THIRD PARTY. THE FOREGOING LIMITATIONS AND EXCLUSIONS APPLY TO THE EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION. ADOBE’S AGGREGATE LIABILITY AND THAT OF ITS SUPPLIERS UNDER OR IN CONNECTION WITH THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT PAID FOR THE SOFTWARE. Nothing contained in this Agreement limits Adobe’s liability to you in the event of death or personal injury resulting from Adobe’s negligence or for the tort of deceit (fraud). Adobe is acting on behalf of its suppliers for the purpose of disclaiming, excluding and/or limiting obligations, warranties and liability as provided in this Agreement, but in no other respects and for no other purpose.

6. TRADEMARKS Adobe and the Adobe logo are the registered trademarks or trademarks of Adobe in the United States and other countries. With the exception of referential use, you will not use such trademarks or any other Adobe trademark or logo without separate prior written permission granted by Adobe.

7. TERM This Agreement is effective until terminated. Adobe has the right to terminate this Agreement immediately if you fail to comply with any term hereof. Upon any such termination, you must return to Adobe all full and partial copies of the Software in your possession or control.

8. GOVERNMENT REGULATIONS If any part of the Software is identified as an export controlled item under the United States Export Administration Act or any other export law, restriction or regulation (the “Export Laws”), you represent and warrant that you are not a citizen, or otherwise located within, an embargoed nation (including without limitation Iran, Iraq, Syria, Sudan, Libya, Cuba, North Korea, and Serbia) and that you are not otherwise prohibited under the Export Laws from receiving the Software. All rights to use the Software are granted on condition that such rights are forfeited if you fail to comply with the terms of this Agreement.

9. GOVERNING LAW This Agreement will be governed by and construed in accordance with the substantive laws in force in the State of California as such laws are applied to agreements entered into and to be performed entirely within California between California residents. This Agreement will not be governed by the conflict of law rules of any jurisdiction or the United Nations Convention on Contracts for the International Sale of Goods, the application of which is expressly excluded. All disputes arising out of, under or related to this Agreement will be brought exclusively in the state Santa Clara County, California, USA.

Epson AcuLaser CX37 Series Reference Guide

10. GENERAL You may not assign your rights or obligations granted under this Agreement without the prior written consent of Adobe. None of the provisions of this Agreement shall be deemed to have been waived by any act or acquiescence on the part of Adobe, its agents, or employees, but only by an instrument in writing signed by an authorized signatory of Adobe. When conflicting language exists between this Agreement and any other agreement included in the Software, the terms of such included agreement shall apply. If either you or Adobe employs attorneys to enforce any rights arising out of or relating to this Agreement, the prevailing party shall be entitled to recover reasonable attorneys’ fees. You acknowledge that you have read this Agreement, understand it, and that it is the complete and exclusive statement of your agreement with Adobe which supersedes any prior agreement, oral or written, between Adobe and you with respect to the licensing to you of the Software. No variation of the terms of this Agreement will be enforceable against Adobe unless Adobe gives its express consent, in writing, signed by an authorized signatory of Adobe.

ICC Profile for TOYO INK Standard Color on Coated paper (TOYO Offset Coated 2.1)

This ICC Profile (TOYO Offset Coated 2.1) characterizes Japanese offset press on Coated paper and is fully compatible with ICC profile format.

About “TOYO INK Standard Color on Coated paper”

This is the standard for color reproduction of sheet-fed offset press on Coated paper made by TOYO INK MFG.CO., LTD. (“TOYO INK”). This standard is made from printing test with using TOYO INK’s sheet-fed offset printing inks and TOYO INK’s own printing conditions. “TOYO INK Standard Color on Coated paper” is compatible with “JAPAN COLOR”.

Agreement

1. The reproduction of images on a printer or a monitor using this ICC Profile do not completely match the TOYO INK Standard Color on Coated paper.

2. Any and all copyrights of this ICC Profile shall remain in TOYO INK; therefore you shall not transfer, provide, rent, distribute, disclose, or grant any rights in this ICC Profile to any third party without the prior written consent of TOYO INK.

3. In no event will TOYO INK its directors, officers, employees or agents be liable to you for any consequential or incidental, either direct or indirect, damages (including damages for loss of business profits, business interruption, loss of business information, and the like) arising out of the use or inability to use this ICC Profile.

Epson AcuLaser CX37 Series Reference Guide

4. TOYO INK shall not be responsible for answering any question related to this ICC Profile.

5. All company names and product names used in this document is the trademarks or registered trademarks of their respective holder.

This ICC Profile made by GretagMacbeth ProfileMaker and granted TOYO INK certain license to distribute by GretagMacbeth AG.

TOYO Offset Coated 2.1 © TOYO INK MFG. CO., LTD. 2004

DIC STANDARD COLOR PROFILE LICENSE AGREEMENT

IMPORTANT: PLEASE READ THIS STANDARD COLOR PROFILE LICENSE AGREEMENT (“LICENSE AGREEMENT”) CAREFULLY BEFORE USING THE DIC STANDARD COLOR PROFILE, INCLUDING THE DIC STANDARD SFC_AM2.0, DIC STANDARD SFM_AM2.0, DIC STANDARD SFU_AM2.0, DIC STANDARD SFC_FM2.0, DIC WAKIMIZU SFC_AM2.0, DIC WAKIMIZU SFC_FM2.0, DIC ABILIO SFC_AM1.0, DIC HY-BRYTE SFC_AM1.0, DIC STANDARD WEBC_AM2.1, DIC STANDARD WEBC_FM2.1, DIC NEWSCOLOR_AM1.0, DIC NEWSCOLOR_FM1.0, PROVIDED BY DIC HEREWITH, AND ANY CORRESPONDIMG ONLINE OR ELECTRONC DOCUMENTATION AND ALL UPDATES OR UPGRADES OF THE ABOVE THAT ARE PROVIDED TO YOU (COLLECTIVELY, THE “PROFILE”).

THIS LICENSE AGREEMENT IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR, IF ACQUIRED BY OR FOR AN ENTITY, AN ENTITY) AND DIC CORPORATION, A JAPANESE COMPANY (“DIC”). THIS LICENSE AGREEMENT PROVIDES A LICENSE TO USE THE PROFILE AND CONTAINS WARRANTY INFORMATION AND LIABILITY DISCLAIMERS. IF YOU DO NOT AGREE TO BE BOUND BY ALL OF THESE TERMS, YOU MAY NOT USE THE PROFILE.

1. License Grant DIC grants you a gratis non-exclusive and non-transferable license to use the Profile and to allow your employees and authorized agents, if any, to use the Profile, solely in connection with their work for you, subject to all of the limitations and restrictions in this License Agreement.

2. Ownership The foregoing license gives you limited license to use the Profile. You will own the rights in the media containing the recorded Profile, but DIC retains all right, title and interest, including all copyright and intellectual property rights, in and to, the Profile and all copies thereof. All rights not specifically granted in this License Agreement, including all copyrights, are reserved by DIC.

Epson AcuLaser CX37 Series Reference Guide

3. Term a. This License Agreement is effective until terminated. b. You may terminate this License Agreement by notifying DIC in writing of your intention to terminate this License Agreement and by destroying, all copies of the Profile in your possession or control. c. DIC may terminate this License Agreement without prior notice to you if you fail to comply with any of the terms and conditions of this License Agreement (either directly or through your employees or agents), retroactive to the time of such failure to comply. In such event, you must immediately stop using the Profile and destroy all copies of the Profile in your possession or control. d. All provisions in this License Agreement relating to warranty disclaimers (Section 5) and the limitation of liability (Section 6) shall survive any termination of this License Agreement.

4. License Method and Restrictions a. You may install and use the Profile on a single desktop computer; provided, however, that, notwithstanding anything contrary contained herein, you may not use the Profile on any network system or share, install or use the Profile concurrently on different computers, or electronically transfer the Profile from one computer to another or over a network. b. You may not make or distribute copies, fix, alter, merge, modify, adapt, sublicense, transfer, sell, rent, lease, gift or distribute all or a portion of the Profile, or modify the Profile or create derivative works based upon the Profile. c. You acknowledge that the Profile is not intended for any usage which may cause death or physical injury or environmental damage and agree not to use the Profile for such usage. d. You shall not use the Profile to develop any software or other technology having the same primary function as the Profile, including but not limited to using the Profile in any development or test procedure that seeks to develop like software or other technology, or to determine if such software or other technology performs in a similar manner as the Profile. e. DIC and other trademarks contained in the Profile are trademarks or registered trademarks of DIC in Japan and/or other countries. You may not remove or alter any trademark, trade names, product names, logo, copyright or other proprietary notices, legends, symbols or labels in the Profile. This License Agreement does not authorize you to use DIC’s or its licensors’ names or any of their respective trademarks.

Epson AcuLaser CX37 Series Reference Guide

5. WARRANTY DISCLAIMER a. THE PROFILE IS PROVIDED TO YOU FREE OF CHARGE, AND ON AN “AS-IS” BASIS, IN ACCORDANCE WITH THE TERMS AND COONDITIONS OF THIS LICENSE AGREEMENT. DIC PROVIDES NO TECHNICAL SUPPORT, WARRANTIES OR REMEDIES FOR THE PROFILE. b. DIC DISCLAIMS ALL WARRANTIES AND REPRESENTATIONS, WHETHER EXPRESS, IMPLIED, OR OTHERWISE, INCLUDING BUT NOT LIMITED TO, THE WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT, TITLE AND QUIET ENJOYMENT. YOU SHALL ASSUME AND BE FULLY LIABLE AND RESPONSIBLE FOR ALL RISKS IN CONNECTION WITH YOUR USE OF THE PROFILE. DIC DOES NOT WARRANT THAT THE PROFILE IS FREE OF DEFECTS OR FLAWS OR WILL OPERATE WITHOUT INTERRUPTION, AND IS NOT RESPONSIBLE FORCORRECTING OR REPAIRING ANY DEFECTS OR FLAWS, FOR FEE OR GRATIS. NO RIGHTS OR REMEDIES WILL BE CONFERRED ON YOU UNLESS EXPRESSLY GRANTED HEREIN.

6. LIMITATION OF LIABILITY DIC SHALL NOT BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, COVER OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR THE INABILITY TO USE EQUIPMENT OR ACCESS DATA, LOSS OF BUSINESS, LOSS OF PROFITS, BUSINESS INTERRUPTION OR THE LIKE), ARISING OUT OF THE USE OF, OR INABILITY TO USE, THE PROFILE AND BASED ON ANY THEORY OF LIABILITY INCLUDING BREACH OF CONTRACT, BREACH OF WARRANTY, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY OR OTHERWISE, EVEN IF DIC OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE FOREGOING LIMITATIONS ON LIABILITY SHALL APPLY TO ALL ASPECTS OF THIS LICENSE AGREEMENT.

7. General a. This License Agreement shall be governed and construed in accordance with the laws of Japan, without giving effect to principles of conflict of laws. If any provision of this License Agreement shall be held by a court of competent jurisdiction to be contrary to law, that provision will be enforced to the maximum extent permissible, and the remaining provisions of this License Agreement will remain in full force and effect. You hereby consent to the exclusive jurisdiction and venue of Tokyo District Court to resolve any disputes arising under this License Agreement. b. This License Agreement contains the complete agreement between the parties with respect to the subject matter hereof, and supersedes all prior or contemporaneous agreements or understandings, whether oral or written. You agree that any varying or additional terms contained in any written notification or document issued by you in relation to the Profile licensed hereunder shall be of no effect. c. The failure or delay of DIC to exercise any of its rights under this License Agreement or upon any breach of this License Agreement shall not be deemed a waiver of those rights or of the breach.

Epson AcuLaser CX37 Series Reference Guide

OpenSSL Statement

LICENSE ISSUES

The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org.

OpenSSL License

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgment:

“This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)”

4. The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used to endorse or promote products derived from this software without prior written permission. For written permission, please contact openssl-core@openssl.org.

5. Products derived from this software may not be called “OpenSSL” nor may “OpenSSL” appear in their names without prior written permission of the OpenSSL Project.

6. Redistributions of any form whatsoever must retain the following acknowledgment:

“This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)”

Epson AcuLaser CX37 Series Reference Guide

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com).

Original SSLeay License

This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL.

This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).

Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer.

Epson AcuLaser CX37 Series Reference Guide

3. All advertising materials mentioning features or use of this software must display the following acknowledgement:

“This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)” The word “cryptographic” can be left out if the rouines from the library being used are not cryptographic related :-).

4. If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement:

“This product includes software written by Tim Hudson (tjh@cryptsoft.com)”

THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.] THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Epson AcuLaser CX37 Series Reference Guide

NetSNMP License

Part 1: CMU/UCD copyright notice: (BSD like)

Copyright 1989, 1991, 1992 by Carnegie Mellon University Derivative Work - 1996, 1998-2000 Copyright 1996, 1998-2000 The Regents of the University of California All Rights Reserved Permission to use, copy, modify and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of CMU and The Regents of the University of California not be used in advertising or publicity pertaining to distribution of the software without specific written permission.

CMU AND THE REGENTS OF THE UNIVERSITY OF CALIFORNIA DISCLAIM ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL CMU OR THE REGENTS OF THE UNIVERSITY OF CALIFORNIA BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM THE LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

Part 2: Networks Associates Technology, Inc copyright notice (BSD)

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

❏ Redistributions of source code must retain the above copyright notice, this list of conditions and

the following disclaimer.

❏ Redistributions in binary form must reproduce the above copyright notice, this list of conditions

and the following disclaimer in the documentation and/or other materials provided with the distribution.

❏ Neither the name of the Networks Associates Technology, Inc nor the names of its contributors

may be used to endorse or promote products derived from this software without specific prior written permission.

Epson AcuLaser CX37 Series Reference Guide

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Part 3: Cambridge Broadband Ltd. copyright notice (BSD)

Portions of this code are copyright © 2001-2003, Cambridge Broadband Ltd. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

❏ Redistributions of source code must retain the above copyright notice, this list of conditions and

the following disclaimer.

❏ Redistributions in binary form must reproduce the above copyright notice, this list of conditions

and the following disclaimer in the documentation and/or other materials provided with the distribution.

❏ The name of Cambridge Broadband Ltd. may not be used to endorse or promote products derived

from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDER “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Epson AcuLaser CX37 Series Reference Guide

Part 4: Sun Microsystems, Inc. copyright notice (BSD)

Copyright © 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. All rights reserved. Use is subject to license terms below. This distribution may include materials developed by third parties. Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

❏ Redistributions of source code must retain the above copyright notice, this list of conditions and

the following disclaimer.

❏ Redistributions in binary form must reproduce the above copyright notice, this list of conditions

and the following disclaimer in the documentation and/or other materials provided with the distribution.

❏ Neither the name of the Sun Microsystems, Inc. nor the names of its contributors may be used to

endorse or promote products derived from this software without specific prior written permission.

Part 5: Sparta, Inc copyright notice (BSD)

❏ Redistributions of source code must retain the above copyright notice, this list of conditions and

the following disclaimer.

Epson AcuLaser CX37 Series Reference Guide

❏ Redistributions in binary form must reproduce the above copyright notice, this list of conditions

and the following disclaimer in the documentation and/or other materials provided with the distribution.

❏ Neither the name of Sparta, Inc nor the names of its contributors may be used to endorse or

promote products derived from this software without specific prior written permission.

Part 6: Cisco/BUPTNIC copyright notice (BSD)

Copyright © 2004, Cisco, Inc and Information Network Center of Beijing University of Posts and Telecommunications. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

❏ Redistributions of source code must retain the above copyright notice, this list of conditions and

the following disclaimer.

❏ Redistributions in binary form must reproduce the above copyright notice, this list of conditions

and the following disclaimer in the documentation and/or other materials provided with the distribution.

❏ Neither the name of Cisco, Inc, Beijing University of Posts and Telecommunications, nor the

names of their contributors may be used to endorse or promote products derived from this software without specific prior written permission.

Epson AcuLaser CX37 Series Reference Guide

Kerberos

Copyright © 1985-2007 by the Massachusetts Institute of Technology. All rights reserved. Export of this software from the United States of America may require a specific license from the United States Government. It is the responsibility of any person or organization contemplating export to obtain such a license before exporting. W IT HI N T HA T C ON ST RA IN T, pe rm is si on to us e, co py , modify, and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of M.I.T. not be used in advertising or publicity pertaining to distribution of the software without specific, written prior permission. Furthermore if you modify this software you must label your software as modified software and not distribute it in such a fashion that it might be confused with the original MIT software. M.I.T. makes no representations about the suitability of this software for any purpose. It is provided “as is” without express or implied warranty. THIS SOFTWARE IS PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE. Individual source code files are copyright MIT, Cygnus Support, Novell, OpenVision Technologies, Oracle, Red Hat, Sun Microsystems, FundsXpress, and others. Project Athena, Athena, Athena MUSE, Discuss, Hesiod, Kerberos, Moira, and Zephyr are trademarks of the Massachusetts Institute of Technology (MIT). No commercial use of these trademarks may be made without prior written permission of MIT. “Commercial use” means use of a name in a product or other for-profit manner. It does NOT prevent a commercial firm from referring to the MIT trademarks in order to convey information (although in doing so, recognition of their trademark status should be given).

Epson AcuLaser CX37 Series Reference Guide

Portions of src/lib/crypto have the following copyright: Copyright © 1998 by the FundsXpress, INC. All rights reserved. Export of this software from the United States of America may require a specific license from the United States Government. It is the responsibility of any person or organization contemplating export to obtain such a license before exporting.

W IT HI N T HA T C ON ST RA IN T, pe rm is si on to us e, co py , modify, and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of FundsXpress. not be used in advertising or publicity pertaining to distribution of the software without specific, written prior permission. FundsXpress makes no representations about the suitability of this software for any purpose. It is provided “as is” without express or implied warranty. THIS SOFTWARE IS PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE.

The implementation of the Yarrow pseudo-random number generator in src/lib/crypto/yarrow has the following copyright: Copyright 2000 by Zero-Knowledge Systems, Inc. Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose is hereby granted without fee, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of Zero-Knowledge Systems, Inc. not be used in advertising or publicity pertaining to distribution of the software without specific, written prior permission. Zero-Knowledge Systems, Inc. makes no representations about the suitability of this software for any purpose. It is provided “as is” without express or implied warranty. ZERO-KNOWLEDGE SYSTEMS, INC. DISCLAIMS ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS, IN NO EVENT SHALL ZERO-KNOWLEDGE SYSTEMS, INC. BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTUOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

LICENSE TERMS

Epson AcuLaser CX37 Series Reference Guide

The free distribution and use of this software in both source and binary form is allowed (with or without changes) provided that:

1. distributions of this source code include the above copyright notice, this list of conditions and the following disclaimer;

2. distributions in binary form include the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other associated materials;

3. the copyright holder’s name is not used to endorse products built using this software without specific written permission.

DISCLAIMER

This software is provided “as is” with no explcit or implied warranties in respect of any properties, including, but not limited to, correctness and fitness for purpose.

Portions contributed by Red Hat, including the pre-authentication plug-ins framework, contain the following copyright: Copyright © 2006 Red Hat, Inc. Portions copyright © 2006 Massachusetts Institute of Technology All Rights Reserved.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of Red Hat, Inc., nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Epson AcuLaser CX37 Series Reference Guide

Portions funded by Sandia National Laboratory and developed by the University of Michigan’s Center for Information Technology Integration, including the PKINIT implementation, are subject to the following license: COPYRIGHT © 2006-2007 THE REGENTS OF THE UNIVERSITY OF MICHIGAN ALL RIGHTS RESERVED Permission is granted to use, copy, create derivative works and redistribute this software and such derivative works for any purpose, so lo ng as the na me of Th e U niv er si ty of Mi chig an is n ot us ed in an y advertising or publicity pertaining to the use of distribution of this software without specific, written prior authorization. If the above copyright notice or any other identification of the University of Michigan is included in any copy of any portion of this software, then the disclaimer below must also be included. THIS SOFTWARE IS PROVIDED AS IS, WITHOUT REPRESENTATION FROM THE UNIVERSITY OF MICHIGAN AS TO ITS FITNESS FOR ANY PURPOSE, AND WITHOUT WARRANTY BY THE UNIVERSITY OF MICHIGAN OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE REGENTS OF THE UNIVERSITY OF MICHIGAN SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WITH RESPECT TO ANY CLAIM ARISING OUT OF OR IN CONNECTION WITH THE USE OF THE SOFTWARE, EVEN IF IT HAS BEEN OR IS HEREAFTER ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

The pkcs11.h file included in the PKINIT code has the following license: Copyright 2006 g10 Code GmbH Copyright 2006 Andreas Jellinghaus This file is free software; as a special exception the author gives unlimited permission to copy and/or distribute it, with or without modifications, as long as this notice is preserved.

This file is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY, to the extent permitted by law; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

WPA Supplicant

Copyright © 2003-2005, Jouni Malinen <jkmaline@cc.hut.fi> and contributors All Rights Reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

Epson AcuLaser CX37 Series Reference Guide

3. Neither the name(s) of the above-listed copyright holder(s) nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Epson AcuLaser CX37 Series Reference Guide

Software License Agreement.............................................................. 2

About Adobe Color Profile............................................................... 4

ICC Profile for TOYO INK Standard Color on Coated paper (TOYO Offset Coated 2.1)............ 7

DIC STANDARD COLOR PROFILE LICENSE AGREEMENT................................. 8

OpenSSL Statement..................................................................... 11

LICENSE ISSUES.................................................................. 11

Original SSLeay License............................................................. 12

NetSNMP License...................................................................... 14

Part 1: CMU/UCD copyright notice: (BSD like)......................................... 14

Part 2: Networks Associates Technology, Inc copyright notice (BSD)....................... 14

Part 3: Cambridge Broadband Ltd. copyright notice (BSD)................................ 15

Part 4: Sun Microsystems, Inc. copyright notice (BSD)................................... 16

Part 5: Sparta, Inc copyright notice (BSD).............................................. 16

Part 6: Cisco/BUPTNIC copyright notice (BSD)......................................... 17

Kerberos.......................................................................... 18

WPA Supplicant................................................................... 21

Chapter 1 Operation on Linux

System Requirements................................................................... 27

Installing PPD File From the Command Line............................................... 27

Adding the Printer Using Printer configuration............................................. 28

Adding the Printer on the CUPS Administration Web page................................... 29

Specifying Printer Driver Settings......................................................... 30

Displaying the Settings Page......................................................... 30

Printer Driver Settings.............................................................. 31

Printing a Document................................................................... 34

Example Using OpenOffice.......................................................... 34

Checking Print Jobs.................................................................... 34

Troubleshooting....................................................................... 35

Chapter 2 Operation on NetWare

Printing With NetWare................................................................. 36

Contents 23

Epson AcuLaser CX37 Series Reference Guide

Network Printing in a NetWare Environment........................................... 36

For Remote Printer Mode With NetWare 4.x Bindery Emulation. ......................... 36

For Print Server Mode With NetWare 4.x Bindery Emulation............................. 37

For NetWare 4.x Remote Printer Mode (NDS).......................................... 38

For NetWare 4.x/5.x/6 Print Server Mode (NDS)........................................ 39

For NetWare 5.x/6 Novell Distributed Print Service (NDPS).............................. 40

Setting Up a Client (Windows) Settings When Using the NetWare Server................... 41

Chapter 3 Using Local Setup Program (for Epson AcuLaser CX37DNF only)

About Local Setup Program (LSP)......................................................... 42

LSP Operating Environment............................................................. 42

Installing LSP..................................................................... 43

Starting Up LSP.................................................................... 43

Main LSP Window..................................................................... 44

Connecting to the Machine.......................................................... 44

Downloading Information from the Machine........................................... 45

Uploading Information to the Machine................................................ 45

Dial Import/Dial Export. . ........................................................... 45

Settings for dial destination.............................................................. 45

Programming a Speed Dial Number................................................... 45

Adding a Speed Dial Number (Fax/E-mail)............................................. 46

Adding a Speed Dial Number (Scan To Server).......................................... 47

Editing a Speed Dial Number........................................................ 48

Deleting a Speed Dial Number....................................................... 48

Programming/Editing a Group Dial................................................... 49

Registering to Favorites............................................................. 49

Printing the List of Speed Dial, Group Dial and Favorite...................................... 50

Displaying Machine Information......................................................... 51

Checking the Total Counter.......................................................... 51

Checking the Configuration Page..................................................... 51

Uninstalling LSP....................................................................... 51

Troubleshooting....................................................................... 51

Chapter 4 Understanding the Network Setting Menu

NETWORK SETTING Menu............................................................ 52

Location within the Configuration Menu. . . . . . ......................................... 52

Contents 24

Epson AcuLaser CX37 Series Reference Guide

Accessing the Network Setting Menu.................................................. 52

Using the Network Setting Menu Options.............................................. 53

Chapter 5 Network Printing

Network Connection................................................................... 61

Theory........................................................................... 61

Making the Connection............................................................. 61

Printing via IPP (Internet Printing Protocol)................................................ 63

With Windows Server 2008/Server 2008 R2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Adding an IPP Port using Add Printer Wizard – Windows Server 2003/XP. . . . . . . . . . . . . . . . . . 64

Adding an IPP Port using Add Printer Wizard – Windows Vista/7/Server 2008/Server 2008 R2

............................................................................... 65

Printing via function Function............................................................ 66

With Windows Server 2008/Server 2008 R2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Making the printer driver known from the Network window.............................. 67

Adding a printer from the Network window............................................ 68

Adding a printer using Add Printer Wizard............................................ 69

Updating the driver after connecting this machine....................................... 71

If the bit number differs between the server operating system and client operating system.......... 72

Installing the Additional Driver...................................................... 73

Troubleshooting....................................................................... 75

Chapter 6 Using Web-Based EpsonNet Config

About Web-Based EpsonNet Config....................................................... 76

Display Language.................................................................. 76

Requirements..................................................................... 77

When connecting with Windows Server 2008/Server 2008 R2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Setting Up the Printer Web Page.......................................................... 78

Determining the Printer Name....................................................... 78

Setting Up Your Browser Software.................................................... 79

Understanding the Web-Based EpsonNet Config Window.................................... 82

Navigation........................................................................ 82

Current Status..................................................................... 83

Logging on to Web-Based EpsonNet Config................................................ 83

Language Setting................................................................... 84

Contents 25

Epson AcuLaser CX37 Series Reference Guide

Public User Mode.................................................................. 84

Registered User Mode.............................................................. 84

Administrator Mode................................................................ 85

Viewing Printer Status.................................................................. 85

System Page....................................................................... 85

Job Page.......................................................................... 91

Print Page........................................................................ 93

Scan Page........................................................................ 100

Configuring the Printer................................................................ 101

System Page...................................................................... 101

Job Page......................................................................... 119

Print Page....................................................................... 120

Scan Page........................................................................ 137

Network Page.................................................................... 155

Index

Contents 26

Chapter 1

Operation on Linux

System Requirements

Operating systems Red Hat Enterprise Linux 5 Desktop

Connecting the computer and printer USB connection, Network connection (10Base-T/100Base-TX/1000Base-T)

RAM More than OS recommendation (128 MB or more is recommended)

Network LPR

Epson AcuLaser CX37 Series Reference Guide

SUSE Linux Enterprise Desktop 10

AppSocket/HP JetDirect

IPP

Available hard disk space 256 MB or more

Note:

As an example, the descriptions of the operations for Red Hat Enterprise Linux 5 are provided in this

chapter.

Installing PPD File From the Command Line

Note:

❏ Before proceeding with the installation, be sure to exit all running applications.

❏ Root privileges are required in order to install ppd file.

1. Copy the ppd file from the Software Disc to the “/usr/share/cups/model” on the computer.

Note:

A ppd file for each language is available in the corresponding “Drivers/LinuxPPD/ language” folder on the Software Disc. Use the appropriate ppd file for the language.

2. From the Main Menu, select Applications, then Accessories, then Terminal.

3. Enter the command “/etc/init.d/cups restart”.

Operation on Linux 27

Epson AcuLaser CX37 Series Reference Guide

4. Quit Terminal.

Adding the Printer Using Printer configuration

Note:

❏ Before proceeding with the installation, be sure to exit all running applications.

❏ Root privileges are required in order to add the printer.

1. Connect the printer to a computer or the network.

❏ With a USB connection, the Specify Printer Driver dialog box appears. Click Cancel to close

the dialog box.

2. Insert the Software Disc in the CD/DVD drive of your computer.

3. From the System menu, select Administration, then Printing.

4. Click New Printer.

5. Enter the printer name, description, and location, and then click Forward.

The printers that can be used are automatically searched for and listed in t he le ft pa ne of th e dial og box.

6. From the left pane of the dialog box, select the port for the printer to be installed.

❏ If the desired printer is not listed, select a device port from the Devices list. In the right pane of

the dialog box, type in the host name or IP address for the printer.

Note:

❏ TCP/IP: AppSocket/HP jetDirect, Internet Printing Protocol (ipp) or LPD/LPR Host or

Printer

❏ Host name of Internet Printing Protocol (ipp): <IP address>/ipp

7. Click Forward.

8. Select Provide PPD file.

9. Click the folder icon.

Operation on Linux 28

Epson AcuLaser CX37 Series Reference Guide

10. Select the PPD file.

Note:

A ppd file for each language is available in the corresponding “Drivers/LinuxPPD/ language” folder on the Software Disc. Use the appropriate ppd file for the language.

11. Click Open.

The name of the selected PPD file is displayed.

12. Click Forward.

13. Click Apply.

Adding the Printer on the CUPS Administration Web page

Note:

❏ Before proceeding with the installation, be sure to exit all running applications.

❏ Root privileges are required in order to add the printer.

1. Connect the printer to a computer or the network.

❏ With a USB connection, the Specify Printer Driver dialog box appears. Click Cancel to close

the dialog box.

2. Start up the Web browser.

3. Enter the URL “http://localhost:631”.

4. Click Add Printer.

5. Enter the printer name, location, and description, and then click Continue.

6. Select a Device Port from the Device list, then click Continue.

❏ TCP/IP: AppSocket/HP JetDirect, Internet Printing Protocol (http) or LPD/LPR Host or

Printer

❏ USB: USB Printer #1

Operation on Linux 29

Epson AcuLaser CX37 Series Reference Guide

7. For a USB connection, skip to step 9. Enter the device URI in the following form: socket://<Printer IP or Printer Hostname>:port

Note:

Example: Using Printer IP - socket://192.168.1.190:9100 Using printer Hostname - socket://Hostname:9100 Hostname may be substituted by IP Address, and Port is optional.

8. Click Continue.

9. Select Epson, click Continue.

Note:

A ppd file for each language is available in the corresponding “Drivers/LinuxPPD/ language” folder on the Software Disc. Use the appropriate ppd file for the language.

10. Select the printer name, then click Add Printer.

11. Enter the user name and password for using root privileges, and then click OK. The Set Printer Options window appears.

Specifying Printer Driver Settings

Displaying the Settings Page

1. Start up the Web browser.

2. Enter the URL “http://localhost:631”, and then click Manage Printers.

3. Click Set Printer Options.

Operation on Linux 30

Printer Driver Settings

Options Installed

Parameters Settings

Epson AcuLaser CX37 Series Reference Guide

Paper Source Unit

Storage

Duplex Unit Select the setting for the duplex unit.

Printer Memory

General

Parameters Settings

Paper Type Specifies the paper type.

Select Unit 3 if an optional 500-sheet paper cassette unit for the printer has been installed.

Default: Disabled

Select None or HDD for the storage unit that is installed.

Do not select CF(1GB Over), because the printer does not support CompactFlash cards.

Default: None

Default: Enabled

Select 256 MB or 768 MB if an optional memory for the pr inte r has been installed.

Default: 256 MB

Default: Auto

Paper Source Specifies the paper source.

Default: Tray 1

Manually Print on 2nd side Select whether or not to print on the back side of paper that has already

been printed on.

Default: Off

Paper Sizes Specifies the paper size. An irregular paper size cannot be selected.

Collate

If On is selected, all pages in the documents are printed as sets of printouts.

Default: Off

Operation on Linux 31

Epson AcuLaser CX37 Series Reference Guide

Parameters Settings

Duplex Options Specifies the duplex print binding position, if the duplex unit for the

printer has been installed.

Default: Simplex

Select Color

Color Separation Specifies the color separation.

Brightness Specifies the brightness of the image.

Edge Strength Set the edge strength.

Economy Print Select whether or not economy printing is used.

Auto Trapping Select whether or not neighboring colors are printed superimposed in

Black Over Print Specify whether black objects are printed (superimposed) on a

Specifies the color for printing as Color or Grayscale.

Default: Color

Default: Off

Default: 0%

Default: Middle

Default: Off

order to prevent white space around images.

Default: Off

neighboring color in order to prevent white space around black characters or figures.

If Text/Figure is selected, superimposed printing is applied to text and graphics.

If Text is selected, superimposed printing is applied to text.

Default: Off

Image Options/Text Options/Graphics Options

Parameters Settings

Image RGB Source/Text RGB Source/ Graphics RGB Source

Image RGB Intent/Text RGB Intent/ Graphics RGB Intent

Specifies RGB source for image/text/graphics as None, sRGB, Adobe RGB (1998), Apple RGB, ColorMatch RGB, or Blue Adjust RGB.

Default: sRGB

Specifies RGB intent for image/text/graphics as Vivid, Photographic, Relative Color, or Absolute Color.

Default: Vivid (for text/graphics), Photographic (for image)

Operation on Linux 32

Parameters Settings

Epson AcuLaser CX37 Series Reference Guide

Image RGB Gray Treatment/Text RGB Gray Treatment/Graphics RGB Gray Treatment

Image Halftone/Text Halftone/Graphics Halftone

Image Edge Enhancement/Text Edge Enhancement/Graphics Edge Enhancement

Simulation

Parameters Settings

Simulation Profile

Match Paper Color Specifies the Match Paper Color.

Specifies the RGB Gray Treatment as Composite Black, Black and Gray, or Black Only.

Default: Black and Gray

Specifies the halftone for image/text/graphics as Line Art, Detail, or Smooth.

Default: Line Art (for text), Detail (for image/graphics)

Select whether image/text/graphics edges are emphasized.

Default: Off (for image), On (for text/graphics)

Specifies the simulation profile as None, SWOP, Euroscale, Commercial Press, Japan Color, DIC, or TOYO.

Default: None

Default: Off

CMYK Gray Treatment

Banners

Parameters Settings

Starting Banner

Ending Banner

Specifies simulation gray treatment as Composite Black, Black and Gray, or Black Only.

Default: Composite Black

Specifies the starting banner as none, classified, confidential, mls, secret, selinux, standard, te, topsecret, or unclassified.

Default: none

Specifies the ending banner as none, classified, confidential, mls, secret, selinux, standard, te, topsecret, or unclassified.

Default: none

Operation on Linux 33

Epson AcuLaser CX37 Series Reference Guide

Printing a Document

The contents and available options that appear in the print dialog box may vary depending on the application being used.

Example Using OpenOffice

Note:

❏ The procedure for printing on Red Hat Enterprise Linux 5 with OpenOffice 2.0.4 is described below.

The following procedure or some steps may be different depending on the version of the operating system being used.

❏ First, add the printer to the system.

For details on adding a printer to the system, refer to “Adding the Printer Using Printer configuration” on page 28 or “Adding the Printer on the CUPS Administration Web page” on page 29.

1. From the Application menu, select Office, then Word Processor.

2. Open the document to be printed.

3. Click Print in the File menu.

4. Select the name of the printer.

5. Click Print to print the document.

Checking Print Jobs

1. Start up the Web browser.

2. Enter the URL “http://localhost:631”.

3. Click Manage Jobs.

Note:

To check the status of completed print jobs, click Show Completed Jobs.

Operation on Linux 34

Troubleshooting

Symptom Action

Epson AcuLaser CX37 Series Reference Guide

The printer stops because of a paper size error or a paper type error.

Printing does not continue with a custom paper size.

Printing cannot be completed correctly from OpenOffice or any other Office application (such as, Kword).

When printing from Acrobat Reader, part of the image is printed in solid black or the job is interrupted.

The job may have been sent with a prohibited combination of settings (for example, for the paper size and media type). Printing is not possible with postcards or overhead projector transparencies if Plain Paper is selected.

Printing with custom paper sizes is not possible directly from the printer driver. This can only be performed from the command line. Specify the following command to print data.

lpr -P [printer_name] -o media=Custom. [WIDTHxLENGTH] [file_name]

1. Format of Custom. [WIDTHxLENGTH]: Custom.150x200mm, Custom.8x11in, Custom.15x20cm, or Custom. 612x782 (postscript points)

2. The specified file must be a PS, PDF or JPEG file.

Applications running under Linux have their own print settings. Some of these functions may not be supported by this printer. Observe the following for best printing results.

❏ Settings made within the application: Paper size and orientation

❏ Settings made with the printer driver (kprinter): Settings other than

those specified above (for example, paper type, tray, and resolution)

There is a compatibility problem between Ghostscript and Acrobat Reader. Try using a different PDF application.

Watermarks cannot be printed from Kword.

This is a bug with Kword. Use Overlay instead.

Operation on Linux 35

Chapter 2

Operation on NetWare

Printing With NetWare

Network Printing in a NetWare Environment

NetWare Version Protocol Used Emulation Service Mode

NetWare 4.x IPX Bindery/NDS Pserver/Nprinter

NetWare 5.x/6 IPX NDS Pserver

TCP/IP NDPS(lpr)

Epson AcuLaser CX37 Series Reference Guide

For Remote Printer Mode With NetWare 4.x Bindery Emulation

Note:

Before using bindery emulation, check that bindery emulation is compatible with the NetWare server.

1. From a client computer, log on with Supervisor permissions to access the NetWare server where the Pserver is registered.

2. Start up Pconsole.

3. From the Available Options list, select Quick Setup, and then click the Enter button.

4. Enter the appropriate names in the Printer Server Name, Printer Name, Print Queue Name, and Print Queue Volume fields, select Other/ Unknown from the Printer type field, and then save the specified settings.

5. Click the Esc button to quit Pconsole.

6. Use the NetWare server console to load PSERVER.NLM.

Note:

For queue user privileges, printer notification option, assignment of multiple queues, and passwords, refer to the NetWare documentation, and specify settings as necessary.

Operation on NetWare 36

Epson AcuLaser CX37 Series Reference Guide

7. In Administrator mode of Web-Based EpsonNet Config, select NetWare from the Network tab, and then specify the following settings.

❏ NetWare Print: Select Enable.

❏ Frame Type:

Select Auto. (Select the frame type according to the network environment.)

❏ Mode: Select NPrinter/RPrinter.

❏ Printer Name:

Specify the printer name. (Default: AL-CX37-xxxxxx)

❏ Printer Number:

Specify the printer number (0-255). When 255 is specified, the setting is Auto.

8. Restart the printer.

9. Use the NetWare server console to display the print server screen, and then check that the created printer is shown as Waiting for Job for the connected printer (0).

For Print Server Mode With NetWare 4.x Bindery Emulation

Note:

Before using bindery emulation, check that bindery emulation is compatible with the NetWare server.

1. From a client computer, log on with Supervisor permissions to access the NetWare server where the Pserver is registered.

2. Start up Pconsole.

3. From the Available Options list, select Quick Setup, and then click the Enter button.

5. Click the Esc button to quit Pconsole.

6. In Administrator mode of Web-Based EpsonNet Config, select NetWare. from the Network tab, and then specify the following settings.

Operation on NetWare 37

Epson AcuLaser CX37 Series Reference Guide

❏ NetWare Print: Select Enable.

❏ Frame Type:

Select Auto. (Select the frame type according to the network environment.)

❏ Mode: Select PServer.

❏ Print Server Name:

Specify the print server name created in step 4.

❏ Print Server Password:

Specify only when setting from the NetWare server.

❏ Print Queue Scan Rate: Specify 1. (Change as necessary.)

❏ Bindery/NDS: Select Bindery/NDS.

❏ Preferred File Server:

Specify the name of the file server that connects to the Pserver.

7. Restart the printer.

8. Use the NetWare server console to load MONITOR.NLM.

9. Select the connection information and, in the active connection column, check that the created Pserver is connected.

For NetWare 4.x Remote Printer Mode (NDS)

1. Log on to NetWare as an administrator from a client computer.

2. Start up NWadmin.

3. Select either the organization or organizational unit container that offers the print service, and then click Print Services Quick Setup on the Tools menu.

Note:

For queue user privileges, printer notification option, assignment of multiple queues, and passwords, refer to the NetWare documentation, and specify settings as necessary.

Operation on NetWare 38

Epson AcuLaser CX37 Series Reference Guide

5. In Administrator mode of Web-Based EpsonNet Config, select NetWare from the Network tab, and then specify the following settings.

❏ NetWare Print: Select Enable.

❏ Frame Type:

Select Auto. (Select the frame type according to the network environment.)

❏ Mode: Select NPrinter/RPrinter.

❏ Printer Name:

Specify the printer name. (Default: AL-CX37-xxxxxx)

❏ Printer Number:

Specify the printer number (0-255). When 255 is specified, the setting is Auto.

6. Restart the printer.

7. Use the NetWare server console to load PSERVER.NLM.

8. Use the NetWare server console to display the print server screen, and then check that created printer is shown as Waiting for Job for the connected printer (0).

For NetWare 4.x/5.x/6 Print Server Mode (NDS)

Note:

To use the Print Server mode, the IPX protocol must be loaded on the NetWare server.

1. Log on to NetWare as an administrator from a client computer.

2. Start up NWadmin.

3. Select either the organization or organizational unit container that offers the print service, and then click Print Services Quick Setup (non-NDPS) on the Tools menu.

4. Enter the appropriate names in the Printer Server Name, Printer Name, Print Queue Name, and Print Queue Volume fields, select Other/ Unknown from the Printer Type field, and then click the Create button.

Note:

For queue user privileges, printer notification option, assignment of multiple queues, and passwords, refer to the NetWare documentation, and specify settings as necessary.

Operation on NetWare 39

Epson AcuLaser CX37 Series Reference Guide

5. In Administrator mode of Web-Based EpsonNet Config, select NetWare from the Network tab, and then specify the following settings.

❏ NetWare Print: Select Enable.

❏ Frame Type:

Select Auto. (Select the frame type according to the network environment.)

❏ Mode: Select PServer.

❏ Print Server Name: Specify the print server name created in step 4.

❏ Print Server Password: Specify only when setting from the Net-Ware server.

❏ Print Queue Scan Rate: Specify 1. (Change as necessary.)

❏ Bindery/NDS: Select NDS.

❏ Preferred NDS Context Name:

Specify the name of the context that connects to Pserver.

❏ Preferred NDS Tree Name:

Specify the name of the tree that Pserver logs on to.

6. Restart the printer.

7. Use the NetWare server console to load MONITOR.NLM.

8. Select the connection information and, in the active connection column, check that the created Pserver is connected.

For NetWare 5.x/6 Novell Distributed Print Service (NDPS)

Note:

❏ Before specifying settings for NDPS, check that the NDPS broker and NDPS manager have been

created and loaded.

❏ Also, before performing the following procedure, check that the TCP/ IP protocol has been set in the

NetWare server, and check that the IP address has been set for this machine and that this machine is on.

1. Log on to NetWare as an administrator from a client computer.

2. Start up NWadmin.

Operation on NetWare 40

Epson AcuLaser CX37 Series Reference Guide

3. Right-click the organization or organizational unit container where you will create the printer agent, and then click NDPS Printer on the Create submenu.

4. In the NDPS Printer Name box, enter the printer name.

5. In the Printer Agent Source column, select Create a New Printer Agent, and then click the Create button.

6. Check the printer agent name, and then in the NDPS Manager Name box, browse through the NDPS manager names, and register one.

7. In the Gateway Types, select Novell Printer Gateway, and then register it.

8. In the Configure Novell PDS for Printer Agent window, select (None) for the printer type and Novell Port Handler for the port handler type, and then register the settings.

9. In Connection type, select Remote (LPR on IP), and then register it.

10. Enter the IP address set for this machine as the host address, enter Print as the printer name, and then click the Finish button to register the settings.

11. The printer driver registration screen appears. Select None for each operating system to complete the registration.

Note:

For settings for the queue user rights, printer notification option, assignment of multiple queues, and passwords, refer to the NetWare documentation, and set them as necessary.

Setting Up a Client (Windows) Settings When Using the NetWare Server

1. Open the printer’s Properties window.

2. In the port settings, browse the network, and specify the name of the created queue (or NDPS printer name).

3. In the Printer Model list, specify the folder on the Software Disc that contains the printer driver for the operating system and printer driver to be used.

4. Follow the on-screen instructions to complete the installation.

Operation on NetWare 41

Epson AcuLaser CX37 Series Reference Guide

Chapter 3

Using Local Setup Program (for Epson AcuLaser CX37DNF only)

About Local Setup Program (LSP)

By installing Local Setup Program (LSP) onto a computer connected to the machine, you can add, edit, delete of Addressbook, and check the counters and machine status from the computer.

The following operations can be performed using LSP.

❏ Save speed dialing, group dialing and favorite information onto a computer

❏ Change speed dialing, group dialing and favorite information

❏ Print speed dialing, group dialing and favorite information specified with this utility.

❏ Check the counters and machine status

LSP Operating Environment

The following environment is required in order to install LSP onto a computer.

Item Operating environment

Operating system Windows XP for 32 bit/64 bit Windows Vista for 32 bit/64 bit Windows 7 for 32

bit/64 bit Windows Server 2003 for 32 bit/64 bit Windows Server 2008 for 32 bit/ 64 bit Windows Server 2008 R2

Processor Pentium II or faster

Memory Memory capacity recommended for the operating system.

There should be enough memory for the operating system and the applications used.

Available hard disk space 100 MB or more

Connecting the computer and the machine

USB connection (USB 2.0 (High-Speed))

Web browser Internet Explorer version 6.0 or later

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 42

Epson AcuLaser CX37 Series Reference Guide

Note:

❏ Use a USB cable with an A-type connector (4-pin male) and a B-type connector (4-pin male). We

recommend that the USB cable be no more than 3 meters (10 feet) long.

❏ The printer driver for this machine and the TWAIN driver must be installed on the computer.

Installing LSP

You can install LSP from the Software Disc.

Note:

❏ You must have administrator privileges in order to install the LSP.

❏ If the User Account Control window appears when installing on -Windows Vista, click the Continue

button or the Yes button.

Starting Up LSP

1. Click the Start button, point to EPSON, Epson AcuLaser CX37, LSP and then click EPSON AL-CX37 Local Setup Program.

The main window of LSP appears.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 43

Main LSP Window

Epson AcuLaser CX37 Series Reference Guide

No. Name Description

1 Connect button Click this button to connect the machine with the computer.

2 Disconnect button Click this button to cut the connection between the machine and the

3 Upload button Click this button to send the settings file to the machine.

4 Download button Click this button to send the machine’s settings to the computer.

5Dial Registration

6 Machine icon

Connecting to the Machine

1. Click .

computer.

Click + beside the machine icon to display the machine speed dialing, group dialing and favorite settings.

Click + beside the machine icon to display the machine information.

For details, refer to “Displaying Machine Information” on page 51.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 44

Epson AcuLaser CX37 Series Reference Guide

When LSP is connected to the machine, Connect Status: Online appears.

Note:

While operations are being performed in LSP, the machine cannot be operated from its control panel.

Downloading Information from the Machine

Click to download all information programmed on the machine.

Uploading Information to the Machine

Click to upload all information to be programmed on the machine.

Dial Import/Dial Export

By clicking Dial Import on the File menu, all information for speed dialing, group dialing and favorites is imported onto the machine. This information can also be exported by clicking Dial Export on the File menu.

Note:

❏ When machine information is imported or exported, the last file that was read and saved is opened.

❏ Do not import CSV files edited in Excel.

Settings for dial destination

This section provides descriptions on the settings that appear for speed dialing, group dialing, favorites and machine information.

Programming a Speed Dial Number

1. Click + beside Dial Registration, and then click + beside the Speed Dial.

2. To register a fax or e-mail destination, click + beside Fax/E-mail. To register an FTP or SMB destination, click + beside Scan To Server.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 45

Epson AcuLaser CX37 Series Reference Guide

3. From the tree that is displayed, click the speed dial number to be programmed, and then click New Registration button.

Note:

❏ A maximum of 001-250 speed dial numbers can be programmed.

❏ The registered list can be switched over when Speed Dial Setting is changed.

❏ When Fax/E-mail or Scan To Server is selected, and New Registration button can be selected,

non registered number is automatically assign the speed dial number.

4. In the Speed Dial Registration dialog box, specify the desired settings.

Note:

❏ To register a fax or e-mail destination, refer to “Adding a Speed Dial Number (Fax/E-mail)” on

page 46.

❏ To register an FTP or SMB destination, refer to “Adding a Speed Dial Number (Scan To Server)”

on page 47.

5. Click the OK button.

Programming of the speed dial number is completed.

Adding a Speed Dial Number (Fax/E-mail)

The following procedures describe how to send scan data with a fax number or e-mail address. The transmission settings and destination can first be registered as a speed dial number.

For registering a fax number

1. Click the New Registration button.

2. Select Fax.

3. Specify the settings for the speed dialing.

❏ A maximum of 20 characters can be entered for a name.

❏ A maximum of 50 numbers can be entered for a fax number.

4. Click the Details button, and then specify the transmission speed and batch transmission time.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 46

Epson AcuLaser CX37 Series Reference Guide

5. When registering speed dial numbers to a group, select from Add to Group list.

These speed dial numbers cannot be added to groups registered with an e-mail address.

Note:

To edit a group dial, refer to “Programming/Editing a Group Dial” on page 49.

6. Click the OK button.

The added speed dial number appears in the Dial Registration list.

For registering an E-mail address

1. Click the New Registration button.

2. Select E-mail.

3. Specify the settings for the speed dialing.

❏ A maximum of 20 characters can be entered for the name.

❏ A maximum of 64 characters can be entered for the E-mail address.

4. When registering speed dial numbers to a group, select from Add to Group list.

These speed dial numbers cannot be added to groups registered with a fax number.

Note:

To edit a group dial, refer to “Programming/Editing a Group Dial” on page 49.

5. Click the OK button.

The added speed dial number appears in the Dial Registration list.

Adding a Speed Dial Number (Scan To Server)

The following procedures describe how to send scan data via a server. The transmission settings and destination can first be registered as a speed dial number.

For FTP transmissions

1. Click the New Registration button.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 47

2. Select FTP.

3. Specify the necessary information.

4. Click the OK button.

The registered speed dial number appears in the Dial Registration list.

For SMB transmissions

1. Click the New Registration button.

2. Select SMB.

3. Specify the necessary information.

4. Click the OK button.

Epson AcuLaser CX37 Series Reference Guide

The registered speed dial number appears in the Dial Registration list.

Editing a Speed Dial Number

1. Select the speed dial number to be edited.

2. Click the Edit button.

Speed Dial Registration dialog box appears

3. Edit the settings as desired.

4. Click the OK button to apply the changes.

The edited speed dial number appears in the Dial Registration list.

Deleting a Speed Dial Number

1. Select the speed dial number to be deleted.

2. Click the Delete button.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 48

Epson AcuLaser CX37 Series Reference Guide

The speed dial number is deleted from the Dial Registration list.

Programming/Editing a Group Dial

The following procedure describes how to edit or delete a group dialing program.

Note:

Program group dialing after programming speed dial numbers. Add or delete destinations from group dialing by changing the settings for the registered speed dial destinations. For details, refer to “Editing a Speed Dial Number” on page 48.

1. Click + beside Dial Registration, and then click + beside the Group Dial.

2. From the tree that is displayed, click the group name to be edited.

Note:

❏ Click + beside the group name, and then displays the speed dial number that registered in the

group.

❏ A maximum of 20 group dial can be programmed.

❏ A maximum of 50 speed dial numbers can be programmed.

3. Click Edit button.

Note:

If a speed dial number in a group is selected, the registered information for the speed dial number can be changed. For details, refer to “Editing a Speed Dial Number” on page 48.

4. Specify the name of the group.

5. Click the OK button.

Editing of the group name is completed.

Registering to Favorites

This section provides details on registering speed dial numbers and group dial in the Favorite list. Frequently used speed dial numbers and group dial destinations can be registered in the Favorite list.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 49

Epson AcuLaser CX37 Series Reference Guide

Note:

A maximum of 20 numbers can be registered to the favorite.

1. Click + beside Dial Registration, and then click Favorite.

2. Click the New Registration button.

3. Click From Speed Dial or From Group Dial.

The corresponding list of registered destinations appears.

4. From the list, select the destination to be registered, and then click the OK button.

The registered destination appears in the Dial Registration list.

Note:

To delete a destination from the Favorite list, select the desired destination, and then click the Delete button.

Printing the List of Speed Dial, Group Dial and Favorite

The settings specified on the machine for speed dialing, group dialing and favorites can be printed.

1. Click Print on the File menu.

Select Print Item dialog box appears.

2. From the Select Print Item dialog box, select the list to be printed.

❏ If All is selected, all items in the list are printed.

❏ If Select No. is selected, the number selected in the list is printed.

3. Click the OK button.

4. Specify the appropriate settings in the Print dialog box, and then click the OK button.

The list is printed.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 50

Epson AcuLaser CX37 Series Reference Guide

Displaying Machine Information

The settings downloaded from the machine can be displayed. These settings can be used to view the counters or check the machine information.

Checking the Total Counter

1. Click + beside Machine Information menu, and then click Total Counter.

The Total Counter dialog box appears.

Checking the Configuration Page

1. Click + beside Machine Information menu, and then click Configuration Summary.

The Configuration Summary dialog box appears.

Uninstalling LSP

Note:

❏ You must have administrator privileges in order to uninstall the LSP.

❏ If the User Account Control window appears when uninstalling on -Windows Vista, click the

Continue button or the Yes button.

1. Click the Start button, point to EPSON, Epson AcuLaser CX37, LSP and then click Uninstall.

2. Follow the on-screen instructions.

Troubleshooting

Symptom Solution

It takes a long time to access the printer driver when LSP has established a connection to the machine.

Wait until it can be accessed.

Using Local Setup Program (for Epson AcuLaser CX37DNF only) 51

Epson AcuLaser CX37 Series Reference Guide

Chapter 4

Understanding the Network Setting Menu

NETWORK SETTING Menu

Location within the Configuration Menu

Note:

The ADMIN. MANAGEMENT menu is accessible only by the administrator. To display the settings for this menu, press d to display UTILITY, and press Select key to display MACHINE SETTING, and then select ADMIN. MANAGEMENT, use the keypad to type in the 6-digits administrator access code (default :

000000), and then press the Select key.

Accessing the Network Setting Menu

Use the following series of keystrokes at the printer to access the Network Setting menu options on your printer. This menu provides access to all of the configurable network items.

Press this key . . . (until) the message window reads . . .

UTILITY

ACCESSIBILITY

ADMIN. MANAGEMENT

Use the keypad to input 6-digits administrator number.

PASSWORD SETTING

NETWORK SETTING

Note:

The machine is automatically restarted if any of the following Ethernet settings are changed.

Understanding the Network Setting Menu 52

Epson AcuLaser CX37 Series Reference Guide

❏ TCP/IP

❏ DHCP (Only when changed from DISABLE to ENABLE)

❏ BOOTP (Only when changed from DISABLE to ENABLE)

❏ ARP/PING (Only when changed from DISABLE to ENABLE)

❏ IPv6 - AUTO SETTING (Only when changed from NO to YES)

❏ NETWARE

❏ IEEE802.1X

Using the Network Setting Menu Options

If the printer is connected to a network, the following settings should be specified. For details about each setting, contact your network administrator.

Note:

Do not use an IP address within the following ranges.

❏ 0.0.0.0 - 0.255.255.255

❏ 127.0.0.0 - 127.255.255.255

❏ 224.0.0.0 - 255.255.255.255

TCP/IP

Purpose Enables or disables TCP/IP.

Options DISABLE/ENABLE

Default ENABLE

IP ADDR. SETTING

IP ADDRESS

Purpose Sets the IP address of this machine on the network.

Default 0.0.0.0

Understanding the Network Setting Menu 53

Range 0-255 for each xxx triplet

Notes A single digit number, such as "1", cannot be input as "001".

SUBNET MASK

Purpose Sets the subnet mask of the network.

Epson AcuLaser CX37 Series Reference Guide

Use the keypad to input each number; use the l and r keys to move between triplets.

Align the number on the left and input "1" as "1 _ _". Use the l and r k ey s t o m ov e between triplets.

The Back key can also be used for deleting. To cancel IP Address menu, hold down the Back key for more than one second, and then press the Back key again after all settings have been cleared.

The subnet mask allows you to limit access to your machine (for example, according to departmental divisions).

Default 0.0.0.0

Range 0-255 for each xxx triplet

Notes A single digit number, such as "1", cannot be input as "001".

GATEWAY

Purpose Sets the address of the router/gateway when a router/gateway is used on your

Default 0.0.0.0

Range 0-255 for each xxx triplet

Use the keypad to input each number; use the l and r keys to move between triplets.

Align the number on the left and input "1" as "1 _ _". Use the l and r k ey s t o m ov e between triplets.

The Back key can also be used for deleting. To cancel IP Address menu, hold down the Back key for more than one second, and then press the Back key again after all settings have been cleared.

network and you allow users outside your network environment to print on your machine.

Use the keypad to input each number; use the l and r keys to move between triplets.

Understanding the Network Setting Menu 54

Notes A single digit number, such as "1", cannot be input as "001".

DHCP

Purpose If there is a DHCP server on the network, specifies whether the IP address and

Options DISABLE/ENABLE

Default ENABLE

BOOTP

Epson AcuLaser CX37 Series Reference Guide

Align the number on the left and input "1" as "1 _ _". Use the l and r k ey s t o m ov e between triplets.

The Back key can also be used for deleting. To cancel IP Address menu, hold down the Back key for more than one second, and then press the Back key again after all settings have been cleared.

other network information is automatically assigned by the DHCP server.

Purpose If there is a BOOTP server on the network, specifies whether the IP address and

Options DISABLE/ENABLE

Default DISABLE

ARP/PING

Purpose If the IP address cannot be acquired due to the DHCP or BOOTP address and if a

Options DISABLE/ENABLE

Default DISABLE

HTTP

Purpose Select whether or not to enable HTTP.

Options DISABLE/ENABLE

other network information is automatically assigned by the BOOTP server.

fixed IP address cannot be acquired, the destination IP address of the ICMP (Ping) packet previously received by the machine can be acquired as the IP address of the machine.

Default ENABLE

Understanding the Network Setting Menu 55

FTP SERVER

Purpose Select whether or not to enable FTP server.

Options DISABLE/ENABLE

Default DISABLE

FTP TX

Purpose Select whether or not to enable FTP client.

Options DISABLE/ENABLE

Default ENABLE

SMB

Epson AcuLaser CX37 Series Reference Guide

Purpose Select whether or not to enable SMB.

Options DISABLE/ENABLE

Default ENABLE

BONJOUR

Purpose Select whether or not to enable Bonjour.

Options DISABLE/ENABLE

Default ENABLE

DYNAMIC DNS

Purpose Select whether or not to enable Dynamic DNS.

Options DISABLE/ENABLE

Default DISABLE

IPP

Purpose Select whether or not to enable IPP.

Options DISABLE/ENABLE

Understanding the Network Setting Menu 56

Default ENABLE

RAW PORT

DISABLE/ENABLE

Purpose Select whether or not to enable Raw port.

Options DISABLE/ENABLE

Default ENABLE

BIDIRECTIONAL

Purpose Select whether or not to enable Bidirectional.

Epson AcuLaser CX37 Series Reference Guide

If ENABLE is selected, Raw port is enabled for bi-directional communication.

SLP

SNMP

If DISABLE is selected, Raw port is disabled for bi-directional communication.

Options DISABLE/ENABLE

Default DISABLE

Purpose Select whether or not to enable SLP.

Options DISABLE/ENABLE

Default ENABLE

Purpose Select whether or not to enable SNMP.

Options DISABLE/ENABLE

Default ENABLE

WSD PRINT

Purpose Select whether or not to enable WSD print.

Options DISABLE/ENABLE

Understanding the Network Setting Menu 57

Default ENABLE

IPSEC

Purpose Select whether or not to enable IPsec.

Options DISABLE/ENABLE

Default DISABLE

IP ADDR. FILTER

ACCESS PER.

Purpose Select whether or not to enable Access Permission transmissions.

Options DISABLE/ENABLE

Epson AcuLaser CX37 Series Reference Guide

Default DISABLE

ACCESS REFUSE

Purpose Select whether or not to enable Access Refuse transmissions.

Options DISABLE/ENABLE

Default DISABLE

IPv6

DISABLE/ENABLE

Purpose Select whether or not to enable IPv6.

Options DISABLE/ENABLE

Default ENABLE

AUTO SETTING

Purpose Select whether or not to enable Auto Setting.

Options YES/NO

Understanding the Network Setting Menu 58

Default YES

LINK LOCAL

Purpose Displays the link-local address of IPv6.

GLOBAL ADDRESS

Purpose Displays the global address of IPv6.

GATEWAY ADDRESS

Purpose Displays the gateway address of IPv6.

NETWARE

Epson AcuLaser CX37 Series Reference Guide

Purpose Select whether or not to enable NetWare.

Options DISABLE/ENABLE

Default DISABLE

APPLETALK

Purpose Select whether or not to enable AppleTalk.

Options DISABLE/ENABLE

Default ENABLE

SPEED/DUPLEX

Purpose Specifies the transmission speed for the network and the transmission method

Options AUTO/10BASE FULL/10BASE HALF/100BASE FULL/100BASE HALF/1000BASE

Default AUTO

for bi-directional transmission.

FULL

Understanding the Network Setting Menu 59

IEEE802.1X

Purpose Select whether or not to enable IEEE802.1X.

Options DISABLE/ENABLE

Default DISABLE

Epson AcuLaser CX37 Series Reference Guide

Understanding the Network Setting Menu 60

Epson AcuLaser CX37 Series Reference Guide

Chapter 5

Network Printing

Network Connection

Theory

To connect your machine in a TCP/IP network environment, you must make sure that the internal network addresses in the machine have been set.

Note:

In many cases, you have to enter only a unique IP address. However, you may also have to enter a subnet mask and/or a gateway (router) address, depending on your network configuration requirements.

Making the Connection

Ethernet Interface

An RJ45 connector can be used as the Ethernet interface for this machine.

When connecting your machine to an Ethernet network, the tasks you perform depend on how you plan to set the machine’s IP (Internet Protocol) address.

Network Printing 61

Epson AcuLaser CX37 Series Reference Guide

❏ IP Address: A unique identifier for each device on a TCP/IP network.

❏ Subnet Mask: A filter used to determine what subnet an IP address belongs to.

❏ Gateway: A node on a network that serves as an entrance to another network.

Since the IP address for each PC and machine on your network must be unique, you usually need to modify this preset address so it doesn’t conflict with any other IP address or your network or any attached network. You can do this in one of two ways. Each is explained in detail in the following sections.

❏ Using DHCP

❏ Setting the address manually

Using DHCP

If your network supports DHCP (Dynamic Host Configuration Protocol), the machine’s IP address will be automatically assigned by the DHCP server when you turn on the machine. (Refer to “Network Printing” on page 61 for a description of DHCP.)

Note:

If the IP address of the machine is not set automatically, check if the machine has been set to allow DHCP to be used (REPORT/STATUS - REPORT - CONFIGURATION PAGE). If the machine has been set so that DHCP cannot be used, select ENABLE in the UTILITY - ADMIN. MANAGEMENT - NETWORK SETTING DHCP menu.

1. Connect your machine to the network.

When using an Ethernet cable, plug the RJ45 connector into the Ethernet interface port of the machine.

2. Turn on your PC and machine.

3. After the machine’s message window is initialized, install the printer driver.

Setting the Address Manually

You may also manually change the machine’s IP address, subnet mask, and gateway by using the following instructions. (See chapter 4 “Understanding the Network Setting Menu” on page 52 for more information.)

Note:

When the IP address is changed, add a new port or reinstall the printer driver.

Network Printing 62

Epson AcuLaser CX37 Series Reference Guide

Caution:

You should always notify your network’s administrator before changing the machine’s IP address.

1. Turn on your PC and machine.

2. After the printer's message window is initialized, select UTILITY, and then press the Select key.

3. Select ADMIN. MANAGEMENT, and then press the Select key.

4. Use the keypad to input 6-digits administrator number.

5. Select NETWORK SETTING, and then press the Select key.

6. Select IP ADDR. SETTING, and then press the Select key twice.

7. Use the keypad to input each number, and then press the Select key.

8. Select SUBNET MASK, and then press the Select key.

9. Use the keypad to input each number, and then press the Select key.

10. Select GATEWAY, and then press the Select key.

11. Use the keypad to input each number, and then press the Select key.

12. Print a configuration page to verify that the correct IP address, subnet mask, and gateway have been set.

13. After the machine’s message window is initialized, install the printer driver.

Printing via IPP (Internet Printing Protocol)

IPP (Internet Printing Protocol) is a protocol for end users’ most common printing situations over the Internet. It allows users to find out about a printer’s capabilities, submit print jobs to a printer, determine the status of the printer or print job, and cancel a previously submitted print job.

Note:

❏ You must have administrator privileges in order to install the printer driver.

❏ If the User Account Control window appears when installing on Windows Vista/7/Server 2008/

Server 2008 R2, click the Continue button or the Yes button.

Network Printing 63

Epson AcuLaser CX37 Series Reference Guide

❏ For IPP printing, specify the network setting. Refer to “Making the Connection” on page 61.

With Windows Server 2008/Server 2008 R2

When using Windows Server 2008/Server 2008 R2, settings must be specified in the operating system before the printer driver is installed.

1. Click the Start button.

2. Point to Administrative Tools, and then click Server Manager.

Note:

If the User Account Control dialog box appears, click the Continue button or the Yes button.

3. In the Server Manager main window, click Add Features in the Features Summary section.

4. Select the Internet Printing Client check box to install the feature.

5. Restart the computer.

Adding an IPP Port using Add Printer Wizard – Windows Server 2003/XP

1. Click Start, select Printers and Faxes.

2. Click Add a Printer.

3. In the second dialog box, select the Network Printer radio button, and then choose Next.

4. In the URL field in the next dialog box, enter the machine’s network pathname in one of the following formats, and then choose Next:

❏ http://ipaddress/ipp

❏ http://ipaddress:80/ipp

❏ http://ipaddress:631/ipp

If your system cannot connect to the machine, the following message appears:

“Windows cannot connect to the printer. Either the printer name was typed incorrectly, or the specified printer has lost its connection to the server. For more information, click Help.”

Network Printing 64

Epson AcuLaser CX37 Series Reference Guide

5. Choose Have Disk.

6. Choose Browse.

7. Locate the directory on the Software Disc where the printer driver files are located and then click Open.

8. Click OK.

9. Click OK.

10. Select whether the machine is to be used as the default printer, and then click Next.

11. Click Finish.

Adding an IPP Port using Add Printer Wizard – Windows Vista/7/Server 2008/ Server 2008 R2

1. Click Start, click Control Panel, and then click Printers.

Note:

When using Windows 7/Server 2008 R2, View devices and printers under Hardware and Sound.

2. Click Add a printer.

3. In the dialog box click Add a network, wireless or Bluetooth printer.

4. In the dialog box, click The printer that I want isn’t listed.

5. In the URL field in the next dialog box enter the machine’s network pathname in one of the following formats and then choose Next:

❏ http://ipaddress/ipp

❏ http://ipaddress:80/ipp

❏ http://ipaddress:631/ipp

Network Printing 65

Epson AcuLaser CX37 Series Reference Guide

Note:

If your system cannot connect to the machine, the following message appears: “Windows cannot connect to the printer. Make sure that you have typed the name correctly, and that the printer is connected to network.”

6. Click Have Disk.

7. Click Browse.

8. Locate the directory on the Software Disc where the printer driver files are located and then click Open.

9. Click OK.

10. Click OK.

11. Click Next.

12. Click Finish.

Printing via function Function

In Windows Vista/7/Server 2008/Server 2008 R2, printers on the network that support Web Service Print can be detected and installed.

Note:

❏ You must have administrator privileges in order to install the printer driver.

❏ Before proceeding with the installation, be sure to exit all running applications.

❏ If the User Account Control window appears when installing on Windows Vista/7/Server 2008/

Server 2008 R2, click the Continue button or the Yes button.

With Windows Server 2008/Server 2008 R2

When using Windows Server 2008/Server 2008 R2, settings must be specified in the operating system before the printer driver is installed.

1. Click the Start button.

Network Printing 66

Epson AcuLaser CX37 Series Reference Guide

2. Point to Administrative Tools, and then click Server Manager.

Note:

If the User Account Control dialog box appears, click the Continue button or the Yes button.

3. In the Server Manager main window, click Add Roles in the Roles Summary section.

4. Select the Print Services or Print and Document Services check box to install the feature.

Making the printer driver known from the Network window

To use Web service print in Windows Vista/7/Server 2008/Server 2008 R2, install the printer driver before making it known to the computer with plug and play.

1. Install the printer driver for this machine.

Install the printer driver using the installer or Add Printer Wizard. The printer driver can be installed in any port.

2. Turn on the power of the machine while it is connected to the network.

Since the printer is searched for, be sure to connect the machine to the network.

3. To use the Web service print, check that Network discovery is enabled in Network and Sharing Center on the computer.

4. Open the Network window.

❏ In Windows Vista/Server 2008, click Start, and Network.

❏ In Windows 7/Server 2008 R2, open Computer and click Network.

If Network is not displayed in Computer, click the Network and Internet category on the Control Panel, and also click View network computers and devices. Connected computers and devices are detected.

5. Select the device name of the machine, and then click Install on the toolbar.

The printer driver for this machine is detected and the machine is ready to print.

6. After finishing the installation, make sure that the icon for the installed printer is displayed in the Printers or Devices and Printers window.

Network Printing 67

Epson AcuLaser CX37 Series Reference Guide

Note:

❏ If the printer driver is not correctly installed, the driver must be updated using Update Driver ....

For details, refer to “Updating the driver after connecting this machine” on page 71.

❏ In Windows Vista/Server 2008, you can continue the task and specify the printer driver

installation disk to install the printer driver if it is not installed in advance. When the Found New Hardware window appears, follow the displayed messages to perform the procedure. For details, refer to “Adding a printer from the Network window” on page 68.

❏ In Windows 7/Server 2008 R2, you cannot specify the installation disk after the machine is

connected to the computer. Install the printer driver in advance (Step 1).

Adding a printer from the Network window

In Windows Vista/Server 2008, you can add a Web service device using the addition function of the printer after connecting this machine.

Note:

In Windows 7/Server 2008 R2, a window for specifying an installation disk does not appear after the machine is connected to the computer. To connect this machine as described in “Making the printer driver known from the Network window” on page 67.

1. Insert the Software Disc in the CD/DVD drive of your computer.

Note:

❏ Click Run AutoRun.exe in the AutoPlay dialog box that appears when the Software Disc is

inserted.

❏ If the installer does not start up automatically, double-click the EPSETUP.EXE icon on the

Software Disc.

The installer starts up.

2. Exit the installer.

3. Turn on the power of the machine while it is connected to the network.

Since the printer is searched for, be sure to connect the machine to the network.

4. To use Web Service print, check that Network discovery is enabled in Network and Sharing Center on the computer.

Network Printing 68

Epson AcuLaser CX37 Series Reference Guide

5. Open the Network window.

❏ In Windows Vista/Server 2008, click Start and Network.

❏ In Windows 7/Server 2008 R2, open Computer and click Network. If Network is not

displayed in Computer, click the Network and Internet category on the Control Panel, and also click View network computers and devices.

6. Select the device name of this machine, and then click Install on the toolbar.

7. Click Locate and install driver software (recommended).

8. If Windows Vista is being used, go to step 9. If Windows Server 2008 is being used, click Don't search online.

9. Click Browse my computer for driver software (advanced).

10. Click Browse.

11. Locate the directory on the Software Disc where the printer driver files are located and then click OK.

12. Click Next.

13. Click Close.

Adding a printer using Add Printer Wizard

In Windows Vista/Server 2008, you can add a Web service device using the addition function of the printer after connecting this machine.

Note:

❏ In Windows 7/Server 2008 R2, a window for specifying an installation disk does not appear after the

machine is connected to the computer. To connect this machine as described in “Making the printer driver known from the Network window” on page 67.

❏ Installing the driver to Windows Vista/Server 2008-based computers requires the administrator

authority.

1. To use Web Service print, check that Network discovery is enabled in Network and Sharing Center on the computer.

Network Printing 69

Epson AcuLaser CX37 Series Reference Guide

2. Insert the Software Disc in the CD/DVD drive of your computer. The installer starts up.

Note:

❏ Click Run AutoRun.exe in the AutoPlay dialog box that appears when the Software Disc is

inserted.

❏ If the installer does not start up automatically, double-click the EPSETUP.EXE icon on the

Software Disc.

3. Exit the installer.

4. Click Start, click Control Panel, and then click Printers.

5. Click Add a printer on the toolbar.

6. In the dialog box, click Add a local printer.

7. Click Create a new port, and then select Standard TCP/IP Port.

8. Click Next.

9. Select Web Services Device and type the IP address for the machine, and then click Next.

The Found New Hardware Wizard dialog box appears.

10. Click Locate and install driver software (recommended).

11. If Windows Vista is being used, go to step 12. If Windows Server 2008 is being used, click Don't search online.

12. Click Browse my computer for driver software (advanced).

13. Click Browse.

14. Locate the directory on the Software Disc where the printer driver files and then click OK.

15. Click Next.

16. Click Close.

17. Click Next.

Network Printing 70

Epson AcuLaser CX37 Series Reference Guide

18. Select whether the printer driver is to be shared, and then click Next.

19. Click Finish.

This completes the installation of the printer driver.

Updating the driver after connecting this machine

In Windows 7/Server 2008 R2, if this machine is connected without first installing the printer driver, the printer driver will not be correctly identified. If the printer driver is not correctly identified, the driver must be updated using Update Driver.

1. Insert the Software Disc in the CD/DVD drive of your computer.

The installer starts up.

Note:

❏ Click Run AutoRun.exe in the AutoPlay dialog box that appears when the Software Disc is

inserted.

❏ If the installer does not start up automatically, double-click the EPSETUP.EXE icon on the

Software Disc.

2. Exit the installer.

3. Open the Devices and Printers window.

❏ Open the Control Panel, select Hardware and Sound, and then click View devices and

printers.

❏ When Control Panel is displayed in an icon view, double-click Devices and Printers.

4. Right-click the device name of the machine that is under Unspecified and then click Properties.

If Unknown Device appears instead of the device name of the machine, right-click to remove the device, and install the printer driver. To connect this machine as described in “Making the printer driver known from the Network window” on page 67.

5. In the Hardware tab, click Properties.

6. In the General tab, click Change Settings.

Network Printing 71

Epson AcuLaser CX37 Series Reference Guide

7. In the Driver tab, click Update Driver....

8. In the page in which to select how to search the driver software, click Browse my computer for driver software anyway.

9. Click Browse....

10. Locate the directory on the Software Disc where the printer driver files are located, and then click OK.

11. Click Next.

12. Follow the instructions on the pages that follow.

If the Windows Security window for verifying the publisher appears, click Install this driver software anyway.

13. Click Close.

14. After finishing the installation, make sure that the icon for the installed printer is displayed in the Device and Printer window.

15. Remove the Software Disc from the CD/DVD drive.

This completes the printer driver updating.

Note:

In Windows Vista/Server 2008, Update Driver... is also available. In Windows Vista/Server 2008, you can specify Update Driver... by opening Properties for this machine that is listed in Other Devices under Device Manager. To select Device Manager, right-click Computer and then click Properties. Select it in the Tasks pane that appears.

If the bit number differs between the server operating system and client operating system

If the bit number differs between the print server's running operating system and client computer's running operating system while Windows Server 2008/Server 2008 R2 is running on the print server, the additional driver may not be installed correctly on the print server.

Network Printing 72

Epson AcuLaser CX37 Series Reference Guide

To solve this problem, specify the setup information file (ntprint.inf) of the operating system with a different bit number when installing the additional driver on the print server.

The following describes how to install the additional driver by specifying a setup information file in a different computer from that the print server.

Note:

❏ Before starting this procedure, prepare to configure a different client computer from that of the print

server and install the operating system that has a bit number different from that of the print server.

❏ On the print server side, the system drive of the client computer is assigned as the network drive.

Configure the setting to share the drive to be assigned in advance.

Installing the Additional Driver

As an example, the following procedure describes the operations performed when Windows Server 2008 (32 bits) is running on the print server and Windows Vista (64 bits) is running on the client computer.

1. Specify the client computer (64 bits) drive installed with the operating system (normally, drive C) as a shared drive.

Note:

This setting is available for only PostScript driver.

2. From the print server (32 bits), map the client computer (64 bits) drive (for example, “C”), specified as a shared drive in step 1, as a network drive (for example, “z”).

Note:

This setting is available for only PostScript driver.

3. Install on the print server (32 bits) the driver for a 32-bit operating system.

4. Right-click the printer that was installed, and then click the appropriate menu command to display printer properties.

5. Select the Sharing tab, and then select the Share this printer check box.

6. Click Additional Drivers.

The Additional Drivers dialog box appears.

Network Printing 73

Epson AcuLaser CX37 Series Reference Guide

7. Under Processor, select the x64 check box, and then click OK.

8. Specify the folder containing the driver for a 64-bit operating system.

A dialog box appears, requesting the location of the setup information file.

9. Click Browse, and then select the setup information file (ntprint.inf) on the client computer mapped as a network drive.

Note:

This setting is available for only PostScript driver.

❏ Specify the file at the following path.z:\Windows\System32\DriverStore\FileRepository

\ntprint.inf_xxx

❏ In the path mentioned above, “z” indicates the mapped network drive. In addition, the

characters indicated by “_xxx” at the end may differ depending on the driver version.

❏ Depending on the client computer being used, the setup information file may be stored in a

different location. If there is a folder named “amd64” at the same level as “ntprint.inf”, specify the setup information file for a 64-bit operating system located within that folder. In addition, if the driver for a 32-bit operating system is to be installed, specify the setup information file in the folder named “I386” at the same level as “ntprint.inf”.

10. Click Open.

The installation begins.

11. After the installation is completed, click Close.

This completes the installation of the driver for a 64-bit operating system onto the print server (32 bits).

Network Printing 74

Troubleshooting

Symptom Action

Epson AcuLaser CX37 Series Reference Guide

Some client functions are not available with the Point and Print feature when the server is running Windows Server 2003/ Server 2008 / Windows Server 2008 R2 and the client computer is running Windows XP/Vista/7.

Install the printer driver directly on the client computer.

Network Printing 75

Epson AcuLaser CX37 Series Reference Guide

Chapter 6

Using Web-Based EpsonNet Config

Note:

The names of setting items for Web-Based EpsonNet Config may vary depending on your printer model.

About Web-Based EpsonNet Config

This chapter provides information on Web-Based EpsonNet Config, an HTTP (HyperText Transfer Protocol)-based web page that resides in your printer and that you can access using your Web browser.

This page gives you instant access to printer status and the most frequently used printer configuration options. Anyone on your network can access the printer using their web browser software. In addition, with the proper password, you can change the configuration of the printer without leaving your PC.

Note:

Users who are not given passwords by the administrator can still view the configuration settings and options but are not able to save or apply changes.

Display Language

The language used in the Web-Based EpsonNet Config screens is specified from the printer’s control panel. For details, refer to the Printer/Copier/Scanner User’s Guide.

Using Web-Based EpsonNet Config 76

Epson AcuLaser CX37 Series Reference Guide

In addition, the language can be selected from the Language drop-down list in Web-Based EpsonNet Config. For details, refer to “Language Setting” on page 84.

Requirements

To use Web-Based EpsonNet Config, the following is required:

❏ Windows Server 2008/Server 2008 R2/Server 2003/7/Vista/XP

Mac OS X 10.3.9 or later Red Hat Enterprise Linux 5, SUSE Linux Enterprise 5

❏ Microsoft Internet Explorer version 6.0 or later

Mozilla Firefox version 3.0 or later

Note:

You do not need an Internet connection.

❏ TCP/IP communication software (used by Web-Based EpsonNet Config) installed on your PC

❏ A network, to which both your PC and the printer are connected

Note:

You cannot access Web-Based EpsonNet Config using a local (USB) connection.

When connecting with Windows Server 2008/Server 2008 R2

When Web-Based EpsonNet Config is started on a computer running Windows Server 2008/Server 2008 R2, only the System tab may appear, and the Job, Print and Network tabs may not. In this case, Java must be installed, and the security settings must be specified according to the following procedure.

Note:

Before using Web-Based EpsonNet Config, be sure to close all Internet Explorer windows.

1. Click the Start button.

2. Point to Administrative Tools, and then click Server Manager.

Note:

If the User Account Control dialog box appears, click the Continue button or the Yes.

Using Web-Based EpsonNet Config 77

Epson AcuLaser CX37 Series Reference Guide

3. In the Server Manager main window, select Configure IE ESC in the Security Information section.

4. Set both Off for Administrators and Off for Users.

5. Click the OK button.

Setting Up the Printer Web Page

Setting up the printer web page to run on your network involves two basic steps:

❏ Determining the name or address of your printer

❏ Setting up the “no proxy” preferences in your browser software

Determining the Printer Name

The printer web page can be accessed in two ways:

❏ Through the assigned name of the printer—This name comes from the IP host table (the filename

is hosts) on the computer system and is usually assigned by the system administrator (for example, Epson AcuLaser CX37). It may be more convenient for you to use the printer name than the IP address.

Location of the Host Table on the PC

Windows Server 2008/Server 2008 R2/Server 2003/XP/Vista/7 \windows\system32\drivers\etc\hosts

❏ Through the printer’s IP address—The IP address of your printer is a unique number and,

therefore, may be the preferred identification to enter, especially if you have more printers active in your network. The printer’s IP address is listed on the configuration page.

Location of the Configuration Page in the Printer’s Configuration Menu

❏ REPORT/STATUS - REPORT - CONFIGURATION PAGE menu

Using Web-Based EpsonNet Config 78

Epson AcuLaser CX37 Series Reference Guide

Setting Up Your Browser Software

Since your printer resides on your intranet and is not accessible beyond the firewall of your network, you must set up the proper “preferences” in your browser software. Your printer name or IP address must be added to the “no proxy” list in the preferences dialog box of the browser.

Note:

You need to do this procedure only once.

The sample screens below may be different from yours depending on software versions and operating systems in use.

Note:

Our examples represent the IP address of the printer with: xxx.xxx.xxx.xxx. Always enter your printer’s IP address without leading zeros. For example, 192.168.001.002 should be entered as 192.168.1.2.

Internet Explorer (version 6.0 for Windows)

1. Start Internet Explorer.

2. From the Tools menu choose Internet Options.

3. Select the Connections tab on the dialog box.

4. Choose the LAN Settings button to display the Local Area Network (LAN) Settings dialog box.

5. Select Advanced in Proxy server to open the Proxy Settings dialog box.

Using Web-Based EpsonNet Config 79

Epson AcuLaser CX37 Series Reference Guide

6. In the Exceptions text box, type a comma after the last entry and then type the printer name or the IP address of your printer.

7. Choose OK three times to return to the main browser window.

8. Enter the printer’s IP address in the URL Address box to access the printer home page.

Mozilla Firefox (version 3.6 for Mac OS X 10.6)

1. Start Mozilla Firefox.

2. From the Firefox menu choose Preferences.

3. Click Advanced at the top of the dialog box.

4. Click the Network tab.

5. In the Connection section, click Settings. The Connection Settings dialog box appears.

Using Web-Based EpsonNet Config 80

Epson AcuLaser CX37 Series Reference Guide

6. Select the Manual proxy configuration radio button.

7. In the No Proxy for: text box, type a comma after the last entry, and then type the printer name or the IP address of your printer.

8. Click OK in the two dialog boxes to return to the main browser window.

9. Enter the printer name or IP address in the URL Location box to access the printer home page.

Using Web-Based EpsonNet Config 81

Epson AcuLaser CX37 Series Reference Guide

Understanding the Web-Based EpsonNet Config Window

The illustration below identifies the navigation and configuration areas of the windows that you see in Web-Based EpsonNet Config windows.

1. Current status

2. Links to main topics

3. Printer name

4. Configuration area

5. Links to subtopics

6. Click to log out of current mode

Navigation

Selecting the main topic and subtopic displays the configuration area for the printer options (parameters) associated with your selections.

Using Web-Based EpsonNet Config 82

Epson AcuLaser CX37 Series Reference Guide

To change a current setting, click on the current setting and then select from the available choices or enter the new value.

Note:

In order to apply or save any changes made to the configuration settings, Web-Based EpsonNet Config must be logged in from Administrator Mode. (For details, refer to “Administrator Mode” on page 85.)

Current Status

The current status of the printer is displayed at the top of all Web-Based EpsonNet Config windows. The icon displays the type of status being displayed.

Icon Status Description Examples

Ready The printer is online and either

ready to print or printing.

Warning The printer needs attention,

but printing continues.

Error The printer needs attention

before printing can resume.

Fatal Error The printer must be rebooted.

If that doesn’t fix the error, service is required.

READY PRINTING

PLEASE WAIT WARMING UP

FUSER JAM FRONT COVER OPEN

MACHINE TROUBLE SERVICE CALL

Logging on to Web-Based EpsonNet Config

Login Page

User authentication and language settings can be specified by using Web-Based EpsonNet Config. In order to perform authentication, you must log on in Administrator Mode. For details on authentication, refer to “Authentication” on page 107 and “User Authentication” on page 188.

Using Web-Based EpsonNet Config 83

Epson AcuLaser CX37 Series Reference Guide

Note:

A total of 100 users, including the administrator, can be logged on to Web-Based EpsonNet Config at the same time from client computers. In addition, public users, registered users, and the administrator can be logged on at the same time. However, only 1 client can be logged on as the Administrator.

Language Setting

If necessary, the display language used for Web-Based EpsonNet Config can be changed.

Public User Mode

In Public User Mode, you can view configuration settings but not change them.

1. Select Public User.

2. Click the Log in button.

Registered User Mode

In Registered User Mode, you can view configuration settings but not change them.

User Authentication Mode

Note:

To enter User Authentication Mode, log on in Administrator mode, set User Authentication (in the Network - Authentication - User Authentication page) to On, and then register a new user in the System Authentication - User Registration - New Registration page. For details, refer to “User Registration” on page 108 and “User Authentication” on page 188.

1. Select Registered User.

2. Type in the user name and user password in the User Name and User Password text boxes.

3. Click the Log in button.

Using Web-Based EpsonNet Config 84

Epson AcuLaser CX37 Series Reference Guide

Administrator Mode

In order to change any configuration settings through Web-Based EpsonNet Config, you must first enter Administrator Mode.

1. Select Administrator.

2. Click the Log in button.

3. Type the password in the Admin Password text box.

Note:

Default password is set to “administrator”; however, once you have logged on in Administrator Mode, the password can be specified in the System - Admin Password window.

4. Click OK button.

Viewing Printer Status

System Page

On this page you find printer status and current configuration settings, printer identification, and links to all other web pages.

Note:

All of the information displayed on the System page is read only.

Device Information

Summary

Item Description

Copier RAM Displays the amount of copier memory installed in the printer.

Printer RAM Displays the amount of printer memory installed in the printer.

HDD If an optional hard disk drive is installed in the printer, displays the size of the hard

disk.

Memory Card This item is not supported by this printer.

Using Web-Based EpsonNet Config 85

Item Description

Duplex Identifies whether the duplex unit is installed on the printer.

Paper Source Identifies the paper feed units installed on the printer.

Output Tray Identifies the output tray installed on the printer.

Network Lists the installed printer interface (Ethernet 10Base-T/100Base-TX/1000Base-T).

Paper Source

Item Description

Paper Source Identifies the paper feed units Tray1/2/3 installed on the printer.

Paper Size Indicates the size of paper loaded in a specific tray.

Epson AcuLaser CX37 Series Reference Guide

Note: Tray3 appears only if the optional 500-sheet paper cassette unit is installed.

Paper Type Indicates the type of paper loaded in a specific tray.

Paper Indicates the paper status (“Ready” or “Empty”) for each tray.

Detail button Displays detailed information about the paper trays.

Paper Source (Detail)

Item Description

Paper Source Displays the names of the paper trays.

Paper Size Displays the paper sizes.

Paper Type Displays the paper types.

Capacity Displays the maximum capacity for each paper tray.

Paper Displays the amount of paper remaining.

Back button Returns to the previous screen.

Output Tray

Item Description

Tray Displays the name of the output tray.

Paper Displays the status (Ready, Full) of the output tray.

Using Web-Based EpsonNet Config 86

Storage

Epson AcuLaser CX37 Series Reference Guide

Item Description

Total Displays the total amount of space on the hard disk.

If no optional storages are installed, “-” are displayed.

Used Displays the amount of space on the hard disk that is used.

If no optional storages are installed, “-” are displayed.

Remaining Displays the amount of space remaining on the hard disk.

If no optional storages are installed, “-” are displayed.

Using Web-Based EpsonNet Config 87

Interface Information

Item Description

Epson AcuLaser CX37 Series Reference Guide

Protocol Information

TCP/IP

IPv6

Bonjour

FTP TX

FTP Server

LDAP

SMB

Dynamic DNS

IPP

LPD

RAW Port

SLP

SMTP

SNMP

If Enable is displayed, TCP/IP is enabled.

If Enable is displayed, IPv6 is enabled.

If Enable is displayed, Bonjour is enabled.

If Enable is displayed, FTP transmission is enabled.

If Enable is displayed, FTP server function is enabled.

If Enable is displayed, LDAP server is enabled.

If Enable is displayed, SMB is enabled.

If Enable is displayed, Dynamic DNS is enabled.

If Enable is displayed, IPP is enabled.

If Enable is displayed, LPD is enabled.

If Enable is displayed, RAW Port is enabled.

If Enable is displayed, SLP is enabled.

If Enable is displayed, SMTP is enabled.

If Enable is displayed, SNMP is enabled.

WSD Print

LLTD

LLMNR

AppleTalk

NetWare

IEEE802.1x

If Enable is displayed, WSD Print is enabled.

If Enable is displayed, LLTD is enabled.

If Enable is displayed, LLMNR is enabled.

If Enable is displayed, AppleTalk is enabled.

If Enable is displayed, NetWare is enabled.

If Enable is displayed, IEEE802.1x is enabled.

Using Web-Based EpsonNet Config 88

Item Description

Epson AcuLaser CX37 Series Reference Guide

Network Information

Type Identifies the type of network interface installed on the printer

(Ethernet 10Base-T/100Base-TX/1000Base-T).

Ethernet Speed Indicates the transmission speed for the network and the

transmission method for bidirectional transmission.

IP Address Identifies the IP (Internet Protocol) address of the Ethernet interface.

IPv6 Link Local Address Identifies the IPv6 link local address of the Ethernet interface.

IPv6 Global Address Identifies the IPv6 global address of the Ethernet interface.

MAC Address Identifies the Media Access Control (MAC) address of the Ethernet

interface.

Host Name Identifies the host name for the printer.

Print Server Name (NetWare)

Printer Name (Apple Talk) Identifies the printer name on AppleTalk.

Current Zone Name (AppleTalk)

Bonjour Name Displays the Bonjour name for the printer.

Identifies the Print Server Name for the NetWare.

Identifies the Current Zone Name for the AppleTalk.

WSD Printer Name Displays the WSD printer name for the printer.

Consumables and Maintenance

Item Description

Consumables and Maintenance Identifies the type of consumables or maintenance parts that are being

Status Indicates the remaining life of the consumables or maintenance parts.

TYPE Identifies the type of Toner Cartridge.

Counter

Item Description

Total Print Indicates the total number of all printed pages.

Total Scan Indicates the total number of pages that have been scanned.

monitored.

Using Web-Based EpsonNet Config 89

Item Description

Normalized Total Faces Counter The number of printed pages is displayed calculated in terms of A4-size paper.

Fax Counter Indicates the total number of fax transmission and reception pages.

Scan Counter Indicates the total number of scanned pages.

Tray Counter Indicates the total number of pages for each tray setting.

Paper Size Counter Indicates the total number of pages for each paper size.

Paper Type Counter Indicates the total number of pages for each paper type.

Application Counter Indicates the total number of pages for each application.

Online Assistance

Item Description

Epson AcuLaser CX37 Series Reference Guide

Contact Name Displays the organization that responsible for providing assistance with the

printer.

Contact Information Displays the web site address for assistance.

Product Help URL Displays the help web site address for assistance.

Corporate URL Displays the Seiko Epson web site address.

Supplies and Accessories Displays the web site address where you can purchase printer supplies and

accessories.

Contact Phone Number Displays the telephone number of the printer administrator.

Contact Address Displays the e-mail address for support.

Contact Utility Link Displays a link to the Printer Management Utilities.

User Authentication

Note:

This page appears only when logged on to Registered User Mode.

User Password Change

Item Description

User Name Shows the name of user who is logged on.

Using Web-Based EpsonNet Config 90

Epson AcuLaser CX37 Series Reference Guide

Item Description

Current Password Type in the current password for the user who is logged on.

Range: Up to 64 characters

New Password Type in the new password.

Range: Up to 64 characters

Retype New Password Type in the new password again for confirmation.

Range: Up to 64 characters

Apply button Applies the new password.

Note:

If the password typed in three text boxes doesn’t match, the following message displays when you choose the Apply button: “Password was changed unsuccessfully. Please retry.” Retype the passwords in both text boxes.

Clear button Resets all configuration settings to previous values.

Registration Information

Item Description

Registration User Information Shows the registration number (No.), user name for the user who is logged on.

Function Permission Information Shows whether printing is permitted by the user who is logged on.

Output Permission Information Shows whether color printing and whether black-and-white printing is

permitted by the user who is logged on.

Job Page

This page allows you to view the status of current print jobs.

Active Job List

Item Description

Job Number Displays the print job identification number. Each print job that the printer

receives is assigned a unique identification number.

User Name If known, displays the owner of the print job.

File Name Displays the name of the print file.

Using Web-Based EpsonNet Config 91

Item Description

Job Status Displays the current status of the print job (Parsing, Printing, Cancel, Pending, or

Create Time Displays the time that the job was queued.

Delete button Deletes the print job(s) that applies to the checked boxes.

Done Job List

Item Description

Job Number Displays the print job identification number. Each print job that the printer

User Name If known, displays the owner of the print job.

File Name Displays the name of the print file.

Epson AcuLaser CX37 Series Reference Guide

Abort).

receives is assigned a unique identification number.

End Time Displays the time that printing finished.

Result Displays the result of the print job.

Detail button Displays a screen containing details.

Done Job List (Detail)

Item Description

Job Number Displays the print job identification number. Each print job that the printer

User Name If known, displays the owner of the print job.

File Name Displays the name of the print file.

Delivery Type Displays the delivery method for the job (Print, Print and Hold, Proof then Print,

Create Time Displays the time that the job was queued.

End Time Displays the time that printing finished.

Result Displays the result of the print job.

receives is assigned a unique identification number.

IPP Print, Secured Job, Time Print, Report Print or PC-FAX).

Back button Returns to the previous screen.

Using Web-Based EpsonNet Config 92

Epson AcuLaser CX37 Series Reference Guide

Print Page

This page allows you to check the settings for printing when there is no PDL printer driver.

Default Settings

General Settings

Item Description

PDL Indicates default language to be selected.

Paper Source The paper tray that is normally used is indicated.

Duplex

Output Tray Displays the name of the output tray.

Copies Indicates the default setting for number of copies to be printed.

Paper Size Indicates the default setting for the size of paper.

Width

Length

Paper Type Indicates the default setting for the type of paper.

Collate

If Long-Edge Binding is indicated, the pages will be printed on both sides of the paper for long-edge binding.

If Short-Edge Binding is indicated, the pages will be printed on both sides of the paper for short-edge binding.

Indicates the paper width when Paper Size is set to Custom Size.

Indicates the paper length when Paper Size is set to Custom Size.

If On is indicated, all pages in a copy of the document can be printed before printing the next copy.

If Off is indicated, all copies of the document are not printed separately.

Note:

This menu item appears only if an optional hard disk drive is installed.

Using Web-Based EpsonNet Config 93

Paper Source Settings

Item Description

Tray1 Paper Size Indicates the setting for the size of paper loaded into

Tray2 Paper Size Indicates the setting for the size of paper loaded into

Epson AcuLaser CX37 Series Reference Guide

Tray1.

Width Indicates the paper width when Paper Size is set to

Custom Size.

Length Indicates the paper length when Paper Size is set to

Custom Size.

Paper Type Indicates the setting for the type of paper loaded into

Tray1.

Tray2.

Width Indicates the paper width when Paper Size is set to

Custom Size.

Tray3

This item appears only if an optional 500-sheet paper cassette unit is installed.

Length Indicates the paper length when Paper Size is set to

Custom Size.

Paper Type Indicates the setting for the type of paper loaded into

Tray2.

Paper Size Indicates the setting for the size of paper loaded into

Tray3.

Paper Type Indicates the setting for the type of paper loaded into

Tray3.

Using Web-Based EpsonNet Config 94

Epson AcuLaser CX37 Series Reference Guide

Item Description

Any Tray Setting Tray1 Paper Size Indicates whether Any Paper Size setting for Tray1 is

enabled or disabled.

Paper Type Indicates whether Any Media Type setting for Tray1 is

enabled or disabled.

Tray2 Paper Size Indicates whether Any Paper Size setting for Tray2 is

enabled or disabled.

Paper Type Indicates whether Any Media Type setting for Tray2 is

enabled or disabled.

Tray Chaining

Tray Mapping Settings

Item Description

Tray Mapping Mode

Logical Tray 0-9 Indicates the tray that is used for printing when a print job is received from

Tray3

This item appears only if an optional 500-sheet paper cassette unit is installed.

Paper Type Indicates whether Any Media Type setting for Tray3 is

enabled or disabled.

If Enable is indicated and the specified paper tray runs out of paper during printing, a paper tray loaded with paper of the same size is automatically selected so printing can continue.

If Disable is indicated and the specified paper tray runs out of paper, printing stops.

If On is indicated, Tray Mapping function is used.

another manufacture’s printer driver.

PCL Settings

Item Description

Font Number Displays the default font in the PCL language.

Symbol Set Displays the symbol set used with the PCL language.

Lines Per Page Indicates how many lines are in a page in PCL language.

Font Point Size Displays the font size in the PCL language.

Using Web-Based EpsonNet Config 95

Item Description

Font Pitch Size Displays the font pitch in the PCL language.

CR/LF Mapping Indicates CR/LF code definition in PCL language.

PS Settings

Item Description

Wait Timeout Indicates Postscript timeout. “0” means that no time-out control is effective.

PS Protocol Displays the settings for the PS protocol.

Print to PS Error Displays whether or not error printing is performed.

Auto Trapping Select this option to superimpose neighboring colors to print so as to prevent

Black Overprint You can specify to cause the overlapping on the characters alone or on characters

Epson AcuLaser CX37 Series Reference Guide

white space being generated around a picture.

and figures.

XPS Settings

Item Description

Digital Signature Shows whether XPS digital signatures are enabled or disabled.

Print to XPS Error Shows whether or not error information is printed when an error has occurred

during XPS printing.

Using Web-Based EpsonNet Config 96

Print Quality Settings

Item Description

Epson AcuLaser CX37 Series Reference Guide

Print Quality Settings

Color Mode

Color Separation

Brightness Indicates the brightness of the printed image.

Halftone (Image Printing/Text Printing/Graphics Printing)

Edge Enhancement (Image Printing/Text Printing/ Graphics Printing)

Edge Strength Shows the setting for the amount that edges are emphasized.

Economy Print Mode Shows the setting for whether or not Economy Print Mode is

If Color is indicated, the pages are printed in full color.

If Monochrome is indicated, the pages are printed in black and white.

If On is indicated, color separation is performed.

Indicates how halftones are reproduced.

If Line Art is indicated, halftones are reproduced with high precision.

If Detail is indicated, halftones are reproduced with detail.

If Smooth is indicated, halftones are reproduced with smoothness.

Shows the settings for whether or not edges are emphasized in images, text and graphics.

enabled. When Economy Print Mode is enabled, the amount of toner used is reduced when printing many drawings.

PCL Settings Contrast Indicates the contrast of the image.

Image Printing/Text Printing/ Graphics Printing (Source)

Image Printing/Text Printing/ Graphics Printing (Intent)

Image Printing/Text Printing/ Graphics Printing (Gray Treatment)

Identifies the color space for RGB data.

I nd i c a te s t he c o lo r i nt e n t to b e us e d o n c o n ve r s io n R G B t o C MY K by printer.

Indicates the method to reproduce RGB black and gray.

Using Web-Based EpsonNet Config 97

Item Description

Epson AcuLaser CX37 Series Reference Guide

PS Settings Image Printing/Text Printing/

Graphics Printing (RGB Source)

Image Printing/Text Printing/ Graphics Printing (RGB Intent)

Image Printing/Text Printing/ Graphics Printing (RGB Gray Treatment)

Image Printing/Text Printing/ Graphics Printing (Destination Profile)

Simulation (Profile) Indicates the specific ICC simulation profile to be used for

Simulation (Intent) Indicates the simulation intent to be used for simulation

Simulation (CMYK Gray Treatment)

Calibration Settings

Tone Calibration

Cyan Density/Magenta Density/Yellow Density/Black Density (Highlight)

Identifies the color space for RGB data.

I nd i c a te s t he c o lo r i nt e n t to b e us e d o n c o n ve r s io n R G B t o C MY K by printer.

Indicates the method to reproduce RGB black and gray.

Indicates the ICC destination profile to be used for printed output.

printed output.

printing.

Indicates the method to reproduce CMYK black and gray for simulation printing.

If On is indicated, image adjustments are applied.

Indicates the density of the highlight color.

Font/Form

PCL Font

Item Description

Number Displays the control number of the font.

Font Name Displays the name of the fonts.

Source Displays the storage source of the font.

Cyan Density/Magenta Density/Yellow Density/Black Density (Middle)

Cyan Density/Magenta Density/Yellow Density/Black Density (Shadow)

Indicates the density of the middle color.

Indicates the density of the shadow color.

Using Web-Based EpsonNet Config 98

PS Font

Item Description

Number Displays the control number of the font.

Font Name Displays the name of the fonts.

Source Displays the storage source of the font.

Form Overlay

Item Description

Number Displays the control number of the overlay.

File Name Displays the name of the overlays.

Source Displays the storage source of the form overlay.

Epson AcuLaser CX37 Series Reference Guide

Color Profile

Item Description

Number Displays the control number of the color profile.

File Name Displays the file name of the color profile.

Profile Name Displays the name of the color profile.

Class Displays the type of color profile.

Color Space Displays the color space for the color profile.

Source Displays the storage source of the color profile.

Report Types

Item Description

Configuration Page Prints the printer configuration page.

Utility Map Prints the printer utility map page.

PS/PCL Menu Map Page Prints the printer PS/PCL menu map page.

PCL Font Page Prints the PCL font lists.

PS Font Page Prints the PostScript font lists.

Using Web-Based EpsonNet Config 99

Epson AcuLaser CX37 Series Reference Guide

Item Description

Directory Listing Page Prints the directory list.

Note:

This menu item appears only if an optional hard disk drive is installed.

Print button Sends the page to the printer.

Clear button Cancels the selected settings.

Direct Print

Note:

❏ This page appears only if an optional hard disk drive is installed.

❏ This page appears when both Public Access (in the Network - Authentication - User Authentication

page) and Print (in the System - Authentication - Default Permission Settings) are set to Allow.

❏ The following file formats can be printed using direct printing: PDF, TIF, and JPEG.

Item Description

File Name Specify the location of the file to be printed.

Click Browse, and then select the file.

Browse button Displays a dialog box for browsing to the file to be printed.

Send button Sends the specified file to the printer.

Scan Page

This page allows you to view the currently specified dial settings.

Favorite

Item Description

No. Displays the number in the Favorite list.

Name Displays the destination name of the selected speed dial number.

Address Displays the address (fax number, e-mail address, FTP address or SMB address) of

the speed dial number.

Using Web-Based EpsonNet Config 100

Epson CX37DNF User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright Notice

Software License Agreement

About Adobe Color Profile

ICC Profile for TOYO INK Standard Color on Coated paper (TOYO Offset Coated 2.1)

DIC STANDARD COLOR PROFILE LICENSE AGREEMENT

OpenSSL Statement

LICENSE ISSUES

Original SSLeay License

NetSNMP License

Part 1: CMU/UCD copyright notice: (BSD like)

Part 2: Networks Associates Technology, Inc copyright notice (BSD)

Part 3: Cambridge Broadband Ltd. copyright notice (BSD)

Part 4: Sun Microsystems, Inc. copyright notice (BSD)

Part 5: Sparta, Inc copyright notice (BSD)

Part 6: Cisco/BUPTNIC copyright notice (BSD)

Kerberos

WPA Supplicant

Contents

Operation on Linux

System Requirements

Installing PPD File From the Command Line

Adding the Printer Using Printer configuration

Adding the Printer on the CUPS Administration Web page

Specifying Printer Driver Settings

Displaying the Settings Page

Printer Driver Settings

Printing a Document

Example Using OpenOffice

Checking Print Jobs

Troubleshooting

Operation on NetWare

Printing With NetWare

Network Printing in a NetWare Environment

For Remote Printer Mode With NetWare 4.x Bindery Emulation

For Print Server Mode With NetWare 4.x Bindery Emulation

For NetWare 4.x Remote Printer Mode (NDS)

For NetWare 4.x/5.x/6 Print Server Mode (NDS)

For NetWare 5.x/6 Novell Distributed Print Service (NDPS)

Setting Up a Client (Windows) Settings When Using the NetWare Server

Using Local Setup Program (for Epson AcuLaser CX37DNF only)

About Local Setup Program (LSP)

LSP Operating Environment

Installing LSP

Starting Up LSP

Main LSP Window

Connecting to the Machine

Downloading Information from the Machine

Uploading Information to the Machine

Dial Import/Dial Export

Settings for dial destination

Programming a Speed Dial Number

Adding a Speed Dial Number (Fax/E-mail)

Adding a Speed Dial Number (Scan To Server)

Editing a Speed Dial Number

Deleting a Speed Dial Number

Programming/Editing a Group Dial

Registering to Favorites

Printing the List of Speed Dial, Group Dial and Favorite

Displaying Machine Information

Checking the Total Counter

Checking the Configuration Page

Uninstalling LSP

Troubleshooting

Understanding the Network Setting Menu

NETWORK SETTING Menu

Location within the Configuration Menu

Accessing the Network Setting Menu

Using the Network Setting Menu Options

Network Printing

Network Connection

Theory

Making the Connection

Printing via IPP (Internet Printing Protocol)

With Windows Server 2008/Server 2008 R2

Adding an IPP Port using Add Printer Wizard – Windows Server 2003/XP

Adding an IPP Port using Add Printer Wizard – Windows Vista/7/Server 2008/ Server 2008 R2
